Monogram ZIK30GNHAII User manual

Owner’s
Manual
30”Built-In
Bottom-Freezer
2-Drawer
Refrigerator
monogram.com
Réfrigérateurs
Congélateurinférieur
Refrigeradores
Congeladorinferior
Manuel d’utilisation
Owner’s Manual
Manual del propietario
La section française commence à la page 25
La sección en español empieza en la página 49
See content section page 2

Consumer Information
30” Bottom-Freezer
2
Contents
Consumer Services
Important Phone Numbers ....................23
Model and Serial Numbers.......................3
Performance Data Sheet ......................19
ProblemSolver.............................17,18
Safety Instructions............................4,5
State of California Water
Treatment Device Certificate...................20
Warranty..............................BackCover
Care and Cleaning
&OHDQLQJ³2XWVLGHDQG,QVLGH ..................14
Light Bulb Replacement .......................15
Vacation ......................................15
Operating Instructions
Features.........................................6
Automatic Icemaker.............................8
Customizable Drawer..........................11
Door Bins......................................11
ExternalMoistureControl......................12
LEDDisplay Lighting ...........................12
Sabbath Mode.................................13
Shelves........................................10
TemperatureControls...........................7
Vegetable Pan.................................10
WaterFilter......................................9
Wine/BeverageRack..........................11
Preparation
Clearances ....................................16
Location.......................................16
Before
using
your
refrigerator
Read this manual carefully. It is intended
to help you operate and maintain your new
refrigerator properly.
Keep it handy for answers to your questions.
If you don’t understand something or
need more help, there is a list of toll-free
consumer service numbers included in
the back section of this manual.
OR
Visit our Website at: monogram.com
In Canada: monogram.ca
Introduction
Your new Monogram Refrigerator makes an eloquent statement of style, convenience and kitchen
planning flexibility. Whether you chose it for its purity of design or the assiduous details, you will find
that your Monogram Refrigerator’s superior blend of form and function will delight you for years to
come.
The information on the following pages will help you operate and maintain your Refrigerator properly.
If you have any other questions, visit our Website at: monogram.com In Canada: monogram.ca

3
Write
down the
model
& serial
numbers
You’ll see them on a label inside the fresh food
compartment, below the vegetable pan. Before sending in this card, please write these numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or
service calls concerning your refrigerator.
If you
received a
damaged
refrigerator
The warranty does not cover damage caused
after delivery. Immediately contact the dealer (or builder) that sold you the refrigerator.
Save time
& money
Before you request service, check the Problem
Solver in the back of this manual. It lists causes of minor operating problems that you can correct yourself.
If you
need
service
To obtain service, see the Consumer Services
page in the back of this manual.
We’re proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are steps to
follow for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all
WKHGHWDLOV³LQFOXGLQJ\RXUSKRQHQXPEHU³WR
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
In Canada:
Director, Consumer Relations
MC Commercial Inc
Suite 310, 1 Factory Lane
Moncton, N.B.
E1C 9M3
Consumer Information
30” Bottom-Freezer

4
,03257$176$)(7<,16758&7,216
READ AND SAVE THESE INSTRUCTIONS
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All
VDIHW\PHVVDJHVZLOOIROORZWKHVDIHW\DOHUWV\PERODQGWKHZRUG´'$1*(5µ´:$51,1*µRU´&$87,21µ7KHVHZRUGVDUH
defined as:
Indicates a hazardous situation which, if not avoided,will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,could result in minor or moderate injury.
WARNING
DANGER
CAUTION
This refrigeratormustbeproperly installedinaccordance
withthe Installation Instructionsbeforeit is used.
Unplug therefrigeratorbeforemaking repairs,replacinga
light bulb,orcleaning.
Note: Power totherefrigeratorcannot bedisconnectedby
any settingonthe controlpanel.
Note: Repairs mustbeperformedby aqualifiedService
Professional.
Do nottrytoreplace aburned-outLED light.Anauthorized
technicianwill need toreplacethe LED lights.
Replaceall parts andpanelsbefore operating.
Do notstoreoruse gasolineorother flammablevaporsand
liquids inthevicinity ofthisor anyotherappliance.
Because ofpotentialsafetyhazards undercertain
conditions, westronglyrecommendagainst theuseof an
extensioncord. However,ifyou mustusean extensioncord,
it isabsolutelynecessarythat itbea UL-listed(inthe United
States) oraCSAcertified (inCanada),3-wire groundingtype
appliance extensioncordhavinga groundingtypeplug
and outletandthatthe electricalratingof thecordbe 15
amperes(minimum) and 120volts.
Do notallowchildrento climb,standor hangonthe door
bins intherefrigerator.They coulddamagethe refrigerator
andseriously injure themselves.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, explosion, electric shock, or injury when using your
refrigerator follow these basic safety precautions:
WARNING
REFRIGERATOR SAFETY INFORMATION
Do not clean glass shelves or covers with warm water when
they are cold. Glass shelves and covers may break if exposed
to sudden temperature changes or impact, such as bumping
or dropping. Tempered glass is designed to shatter into many
small pieces if it breaks.
Keep fingers out of the “pinch point” areas; clearances
between the doors and between the doors and cabinet are
necessarily small. Be careful closing doors when children are in
the area.
Do not touch the cold surfaces in the freezer compartment
when hands are damp or wet, skin may stick to these
extremely cold surfaces.
Do not refreeze frozen foods which have thawed completely.
In refrigerators with automatic icemakers, avoid contact with
the moving parts of the ejector mechanism, or with the heating
element that releases the cubes. Do not place fingers or hands
on the automatic ice making mechanism while the refrigerator
is plugged in.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of injury when using your refrigerator, follow these basic
safety precautions.
CAUTION
WARNING Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from refrigerator. Failure to do so can
result in fire, explosion, or death.
INSTALLATION
State of California Proposition 65 Warnings:
WARNING This product contains one or more chemicals known to the State of California to cause cancer and birth
defects or other reproductive harm.

5
All refrigeration products contain refrigerants, which under
federal law must be removed prior to product disposal. If you
are getting rid of an old refrigeration product, check with the
company handling the disposal about what to do.
WARNING R600a Refrigerant
This appliance contains isobutane refrigerant, R600a, a
natural gas with high environmental compatibility. However
it is also combustible. Please adhere to the warnings below:
1) When handling,installingandoperating theappliance,care
shouldbe taken toavoiddamage to therefrigeranttubing.
2) Servicing shallbeperformedby factory-authorizedservice
personnel andcomponentpartsshall bereplacedwith
manufacturer-authorizedreplacement components.
3)Refrigeration products contain refrigerants, which under
federal law must be removed prior to product disposal.
4) Keep ventilationopeningsinthe applianceenclosuresor in
thebuilt-in structure clearofobstruction.
5) Do notusemechanicaldevices orothermeans toaccelerate
thedefrosting process.
6) Donot damage refrigerantcircuit.
7) Do notuseelectricalappliances insidethefood storage
compartmentof the appliance.
,03257$176$)(7<,16758&7,216
CONNECTING ELECTRICITY
WARNING Electrical Shock Hazard.
Plug into a grounded 3-prong outlet
Do not remove the ground prong
Do not use an adapter
Failure to follow these instructions can result in death, fire, or electrical shock.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The powercordofthis applianceisequipped witha
3-prong (grounding)plugwhichmates withastandard
3-prong (grounding)walloutletto minimizethe
possibilityof electric shockhazardfrom this appliance.
Have thewalloutletand circuitcheckedby aqualified
electrician tomakesurethe outletisproperly
grounded.
Where astandard2-prongwall outletisencountered,
it isyourpersonalresponsibility andobligationto have
it replacedwithaproperly grounded3-prongwall
outlet.Do not useanadapter.
The refrigeratorshouldalwaysbe pluggedintoits own
individual electricaloutletwhichhas avoltagerating
thatmatches the ratingplate.
A 115VoltAC,60 Hz,15-or 20-ampfused,grounded
electrical supplyisrequired.This providesthebest
performance andalsopreventsoverloading house
wiring circuitswhichcouldcause afirehazard from
overheatedwires.
Never unplugyourrefrigeratorby pullingonthe power
cord. Alwaysgripplugfirmly andpullstraight outfrom
theoutlet.
Repair orreplaceimmediatelyall powercordsthat
have becomefrayedorotherwise damaged.Donot
use acordthatshows cracksorabrasion damage
alongits length orateither end.
When movingtherefrigeratoraway fromthewall, be
carefulnot to rolloveror damage thepowercord.
PROPER DISPOSAL OF YOUR OLD REFRIGERATOR
REFRIGERANTS
WARNING Suffocation and child entrapment hazard.
Remove fresh-food and freezer doors from the refrigerator, prior to disposal. Failure to do so can result
in child entrapment which can lead to death or brain damage.
Child entrapmentandsuffocationare notproblems
of thepast.Junkedor abandonedrefrigeratorsare
still dangerousevenifthey willsitfor “justafew
days.” Ifyouaregetting ridofyour oldrefrigerator,
please followtheinstructionsbelow tohelpprevent
accidents.
Before You Throw Away Your Old Refrigerator:
Takeoff the door/drawers.
Leave theshelvesinplace sothatchildren maynot
easilyclimb inside.
IMPORTANT:

Icemaker
Customizable
Drawer
Freezer
Drawer
6
Features
30” Bottom-Freezer
Winerack
FreshFood
Shelves
FreshFood
DoorBins
VegetablePan
FreshFood
Section

7
Temperature
controls
Alarm
To turn the Alarm feature on, press and hold
the ALARM button for 3 seconds. ALARM will
be underlined when active. To turn off, press
and hold the ALARM button for 3 seconds.
The underline will disappear.
When the ALARM
is active, the alarm
will flash and beep
if you keep the door
open for more than 2
minutes.
Changing
display
temperatures
from °F to °C
To change the temperature display between
Fahrenheit and Celsius, press both the plus (+)
and minus (–) pads for 5 seconds.
The temperature display shows the actual
temperature of the fresh-food compartment,
freezer drawer or customizable drawer when
each one is selected by toggling the Zone
indicator. The actual temperature will vary from
the set temperature based on factors such as
frequency of door openings, amount of food,
defrost cycling and room temperature.
NOTE: Frequent door openings or doors left open
for periods of time may increase the internal
temperature of the compartments temporarily.
To turn off the cooling system, toggle the ZONE
indicator to the fresh-food mode. Press the plus
(+) pad until the display shows OFF.
To turn the cooling system on, toggle the ZONE
indicator to the fresh-food mode and press
the minus (–) pad until the desired temperature is
displayed. The preset temperature of 0°F for the
freezer or 37°F for the fresh-food unit will appear
in the display.
To check the current temperature setting for a
compartment, press the plus (+) or minus (–) pad
once. After 5 seconds, the display will return to
the actual temperature.
To change the temperature settings, press
the plus (+) or minus (–) pad for each increment
to the desired temperature set point. Allow
24 hours for the unit to reach the temperature
you have set.
Temperature Ranges
Low High
Fresh Food
Freezer
Drawer
Customizable Drawer Temperature Ranges
Low High
Freezer
Chill
Wine
NOTE: Setting the controls to OFF stops cooling,
but does not shut off electrical power to the unit.
All readings in °C will be rounded.
34°F
1°C 46°F 8°C
Temperature Controls
30” Bottom-Freezer
Fresh Food – Solid Door Unit
Fresh Food – Glass Door Unit
Upper Drawer – Freezer
Lower Drawer – Customizable
-6°F
–21°C
34°F
1°C
40°F
4°C
+6°F
–14°C
46°F
8°C
55°F
13°C
–6°F
–21°C +6°F –14°C

8
Automatic Icemaker (freezer models)
30” Bottom-Freezer
Automatic
icemaker
A newly installed refrigerator may take 12–24
hours to begin making ice. The refrigerator
LVVKLSSHGZLWKWKHLFHPDNHUVHWWR21
The icemaker will produce seven cubes per
F\FOH³DSSUR[LPDWHO\F\FOHVLQDKRXU
period, depending on freezer compartment
temperature, room temperature, number of
door openings and other use conditions.
If the refrigerator is operated before the water
connection is made to the icemaker, set the
icemaker to OFF7RVHWWKHLFHPDNHUWR2))
press the ZONE indicator on the control pad
twice to select the freezer drawer. Press the ICE
icon to the right. The line under ICE will disappear
and the word OFF will show under ICE.
Throw away the first full bucket of ice.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler arm,
the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale and shrink.
After the icemaker has been turned on again,
there will be a delay of about 45 minutes before
the icemaker resumes operations.
NOTE: In homes with lower-than-average
water pressure, you may hear the icemaker
water valve cycle on several times when
making one batch of ice.
NOTE: Icemaker works best between
40 and 120 PSI home water pressure.
CAUTION Avoid contact with the moving
parts of the ejector mechanism, or with the
heating element (located on the bottom of the
ice maker) that releases the cubes. Do not place
fingers or hands on the automatic ice making
mechanism while the refrigerator is plugged in.
Icemaker
FeelerArm
Accessing
the icemaker
and freezer
drawer
The icemaker is located on the ceiling of the
freezer drawer and to the left rear. There is
an LED strip in the freezer drawer ceiling. The
freezer drawer contains 1 ice bin.

The water filter cartridge is located below the
customizable drawer on the lower-right side of the
appliance.
To Replace the Filter:
There is a replacement indicator light for the
water filter cartridge on the control panel. The
filter cartridge should be replaced when the word
REPLACE appears beneath FILTER on the control
panel.
IMPORTANT: Filter is mandatory for ice production.
Installing the Filter Cartridge:
1. 2SHQWKHFXVWRPL]DEOHGUDZHUWRJDLQDFFHVVWR
the water filter cartridge.
2. Remove the old cartridge by twisting
counterclockwise. Pull forward on the filter
to remove.
3. Insert the new filter into the compartment and
twist clockwise until the cartridge stops.
To Reset the Filter Status Light:
Pressand hold theFILTER buttonfor3 seconds.
Replacement filters:
To order additional filter cartridges, visit
our Website at monogram.com, or call GE
Appliances Parts and Accessories, 877.959.8688.
Filter Model Number GSWF
IMPORTANT NOTE: Remove the water filter
to immediately stop any water leak from the
icemaker.
9
Water Filter
30” Bottom-Freezer
Water filter
cartridge
Water Filter
Cartridge
Child control
lockout
This child control lockout feature prevents
unwanted changes to your temperature settings. After the desired temperature is set, the temperature can be locked. To lock, press and
hold the LOCK button for 3 seconds. To unlock,
press and hold the LOCK button for 3 seconds.

Adjustable
shelves
Tempered glass shelves in the fresh food section
enable you to make efficient shelf arrangements
to fit your family’s food storage needs.
To adjust shelves: Tilt the shelf up at the front
and slide it up or down along the back wall to the
placement you want.
Handle glass shelves carefully. Rough handling
of tempered glass can cause it to shatter.
To remove shelves:
NOTE: To remove a shelf, all shelves under it must
first be removed.
1. Remove any food from the shelf
2. Remove covers at the bottom of each track.
3. Tilt the first shelf up at the front.
4. Slide the shelf down along the back wall until
you reach the bottom where the notch is
located. Slide the shelf through the notch.
10
Vegetable Pan/Shelves
30” Bottom-Freezer
Vegetable pan
The Vegetable Pan in the fresh-food section
of the refrigerator has LED strip lighting above
the drawer.
There are adjustable dividers with several
different position options. The divider is held in
place by a tab located under the handle, a slot
located on the back wall and a stabilizing rib on
the bottom of the drawer for each position.
To change the divider position:
1. Pull up on the back of the divider to release
it from the slot in the back and off of the tab
in the front.
2. Slide the divider into a new location, making
sure it seats into the rib on the bottom of
the drawer.
3. Pull up on the back of the divider to locate
the front under the tab at the new location.
Lighted
vegetable
drawer shelf
The lighted vegetable drawer shelf provides
lighting for the lower compartments. The lights
are recessed into the shelf to illuminate the
drawers below.
To remove the shelf:
1. Lift the shelf and carefully pull forward to
expose the wires.
2. Unplug the shelf and carefully remove it from
the refrigerator.
To replace the shelf:
1. Carefully set the shelf onto the side rails,
leaving the plug exposed.
2. Plug the shelf into the refrigerator.
3. Carefully slide the shelf into place.
Ribs
Tab Slot
Cover
LED lights are located
under the shelf at the front
Lighted
Vegetable
Drawer Shelf
Lift shelf and
pull forward
5. Repeat for removing the other shelves.
To replace shelves:
Replace shelves by perform steps 1 through 4
in reverse.
4. Push down on the back of the divider to seat
it into the slot at the new location.
Front
Back

11
Bins/Rack/Customizable Drawer
Door
bins
The door bins are removable. Lift bin out of the
bin bracket to remove.
The bin brackets are adjustable and can move
up and down to meet your storage needs.
Do this by tilting the bin up at the front and
sliding it up or down along the door to the
placement you desire.
30” Bottom-Freezer
Door Bin
Bin Bracket
Wine/
beverage rack
The wine/beverage rack fits onto one of the glass
shelves in the fresh-food compartment. The rubber
coating on the portions of the rack that sit on top of
the shelf keeps the rack from slipping or scratching
the shelf. The wine/beverage rack will hold 2-liter
bottles, wine bottles and champagne bottles.
Customizable
drawer
The customizable drawer can be used as
a freezer, as a fresh-food refrigerator or as
a wine/beverage drawer.
To customize your drawer:
Press the ZONE indicator on the control pad to
select the customizable drawer.
Recommended Temperatures for Customizable
Drawer:
This drawer has LED strip lighting above it. There
is also one adjustable divider that can be placed
in different positions and a bin that can slide left
or right in the drawer.
To change the divider position:
1. Pull in the tabs at the top of the divider to
release it from the tab holes at the front and
back of the drawer.
2. Lift the divider off of the raised tabs at the
bottom of the drawer.
3. Move the divider to its new location and slide it
onto the raised tabs.
4. Pull in the tabs at the top of the divider and
position the divider so the tabs will fit into the
tab holes. Release the tabs so they lock into
place.
Raised Tab Tab Hole
Divider
Chill
Freeze
Wine
Fresh Food
Freezer
Wine Storage
37°F/3°C
0°F/–18°C
55°F/13°C
Button Function Temperature
Removable sliding bin
Tab

12
External Moisture Control / LED Lighting
External
moisture
control
This product is equipped with an external moisture
control feature. The refrigerator is shipped with the
external moisture control feature off.
In some humid environments, moisture can form
on the front surface of the refrigerator cabinet.
If moisture does appear on the front surface
of the refrigerator cabinet, turn on the external
moisture control feature by pressing and holding
the ALARM and LOCK buttons on the control panel
for 5 seconds. When activated, a small picture of
a water droplet with a line through it will appear
below the (+) and (–) signs on the control panel.
30” Bottom-Freezer
LEDdisplay
lighting
This refrigerator has LED lighting on both sides of
the interior as well as above the freezer drawer
and above the customizable drawer.
Glass Door Models Only
The glass door models have a display light option
for the interior side lights: full power and 1/2
power.
In display mode at either full or 1/2 power, the
lights will stay on after the door is closed and
automatically go off after 1 hour.
To access the lighting options, press the ZONE
indicator on the control pad. In fresh-food mode,
the LIGHTS button is to the right on the control
pad. When lights are at full power, there are 2
bars under LIGHTS; at 1/2 power, there is 1 one
bar; when the lights are off, there are no bars.
Glass Door Model – Lights at Full Power
Glass Door Model – Lights at 1/2 Power
*ODVV'RRU0RGHO²/LJKWV2II

13
Sabbath Mode
Sabbath
Mode
The Sabbath Mode was designed for use on the
Jewish Sabbath and Holidays. The Sabbath Mode
feature makes it possible for observant Jews to
refrigerate and freeze food during the duration
of the holiday.
The Sabbath Mode feature can be set to override
typical reactions caused by your interaction
with the refrigerator. While in the Sabbath Mode,
your refrigerator will still operate. However, the
refrigerator will not respond to your actions.
While in the Sabbath Mode, you may notice
the fan running when the door is opened,
however, this is not a result of your actions.
The fan will operate at predetermined times.
The defrost heater will continue to defrost
the refrigerator and freezer and will be activated
on a timer. The defrost heater will not defrost
as a result of door openings or any consumer
actions.
212))³To activate the Sabbath Mode, hold
down the ALARM button and (+) pad on the
control panel for 5 seconds. SAB will be displayed
on the control. SAB will remain in the display and
the (+) pad and alarm button will remain lit until
the Sabbath mode is deactivated. Controls and
lights do not work until the ALARM button and
(+) pad are held again for 5 seconds.
',63/$<6$/$506DQG/,*+76³The main
temperature control displays will be deactivated,
therefore they will not be lit, sound a tone or
operate when touched. Door alarms and lights
will be disabled.
,&(0$.(5³The icemaker will continue
to operate. The icemaker can be disabled by
turning the icemaker OFF prior to the Sabbath
(see Automatic Icemaker).
30” Bottom-Freezer

14
Care and Cleaning
Cleaning
outside
'RRUKDQGOHVDQGWULP³Cleanwith acloth
dampenedwith soapy water.Drywith a softcloth.
Keep the outside clean. Wipewith a clean
cloth lightlydampenedwithmild liquiddish
detergent.Dry with aclean,soft cloth.
Do notwipetherefrigerator withasoiled dish
cloth orwettowel.These mayleavea residuethat
can damagethefinish.Do notusescouring pads,
powdered cleaners,bleachorcleaners containing
bleach becausetheseproductscan scratchand
damagethe finish.
6WDLQOHVVVWHHO³Thestainless steeldoorsand door
handles (onsomemodels)can becleanedwith
a commercially availablestainlesssteel cleaner.
Cleaners withoxalicacidsuch asBarKeepers Friend
Soft Cleanser™willremovesurface rust,tarnish,
and smallblemishes.Useonly aliquidcleaner free
of gritandrubin thedirectionofthe brushlineswith
a dampsoftsponge.Do notuseappliance waxor
polishon the stainlesssteel.
Custom Wood Panels - pleasecontact yourcustom
panelsupplier for directiononcleaning and care.
Cleaning
inside
Turn off power at the circuit breaker or fuse box
before cleaning. If thisisnotpractical, wringexcess
moisture outofspongeor clothwhencleaning
aroundswitches, lights orcontrols.
8VHZDUPZDWHUDQGEDNLQJVRGDVROXWLRQ³DERXW
a tablespoon(15ml)of bakingsodato aquart(1
liter) ofwater.Thisboth cleansandneutralizes
odors.Thoroughly rinse andwipedry.
2WKHUSDUWVRIWKHUHIULJHUDWRU³includingdoor
gaskets, vegetabledrawer,icestorage binsand
DOOSODVWLFSDUWV³FDQEHFOHDQHGWKHVDPHZD\
After cleaningthedoorgaskets, applyathin layer
of petroleumjellytothe doorgasketsat thehinge
side. Thishelpskeepthe gasketsfromsticking and
bending outofshape.
CAUTION Do not clean glass shelves
or covers with warm water when they are cold.
Glass shelves and covers may break if exposed
to sudden temperature changes or impact such
as bumping or dropping. Tempered glass is
designed to shatter into many small pieces if it
breaks.
Do not wash any plastic refrigerator parts in the
dishwasher.
30” Bottom-Freezer

Care and Cleaning
15
Preparing
for vacation
For long vacations or absences, remove food
from the refrigerator. Adjust the temperature up
(+) until the unit turns off. Clean the interior with
a baking soda solution of one tablespoon (15 ml)
of baking soda to one quart (1 liter) of water.
Leave the door open.
For shorter vacations, remove perishable foods
and leave the control at the regular setting.
However, if the room temperature is expected
to drop below 60°F (16°C), follow the same
instructions as for extended vacations.
Turn off the icemaker and shut off the water
supply to the freezer.
Interior Light
replacement
Do not try to replace a burned-out LED light.
An authorized technician will need to replace
the LED lights.
30” Bottom-Freezer

16
Preparation
Refrigerator
location
Do not install the refrigerator where
temperatures will be below 60°F (16°C) because
it will not run long enough to maintain proper
temperatures.
Do not install the refrigerator where the
temperature will go above 100°F (37°C) because
it will not perform properly.
Do not install the refrigerator in a location
exposed to water (rain, etc.) or direct sunlight.
Install the refrigerator on a floor strong enough
to support it fully loaded.
30” Bottom-Freezer
Clearances
Allow 15” minimum clearance between the door
and wall for a full 115° door swing. Allow 5”
min. clearance to a wall for a 90° door swing for
Monogram Stainless Steel (European) models.
4” distance to Wall.

The Problem Solver
Questions?
Use this
problem
solver!
PROBLEM POSSIBLE CAUSE
REFRIGERATOR SYSTEM •May be in defrost cycle when refrigerating system does not operate
DOES NOT OPERATE for about 45 minutes.
•Temperature control in the OFF position.
•If interior light is not on, refrigerator may not be plugged in at wall
outlet.
•The house fuse is blown/house circuit breaker is tripped. Replace fuse
or reset the breaker.
• Turn off the Sabbath Mode.
•If your control panel says SHO, then your showroom mode
was enabled. To turn this off, hold the ALARM button and (-) pad
simultaneously for 5 seconds.
•Normal when refrigerator is first plugged in. Wait 24 hours
for the refrigerator to completely cool down.
 2IWHQRFFXUVZKHQODUJHDPRXQWVRIIRRGDUHSODFHGLQUHIULJHUDWRU
This is normal.
•Door left open or package holding door open.
•Hot weather or frequent door openings. This is normal.
•Temperature control set at the coldest setting. See Temperature
Control.
VIBRATION OR RATTLING •Refrigerator may not be properly installed.
(Slight vibration – Anti-tip bracket may be loose.
is normal.) – Unit may not be level.
THUMPING SOUND • This is a normal operating sound.
WHEN CLOSING DOOR • Closing the door slowly will minimize the sound.
OPERATING •The variable speed compressor.
SOUNDS 1RUPDOIDQDLUIORZ³PXOWLSOHIDQVEORZFROGDLUWKURXJKWKHIUHVKIRRG
DQGIUHH]HUFRPSDUWPHQWV³RWKHUIDQVFRROWKHFRPSUHVVRU
• The fans change speeds in order to provide optimal cooling and
energy savings.
 7KHVH1250$/VRXQGVZLOODOVREHKHDUGIURPWLPHWRWLPH
– You may hear a whooshing or gurgling sound when the door closes.
This is due to pressure equalizing within the refrigerator.
– A water dripping sound may occur during the defrost cycle as ice
melts from the evaporator and flows into the drain pan.
– The flow of refrigerant through the freezer cooling coils may make a
gurgling sound like boiling water.
– Water dropping on the defrost heater can cause a sizzling, popping or
buzzing sound during the defrost cycle.
– You may hear cracking or popping sounds when the refrigerator is
first plugged in or during/after the defrost cycle. This happens as the
refrigerator cools to the correct temperature.
– The compressor may cause a clicking or chirping sound when
attempting to restart (this could take up to 5 minutes).
– The electronic control board may cause a clicking sound when relays
activate to control refrigerator components.
– Ice cubes dropping into the bin and water running in pipes as
icemaker refills.
– The icemaker water valve will buzz when the icemaker fills with water.
30” Bottom-Freezer
17
REFRIGERATING SYSTEM
OPERATES FOR LONG
PERIODS OR CYCLES ON
FREQUENTLY
(Modern refrigerators
and freezers with more
storage space and a
larger freezer require
more operating time.
They start and stop
often to maintain
even temperatures.)

18
PROBLEM POSSIBLE CAUSE
DOOR NOT CLOSING •Package or bottle may be holding door open.
PROPERLY • Check the door gasket; it may be out of position
• Refrigerator is not level. See Installation Instructions.
• Hinge springs deactived. See Installation Instructions.
REFRIGERATOR •Temperature control not set cold enough. See Temperature Control.
TOO WARM •Hot weather or frequent door openings.
•Door left open for long time.
•Package may be holding door open.
ACTUAL TEMPERATURE •Refrigerator just plugged in. Allow 24 hours for system to stabilize.
NOT EQUAL TO SET •Door open for too long. Allow 24 hours for system to stabilize.
TEMPERATURE •Warm food added to refrigerator. Allow 24 hours for system to stabilize.
•Defrost cycle is in process. Allow 24 hours for system to stabilize.
FROST OR ICE •Drawer left open or package holding door open.
CRYSTALS ON •Too frequent or too long door openings.
FROZEN FOOD •Drawer may have been left open.
(Frost within package •Ice cubes or some other object may be stuck behind the drawer.
is normal)
SLOW ICE CUBE •Drawer may have been left open.
FREEZING •Turn temperature control to a colder setting.
•Package may be holding drawer open.
ICE CUBES HAVE 2OGFXEHVQHHGWREHGLVFDUGHG
ODOR/TASTE •Ice storage bin needs to be emptied and washed.
•Unsealed packages in freezer may be transmitting odor/taste
to ice cubes.
•Interior of freezer needs cleaning. See Care and Cleaning.
•Poor-tasting incoming water. Change the water filter.
AUTOMATIC •Icemaker is turned off.
ICEMAKER •Water supply turned off or not connected.
DOES NOT WORK •Freezer too warm.
•Piled up cubes in storage bin may cause icemaker to shut off
too soon. Level cubes by hand.
•Ice bin is not in position.
•Clogged water filter.
•Reverse osmosis system installed.
MOISTURE FORMS •Not unusual during periods of high humidity. Wipe surface dry.
ON OUTSIDE OF •Turn on the External Moisture Control feature.
REFRIGERATOR
MOISTURE •Too frequent or too long door openings.
COLLECTS INSIDE •In humid weather, air carries moisture into refrigerator when doors
are opened.
•Lower drawer switched from (freezer) to chill or wine.
REFRIGERATOR •Foods with strong odors should be tightly covered.
HAS ODOR •Check for spoiled food.
•Interior needs cleaning. See Care and Cleaning.
INTERIOR LIGHTS •No power at outlet.
DO NOT WORK •LEDs need replacing. See Consumer Service Section.
•The Sabbath Mode may be operating. Turn off Sabbath Mode.
DOOR DIFFICULT TO •Tight door seal is due to pressure equalizing within the refrigerator.
REOPEN IMMEDIATELY After closing the door, wait 5–30 seconds to reopen.
AFTER CLOSING
The Problem Solver
30” Bottom-Freezer

19
Manufactured for:General Electric Company, Louisville, KY 40225
Performance Data Sheet
SmartWater Filtration System
GSWF Cartridge
This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below.
The concentration of the indicated substances in water entering the system was reduced to a concentration
less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.*
(100% safety factors built in for unmetered usage)
Standard No. 42: Aesthetic Effects
Parameter USEPA Influent Influent Challenge Effluent % Reduction Min. Required
MCL Average Concentration Average Maximum Average Minimum Reduction
 &KORULQH ³ PJ/ PJ/+10% <0.05 mg/L 0.05mg/L > 97.29% 96.43% > 50%
 72 ³ ³ ³ ³ ³ ³ ³ ³
 3DUWLFXODWH ³ P/
atleast 10,000particles/mL P/ P/   > 85%
Standard No. 53: Health Effects
Parameter USEPA Influent Influent Challenge Effluent % Reduction Min. Required
MCL Average Concentration Average Maximum Average Minimum Reduction
Turbidity 1NTU*** 10.3NTU*** 1+1 NTU*** 0.106NTU 0.14NTU 98.97% 98.61% 0.5NTU
Cysts
99.95%Reduction  / Minimum50,000 L 0 0 >99.99% > 99.99% >99.95%
Leadat pH6.5 0.015mg/L 0.15mg/L 0.15mg/L+10% < 0.001mg/L <0.001 mg/L >99.33% >99.33% 0.010mg/L
Leadat pH8.5 0.015mg/L 0.14 mg/L 0.15mg/L+10% 0.001 mg/L 0.003mg/L >99.29% 97.86% 0.010mg/L
Lindane
0.0002mg/L 0.0216 mg/L 0.002mg/L+10% <0.00002 mg/L <0.00002 mg/L 99.07% 98.75% 0.0002mg/L
Atrazine
0.003mg/L 0.008mg/L 0.009 mg/L+10% < 0.002mg/L < 0.002 mg/L > 76.12% > 66.67% 0.003 mg/L
* Tested using a flow rate of 0.5 gpm; pressure of 60 psig; pH of 7.5 ± 0.5; temp. of 68° ± 5°F (20° ± 3°C)
** Measurement in Particles/ml. Particles used were 0.5-1 microns
*** NTU=Nephelometric Turbidity units
Operating Specifications
Capacity: certified for up to 750 gallons (2,838 l); up to six months
Pressure requirement: 40–120 psi (2.8–8.2 bar)
Temperature: 33–100ºF (0.6–38ºC)
Flow rate: 0.5 gpm (1.9 lpm)
General Installation/Operation/Maintenance Requirements
Flush new cartridge at full flow for 3 minutes to purge out trapped air.
Replace cartridge when flow becomes too slow.
Special Notices
Installation instructions, parts and service availability, and standard warranty are included with the product when shipped.
This drinking water system must be maintained according to manufacturer’s instructions, including replacement of filter
cartridges.
Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used on disinfected water that may contain filterable cysts.
The contaminants or other substances removed or reduced by this water treatment system are not necessarily in your water.
Check for compliance with the state and local laws and regulations.
Note that while the testing was performed under standard laboratory conditions, actual performance may vary. Systems
must be installed and operated in accordance with manufacturer’s recommended procedures and guidelines.
NSF®
System tested and certified by NSF International against Standard 42 for the reduction of
chlorine, taste and odor, particulate Class I and Standard 53 for the reduction of cyst, lead,
Lindane, Atrazine and turbidity.

Notes
30” Bottom-Freezer
20
