PARTS LIST
962
962IM
963
963IM
982
982F
982IM
982FIM
983
983IM
PART NO.619701
NORCOLD 03/25/2008
900 SERIES

900 SERIES PARTS LIST - PAGE 2
DOOR - UPPER (FREEZER) - 900 SERIES
NO. PART # DESCRIPTION 96 96IM 98 98IM
1618128 PANELRETAINER-UPPERDOOR XXXX
2618511 HINGE-DOORSIDE/TOPRH/BTMLH/BLACK XXXX
3618144 HINGEBUSHING-DOORHINGE/BLACK XXXX
4618205 DOORLINERASSY-UPPER/GRAYDOORGASKET XXXX
620076 DOORLINERASSY-UPPER/WHITEDOORGASKET(USE619627) XXXX
5618160 CAP-HINGEPLUG/BLACK XXXX
6619569 BOLT-CAPSHOULDER/TORXHEAD XXXX
7618235 DOORHANDLEASSY-UPPERDOOR/RHSWING/BLACK(USE619574) XXXX
8618119 STORAGELATCH-DOOR/BLACK(USE619648) XXXX
9618510 HINGE-DOORSIDE/TOPLH/BTMRH/BLACK XXXX
10619006 BIN-DOORSHELF/SMALL/CLEAR XXXX
11619008 DIVIDER-DOORBIN/CLEAR XXXX

900 SERIES PARTS LIST - PAGE 3
DOOR - LOWER (FRESH FOOD) - 900 SERIES
NO. PART # DESCRIPTION 96 96IM 98 98IM
1 618132 PANEL RETAINER-LOWER DOOR X X
618129 PANEL RETAINER-LOWERDOOR XX
2619569BOLT-CAPSHOULDER/TORXHEAD XXXX
3618511HINGE-DOORSIDE/TOPRH/BTMLH/BLACK XXXX
4618144HINGEBUSHING-DOORHINGE/BLACK XXXX
5 618210 DOOR LINER ASSY-LOWER/6 FT/GRAY DOOR GASKET X X
620077 DOORLINERASSY-LOWER/6 FT/WHITEDRGASKET (USE619629) X X
618270 DOOR LINER ASSY-LOWER/8 FT/GRAY DOOR GASKET (USE 630255) X X
620081 DOORLINERASSY-LOWER/8 FT/WHITEDR GASKET (USE619631) X X
6618230DOORHANDLEASSY-LOWERDOOR/RHSWING/BLACK(USE619573) XXXX
7618119STORAGELATCH-DOOR/BLACK(USE619648) XXXX
8618160CAP-HINGEPLUG/BLACK XXXX
9618510HINGE-DOORSIDE/TOPLH/BTMRH/BLACK XXXX
10619005BIN-DOORSHELF/LARGE/CLEAR XXXX
11619006BIN-DOORSHELF/SMALL/CLEAR XXXX
12619008DIVIDER-DOORBIN/CLEAR XXXX

900 SERIES PARTS LIST - PAGE 4
CABINET ASSEMBLY - FRONT VIEW - 900 SERIES

900 SERIES PARTS LIST - PAGE 5
CABINET ASSEMBLY - FRONT VIEW - 900 SERIES
NO. PART # DESCRIPTION 96 96IM 98 98IM
1618124TRIMPIECE-CABINET/TOP/WITHOUTBRASSINSERTS XXXX
619687 TRIM PIECEASSY-TOP/WITH INSERTS/BLACK (USE622319) XXXX
2618170HOLEPLUG-FORTOPTRIMPIECE/BLACK XXXX
3618171COVER-HINGEHOLE/WHITE/2POINT XXXX
619301COVER-HINGEHOLE/WHITE/3POINT XXXX
4618988HINGE-CABINETSIDE/FREEZER/SLOTTED/PAINTED XXXX
619336HINGE-CABINET/3POINT/TOPLH/BTMRH/BLACK XXXX
5618988HINGE-CABINETSIDE/FREEZER/SLOTTED/PAINTED XXXX
619335HINGE-CABINET/3POINT/TOPRH/BTMLH/BLACK XXXX
6 618133 TRIM PIECE-CABINET/SIDE/6' (USE622295) X X
618134 TRIM PIECE-CABINET/SIDE/8' (USE622296) X X
7 61630422 ICE CUBETRAY-PLASTIC X X
8618172SHELF-WIRE/FREEZER(USE620249) XXXX
9 618112 FRONT BOX XXXX
10 618245 CONTROL ASSY-OPTICAL/900 SERIES (USE625386 FOR EG2/ 625387 FOREG3) XXXX
11618176LOUVER-DRIPTRAY/WHITE(USE623250) XXXX
12618137DRIPTRAY-INSIDE(USE623250) XXXX
13618239SHELF-WIRE/SHORT(USE620269) XXXX
14618114SHELF-WIRE/FULL(USE620270) XXXX
15617756TRAY-SHELF/WHITE/CUTOUT XXXX
16618177SHELF-WIRE/CUTOUT(USE620268) XXXX
17618158CRISPERCOVER-GLASSSHELF XXXX
18619007BIN-ICE/CRISPER/CLEAR XXXX
19 618145 HINGEPIN-DOOR XXXX
20618144HINGEBUSHING-DOORHINGE/BLACK XXXX
21618136TRIMPIECE-CABINET/BOTTOM(USE622323) XXXX
22 618181 RETAINER-SHELF XXXX
2361586722BRACE-CABINET/BACK XXXX
24 618184 PLUG-FACADE/BLACK XXXX
619381HOLEPLUG-DIVIDER/BLACK XXXX
25618167STRIKEPLATE-BLACK XXXX

900 SERIES PARTS LIST - PAGE 6
CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - 900 SERIES
NO. PART # DESCRIPTION 96 96IM 98 98IM
1 632307 NSC SYSTEM PACK-COOLING UNIT (BACKERHEATER) X X
632314 NSC SYSTEM PACK-COOLING UNIT (BACKERHEATER) X X
NS618111BAFFLEDIFFUSER/WIREASSY-COOLINGUNIT(NOTSHOWN) XXXX
2 61505122 HOSECLAMP XXXX
3 618217 DRAINHOSE-26" (USE622390) X X
618242 DRAIN HOSE-32" (USE622391) XX
461710922DRIPCUP-REAR/METAL(USE622546) XXXX
561712637COVERASSY-BURNERBOX XXXX
6 61695322 BASE-BURNER BOX XXXX
7 621702 HEATER-AC/96 SERIES (COOLING UNIT SERIAL# 11231023 & BELOW) X X
HEATER-AC/98 SERIES (COOLING UNIT SERIAL# 11232007 & BELOW) X X
630811 HEATER-AC/BACKER/96 SERIES (COOLING UNIT SERIAL# 11231024 & ABOVE) X X
HEATER-AC/BACKER/98 SERIES (COOLING UNIT SERIAL# 11232008 & ABOVE) X X
8 626832 HEATER-DC/96 SERIES (COOLING UNIT SERIAL# 11231023 & BELOW) EG3 EG3
HEATER-DC/98 SERIES (COOLING UNIT SERIAL# 11232007 & BELOW) EG3 EG3
630812 HEATER-DC/BACKER/96 SERIES (COOLING UNIT SERIAL# 11231024 & ABOVE) EG3 EG3
HEATER-DC/BACKER/98 SERIES (COOLING UNIT SERIAL# 11232008 & ABOVE) EG3 EG3
961695022CAP-HEATDEFLECTOR XXXX
1061586722BRACE-CABINET/BACK XXXX
11 61686823 FINS XXXX

900 SERIES PARTS LIST - PAGE 7
CONTROLS - REAR VIEW - 900 SERIES
NO. PART # DESCRIPTION 96 96IM 98 98IM
1618186BASE-POWERBOARD XXXX
2 618198 POWER BOARD-EG2 (USE625386) EG2 EG2 EG2 EG2
618224 POWER BOARD-EG3 (USE625387) EG3 EG3 EG3 EG3
3618185COVER-POWERSUPPLY XXXX
4618287WIRE-WHITE/6"/GASVALVE(USE621448) XXXX
561694022BRACKET-MOUNTING/GASVALVE XXXX
661551822GASVALVE-ASCO(USE621444) XXXX
621444 KIT-GAS VALVE/BURNER TUBE ASSY XXXX
761546822CONNECTOR-MALE(NOTSHOWN) XXXX
861694622UNIONTUBE(NOTSHOWN) XXXX
961694922MANUALSHUTOFFVALVEASSY-KINCOBALON(USE621444) XXXX
1061445322PLUG-1/8"/FORPRESSURETAP XXXX
11 61594422 PRESSURETAP XXXX
12 618252 BURNER TUBE XXXX
13 618283 ORIFICE-JEWELED/.015" (USE621957) X X
618284 ORIFICE-JEWELED/.0155" (USE621957) X X
14 61705222 BURNER ASSY-5 SLOT (USE 621957) XXXX
15 61554422 CORD-AC POWER/BLACK X X
618406 CORD-AC POWER/IM IM IM
1661712637COVERASSY-BURNERBOX XXXX
17 61695322 BASE-BURNER BOX XXXX
1861692222ELECTRODE-SPARK/SENSE/SINGLEELECTRODE/0.25" XXXX
19 618516 DAUGHTER BOARD-EG3 (NOT SHOWN)(USE625387) EG3 EG3 EG3 EG3
NS 618606 WIRE-EG3/12 VOLT (NOT SHOWN) EG3 EG3 EG3 EG3
NS 618602 WIRE-EG3/GROUND (NOT SHOWN) EG3 EG3 EG3 EG3
NS 618605 WIRE-EG3/SENSE (NOT SHOWN) EG3 EG3 EG3 EG3

900 SERIES PARTS LIST - PAGE 8
INTERIOR LIGHT & THERMISTER ASSEMBLY - 900 SERIES
Continued on Page 13
NO. PART # DESCRIPTION 96 96IM 98 98IM
161629722LAMPBRACKETASSY XXXX
261628922LAMP-GE#214-2/DCLIGHTBULB XXXX
3618190COVER-LAMPBRACKET(USE621827) XXXX
461689122CLIP-THERMISTERMOUNTING/FIN XXXX
5618548LAMPTHERMISTERWIREASSY XXXX

900 SERIES PARTS LIST - PAGE 9
ICE MAKER PARTS - 900 SERIES
NO. PART # DESCRIPTION 96IM 98IM
1 61656822 COVER-FRONT/ICEMAKER IM IM
2 621266 ICE MAKER IM IM
3 61690822 CLAMP-TUBING/IM IM IM
4 617869 TUBE-WATER FEED/IM/68" (USE621429) IM IM
5 61346822 SNAP BUSHING IM IM
6 620038 FITTING-WATER TUBE/IM/4.63" (USE620659) IM IM
7 618407 WIRING HARNESS-IM IM IM
8 617831 BRACKET-MOUNTING/ICEMAKER/RELOCATED IM IM
9 619007 BIN-ICE/CRISPER/CLEAR IM IM
10 61656922 SHUT OFF ARM/IM IM IM
11 618172 SHELF-WIRE/FREEZER(USE620249) IM IM
12 61679622 GARDEN HOSEADAPTER-STRAIGHT/IM IM IM
13 61678722 NUT-COMPRESSION/WATER VALVEFITTING/IM (USE622991) IM IM
14 618253 WATER VALVE-BRACKET INCLUDED IM IM
15 618169 SPACER-WATER VALVE/NYLON IM IM

900 SERIES PARTS LIST - PAGE 10
FAN MODEL PARTS - 982F, 982FIM
PART # DESCRIPTION 982F 982FIM
618857 BRACKET-DC FAN FF
619016 BRACKET-FAN SUPPORT FF
61417922 CABLETIE-NYLON FF
618856 FAN-EXTERNAL DC FF
618093 THERMOSTAT-DC FAN/THERMO DISC FF
618950 WIREMOUNT-ADHESIVE FF
618700 WIRE-BLACK/24"/18 GA FF
619017 WIRE-BLACK/6"/18 GA FF
618701 WIRE-RED/36"/18 GA FF
618978 WIRE-RED/6"/18 GA/12V FAN FF
618699 WIRE-RED/60"/18 GA/WITH FUSEHOLDER FF
