Monogram ZISS480DXASS User manual

Owner's
Manual
Side-bg-Side
36','42" 48"
Built-in Refrigerators
PO05]
02-08 JR
monogram.corn

Consumer Information
Built-In Refrigerators
Contents Consumer Services
Important Phone Numbers .................. 29
Model and Serial Numbers ................... 3
Problem Solver ......................... 24-26
Product Registration ......................... 3
Safetg Instructions ........................ 4-7
Smartwater Filter Performance
Data Sheet ................................. 27
State of California
Water Treatment Device Certificate ......... 28
Warrantg ......................... Back Cover
Care and Cleaning
Cleaning-Outside and Inside ............... 19
Light Bulb Replacement ................ 20-21
Moving and Vacation ....................... 22
Master Light Switch ........................ 21
Operating Instructions
Automatic Icemaker ........................ 12
Climate Control Drawer .............. 13, 14, 16
Control Lock ................................ 14
Ice and Water Dispenser ................ 10, 11
Shelves and Bins ........................ 17, 18
Storage Pans ........................... 15, 16
Temperature Controls ........................ 8
Water Filter Cartridge ........................ 9
Sabbath Node Product Kit, ZSAB1........... 18

Consumer Information
Built-In Refrigerators
Before
using gour
refrigerator
Read this manual carefully. It is intended
to help 9ou operate and maintain gour new
refrigerator properlg.
Keep it handg for answers to gour questions.
If gou don't understand something or need more
help, there is a list of toll-free consumer service
numbers included in the back section of this
manual.
OR
Visit our website at: monogram.cam
Write
down the
model &
serial
numbers
You'll see them on a label in the lower right hand
side of the fresh food compartment beneath
the climate control drawer.
These numbers are also on the Consumer
Product Ownership Registration Card
included with this manual.
Before sending in this card, please write these
numbers here:
Model Number
Serial Number
Use these numbers in ang correspondence or
service calls concerning gour refrigerator.
If gou
received a
damaged
refrigerator
Immediatelg contact the dealer (or builder) that
sold gou the refrigerator.
Save time
& moneg Before gou request service, check the
Problem Solver in the back of this manual. It lists causes of minor operating problems that
9ou can correct yourself.
If gou
need
service
To obtain service, see the Consumer Services
page in the back of this manual.
We're proud of our service and want gou to be
pleased. If for some reason you are not happg
with the service gou receive, here are steps to
follow for further help.
For customers in the USA:
FIRST,contact the people who serviced gour
appliance. Explain whg gou are not pleased.
In most cases, this will solve the problem.
NEXT,if gou are still not pleased, write all the
details-including 9our phone number-to:
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY/40225
For customers in Canada:
FIRST,contact the people who serviced gour
appliance. Explain whg gou are not pleased.
In most cases, this will solve the problem.
NEXT,if gou are still not pleased, write all
the details-including geur phone number to:
Manager, Consumer Relations
Mabe Canada Inc.
1 Factorg Lane, Suite 310
Moncton, N.B.EIC 9M3

IMPORTANTSAFETYINSTRUCTIONS
READAND SAVE THESEINSTRUCTIONS
WARNING - When using
this appliance, alwags exercise basic safetg
precautions, including the following:
• Use this appliance onlg for its intended
purpose as described in this Owner's Manual.
• This refrigerator must be properlg installed
in accordance with the Installation
Instructions before it is used,
• Do not allow children to climb, stand or
hang on the shelves in the refrigerator,
Theg could damage the refrigerator and
seriouslg injure themselves.
• After gour refrigerator is in operation,
do not touch the cold surfaces in the
freezer compartment, particularlg when
hands are damp or wet. Skin mag adhere
to these extremelg cold surfaces.
• Do not store or use gasoline or other
flammable vapors and liquids in the
vicinitg of this or ang other appliance.
In refrigerators with an automatic Jcemaker,
avoid contact with the moving parts of the
ejector mechanism, or with the heating
element located on the bottom of the
icemaker. Do not place fingers or hands
on the automatic icemaking mechanism
while the refrigerator is plugged in.
Keep fingers out of the "pinch point" areas:
clearances between the doors and between
the doors and cabinet are necessarilg small.
Be careful closing doors when children are
in the area.
Unplug gour refrigerator before cleaning
and making repairs. NOTE:We stronglg
recommend that ang servicing be performed
bg a qualified individual.
Before replacing a burned-out light bulb,
set the Master Light switch in the OFFposition
to turn off the lights in order to avoid contact
with a live wire filament. (A burned-out light
bulb mag break when being replaced.}
NOTE:Setting the refrigerator temperature
controls to OFF does not remove power
to the light circuit.
Do not refreeze frozen foods which have
thawed completelg.
DANGER: RISKOF CHILD ENTRAPMENT
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigeration products are still dangerous.., even
if theg will sit for '_justa few dags." If gou are
getting rid of gour old appliance, please follow
these instructions to help prevent accidents.
Before You Throw Awag Your Old Refrigeration
Product:
• Take off the doors.
• Leave the shelves in place so that children
mag not easilg climb inside.
REFRIGERANTS
All refrigeration products contain refrigerants,
which under federal law must be removed prior
to product disposal. If gou are getting rid of
an old refrigeration product, check with the
compang handling the disposal about what
to do.

IMPORTANTESINSTRUCTIONSDESECURITE
LISEZETCONSERVEZCESINSTRUCTIONS
AVERTISSEMENT :Lorsque
vous utilisez le r_frig_rateur, observez
toujours certaines precautions de base,
notamment :
• N'utilisez le r_frig_rateur que pour son usage
pr_vu, comme d_crit dans le pr6sent manuel.
•Installez le r_frig_rateur conform_ment aux
directives d'installation avant de I'utiliser.
• Ne laissez pas les enfants grimper, s'asseoir,
se tenir debout ni se pendre aux clagettes
du r_frig_rateur. IIs pourraient endommager
le r_frig_rateur et se blesser gravement.
• Une fois le r_frig_rateur en marche,
ne touchez pas les surfaces froides
du cong_lateur, surtout si vous avez
les mains humides ou mouill_es :la peau
risque d'adherer _ ces surfaces tr_s froides.
• N'entreposez et n'utilisez pas d'essence
ou autres vapeurs et liquides inflammables
_1proximit_ de cet appareil ou de tout autre
appareil _lectrom_nager.
• Pour les r_frig_rateurs dot_s d'une machine
glaqons automatique, _vitez le contact avec
les pi_ces mobiles du m_canisme _jecteur,
ou avec I'_l&ment chauffant situ& _ la partie
inf_rieure de la machine _ gla¢ons. Ne posez
pas les doigts ou les mains sur le m6canisme
de la machine 6 gla¢ons pendant que
le r_frig_rateur est branch&
Eloignez les doigts des parties du
r_frig_rateur o6 I'on peut facilement
se pincer : les espaces entre les portes
et les placards sont toujours _troits. Sogez
prudent Iorsque vous fermez les portes
de I'appareil en presence des enfants.
D_branchez votre r_frig_rateur avant
de le nettoger et de le r_parer. REI',IARQUE:
Nous vous recommandons vivement de confier
toute r_paration _ un technicien qualifi_.
Avant de remplacer une ampoule grill_e,
mettez le commutateur de lumi_re principale
en position OFF(arr_t} pour &teindre la lumi_re
afin d'eviter tout contact avec un fil sous
tension. (Uneampoule grill_e peut se briser
pendant I'op6ration). REMARQUE: Lorsque
vous placez les commandes de temp6rature
du r_frig_rateur sur OFF (arr_t), I'alimentation
_lectrique de I'ampoule n'est pas couple.
Ne faites PASrecongeler des aliments
surgel_s qui ont compl_tement d_gel_.
DANGER! RISQUESPOUR LESENFANTS
Les enfants pris au pi_ge ou morts d'asphgxie
sont toujours d'actualit6. Lesappareils de
r6frig6ration abandon6s sont toujours aussi
dangereux, re&me si on n'attend que "quelque
jours" pour s'en d&barasser. Si vous ne gardez
pas votre ancien appareil, veuillez suivre
les directives ci-dessous afin de pr&venir
les accidents.
Avant de vous d_barasser de votre vieux
appareil de r6frig&ration :
• D6montez les portes.
• Laissez les clagettes en place afin d'emp_cher
les enfants de grimper 6 I'int&rieur.
REFRIGERANTS
Tousles appareils de r&frig_ration
contiennent des r&frig_rants qui, conform_ment
aux lois f_d_rales, doivent _tre enlev6s avant
toute 61imination de I'appareil. Sivous vous
d_barrassez de vieux appareils de r_frig_ration,
v&rifiez, aupr_s de la soci_t6 qui s'occupe
de leur elimination, ce que vous devez faire.

IMPORTANTSAFETYINSTRUCTIONS
HOW TOCONNECTELECTRICITY
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord. For personal safety, this appliance
must be properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding} plug which mates
with a standard 3-prong (grounding} wall outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit checked
by a qualified electrician to make sure the outlet
is properly grounded.
Where a standard 2-prong wall outlet is
encountered, it is your personal responsibility
and obligation to have it replaced with
a properlg grounded 5-prong wall outlet.
Use ofa GFI (Ground Fault Interruptor)is not
recommended for the refrigerator outlet.
The appliance should always be plugged into
its own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits
which could cause a fire hazard from
overheated wires.
DO NOT USE AN ADAPTER PLUG TO CONNECT
THE REFRIGERATOR TO A 2-PRONG OUTLET.
DO NOT USEAN EXTENSION CORD WITH
THIS APPLIANCE.
Never unplug an appliance by pulling on
the power cord. Always grip the plug firmly
and pull straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the appliance, be careful notto
roll over or damage the power cord.
SAVE THESEINSTRUCTIONS

IMPORTANTESINSTRUCTIONSDESECURITE
RACCORDEMENT ELECTRIQUE
Ne coupez ni retirez en aucun cas
la troisi_me broche (mise 6 la terre) de la fiche
du cordon d'alimentation. Pour votre s_curit_,
cet appareil doit _tre correctement mis
la terre.
Le cordon d'alimentation de cet appareil est
muni d'une fiche 8 3 broches (mise _ laterre)
qui se branche dans une prise mural ordinaire
6 3 alv6oles (mise 6 la terre) pour r6duire
au minimum les risques du chocs _lectriques.
Faites examiner la prise de courant et le circuit
par un electricien qualifi_ pour vous assurer
que la prise est correctement mise 6 la terre.
Si la prise murale est du tgpe standard
2 alv_oles, il vous incombe de la faire
remplacer par une prise 6 3 alv_oles
correctement mise _ la terre.
L'utilisation d'un interrupteur de d_faut
6 la terre (GFl-Ground Fault Interruptor)
n_st pas recommand_ pour la prise
de courant du r_frig_rateur.
La machine 6 glagons doit toujours @trebranch6
dans sa propre prise de courant, dont la tension
nominale est identique 6 celle indiqu_e sur
la plaque signal6tique. Cette pr@caution est
recornmand&e pour garantir un rendement
optimum et _viter une surcharge des circuits
&lectriques de la r6sidence, ce qui pourrait cr6er
un risque d'incendie par surschauffe des fils.
N'UTILISEZ PAS UNE FICHE D'ADAPTATION POUR
RACCORDER LE RI_FRIGI_RATEURDANS UNE PRISE
MURALE/i 2 ALVEOLES.
N'UTILISEZ PAS DE CORDONS PROLONGATEURS
AVEC CET APPAREIL.
Ne d_branchezjamais I'appareil en tirant
le cordon d'alimentation. Saisissez fermement
la fiche du cordon et tirez droit pour la retirer
de la prise.
R@parezou remplacez imm_diatement tout
cordon effiloch_ ou endommag& N'utilisez
pas un cordon fendill_ ou pr&sentant des
signes d'usure.
Lorsque vous d&placez I'appareil du mur,
faites attention de ne pas la faire rouler
sur le cordon d'alimentation afin de ne pas
I'endommager.
CONSERVEZ CESDIRECTIVES

Temperature Controls
Built-In Refrigerators
@
_c0 Q_
f
FREEZER X R£FRIGERATOR @
H{}LO 3_EC
Preset Settings:
Allow 24 hours to reach these preset temperatures,
Temperature
controls The temperature display shows the actual
temperature of the freezer and fresh food
compartments. The actual temperature will vary
frorn the set temperature based on factors such
as door opening, amount of food, defrost cgcling
and room temperature.
NOTE:Frequent door openings or door left open
for periods of time mag increase the internal
temperature of the freezer and fresh food
compartments temporarilg.
To turn offthe cooling system in both
the freezer and fresh food compartments, press
either 0.2)pad until both displays show OFF.
To turn the cooling system on, press either
_'_ pad. The preset temperatures of 0°F and 37°F
will appear in the display.
To check the current temperature setting
for the fresh food or freezer compartment,
press the (_ or _-_ pad once. After 5 seconds,
the display will return to the actual temperature.
To change the temperature settings, press
the _ or _ pads to desired temperature set
point for fresh food and freezer separatelg.
Allow 24 hours for the refrigerator to reach
the temperature you have set.
Fresh Food
Freezer
Temperature Ranges
Low High
34°F 45%
1oc 7oc
-6OF +6OF
-21°C -14°C
NOTE: Setting the controls to OFF stops
cooling, but does not shut off electrical power
to the refrigeraton
Changing
display
temperatures
from °F to °C
Tochange the temperature display
between Fahrenheit and Celsius, press
Temp Display °C/°F.
Door
alarm To turn the Door Alarm feature on, press
DOOR ALARM once. The ACTIVE light will come
on. To turn it off, press it again.
On models with a dispenser, the Door Alarm
feature is located on the dispenser panel on
the front of the freezer door.
When the DOOR ALARM
is active, the alarm will flash
and beep if you keep the door
open for more than 2 minutes.

Water Filter Cartridge
Built-In Refrigerators
Water filter
cartridge Thewater filter cartridge islocated in the top
machine compartment of the refrigeraton
To Replace the Filter:
The filter cartridge is designed
to filter 300 gallons of water
{lasting approximately 12 months}.
Thereisa replacement indicator light
@
HeLD 3 SEC
for the water filter cartridge on the temperature
control panel.Thislight will turn yellow to tell
you that you need to replace the filter soon.
Thefilter cartridge should be replaced when
the replacement indicator light turns red
or ifthe flow of water to the dispenser
or icemaker decreases.
Installing the Filter Cartridge:
1. Removethe old cartridge bg slowly turning
it to the left. A small amount ofwater may
drip down. Do not pulldown on the cartridge.
2. Fillthe new cartridge with water from the tap
to allow for better flow immediately after
installation.
3. Line up the arrow on the cartridge with
the center of the holden Do not push it up
into the holder.
4. Slowly turn it to the right until the cartridge
stops. It will rotate about 1/4 turn. DO NOT
OVERTIGHTEN.
To Reset the Filter Status Light:
Press and hold the RESETpad for 3 seconds.
Filter BypassPlug:
Youmust usethe filter bypass plug:
a) if you havea household
reverseosmosiswater system
and/or another form of home
water filtration system
b) if a replacement filter is not
available.
I t Filter
'_'Bypass
Plug
€,,
Thebypass plug and the mini-manual are located
in the top machine compartment.
Theicemaker and dispenser will not operate
without the filter or filter bypass plug installed.
Replacement filters:
Toorder additional filter cartridges in the United
States, visit our Website at monogram.corn, or
call GEParts and Accessories, 800.626.2002.
Customersin Canada should consult the yellow
pages for the nearest MabeServiceCenter.
Cartridge
Cartridge
Slowly turn it to the right
Do not overtighten
IMPORTANTNOTE:Remove the water filter to
immediately stop any water leak from the
Icemaker/Dispenser system. The water filter
cartridge holder (bracket) acts as a cut-off valve
when the filter is removed and will prevent
further leaking.
Call 1.800.844.1845 to schedule a service call
to repair the leak.

Ice & Water Dispenser (onsome models)
Built-In Refrigerators
Dispenser
with
glass-touch
controls
How it Works
The electronic controls on the dispenser are
trulg interactive. The control panel is equipped
with a proximity sensor that causes the panel to
light up as gou approach the dispenser (approx.
2 inches/. To make a selection, simply touch
the graphic for the feature you want, and the
halo for that feature will light up. When you walk
awag from the refrigerator, the lighted graphics
switch off automaticallg.
®®®
SpNEShelf
\\
How to Use
Todispensewater or ice,select WATER_, CUBED
ICE_ or CRUSHEDICE_I Thenpress the glass
gently against the top of the dispenser cradle.
The spill shelf is not self-draining. To reduce
water spotting, the shelf and its grille should be
cleaned regularlg.
If no water is dispensed when the refrigerator
is first installed, there mag be air in the water
line sgstem. Pressthe dispenser cradle for at
least two minutes to remove trapped air from
the water line and to fill the water sgstem.
Toflush out impurities in the water line,
throw awag the first gallon of water.
CAUTIO N:Never put fingers
or ang other objects into the ice crusher
discharge opening.
Locking the Dispenser:
Touch CONTROL LOCKfor
3 seconds to lock the dispenser
and control pad. Tounlock, touch
it again for 3 seconds.
Dispenser Light:
This feature turns the night light _,
on and off. The light also comes
on when the dispenser cradle is
pressed. If this light burns out, it
should be replaced with a 6 watt
12V maximum bulb. The bulb is available
through GEParts and Accessories, 800.626.2002.
Order part number WRO2X10675.
Door Alarm:
Toturn the Door Alarm feature on,
touch DOORALARM once. Toturn
it off, press it again.
When the DOORALARM
is active, the alarm will flash and beep if gou
keep the door open for more than 2 minutes.
10

Ice & Water Dispenser (onsome models)
Built-In Refrigerators
Ice storage
bin To remove:
Lift up the access door to reach the icemaken
Set the icemaker power switch to the OFF
position. With the access door closed, support
the storage bin at the bottom while slightlg
lifting. Pull bin straight out.
To replace:
Slide the bin back until the tab on the bin locks
into the slot on the shelf. If the bin does not go
all the wag back, remove it and rotate the drive
mechanism 1/4 turn. Then push the bin back
again.
Important
facts about
sour ice
&water
dispenser
•Do not add ice from trags or bags to
the storage bin. It mag not crush or
dispense well.
• Avoid overfilling glass with ice and use
of narrow or extra-tall glasses. Backed-up
ice canjam the chute or cause the door in
the chute to freeze shut. If ice is blocking
the chute, poke it through with a wooden
spoon.
• Beverages and foods should not be
quick-chilled in the ice storage bin. Cans,
bottles or food packages in the storage bin
mag cause the icemaker or auger to jam.
• Tokeep dispensed ice from missing
the glass, put the glass close to, but not
touching, the dispenser opening.
• Some crushed ice mag be dispensed even
though SOU selected CUBES. This happens
occasionallg when a few cubes accidentallg
get directed to the crushen
After crushed ice is dispensed, some water
mag drip from the chute.
Sometimes a mound of ice chips will form
on the door in the ice chute. This condition
is normal and usually occurs when you have
dispensed crushed ice repeatedlg. The ice
chips will eventually evaporate.
Dispensed water is not ice cold. For colder
water, simplg add crushed ice or cubes before
dispensing water.
The first glass of water dispensed mag
be warmer than the following ones.
This is normal.
Toeliminate drips on the spill shelf, tilt
the glass in slightlg when dispensing waten
11

Automatic Icemaker
Built-In Refrigerators
Automatic
icemaker A newlg-installed refrigerator mag take
12-24 hours to begin making ice.
The icemaker will produce seven cubes per
cycle-approximately 15 cycles in a 24-hour
period, depending on freezer compartment
temperature, room temperature, number of
door openings and other use conditions.
If the refrigerator is operated before the water
connection is made to the icemaker, set the
power switch to OFF.
When the refrigerator has been connected
to the water supply, set the power switch to ON.
Throw away the first full bucket of ice.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler arm,
the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale and shrink.
Icemaker
Switch FeelerArm
After the icemaker has been turned on again,
there will be a delay of about 45 minutes before
the icemaker resumes operations.
NOTE:In homes with lower-than-average
water pressure, you may hear the icemaker
water valve cycle on several times when
making one batch of ice.
NOTE: Icemaker works best between
40 and 120 PSI home water pressure.
12

Climate Control Drawer
Built-In Refrigerators
Climate
Control
drawer
How it Works
The Climate Control feature is a system of
dampers, a fan, a temperature thermistor, and a
heater. The Climate Control drawer can be used to
chill items quickly, thaw foods quickly or store items
at their optimum temperatures.
The drawer is tightlg sealed to prevent the drawer's
temperature from causing temperature fluctuations
in the rest of the refrigerator.
SELECTTEMP--Use this feature to store items at
their optimum temperatures. The CITRUSsetting
will maintain a drawer temperature of 59-47°F
bg cgcling a small heater off and on as needed.
The PRODUCEsetting will maintain the drawer
temperature at 31-58°F bg drawing in additional
cold air as needed. The MEATsetting will
maintain the drawer temperature at 27-37°F
bg drawing in additional cold air as needed.
EXPRESS CHILL--This feature can be used
to cool items in minutes, rather than hours.
Extra cool air is circulated throughout the
drawen Once the cycle is complete, the drawer
will revert to the pre-set fresh food temperature.
EXPRESSTHAW--This feature thaws items
in hours rather than dags. Food is gentlg
thawed in a cool environment bg circulating
air throughout the drawer. Temperature is
maintained in the drawer bg cgcling a small
heater off and on as needed. Once the thaw
cgcle is complete, the pan will autematicallg
adjust to a temperature of 27-37°F to store
the food at its optimum temperature.
NOTE:Bg turning the controls on the Climate
Control drawer off, the drawer can be used as
a standard sealed produce pan.
_ _ _ CLIMA_ COt_TROL DRAWFR
........ .........................................
How to Use
1 Emptg the drawen Place the items in
the drawer.
2 Select the Express Thaw,TM Express Chill TM
or Select Temp TM pad. The displag will come
on. Pressthe pad until the light appears next
to the desired setting. Use the chart on
the next page to determine the best setting.
• To stop a feature before it is finished,
press that feature's pad until no options
are selected and the displag is off.
• During Express Thaw TM and Express Chill,TM
the displag on the controls will count down
the time remaining in the cgcle.
• After the Express Thaw TM cgcle is
complete, the drawer will reset to the MEAT
setting 127-37°F)to help preserve thawed
items until theg are used.
• The displaged actual temperature of
the Climate Control drawer mag varg slightlg
from the SETtemperature based on usage
and operation environment.
NOTE:For food safetg reasons, it is
recommended that foods be wrapped in
plastic wrap when using Express ThawTM
This will help contain meat juices and
improve thawing performance.
ExpressThawTM ExpressChillTM
13

Climate Control Drawer
Built-In Refrigerotors
Climote
Control
chort
NOTE:Results mag varg depending on packaging, starting temperature and other food traits.
-.Q -.@ o-...@
PRODUCE •30MIN •1.5LBS •
MEAT •45MIN •3,0LBS •
Citrus Setting (39-47°F)
• Oranges, Lemons, Limes,
Pineapple, Cantaloupe
• Beans, Cucumbers, Tomatoes,
Peppers, Eggplant, Squash
Produce Setting (31-3B°F)
• Strawberries,Raspberries,
Kiwifruit, Pears,Cherries,
Blackberries,Grapes,Plums,
Nectarines,Apples
• Asparagus,Broccoli,Corn,
Mushrooms,Spinach,
Cauliflower,Kale,Green
Onions,Beets,Onions
15 Minutes
1 BeverageCan(12oz}
2 SmallJuice Boxes
(6-8 ozeach}
30 Minutes
• Wine (750ml bottle)
• 2 to 6 BeverageCans
(12 azeach)
• 2 Plastic20 oz Bottles
of Beverage
• 4 to 6 SmallJuice Boxes
(6-8 ozeach}
• 5 FoilJuice Packets
Meat Setting (27-37°F} 45 Minutes
• Raw Meat, Fishand Poultrg • 2 Literof Beverage
• 1/2 GallonofJuice
•Gelatin--1 package
03 Lbs.14hours)
• IndividuallgWrapped
FiletMignon (0.5Ib)
• Hamburger Patties(0.5 Ib}
1.5Lbs.(8 hours)
• Chicken Breasts(1.5Ibs)
• Ground Beef(1.Slbs}
• Steak(1.5 Ibs}
3.0Lbs. 112hours)
•Chicken Breasts(3.0Ibs}
• Ground Beef(3.0Ibs}
• Steak(3.0Ibs/
Control
lock Control Lock
Press and hold this pad for 3 seconds to lock
the settings for the Climate Control drawee
To unlock, press and hold for another 3 seconds.
14

Storage Pans
Built-In Refrigerators
Sealed
deli pan Use the Sealed Deli Pan for the convenient
storage of lunch meats and cheese, hors
d'oeuvres, spreads and snacks. The pan and
shelf to which it is attached can be adjusted
to any height.
Sealed
produce
pans
The top pan is designed to provide constant high
humidity levels.
Make sure the drawers are closed completely
to maintain the correct humidity level.
15

Climate Control Drawer and Storage Pans
Built-In Refrigerators
Drawer
and pan
removal
To remove a drawer or pan:
1. Pullthe pan out to the stop position.
2. Lift the front of the pan up and out of
the wire holden
3. Lift the back of the pan up and out.
To replace a pan:
1. Placethe back of the pan in the wire
holder, making sure the wire holder fits
into the grooves on the back of the pan.
2. Lower the front of the pan into the wire holden
3. Pressfirmlg on the top of the pan to snap it
into the wire holden
Drop down
shelf The drop-down shelf gives gou the use
of another full-size shelf when gou need extra
storage. It conveniently folds back out
of the wag when not in use, giving you room
for storage of larger items.
To use drop down shelf:
1. Pullforward and down to drop the shelf
into place.
2. Pullforward while lifting up to place the shelf
out of the wag.
Lighted
vegetable
drawer
COVeF
16
The lighted vegetable drawer cover provides
lighting for the lower compartments. The lights
are recessed into the cover to illuminate
the drawers below.
To remove cover:
1. Remove the top drawer (see Drawer and pan
removal section}.
2. Removethe thumb screw located inside
the front left corner under the cover.
This screw isin place sothe cover cannot
be accidentallg dislocated while in use.
3. Lift the cover and carefullg pull forward
to expose the plug.
4. Unplugthe cover and carefullg remove itfrom
the refrigerator.
To replace cover:
1. Carefullg set cover onto the siderails,leaving
the plug exposed.
2. Plugthe cover into the refrigerator.
3. Carefullg slidethe cover into place.
4. Replace the thumb screw under the front edge
of the cover.
5. Replacethe drawer (seeDrawer and pan
removal section}.

Shelves and Bins
Built-In Refrigerators
How to
rearrange
gour shelves
Tempered glass shelves in the fresh food
compartment and wire shelves in the freezer
compartment are adjustable, enabling you to
make efficient shelf arrangements to fit your
family's food storage needs.
To remove shelves:
Tilt shelf up at front, then lift it up and out
of tracks on rear wall of refrigeraton
To replace shelves:
Select desired shelf height. With shelf front
raised slightly, engage tap lugs in tracks at rear
of cabinet. Then lower front of shelf until it locks
into position.
Door bins All door bins, except for the deep gallon door bin,
are adjustable using one of 2 tabs on each end
of the bin. They can be moved up and down to
many different positions to meet your storage
needs. The deep gallon door bin can be removed
for cleaning.
To remove any bin:
Lift the bin up and slide it toward you.
Door Bin
Door Bin
Removable
wine rack The rack can be attached to the left or
right side of any shell It is designed to hold
a bottle, including a 2 liter bottle, on its side.
------------mTT---
17

Shelves and Bins
Built-In Refrigerators
Freezer
baskets Wire slide-out freezer baskets can be pulled out
for eas9 access to frozen foods.
To remove:
Pull basket out. Lift the front of the basket up
and then take it out.
Sabbath
Mode
Product Kit
(available at
extra cost)
The Sabbath Mode Product Kit was designed
for use on the Jewish Sabbath and Holidags.
The Sabbath Mode feature makes it possible
for observant Jews to refrigerate and freeze
food during the duration of the holidag.
The Sabbath Mode feature can be set to override
tgpical reactions to actions in gour refrigeraton
While in the Sabbath Mode, your refrigerator will
still operate normally. However, the refrigerator
will not respond to your actions.
While in the Sabbath Mode, you may notice
the fan running when the door is opened;
however, this is not a result of your actions.
The fan will operate at random times.
The defrost heater will continue to defrost
the refrigerator and freezer and will be activated
on a timer. The defrost heater will not defrost
as a result of door openings or any consumer
actions.
ON/OFF--To activate, raise the top grille
panel and set the Sabbath Mode switch to
the ON position. A green LEDlight will be visible
below the Sabbath lode Kit switch. The light will
be visible when the grille is closed between the
grille door and compartment doors.
DISPLAYS,ALARMSand LIGHTS--The main
temperature control and ExpressChill displays
will be deactivated; therefore they will not be lit,
sound a tone or operate when touched. Door
alarms and lights will be disabled.
ICE and WATERDISPENSER--Theproximitg
sensor and dispenser touch sensor icons will
not operate. Ice or water cannot be retrieved
from the dispenser.
ICEMAKER--The icemaker will continue
to operate. The icemaker can be disabled by
opening the freezer, opening the ice storage bin
door and setting the icemaker power switch to
the OFF position (seeAutomatic Icemaker).
Toobtain ice, open the freezer door and remove
the cubed ice from the ice bin.
This Sabbath Mode Product Kit can be purchased
from gour local appliance dealen TheZSAB1Kit
is designed for usewith all Monogram Built-In
Refrigerators manufactured after 2008.
Tolocate gour nearest dealer,visit our web site
monogram.corn or call 1.800.626.2000.InCanada,
call 1.800.561.3344. Order Kit # ZSAB1.
NOTE:The Sabbath Mode Product Kit must
be installed bg a qualified service technician.
18

Careand Cleaning
Built-In Refrigerators
Cleaning
outside The dispenser spill shelf
and the area beneath it
should be cleaned
periodicallg with a mild liquid dish detergent.
Dispenser cradle--Before cleaning, lock
the dispenser by touching CONTROL LOCK for
5 seconds to prevent activating the dispensen
Clean with warm water and a mild liquid dish
detergent. Rinse thoroughly and wipe dry.
Unlock the dispenser by touching CONTROL
LOCK for 5 seconds.
Do not use chemical cleaners to clean
the dispenser or any part of the dispenser,
Door handles and trim-Clean with a cloth
dampened with soapy waten Drg with a soft
cloth.
Keep the outside clean. Wipe with a clean
cloth lightlg dampened with mild liquid dish
detergent. Drg with a clean, soft cloth.
Do not wipe the refrigerator with a soiled
dish cloth or wet towel. These mag leave
a residue that can damage the finish. Do not
use scouring pads, powdered cleaners, bleach
or cleaners containing bleach because these
products can scratch and damage the finish.
Stainless steeI--Regularlg clean and polish
the stainless steel door panels and handles
(on some models)with a commerciallg available
stainless steel cleaner such as Stainless Steel
MagicTM to preserve and protect the fine finish.
Stainless Steel Magic and the Monogram
polishing cloth are available through GEParts
and Accessories,800.626.2002,or monogram.com.
For Stainless Steel Magic, order part number
WXlOX15. For Monogram polishing cloth,
order part number WX72X10001.
Do not use appliance wax or polish on
the stainless steel.
Cleaning
inside Turn off power at the circuit breaker or fuse
box before cleaning. If this is not practical, wring
excess moisture out of sponge or cloth when
cleaning around switches, lights or controls.
Use warm water and baking soda solution-
about a tablespoon (15 ml) of baking soda
to a quart (1 liter) of water. This both cleans
and neutralizes odors. Thoroughlg rinse
and wipe drg.
Other parts of the refrigerator-including
door gaskets, meat and vegetable drawers,
ice storage bin and all plastic parts-can be
cleaned the same wag.
Do not wash ang plastic refrigerator parts
in the dishwasher.
Avoid cleaning cold glass shelves with hot
water because the extreme temperature
difference may cause them to break. Handle
glass shelves carefully. Rough handling of
tempered glass can cause it to shatter.
NOTE:Interior lights mag get too hot and turn
off automaticallg if the refrigerator door is left
open too long. This is normal and theg will turn
back on when theg cool down.
19

Careand Cleaning
Built-In Refrigerators
Light bulb
replacement WARNING - Halogen lights generate
intense heat. Be certain power is off and lamps
have sufficient time to cool before attempting
to replace.
Power to the lamps can be turned off at
the Master Light switch located behind
the grille panel at the top of the refrigerator.
There is a switch for the freezer and a switch
for the fresh food compartment.
Turning the temperature control to OFF
does NOT remove power to the light circuits.
AVERTISSENENT :
Les ampoules halog@nesproduisent une chaleur
intense. Assurez-vous de bien couper le courant
et de laisser suffisamment de temps aux
ampoules pour leur permettre de se refroidir
avant d'essager de les remplacen
Vous pouvez couper le courant en utilisant
le commutateur de lumi&re principale situe
derriere le panneau grillag@ en haut du
r@frig&ateun II g a un commutateur pour le
compartiment cong&lateur et un commutateur
pour le compartiment r@frig6rateun
Vous NE COUPEZPASI'alimentation _lectrique
du r@frig&ateur des circuits de lumi&res en
mettant le bouton de contr61ede temp&ature
en position OFF(arr@t).
The refrigerator uses a halogen bulb:
The columns along the back wall
of the fresh food and freezer compartments
are lit up by lamps located behind the top pan
in the fresh food compartment and the bottom
basket in the freezer compartment.
These bulbs have a life expectancy of
about 2000 hours. However, if the bulbs
do need to be replaced, they can be
purchased at hardware, general retail
and home improvement stores or through
GE Parts and Accessories, 800.626.2002.
Light
Columns
Bulbs
This is a 35 watt, 12volt,
Type MR11bulb
If ordering through
GEPorts and Accessories,
order part WR02X11183
2O
