Monoprice 38594 User manual
Portable Fridge/Freezer, 30 Liter with LG Compressor
P/N 38594
User's Manual
2
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future reference.
This device is intended for indoor use only.
Do not allow the refrigerator to get wet. If it does get wet, stop using it
immediately, unplug it from its power source, then wipe it dry with a towel or cloth.
Clean the inside of the unit with warm water and neutral detergent before first use.
Do not allow the electrical parts to come in contact with water or a wet cloth.
When moving the unit with the handle and wheels, keep the angle at less than 45
degrees.
Do not place electrical or electronic devices inside the unit.
It is recommended to operate the unit on a flat surface. The maximum operation
angle is 30 degrees.
This device needs good ventilation for safe operation. Ensure that there is at least 8"
(200mm) of ventilation space on the back of the unit and 4" (100mm) on the sides.
Do not expose this device to excessively high temperatures. Do not place it in, on,
or near a heat source, such as a fireplace, stove, radiator, etc. Do not leave it in
direct sunlight.
Do not allow children to play with or on this unit. Do not sit or stand on it.
Unplug the unit from its power source before cleaning or defrosting.
Unplug the unit and clean it if it will go unused for a long period of time. Do not use
chemical cleaners, solvents, or detergents.
The one-piece inner tank can have water inside, but should not be emptied by
pouring it out of the top. Use a cup to empty the majority of water, then use a
sponge to absorb the rest. Finally, wipe the interior dry with a towel.
Do not use sharp metal objects to clean accumulated ice/frost from inside the unit.
3
FEATURES
High efficiency DC inverter compressor and conversion module with high reliability
and long life
Fluoride-free insulation with good heat preservation performance and low energy
consumption
Powered by 12/24 VDC from a cigarette lighter receptacle or using the included AC
power adapter
Compressor delay protection
Quick cooling to -4°F (-10°C), based on a +77°F (+25°C) ambient temperature
Intelligent car battery protection system
Wide range electronic temperature control
Can be used as a refrigerator or freezer
Includes a weatherproof USB charging port on the top panel
Backlit LCD display
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
support times and links.
4
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Portable Refrigerator/Freezer
1x Cigarette Lighter Power Cord
1x AC Power Adapter
1x AC Power Cord
1x User's Manual
OPERATION
If using this device in a vehicle, plug one end of the included Cigarette Lighter
Power Cord into the power receptacle on the right side, then plug the other end
into the cigarette lighter receptacle.
If using this device in a building, plug the included AC Power Adapter into the
power receptacle on the right side, then plug one end of the included AC Power
Cord into the Adapter and plug the other end into a nearby AC power outlet.
Press the button on the top panel to turn the unit on. The LCD will illuminate and
display the input voltage and current temperature.
Use the ╋and ━buttons on the top panel to adjust the target temperature.
Momentarily press the button on the top panel. The ECO or MAX setting will
start blinking, indicating that the setting can be changed. Momentarily press the
5
button again to toggle between the ECO and MAX setting. The MAX setting
indicates that the unit is in fast cooling mode, while the ECO setting indicates an
energy saving mode. After a couple seconds of no input, the setting will stop
blinking. The factory default setting is MAX.
Press and hold the button for several seconds. The H, M, or Lsetting will start
blinking, indicating that the setting can be changed. Momentarily press the button
again to cycle through the H, M, and Lsettings. The setting indicates the level of
battery protection in operation. When connected to a car, it is recommended to use
the Hsetting to ensure that the battery does not completely drain with the engine
off.
FOOD STORAGE NOTES
Freezer (≤-4°F)
Meat should be cut and wrapped tightly.
If you purchase frozen food, put it in the freeze before it thaws.
Do not mix fresh and frozen food.
Do not put fruits and vegetables in the freezer to avoid freeze drying.
Do not place glass or other containers with sealed liquid in the freezer.
Refrigerator (+32 ~ +50°F)
You can put eggs, butter, milk, and bottled drinks in the refrigerator.
Fruit and vegetables should be put in the crisper to allow them to retain their
moisture.
Hot food should be cooled down before placing it in the refrigerator to help save
power.
Food should be placed in fresh plastic bags.
Leave space between packaged foods to allow for air circulation.
6
DEFROSTING
With prolonged use as a freezer, the unit may accumulate frost on the interior surfaces,
which can reduce its ability to cool and increase power consumption. If this occurs, you
should defrost the unit. Perform the following steps to defrost the unit.
1. Press the button on the top panel to turn the unit off, then unplug it from its
power source.
2. Open the door, then remove any foods or drinks and place them in a cool place
(ideally another refrigerator or freezer).
3. Use a defrosting shovel to remove the ice buildup. Do not use sharp metal tools to
avoid damage to the surface of the inner tank. This will be easier if you leave the
door open and allow the ice to soften. Alternatively, you can simply leave the door
open until the ice buildup melts entirely.
4. Use a cup, sponge, and/or towel to remove the water and ice.
5. Thoroughly dry the inner tank with a clean towel.
6. Close the door, reconnect power, turn it on, and set the temperature to the desired
level. Once the temperature reaches the target value, put your food back inside the
unit.
OPERATING NOTES
The following conditions are normal when operating this unit.
The flow of refrigerant through the evaporator may cause a boiling or gurgling
sound.
In rainy or high humidity weather, moisture may form on the outside of the unit and
door gaskets. Wipe the surfaces dry with a towel.
The temperature on the back of the unit may be quite high, especially when
operating in the summer, caused by the heat emissions of the condenser.
The temperature on the external surface of the compressor may be high when the
compressor is working.
7
The compressor may cause a high hum or pulsating sound when it is starting or
stopping.
It is normal to hear a metal hitting metal noise when the unit is bumped.
TROUBLESHOOTING
Q1: The appliance is not working.
A1: Ensure that the unit is plugged in and connected to a power source. Press the
button to turn the unit on. If connected to an AC power source, ensure that the outlet
is active by plugging in a lamp or other device. If the unit was just started, the
compressor delay start protection may be active.
Q2: The food inside is frozen when using the unit as a refrigerator.
A2: Increase the target temperature.
Q3: You hear the sound of water moving inside the unit.
A3: This is due to the flow of refrigerant and is normal.
Q4: The display shows an F1 error code.
A4: The battery protection circuit has activated. Change the battery protection level from
Hto Mor L.
Q5: The display shows an F2 error code.
A5: The fan overload protection circuit has activated. Turn the unit off, then restart it after
30 minutes. If the code is still displayed, contact Monoprice Technical Support.
8
Q6: The display shows an F3 error code.
A6: The compressor protection circuit has activated. Turn the unit off, then restart it after
30 minutes. If the code is still displayed, contact Monoprice Technical Support.
Q7: The display shows an F5 error code.
A7: The compressor controller module protection circuit has activated. Turn the unit off
and place it in a well-ventilated area, then restart it after 30 minutes. If the code is still
displayed, contact Monoprice Technical Support.
Q8: The display shows either an F7 or F8 error code.
A8: The temperature sensor has encountered an error. Restart the unit. If the code is still
displayed, contact Monoprice Technical Support.
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
support times and links.
9
SPECIFICATIONS
Model
38594
Climactic Category
T/ST/N/SN
Protective Classification of Electric Shock
Resistance
III
Input Voltage
12/24 VDC
AC Adapter Input Power
100 ~ 240 VAC, 50/60 Hz
Total Power Consumption
45 watts
Rated Current (MAX Mode)
3.75A
Rated Current (ECO Mode)
1.875A
Refrigerant
32g
Weight
34.2 lbs. (15.5 kg)
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
10
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
PURE OUTDOOR™ and the PURE OUTDOOR logo are trademarks of Monoprice Inc.
