Monster Power HTS 5000 User manual

®
Home Theatre
Reference PowerCenter™
HTS5000
Owner’s Manual

i
TABLE OF CONTENTS
Page
Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Proper Grounding and InstallationTips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Monster’s Patented Clean Power Stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
The Design Minds Behind the Monster PowerCenter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Content Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Hookup Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
GroundingYour Cable TV, Satellite Dish, andAntenna Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
HTS5000 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Appendices
A. Glossary ofTerms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
B. Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
C. How to Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
D. Warranty Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

IMPORTANT SAFETY PRECAUTIONS
Please read and observe the following safety points at all times.
WARNING – Power Sources
Do not plug your Monster PowerCenter into a power outlet that differs from the source indicated
for safe use on the Monster PowerCenter. If you don’t know the type of electrical power that is supplied
to your home, please consult your local power company.
WARNING – Grounding and Polarization
A.Your Monster PowerCenter has a three-wire grounding-type AC plug (a three-prong plug).
This plug is designed to be inserted into a grounding-type outlet only. If this plug doesn’t fit directly inside
your outlet, do not attempt to force it into the outlet. [Never attempt to dismantle the plug in any way
(or to alter an extension cord) to make it fit into a two-prong outlet. Do not attempt to defeat the grounding feature
by using a 3-to-2 prong adapter. Instead, call a local electrician to install a properly grounded outlet.]
B. If you use rooftop devices such as satellite dishes, antennas, or any other component with wire
that connects to your PowerCenter, be sure the wire(s) is properly grounded. Use grounding techniques
specified in Section 810 of the National Electrical Code (NEC),ANSI/NFPA 70 (in Canada, Part 1 of the Canadian
Electrical Code).This protects against harmful voltage surges and static discharges.Do not place any part
of an antenna near overhead power lines, or any other power circuit.Do not touch any power line or power circuit.
Doing so may cause you severe physical injury and possibly result in death.
ii

WARNING – Liquid:To Avoid Electrical Shocks
Do not operate your Monster PowerCenter if liquid of any kind is spilled onto or inside the unit.
Do not operate your Monster PowerCenter near rain or water that’s spilled or openly exposed (e.g., bathtub,kitchen
or bathroom sink).
WARNING – Power Cord Safety
A.When routing your Monster PowerCenter AC power cord, do not place it near heat sources
or heavy foot traffic areas (e.g., hallways, doorways, and kitchen floors). Do not create a trip hazard
with the power cord.
B. If your power cord’s protective jacket begins to rip or fray, exposing the internal wiring, shielding,
etc., disconnect it from the power source and discontinue use of the Monster PowerCenter
immediately. See the warranty section of this owner’s manual (page 35).
WARNING – Proper Cleaning
In general, the only cleaning necessary for your Monster PowerCenter is a light dusting.
Unplug your component from the wall outlet before cleaning it.Do not use any type of liquid or aerosol cleaners.
iii

WARNING – Storm Precautions
In the event of a lightning storm, immediately disconnect your Monster PowerCenter
from its power source. After you’ve done this, it’s not necessary to disconnect any components
that are connected to your Monster PowerCenter.
WARNING – No User Serviceable Parts Inside
If, for any reason, your Monster PowerCenter is not operating properly, do not remove any part
of the unit (cover, etc.,) for repair. Unplug the unit and consult this owner’s manual for warranty and service
information.
CAUTION – Exposure To Heat
Do not expose your Monster PowerCenter to direct sunlight or place it near wall heaters, space heaters,
or any enclosed space prone to temperature increase (e.g., car trunk).
iv

PROPER GROUNDING AND INSTALLATION TIPS
CAUTION – Proper Grounding
Monster PowerCenters require a properly grounded 3-wire outlet for safety and to protect connected equipment.
If yourAC outlet is improperly wired (no ground or reverse polarity),the green ”SYSTEM GROUNDED” LED light on
the front panel of the HomeTheatre Reference PowerCenter™HTS5000 will not light up. In this event, call a qualified
electrician to fix the problem in your home’s wiring.
Many older buildings are inadequately wired. It’s very common for a building to be improperly grounded. Building
wiring and grounding must conform to applicable NEC (USA) or CEC (Canada) codes for the $100,000 Limited
Connected EquipmentWarranty to be valid.If you’re not sure about your home’s wiring, have it checked by
a qualified electrician.
Note to CATV Installer
This reminder is provided to call the CATV System Installer’s attention toArticle 820-40 of the NEC that provides
specific guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the
point of cable entry as practical.
IMPORTANT NOTE–Proper Power and Protection
To completely deliver clean power and protect your equipment against electrical surges,every phone, coaxial cable,
orAC power cable in your system must be connected to an appropriate Monster PowerCenter.
IMPORTANT NOTE–Proper Protection and the Limited Connected Equipment Warranty
The $100,000 Limited Connected Equipment Warranty becomes invalid if any wire (phone, coax, or AC), or audio
or video interconnect leading into the equipment comes from a component that is not properly protected by
the Monster PowerCenter.
v

INTRODUCTION
Thank You
Thank you for purchasing Monster Power’s Home Theatre Reference PowerCenter™HTS5000.The PowerCenter
reflects Monster’s commitment to creating performance-enhancing solutions for home theater systems,so you
will enjoy superior picture and sound quality.
OrdinaryAC power accessories compromise the quality of the components they power.The PowerCenter’s advanced
technologies and innovative design solve this problem and offer several unique convenience and performance features.
While your PowerCenter does an excellent job of protecting your components from harmful power surges,its main benefit
is much more than just surge protection.Exclusive Clean Power™filter circuitry virtually stops the noise that goes right
through typical surge protectors. It isn’t enough to only have filtering from a noisy incoming power line.That’s why your
PowerCenter also features revolutionary separate noise isolation between filtered digital,audio,and video outlets.
If any noise from an electronic product plugged into an outlet gets through our Clean Power noise filters and to the power
line, it will have to go through another filter to get to an adjacent set of outlets.The result is high quality picture and sound
that’s free from performance-damaging interference.
Another Monster Power breakthrough is the PowerCenter’s ultra-low loss RF circuitry.While other“line conditioners”
feature coaxial outlets for convenience, their insertion loss can be up to 30dB.The PowerCenter’s incredibly small insertion
loss makes it ideal for all digital coaxial connections such as DBS.
®Your PowerCenter also features an exclusive color-coding
system which identifies which component should be plugged in where and outlet filter type (digital,high current audio,
analog audio, and video).This way, you won’t jeopardize performance by plugging a high current audio component into
an analog audio outlet.
As fellow audiophiles and videophiles, we designed your PowerCenter for the best possible sound and picture.Enjoy!
1

2
MONSTER’S PATENTED CLEAN POWER STAGES
Each PowerCenter has its own Clean Power stage. Clean Power performs two tasks vital to high performance
audio, video and digital reproduction:filtration and isolation.The higher the Clean Power stage,the more
sophisticated and advanced the filters are, to reject noise generated on theAC powerline.Also, the higher
the Clean Power stage,the more isolation between connected equipment for maximum component-generated
noise rejection. HTS5000 features Clean Power Stage 4 for the best possible possible performance.
Clean Power Stage 4: Five ultra-advanced isolated filters including two separate digital filters for separate
digital sources, analog audio, video, and ultra-high current audio filters provide the best possibleAC powerline
noise rejection and isolation of audio equipment from video equipment for improved component-generated
noise rejection. Ideal for audiophile and videophile a/v systems and reference home theatres.

THE DESIGN MINDS BEHIND THE MONSTER POWERCENTER
Richard Marsh –There are few experts able to solve the complex problems of AC power.
Richard Marsh is one of the illustrious few. He has designed best selling power conditioning
components costing more than $3,000 and now brings his expertise to Monster Power.
Richard developed Monster’s exclusive Clean Power™circuitry.He is also responsible for several
other groundbreaking designs. Richard’s background and research into amplifier and capacitor
design led to his development of the Servo-DC feedback concept in power amplifiers – a concept
that is used by virtually every amplifier manufacturer today. His status as both the inventor of
the MultiCap™internal bypass capacitor and as the driving force behind the high-end audio
balanced circuit design concept has influenced the audiophile community for years. Richard
is responsible for some of the high-end audio world’s most respected product designs, essays and articles,and has
contributed to Fi,The Absolute Sound and Audio magazines. He is included in Who’s Who in the West.
Demian Martin – Demian Martin has been solving complex AC power problems for several
years.As a technical consultant for successful paper and steel mills,Demian helped create
several innovative AC power solutions. He developed techniques to dramatically improve the
efficiency of these factories’ high power motor control systems – up to 50,000 watts each.
As a result, they avoided the costly premiums many factories must pay for AC power inefficiency.
He now brings his expertise to Monster Power’s elite research and development team.
3

Noel Lee – Noel Lee is best known for popularizing the concept of high performance audio
cable over 20 years ago with his creation of Monster Cable. Originally a laser-fusion design
engineer at Lawrence Livermore National Laboratory and later a touring musician,Noel has
invented or co-invented over 125 U.S.and international patents and drives the explosive growth
ofThe Monster Group into more than 80 countries worldwide.Monster Power is his realization
of a long-nurtured vision of making affordable power solutions that deliver the best possible
sound and picture.
4

CONTENT CHECKLIST
Before You Begin
Before you do anything, make sure you have everything you need to enjoy the high performance
of your Monster PowerCenter.You’ll need the following items to get started:
1) This owner’s manual.
2) Your favorite pen or a computer with an Internet browser (for registering your warranty information).
3) One Monster Power HomeTheatre Reference PowerCenter™HTS5000.
4) One sheet of Monster Power audio/video ID labels (included).
5) Phone cable, coax cable, and rack ears.
5

PHONE
OUT 1IN
OUT 2
6
HOOKUP GUIDE
STEP 1 DBS/DVD/Phone Line Hookup
NOTE:
The PowerCenter is intended for hookup of a single phone line only.A second line will NOT be connected through
the phone line surge protector.You can use this feature as a phone splitter, however. If the“PHONE IN USE –
OUT 1” LED is on, the phone or Pay-Per-View device plugged into the OUT 1 outlet is in use and Monster’sAccess
Control Unit disengages the OUT 2 outlet. If the “PHONE IN USE – OUT 2” LED is on,the phone or Pay-Per-View
device plugged into the OUT 2 outlet is in use and Monster’s Access Control Unit disengages the OUT 1 outlet.
FOR PAY-PER-VIEW DEVICES (SUCH AS DBS)
A) Connect one end of a phone cable into a telephone wall jack.Plug the other end into the HTS5000
“IN” jack (figure 1a).
B) Connect a second phone cable from one of the HTS5000 “OUT” jacks to the Pay-Per-View input
on your DBS receiver or DVD player (figures 1b and 1c).
FOR STANDARD TELEPHONE LINE PROTECTION (NOT A PAY-PER-VIEW DEVICE)
A) Connect a phone cable from a telephone wall jack to the HTS5000 “IN”jack. Connect a second
phone cable from one of the HTS5000 “OUT” jacks to the telephone (figures 1b and 1c).
Figure 1a
From telephone
wall jack
Figure 1b
To DBS receiver, DVD player,
or telephone
Figure 1
Figure 1c
To DBS receiver, DVD player,
or telephone

STEP 2 Outlet Programming
NOTE:
All PowerCenter outlets located on the rear panel are “programmable”. In order to program each outlet pair, you
must use the recessed slide switches (fig.2).There are two recessed slide switches for each outlet pair that enable
you to program between ”unswitched“,”switched on“, and ”switched on after delay“ settings.You can change the
settings, when necessary. Using the outlet pair labeled as an example, the following diagrams illustrate how to
program the outlets:
7
DC OUT 9~12V 300MA
NO DELAY
DELAY
OUTLET PROGRAMMING SWITCHES
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER OUT
SWITCH
UNSWITCHED SWITCHED DELAY NO DELAY
1
2
3
5
4
1
OUTLETS ALWAYS ON
(UNSWITCHED):
UNSWITCHED SWITCHED DELAY NO DELAY
1
OUTLETS SWITCHED ON:
UNSWITCHED SWITCHED DELAY NO DELAY
Figure 2
Figure 2a
Figure 2b
1
OUTLETS SWITCHED ON
AFTER DELAY:
UNSWITCHED SWITCHED DELAY NO DELAY
Figure 2c
Figure 2d
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
NO DELAY
DELAY TRIGGER OUT
SWITCH
Figure 2e
1

A) Outlet Pair Always On (Unswitched): For components (including yourVCR,TV, etc.) that need to retain
memory, set left slide switch to UNSWITCHED and the right slide switch to either DELAY or NO DELAY (fig. 2a).
B) Outlet Pair Switched On: Set the left slide switch to SWITCHED and the right slide switch to NO DELAY.
(fig. 2b).The outlet pair will be “live” once the PowerCenter is switched on by pressing the front panel ON
button or by external signal when the NORMAL/REMOTE switch is set to REMOTE (see STEP 3 and STEP 4).
However, it will remain active for approximately 10 seconds after switching off the PowerCenter.
C) Outlet Pair Switched On After Delay: Set the left slide switch to SWITCHED and the right slide switch
to DELAY (fig. 2c).When the PowerCenter is switched on by pressing the front panel ON button or by
external signal, the outlet pair will be “live”after a delay set by the DELAY TIME slide switch. However,
the outlet pair will be turned off immediately once the PowerCenter is switched off by pressing the front
panel OFF button or by external signal.
D) Delay Time Switch: Set to the SHORT position, outlets will receive power after an approximate six second
delay, once the PowerCenter is switched on (fig.2d). Set to the LONG position, outlets will receive power
after an approximate twenty second delay, once the PowerCenter is switched on.This is the recommended
delay setting for tube-based products.
NOTE: This switch affects all outlet pairs located on the back panel, if the outlet pair switched on
after delay is selected.
E) Trigger Out Programming Switch: Set to the DELAY position, the 12 volt remote trigger will power
an external device after a delay set by the DELAY TIME slide switch once the PowerCenter is switched on
(fig. 2e). Set to the NO DELAY position, the 12 volt trigger powers an external device as soon as the
PowerCenter is switched on.
8

9
STEP 3 Remote AC Control Hookups
NOTE:
This feature allows you to turn on/off your PowerCenter via yourA/V receiver or preamplifier.You can’t turn off
the PowerCenter using the front panel OFF button when the unit is operating in the REMOTE mode.
A) Plug the RemoteAC Control Cord’s (included) female end into back of your PowerCenter (see diagram below).
B) Switch the NORMAL/REMOTE switch (located on the back of the PowerCenter) to REMOTE.
C) Plug the RemoteAC Control Cord’s 2-prong male end into a switched AC power outlet on a receiver
or preamplifier.When you turn on your receiver or preamplifier the PowerCenter’s outlets programmed
as “switched on” will be turned on immediately. However, the PowerCenter’s outlets programmed
as ”switched on after delay” will be turned on after a delay set by the DELAYTIME switch.
GROUND
IN OUT
IN OUT
IN OUT
CABLE TV
SATELLITE
ANTENNA
PHONE
OUT 1IN
OUT 2
BREAKER 15A
PRESS TO RESET 1800W MAX TOTAL
21 3 4 5
DC IN
9~12V 300MA
REMOTE
AC IN
110V
REMOTE
NORMAL
DC OUT 9~12V 300MA
NO DELAY
DELAY
OUTLET PROGRAMMING SWITCHES
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER OUT
SWITCH
UNSWITCHED SWITCHED DELAY NODELAY
1
2
3
5
4

STEP 4 Remote DC Control Hookups
NOTE:
This feature allows you to turn on/off your PowerCenter via your HomeAutomated Control System.
A component you don’t want powered constantly (such as your projector or surround amplifier) can be plugged into
one of the PowerCenter’s outlets programmed as“switched on” or “switched on after delay”and be remotely
activated when needed.This feature also allows you to use a low voltage cable (not supplied) to remotely control
multiple PowerCenters.
You can’t turn off the PowerCenter using the front panel OFF button when the unit is operating in the REMOTE mode.
A) Plug a 1/8" mini-plug cable (not supplied) into the corresponding outlet on the PowerCenter
(see diagram below).
B) Switch the NORMAL/REMOTE switch (located on the back of the PowerCenter) to REMOTE.
C) Plug the other end of the cable into the corresponding outlet on your component that has a 12 volt
output.When you turn on the component that has a 12 volt output, the PowerCenter’s outlets programmed
as ”switched on” will be turned on immediately.However, the PowerCenter’s outlets programmed as
”switched on after delay” will be turned on after a delay set by the DELAYTIME switch.
GROUND
IN OUT
IN OUT
IN OUT
CABLE TV
SATELLITE
ANTENNA
PHONE
OUT 1IN
OUT 2
BREAKER 15A
PRESS TO RESET 1800W MAX TOTAL
21 3 4 5
DC IN
9~12V 300MA
REMOTE
AC IN
110V
REMOTE
NORMAL
DC OUT 9~12V 300MA
NO DELAY
DELAY
OUTLET PROGRAMMING SWITCHES
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER OUT
SWITCH
UNSWITCHED SWITCHED DELAY NODELAY
1
2
3
5
4
10

11
STEP 5 Coaxial Outlet Hookup
NOTE:
You will need additional coaxial cables to connect the PowerCenter to your components with coaxial/RF connections.
Protect Cable TV, Satellite, and Antenna Connections as Follows:
IN
IN OUT
IN OUT
OUT
CABLE TV
SATELLITE
ANTENNA
ToTV,VCR, or cable box
From grounding block
(connected to
satellite dish)* To satellite receiver
“DISH IN” jack
From grounding block
(connected to antenna)* ToTV,VCR, or signal splitter
From grounding block
(connected to incoming
cableTV line)*
*See page 18 regarding proper grounding.

STEP 6 High Current Audio AC Outlet Hookup
Isolated Clean Power™Stage 4 Ultra-High Audio Current Filter: Optimized for maximum noise rejection,
while providing maximum current to high current audio components.
NOTE:
These outlets are designed to deliver maximum current to power hungry components such as power amplifiers
and receivers.
You may want to program these outlets to be“switched on after delay” (see page 7, fig. 2c) to enable sequential
power activation.This way, power amplifiers are turned on last and turned off first,preventing the “thump”
from getting to your speakers.See “STEP 2: Outlet Programming” (page 7) for details.
A) Attach a Monster Power®ID label to each component’s power cord before you plug it into
the appropriate color-coded PowerCenter outlet.
B) MAIN AMP: Plug the power cord of any separate amplifiers (not preamplifiers) into the PowerCenter’s
corresponding MAINAMP outlet.
C) SURROUND AMP: Plug your dedicated surround amplifier’s power cord into the corresponding
SURROUNDAMP outlet.
12
GROUND
IN OUT
IN OUT
IN OUT
CABLE TV
SATELLITE
ANTENNA
PHONE
OUT 1IN
OUT 2
BREAKER 15A
PRESS TO RESET 1800W MAX TOTAL
21 3 4 5
DC IN
9~12V 300MA
REMOTE
AC IN
110V
REMOTE
NORMAL
DC OUT 9~12V 300MA
NO DELAY
DELAY
OUTLET PROGRAMMING SWITCHES
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER OUT
SWITCH
UNSWITCHED SWITCHED DELAY NODELAY
1
2
3
5
4

13
STEP 7 Analog Audio AC Outlet Hookup
Isolated Clean Power Stage 4 Analog Audio Filter: Optimized to provide maximum noise rejection
for sensitive analog audio components.
NOTE:
Because certain components don’t need to, or shouldn’t be turned on continuously, you should program these outlets
to be “switched on”(see page 7, fig.2b).This means the components plugged into these outlets won’t receive power
or shut down unless your PowerCenter is turned on or off.
You can plug any type of low current analog audio component (e.g.,preamplifier, tape deck) into the corresponding
PREAMP or TAPE outlet.
A) Attach a Monster Power®ID label to each component’s power cord before you plug it into
the appropriate color-coded PowerCenter outlet.
B) PREAMP: Plug your preamplifier’s power cord into the PowerCenter’s corresponding PREAMP outlet.
C) TAPE: Plug your tape deck’s power cord into the correspondingTAPE outlet.
GROUND
IN OUT
IN OUT
IN OUT
CABLE TV
SATELLITE
ANTENNA
PHONE
OUT 1IN
OUT 2
BREAKER 15A
PRESS TO RESET 1800W MAX TOTAL
21 3 4 5
DC IN
9~12V 300MA
REMOTE
AC IN
110V
REMOTE
NORMAL
DC OUT 9~12V 300MA
NO DELAY
DELAY
OUTLET PROGRAMMING SWITCHES
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER OUT
SWITCH
UNSWITCHED SWITCHED DELAY NODELAY
1
2
3
5
4

STEP 8 Video AC Outlet Hookup
Isolated Clean Power Stage 4 Video Filter: Optimized to reduce noise generated by video equipment.
Isolates video components from connected digital, analog audio and video components for maximum rejection
of interference.
NOTE:
You may want to program these outlets to be“unswitched” (see page 7,fig. 2a) because some components perform best
when powered continuously.AVCR, for example,should be plugged into one of these outlets to avoid the hassle
of resetting its clock when power is interrupted.Whether you turn your PowerCenter on or off, any component
plugged into these outlets can receive power continuously as long as your PowerCenter is plugged into a properly
grounded 120-volt wall socket and the OUTLET PROGRAMMING SWITCHES for the outlet pair are set to “unswitched”.
You can plug any type of analog video component (e.g.,VCR, camcorder) into these twoVideoAC outlets.
A) Attach a Monster Power®ID label to each component’s power cord before you plug it into the appropriate
color-coded PowerCenter outlet.
B) VCR: Plug yourVCR’s power cord into the PowerCenter’s corresponding
AV RECEIVER outlet.
C) TV: Plug your TV’s power cord into the corresponding TV outlet.
GROUND
IN OUT
IN OUT
IN OUT
CABLE TV
SATELLITE
ANTENNA
PHONE
OUT 1IN
OUT 2
BREAKER 15A
PRESS TO RESET 1800W MAX TOTAL
21 3 4 5
DC IN
9~12V 300MA
REMOTE
AC IN
110V
REMOTE
NORMAL
DC OUT 9~12V 300MA
NO DELAY
DELAY
OUTLET PROGRAMMING SWITCHES
DELAY TIME
SWITCH
LONG
(20 seconds)
SHORT
(6 seconds)
TRIGGER OUT
SWITCH
UNSWITCHED SWITCHED DELAY NODELAY
1
2
3
5
4
14
