montpellier MIFF701 User manual

Integrated 70/30 Fridge Freezer
MIFF701 - Static
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

Thank you for choosing this Montpellier Integrated Fridge Freezer.
Our refrigeration products have been designed to provide you with the best combination of style, reliability and
performance to give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Fridge Freezer to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Integrated Fridge Freezer is covered by a comprehensive five year Parts
& Labour Guarantee. In the unlikely event that you experience a problem with
your Fridge, you can rest assured that you are fully protected against the
cost of repairs for the first 5 Years. Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS INTEGRATED COOLING
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com

Please read this manual first!
Dear Customer,
Congratulations on your choice of a quality appliance which
has been designed to give you excellent service.
•This manual will help you use your appliance quickly and safely.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those about safety warnings.
• Keep the manual in an easily accessible place as you may need it later.
• Also read the other documents provided with your product.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning for possible hazards to health & property.
BWarning possibility of electric shock.

EN
CONTENTS
1 Your Fridge Freezer 3
2 Warnings 4
Compliance with WEEE Directive and
Disposing of the Waste Product: ....... 4
Compliance with RoHS Directive: ...... 5
Package information .......................... 5
Electrical Requirements ..................... 5
Warning! This Appliance Must Be
Earthed .............................................5
Energy Saving Tips ............................ 6
Disposing of the packaging ............... 6
Disposing of your old appliance ......... 6
3 Preparation 7
Before operating your Fridge Freezer .....7
Electric connection ............................7
Placing and Installation ...................... 7
Replacing the interior lamp ................ 8
4Installation 9
5 Using your Appliance 19
Temperature control and
adjustment.................... .............19
Defrost ............................................19
6 Maintenance and
cleaning 21
Protection of plastic surfaces .......... 21
7 Possible solutions for any
problems 22
Reversing the doors.........................10
Installation instructions
detailed step by step........................12
2

EN
3
1 Your Fridge Freezer
1) Thermostat control
2) Interior Light (with audible alarm
where applicable)
3) Adjustable body shelves
4) Defrost water collection channel
- drain tube
5) Crisper
6) Fast-freeze compartment
7 ) Deep-freeze compartment
8) Adjustable door shelves
9) Egg holder
10) Bottle shelf
11) Fridge compartment
12) Freezer compartment
2
3
6
7
3
7
3
8
4
1
11
12
9
10
5
8
8
C
Please note the illustration above is generic and may include features
not included with on your specific model.

EN
4
2 Warnings
• DO NOT connect your appliance to the
electricity supply until all packing and
transit protectors have been removed.
• Leave to stand for at least 4 hours before
switching on to allow compressor oil to
settle if transported horizontally.
• If you are discarding an old refrigerator
with a lock or latch fitted to the door,
disable the lock/latch, ensure that it is
left in a safe condition to prevent the
entrapment of young children.
• This fridge/freezer must only be used for
its intended purpose i.e the storing and
freezing of edible foodstuff.
• Do not dispose of the appliance
on a fire. At , the care
and protection of our environment is an
ongoing commitment. This appliance
which is among the latest range
introduced is particularly environment
friendly. Your appliance contains non
CFC/HFC natural substances in the
cooling system
(Called R600a) and in the insulation
(Called cyclopentane) which are
potentially flammable if exposed to fire.
Therefore, take care not to damage, the
cooling circuit /pipes of the appliance in
transportation and in use. In case of
damage do not expose the appliance to
fire or potential ignition source and
immediately ventilate the room where
the appliance is situated.
• We suggest you contact your local
authority for disposal information and
facilities available.
• See Installation Instructions on page 7
for information on suitable location.
• To obtain the best possible
performance and trouble free
operation from your appliance it is
very important to carefully read these
instructions.
• On delivery, check to make sure that
the product is not damaged and that
all the parts and accessories are in
perfect condition.
• Ensure that the plug remains readily
accessible. Do not use multiple
adapter bar or extension cable.
• Failure to observe these instructions
may invalidate your right to free
service during the guarantee period.
• Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances
inside the food storage
compartments of the appliance.
• We suggest you keep these
instructions in a safe place for easy
reference.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This
product bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).This product has
been manufactured with

EN
5
*-88)(;-8,
&7%*97)%0;%=7
*-8&76)40%')1)28
'%686-(+)*97)
+6))2
=)003;
36
+6))2
N
&09)
36
&0%'/
L
&63;2
36
6)(
QQ
QQ
QQ
QQ QQ
QQ
FUSE
CORD GRIP
WARNING: When positioning the
appliance ensure the supply cord is
not trapped or damaged.
Should the mains lead of the appliance
become damaged or should it need
replacing at any time, it must be
replaced by a special purpose made
mains lead which can only be obtained
from a MONTPELLIER Authorised
Service Agent.
high quality parts and materials which
can be reused and are suitable for
recycling. Do not dispose of the waste
product with normal domestic and
other wastes at the end of its service
life. Take it to the collection center for
the recycling of electrical and
electronic equipment. Please consult
your local authorities to learn about
these collection centers.
Compliance with RoHS
Directive:
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities
Electrical Requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown on the rating
plate inside the appliance corresponds
to your electricity supply.
Rating label is on the left hand side of
fridge inner liner.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket.
The appliance must be positioned so
that the plug is accessible.
Warning! This Appliance
Must Be Earthed
If the fitted moulded plug is not
suitable for your socket, then the plug
should be cut off and an appropriate
plug fitted. Destroy the old plug which
is cut off as a plug with bared cord
could cause a shock hazard if inserted
into a socket elsewhere in the house.
The moulded plug on this appliance
incorporates a 13 A fuse. Should
the fuse need to be replaced an
ASTABEAB approved BS 1362 fuse of
the same rating must be used. Do not
forget to refit the fuse cover. In the
event of losing the fuse cover the plug
must not be used until a replacement
fuse cover has been fitted.

EN
6
Important! Fitting A Different Plug
As the colours of the wires in the
mains lead of this appliance may not
correspond with the coloured
markings identifying the terminals in
your plug proceed as follows: (See
diagram).
1. Connect the green-yellow or green
(Earth) wire to the terminal in the plug
marked ‘E’ or with the symbol or
coloured green and yellow or green.
2. Connect the blue (Neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3. Connect the brown (Live) wire to
the terminal in the plug marked ‘L’
or coloured red.
With alternative plugs a 13 A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
Energy Saving Tips
1. Ensure your appliance is installed in
a well ventilated area.
2. Ensure the time between buying
chilled/frozen food and placing them
in your appliance is kept at
minimum, particularly in summer. We
recommend you use a cool bag or a
special carrier bag to carry
perishable food.
3. Do not leave the door (s) of your
appliance open longer than
necessary and ensure they are
closed properly after each opening.
4. Defrost frozen food in the fridge
compartment, so that frozen food
acts as an ice pack to assist cooling
in the fridge.
5. Energy consumption of this
appliance is measured while freezer
compartment is loaded without
use of top shelf lid and the drawers
except the bottom drawer. It is advised
that freezer compartment is loaded
without use of drawers except the
bottom drawer in order to achieve
maximum loading capacity.
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance
with the waste instructions. Do not
dispose of them along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
appliance
Dispose of your old appliance without
causing harm to the environment.
• Please seek advice from your local
Council waste & Refuse Dept.
Before disposing of your appliance,
cut off the electric plug and, if there
are any locks on the door, make
them inoperable in order to protect
children against any danger.

EN
7
3 Preparation
B Please remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Before operating your Fridge
Freezer
Before starting to use your Fridge Freezer
check the following:
1.Is the interior of the Fridge Freezer dry
and can the air circulate freely in the
rear of it?
2.Clean the interior of the Fridge
Freezer as recommended in the
“Maintenance and cleaning” section.
3.Plug the Fridge Freezer into the wall
outlet. When the fridge door is open,
the fridge compartment interior light
will come on.
4.You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
5.Front edges of the Fridge Freezer may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation
Electric connection
Connect your product to an earthed
socket which is being protected by a
fuse with the appropriate capacity.
Important:
• The connection must be in compliance
with national regulations.
• The power cable plug must be easily
accessible after installation.
• The specified voltage must be equal to
your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
B A damaged power cable must be
replaced by a qualified electrician.
Placing and Installation
1. Install your fridge freezer in a place that
allows ease of use.
2. Keep your fridge freezer in away from
heat sources, humid places and direct
sunlight.
3. There must be appropriate air
ventilation around your fridge freezer in
order to achieve an efficient operation.
If the refrigerator is to be placed in a
recess in the wall, there must be at
least 5 cm distance with the ceiling and
at least 5 cm with the wall. If the floor i
covered with a carpet, your product
must be elevated 2.5 cm from the floor.
4. Place your fridge freezer on an even
surface to prevent jolts.
5. Do not keep your fridge freezer in
ambient temperatures under 10°C.
WARNING: Do not locate extension
sockets or charging transformers/power
supplies or Lithium-Iron battery operated
products adjacent to the compressor
as they could overheat.

EN
8
IMPORTANT: This freezer contains very
cold elements and components. To
prevent injury; when using this product
ensure your hands are dry and avoid
prolonged skin contact with cold parts
and foodstuffs.
-Do not touch frozen food or frozen
surfaces with wet hands.
-Avoid prolonged touching of frozen
food, ice, frozen surfaces.
- Possibility of low-temperature burns!
If freezing to frozen surface occurs:
- DO NOT TEAR AWAY! -- use cool
water to release.
FIRST AID ( if necessary): Hold affected
area under cold running water
Replacing the interior lamp
To change the Bulb/LED used for
illumination of your refrigerator,
call your AuthorisedService.
The lamp(s) used in this appliance is not
suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in a
safe and comfortable way.
The lamps used in this appliance have
to withstand extreme physical
conditions such as temperatures below
-20°C.

EN
9
4 Installation
C Do not place the appliance near
cookers, radiators or in direct sunlight
as this will cause your appliance to
work harder. If next to a source of
heat ; maintain the following minimum
side clearances:
From cookers 50mm (2”)
From radiators 300mm (12”)
From freezers 25mm (1”)
C The ambient temperature of the
room where you install your fridge
freezer should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
C Please make sure that the interior
of your fridge freezer is cleaned
thoroughly.
C If two appliances are to be installed
side by side, there should be at least
2 cm distance between them.
C When you operate your fridge freezer
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your fridge freezer. If
a power failure occurs out of your
control, please see the warnings
in the “Possible solutions for the
problems” section.

EN
10
REVERSING THE DOORS
Top Door
1.Unscrew top hinge (1).
2.Carefully remove the top door (2).
3.Unscrew lower hinge (3).
4.Remove plastic plugs (7 & 8).
5.Refit top hing (1) as lower hinge (17) on the left hand side.
6.Replace top door (18).
7.Refit lower hing (3) as top hinge (19) on the left hand side.
Lower door
1.Unscrew top hinge (4).
2.Carefully remove the lower door (5).
3.Unscrew lower hinge (6).
4.Remove plastic plugs (9 & 10).
5.Refit hinge (4) as lower hinge (12) on the left hand side.
6.Replace lower door (13).
7.Refit lower hing (6) as top hinge (14) on the left hand side.
Refit plastic plugs (7, 8, 9 & 10) into the s rew holes on the right hand
side (15, 16, 20 & 21).

EN
11
Reversing the doors
Proceed in numerical order
1
4
3
6
2
5
7
8
9
10
17
19
20
21
15
16
18
13
14
12

EN
12
Installation instructions
detailed step by step
545
540
1775
1001
32
71
40
629
1775
1778-1788
1001
555
No wooden
back wall
Adjusting the legs (*optional)
If your refrigerator is unbalanced:
You can balance your refrigerator by turning the legs of it as illustrated in the figure. The corner where the
leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite
direction. Taking help from someone to slightly lift the refrigerator will facilitate this process.
-JXLIWYFNIGXTEVXWEVIRSXMRGPYHIHMRXLITVSHYGX]SYLEZI YVGLEWIHXLIRMXMWZEPMHJSVSXLIVQSHIPW
The backwall of the wooden cabinet must be left open completely to kitchen wall in order to
allow sufficient air circulation to cool down the condenser unit for energy efficiency.

EN
13
629
40 71
1001
1778-1788

EN
14
90o
2
1
3
5
1
a
4
b
PS
PS
≤ 17
Torx
(T)
x6
Wood
(W)
x15
Plastic Sheet
(PS)
x12
Wood
(1TW)
x3
42 mm
Top
view
5
* Spares Included
Note: Installation step for 2, screws for connecting top plastic part should not be screwed very hard,
because of moving the plastic part easily left or right side.

EN
15
1
23
45
6
(T)
7

8
10
9
11
(T)
42.0 mm
42.0 mm
(1TW)
12
42,0 mm
42,0 mm
EN
16

EN
17
14
13
(T)
(1TW)
15
17
16
(1TW)
42,0 mm
42,0 mm
(W)
2.0 mm
18

EN
18
20
22
90o
21 mm
(W)
19
21
W
2 mm
2 mm
2 mm
