montpellier MNF167EW User manual

Freestanding No Frost Fridge Freezer
MNF167EW/ES/EBK - White/Silver/Black
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING

We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be accompanied
by the model reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
•
•
Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing or
using your appliance to ensure you get the most from your purchase.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation and
maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this book for
future reference.
The design and specifications are subject to change without prior notice for product improvement.

4-8
9
10-12
13-14
Contents
Section 1 : Safety Info
Section 2: Overview
Section 3: Reversing the Door
Section 4: Installation
Section5: User Interface
Section 6:Daily Use - Using The Appliance
Section 7: Product Information Sheet
Section 8:Here For You - Service Details
15-16
21-22
23
17-20

Safety information
In the interest of your safety and to ensure the correct use, before
installing and first using the appliance, read this user manual carefully,
including its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to ensure that all people using the appliance
are thoroughly familiar with its operation and safety features. Save
these instructions and make sure that they remain with the appliance if
it is moved or sold, sothat everyone using it through its life will be
properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user’s
instructions as the manufacturer is not responsible for damages
caused by omission.
Children and vulnerable people safety
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given super vision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children aged from 3 to 8 years are allowed to load and unload this
appliance.
Children should be supervised to ensure that they do not play with the
appliance.
Cleaning and user maintenance shall not be made by children unless
they are aged from 8 years and above and supervised.
Keep all packaging well away from children. There is risk of
suffocation.
If you are discarding the appliance pull the plug out of the socket, cut
the connection cable (as close to the appliance as you can) and
remove the door to prevent playing children to suffer electric shock
or toclose themselves into it.
If this appliance featuring magnetic door seals is to replace an older
appliance having a spring lock (latch) on the door or lid, be sure to
make that spring lack unusable before you discard the old appliance.
This will prevent it from becoming a death trap for a child.
General safety
WARNING! The fridge freezer needs to be stood upright for a minimum of
4 hours before it is turned on.
WARNING! Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
4

Safety information
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
The refrigerant isobutane (R-600a) is contained within the refrigerant
circuit of the appliance, a natural gas with a high level of environmental
compatibility, which is nevertheless flammable.
During transportation and installation of the appliance, be certain that
none of the components of the refrigerant circuit become damaged.
-avoid open flames and sources of ignition
-thoroughly ventilate the room in which the appliance is situated
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire and/or electric shock.
This appliance is intended to be used in household and domestic
applications only.
WARNING! Any electrical components (plug, power cord, compressor
and etc.) must be replaced by a certified service agent or qualified
service personnel.
WARNING! The light bulb supplied with this appliance is a “special use
lamp bulb” usable only with the appliance supplied. This “special use
lamp” is not usable for domestic lighting.1)
1) If there is a light in the compartment.
WARNING! Do not use other electrical appliances (such as ice
cream makers) inside of refrigerating appliances, unless they are
approved for this purpose by the manufacture.
WARNING! Do not touch the light bulb if it has been on for a long
period of time because it could be very hot.1 )
WARNING! When positioning the appliance, ensure the supply
cord is not trapped or damaged.
WARNING! Do not locate multiple portable socket-outlets or
portable power suppliers at the rear of the appliance.
5

Safety information
1) If there is a freezer compartment.
2) If there is a fresh-food storage
compartment.
Power cord must not be lengthened.
Make sure that the power plug is not squashed or damaged by the
back of the appliance. A squashed or damaged power plug may
overheat andcause afire.
Make sure that you can access the mains plug of the appliance.
Do not pull the mains cable.
If the power plug socket is loose, do not insert the power plug. There
is arisk of electric shock or fire.
You must not operate the appliance without the lamp.
This appliance is heavy. Care should be taken when moving it.
Do not remove nor touch items from the freezer compartment if you
hands are damp/wet, asthis could cause skin abrasions or
frost/freezer burns.
Avoid prolonged exposure of the appliance to direct sunlight.
Daily use
Do not put anything hot on the plastic parts in the appliance.
Do not place food products directly against the rear wall.
Frozen food must not be re-frozen once it has been thawed out.1 )
Store pre-packed frozen food in accordance with the frozen food
manufacture, s instructions.1 )
Appliance, s manufactures storage recommendations should be
strictly adhered to. Refer to relevant instructions.
Do not place carbonated of fizzy drinks in the freezer compartment as
it creates pressure on the container, which may cause it to explode,
resulting in damage to the appliance.1 )
Ice lollies can cause frost burns if consumed straight from the
appliance.1 )
To avoid contamination of food, please respect the following
instructions
Opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance.
Clean regularly surfaces that can come in contact with food and
accessible drainage systems.
Clean water tanks if they have not been used for 48h; flush the water
system connected to a water supply if water has not been drawn for 5
days.
Store raw meat and fish in suitable containers in the refrigerator, so
that it is not incontact with or drip onto other food.
Two-star frozen-food compartments (if they are presented in the
appliance) are suitable for storing pre-frozen food, storing or making
ice-cream and making ice cubes.
6

Safety information
1) If there is a freezer compartment.
2) If there is a fresh-food storage
compartment.
Care and cleaning
 Before maintenance, switch off the appliance and disconnect the
mains plug from the mains socket.
 Do not clean the appliance with metal objects.
 Do not use sharp objects to remove frost from the appliance. Use a
plastic scraper.1 )
 Regularly examine the drain in the refrigerator for defrosted water. If
necessary, clean the drain. If the drain is blocked, water will collect in
the bottom of the appliance.2 )
Installation
Important! For electrical connection carefully follow the instructions
given in specific paragraphs.
 Unpack the appliance and check if there are damages on it. Do not
connect the appliance if it is damaged. Report possible damages
immediately to the place you bought it. In that case retain packing.
 It is advisable to wait at least four hours before connecting the
appliance to allow the oil to flow back in the compressor.
 Adequate air circulation should be around the appliance, lacking this
leads to overheating. To achieve sufficient ventilation, follow the
instructions relevant toinstallation.
 Wherever possible the spacers of the product should be against a
wall to avoid touching or catching warm parts (compressor, con-
denser) to prevent possible burn.
 The appliance must not be located close to radiators or cookers.
 Make sure that the mains plug is accessible after the installation of
the appliance.
Service
 Any electrical work required to do the servicing of the appliance
should be carried out by a qualified electrician or competent person.
 This product must be serviced by an authorized Service Center, and
only genuine spare parts must beused.
Energy saving
 Don’t put hot food in the appliance;
 Don’t pack food close together as this prevents air circulating;
 Make sure food don’t touch the back of the compartment(s);
One-, two- and three -star compartments (if they are presented in the
appliance) are not suitable for the freezing of fresh food.
If the appliance is left empty for long periods, switch off, defrost,
clean, dryand leave the door open to prevent mould developing
within the appliance.
7

Safety information
 If electricity goes off, don’t open the door(s);
 Don’t open the door(s) frequently;
 Don’t keep the door(s) open for too long time;
 Don’t set the thermostat on exceeding cold temperatures;
 All accessories, such as drawers, shelves, and balconies should be kept
there for lower energy consumption.
Environment Protection
This appliance does not contain gasses which could damage the
ozone layer, in either its refrigerant circuit or insulation materials. The
appliance shall not be discarded together with the urban refuse and
rubbish. The insulation foam contains flammable gases: the appliance
shall be disposed according to the appliance regulations to obtain
from your local authorities. Avoid damaging the cooling unit, especially
the heat exchanger. The materials used on this appliance marked by
the symbol are recyclable.
The symbol on the product or on its packaging indicates that
this product may not betreated as household waste. Instead it
should be taken to the appropriate collection point for the
recycling of electrical and electronic equipment. By ensuring this
product isdisposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product,
please contact your local council, your household waste disposal
service or the shop where you purchased the product.
Packaging materials
The materials with the symbol are recyclable. Dispose the packaging in
a suitable collection container to recycle it.
Disposal of the appliance
1. Disconnect the mains plug from the mains socket.
2. Cut off the mains cable and discard it.
WARNING! During using, service and disposal the appliance,
please pay attention to symbol as left side, which is located on
rear of appliance (rear panel or compressor.
It’s risk of fire warning symbol. There are flammable materials in
refrigerant pipes and compressor.
Please be far away fire source during using, service and
disposal.
8

Overview
Note: Above picture is for reference only. Real appliance may vary slightly.
Freezer
Drawers
Fridge
Balconies
Fridge
Shelves
Crisper
Crisper Cover
Thermostat and Light
Leveling Feet
9

Reversing the Door
1. Unscrew top hinge cover and then unscrew the top hinge .
Then lift upper door and place it on a soft pad to avoid scratch and damage.
. Remove the top left screw cover.
Left Door Hinge Cover x 1
Door Reversibility
Before reversing the door, please be prepared below tools and material: straight screwdriver,
cross screwdriver, spanner and the components included in the poly bag:
"!-&.#'"!-&"+#'
10

Reversing the Door
1
2
3. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,then
take off the lower door.
4. Laying down the refrigerator, take out the adjusting feet as below, then take off the lower hinge
using the cross screwdriver.
5. Adjusting the hinge core position of the lower hinge and upper hinge to opposite position
6. Install the lower hinge under to the refrigerator like below, screwing in the adjusting feet, make
sure the position in horizon.
11

Reversing the Door
9. Place the upper door back on. Ensure the door is aligned horizontally and vertically so that the seal are
closed on all sides before finally tightening the top hinge. Then inert the top hinge and screw it to the top of
unit and then fix hinge cover (in accessary bag) by screw.
10. Fix the screw
cover.
8.Install the lower door, adjust and fix the middle hinge onto the cabinet.
7# ))5!% !)56!% / !)  )),  %
12

Installation
Space Requirement
•Keep enough space to allow the door to open.
•Keep at least a 50mm gap at both sides and above when up
against a solid wall/unit.
A 545
B 620
C 1670
Dmin=50
Emin=50
G930
Fmin=50
H1170
I 135°
F F
F
I
Levelling the unit
To do this adjust the two levelling feet at front of the unit.
If the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
13

Installation
Warning! It must be possible to disconnect the appliance from the mains power supply; the plug must
therefore be easily accessible after installation.
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your domestic
power supply.
The appliance must be earthed.
The power supply cable plug is provided with a contact for this purpose. If the domestic power supply socket is
not earthed, connect the appliance to a separate earth in compliance with current regulations, consulting a
qualified electrician.
The manufacturer declines all responsibility if the above safety precautions are not observed.
This appliance complies with the E.E.C. Directives.
14
Positioning
Install this appliance at a location where the ambient temperature corresponds to the climate class
indicated on the rating plate of the appliance (see below also).
For refrigerating appliances with climate class:
-Extended Temperate (SN): this refrigerating appliance is intended to be used at ambient
temperatures ranging from 10
'C to 32'C;
-Temperate (N): this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16'C to 32'C;
-Subtropical (ST): this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16'C to 38'C;
-Tropical (T): this refrigerating appliance is intended to be used at ambient temperatures ranging
from 16'C to 43'C;
Location
The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight etc.
Ensure that air can circulate freely around the back of the cabinet.
To ensure best performance, if the appliance is positioned below an overhanging wall unit, the minimum distance
between the top of the cabinet and the wall unit must be at least 100 mm. Ideally, however, the appliance should
not be positioned below overhanging wall units as this impairs the flow of hot air from the rear of the appliance.
Accurate leveling is ensured by one or more adjustable feet at the front base of the cabinet
This refrigerating appliance is not intended to be used as a built-in appliance so under no circumstances should it
be enclosed in any unit and never be placed behind a door.

9KZ
Super 9[VKXY
12
A
User interface
1.
1.1 Operation button
1.2 Indicators
Temperature setting of fridge compartment
Fridge temperature setting Panel
1.3 Super mode
Activate super mode:
Keep pressing the button for 3 seconds, Super Mode will then be activated.
The indicator will be illuminated.
Quitting Super mode:
y Press Set button ( A ) for over 3 seconds
y Or the appliance will automatically restore to original setting when Super
mode has been running for more than 50 hours.
2.Temperature setting of freezer compartment
Freezer temperature setting slider:
●This slider in fridge compartment is used to adjust temperature of freezer
compartment.
●Slider is positioned toward ,the temperature in freezer compartment will be
higher. Contrarily the temperature in freezer compartment will be lower if the slider
is moved toward
●Middle position of slider is advised position for normal using.
,8++@+8)54:852
15
Set button (A):
Short press this button to select running temperature. Keep pressing this button
for 3s to select “Super” mode.
Super
When super mode is activated, fridge temperature will remain as previously set
and can not be changed by pressing button. The freezer will be in Super
Freeze mode and run to a lower temperature.
Set
Super mode indicator (1): The light is on when Super mode is selected.
Temperature setting indicators (2): These will light according to the related
temperature set.
Set
Set

User interface
3. Temperature setting recommendation
Environment
Temperature Fridge Compartment Freezer Compartment
Temperature setting recommendation
Warm
Normal
Cold
16
>27oC
17oC~27oC
<17oC
SuperSuper
SetSet
Super/3s Super/3s
SuperSuper
SetSet
Super/3s Super/3s
SuperSuper
SetSet
Super/3s Super/3s
WARNING! Please never position the slider at left as below.

Daily Use
First use
Cleaning the interior
Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm
water and some neutral soap so as to remove the typical smell of a brand new product, then dry thoroughly.
Important! Do not use detergents or abrasive powders, as these will damage the finish.
Daily use
Position different food in different compartments according to be below table
Storing frozen food
When first starting-up or after a period out of use. Before putting the product in the compartment let the
appliance run at least 2 hours on the higher settings.
Important! In the event of accidental defrosting, for example the power has been off for longer than
the value shown in the technical characteristics chart under “rising time”, the defrosted food must be
consumed quickly or cooked immediately and then re-frozen (after cooked).
Thawing
Deep-frozen or frozen food, prior to be used, can be thawed in the freezer compartment or at room
temperature, depending on the time available for this operation.
Small pieces may even be cooked still frozen, directly from the freezer. In this case, cooking will take
longer.
Refrigerator compartments Type of food
Door or balconies of fridge
compartment
Foods with natural preservatives, such as jams,juices,
drinks, condiments.
Do not store perishable foods.
Fruits, herbs and vegetables should be placed
separately in the crisper bin.
Do not store bananas, onions, potatoes, garlic in
Crisper drawer (salad drawer)
Fridge shelf – middle Dairy products, eggs
Fridge shelf – top Foods that do not need cooking, such as ready-to-eat foods,
deli meats, leftovers.
Foods for long-term storage.
Bottom drawer/shelf for raw meat, poultry, fish.
Middle drawer/shelf for frozen vegetables, chips.
Top drawer/shelf for ice cream, frozen fruit, frozen
Freezer drawer(s)/shelf
Freezing fresh food
yThe freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for
along time.
yPlace the fresh food to be frozen in the bottom compartment.
yThe maximum amount of food that can be frozen in 24 hours is specified on the rating plate.
yThe freezing processlasts 24 hours: during this period do not add other food to be frozen.
yIn order to get bigger freezing capacity, please put unfrozen food into freezer compartment after you
have started super mode for 26 hours.
17

Daily Use
ythe maximum quantity of food which can be frozen in 24 hrs. is shown on the rating plate;
ythe freezing process takes 24 hours. No further food to be frozen should be added during this period;
yonly freeze top quality, fresh and thoroughly cleaned, foodstuffs;
yprepare food in small portions to enable it to be rapidly and completely frozen and to make it possible
subsequently to thaw only the quantity required;
ywrap up the food in aluminium foil or polythene and make sure that the packages are airtight;
ydo not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding a rise in
temperature of the latter;
ylean foods store better and longer than fatty ones; salt reduces the storage life of food;
ywater ices, if consumed immediately after removal from the freezer compartment, can possibly cause
the skin to be freeze burnt;
yit is advisable to show the freezing in date on each individual pack to enable you removal from the
freezer compartment, can possibly cause the skin to be freeze burnt;
yit is advisable to show the freezing in date on each individual pack to enable you to keep tab of the
storage time.
Helpful hints and tips
Hints for freezing
To help you make the most of the freezing process, here are some important hints:
 ?;,#;
2#+#">+#
###;,!
"#,
Door balconies can be disassembled for cleaning. To make the disassembling
as follows: gradually pull the balcony in the direction of the arrows until it
comes free, after cleaning, reposition it.
Disassemble the bottom drawer
1.Pull out the bottom drawer to stopper position.
2.Lift up the front of drawer.
3.Pull out the bottom drawer.
18

Daily Use
Cleaning
For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
Caution! The appliance may not be connected to the mains during cleaning. Danger of electrical
shock! Before cleaning switch the appliance off and remove the plug from the mains, or switch off or
turn out the circuit breaker or fuse. Never clean the appliance with a steam cleaner. Moisture could
accumulate in electrical components, danger of electrical shock! Hot vapors can lead to the damage
of plastic parts. The appliance must be dry before it is placed back into service.
Important! Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice form
orange peel, butyric acid, cleanser that contain acetic acid.
yDo not allow such substances to come into contact the appliance parts.
yDo not use any abrasive cleaners
yRemove the food from the freezer. Store them in a cool place, well covered.
ySwitch the appliance off and remove the plug from the mains, or switch off or turn out the circuit breaker
of fuse.
yClean the appliance and the interior accessories with a cloth and lukewarm water. After cleaning wipe
with fresh water and rub dry.
yAfter everything is dry place appliance back into service.
Hints for storage of frozen food
To obtain the best performance from this appliance, you should:
make sure that the commercially frozen foodstuffs were adequately stored by the retailer;
be sure that frozen foodstuffs are transferred from the food store to the freezer in the shortest possible
time;
not open the door frequently or leave it open longer than absolutely necessary.
Once defrosted, food deteriorates rapidly and cannot be refrozen.
Do not exceed the storage period indicated by the food manufacture.
Hints for fresh food refrigeration
To obtain the best performance:
yDo not store warm food or evaporating liquids in the refrigerator
yDo cover or wrap the food, particularly if it has a strong flavour
Hints for refrigeration
Useful hints:
yMake (all types): wrap in polythene bags and place on the glass shelves above the vegetable drawer.
yFor safety, store in this way only one or two days at the most.
yCooked foods, cold dishes, etc...: these should be covered and may be placed on any shelf.
yFruit and vegetables: these should be thoroughly cleaned and placed in the special drawer(s) provided.
ybutter and cheese: these should be placed in special airtight containers or wrapped in aluminum foil or
polythene bags to exclude as much air as possible.
yMilk bottle: these should have a cap and should be stored in the balconies on the door.
yBananas, potatoes, onions and garlic, if not packed, must not be kept in the fridge.
19

'DLO\8VH'DLO\8VH
;
<9  .
Troubleshooting
Caution! Before troubleshooting, disconnect the power supply. Only a qualified electrician of
competent person must do the troubleshooting that is not in this manual.
Important! There are some sounds during normal use (compressor, refrigerant circulation).
If the malfunction shows again, contact the Service Center.
These data are necessary to help you quickly and correctly. Write the necessary data here, refer to the
rating plate.
Mains plug is not plugged in
or is loose
Check fuse, replace if necessary.
Socket is defective
Mains malfunctions are to be
corrected by an electrician.
Problem Solution
Fuse has blown or is defective
Insert mains plug.
Unusual noises
Appliance is not level.
The appliance is touching the
wall or other objects.
Re-adjust the feet.
Move the appliance slightly.
A component, e.g. a pipe, on
the rear of the appliance is
touching another part of the
appliance or the wall.
If necessary, carefully bend the
component out of the way.
Possible cause
Appliance does not
work
Temperature regulation knob is
set at coldest
Set the knob at other switch on the
appliance.
Water drain hole is blocked.
Water on the floor
See the Cleaning and Care section.
Side panels are hot.
It’s normal. Heat exchange
parts are in the sides. Take gloves to touch sides if needed.
Appliance freezes or
cools too much
Turn the temperature regulator to a
warmer setting temporarily.
Temperature is set too cold or
t
he appliance runs at coldest.
Temperature is not properly
adjusted.
Please look in the initial
Te
mperature Setting section.
Door was open for an extended
period.
Open the door only as long as
n
ecessary.
A large quantity of warm food
w
as placed in the appliance
within the last 24 hours.
Turn the temperature regulation to a
c
older setting temporarily.
The food is not frozen
e
nough.
Please look in the installation
location section.
The appliance is near a heat
source.
Door seal is not air tight.
Heavy build up of
frost on the door
s
eal.
Carefully warm the leaking sections
o
f the door seal with a hair dryer (on
a cool setting). At the same time
s hape the warmed door seal by
hand such that it sits correctly.
20
