montpellier MWDI7554 User manual

Installation and Operating Instructions
Model: MWDI7554
INTEGRATED WASHER DRYER
Please read these instructions carefully before attempting to install or use this appliance.
It is advisable to keep these instructions in a safe place for future reference.
7.5kg Wash – 5kg Dry

2
Introduction
Thank you for choosing this Montpellier appliance. It has been
designed to give years of trouble-free use provided it is installed and
maintained correctly.
Please read these instructions carefully before installing or using your
appliance. It is advisable to keep your purchase and installation receipts
with these instructions in a safe place for future reference. Included is
some important safety information in addition to guidelines and
recommendations that will enable you to take full advantage of all the
functions available.
This quality appliance has been tested and certified to meet all applicable
UK electrical and safety standards.
This appliance must be installed and connected in accordance with
current regulations by a qualified electrician.
After unpacking the appliance ensure that there is no visible damage. If the
appliance has been damaged during transit, do not use it, contact your
retailer immediately.

3
Your 2 year Manufacturer's guarantee
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
Your new Montpellier appliance carries a free guarantee which protects you against the cost of
repairs during the first 24 months from date of purchase provided that:
Any claim is accompanied by evidence of the model reference, model serial number and proof
of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24
months prior to the date of claim.
What is not covered under the guarantee:
x
Any appliance not correctly installed and operated in accordance with the manufacturer's
instructions.
Any appliance that is used for anything other than domestic purposes.
Any defect caused by accident, misuse, unauthorized modification or inexpert repair.
Cost of Call-out where a fault cannot be found with the appliance.
Cost of Call-out for work covering routine maintenance, such as, but not exclusively,
cleaning of filters.
Cost of Call-out for work required to correct the alignment of doors following door
reversal procedures carried out by you.
Use of the appliance by anyone other than the Householder.
Use in any commercial environment.
Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable
items which require routine replacement.
Repair costs incurred that have not been authorised by Repairtech and/or carried out by
a non-approved Repairtech engineer.
x
x
x
x
x
x
x
x
x
YOUR GUARANTEE IS VALID ONLY IN THE UK.
To Register your Appliance simply complete the card in your appliance pack and return it
with a stamp affixed or Alternatively you can Register online at www.montpellier-
a
pp
liances.com
SERVICE HELP-LINE
Should your appliance develop a fault, please call the
Repairtech Service Helpline on:
01527-888133
Please remember to have all your product details available, including the model
number, serial number, date of purchase and your retailer’s details before
registering a fault.
Your service call cannot progress without this information.
To Register your Appliance simply complete the card in your appliance pac
k
and return it with a stamp affixed or Alternatively you can Register online at
www.montpellier-appliances.com

Contents Page
Introduction 2
General delivery notes 4
Safety notes 4
Quick start 5
Description of controls 6
Programme Table 14
Programme selector 16
Detergent drawer 19
Detergents, washing aids and amounts to use 20
Useful advice for the user 22
The main wash 23
Drying 25
Automatic washing/drying cycle 26
Drying cycle 27
Cleaning and routine maintenance 29
Investigating malfunctions 31
Technical data 33
Setting up + installation 34
BEFORE SWITCHING ON THE APPLIANCE MAKE SURE
IT IS CORRECTLY INSTALLED AND THAT THE TRANSIT
SCREWS ARE REMOVED AS SHOWN IN PAGE 34.
This appliances is intended to be used in household and similar
applications such as:
•Staff kitchen areas in shops, ofÀces and other working
environments;
•Farm houses;
•By clients in hotels, motels and other residential type
environments;
•Bed and breakfast type environments.
A different use of this appliance from household environment or
from typical housekeeping functions, as commercial use by expert
or trained users, is excluded even in the above applications. If the
appliance is used in a manner inconsistent with this it may reduce the
life of the appliance and may void the manufacturer’s warranty. Any
damage to the appliance or other damage or loss arising through
use that is not consistent with domestic or household use (even
if located in a domestic or household environment) shall not be
accepted by the manufacturer to the fullest extent permitted by law.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Children should be supervised to ensure that they do not play with
the appliance.
Children of less than 3 years should be kept away unless
continuously supervised.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualiÀed persons in
order to avoid a hazard.
Only use the hose-sets supplied with the appliance for the water
supply connection (do not reuse old hose-sets).
Water pressure must be between 0,05 MPa and 0,8 MPa.
Make sure that a carpet do not obstruct the base of the machine and
ventilation openings.
The OFF condition is reached by placing the reference mark on
the programmes control/knob in the vertical position. Any other
different position of such control sets the machine in ON condition
(only for models with programmes knob).
General safety rules
–
–
–
–
–
–
–
–
–
4

Contents Page
Introduction 2
General delivery notes 4
Safety notes 4
Quick start 5
Description of controls 6
Programme Table 14
Programme selector 16
Detergent drawer 19
Detergents, washing aids and amounts to use 20
Useful advice for the user 22
The main wash 23
Drying 25
Automatic washing/drying cycle 26
Drying cycle 27
Cleaning and routine maintenance 29
Investigating malfunctions 31
Technical data 33
Setting up + installation 34
BEFORE SWITCHING ON THE APPLIANCE MAKE SURE
IT IS CORRECTLY INSTALLED AND THAT THE TRANSIT
SCREWS ARE REMOVED AS SHOWN IN PAGE 34.
The final part of a washer dryer cycle occurs without heat (cool
down cycle) to ensure that the items are left at a temperature that
ensures that the items will not be damaged.
For the installation of built in appliances, please look at the specific
paragraph.
After installation, the appliance must be positioned so that the plug
is accessible.
The appliance must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that of the
washer dryer, in such way that a full opening of the washer dryer
door is restricted.
The maximum load capacity of dry clothes depends on the model
used (see control panel).
The appliance is not to be used if industrial chemicals have been
used for cleaning.
Do not dry unwashed items in the washer dryer.
Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes
and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the washer dryer.
Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with
foam rubber pads should not be dried in the washer dryer.
Fabric softeners, or similar products, should be used as specified
by the fabric softener instructions.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as a washer dryer. The items become
warm, causing an oxidation reaction in the oil, Oxidation creates heat.
If the heat cannot escape, items can become hot enough to catch fire.
Piling, stacking or storing oil-effected items can prevent heat from
escaping and so create a fire hazard.
WARNING: never stop a washer dryer before the end of the drying
cycle unless all items are quickly removed and spread out so that the
heat is dissipated.
–
–
–
–
–
–
–
–
–
–
–
