montpellier MWD8614W User manual

Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Freestanding Washer Dryer
MWD8614W/DS - White/Dark Silver

Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your appliance to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
• Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
•By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•
Read This Manual
Read all instructions and explanations for the installation before use. Follow the instructions carefully. Keep
the operation instructions handy for later use. If the appliance is sold or passed on, ensure that the new
owner always receives this operation instructions.
CAUTION: HOT SURFACE !
CAUTION: RISK OF FIRE !

CONTENTS
1
SAFETY INSTRUCTIONS
Safety Instructions ....................................
INSTALLATION
Product Description ..................................
Installation ...............................................
OPERATION
Quick Start ................................................
Before Each Washing ...............................
Detergent Dispenser .................................
Control Panel ............................................
Programmes..............................................
Option........................................................
MAINTENANCE
Cleaning and Care ....................................
Trouble Shooting ......................................
Technical Specifications ...........................
Product Fiche ...........................................
2
8
9
12
13
14
16
17
20
25
28
29
30
Function Options .......................................
Additional Features ...................................
23
24
Here For You............................................. 32

2
Safety Instructions
For your safety,the information in this manual must be followed to
minimize the risk of fire or explosion, electric shock, or to prevent
property damage, personal injury or loss of life. Explanation of
the symbols:
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person
in order to avoid a hazard.
Electric shock!
SAFETY INSTRUCTIONS
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
！ Warning!
This combination of symbol and signal word indicates a
potentially dangerous situation which may result in
slight or minor injuries.
Note!
This combination of symbol and signal word indicates a
potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Caution!
！ Warning!

3
SAFETY INSTRUCTIONS
•The appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision.
•Children should be supervised so that they do not play with
the appliance.
•Children 3 years and under shall be kept away from the
appliance or continuously supervised.
•Animals and children may climb into the machine. Check
the machine before every operation.
•Do not climb or sit on the appliance.
•The glass door may become very hot during
operation.Keep children and pets away from the appliance
during operation.
Risk to children!
Risk of damaging the appliance !
•Remove all packaging and transit bolts before using the
appliance otherwise serious damage may result !
•This washing machine is only for domestic use and is only
designed for the textiles suitable for a domestic washing
machine.
•It is forbidden to wash carpets.
•Do not climb or sit on the appliance at all.
•Do not lean against or use excessive force on the door
•Do not operate the machine in rooms with a temperature of
below 5°C. This can cause damages to parts of it. If it is
unavoidable, make sure to drain the water completely from
the appliance after every use (see „Maintenance - Cleaning
of drain pump filter“) to avoid damages caused by frost.
•Never use flammable sprays or substances in the immediate
proximity of the appliance.

SAFETY INSTRUCTIONS
4
Risk of explosion!
•Do not wash or dry articles that have been cleaned in, soaked
in, or dabbed with combustible or explosive
substances(such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene, etc.) This may result in fire,
explosion or contamination of your appliance. Before
washing any items in the washing machine that may have
come in to contact with such substances make sure they
have been thoroughly rinsed by hand.
INTENDED USE
•The product is intended only for home use and for
textiles in household amounts suitable for machine
washing and drying. This appliance is for indoor use only
and not intended for built-in use. Only use according to
these instructions. The appliance is not intended for
commercial use.
•Any other use is considered as improper use. The
producer is not responsible for any damage or injuries
that may result of it.
INSTALLATION LOCATION AND SURROUNDING
•This appliances is designed for indoor use only.
•All washing and additional substances are to be kept in a
safe place out of the reach of children.
•Do not install the machine on a surface (such as carpet)
that would prevent ventilation at the base of the appliance.
•Keep the appliance clear from heating sources and direct
sunlight to avoid plastic and rubber parts to corrode.
•Do not use the appliance in humid environments, wet
rooms, bathrooms or rooms containing explosive or caustic
gas. In case of water leakage or water splashes let the
appliance dry in the open air.

5
•The appliance must not be installed behind a lockable door,
a sliding door or a door with a hinge on the opposite side to
that of the washing machine, it is not intended to be built-in.
•Water and electrical connections must be carried out by a
qualified technician in accordance with the manufacturer‘s
instructions and local safety regulations.
•Remove all packaging material and transport bolts before
installing the appliance. Otherwise, serious damage may
result. Transit bolts should be retained in case the appliance
needs to be moved in the future.
•This appliance is equipped with a single inlet valve and can
be connected to the cold water supply only, making sure that
the new hose supplied is used rather than the old one.
•Check the connections of the water inlet hose, the water tap
and the outlet hose for possible problems due to changes of
water pressure. If the connections loosen or leak close the
water tap and get it repaired. Do not use the appliance
before the pipes and hoses are installed properly by
qualified persons and checked for any leaks.
•To ensure your safety the mains plug must be plugged in to
a suitable 13amp switched wall socket which is properly and
reliably earthed. If you notice any discolouring or damage to
the wall socket this must be replaced by a qualified person
straight away.
•Always unplug the appliance and turn off the water supply
after use and especially if the appliance is not to be used for
a prolonged period of time.
•Mains plug must be accessible after installation.
SAFETY INSTRUCTIONS

6
OPERATION AND MAINTENANCE
•Before using for the first time it is recommended to run
the washer through one complete wash cycle at a
minimum temperature of 40°without any clothes and use
half of your usual amount of detergent.
•Never use any flammable, explosive or toxic solvents. Do
not use gasoline and alcohol etc. as detergents. Only
select detergents that are suitable for machine washing.
•Make sure that all pockets are emptied. Sharp and rigid
items such as coins, brooches, nails, screws, stones etc.
may cause serious damages to this machine.
•Remove all objects from pockets such as lighters and
matches before use the appliance.
•Thoroughly rinse items that have been washed by hand.
•Fabric softeners or similar products should be used as
recommended in their instructions.
•Never try to open the door forcefully. The door will unlock
shortly after the end of a cycle.
•Please do not close the door with excessive force. If it is
found difficult to close the door, please check if the
clothes are properly inserted and distributed.
•Always unplug the appliance and close the water tap
before cleaning and maintenance and after each use.
•Never pour water over the appliance for cleaning
purpose. Risk of electric shock!
•Do not remove the drain pump filter while there is still
water in the appliance. Big quantities of water can leak
out, and there is a risk of scalding due to hot water.
•Repairs shall only be carried out by the manufacturer, its
service agent or similarly qualified persons in order to
avoid a hazard. The producer will not be responsible for
damages caused by the intervention of not authorized
persons.
SAFETY INSTRUCTIONS

TRANSPORT
7
•Transport bolts shall be carefully reinstalled to the appliance
by a suitably qualified person.
•Any residual water left in the appliance shall be drained out of
the appliance.
•The appliance should always be handled with care. Do not
carry, lift or move the appliance with any part protruding from
the appliance. The door should never be used as a handle
when moving the appliance.
•This appliance is very heavy. Always transport with care and
we strongly recommend that it is moved by a minimum of two
people.
•Don´t use multiple plugs or extension cords.
•The appliance must not have an external switching
device such as a timer or connected to a circuit that is
regularly switched on and off.
•Do not pull the plug out of the mains outlet if there is
flammable gas around.
•Never pull out power plug with wet hands.
•Always pull at the plug, not at the cable.
•Always unplug the appliance if it is not being used.
！Warning!
Packaging/Old appliance
SAFETY INSTRUCTIONS
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal,recycle
it responsibly to promote the sustainable reuse of
material resources. To return your used device, please
use the collection systems or contact the retailer where
the product was purchased. They can take this product
for environmental safe recycling.

INSTALLATION
Accessories
Product Description
4 x Cover caps 1 x Supply hose
cold water
•The product picture is for illustration only, please refer to real product as
reference.
Note!
Drum
Control panel
Power supply cord
Detergent dispenser
Service flap
Door
Water supply hose
Top cover
Drain hose
1 x Owner’s manual
8

9
INSTALLATION
•Install on a dry, rigid and level surface.
•Avoid direct sunlight.
•Make sure the appliance has sufficient
ventilation.
•Room temperature is above 5℃
•Keep far away from the heat resources such as
heating pipes/radiators
Before installing the appliance ensure that all
below points are adhered to:
Unpacking the washer dryer.
•Remove the cardboard box and styrofoam packing.
•Lift the washing machine and remove the base
packing. Make sure that the small triangle of foam is
also removed with the bottom packing. If not then
carefully tilt the appliance backwards so that you can
manually remove the foam part.
•Remove the tape securing the power supply cord
and drain hose.
•Remove the inlet hose from the drum.
•Stability is extremely important for quiet and
vibration free running.
•Make sure the appliance doesn't stand on
the mains cable.
！Warning!
Packaging material (e.g. Films, Styrofoam) can
be dangerous for children.
There is a risk of suffocation ! Keep all packaging
well away from children.
！Warning!
Installation

INSTALLATION
Remove transport bolts
•You must remove the transport bolts from the backside before using the product.
•You'll need the transport bolts again if you move the product, so make sure you keep
them somewhere safe.
！Warning!
Loosen the 4
transport bolts with a
spanner.
Remove the bolts including
the rubber parts and keep
them for future use.
Close the holes using
the cover caps.
Levelling the washing machine
•The lock nuts on all four feet must be screwed tightly against the housing.
！
Warning!
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with
a spanner. Make sure the machine is
level and steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in
this chapter
•Do not kink, crush or modify water inlet hose.
！Warning!
Connect the water supply
hose to the water inlet
valve and a water tap with
cold water as indicated.
•Connect manually, do not use tools. Check if the connections
are tight.
Note!
10

INSTALLATION
11
Drain Hose
There are two ways to connect the drain pipe to a water outlet.
1. Connect the drain to a suitable stand pipe or 2. connect to an outlet below a household
sink.....see below.
When the drain hose has been installed check that it is secure and will not
move or become dislodged during discharge of the drain water
If the drain hose is too long do not force it back in to the washing machine as
this will cause damage to the hose/appliance
•
•
Do not kink or extend the drain hose
Position the drain hose correctly to avoid damage which may result in a leak
Trough
Hose Retainer
Bind
Max.100cm
Min.60cm
Min.60cm
Max.100cm
• If the machine has drain hose support, please install it like the following .
！！
WARNING
Note!
80 cm
In either option the drain hose must be
between 60 cm and 80 cm from the ground.
！！
WARNING

2. Washing
Select programme Select function or
default settings
Press
Start/Pause to
start the program
2 3 4
3. After Washing
Buzzer beep and “End”
on display.
1. Before Washing
Open tap
Load
Close door
Plug in
Add detergent
•Detergent need to be added in compartment I if the pre-wash function is
selected.
1 2 3 4 5
Note!
Main
wash
Prewash
Softener
earth
terminal
OPERATION
Power On
1
12
Quick Start
Caution!
Before using the appliance make sure that it is correctly installed.
Before washing for the first time it is advisable to run the appliance
through one complete wash cycle at a minimum temperature of 40°
C without any clothes and using half your usual amount of detergent.

•Do not wash or dry articles that have been cleaned in, washed
in, soaked in, or dabbed with combustible or explosive
substances like wax, oil, paint, gasoline, alcohol, kerosene,
and other flammable materials.
•Washing single items may easily cause alarm due to an
unbalanced load. Therefore it is suggested to add one or two
more laundry items to the wash so that spin can be done
smoothly if this occurs.
•The ambient temperature of the washer dryer should be 5-40°C. If used
under 5°C, the inlet valve and draining system may be damaged. If the
machine is installed under freezing conditions, it should be transferred to
normal ambient temperature to ensure the water supply hose and drain
hose can unfreeze before use.
•Please check your laundry care labels and the detergent use instructions
before wash. Use non-foaming or less-foaming detergent suitable for
machine washing properly.
Tie together long
textile strips and belts,
close zips and button
Take all items out
of the pockets
Put small items into
a laundry bag
Check the care label
Before Each Washing
Turn easy-pilling and
long-pile fabric
inside out
Sort laundry
according to colour
and textile type
！Warning!
OPERATION
1 2 3
4 5 6
13

Caution!
•Detergent only need to be added in "compartment I “after selecting
pre-wash function.
OPERATION
I
I
I
Detergent Dispenser
Pre wash
Main wash
Softener
Release button to pull out
the dispenser
Programme
Sterlilzation
Cotton
Synthetic
Mix
Wool
Duvet
Eco 40-60
Intensive
Programme
Self Clean
Spin Only
Wash and Dry
Dry Only
20℃
1 Hour W/D
Quick 45’
Rapid15’
○Means optional
Means must
14

OPERATION
Detergent Recommendation
•Thick or concentrated softeners may cause clogging of the soap drawer inlets
so it is advisable to dilute if possible, also excessive use of powder may also
cause clogging. Always use detergents produced for automatic washing
machines and follow the dosing guidelines form the detergent manufacturer.
•Please choose the suitable type of detergent to get a maximum of washing
performance and a minimum of water and energy consumption
• To achieve the best cleaning result a proper detergent dosing is important.
•Use a reduced detergent amount if the drum is not filled completely.
• Always adjust the amount of detergent to the water hardness, if your tap
water is soft, use less detergent.
•Dose according to how dirty your laundry is, less dirty clothes require less
detergent.
•Highly concentrated (compact detergent) requires particularly accurate
dosing.
Following symptoms are a sign of detergent overdosing:
-heavy foam formation
-poor washing and rinsing result
Following symptoms are a sign of detergent underdosing:
-laundry turns grey
-build-up of limescale deposits on the drum, the heating element and/or
the laundry
Note!
15
Recommended washing
detergent
Heavy-duty detergent
with bleaching agents
and optical brighteners
Colour detergent
without bleaching agent
and optical brighteners
Color or mild detergent
without optical brighteners
Mild washing detergent
Special wool detergent
Wash cycles
Cotton,ECO 40-60,Mix
Cotton,ECO40-60,Mix
Synthetic
Synthetic
Wool
Washing
temp.
20/30
40/60/90
/
20 /30
20/30/40
Type of laundry
and textile
White laundry made
from boil-proof cotton or
linen
Coloured laundry
made from cotton
or linen
Coloured laundry made
from easy care fibres or
synthetic materials
Delicate textiles,
silk, viscose
Wool
Cold/20/
30/40
Cold/20/
30/40

OPERATION
Control Panel
5
321
4
A
Display
Wash Time Delay Time
Speed
End Temp.
A
B
C
DE
F
G
H
16
Error
B
Child Lock
D
Stop Add Go
C
Hygiene Pro
E
Door Lock
F
Pre Wash
G
Extra Rinse
H
Dry Level
Power
Product is on/off.
Start/Pause
Press the button to start or pause the
washing cycle.
Programmes
Available according to the laundry type.
Option
This allows you to select an additional
function and will light when selected.
1
3
2
4
Display
The display shows the settings, estimated time remaining, options, and status messages
for your washer. The display will remain on through the cycle.
5

•The parameters in this table are only for user's reference. The actual parameters may be
different from the parameters in the above mentioned table.
Note!
Programme
Load(kg) Default Time
Default
Temp.(°C)
8.0
4.0/4.0
8.0/6.0
4.0
–
8.0
5.0/5.0
8.0
8.0/6.0
8.0
Sterlilzation
Cotton
Synthetic
Mix
Wool
Duvet
Eco 40-60
Intensive
Self Clean
Spin Only
Wash and Dry
Dry Only
20℃
1 Hour W/D
Quick 45’
Rapid 15’
70
40
–
40
–
Cold
8.0/6.0
2.0
4.0
6.0
8.0
2:27
3:39
3:28
1:30
1:07
1:48
3:35
3:48
1:18
0:12
5:00
4:14
1:11
0:58
0:45
0:15
Model: MWD8614W/DS
40
40
40
40
90
–
–
20
40
Cold
1.0/1.0
2.0
2.0
Programmes
OPERATION
17
Specific wash programmes you can select to automatically Dry
Caution!
•If there is any break in the power supply while the machine is operating, a special
memory stores the selected programme. The machine will continue the programme
when the power supply is re-established.

Programmes
OPERATION
18
MWD8614W/DS
•The above data is for reference only, and the data may change due to different actual use
conditions.
•The valves given for programmes other than the ECO 40-60 programme and the Wash
and Dry cycle are indicative only.
•Concerning to Regulation(EU) No 1061/2010,The EU energy efficiency class is: A Energy
test program: Intensive;Speed:The highest speed; Temp.: 60℃;
Other as the default.
Half load for 8.0Kg machine:4.0Kg.
•Concerning to Regulation(EU) 2019/2023,
The EU energy efficiency class is: E/D,Energy test program: ECO 40-60/Wash & Dry. ECO
40-60: as the default Wash and dry : dry level: (Extra Dry),Other as the default. Half load
for 8.0Kg machine:4.0Kg.
Quarter load for 8.0Kg machine:2.0Kg.
1) The highest temperature reached by the laundry in the wash cycle for at least 5 minutes
2) Residual moisture after the wash cycle in water content percent and the spin speed at which this was
achieved.
3) The ECO 40-60 programme is able to clean normally soiled cotton laundry declared to be washable at
40°C or 60°C, together in the same cycle. This programme is used to assess the compliance with the
regulation (EU) 2019/2023.
4) The Wash and Dry programme, dry level setting Extra Dry is able to clean normally soiled cotton laundry
declared to be washable at 40°C or 60°C, together in the same cycle, and to dry it in such a way that it can be
immediately stored in a cupboard. This programme is used to assess the compliance with the regulation
(EU) 2019/2023.The most efficient programmes in terms of energy consumption are generally those that perform at
lower temperatures and longer duration. Loading the household washer-dryer up to the capacity indicated for the
respective programmes will contribute to energy and water savings. Noise and remaining moisture content are
influenced by the spinning speed: the higher the spinning speed in the spinning phase, the higher the noise and the lower
the remaining moisture content.
Rapid 15'
