Moore Industries PSD User manual

PSD
PC-Programmable Loop Display
No. 178-717-00M
June 2018

Customer Support
Moore Industries is recognized as the industry leader in delivering top quality to its customers in products
and services. We perform a sequence of stringent quality assurance checks on every unit we ship. If any
Moore Industries product fails to perform up to rated specications, call us for help. Our highly skilled sta󰀨 of
trained technicians and engineers pride themselves on their ability to provide timely, accurate, and practical
answers to your process instrumentation questions. Our headquarters and other facilities phone numbers
are listed below.
There are several pieces of information that can be gathered before you call the factory that will help our
sta󰀨 get the answers you need in the shortest time possible. For fastest service, gather the complete model
and serial number(s) of the problem unit(s) and the job number of the original sale.
www.miinet.com
Demand Moore Reliability
Locations
World Headquarters Europe Australia
16650 Schoenborn Street
North Hills, California
91343-6196, U.S.A.
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
TOLL FREE: 1-800-999-2900
www.miinet.com
1 Lloyds Court, Manor Royal, Crawley
W. Sussex RH10-9QU
United Kingdom
Tel: [phone]
Fax: [phone]
FREE PHONE: [phone]
[email protected]
www.miinet.com/uk
Sydney, NSW
3/1 Resolution Drive
Caringbah, New South Wales 2229
Australia
Tel: [phone]
Fax: [phone]
[email protected]
www.miinet.com/au
China Guido Gezellestraat 106
BE-2630 Aartselaar
Belgium
Tel: [phone]
Fax: [phone]
[email protected]
Dutch: www.miinet.com/dbe
French: www.miinet.com/fbe
Perth, WA
6/46 Angove Street
North Perth, Western Australia 6006
Australia
Tel: [phone]
Fax: [phone]
[email protected]
www.miinet.com/au
Room 402, No. 57,
Lane 651, Xipu Road,
Xinqiao Town, Songjiang District,
Shanghai, 201612, P. R. China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.miinet.com/cn
Burg Meslaan 98
4003 CD Tiel
The Netherlands
Tel: [phone]
Fax: [phone]
[email protected]
www.miinet.com/nl
www.miinet.com Moore Industries-International, Inc.

Table of Contents
Introduction ............................................................................................................................................. 5
The PSD .......................................................................................................................... 5
Model and Serial Numbers............................................................................................ 5
Specifications ................................................................................................. 5
Dimensions ..................................................................................................... 6
Configuring the PSD ...................................................................................... 8
Installing the Configuration Software .......................................................................... 8
Using the PC Program................................................................................................... 9
Connecting the PSD to PC........................................................................... 10
Necessary Equipment Table........................................................................................ 10
Square Roots and the Curve Generator ..................................................... 11
Programming the PSD ................................................................................. 13
Site-Viewing the Configuration................................................................................... 14
Installation..................................................................................................... 14
Recommended Ground Wiring Practices................................................................... 14
Electrical Connections ................................................................................................ 14
CE Conformity .............................................................................................................. 15
Operation ...................................................................................................................... 15
Maintenance ................................................................................................................. 13

Intrinsic Safety.............................................................................................. 16
Installation in Hazardous Locations ........................................................... 18
Specific Conditions for Safe Use ................................................................. 19
Appendix - A PSD in Safety Instrumented Systems ...................................... 21

Demand Moore Reliability 5
PSD
Input Accuracy:
±0.012% of input scale
Overall Accuracy: The
overall accuracy of the
unit is the input accuracy.
(±0.012% of input scale)
It includes the combined
effects of linearity, hys-
teresis, repeatability, and
adjustment resolution. It
does not include ambient
temperature effect.
Stability: Error is in % of
maximum span
Stability Input to Output
1yr 3yrs 5yrs
mA
0.08 0.14 0.18
Resolution:
0.0028% of input scale
Over-Current
Protection:
100mA maximum
Input Overrange: 24mA
Digital Input Filter:
User-programmable;
50 or 60 Hz
Introduction
This is the user’s manual for the PSD, Moore
Industries’ PC-Programmable Loop Display. It
contains all of the information needed to configure,
install, operate and maintain the PSD.
The following guidelines are used in this manual:
WARNING - Hazardous procedure or condition that
could injure the operator.
Caution - Hazardous procedure or condition that could
damage or destroy the unit.
Note - Information that is helpful for a procedure, con-
dition or operation of the unit.
The PSD
The PSD is a 2-wire (loop-powered),
PC-programmable loop display. Typically paired
with one of our extensive line of durable housing
and enclosure options, its size, accuracy, and low
voltage drop make it the ideal solution for displaying
measurements in remote or otherwise difficult-to-
access locations or nearly overburdened loops.
Model and Serial Numbers
Moore Industries uses the model and serial numbers of
our instruments to track information regarding each unit
that we sell and service. If a problem occurs with your
instrument, check for a tag affixed to the unit listing these
numbers. Supply the Customer Support representative
with this information when calling.
Specifications
Excitation Current:
≥3.8mA
Burden: <2.3VLP
(<5.1VLP when –LMD
option is installed and the
PSD is disconnected from
the loop)
Type: LCD; Top Row,
10mm (0.4 inch) high
black digits on a reflective
background;
Bottom Row, 6mm
(0.23 inch) high black
digits on a reflective
background
Display Update Rate:
100msec
Format: Top row is five
alphanumeric characters
plus sign and decimal
point; Bottom row is five
alphanumeric characters
Range:
-99999 to 99999
Minimum Display Span:
1.00
Operating Range:
-25°C to 85°C
(-13°F to 185°F)
Performance Performance
(Continued)
Display
Ambient
Conditions
Ambient
Conditions
(Continued)
Weight
Storage Range:
-45°C to 85°C
(-49°F to 185°F)
Relative Humidity:
0-95%, non-condensing
Ambient Temperature
Effect: ±0.015% of span
per °C change, maximum
RFI/EMI Immunity:
20 V/m when tested ac-
cording to SAMA 33.1 abc
with 0.5% of span or less
error; 20 V/m @
80-1000MHz, 1KHz AM,
when tested according to
IEC1000-4-3-1995
Common Mode
Rejection:
100dB @ 60Hz
Normal Mode
Rejection:
30dB @ 60Hz
BH housing:
1.37 kg (3 lbs, 1.1 oz)
D2LC housing:
640g (1 lb, 6.3 oz)
HP-style housing:
150g (5.3 oz)
Specifications and Information subject to change without notice.

6 Demand Moore Reliability
PSD
Ordering Information
Unit
PSD
PC-
Program-
mable
Loop
Display
Input
4-20MA
Loop
Input
Output
PRG
Program-
mable
with sup-
plied con-
guration
software
to display
a percent
or any
other EGU
of
up to 5
characters
in length.
Options
-LMD Loop
Maintenance Zener
Diode provided
at input terminals
allowing the PSD
to be removed from
the loop without
interrupting loop
continuity (Burden:
increases from <2.3
to <5.1VLP when
PSD is removed
from the loop)
-ISC: CSA
Approved
Intrinsically-Safe &
Non-Incendive
-ISE: ATEX
Approved
Intrinsically-Safe
-ISF: FM Approved
Intrinsically-Safe &
Non-Incendive
-VTD: Standard
Factory Calibration
with NIST Test Data
Report
Power
2.3VLP
Loop
Powered
Housings
BH2NG* (*) or (‡) Aluminum 2-Hub, Explosion-Proof enclosure with two,
½-inch NPT entry ports and a glass cover
BH2TG* (*) or (‡) Aluminum 2-Hub, Explosion-Proof enclosure with two,
¾-inch NPT entry ports and a glass cover
BH2MG* (*) or (‡) Aluminum 2-Hub, Explosion-Proof enclosure with two,
M20 x 1.5 entry ports and a glass cover
BH3NG* (*) or (‡) Aluminum 3-Hub, Explosion-Proof enclosure with three,
½-inch NPT entry ports and a glass cover
BH3TG* (*) or (‡) Aluminum 3-Hub, Explosion-Proof enclosure with two,
¾-inch NPT side-entry ports, one ½-inch NPT bottom-entry port, and a
glass cover
BH3MG* (*) or (‡) Aluminum 3-Hub, Explosion-Proof enclosure with two, M20
x 1.5 side-entry ports, one ½-inch bottom-entry port, and a glass cover
D1LC 1-Hub, Low base, Clear cover, NEMA 4X (IP66) enclosure
D2LC 2-Hub, Low base, Clear cover, NEMA 4X (IP66) enclosure
HP Hockey-puck housing and spring clips
DN Snap-in mounting for HP case on TS-32 DIN rail
FL Mounting anges on HP suitable for relay track or screw mounting
FLD Mounting anges on HP suitable for 3½” relay track or screw
mounting
SB2NG* (*) or (‡) 316 Stainless Steel 2-Hub, Explosion-Proof enclosure
with two, ½-inch NPT entry ports and a glass cover
SB2MG* (*) or (‡) 316 Stainless Steel 2-Hub, Explosion-Proof enclosure
with two, M20 x 1.5 entry ports and a glass cover
* Either Aor E su󰀩x (comes supplied with 2” pipe mount hardware)
A su󰀩x indicates ANZEx/TestSafe (Ex d)
Flameproof approvals (i.e. BH2MGA)
E su󰀩x indicates ATEX (Ex d and tb) Flameproof approvals
(i.e. BH2MGE)
‡ P su󰀩x indicates enclosure comes equipped with base plate and U-bolts
for mounting on a 2-inch pipe (i.e. BH2NGP)
See BH, SB and D-BOX Datasheets for additional information.
To order, specify: Unit / Input / Output / Power / Options [Housing]
Model Number Example: PSD / 4-20MA / PRG / 2.3VLP / -LMD [BH2NG]

Demand Moore Reliability 7
PSD
Figure 1. PSD Explosion-Proof BH Enclosure Dimensions
FRONT VIEW SIDE VIEW
61mm
(2.4 in)
83mm
(3.25 in)
62mm
(2.45 in)
64mm
(2.50 in)
66mm
(2.58 in)
76mm
(3.00 in)
43mm
(1.70 in)
18mm
(.70 in)
+IN -IN VIEW
PSD
602.78
MMETR
+IN -INVIEW
PSD
602.78
MMETR
Figure 2. PSD Hockey-Puck Dimensions

8 Demand Moore Reliability
PSD
84mm
(3.30 in)
118mm
(4.65 in)
130 mm
(5.12 in)
112mm
(4.40 in)
83mm
(3.25 in)
64mm
(2.50 in)
C
L
Interior Diameter
81mm (3.2 in)
Instrument
Tag
116 mm
(4.56 in)
27mm
(1.05 in)
Conduit
Fitting
Cover
Body
Bezel
Figure 3. Field-Mount, NEMA 4X/IP66 D-BOX Enclosure Dimensions

Demand Moore Reliability 9
PSD
Installing the Configuration
Software
Refer to Table 1 for the equipment needed.
1. Insert the Moore Industries Interface Solution
PC Configuration Software CD into the CD
drive of the PC. Access the CD and open the
PSD SPD PC Configuration Software folder.
2. Double-click the installation program located
in the folder. Follow the prompts to correctly
install the program.
Once the Configuration Program is installed on the
PC, the PSD can be connected to the loop or to
equipment to simulate and calibrate input. You can
then view and/or change the instrument’s parameters.
No PSD Required
It is not necessary to connect the display to a PC while
creating configuration files using the Configuration
Software. The Configuration Program can be run
without connecting a PSD, and most operating
parameters can be set without benefit of an attached
unit.
This makes it easy to create a set of operating
parameters, save and download them to one or more
transmitters at a later time.
The PSD must be connected to the PC in order to:
capture input, assign a tag, receive (via download) a
configuration file and save the configuration file from
the instrument’s memory.
Configuring the PSD
One of the benefits of the PSD is that it has no internal
or external controls to adjust or settings to change. All
operating parameters are set using Moore
Industries’ Intelligent PC Configuration software.
Once these software settings are made, they are
downloaded to the instrument in the form of a
Configuration File and stored in the unit’s non-volatile
memory. You can choose to save a backup copy of
the file on your PC hard drive or other external media.
The transmitter communicates with the PC through
a cable connection to the PC’s serial (COM) port or
optional USB cable.
The serial cable is P/N 803-040-26 and the USB cable
is P/N 804-030-26.
Default/Factory Configurations
The following are the default factory settings for your
unit:
Input:
- 4-20mA
- Filter: 60Hz
- Damping Time: 0.0
Display:
- 0-100 PCT
- Display Resolution: AUTO
- Linearization Mode: Normal

10 Demand Moore Reliability
PSD
6
5
7
9
4
3
21
8
Using the PC Program
The PSD PC Configuration Software is used to
program all of the PSD’s parameters. The PC
Software is made up of these sections:
1. Arrow Buttons–Three Arrows here are used for
Downloading to Unit (down Arrow), Uploading from
Unit (Up Arrow),or Get Set-up (Right Arrow).
Note:
After uploading file (by pressing the Up Arrow), you
must press the Right Arrow button to populate all
information into the configuration dialog area.
2. Status–This portion of the screen displays the
activity of the connected unit. It will show you if the
unit is Idle, Uploading, Downloading, or Monitoring.
3. Process Variables–This displays two variables: the
loop signal in mA and the loop signal after the PSD
has converted it to the designated EGU.
4. Input Settings, Output Setings, Tag, and Device–
These three sections display the configuration of the
connected PSD.
Figure 4. Most of the PSD Operating Parameters can be set from the Main Screen of the Configuration Program.
5. Connection–Check this section to track the status
of the PC’s connection with the PSD.
6. Input/Output & Custom Curve Tabs–Displays all
the information to program the PSD with either a
standard, linear curve (Input / Output), or with a
custom linearization curve (Custom Curve).
6. Input Configuration–Displays the input settings
proposed for the transmitter. The two different capture
buttons permit you to capture the input span.
7. Display Configuration–Shows the display settings
proposed for the PSD.
8. Engineering Units (EGU), Linearization Mode,
Filter, Display Resolution, and Damping Time–This
set of radio buttons and edit boxes allow you to input
different
values proposed for transmission to the PSD.

Demand Moore Reliability 11
PSD
Figure 5. Connecting the PSD to a 4-20mA Loop
Connecting the PSD to PC
It is recommended that the PSD be installed in the
loop before it is configured so that you can use the
input capture feature to capture the exact full and
zero values of the loop. See Figure 5 for a hookup
diagram, and Table 1 for a list of necessary equipment.
If it is not possible to hookup the PSD to the loop,
you can also use a variable current source and an
ammeter or multimeter to setup your unit before
you install it on the loop. See Figure 6 for a hookup
diagram, and Table 1 for a list of necessary equipment.
The PC Configuration Software can program and
save the settings for the PSD without having a PSD
attached, but you do need to attach the PSD as shown
below in order to download information.
Caution: Unplugging the programming cable or
resetting power while downloading to the unit could
result in a default configuration / calibration and the
unit may have to be returned to the factory.
Multimeter or
Ammeter (optional)
Variable Current
Source
Personal Computer
PC Operating
System
Moore Industries
PC Configuration
Software
Accurate to ±0.025% of span
Capable of 4-20mA; accurate to ±0.01%
of span
Microsoft Windows-based PC;
16Mb free RAM; 20Mb free disk space
on hard drive
1 (one) serial port or one USB port (with
optional cable)
Microsoft Windows®XP, 7 or 10
Version 1.0 or higher, successfully
installed onto the hard drive
Device Specifications
Table 1. Assembling the necessary equipment.
NOTE:
1. Terminal blocks can accommodate 14-22 AWG (2.08-0.33 mm2)solid wiring.
2. Tighten terminals to 4 In-lb (0.45 Nm), maximum.
PSD
+IN -IN VIEW
PSD
602.78
D E G C
+
–
4-20mA
TRANSMITTER
+–+
–
LOOP
POWER
SUPPLY
TO SERIAL
(COM) PORT
OF PC
OR
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
*When using Optional USB Cable Part# 804-030-26
please assure that the ground of the PSD is at the
same potential as the PC that the usb cable is plugged in.
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
DIRECTLY TO THE PSD!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST
BE IN THE LOOP!
To USB
(COM)
Port of PC

12 Demand Moore Reliability
PSD
Square Roots and the
Curve Generator
Moore Industries provides two options for customers
who require a custom square root linearization table.
You can either generate a custom curve table or
import a pre-made curve.
Option One: Generating a Custom Curve
The first option is to run the Table Generator and
generate a custom table that can be easily saved
and imported into the Universal PC Configuration
Software.
To generate your own table, follow the instructions
below.
1. From the START Menu, click on PROGRAMS,
MOORE INDUSTRIES, then CURVE GENERATOR.
The program that is shown below will appear.
Figure B-1. The Square Root Curve Generator program will allow
you to easily create any custom square root curve that you need.
2. Enter the values for the input and display into the
appropriate boxes. Enter the number of linearization
points that you would like generated into the NUMBER
OF LIN. POINTS box.
3. Click on GENERATE to create the table, then enter
the name you would like the table saved as.
4. Close the Curve Generator and open the Universal
PC Configuration Software. Click on the FILE menu,
then on IMPORT CUSTOM CURVE. Select the
“view all files” on the OPEN dialog box, then find the
file name that you just saved.
5. Verify all settings.
6. Use the download button to transmit the new file to the
PSD and finish the process.
Option Two: Importing a Pre-made Curve
The second option is to use a pre-made custom curve
table that will work the function. To import the file,
follow the instructions below.
1. In the Universal PC Configuration Program, click on
the FILE menu, then on IMPORT CUSTOM CURVE.
Select the “view all files” on the OPEN dialog box, then
navigate to the location in the filesystem of the custom
curve of interest and click OPEN. The Universal PC
Configuration Software will import the file.
2. Verify all settings.
3. Use the download button to transmit the new file to
the PSD and finish the process.

Demand Moore Reliability 13
PSD
Figure 6. Connecting the PSD to configuration equipment
Programming the PSD
There are two sections for programming the PSD –
“Input/Output,” and “Custom Curve”. The Input/
Output tab allows you to program the PSD with a
normal, linear curve; the “Custom Curve” allows you to
program the PSD with a custom linearization curve.
Programming the PSD with a Normal (linear) Curve
It is a simple process to program the PSD with a
normal curve. Using the “Input/Output” tab, you will
need to adjust the following settings.
1. In the “Input Settings” box, enter the Zero and Full
Input values, or click the “Capture” buttons (this is the
preferred method) and adjust the input.
2. Go to “Display Settings” and input the range you
would like displayed on the PSD’s screen.
3. Enter a name for the unit (to be read by the PC
Program) in the “Tag” box.
4. Enter into the “EGU” box the engineering unit you
would like displayed.
5. “Linearization Mode” should be left at “Normal”.
6. Set the “Filter” to match the frequency of the filter
for the AC power mains in your country.
7. Set the “Display Resolution” to the number of
decimal points you would like the PSD to display.
8. Smooth out input variations by increasing the
Damping Time.
9. Download the new settings to the instrument by
attaching the instrument to the PC and clicking on the
download button.
Programming the PSD with a Custom Curve
There are a variety of ways to program the PSD with
a custom curve. You can import a comma-delimited
table that you have written in another program (for
example, design the table in Microsoft®Excel and save
it as .csv type). You can import a ready-made file that
came with your configuration software (such as the
square root table). Or, you can set your own custom
curve by follwing the directions described below.
1. Set the “Linearization Mode” to “Custom”. In
the “Linearization Data” box, enter the number of
linearization points. Then, in the “X data” column
of the table, enter the value of the loop input in
mA. In the “Y data” column of the table, enter
the corresponding EGU value that you would like
displayed. Do this for each point of your custom curve.
It may be useful to use the buttons in the “Commands”
box to work with the custom curve table cells.
2. Set the “Input Settings” to the span of the loop you
will be reading.
3. Set the “Display Settings” to the span that you
would like to have displayed. This allows you to reset
the range of the display with one step instead of
needing to recalculate the entire custom curve table.
4. Click on the “Input/Output” tab so that you can set
the Filter, Display Resolution, and Damping Time to
the appropriate values.
5. Download the new settings to the instrument by
attaching the instrument to the PC and clicking on the
download button.
PSD
+IN -IN VIEW
PSD
602.78
D E G C
AMMETER OR
MULTIMETER
+–
ADJUSTABLE
CURRENT
SOURCE
+–
+
–
TO SERIAL
(COM) PORT
OF PC
OR
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
*When using Optional USB Cable Part# 804-030-26
please assure that the ground of the PSD is at the
same potential as the PC that the usb cable is plugged in.
To USB
(COM)
Port of PC

14 Demand Moore Reliability
PSD
Site-Viewing the Configuration
Even after your PSD has been installed in the field,
it is easy to verify its configuration using the front-
mounted View button. Figure 7 describes the various
displays controlled by the View button.
Installation
Installing the PSD in your loop involves mounting and
making electrical connections.
Recommended Ground
Wiring Practices
Moore Industries recommends the following ground
wiring practices:
• Any Moore Industries product in a metal case or
housing should be grounded.
• The protective earth conductor must be connected
to a system safety earth ground before making any
other connections.
• All input signals to, and output signals from,
Moore Industries’ products should be wired using
a shielded, twisted pair wiring technique. Shields
should be connected to an earth or safety ground.
• For the best shielding, the shield should be run
all the way from the signal source to the receiving
device. (see Note below)
• The maximum length of unshielded input and
output signal wiring should be 2 inches.
Note:
Some of Moore Industries’ instruments can be
classified as receivers (IPT 2, IPX 2, etc.) and
some can be classified as transmitters (TRX,
TRY, etc.) while some are both a receiver
and a transmitter (SPA 2, HIM, etc). Hence,
your shield ground connections should be
appropriate for the type of signal line being
shielded. The shield should be grounded at
the receiver and not at the signal source.
Electrical Connections
When installing any Moore Industries product,
always follow all local regulations and standards for
grounding, shielding, and safety.
WARNING: Terminals on this unit may be connected to
hazardous voltages. Before making ANY connections to
this unit, always remove power from the loop instrument
power terminals. or instrument power terminals.
Meter Mode:
The display flashes Meter
Mode, then displays the
monitored input value in mA.
Input Full Value:
Displays the upper range
of the input value.
Input Zero Value:
Displays the lower range
of the input value.
VIEW
current
settings
Front Panel
Push Button
VIEW
MENU
VIEW
Normal/Custom Mode:
Shows whether the PSD is in
Custom Mode or Normal Mode.
VIEW
VIEW
VIEW
Exit View Mode:
Returns to normal process display.
VIEW
Figure 7. The View button on the front of the PSD allows you view
the different PSD settings.

Demand Moore Reliability 15
PSD
Installation Category
All terminals are rated CAT I.
Equipment Ratings
The PSD does not generate hazardous voltages. it
provides a low current input.
WARNING: If this unit is used in a manner not
specified by Moore Industries, the protection
provided by the equipment may be impaired.
CE Conformity
Installation of any Moore Industries’ products that
carry the CE marking must adhere to the guidelines in
the Recommended Ground Wiring Practices section in
order to meet the EN 61326 requirements set forth in
the applicable EMC directive.
WARNING: If this unit is used in a manner not
specified by Moore Industries, the protection
provided by the equipment may be impaired.
Operation
Once installed and programmed, PSD displays
begin to operate immediately. Depending upon
environmental conditions, they can be expected to
operate unattended for extended periods of time.
Maintenance
Moore Industries suggests a quick check for terminal
tightness and general unit condition every 6-8
months. Always adhere to any site requirements for
programmed maintenance.
Customer Support
If service assistance is ever required for an device in
your application, refer to the back cover of this manual
for the telephone numbers to Moore Industries’
customer service department.
If possible, make a note of the model number of the
unit before calling. For fastest assistance, have the
following information available: serial number, the job
number and purchase order number under which it
was shipped.

16 Demand Moore Reliability
PSD
Intrinsic Safety
This page contains the installation diagram for the
PSD carrying the intrinsically safe option (FM/CSA). It
also includes guidelines for setting up zener barriers
necessary in these types of applications.
These diagrams must be used to augment the
installation instructions earlier in this manual for units
that are to operate in areas requiring intrinsically safe
instrumentation.
  
 CONTROL DRAWING
 
 



Product









(1)





 n



Field Installation Diagram

   
  KV CB


w_.




 PSD [HP]
    09100 Intrinsically Safe System
 NONE  
 


(MIi} 
MIi.
  
 
+PS
-PS
(3)
 












(2)


        
  
  
 
 
 
 
 





  °
 °°
 

 

 
   



  
 
 =  =   = 

Demand Moore Reliability 17
PSD
This page contains the installation diagram for the
PSD carrying the intrinsically safe option (ATEX/). It
also includes guidelines for setting up zener barriers
necessary in these types of applications.
These diagrams must be used to augment the
installation instructions earlier in this manual
for units that are to operate in areas requiring
intrinsically safe instrumentation.
  
CONTROL DRAWING
 
 



Product









(1)



(2)


 n
       
 Field Installation Diagram
PSD/SLD -ISE [HP]
lntrincisally Safe System

 
   CB
  
 

(MIi} 
MIi.

  
NONE
  
 
 
 

'View 
Must Not be used 
Hazardous 'Classified' Locations


  
  
  
  
  








 
  
 
 
+PS
-PS
(3)
 
 
(2)
 
  

 °
 °°


 


 

 
 

 =  =  = 

18 Demand Moore Reliability
PSD
Installation in Hazardous Locations
This section contain important information regarding the installation of the PSD in Hazardous Area Locations
WARNING:
Do not separate power connector when energized.
WARNING:
Substitution of components is not allowed, as it may impair the intrinsic safety.
AVERTISSEMENT:
La substitution de composants peut compromettre la sécurité intrinséque.
WARNING:
To prevent ignition of ammable or combustible atmospheres, disconnect power before servicing.
AVERTISSEMENT:
Risque d’explosion. Avant de déconnecter l’equipement, couper le courant ou s’assurer que débrancher tant
que l’emplacement est désigné non dangereux.
WARNING:
Explosion Hazard. Do not disconnect equipment when a ammable or combustible atmosphere is present.
AVERTISSEMENT:
Risque d’explosion. Ne pas débrancher tant que le circuit est sous tension, a moins qu’il ne
s’ agisse d’un emplacement non dangereux.
Maximum operating parameters of the “COM” port for use in Non-Hazardous areas shall not exceed 3.0V, 300mA
and 240mW

Demand Moore Reliability 19
PSD
Specific Conditions for Safe Use
The following instructions must be adhered to when the PSD is used in hazardous locations and potentially
explosive atmospheres.
FM Installations
Intrinsically Safe Applications
Class I, II, III Division 1, Groups A-G
The PSD shall be installed in compliance with the enclosure, mounting, spacing and segregation requirements of
the ultimate application.
Connections shall not be made to the communications “COM” port in Hazardous (Classified) Locations
The maximum operating parameters fo the “COM” port for use in Non-Hazardous areas shall not exceed 3.0V ,
300uA, and 240 uW.
Nonincendive Applications
Class I, Division 2, Groups A-D
The PSD shall be installed in compliance with the enclosure, mounting, spacing and segregation requirements of
the ultimate application.
Connections shall not be made to the communications “COM” port in Hazardous (Classified) Locations.
The maximum operating parameters fo the “COM” port for use in Non-Hazardous areas shall not exceed 3.0V ,
300uA, and 240 uW.
CSA Installations
Intrinsically Safe Applications
Class I, Division 1, Groups A-D
The Model PSD must be installed per drawing No. 100-100-55 to be intrinsically safe.
Connections shall not be made to the communications “COM” port in Hazardous (Classified Locations)
The PSD is of open type unit Certified as a component for use only in other equipment where the suitability of the
combination is to be determined by the authority having jurisdiction.
Nonincendive Applications
Class I, Division 2, Groups A-D
Connections shall not be made to the communications “COM” port in Hazardous (Classified Locations)
The PSD is of open type unit Certified as a component for use only in other equipment where the suitability of the
combination is to be determined by the authority having jurisdiction.

20 Demand Moore Reliability
PSD
General Locations
The PSD is of open type unit Certified as a component for use only in other equipment where the suitability of the
combination is to be determined by the authority having jurisdiction.
European Union Installations
(ATEX 2014/34/EU Directive)
Intrinsically Safe Applications
II 1 G Ex ia IIC
The model PSD is intrinsically safe. It can be used in potentially explosive atmospheres and can only be
connect-ed to certified intrinsically safe associate equipment. This combination must be compatible with regards
to intrinsic safety.
The specific electrical parameters of the PSD model are:
Ui : 29.1V; Ii : 109mA; Ri : 71.12Ohms; Pi : 793mW; *Ci : 31.55uF; Li : 0
*Ci : 31.55uF is given for Ui : 6.2V internally limited by voltage limiters.
The electrical parameters of the certified associated intrinsically safe apparatus must
not exceed any of the following values:
Uo<=29.1VDC; Io<=109mA; Po<= 0.793W.
The “COM” port and the “VIEW” switch must not be used in hazardous locations.
The equipment must not be submitted to mechanical impacts or friction.
Nonincendive, Type n Applications - Zone 2
II 3 G Ex nA IIC T4
The PSD shall be installed in compliance with the enclosure, mounting, spacing and segregation requirements of
the ultimate application.
Connections shall not be made to the communications “COM” port in Hazardous (Classified) Locations.
The maximum operating parameters of the “COM” port for use in Non-Hazardous areas shall not exceed 3.0V ,
300uA and 240uW.
On installation the PSD shall be provided with supply transient protection external to the apparatus such that the
voltage at the supply terminals of the PSD does not exceed 119V peak or 119Vdc.
