SPD Quickstart Menu

Demand Moore Reliability 5
SPD
Programmable Field-Mount
Loop Display (NEMA 4X, IP66)
The SPD
The Moore Industries universal SPD Programmable
Loop Display accepts a 4-20mA input from a process
transmitter or similar analog device, and indicates
real-time process status in mA, percent, or any
designated engineering unit (EGU) on its 5-digit
display. Both the process value and engineering unit
(up to 5 characters) are shown on the display.
Versatile Programmability—The SPD can be
programmed on-site using front mounted buttons, or
our easy-to-use SPD PC Configuration Software.
Extra-Large Display—Read the process status from
across the room using the SPD’s independently
configured display, which features 29 millimeter-high
(1.15 inch) characters and an optional back-lit display
(The –BL option requires a 24Vdc power supply).
Superior Accuracy—The SPD displays your process
information with phenomenal accuracy of ±0.012% of
input scale.
Housing—The SPD comes in our Field Housing (FH)
that is NEMA 4X and IP66 certified. Pipe-mount
hardware is optional.
Dual Alarm Relays Available—The SPD is available
with individually configurable dual alarm trip relays
(–2PRG option). Each relay can be set to trip if the
4-20mA process variable falls outside of user set
high and/or low process limits. This allows the SPD
to connect to a warning light, annunciator, bell, or
shutdown system, protecting your process with a
simple, reliable shutdown system.
About this Manual
Wherever you see a “Note”, “Caution”, or “WARNING
” pay particular attention.
• A“Note” provides information to help you in avoiding
minor inconveniences during calibration, installation,
or operation of the SPD.
• A “Caution” provides information on steps to take
in avoiding procedures and practices that could risk
damage to the SPD or other equipment.
• A“WARNING ” provides information on steps to take
in avoiding procedures and practices that could pose
safety risks to personnel.
Figure 1. Both PC- and Site-Programmable, the SPD accepts a 4-20mA signal and outputs the signal to two alarm relays
4-20mA LOOP INPUT
A1
SELECT SITE PROGRAMMABLE
DISPLAY
ALARM RELAY #1
ALARM RELAY #2
PC FOR CONFIGURING
THE SPD USING THE
INTELLIGENT PC
CONFIGURATION
SOFTWARE
PUSH-BUTTONS
FOR ON-SITE
CONFIGURATION
SPD
A2
(ALARM RELAYS
ARE OPTIONAL)
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 208-236-00A*
* When using Optional USB
Cable Part# 208-236-00
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.

SPD
6 Demand Moore Reliability
Programmable Field-Mount
Loop Display (NEMA 4X, IP66)
Specifications
Type: LCD; Top Row,
29.21mm (1.15 inch) high
black digits on a reflective
background; Bottom Row,
15.24mm (0.6 inch) high
black digits on a reflective
background
Format: Top Row is five
alphanumeric characters
plus sign and decimal point;
Bottom row is five
alphanumeric characters
Range: -99999 to 99999
Display Update Rate:
100msec
Minimum Display Span:
1.00
Accuracy: ±0.012% of
input scale at 22°C (72°F).
This includes the combined
effects of linearity,
hysteresis, repeatability,
and adjustment resolution. It
does not include ambient
temperature effect
Stability:
0.09% of span for 1 year;
0.16% of span for 3 years;
0.2% of span for 5 years
Resolution:
0.0028% of input scale
Power Consumption
(24DC power):
With 2PRG option, 0.65W;
With 2PRG and BL
options, 1.15W
Burden (on input loop):
2.3VLP model, 115Ω; 24DC
model, 20Ω
Over-Current
Protection: 100mA
absolute maximum
Display Input Overrange:
24mA
Digital Input Filter: User-
programmable;
50 or 60Hz
Minimum Input Signal:
3.8mA
Isolation:
When 24Vdc power supply
is used, 500V between
supply and input
Response Time: Normal
Linearization Mode:
180msec or less for input to
display on a step input from
10% to 90% of the input
scale, 220msec or less for
input to alarm from time
of step change on input to
alarm state when alarm is
set to trip mid-point;
Custom Linearization Mode:
200msec or less for input to
display on a step input from
10% to 90% of the input
scale, 400msec or less for
input to alarm from time
of step change on input to
alarm state when alarm is
set to trip mid-point
Damping: User-selectable
for 0-30 seconds
Display
Performance
Performance
(Continued)
Ambient
Conditions
Weight
Operating Range:
-40°C to +85°C
(-40°F to +185°F)
Some slowing of display
response time will occur
below -25°C (-13°F)
Storage Range:
-45°C to +85°C
(-49°F to 185°F)
Relative Humidity:
0-95%, non-condensing
Ambient Temperature
Effect: ±0.005% of
span/°C maximum
RFI/EMI Immunity:
20V/m when tested
according to SAMA 33.1
ABC with 0.5% of span or
less error. 20 V/m@
80-1000MHz, 1 KHz AM,
when tested according to
IEC1000-4-3-1995
Common Mode Rejection:
100dB @ 50/60Hz
Normal Mode
Rejection: 50dB @
50/60Hz, 10mA p-p
maximum
1.56 kg (3.44 lbs.)
Specifications and information subject to change without notice.

Demand Moore Reliability 7
SPD
Programmable Field-Mount
Loop Display (NEMA 4X, IP66)
Installing the SPD
Installing the SPD in your loop involves mounting and
making the electrical connections. It is recommended
that the SPD be installed in the loop before it is
programmed so that you can use the input capture
features to capture the exact full and zero values of the
loop. (See Loop Connections) If this is not practical,
you can also use a variable current source and an
ammeter or multimeter to setup your unit before you
install it on the loop. (See Configuration Connections)
Mounting
The SPD comes prepared for field-mounting in a FH
enclosure.
Loop Connections
The recommended method of programming requires
you to install the SPD into the loop before you program
it. Figures 2 and 3 describe typical loop installations
of the 2.3VLP and 24DC SPD units.
To connect to the SPD, you will first need to remove
the side panel(s). Use a flathead screwdriver to
remove the four screws on the right side of the SPD. If
your SPD has the –2PRG option, you will also need to
remove the left side panel to give access to the alarm
relays.
Once the panels are open, make the electrical
connections as shown in Figures 2 and 3. When
connecting the SPD to the PC, it is essential that you
use the communications cable included with your SPD.
Note that 2.3VLP models with the –BL option require a
24Vdc power supply to power the backlight.
Note:
On the tag for the communications cable, it should
read “rev. D” or later. If it does not list a revision, then
it is an older Moore Industries cable, and may or may
not work properly with the SPD.
Device
Current Source
Power Supply
Multimeter
Communications
Cable
Screwdriver
Screwdriver
Specifications
Adjustable, Accurate to ±0.01% of reading
24Vdc (24DC or –BL models only)
Accurate to ±0.025% of reading
Isolated and non-isolated versions available
Slotted Tip, head width 5mm, maximum
Large, slotted tip
Table 1. Assembling the Necessary Equipment
Configuration Connections
To configure the SPD before attaching it to the loop,
you need a calibrated, adjustable current source
capable of discrete output levels in the 4-20mA range.
It should have a minimum accuracy of ±0.01%. Once
you have the required equipment (as shown in
Table 1), hook up the SPD according to either
Figure 4 or 5.
To connect to the SPD, you will first need to remove
the side panel(s). Use a flathead screwdriver to
remove the four screws on the right side of the SPD.
If your SPD has the –2PRG option, you may decide to
remove the left side panel to give access to the alarm
relays.
Once the panels are open, make the electrical
connections as shown in the appropriate Figure. When
connecting the SPD to the PC, it is essential that you
use the communications cable included with your SPD.
Note that 2.3VLP models with the –BL option require a
24Vdc power supply to power the backlight.

SPD
8 Demand Moore Reliability
Programmable Field-Mount
Loop Display (NEMA 4X, IP66)
SPD (2.3VLP Model)
SELECT SITE PROGRAMMABLE
DISPLAY
REMOVE
PANEL
TO ACCESS
TERMINALS
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
DIRECTLY TO THE INPUT!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST BE
IN THE LOOP!
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
*When using Optional USB
Cable Part# 804-030-26
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.
4-20mA
TRANSMITTER
–
+IN
–IN
+
–
LOOP
POWER
SUPPLY
Figure 2-A. Loop Connections for the 2.3VLP SPD
SPD (2.3VLP Model)
SELECT
SITE PROGRAMMABLE
DISPLAY
+IN
–IN
+24VDC
COM
INTERNAL SIDE VIEW
REMOVE
PANEL
TO ACCESS
TERMINALS
NOTE:
FOR 2-WIRE UNITS WITH
THE BACKLIGHT (–BL)
OPTION, ALSO ATTACH A
24VDC POWER SUPPLY
TO THE TERMINALS
LABELED "BACKLIGHT".
PC COMM.
CABLE
4-20mA
ONLY
BACKLIGHT
ONLY
+
–
24VDC
POWER
SUPPLY
FOR -BL
OPTION
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
DIRECTLY TO THE INPUT!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST BE
IN THE LOOP!
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
* When using Optional USB
Cable Part# 804-030-26
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.
4-20mA
TRANSMITTER
–
+IN
–IN
+
–
LOOP
POWER
SUPPLY
Figure 2-B. Loop Connections for the 2.3VLP SPD with Backlight ( -BL option)

Demand Moore Reliability 9
SPD
Programmable Field-Mount
Loop Display (NEMA 4X, IP66)
SPD (2.3VLP Model)
SELECT
SITE PROGRAMMABLE
DISPLAY
INTERNAL SIDE VIEW
REMOVE
PANELS
TO ACCESS
TERMINALS
BACKLIGHT
ONLY
+–
24VDC
POWER SUPPLY
FOR -BL
OPTION*
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
DIRECTLY TO THE INPUT!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST BE
IN THE LOOP!
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
* When using Optional USB
Cable Part# 804-030-26
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.
* For -ISC Option wiring for
Back light is located on left side,
remove panels to access terminals.
-ISC option has second port which
Back Light must be run through
Refer to Drawing 100-100-66
4-20mA
TRANSMITTER
–
+IN
–IN
+
–
LOOP
POWER
SUPPLY
Figure 2-C. Loop Connections for the 2.3VLP SPD with Backlight and Intrinsically Safe option ( -BL and -ISC )
Figure 3. Loop Connections for the 24DC SPD
SPD (24DC Model)
4-20mA
TRANSMITTER
+
–
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
TO THE SPD INPUT!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST BE
IN THE LOOP!
A1
SELECT SITE PROGRAMMABLE
DISPLAY
+IN
–IN
24DC POWER
SUPPLY
+
–
TO ALARM RELAYS
(UNITS WITH –2PRG)
+IN
–IN
+24VDC
COM
INTERNAL RIGHT SIDE VIEW
PC COMM.
CABLE
4-20mA
ONLY POWER
+24VDC
COM
+
–
LOOP
POWER
SUPPLY
NO1
COM1
NC1
INTERNAL LEFT SIDE VIEW
RELAY 1
RELAY 2
NO2
COM2
NC2
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
* When using Optional USB
Cable Part# 804-030-26
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.

SPD
10 Demand Moore Reliability
Programmable Field-Mount
Loop Display (NEMA 4X, IP66)
SPD (24DC Model)
+–
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
TO THE SPD INPUT!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST BE
IN THE LOOP!
A1
SELECT SITE PROGRAMMABLE
DISPLAY
+IN
–IN
24DC POWER
SUPPLY
+
–
TO ALARM RELAYS
(UNITS WITH –2PRG)
+IN
–IN
+24VDC
COM
INTERNAL RIGHT SIDE VIEW
PC COMM.
CABLE
4-20mA
ONLY POWER
+24VDC
COM
NO1
COM1
NC1
INTERNAL LEFT SIDE VIEW
RELAY 1
RELAY 2
NO2
COM2
NC2
AMMETER OR
MULTIMETER
+
–
ADJUSTABLE
CURRENT
SOURCE
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
* When using Optional USB
Cable Part# 804-030-26
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.
Figure 5. Configuration Connections for the 24DC SPD
SPD (2.3VLP Model)
SELECT
SITE PROGRAMMABLE
DISPLAY
+–
REMOVE
PANEL
TO ACCESS
TERMINALS
NOTE:
SEE FIGURES 2-B AND 2-C FOR
24VDC CONNECTIONS FOR
BACKLIGHT ( -BL )
AMMETER OR
MULTIMETER
+
–
ADJUSTABLE
CURRENT
SOURCE
CAUTION:
DO NOT CONNECT THE
LOOP POWER SUPPLY
DIRECTLY TO THE INPUT!
A CURRENT LIMITING
DEVICE SUCH AS A
TRANSMITTER MUST BE
IN THE LOOP!
TO SERIAL
(COM) PORT
OF PC
OR
To USB
(COM)
Port of PC
803-040-26 FOR NON-ISOLATED CABLE
803-039-26 FOR ISOLATED CABLE
or Optional USB Cable Part# 804-030-26*
* When using Optional USB
Cable Part# 804-030-26
please assure that the ground
of the SPD is at the same
potential as the PC that the
usb cable is plugged in.
–IN
+IN
Figure 4. Configuration Connections for the 2.3VLP SPD
