Javelin CVMA9A User manual

BcJ!!iAVEllN
CVMSA(X)
9” Color Monitor
Installation and Operation Manual
November 1996
Revision A 25-CVM9A

CVMSA(X) INSTALLATION AND OPERATION MANUAL
.’ I, .
Copyright 0 Javelin Systems, A Division of Ademco Security Group, Inc.
All rights resewed. No part of this publication may be reproduced by any means‘
without the permission of Javelin Systems.
The information in this publication is believed to be accurate in all respects.
However, Javelin Systems cannot assume responsibility for any consequences
resulting from the use thereof. The information contained herein is subject to
change. Revision to this publication or new additions to it may be issued to
incorporate such changes.
ii

CVMSA(X) 9” COLOR MONITOR
.. ‘INSTALLATION AND OPERATION MANUAL
IMPORTANT SAFEGUARDs
1.
2.
.3.
4.
5.
6.
7.
a.
9.
Read Instructions - All the safety and operating instructions should be
read before the unit is operated. .
Retain Instructions - The safety and operating instructions should be
retained for future reference.
Heed Warnings - All warnings on the unit and in the operating instructions
should be adhered to.
Follow instructions - All operating and user instructions should be
followed.
Cleaning - Unplug the unit from the outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
Water and Moisture - Do not use this unit near water - for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, near
a swimming pool, in an unprotected outdoor installation, or any area which
is classified as a wet location.
Accessories - Do not place this unit on an unstable stand, tripod bracket,
or mount. The unit may fall, causing serious injury to a person, and
serious damage to the unit. Use only with a stand, tripod, bracket, or
mount recommended by the manufacturer, or sold with the product. Any
mounting of the unit should follow the manufacturer’s instructions, and
should use a mounting accessory recommended by the:manufacturer.
An appliance and cart combination should be moved with care. ‘Quick
stops, excessive force, and uneven surfaces may cause the appliance
and cart combination to overturn.
Ventilation - Openings in the enclosure, if any, are provided for ventilation
and to ensure reliable operation of the unit and to protect it from
overheating. These openings must not be blocked or covered. This unit
November 1996 Page 1

CVMSA(X) INSTALLATION AND OPERATION MANUAL
should not be placed in a built-in installation unless proper ventilation is
provided or the manufacturer’s instructions have been adhered to.
10. Power Sources - This unit should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of
power supply you plan to use, consutt your appliance dealer or local
power company. For units intended to operate from battery power, or
other sources, refer to the operating instructions.
11. Grounding or Polarization - This unit may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to frt, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
Alternately, this unit may be equipped with a 3-wire grounding type plug, a
plug having a third (grounding) pin. This plug will only fit into a grounding-
type power outlet. This is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the grounding-type plug.
12. Power Cord Protection - Power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
13. Power Lines - An outdoor system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it
can fall into such power lines or circuits. When instailing an outdoor _
system, extreme care should be taken to keep from touching such power
lines or circuits as contact with them might be fatal. U.S.A. models only -
refer to the National Electrical Code Article 820 regarding installation of
CAN systems.
14. Overloading - Do not overload outlets and extension cords as this can
result in a risk of fire or electric shock.
15.
Object and Liquid Entry - Never push objects of any kind into this unit
through openings as they may touch dangerous voltage points or short
out parts that could result in a fire or electric shock. Never spill liquid of
anykindontheunit.
November 1996 Page 2

CVMSA(X)INSTALLATIONAND OPERATIONMANUAL
16.
17.
18.
19.
20.
21.
Servicing - Do not attempt to service this unit yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
.Refer all servicing to qualified service personnel.
Damage Requiring Service - Unplug the unit from the outlet and refer
servicing to qualified service personnel under the following conditions:
a. : When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen .intothe unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualified.technician to restore the unit to its normal operation.
e.
f.
If the unit has been dropped or the cabinet has been damaged.
When the unit exhibits a distinct change in performance -,this
indicates a need for service.
Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other
hazards.
Safety Check - Upon completion of any service or’repairs to this unit, ask
the service technician to perform safety checks to determine that the uriii
is in proper operating conditions.
Coax Grounding - If an outside cable system is connected to the unit, be
sure the cable system is grounded. U.S.A. models only - Section 810 of
the National Electrical Code, ANSIINFPA No. 70-1981, provides
information with respect to proper grounding of the coax to a discharge
unit, size of grounding conductors, location of discharge unit, connection
to grounding electrodes, and requirements for the grounding electrode.
Lightning - For added protection of this unit during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the cable system. This will prevent
damage to the unit due to lightning and power line surges.
November1996 Page3

CVMSA(X) INSTALtATIONAND OPERATIONMANUAL
FCC AND ICES INFORMATION
(U.S.A. and Canadian Models Only)
WARNING - This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules and ICES-003
of Industry Canada. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential
installation. .This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
0 Reorient or relocate the receiving antenna.
l
Increase the separation between the equipment and receiver.
0 Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
0 Consult the dealer or an experienced radio/TV technician for help.
Intentional or unintentional changes or modifications not expressly approved by
the party responsible for compliance shall not be made. Any such changes or
modifications could void the user’s authority to operate the equipment.
The user may find the following booklet prepared by the Federal
Communications Commission helpful: “How to Identify and Resolve Radio-TV
Interference Problems”. This booklet is available from the U.S. Government
Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4.
SAFETY PRECAUTIONS
RISK OF ELECTRIC SHOCK
DO NOT OPEN! A m
CAUTION: TO REDUCE THE RISK OF ELECTRiCAL SHOCK. DO NOT
OPEN COVERS. NO USERSERVICEABLE PARTS INSIDfi. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
November 1996 Page 4

CVMSA(X)INSTALLATIONAND OPERATION’MANUAL
This label may appear on the bottom of the unit due to space limitations.
A
The lightning flash with an arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
To prevent fire or shock hazard, do not
i
expose units not specifically desrgned
tfor outdoor use to rain or moisture.
Attention: Installation should be performed by qualified service
personnel only in accordance with the national Electrical Code
or applicable local codes.
Power Disconnect. Units with or without ON-OFF switches
have power supplied to the unit whenever the power cord is
inserted into the power source; however, the unit is operational
only when the ON-OFF switch is in the ON position. The
power cord is the main power disconnect for all units.
Improper Operation. Alteration of the high voltage circuit ‘or’
changing the display tube type may result in an increase in the
x-ray emission of this unit. A unit altered in such a way no
longer meets the standards of certification and must no longer
be operated.
WARNING: Electrostatic-sensitive device. Use proper CMO&MOSFET
handling precautions to avoid electrostatic discharge.
NOTE: Grounded wrist straps must be worn and proper ESD safety precautions
observed when handling the electrostatic-sensitive printed circuit boards.
November 1996 Page 5

CVMSA(X)INSTALLATIONANDOPERATIONMANUAL
UNPACKING
Unpaek carefully. This is electronic equipment and should be handled with care.
The shipping carton is the safest container in which the unit may be transported.
Save it for possible future use.
DESCRIPTION
The CVMSA(X) is a 23-cm (g-inch) color video monitor for specialized
sunreillance and industrial CCTV applications. This color monitor provides
excellent picture quality and convenient control of functions. It is ideal for time
lapse and event alarm VCR systems, or color video multiplexers.
INSTALLATION
Location - The monitor should be located in a position such that the flow of air
around the unit is not restricted:! Avoid heat vents or other heat sources.
Component life is greatly enhanced with moderate temperatures.
POWER
Model Rated
No.’ Voltage Voltage Range Nominal
PoweS Color System
CVMSA 120 VAC, 60Hz 108 to 132 0.63 A NTSC
CVMSA(X) 230 VAC, 50Hz 198 to 264 0.31 A CCIR PAL
1. These units’may be supplied with grounded power cords; grounding .
should be defeated.
2. At rated voltage.
Video Cabling - To assure good picture quality, use 75 ohm coaxial cable and be ’sure the unit is terminated correctly. Cable attenuation should also be
considered on long cable runs and adequate video signal levels provided.
When the monitor is located at the end of the cable run, use the VIDEO IN
connector on the rear of the chassis and set the termination switch to the “75 Q
position.
November1996 Page6

CVMSA(X)INSTALLATIONAND OPERATIONMANUAL
OPERATION
To obtain the best possible operation from this product, the following setup
procedure should be followed when installing the monitor. The setup process is
very simple and straightforward, and involves nothing more than attaching a
source of color video and adjusting the controls to the detent position. This
provides a factory preset condition which allows normal viewing. If contrast,
brightness, chrome or phase need to be fine tuned, please use the following
procedures to obtain the best picture. Note that the center detent position on all
front panel controls is the normal setting; a subcontrol is provided for presetting
each control. The subcontrol,adjustments should be adjusted by a qualified
service technician only.
1
*
2.
3.
4.
5.
6.
7.
Connect a camera or other source of standard color video signal to the
VIDEO IN of the monitor.
Turn on the PO\(?JERswitch; LED indicator will light. Allow the monitor to
warm up for about 30 seconds. Adjust the PHASE control (applies to
CVMSA only), to the center detent position. If necessary, for best tint
adjustment, rotate the Phase control to obtain the desired picture.
Adjust the CHROMA control to the center detent position. The monitor
screen should appear to provide a color image. If the image requires
more color saturation, rotate the cqntrol clockwise. If colors appear too
saturated, adjust the control counter-clockwise.
Adjust BRIGHT and CONTRAST controls to the center detent position. If
dark scene areas require enhancement, the BRIGHT control can be
rotated clockwise. If the “black level”, which determines the darkest
portion of the picture, appears too light,.rotate the BRIGHT control --
counter-clockwise. -a
When video is looping through the monitor to another video device,
properly switch the termination switch on the rear panel of the monitor
from the 75 ohm position to the Hi2 position (High Impedance).
NOTE - There are no external Vertical or Horizontal Hold controls. The
monitor contains circuitry to lock the synchronization internally.
NOTE - Overdrive of the white portions of the video, sufficient to cause
blooming, can significantly shorten the service life of the C,RT. Always
adjust the BRIGHT and CONTRAST controls to the center detent position
or towards a minimum setting to enhance monitor life expectancy.
November1996 Page7

CVMSA(X) INSTALLATION AND OPERATIONMANUAL
MAINTENANCE ”
This unit contains no user serviceable components.
Maintenance, beyond the adjustments described herein,
should be attempted only by trained technical personnel.
CVMSA
Front Panels
November 1996 Page 8

CVMSA(X) INSTALlATlON AND OPERATION MANUAL
Rear Panel
I.
!I
VideoCamera
7sn
PI
OPEN
bridged(looping)connectionis
mwe. J
OPEN
Equipmentwhichrequitesvideo
signalinput
l!zizl
..
._
VideoMonitor
Typical A~cations
November 1996 Page 9

CVM9A(X) INSTALLATION AND OPERATION MANUAL
LIMITED WARRANTY
Javelin Systems warrants each CVMSA(X) 9” Color Monitor to be free from
defects in material and workmanship for the period of one (1) year from the date
of purchase. This warranty shall not apply to any product or parts which have
been subject to misuse, modification, neglect, accident, lightning, electrical
transients, improper wiring or abnormal conditions of operation.
In the event of failure of a product covered by this warranty, Javelin Systems will
at its own option, either repair or replace the product when returned to Javelin
Systems. Upon examination of equipment at the factory, Javelin Systems shall
be the sole and final judge of propriety of qualification for warranty services. This
warranty does not cover transportation costs.
SHIPPING INSTRUCTIONS
If this equipment must be returned to the factory, follow these instructions.
1. Call Javelin Customer Service and ask them to assign you a RETURN
AUTHORIZATION number, as well as provide you with any additional
instructions that might be needed.
2. Write the following information on a sheet of paper so that you can send it
with the unit:
0
A short description of your installation.
0
Describe the problem and circumstances under which the problem
occurs.
l
The original purchase date and estimated length of time that the
unit has actively been used.
3.
4. Package the unit using the ORIGINAL shipping carton.
The Return Authorization Number, with out address, MUST be clearly
written on the outside of the carton. Our address is:
Javelin Systems .
325 Maple Avenue
Torrance, CA 90503-2602
Returned equipment that is not clearly marked with a valid RETURN
AUTHORIZATION number will be refused and returned to you at your expense.
November 1996 Page 10

JAVELIN SYSTEMS
A diision of AdemcaSecurityGroup,Inc
USA
23456HawthorneBlvd..Bldg5
TorranceCA905054716
[phone]or(600)421-2716(USA)
Fax [phone]X63
Javelin Systems maintainsa completetechnicalstafftoassistin spedfyingandusingJavelinproducts. Javelinis an EqualOpportunity
Employer. Javelinresews therighttochangefeaturesandSpedf~cationswithoutnotice. Printed in USA.
