Philips HUDSON IV 150C5 User manual

Horizontal Frequencies
30 - 61KHz
Service
Service
Service
TABLE OF CONTENTS
Published by BCU Monitors Printed in Suzhou Copyright reserved Subject to modification H July. 9 2004
Description Page
Important Safety Notice ---------------------------------- 2
Technical Data ------------------------------------------3~4
On Screen Display---------------------------------------10
Electrical Instructions------------------------------------11
Mechanical Instructions----------------------------13
Factory Mode &Aging Mode---------------------------15
Warning Message----------------------------------------16
Repair FlowChart-----------------------------------18
~14
~20
Philips Pixel Defect Policy--------------------------------5
Troubleshooting--------------------------------------------6
Installation -----------------------------------------------7~9
Safety Test Requirement--------------------------------12
Repair Tips------------------------------------------------17
Wiring Diagram-------------------------------------------21
Description Page
--------------------------------22
-------------------------------------------32
Function BlockDiagram
Scaler Schematic Diagram-----------------------23~26
Scaler Board C.B.A.--------------------------------27~28
Control Schematic Diagram &C.B.A.---------------29
Power Schematic Diagram------------------------30~31
Exploded View
Failure Mode Of Panel----------------------------------36
34Spare Parts List------------------------------------33~
Recommended Parts List -----------------------------35
General Product Specification-------------------37~58
DDCInstructions------------------------------------59~63
DDCData-------------------------------------------------64
~67
-----------------------65Firmware Update For CPU
HUDSON IV 150C5
REFER TO BACK COVER FOR IMPORTANT SAFETYGUIDELINES
CAUTION:USEASEPARATE ISOLATION TRANSFORMER FOR THISUNIT WHEN SERVICING.
ANYPERSON ATTEMPTING TO SERVICETHISCHASSISMUSTFAMILIARIZEHIMSELF WITHTHECHASSIS
AND BE AWARE OF THENECESSARYSAFETYPRECAUTIONSTO BEUSED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGHVOLTAGES.
SAFETY NOTICE
GBGB3138 10610406
15"XGATFTLCDMonitor
«
Model: 150C5BS/00
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Proper service and repair is important to the safe, reliable
operation of all Philips Consumer Electronics Company**
Equipment. The service procedures recommended by
Philips and described in this service manual are effective
methods of performing service operations. Some of these
service operations require the use of tools specially designed
for the purpose. The special tools should be used when and
as recommended.
It is important to note that this manual contains various
CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service
personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to
understand that these CAUTIONS and NOTICES ARE NOT
EXHAUSTIVE. Philips could not possibly know, evaluate and
advise the service trade of all conceivable ways in which
service might be done or of the possible hazardous
consequences of each way. Consequently, Philips has not
undertaken any such broad evaluation. Accordingly, a
servicer who uses a service procedure or tool which is not
recommended by Philips must first satisfy himself thoroughly
thatneitherhissafetynorthesafeoperationofthe
equipment will be jeopardized by the service method
selected.
* * Hereafter throughout this manual, Philips Consumer
Electronics Company will be referred to as Philips.
Critical components having special safety characteristics are
identifiedwitha bytheRef.No.inthepartslistand
enclosed within a broken line*
(where several critical components are grouped in one area)
along with the safety symbol on the schematics or
exploded views.
Use of substitute replacement parts which do not have the
same specified safety characteristics may create shock, fire,
or other hazards.
Under no circumstances should the original design be
modified or altered without written permission from Philips.
Philips assumes no liability, express or implied, arising out of
any unauthorized modification of design.
Servicer assumes all liability.
WARNING
*Broken Line
FOR PRODUCTS CONTAINING LASER :
Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
The use of optical instruments with this
product will increase eye hazard.
DANGER-
CAUTION-
CAUTION-
TO ENSURE THE CONTINUED RELIABILITY OF THIS
PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S REPLACEMENT
PARTS, WHICH ARE LISTED WITH THEIR
PART NUMBERS IN THE PARTS LIST SECTION OF THIS SERVICE
MANUAL.
Take care during handling the LCD module with backlight unit
- Must mount the module using mounting holes arranged in four
corners.
- Do not press on the panel, edge of the frame strongly or electric
shock as this will result in damage to the screen.
- Do not scratch or press on the panel with any sharp objects, such
as pencil or pen as this may result in damage to the panel.
- Protect the module from the ESD as it may damage the electronic
circuit (C-MOS).
- Make certain that treatment person s body are grounded through
wrist band.
-Donotleavethemoduleinhightemperatureandinareasofhigh
humidityforalongtime.
-Avoidcontactwithwaterasitmayashortcircuitwithinthe
module.
-Ifthesurfaceofpanelbecomedirty,pleasewipeitoffwithasoft
material. (Cleaning with a dirty or rough cloth may damage the
panel.)
Important Safety Notice
!
!
2150C5 LCD
Go to cover page
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Go to cover page
150C5 LCD 3
Technical Data
Product Features
Fast response time capable of handling fast moving pictures
sRGB ensures color matching between display and printouts
XGA 1024x768 resolution for sharper display
Elegant, sleek design complements your home d cor
Compact and slim design saves space and fits anywhere
TCO guarantees the highest safety and ergonomics standards
The lower power consumption than industry average
Embedded power supply eliminates external power adaptors
Auto adjustment for perfect picture display with one touch
Easily adjust display settings with Philips SmartControl
Cable clip manages cables for a tidy work space
Detachable base for easy moving and storage
Screen tilts for comfortable viewing from any angle
Outstanding front of screen performance
Design that complements any interior
Best value for money
Great convenience
Technical Specifications*
LCD PANEL
SCANNING
VIDEO
Type TFT LCD
Screen size 15" visual (38cm)
Pixel Pitch 0.297 x0.297 mm
1024x768 pixels
R.G.B. vertical stripe
Anti-glare polarizer, hard coated
Ef fective viewing area 304.1x228.1mm
Display Colors 16M colors
Vertical refresh rate 56 Hz-76 Hz
Horizontal Frequency 30kHz-61 kHz
V ideo dot rate 80 Mhz
Input impedance
- Video 75 ohm
- Sync 2Kohm
Input signal levels 700m Vpp
Sync input signal
Sync polarities Positive and negative
XGA Hsync 48-61 kHz,
Vsync 60 -76 Hz (N.I.)
VGA Hsync 31-38kHz,
Vsync 60 -76 Hz (N.I.)
V ideo interface Analog (D-Sub)
SVGA Hsync 35-50 kHz,
Vsync 56 -75 Hz (N.I.)
LCD Panel type
Separate sync
Composite sync
Sync on green
Input Frequency
contrast ratio 400:1(typ.)
Brightness 250 cd/m (typ.)
Optical characteristics
Peak contrast angle 6o'clock
x: 0.283y:0.297 (at 9300 K)
White Chromaticity x: 0.313y:0.329(at 6500 K)
x: 0.313y:0.329(at sRGB)
Upper 45 (typ.)
Viewing Angle (C/R>=10) Lower 55 (typ.)
Left 65 (typ.)
Right 65 (typ.)
Response time 16 ms (typ.)
sRGB is a standard
SRGB
for ensuring correct exchange of colors between
different devices (e.g. digital cameras, monitors, printers, scanners, etc.)
Using a standard unified color space, sRGB will help represent pictures
taken by an sRGBcompatible device correctly on your sRGB enabled
Philips monitors. In that way, the colors are calibrated and you can rely
on the correctness of the colors shown on your screen.
Important with the use of sRGB is that the brightness and contrast of
your monitor is fixed to a predefined setting as well as the color gamut.
Therefore it is important to select the sRGB setting in the monitor's OSD.
To do so, open the OSD by pressing the OKbutton on the front of your
monitor. Use the down button to go to Adjust Color and press OKagain.
Then move the down button to go to sRGB and press OKagain.
After this, please do not change the brightness or contrast setting of your
monitor. If you change either of these, the monitor will exit the sRGB
mode and go to a color temperature setting of 6500K.
For more information on sRGB, please visit: www.srgb.com
2
O
O
O
O
O
O
Resolution & Preset Modes
15 user definable modes
14 factory preset modes:
Maximum 1024X768 at 75Hz
Recommended 1024X768 at 60 Hz
31.469 640*350 70.086
31.469 720*400 70.087
31.469 640*480 59.940
35.000 640*480 67.000
37.861 640*480 72.809
37.500 640*480 75.000
35.156 800*600 56.250
37.879 800*600 60.317
48.077 800*600 72.188
46.875 800*600 75.000
49.700 832*62475.000
48.3631024*768 60.004
56.476 1024*768 70.069
60.023 1024*768 75.029
H. Freq (kHz) Resolution V. freq (Hz)
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

4150C5 LCD
Go to cover page
Technical Data
R
R
R
Physical Specification
Dimension (WXHXD)* 360 x349 x173.5mm (incl. Pedestal)
Weight 2.97 Kg
Tilt -5--25
Power Supply 100 ---240VAC, 50/60 Hz
Power consumption 18 W* (typ.)
Temperature 5Cto40 C (operating)
-20Cto60 C (storage)
Relative humidity 20% to 80%
System MTBF 50K hours (excluding CCFL 40K hours)
*This data is subject to change without notice.
*Resolution 1024X768, standard size, brightness max., Contrast 50%,
full white pattern.
OO
OO
OO
Pin
No. Assignment Pin No. Assignment
1Red video input 9+5V
2Green video input/SOG 10 Logic ground
3Blue video input 11 Ground
4Sense (GND) 12Serial data line (SDA)
5Hot Plug Detect 13H. Sync /H+V
6Red video ground 14 V. Sy nc ( VC LKfor DDC)
7Green video ground 15 Data clock line (SCL)
8Blue video ground
Pin Assignment
The 15-pin D-sub connector(male) of the signal cable(IBM systmes):
Physical Function
Tilt
Automatic Power Saving
If you have VESA DPMS compliance display card or software installed in
your PC, the monitor can automatically reduce its power consumption
when not in use. If an input from a keyboard, mouse or other input device
is detected, the monitor will 'wake up' automatically. The following table
shows the power consumption and signaling of this automatic power
saving feature:
VESA Mode Video H-sync V-sync Power Used LED color
ON Active Yes Yes <20W Green
OFF Blanked No No <1W Amber
This monitor is ENERGY STAR compliant. As an ENERGY STAR
Partner, PHILIPS has determined that this product meets the ENERGY
STAR guidelines for energy efficiency.
Power Management Definition
This monitor is equipped with a function for saving energy which
supports the VESA Display Power Management Signaling (DPMS)
standard. This means that the monitor must be connected to a
computer which supports VESA DPMS to fulfill the requirements
in the NUTEKspecification 803299/94. Time settings are adjusted
from the system unit by software
.
NUTEKVESA State LED Indicator Power Consumption
Normal operation ON Green <20W
Power Saving
Alternative 2
One step
OFF Amber <1W
As an ENERGY STAR Partner, PHILIPS has
determined that this product meets the
ENERGY STAR guidelines for energy
efficiency.
R
R
Energy Star Declaration
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Go to cover page
150C5 LCD 5
Philips Pixel Defect Policy
Philips' Flat Panel Monitors Pixel Defect Policy
Philips strives to deliver the highest quality products. We
use some of the industry's most advanced manufacturing
processes and practice stringent quality control. However,
pixel or sub pixel defects on the TFT LCD panels used in
flat panel monitors are sometimes unavoidable. No
manufacturer can guarantee that all panels will be free
from pixel defects, but Philips guarantees that any monitor
with an unacceptable number of defects will be repaired or
replaced under warranty. This notice explains the different
types of pixel defects and defines acceptable defect levels
for each type. In order to qualify for repair or replacement
under warranty, the number of pixel defects on a TFT LCD
panel must exceed these acceptable levels. For example,
no more than 0.0004% of the sub pixels on a 15" XGA
monitor may be defective. Furthermore, Philips sets even
higher quality standards for certain types or combinations
of pixel defects that are more noticeable than others. This
policy is valid worldwide.
Pixels and Sub pixels
A pixel, or picture element, is composed of three sub pixels
in the primary colors of red, green and blue. Many pixels
together form an image. When all sub pixels of a pixel are lit,
the three colored sub pixels together appear as a single
white pixel. When all are dark, the three colored sub pixels
together appear as a single black pixel. Other combinations
of lit and dark sub pixels appear as single pixels of other
colors.
Types of Pixel Defects
Pixel and sub pixel defects appear on the screen in different
ways. There are two categories of pixel defects and several
types of sub pixel defects within each category. Bright dot
defects appear as pixels or sub pixels that are always lit or
'on'. These are the types of bright dot defects:
One lit red,
green or
blue sub pixel
Two adjacent lit
sub pixels:
- Red +Blue =Purple
- Red +Green =Yellow
- Green +Blue =Cyan
(Light Blue)
Three adjacent lit
sub pixels
(one white pixel)
Black Dot Defects Black dot defects appear as pixels or sub
pixels that are always dark or 'off'. These are the types of black
dot defects:
One dark sub pixel Two or three adjacent dark sub pixels
Proximity of Pixel Defects
Because pixel and sub pixels defects of the same type that are
near to one another may be more , Philips also
specifies tolerances for the proximity of pixel defects.
Pixel Defect Tolerances
In order to qualify for repair or replacement due to pixel defects
during the warranty period, a TFT LCD panel in a Philips flat panel
monitor must have pixel or sub pixel defects exceeding the
tolerances listed in the following tables.
BRIGHT DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150C5
1lit subpixel 4or fewer
2 adjacent lit subpixels 2 or fewer
3 adjacent lit subpixels (one white
pixel) 0
Distance between two bright dot
defects* 15 mm or more
Total bright dot defects of all types 4 or fewer
BLACKDOT DEFECTS ACCEPTABLE LEVEL
MODEL 150C5
1dark subpixel 4or fewer
2 adjacent dark subpixels 2 or fewer
3 adjacent dark subpixels 1or fewer
Distance between two black dot defects* 15 mm or more
Total black dot defects of all types 4or fewer
TOTAL DOT DEFECTS ACCEPTABLE LEVEL
MODEL 150C5
Total bright or black dot defects of all
types 5or fewer
Note:
*1or 2 adjacent sub pixel defects =1dot defect
All Philips monitors are ISO13406-2 Compliant
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Troubleshooting
6150C5 LCD
Go to cover page
Common Problems
Having this problem?Check these items
No Picture
(power LED not lit)
·Make sure the power cord is plugged into the power outlet
and into the back of the monitor.
·First, ensure that the power button on the front of the monitor is in
the OFF position, then press it to the ON position
No Picture
(Power LED is amber or yellow)
·Make sure the computer is turned on.
·Make sure the signal cable is properly connected to your computer.
·Check to see if the monitor cable has bent pins.
·The Energy Saving feature may be activated
Screen says ·Make sure the monitor cable properly connected to your computer.
(Also refer to the Quick Set-Up Guide).
·Check to see if the monitor cable has bent pins,
·Make sure the computer is turned on.
Screen says ·Make sure the vertical sync of input signal is within the range of
56--75Hz.
·Change the refresh rate to 56--75Hz within 10 minutes.
·Re-power on monitor to start over again if you failed to change the
refresh rate within 10 minutes.
AUTO button not working properly ·The Auto Function is designed for use on standard Macintosh or
IBM-compatible PCs running Microsoft Windows.
·It may not work properly if using nonstandard PC or video card.
Image Problems
Having this problem?Check these items
Display position is incorrect ·Press the AUTO button
·Adjust the image position using the Horizontal Position
and/or Vertical Position in OSD Main Controls.
Image vibrates on the screen ·Check that the signal cable is properly connected to the
graphics board or PC.
Vertical flicker appears ·Press the AUTO button
·Eliminate the vertical bars using the Clock Adjustment of
VIDEO NOISE in OSD Main Controls.
Horizontal flicker appears ·Press the AUTO button
·Eliminate the horizontal bars using the Phase
Adjustment of VIDEO NOISE in OSD Main Controls.
The screen is too bright or too dark
·Adjust the contrast and brightness on OSD Main Controls. (The
backlight of the LCD monitor has a fixed life span. When the
screen becomes dark or begins to flicker, please contact your
dealer).
An after-image appears ·If an image remains on the screen for an extended period of time,
it may be imprinted in the screen and leave an after-image. This
usually disappears after a few hours.
An after-image remains after the power has
been turned off.
·This is characteristic of liquid crystal and is not caused by a
malfunction or deterioration of the liquid crystal. The after-image
will disappear after a period of time.
Green, red, blue, and white dots remains ·The remaining dots are normal characteristic of the liquid crystal
used in today s technology.
This page deals with problems that can be corrected by the user.
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Go to cover page
150C5 LCD 7
Front view product description
1Automatically adjust the horizontal position,
vertical position, phase and clock setting.
2 UP and DOWN buttons are used when
adjusting the OSD of your monitor.
3 BRIGHTNESS hotkey. When the UP and
DOWN arrow buttons are pressed, the
adjustment controls for the BRIGHTNESS will
show up.
4OKbutton which when pressed will take you to
the OSD controls.
5LEFT and RIGHT buttons, like the UP and
DOWN buttons, are also used in adjusting the
OSD of your monitor.
6Power LED
7POWER button switches your monitor on.
Back view product description
1Kensington anti-thief lock
2 VGA input
3 AC power input
Optimizing Performance
For best performance, ensure that your display settings are set at
1024x768,60Hz.
You can check the current display settings by pressing
the 'OK' button once. Go into the Product Information.
The current display mode is shown on the item called
RESOLUTION.
You can also install the , a
program for getting the best performance out of your monitor. This is
included on this CD. Step-by-step instructions are provided to guide
you through the installtion process. Click on the link to know more about
this program.
Note:
Flat Panel Adjust (FP Adjust) program
Installations
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

8150C5 LCD
Go to cover page
1)
2)
3)
Note: If you use an Apple Macintosh, you need to connect the
special Mac adapter to one end of the monitor signal cable.
4)
4)
(a)
(b)
(c)
(d)
Connect to PC
Turn off your computer and unplug its power cable.
Connect the monitor signal cable to the video connector on
the back of your computer.
Plug the power cord of your computer and your monitor into a
nearby outlet.
Turn on your computer and monitor. If the monitor displays an
image, installation is complete.
Connecting to Your PC
Installations
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Go to cover page
150C5 LCD 9
Attaching & Detaching and Removing the base
Installations
To attach the base:
1)
2)
3)
Hold the monitor body with both hands.
Align four-pronged base attachment unit on the bottom of
the screen with the four socket holes on the base.
Firmly fix screen into the base plate.
To detach the base:
1)Place the monitor face down a smooth surface taking care
to avoid scratching or damaging the screen.
2)
1)
Press the release latches on the bottom of the base
together and gently remove the attachment unit from the
base.
Detach the screen from the base.
To remove the base for VESA standard mounting applications
2) Remove the screws and then detach the base attachment unit
from the LCD monitor.
Note: This monitor is designed to work with a 100mm x 100mm
VESA-compliant mounting interface.
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

10 150C5 LCD
Go to cover page
Description of the On Screen Display
This is a feature in all Philips LCD monitors. It allows an end user to adjust screen performance of the monitors directly through an on-screen
instruction window. The user interface provides user friendliness and ease-of-use when operating the monitor.
When you press the button on the side control of your monitor,
the On-Screen Display (OSD) Main Controls window will pop up and
you can then start making adjustments to your monitor's various features.
Use the or the keys to make your adjustments.
What is the On-Screen Display?
Basic and simple instruction on the control keys.
The OSDTree
Below is an overall view of the structure of the On-Screen Display. You
can use this as a reference when you want to work your way around
the different adjustments later on.
On-Screen Display
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Electrical Instructions
Go to cover page
150C5 LCD 11
1. General points
1.1During the test and measuring, supply a distortion free AC
mains Voltage to the apparatus via an isolated transformer
with low internal resistance.
1.2 All measurements mentioned hereafter are carried out at a
Normal mains voltage (90 - 132 VAC for USA version,
195 -264 VAC for EUROPEAN version, or 90 - 264 VAC
for the model with full range power supply, unless otherwise
stated.)
1.3 All voltages are to be measured or applied with respect to
ground, unless otherwise stated.
Note: don t use heat-sink as ground.
1.4 The test has to be done on a complete set including LCD
panel after 30 minutes warm-up at least in a room with
temperature of 25 +/- 5 degree C.
1.5 All values mentioned in this test instruction are only applicable
of a well aligned apparatus, with correct signal.
1.6 The letters symbols (B) and (S) placed behind the test
instruction denotes(B): carried out 100% inspection at
assembly line (S): carried out test by sampling
1.7 The white balance (color temperature), has to be tested in
subdued lighted room.
1.8 Repetitive power on/off cycle are allowed except it should
be avoided within 6 sec.
2. Input signal
2.1Signal type
Video: 0.7 Vp-p linear, positive polarity
Sync. : TTL level, separate, positive or negative polarity
Signal source: pattern generator format as attachment
(table 1to 14)
Reference generator: Quantum 802BT or VTG 1250
2.2 Allowed signal mode specified
PRESET VIDEO RESOLUTION
Dot rate (MHz) H.freq (KHz) Mode Resolution V.freq (Hz)
25.175 31.469 VGA 640 * 350 70.087
28.322 31.469 VGA 720 * 400 70.087
25.175 31.469 VGA 640 * 480 59.940
30.240 35.000 MACINTOSH 640 * 480 66.667
31.500 37.861VESA 640 * 480 72.809
31.500 37.500 VESA 640 * 480 75.000
36.000 35.156 VESA 800 * 600 56.250
40.000 37.879 VESA 800 * 600 60.317
50.000 48.077 VESA 800 * 600 72.188
49.500 46.875 VESA 800 * 600 75.000
57.300 49.700 MACINTOSH 832 * 624 75.000
65.000 48.363 VESA 1024 * 768 60.004
75.000 56.476 VESA 1024 * 768 70.069
78.750 60.023 VESA 1024 * 768 75.029
3. AC Adaptor
3.1Setup the AC I/P at 90VAC, and Output DC loading
at 12V 1.6 Amp, 3V3 1Amp, The DC output voltages
are 3.3V +/- 0.16V DC, and 12VDC (+11V~16V)
4. Display Adjustment
4.1Auto color adjustment (B)
Apply a 640 * 480 / 60Hz signal with 16 level grey test
pattern, set brightness control at 100%, and contrast control
at 50%.
Adjust the R. G. B offset, and gain to calibrate the color
smoothly and 64-grey level distinguishable.
4.2 Color temperature adjustment (B)
Apply a 1024 * 768, 48.36kHz / 60Hz signal with white pattern.
Set brightness control at 100%, and contrast control at 50%.
Adjust the R.G. B gain in factory setting to reach special color
temperature on center of screen.
The 1931CIE chromaticity (X, Y) co-ordinates shall be:
Use Minolta CA-110 for color coordinates and luminance check.
Luminance is > 200 nits in the center of the screen at original
panel color.
9300°K 6500°K
x (center) 0.283 ±0.005 0.313±0.005
y (center) 0.297 ±0.005 0.329 ±0.005
4.3 Adjustment of sRGB
Apply a 1024*768 / 60Hz signal with white pattern, set
brightness control at 100%, and contrast control at 50%.
Adjust the R, G, B Sub-Gain, for the screen center, the
1931CIE chromaticity (X, Y) co-ordinates shall be:
sRGB
x(center) 0.313±0.005
y(center) 0.329 ±0.005
Ynits 180 ±10
4.4 EEPROM presetting (B)
After finishing all the adjustment, set:
Brightness control to 100%
Contrast control to 50%
OSD position at middle of screen
COLOR ADJUST to 6500°K
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

12150C5 LCD
Go to cover page
All units that are returned for service or repair must pass the
original manufactures safety tests. Safety testing requires both
and testing.Hipot Ground Continuity
HI-POT TEST INSTRUCTION
1.Application requirements
Test method
1.1All mains operated products must pass the Hi-Pot test as
described in this instruction.
1.2 This test must be performed again after the covers have
been refitted following the repair, inspection or modification
of the product.
2.1Connecting conditions
2.1.1The test specified must be applied between the parallel-
blade plug of the mainscord and all accessible metal
parts of the product.
2.1.2 Before carrying out the test, reliable conductive
connections must be ensured and thereafter be
maintained throughout the test period.
2.1.3 The mains switch(es) must be in the "ON"position.
2.2 Test Requirements
All products should be HiPot and Ground Continuity tested as
follows:
Test 2820VDC 1700VDC Test current:
voltage (2000VAC) (1200VAC) 25A,AC
Test time:
Test time 3 seconds 1second 3 seconds(min.)
(min.) Resistance
required:
Trip set at 100 uA 5 mA <=0.09+Rohm,
current for Max. R is the
(Tester) limitation;set resistance of
at 0.1uA for the mains cord.
Min. Limitation
Ramp set at 2
time seconds
(Tester)
2.
Condition HiPot Test for HiPot Test for Ground Continuity
products where products where Test requirement
the mains input the mains input is
range is Full 110V AC(USA
range(or 220V type)
AC)
2.2.1The minimum test duration for Quality Control Inspector
must be 1minute.
2.2.2 The test voltage must be maintained within the specified
voltage + 5%.
2.2.3 There must be no breakdown during the test.
2.2.4 The grounding blade or pin of mains plug must be
conducted with accessible metal parts.
3. Equipments and Connection
3.1. Equipments
For example :
- ChenHwa 9032 PROGRAMMABLE AUTO SAFETY
TESTER
- ChenHwa 510B Digital Grounding Continuity Tester
- ChenHwa 901(AC Hi-pot test), 902 (AC, DC Hi-pot test)
Withstanding Tester
3.2. Connection
4. Recording
Hipot and Ground Continuity testing records have to be kept
for a period of 10 years.
* Turn on the power switch of monitor before Hipot and
Ground Continuity testing.
Connect the "video cable"
or "grounding screw"
to the CLIP on your tester.
Video cable
(Rear view of monitor)
Connect the power cord
to the monitor.
Grounding screw
Power outlet
(ChenHwa 9032 tester)
Clip
Clip
Safety Test Requirement
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Mechanical Instructions
Go to cover page
150C5 LCD 13
Fig. 3
Front View
Back View
Step 1:
-Unscrew the four screws as shown in Fig. 3.
- Remove the base.
- Unscrew the three screws as shown in Fig. 4.
Fig. 2
Fig. 1
Step 2: Remove the front bezel
- Use thin "l" type screwdriver to open 2 clicks on bottom
side as shown in Fig. 5.
- Use thin "l" type screwdriver to open 3clicks on right
and left side as shown in Fig. 6.
- Use thin "l" type screwdriver to open 4 clicks on top
side as shown in Fig. 7.
Fig. 5
Fig. 6
Fig. 7
Fig. 4
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Mechanical Instructions
14150C5 LCD
Go to cover page
Fig. 8
Step 3: Remove the Back Cover shown as Fig. 9 & Fig. 10.
Fig. 9
Fig. 10
Step4:
- Unscrew on screw, remove the shield inverter as shown in
Fig.10.
- Unscrew seven screws as shown in Fig. 11.
- Unconnect 3cables as shown in Fig. 11.
Fig. 10
==============>
100
313815135901
SHIELD INVERTER
=========>
1051
313815860191
313815860201
SCALER ASSY
=========>
1053
313815860081
CONTROL ASSY
=========>
1052
313819872542
LIPS(ADP-23AF A)
1050 823827714731 TFT-LCD MOD LM150X08-A4
1050 93222113 5682 TFT-LCD CLAA150XP01(CPT0) B
LCD Panel
***************************************************************************
In warranty, it is not allowed to disassembly the LCD panel, even the
backlight unit defect.
Out of warranty, the replacment of backlight unit is a correct way
when the defect is cused by backlight (CCFL,Lamp).
***************************************************************************
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Front View
HUDSON 150C5 V002 20040511
Factory Mode
Indicator
---------->
Factory Menu
Cursor can move on gray color area
AGING...
After 15 seconds,
bring up:
After 15 seconds,
bring up: AGING...
After 15 seconds,
bring up:
----------
----------
repeatly
Connect Signal cable again=> go back to normal display
How to Access Aging Mode
Step 1: Turn off LCD monitor, and disconnect Interface Cable betwe-
en Monitor and PC.
Step 2 : [Push "AUTO"&"OK "buttons at the same time and hold it]
+[Press power ""button untill comes out "AGING screen"] =>
then release all buttons.
Bring up:
Go to cover page
150C5 LCD 15
Factory Mode & Aging Mode
How to enter Factory Mode
1. Turn off the monitor.
2. [Push "AUTO "&"OK"buttons at the same time and hold it
]+[Press power ""button until comes out "Windows screen"]
=> then release all button, then press , wait until the
OSD menu with Characters HUDSON 150C5 V002 20040511
(below OSD menu) come on the Screen of the monitor
(see Fig. 2).
"OK"button
BL : Black level value
SUB- BRI : Brightness value range( Min Max)
SUB- CON : Contrast value range( Min Mid Max )
SRGB- B : Brightness of sRGB
SRGB- C : Contrast of sRGB
Gain- m : Minimum value of User Gain
Gain- M : Maximum value of User Gain
AUTO- SUB : To do Auto color function when push Menu key in white
pattern
OSD TIMER: OSD time out control(sec)
IDX : Limit current of inverter (CPT: 28) (LG:7)
Panel TYPE :PLS reference section 2.9.6
SCALER : Read/Write scaler register
Panel : HS (Hannstar panel)
CPT (CPT panel)
LG (LG. Philips panel)
7
HUDSON 150C5 V200 20040705
HS 1.LG (7) 2. CPT (28) 3. HS (28) 4. QDI (28)
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Warning Message
16150C5 LCD
Go to cover page
Item Attention Signals Display Time Condition Active off
1
CANNOT DISPLAY
THIS VIDEO MODE,
CHANGE COMPUTER
DISPLAY
INPUT TO 1024 X 768
@60Hz
30 mins
This warning appears when the input signal from your computer
is not in a standard video mode or is out of the monitor's scanning
range. After 30 mins, monitor enters sleeping mode. No
2
NO VIDEO INPUT
30 mins
This message appears when there is no signal input but with cable
while AC to DC while power on. After 30 mins, monitor enters
sleeping mode.
Yes
show floating menu
"ATTENTION
SIGNAL OFF"
3
CHECK CABLE
CONNECTION 30 mins
This message appears when a signal cable is disconnected while
monitor is working. After 30 mins, monitor enters sleeping mode
Yes
show floating menu
"ATTENTION
SIGNAL OFF"
4ENTER SLEEP MODE 3 secs This message appears when monitor is about to enter power
saving mode. No
5
WAITING FOR
AUTOMATIC
ADJUSTMENT
Till auto adjustment
finished This message is displayed when the auto adjustment button is
pressed. It disappears when automatic adjustments are completed. No
6USE 1024 x 768 FOR
BEST RESULT
On top of OSD main
menu
The message will show up at the top of the OSD main menu in
red color when the input resolution is not the 1024 X 768. Yes
7
OSD MAIN CONTROLS
LOCKED 3 secs / or till "OSD
MAIN CONTROLS
UNLOCKED"appear
This message will appear 3 seconds to indicate the OSD MAIN
CONTROLS status when to lock or un-lock it by pressing
"MENU(OK)"button for more than 10 seconds while there is
video input from PC. This function provides the alternative that
user can lock all the OSD main control in case user don't want
the OSD performance setting to be changed, for instance, during
commercial exhibition.
No function when
push 10 secs (if OSD
lock then attention off,
not any message and
only attention on)
8
OSD MAIN CONTROLS
UNLOCKED 3 secs
This message will appear 3 seconds to indicate the OSD MAIN
CONTROLS status when to lock or un-lock it by pressing
"MENU(OK)"button for more than 10 seconds while there is video
input from PC.
No function when
push 10 secs.
9
ATTENTION SIGNAL
ON
3 secs This message will appear 3 seconds to indicate the attention
signals in ON or OFF status when to switch this function on or off
by pressing the AUTO button for more than 10 seconds while at
no video input from PC.
Yes
ATTENTION SIGNAL
OFF 3 secs
10
THIS IS 85 Hz
OVERSCAN, CHANGE
COMPUTER DISPLAY
INPUT TO
1024 X 768@60Hz
10 mins
This message will appear 5 seconds in every 60 seconds for 10
minutes when the input of PC video timing is at 85 Hz mode.
Remark: AUTO is still functional in this mode. No
Yes
Yes
TBD
11
12
13
The window of "OSD
MAIN CONTROLS"
The window of
"brightness"
"SELECTED INPUT NOT
AVAILABLE"
60 secs
60 secs
5 secs
This message will appear when the "OK"button is pressed.
This message will appear when the "BRIGHTNESS"button is
pressed.
When just on input(analog or digital), press"input switch"or
hot key, then after show this warning message 5 sec, return to
original input.
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Go to cover page
150C5 LCD 17
Repair Tips
0. Warning
All ICs and many other semi-conductors are susceptible to
electrostatic discharges (ESD). Careless handling during
repair can reduce life drastically. When repairing, make sure
that you are connected with the same potential as the mass
of the unit via a wrist wrap with resistance. Keep components
and tools also at the same potential !
1. Servicing of SMDs (Surface Mounted Devices)
1.1General cautions on handling and storage
- Oxidation on the terminals of SMDs results in poor soldering.
Do not handle SMDs with bare hands.
- Avoid using storage places that are sensitive to oxidation
such as places with sulphur or chlorine gas, direct sunlight,
high temperatures or a high degree of humidity. The
capacitance or resistance value of the SMDs may be
affected by this.
- Rough handling of circuit boards containing SMDs may
cause damage to the components as well as the circuit
boards. Circuit boards containing SMDs should never be
bent or flexed. Different circuit board materials expand and
contract at different rates when heated or cooled and the
components and/or solder connections may be damaged
due to the stress. Never rub or scrape chip components as
this may cause the value of the component to change.
Similarly, do not slide the circuit board across any surface.
1.2 Removal of SMDs
- Heat the solder (for 2-3 seconds) at each terminal of the
chip. By means of litz wire and a slight horizontal force,
small components can be removed with the soldering iron.
They can also be removed with a solder sucker (see Fig.
1A)
-While holding the SMD with a pair of tweezers, take it off
gently using the soldering iron's heat applied to each
terminal (see Fig. 1B).
- Remove the excess solder on the solder lands by means of
litz wire or a solder sucker (see Fig. 1C).
1.3 Caution on removal
-When handling the soldering.iron. use suitable pressure and
be careful.
-When removing the chip, do not use undue force with the
pair of tweezers.
-Thesolderingirontobeused(approx.30W) should
Fig. 1DISMOUNTING
SOLDERING
IRON
E.g. WELLER
SOLDER TIP PT-H7
VACUUM PISTON
4822 395 10159
SOLDER WICK
4822 32140042
E.g. A PAIR OFTWEEZERS
HEATING
SOLDERING
IRON
SOLDER WICK C
B
A
SOLDERING
IRON
HEATING
Fig. 2 MONUTING
E.g. A PAIR OFTWEEZERS
SOLDER
0.5-0.8 mm
PRESURE
SOLDERING
IRON
SOLDERING TIME
<3 sec/side
B
A
SOLDER
0.5-0.8 mm
PRESURE
SOLDERING
IRON
Fig. 3 Examples
RIGHT
SOLDERING
IRON
Preferably be equipped with a thermal control
(soldering temperature: 225 degree V to 250 degree C.
-The chip, once removed, must never be reused.
-Locate the SMD on the solder lands by means of tweezers
and solder the component on one side. Ensure that the
component is positioned correctly on the solder lands (see Fig. 2A)
-Next complete the soldering of the terminals of the component.
(See Fig. 2B)
1.4 Attachment of SMDs
2. Caution when attaching SMDs
-When soldering the SMDs terminals, do not touch them
directly with the soldering iron. The soldering should be
directly with the soldering iron. The soldering should be
done as quickly as possible, care must be taken to avoid
damage to the terminals of the SMDs themselves.
- Keep the SMD's body in contact with the printed board
when soldering.
- The soldering iron to be used (approx. 30W) should
preferably be equipped with a thermal control (soldering
temperature: 225 degree C to 250 degree C).
- Soldering should not be done outside the solder land.
- Soldering flux (of rosin) may be used, but should not
be acidic.
- After soldering, let the SMDs cool down gradually at room
temperature.
- The quantity of solder must be proportional to the size of
the solder land. If the quantity is too great, the SMD might
crack or the solder lands might be torn loose from the
printed board (See Fig. 3).
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

18150C5 LCD
Go to cover page
Repair Flow Chart
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Go to cover page
150C5 LCD 19
No Display
Check Mains cord
&LED of Monitor
Check
Power board
12V/3.3V DC
Yes
No
Check
video signals input
interface
Video source
Yes
No
No
OK
Check
Inverter panel
625~765Vrms with load
Check fluorescent
lamp
Check inverter
panel Check main panel
Front control key
does not work
Check
Front control panel
(Key &SW)
Check
Signal connectors
Yes
Yes
Check main panel
Repair Flow Chart-2
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

20 150C5 LCD
Go to cover page
Bad brightness
No
Check
Inverter panel output
625~765Vrms
Bad Inverter
panel
Yes
Check fluorescent
lamp
No
Check LCD panel
Bad image
Check
Video, fh/fv
signals
Yes
Check main panel Yes Check components
cold soldering
No
Check
all connectors &
LVDS cable
No
Check LCD panel
Repair Flow Chart-3
http://jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料
