Mooreco 91105 User manual

Assembly Instructions

123456789012345678901234567890121234567890123456789012345678901212345678901234

91105

Up-Rite Standing Mobile Workstation

P-1 Top Shelf 1 EA

P-2 Work Surface 1 EA

P-3 Bottom Shelf 1 EA

P-4 Keyboard Shelf 1 EA

P-5 Short Tube Support 2 EA

P-6 Long Tube Support 4 EA

P-7 Back Panel 1 EA

P-8 Slide Bracket 4 EA

P-9 Left Slide 1 EA

P-10 Right Slide 1 EA

APan Hd Screw #10x5/8 28 EA

A1 CS Wood Screw 56mm 4 EA

A2 Screw 1/4 X 50mm 6 EA

CCamLock 2 EA

DCam Post 2 EA

E Threaded Rod 6 EA

F2” Locking Plate Caster 2 EA

G2” Plate Caster 2 EA

H Screw M4X5mm 4 EA

KAllenWrench 1 EA

Part Drawing Description Qty Part Drawing Description Qty

Hardware List

Tools required: PhillipsHead Screwdriver

Illustration # 1

Illustration # 2

Assembly Diagram

To Assemble:

IdentifyandSeparate alltheParts andHardware.

P-1

Place two Cam Locks (C) into the large

predrilledholesinthe BackPanel(P7).

Makesurethearrows onthe Cam

Locks are pointed down to the

connectingholes inthe edge. Position

the Back Panel over the Cam Posts (D)

andturn theCam Locks a 1/4 turnto

lockin place.

Screwin twoThreaded Rods(E) intothe frontthreaded inserts inthe bottomof theTopShelf (P1)

Screwon twoShortTube Supports(P5) onthe longsection oftheThreaded Rods. Screw in two

CamPosts(D) intothe tworear threadedholes in the bottom oftheTopShelfas shownin

illustration#1.

Illustration # 3

Illustration # 4

Screwin fourThreaded Rods (E) into the threaded inserts inthe bottomof Work Surface (P2).

Screwon four LongTubeSupports(P6) ontothe longend oftheThreaded Rods (E) as shown

inillustration# 4.

Placethe WorkSurface (P2) ontop ofthe ShortTube Supports(P5) andconnect usingtwo

Screws(A2). Tighten ScrewsusingAllenWrench(F). Screw in two longCS Wood

Screws(A1) throughthe predrilled holes in the BackPanell (P7)and intothe holesin the

edgeof theWork Surface.

Illustration # 5

Placethe BottomShelf (P3) on the LongTubeSupports (P6), lineup holesand securewith

four Screws (A2). Attach the Bottom Shelf to the Back Panel (P7) using two CS Wood

Screws(A1). Attach two Locking PlateCasters (F) to theBottom Shelf asshown in

illustration#5 usingfour PanHD Screws(A). Attachtwo PlateCaster (G)to thebottom

of theBottom Shelfusing fourPan HDScrews (A)for eachas shown.

P6 P6

Illustration # 6

Attach two Slide Brackets (P8) to the Left Slide (P9) using two Screws (H) as shown in

illustration #6. Repeat this Step to attach two Side Brackets (P8) to the Right Slide (P10)

usingtwoScrews (H).

Illustration # 8

Screw the Keyboard Shelf assembly from Step #7 to the bottom side of the Work Surface (P2)

usingeight Screws (A)into thepredrilledmounting holesas shown inillustration #8.

Keyboard

Assembly

Illustration # 7

Attachthe Left Slide assembly(P9)to the Keyboard Shelf (P4) using two Srews(A)in the

bottompredrilled holes. Repeat thisStep toattachthe Right Slide assemblyas shown in

illustration#7.

LeftSlideAssembly

Right SlideAssembly

P10

91105

Up-Rite Standing Mobile Workstation

5 7/8”

40”

45 7/8”

35 5/8”

25 1/4”

3 1/4”

91105_08-25-15
