Morbella Geomate 500s User manual

Page 1
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
GPS Navigator
User Manual
R07
October 2013
Trademarks
All brand and product names are trademarks or registered trademarks of Maka GPS Technologies Group. In
association with Maka GPS Technologies Private Limited (Singapore), Maka GPS Technologies Sdn. Bhd.
(Malaysia) & Maka Technologies Group (H.K.) Limited.
The information in this manual is subject to change without notice.

Page 2
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Please read this manual before you start using this device
Thanks for purchasing our product. Please read this instruction manual carefully and completely before using the
product.
The information in this manual has been verified for its accuracy. But no liability will be applied for the correctness
of mapping data of navigation, technical and/or editorial interpretation or illustration, or the printing and translation
of this manual, nor liable for any consequence or incidental damages caused by using this manual.
This is a complicated technical product which consists of in-house OS and third party software. The manufacturer
has paid sufficient attention to fulfill its duty in its hardware manufacture processing and in development and/or
application of the software so as to ensure the device work properly. If there is any malfunction or defective of the
device, the manufacturer will provide a warranty for the congenital quality problem, but not covering for any loss
or damage of property, or any consequence caused by or related to using this device.
The navigation software and mapping data is provided by a third party. Its copyright is protected by laws. User can
only use on this device, any copying or application of the software for other purpose is not allowed. No explicit
and/or implicit guarantee or assurance will be applicable for the validity, integrity, correctness, accuracy of
mapping data for navigation used on this device, nor liability for any loss, damage, and/or any consequence
caused by or related to defective mapping data or software used on this device.
The copyright of this manual is owned by the company and protected by laws.Any copy or translation of whole or
part of its content, including words, figures, signs, phonetic index, etc., is only allowed for the individual
customer's reference, but not for public circulation, or other legal and/or commercial purpose. The company
reserves the right for final interpretation of this manual.

Page 3
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
General tips for GPS application
The following content are the instructions for GPS device application and operation. Please read this instruction
manual carefully and completely before using the product.
Each GPS device requires stable satellite signals for GPS positioning. Hence, it is important to acquired satellite
signals before the use of the GPS device. Kindly take note that the GPS device will not be able to receive any
signals in an enclosed area such as in a house, carparks surrounded by big buildings, or under overhead bridges.
Time taken to acquire GPS positioning will be extended during the case of driving. Please search the positioning
signal by stopping your car for a better and safer effect.
While charging the device, please only use the travel charger or car charger equipped by the manufacturer in its
original package. Other chargers may cause damage to this device, and this damage is not covered by our
warranty.

Page 4
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Features:
5.0inch LCD TFT display with touch screen for control and input
Professional portable navigation system, UI design for mobile application
Most popular Windows OS, World class CPU
MicroSD card (Not included in the package) of extensible capacity for mapping data, MP4 video, MP3
music, Photo, and Personal files
Built-in high sensitive GPS receiving module and antenna, Faster GPS signal receiving and more
accurate positioning
Prompt and accurate positioning applicable for GPS data collection, e.g.Area measuring
Prompt response for both cold and warm start; Re-capture of GPS signal just in 1 second on average,
Accuracy of positioning: no more than 10 meters;Accuracy of timing: no more than 1 microsecond
Embedded Organizer/Calendar: Personalized touch panel handwriting control, record and plan personal
schedule on the calendar
Multimedia Entertainment: Supports Flash playback, MP3 music, MP4 video, Photo Viewing
Scientific Calculation: Embedded Calculator
FM transmitter: Designed for use in a car with car stereo is not controlled with volume of the device.
Personalized Function Settings：Language Selection, Backlight Brightness Adjustment; Power
Management, Coordination Calibration.
Running multiples applications in the background: This feature allows other applications, like music,
e-Book, except for flash, to run in the background during navigation mode.
To activate programs during Navigation mode: During Navigation Mode, Simply press on the ON/OFF
button and activate preferred applications.
To return back to Navigation mode: Press Return button on the device then press on the Navigation
icon to switch back to GPS application.

Page 5
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Warnings:
Please install the device in a right (appropriate position) way to avoid driver's sight and airbag to be
hindered. Marbella GPS will not be liable or hold any responsibility if any property or loss caused by
mistakes of mounting or installing of the device.
Please not put on earphone and operate the device when you drive to ensure your safety.
Please consult with airline crew for application of the device if you want to use it during flight.
Please keep the device far away from strong magnetic field which may cause damage or malfunction to
the device.
Please refrain the device from being dropped, shocked or scratched on or by hard objects to avoid
possible damages (scratches on the device face, loose contact of the battery, data loss or other hardware
part broken) to the device.
Please not use earphone with a continuous and large volume for long time, set the volume at a moderate
loudness and use it not for a long time to avoid possible damage to your ear audibility.
Please not use chemical solution or cleaner to clean the device to avoid possible damage to the paint and
polish of its surface.
When the device is used as a mobile storage device, please follow right procedures of file management
operation to copy or transfer files. The warranty does not cover any mistake, or damage, or loss of files
Do keep a backup copy of your personal files in the device into your PC or laptop in time
It is prohibited to use higher voltage power supply, to bent or squeeze the power cord with big force so as
to avoid possible damage and overheat resulting in fire
Never use wet hands to pull out or plug in the power plug to avoid possible electric shock
Not use the device in an environment over 60℃, or below -10℃, and with high humidity as well
The content of this manual is subject to definition, or interpretation, or modification from time to time for
improvement on features and function without prior notice.

Page 6
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Illustrations on screen display:
System UI
In this interface, touch the screen or the small icon on the bottom to enter the specific function. To view next page,
click on the arrow on the right bottom. There will be an animation effect when turning the page.
Secondary UI
In this interface, click the displayed icons on the screen to enter the relevant functions. To view next page, click on
the arrow on the right.
Battery Status Icon:
Full=======================================>Drained
When the battery is at low power level, please charge it immediately to ensure the device work normally.
Charging:
Warnings for charging:
1. A new battery may be empty and not charged before you get the device.
2. In normal charging with AC charger (Not included in the package), please make sure to charge it for 2 –
2.5 hours to get it fully charged.

Page 7
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Note: A new battery will reach its best performance after number cycles of charging and discharging.
If the device is not used for long time, it is better to charge it to full capacity every 2 or 3 months during storage.
Charger Application:
AC Charger (Not included in the package):
Take out theAC charger, plug it into the wall outlet with AC 220V(100V~240V), then plug in the AC jack into the
deviceAC-in jack.(see the illustration below).
Car Lighter Charger:
Please insert the car charger into car cigarette lighter jack, then plug into the USB jack(see the illustration below).
Note: When you use car charger, please start car engine first, then connect it to the device to avoid possible
damage to the device due to overloaded pulse current during ignition. Please pull it out when you stop the engine,
and plug it in again after next ignition.
Power On/Off the device
In power off status, slide the power switch to "ON" position to turn on the device, then the OSD will be displayed
on screen.
Sleeping & Power –off
In power-on mode, press the power button on the device for 3-5 seconds then the sleeping mode or confirmation
for power-off screen will display as follows:
20
Theclevicewillbepoweroffin
s
In this UI click the button will be in sleeping mode
Click the button will power off
Click the button to exit the UI and back to normal operation.

Page 8
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Waking -up from the sleeping
When in sleeping mode, a short press on the power-on button of the device will wake up the system.
Note: When in sleeping mode, all the procedure in operation will pause but will back to normal status after waking
up.
FLASH Playback
On system main menu, click icon, to get into Flash playing mode, a list of file selections UI will be shown
on screen as shown below:
FLASH
Flashfile1.wmv
Flashfile2.wmv
Flashfile3.wmv
Flashfile4.wmv
On this UI, click button to search Flash files not in selected folder. Click button to close this window and exit
flash playback mode. Double click, or select then click button to open specific file.
2238/4875
Control buttons in playing mode:
:Play, During Pause or Stop mode, press this button to play;
:Pause, During Play mode, pressing this button to pause;
:Stop, During Play mode, pressing this button to stop;
:Fast Forward, During Play mode, pressing this button to get fast forward once;
:Fast Rewind, During Play mode, pressing this button to fast retreat once;
:Full Screen, pressing this button for full screen play;

Page 9
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
:Return, pressing this button to return back to system main menu from playing mode;
:Sound Settings, Click the button to mute or unmute sound /
Note: In full screen, tool bar will be hidden at screen bottom, you may retrieve it back by tapping on the screen.
Video Playback
This following are the supported video formats:AVI, MPEG, MPG, ASX, DAT,ASF and WMV.
On system main menu, click icon to enter into Video Playback mode, a list of file selections UI will be
shown on screen as shown below:
videofile1.wmv
videofile2.wmv
videofile3.wmv
videofile4.wmv
Video
On this UI, click button to search video files not in selected folder. Click button to close and exit from Video
Playback application. Double click or select and click button to open specific file.
UI and button definition:
Play Next
Pause Previous
Stop Full screen display
Close
Play Progression, drag to a point to start play
Volume tune, click anterior to set into mute status, click it again to resume

Page 10
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
In full screen display, the tool bar at screen bottom will be hidden, you can slightly tap on screen to get it. It will
take a few minutes to search fies when video play mode starts if this application has not been used for a long
time.
RMVB Player
The Amazing Marbella Geomate Series also supported formats: RM and RMVB files.
In the system UI, click the icon to entry the function of Media player, a list of file selections UI will be
shown on screen as shown below:
Video_01rm.
Video_02rm
Video_03rm
Video_04rmvb
.
.
.
RMVBPlayer
On this UI, click button to search video files not in selected folder. Click to exit the rmvb player. Double
click or select and click button to open specific file.
16:9
UI and button definition:
Play Next
Pause Previous
Stop Full screen display
Close
16:9
:Full screen Display (Stretch to the whole screen)
Play Progression, drag to a point to start play
Volume tune, click anterior to set into mute status, click it again to resume

Page 11
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Music Playback
This following are the supported formats:MP3, WMA, WAV.
On system main menu, click icon to play music. Screen display is shown as the illustration below:
Music
music01
music02
music03
music04
music05
On this UI, click button to search music files not in selected folder. Click to exit the music play mode.
Double click or click button to open specific file.
The music play mode is as shown below as illustration:
Button and control in Play Mode:
Play Next Track Mute or unmute sound
Pause Previous Track Exit
Stop Repeat mode

Page 12
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Bluetooth Function
The Bluetooth function is used for communication purpose.After the device is connected to a mobile phone with
Bluetooth capability, you can operate the mobile phone functions on this system. You may dial, receive a call, or
view the call record of the mobile phone or perform other functions.
Click the Bluetooth icon on the main interface and enter the following interface. Click on Enable button to
start using of the Bluetooth function in the interface shown below.
Connecting Mobile Phone
After enabling the Bluetooth feature, the Pair icon will be made available.

Page 13
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Click on Pair button to starting pairing with your mobile phone and enter the following interface. Follow
by clicking on the Magnifying glass icon to search for discoverable Bluetooth devices.
Once you have identified your Bluetooth device on the list, click on Pair Mobile icon and enter the
identification code on your mobile phone to get both devices connected.
To connect the mobile phone, you need to enter this PIN Code on the mobile phone before the connection
is established. You may set the password according to your own preference. By default the password is
8888.And click on Pair icon on your mobile phone.
Once it is successfully connected, click on Exit to return to the previous menu
Dial Keypad
On the Bluetooth function interface, click the Dial icon to enter the Dial Keypad:
Click the number keypad to enter the telephone number to be dialed
Click the Dial button at the right lower corner to dial the number.
Click the Back button to return to previous interface
1st Step
2nd Step

Page 14
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Photo Display
This is for Photo Display with format JPG can be stored into a MicroSD card (Not included in the standard
package) or internal ROM. On system main menu, click picture icon to enter into Photo Display function.
Screen display is shown as the illustration below:
image01jpg
bmp
gif
.
.
.
On this UI, click button to search photo files not listed in the appointed photo file folder. Click button to close
current UI and exit Photo Display function. Double click or select then click button to open or play this file.
Display shown as the right illustration:
Click or button to select previous or next photos
Click or button to zoom in or zoom out photo
Click button for full screen display. In full screen display, tap the screen again to exit full screen display
Click button to select display of different percentage.
Click the button to rotate picture
Exit Photo Display
Click the button on upper right corner to exit.

Page 15
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Schedule Organizer
This is toAdd, Edit, Delete, and Display the schedule in week, month, enable the user to find the scheduled
agenda conveniently. Click the tools icon in the main page, next click on the Schedule icon to
enter the following interface shown below:
The above screen shown is display in month display mode.
Click the specific date to enter into day display mode
Click ‘Week” to enter into week display mode.
Search by Date
Select and click a date on the screen to enter into Date display mode.
Screen display is shown as in the illustration below:
12-27-2006
Click to see
the previous day Click to see
the next day
Click time tag on date screen to check and revise a stored schedule or agenda.
If the time tag is blank, then click it to set up a new schedule or agenda.

Page 16
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Search by Week
Click “Week” button to enter into week display mode. Screen display is shown as in the illustration below:
Sun Mon Tue Wed Thu Fri Sat
Dec
Click to see the
previous week Click to see
the next week
As shown in the illustration above, there will be an icon if an agenda is set on the date and timing.
Click on screen to check or edit this agenda
Click the corresponding spot of date and time on which you want to add a new agenda to set it.
Create New Schedule
In mode of Search by Month, click “Add”, or click timing tag under mode of Search by Date, or click dating and
timing tag under mode of Search by Week to enter into Create New Schedule UI, screen display is shown as in
the illustration below:
Topic:
Date:
to
Place:
Import:
Type:
Click on the input field on the screen, and a soft keyboard appears as follows:
As shown in the picture above, you can choose the input method from the last button at the bottom.
Click "Handwrite" to change to the handwriting input state

Page 17
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Click "Hide" to close the small keyboard.
The handwriting input state is shown as follows:
As shown in the picture, the middle empty area is the handwriting area.
Click the button on the right side to change the input method
Click "Hide" to close the handwriting input panel
Click "keyboard" to return to keyboard input state.
Input “Subject, Place, Content” you want to set; “Date, Time” can be input directly, or use adjustment
buttons to set; “Priority, Type” can be selected in drag menu underneath them respectively.
Click “Save” to save the revised schedule, then return back to mode of Search by Month.
Delete Schedule
In mode of Search by Month, click “Delete” button at bottom of the screen to enter into delete mode, all schedule
saved in the system will be listed out, screen display is shown as in the illustration below:
Click drag menu after “Time, All” to choose other list
Select an agenda to be deleted
Click button, a dialogue block will pop up
Select “OK” to delete this agenda.
Click button at upper right corner to exit Delete mode
Exit mode of Schedule Organizer
In mode of Search by Month, click “ ” button at upper right corner of the screen to return to main menu of
system.

Page 18
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
FM Transmitter
This feature is designed for transmitting the sound of this device via a set frequency to your car FM radio receiver.
It allows sound to be transmitted to the car audio system. The volume will be determine by the car audio system
set by user.
In the system UI, click on the FM icon to activate FM transmission. It will be illustrated like below:
FM
87.8MHz
OpenChannel
CloseChannel
OpeningFMwithoutloudspeaker
Select Open Channel (Transmission On) or Close Channel (Transmission Off)
Select Open Channel, you may also select device speaker on or off. It is suggested to off the device
speaker when Open Channel is selected
Press or button, or directly drag the slide bar to set FM transmission frequency
Turn on car radio FM receiver and tune it to the same frequency as the transmission.
Please do not set a radio frequency used by a local radio station. The recommended FM frequency is
92.0MHz.
Status Display:
When FM transmission is on, you may see an icon on the main menu screen:
FM transmission is ON, the device speaker is OFF
FM transmission is ON, the device speaker is ON
FM transmission is OFF, the device speaker is ON
Note: Click the above icons directly in the main menu to enter into FM transmission mode directly.

Page 19
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Calculator
This device has two calculators: Ordinary and Scientific calculator, able to be switched at any time, a good
assistant for your work and study.
In the system UI, click the Tool icon on the main menu and click on the calculator icon .As shown
in the below illustration, the calculators can be used like normal others.
789
456
123
0AC
1/X
-
=
Click “Scientific/Ordinary” on the right to switch between Scientific Calculator and Ordinary Calculator
The unit of calculation of the right can be taken according to actual demand.
Exit Calculator Mode
In Calculator mode, click button at the upper right corner of the screen to exit and return to system main menu.
Notepad Function
With the Notepad function, you can record some instantaneous simple information as memo. It is a highly
practical function.
In the system UI, click the Tool icon on the main menu, then find the icon and click on the Notepad
icon . As shown in the diagram below, the panel on the left shows the list of saved notes. Click on the
preferred note title to display the full content on the right panel.
Title Content
Title001_Content_001

Page 20
© 2012 Maka Technologies Group. All Rights Reserved.
2 Alexandra Road #02-03
Delta House
Singapore 159919
Tel:[phone] Fax: [phone]
Visit our website at: www.makagps.com
Creating a Note
At Notepad function, click the button to enter the state of adding notes as shown in the diagram below.
The screen shows the soft keyboard when it is in input state. As shown in the picture, you can choose the input
method from the last button at the bottom.
Click "Handwrite" to change to the handwriting input state
Click "Hide" to close the small keyboard.
The handwriting input state is shown as follows:
As shown in the picture, the middle empty area is the handwriting area.
Click the button on the right side to change the input method
Click "Hide" to close the handwriting input panel
Click "keyboard" to return to keyboard input state
Enter the content to be saved, hide the soft keypad
Click the button in the lower part of the screen to save the entered content and return to the main
interface of the Notepad function.
Edit/modify Notes Saved
At Notepad function, select the note to be modified
Click the button in the lower part of the screen to enter the note editing state. The screen display and
operation are all the same as “Creating a Note”.
After the modification, click the button to save it, and return to previous interface of the Notepad
function.
Deleting a Note
At Notepad function, select the note to be deleted
Click the button in the lower part of the screen.
