Morgan PLUS FOUR User guide

MORGAN MOTOR COMPANY
MORGAN PLUS FOUR
OWNER’S HANDBOOK

The content contained within this handbook is correct at the time of publication,
however due to the nature of Morgan motor vehicle production, some details may be subject to change.
Version 1.0, March 2020 - 21MY
© Morgan Motor Company 2020
WARNING
It is recommended that children are not transported in the vehicle.
Advanced driver training may be required to drive this vehicle.
SWARNUNG
Es wird empfohlen, dass Kinder nicht im Fahrzeug befördert werden.
Möglicherweise ist eine fortgeschrittene Fahrerschulung erforderlich, um dieses Fahrzeug zu fahren.
ATTENTION
Il est recommandé de ne pas transporter les enfants dans le véhicule.
Une formation de conducteur avancée peut être nécessaire pour conduire ce véhicule.
AVVERTIMENTO
Si raccomanda che i bambini non vengano trasportati nel veicolo.
Per guidare questo veicolo potrebbe essere necessario un addestramento avanzato del conducente.
ADVERTENCIA
Se recomienda que los niños no sean transportados en el vehículo.
El entrenamiento avanzado del conductor puede ser requerido para conducir este vehículo.
警告
建议儿童不要在车内运输。
驾驶该车辆可能需要高级驾驶员培训。
تحذير
يوصى بعدم نقل الأطفال في السيارة.
قد تكون هناك حاجة لتدريب السائق المتقدم لقيادة هذه
السيارة.

1
CONTENTS
Welcome...............................................................2
Vehicle Identification......................................3
Technical Information ...................................4
Safety Information........................................... 7
Locks, Keys and Security.............................9
Seating and Safety Restraints .................. 9
Instruments and Switches..........................12
Driver Information Panel............................ 16
Control Stalks..................................................... 21
Lights, Indicators and Wipers.................. 22
Transmission Modes......................................24
Gear Modes.........................................................27
Under Dashboard Functions................... 28
Foot Operated Controls............................29
Hand Operated Controls ..........................30
Heating Ventilation and AC......................31
Starting Procedure.......................................... 31
Hood Operation..............................................32
Fuel Filling..............................................................37
Bonnets...................................................................38
Tyres......................................................................... 39
Fuse box.................................................................42
Battery.....................................................................42
Maintenance ........................................................46
Cleaning.................................................................. 50
Warranty...............................................................52
Service History .................................................. 57

2
WELCOME TO THE WORLD OF MORGAN
Your car is as individual as you are, and employs traditional coach-building
techniques, using only the highest quality materials – leather, aluminium and
seasoned ash. Each Morgan is built to an individual specification. Morgan uses
the latest drive-train technology, using a lightweight, powerful engine that meets
current standards in emissions and fuel economy.
MORGAN PLUS FOUR
This handbook has been produced in order to give the owner a good
understanding of how best to use and enjoy their Morgan Plus Four. The owner/
driver should read and understand the content of this handbook before using the
car, and the handbook should then be kept in the car for reference at any time.
It should be passed on to new owners if the car changes hands.
To get the full enjoyment of driving this vehicle, it is recommended that the
owner undergoes advanced driver training. Contained within the handbook are
important safety warnings and instructions. These warnings are to prevent any
risk of injury being caused to you or others. This book is intended to give an
understanding of the operating procedures and general servicing instructions as
well as technical information. It is not intended to give comprehensive technical
details and full servicing procedures.
To ensure maximum pleasure and performance, it is important to keep your
Morgan well maintained and serviced at the correct intervals. It is the responsibility
of the owner to ensure the vehicle is serviced at the correct periods. If any
adjustment is required we request that you contact a Morgan dealer for advice
before any work is carried out. Alterations from the standard specification are
not recommended as this may affect the performance and safety of the vehicle
and invalidate the warranty.

3
Supplying Dealer Information:
VEHICLE IDENTIFICATION
Morgan advises that the Vehicle Identification Number (VIN) is recorded in this
section along with other records that may be useful when requesting or ordering
replacement parts.
The VIN (Vehicle Identification Number) plate is positioned under the left
bonnet on the inner panel ahead of the A-Post. The VIN Number is stamped
into the chassis behind the right hand seat under the carpet.
VIN: ...........................................................................................................
Registration: ..........................................................................................
Body Colour: .........................................................................................
Trim Colour:..........................................................................................
Hood Colour: ......................................................................................
Paint Colour Code: ..........................................................................
Warranty Start Date: ......................................................................

4
MORGAN PLUS FOUR TECHNICAL INFORMATION
Engine Information
Engine..........................................................BMW 2.0L (1998.3cc) in-line four cylinder
direct injection with twin scroll turbo.
Cylinders ..................................................4
Capacity ..................................................1998.3cc.
Bore (mm) ..............................................82
Stroke (mm) ..........................................94.6
Compression Ratio ............................10:2:1
Firing Order ...........................................1-3-4-2
Power Net (kW) ................................190 kW at 6000rpm
Torque Nm ............................................Manual: 350 Nm
Automatic: 400 Nm
Valve Operation ..................................2 overhead camshafts, chain driven
Valve Timing ...........................................Variable valve timing system
Fuel System
Type ............................................................Electronic fuel injection
Fuel Pressure kPa (psi)......................600 BAR 35000 kPa
Fuel Type .................................................98 or 95 RON unleaded petrol
Ethanol Rating ........................................E10
Ignition System
Type ............................................................Digital electronic
Operation.................................................ECU controlled, direct coil
Spark Plug ................................................NGK/Champion R5/R6 Gap 0.75mm
Cooling System
Type ............................................................Engine driven water pump, electronically
controlled water management module, radiator,
twin electric cooling fans.
Normal Operating Temp. ..............85 – 115°C
Air Conditioning System
Refrigerant................................................R1234yf - 650g
Oil..................................................................Denso ND-12
Capacities
Fuel Tank (approx.) ...........................43 litres (10 US Gall.)
Windscreen washer bottle ...........2.5 litres (0.7 US Gall.)
Engine oil with new filter ...............5.25 litres (1.4 US Gall.)
Rear Differential ..................................1.7 litres (0.5 US Gall.)
Oil and Fluid Specifications
Engine .......................................................5W-30
Gearbox Oil - Manual......................MTF-LT-5
Gearbox Oil - Automatic...............Shell L12108
Rear Differential Oil .........................G1 HYPOID Axle Oil G3 synthetic oil
of the highest grade.
Engine Coolant Type .......................BMW HT-12 Mix ratio 50%for coolant
down to -38oC.
Brake Fluid .............................................DOT 4
Transmission - Manual
Gear Box ................................................6-speed manual transmission with
Comfort and Sport+ engine modes.
Differential .............................................Ratio 2.81:1
Transmission - Automatic
Gear Box ................................................8-speed automatic transmission with
Comfort, Sport and Sport+ shift modes.
Differential .............................................Ratio 2.81:1
Gear Ratios - Automatic
Gear ...........................................................Ratio
1st ..................................................................5.25
2nd .................................................................3.36
3rd..................................................................2.172
4th ..................................................................1.72
5th ..................................................................1.316
6th ..................................................................1
7th ..................................................................0.822
8th ..................................................................0.64
Gear Ratios - Manual
Gear ...........................................................Ratio
1st ..................................................................3.683
2nd .................................................................2.062
3rd..................................................................1.313
4th ..................................................................1
5th ..................................................................0.809
6th ..................................................................0.677

5
Track Rear ................................................................................................1492mm (58.74 in)
Ground Clearance Front Axle ......................................................125mm (4.92 in)
Ground Clearance Rear Axle........................................................135mm (5.31 in)
Turning Circle ........................................................................................4.29m (14 ft)
Overall
Length .........................................................................................................3830mm (150.79in)
Width (Base Wheels).........................................................................1650mm (64.96 in)
Width (Option Wheels)...................................................................1665mm (65.55 in)
Height .........................................................................................................1235mm (48.62 in)
Technical Information
Vehicle in Running Order (Including Fuel) - Auto ..........1115kg
Vehicle in Running Order (Including Fuel) - Manual .....1119kg
Maximum permissible mass...........................................................1300kg
Maximum weight per axle (Front) ...........................................624kg
Maximum weight per axle (Rear) ............................................676kg
This vehicle is not designed for towing.
Fuel Consumption and Carbon Dioxide Emissions**
MANUAL:
Low CO2..............................243.5 g/km
Medium CO2....................162.3 g/km
High CO2............................139.2 g/km
Extra High CO2................159.5 g/km
Combined CO2................165 g/km
Low ......................................26.3 mpg
10.7 l/100km
Medium ..............................39.5 mpg
7.2 l/100km
High ......................................46.0 mpg
6.1 l/100km
Extra High............................40.1 mpg
7.0 l/100km
Combined............................38.8 mpg
7.3 l/100km
*Not all options may be available to purchase from Morgan Motor Company at launch.
**All figures quoted are WLTP declared values.
Suspension
Front ...................................................................Double wishbone with anti-roll bar
Rear ...................................................................Double wishbone
Caster Front ..................................................5°30’
Caster Rear ....................................................N/A
Camber Front .............................................-0° 30’ +/- 15’
Camber Rear .................................................-0° 45’ +/- 15’
Toe In Front ...................................................+0.50mm +/- 0.25mm
Toe In Rear ....................................................+1mm +/- 0.25mm
Brakes
Front ..........................................................Floating single piston aluminium caliper, 294mm
(diameter) x 24mm (thickness) ventilated disc.
Rear.............................................................1-piston aluminium caliper, 288mm (diameter)
x 20mm (thickness) ventilated disc with integral
self-adjusting handbrake.
Handbrake .............................................Cable operated, self-adjusting.
Operation ..............................................Hydraulic with vacuum servo assistance,
ABS standard.
Operating Fluid.....................................DOT 4
Wheels and Tyres*
Wheels Standard.................................15x6.5 (Alloy)
Wheels Option 1................................15x6.5 (Wire)
Wheels Option 2................................16x7 (Wire)
Tyres Front Standard........................Cooper Avon ZV7 205/60 R15 91V
Tyres Rear Standard..........................Cooper Avon ZV7 205/60 R15 91V
Tyres Front Option 1.......................Yokohama BluEarth AE50 205/60 R15 91V
Tyres Rear Option 1.........................Yokohama BluEarth AE50 205/60 R15 91V
Tyres Front Option 2.......................Yokohama BluEarth ES32 205/55 R16 91V(W)
Tyres Rear Option 2.........................Yokohama BluEarth ES32 205/55 R16 91V(W)
Tyre Pressures .....................................28psi/193 kPa
Wheels/Torque Setting....................15” Wire or 16” Wire or 15” Alloy/80lb/ft(110Nm)
Chassis
Wheelbase (fully loaded) ................................................................2520mm (99.21 in)
Track Front ..............................................................................................1492mm (58.74 in)
AUTOMATIC:
Low CO2..............................240.1 g/km
Medium CO2....................146.6 g/km
High CO2............................130.6 g/km
Extra High CO2................160.4 g/km
Combined CO2................159 g/km
Low ......................................26.7 mpg
10.6 l/100km
Medium ..............................43.7 mpg
6.5 l/100km
High ......................................49.0 mpg
5.8 l/100km
Extra High............................39.9 mpg
7.1 l/100km
Combined............................40.2 mpg
7.0 l/100km

6

7
SAFETY INFORMATION
Throughout this handbook there are important SAFETY WARNINGS as
well as safety warning labels located on the Morgan Plus Four. These safety
warnings are there to help you make informed decisions and reduce the risk of
accidents causing possible injury or death to yourself or others. There are also
CAUTIONS and NOTICES to assist you in making decisions to avoid damage to
your Morgan Plus Four or other property.
SAFE USE OF THE MORGAN PLUS FOUR
Your safety and enjoyment of your high performance sports car is Morgan’s
priority, therefore it is highly recommended that you take time to familiarise
yourself with the safe operation of your Morgan vehicle before driving it.
MISUSE OF THE MORGAN PLUS FOUR
Your Morgan Plus Four is intended to be used in a safe manner, always obey
the local laws and speed limits, never travelling faster than is appropriate for
the road, weather and traffic conditions. Accidents may cause injury or death to
both the occupants of the vehicle and/or other persons. Remember that using
sensible judgement when driving this high performance vehicle may prevent an
accident from occurring.
RESPONSIBILITIES OF THE OWNER
As the owner of this vehicle, you are responsible for the safe and proper
operation of this vehicle. This is a high performance vehicle and safe use is
dependent upon the practice of safe driving technique as well as the expertise
of the driver.
It is highly recommended that every owner should:
• Obtain instructions from a competent source on all aspects of the
operation of this high performance vehicle.
• Understand that this vehicle is not fitted with airbags or electronic stability
control systems. An Anti-Lock Braking System (ABS) is fitted to this vehicle.
• Observe the warnings and maintenance requirements contained within this
Owner’s Manual.
• Obtain qualified training in safe and proper driving techniques, applicable
to high performance vehicles.
• Know your own limits and skill level. Driving safely within your own limits
may help you to avoid an accident.
• Take particular care when driving on wet or slippery surfaces.
IMPORTANT SAFETY WARNINGS
• Always ensure that the car is in a roadworthy condition. It is the
responsibility of the driver to ensure that the vehicle is in a proper
and roadworthy condition.
• The driver and passenger must be seated correctly and should ensure that
all safety restraints are used properly and are free from obstructions.
• Check that the tyres are in good condition with no excessive wear or damage.

8
• Ensure all windows and mirrors are clear and positioned correctly
before driving.
• Ensure that all doors, bonnets and hoods (when fitted) are
fastened/shut correctly.
• Check all lights and signalling devices are operating correctly before use.
Always Wear a Seat Belt
Wearing a seat belt will dramatically reduce the risk of injury or death in the
event of an accident. Always ensure that the driver and any passengers
travelling in the vehicle always wear a seat belt.
Morgan Motor Company recommend that young children are not
carried in a Morgan Plus Four.
Harmful Substances
Some components used in the manufacture of cars contain or emit
chemicals known to increase the risk of cancer and birth defects as
well as increasing the risk of reproductive harm.
Exhaust gases contain carbon monoxide (CO). This gas cannot be seen, has
no odour and exposure to the gas can cause unconsciousness or death. If
it is suspected that exhaust gases are entering the cockpit of the car do not
drive the car until a Morgan engineer has rectified the fault. Never park in a
confined space with the engine running without adequate ventilation.
Engine System
If the engine malfunctions in any way, ECU warnings show on the LCD
screen. Morgan recommends that the fault is diagnosed and repaired by
a Morgan engineer before using the vehicle. Failure to react appropriately
to any engine management faults may result in permanent damage to the
engine. Continuing to drive the car with an engine misfire could cause the
catalytic converter to overheat, with possible heat damage to other car
components, and an engine bay fire.
DO NOT park or drive the car in areas where combustible material, such
as dry grass or leaves, could come into contact with the hot exhaust
system as this may ignite fires.
DO NOT tamper with the electrical system whilst the battery is connected.
DO NOT enter the engine bay when the engine is running.
DO NOT use the car if a fuel leak is suspected. Ensure that a Morgan
engineer or service agent repairs the fault before starting or using the
vehicle. Leaking fuel may cause fires or explosions.
DO NOT touch or approach any part of a hot exhaust system. Failure to
comply with this may result in injury.
It is recommended that any work to be performed on a Morgan Plus Four should
be undertaken by a qualified engineer or Morgan service agent.
Electrical Equipment
Morgan does not recommend installing any non-approved electronic
systems that emit radio frequencies. Such items include electronic
garage door activation and similar devices.

9
SEATING AND
SAFETY
RESTRAINTS
Seats
The seats in the Morgan
Plus Four are adjustable
both fore/aft, rake angle and
lumbar support and should
be adjusted to suit. To adjust
the fore/aft position of the
seats, raise the lever located
under the front of the seat.
This will allow the seat to
slide fore/aft. Once in the
desired position release the
lever and the seat will be
engaged in position. It is important to check that the seat is engaged fully in
position by attempting to slide the seat fore/aft without touching the lever.
VEHICLE SECURITY - KEYS
The Morgan Plus Four may be supplied with two keys for the vehicle ignition system,
and a Remote Central Locking fob. Contained within the ignition key is a chip used
to disarm the engine immobilisation system. The Morgan Plus Four can only be
started with a key containing the correct chip corresponding to the correct vehicle.
WARNING While the car is fitted with an immobiliser, there is no alarm
system supplied on the Morgan Plus Four. Do not leave the car unattended
with the keys in the ignition.
Remote Central Locking (RCL)
The Morgan Plus Four may be provided
with 2 RCL fobs that can be activated
by pressing either of the buttons on the
RCL fob. To lock the doors press the
lower button on the fob marked with a
lock icon for approximately 1 second. To
unlock the doors press the top button on
the fob marked with an unlock icon for
approximately 1 second. When unlocking
the car with the key fob the lights will
come on for 10 seconds. The range from
WARNING Never lock the vehicle when a person or animal is inside
the vehicle. Never leave the vehicle unattended and unlocked.
WARNING Do not force the lock mechanism. If the key does not go into
the lock or the lock will not operate, lubricate with light grade oil. If the
problem persists, consult a Morgan engineer.
Engine Immobiliser
The Morgan Plus Four is fitted with an engine immobiliser. This means that the
engine can only be started using the correct keys programmed to the vehicle.
which the fob will operate the locks will vary depending on environmental
conditions and the RCL fob battery condition. Replacement fob batteries can be
obtained from your nearest Morgan service agent.
Door Locks - Manual Operation
Manual locking operation using the ignition key is only required if there is an RCL
fault. There is no manual door lock on the passenger side. To unlock the driver’s
door from outside the vehicle, insert the ignition key into the lock and rotate anti-
clockwise until the stop is reached, then remove the key. The door is now unlocked.
RCL Fob Ignition Key
RAKE
RAKE
FORE/AFT
FORE/AFT
DEFLATE
INFLATE

10
To adjust the rake angle of the seat, sit in the seat and operate the lever to the side
of the seat base. Any attempt to engage the rake angle lever without sitting in the
seat could result in injury.
Back support (lumbar) can be adjusted to provide different pressure, depending
on the level of firmness required. To increase firmness, squeeze the rubber hand
pump. Press the valve button below the hand bulb to decrease pressure.
WARNING Do not adjust the seat position whilst the vehicle engine
is running.
WARNING Ensure that no objects can be trapped when the seats are
moved/adjusted.
Seat Belts
Seat belts should be worn at all times when in the vehicle. It is a proven fact that
wearing seat belts reduces the risk of injury or death in the event of an accident,
wearing a seatbelt incorrectly increases the chances of serious injury or death in
the event of a crash. When the ignition is turned on there will be a warning light
and once the vehicle reaches 5mph an audible warning reminding the occupants
to fasten their seat belts.
The seat belt units fitted to the Morgan Plus Four are inertia reel seat belts. The
seat belts may lock automatically when the vehicle is subjected to extreme braking,
acceleration, cornering and impact forces. The seat belt unit may also lock if the
vehicle is tilted in any way.
Local rules and restrictions associated with seat belts may apply. It is the
driver’s responsibility to ensure both the driver and passenger adhere to
local laws. When fastening the seat belt sit in the seat erect and fully back.
Hold the buckle tongue and draw the belt diagonally across the body and fasten
into the buckle lock. Ensure the buckle is secured and correctly engaged; this will
be apparent by a click sound when fastening the buckle tongue into the buckle
lock. Ensure that the belt sits across the front of the pelvis and across the chest
and shoulder.
To release the belt push the red button on the buckle. The belt will
automatically retract.
WARNING Driver and passenger seat belts should always be worn
properly. Wearing a seat belt incorrectly increases the chance of serious
injury or death in a crash.
WARNING When the vehicle is in motion above 5mph and weight
is detected in the passenger seat, the vehicle will emit an audible warning
unless the seat belt is fastened.
WARNING When fastening the seat belt, ensure that the belt is not
twisted or entangled in the door or seat mechanism.
WARNING Seat belts are designed to bear upon the bone structure of
the body and should be worn low across the front of the pelvis, chest and
shoulder. Wearing the lap section of the belt across the abdominal area
must be avoided.
WARNING Improperly positioning the seat belts can cause serious injury or
death in a crash. Ensure the seat belts are correctly positioned before driving.
WARNING Seat belts should be worn by all persons regardless of the
physical condition of the person. For example, pregnant women should
always wear a seat belt.
WARNING The shoulder portion of the seat belt must never be worn
beneath the arm or behind the back.

11
WARNING Each seat belt assembly is designed for use by one occupant of
adult build, and it is not recommended that they are used by children.
WARNING A child seat must never be used in the seats of a Morgan Plus Four.
WARNING Never use one seat belt around two people, or allow a child
to be carried on a driver or passenger’s lap.
WARNING No modifications or additions should be made to the
seat belt assemblies.
WARNING The seat belt should be replaced if components are frayed,
contaminated or damaged. Inspect regularly.
WARNING The seat belt system must be replaced if the vehicle has been
involved in a severe impact, even if no damage to the assembly is visible.
Seat belt anchorage points must also be checked.
WARNING Not checking or maintaining seat belts can result in serious
injury or death if the seat belts do not work properly when needed.
Check the seat belts regularly and ensure that any problems are
corrected immediately.
WARNING Seat belts should be adjusted as firmly as possible, consistent
with comfort, to provide the protection for which they have been designed.
A slack seat belt will greatly reduce the protection afforded to the wearer.
WARNING Seat belts should not be worn with the straps twisted.
CAUTION When cleaning the seat belt assembly, care should be taken to
avoid contamination or damage to the system.
CAUTION Do not use any substance that may contaminate or damage
the webbing material. Never use bleach or dye, only clean with a mild
detergent and ensure the system is completely dry before using the
vehicle. Ensure the entire system is kept free of dirt contamination.
WARNING Do not disassemble the system for cleaning purposes.
AIR BAGS
CAUTION Morgan Plus Four is NOT FITTED with driver and passenger
air bag systems.
INFANT PASSENGERS
WARNING Morgan Motor Company recommends that children who
require additional safety restraints are not transported in a Morgan Plus Four.
Only carry people in a Morgan Plus Four who are able to use the seat belts as
intended without any modification or seating aid. Child booster seats are not
recommended for use in a Morgan Plus Four.

12
93
12
6
20
30
40
50
60
70
80 90 100 110
120
130
140
150
160
170
0
MPH
10
0Miles
VDO
180
x100
RPM
0
10
20
30
40 50
60
70
1
4 6 7 9 11 12
5 8 10 13
2 3
INSTRUMENTS AND SWITCHES
Central Dashboard - RHD
1. Speedometer
2. Analogue Clock
3. Tachometer
4. Odometer & Trip meter
5. Trip Reset Button
6. Heater Fan Control
7. Footwell Vent
8. Air Conditioning
9. Ignition/Engine Start
10. Hazard Warning
11. Heated Windscreen
12. Temperature Control
13. Rev Limit Warning Light

13
93
12
6
x100
RPM
0
10
20
30
40 50
60
70
1
5 6 8 10 11
4 7 9
2 3
VDO
0
40
60
80
100
120
140 160 180
200
220
240
260
280
KmH
20
290
0Km
12
13
1. Tachometer
2. Analogue Clock
3. Speedometer
4. Rev Limit Warning Light
5. Heater Fan Control
6. Footwell Vent
7. Air Conditioning
8. Ignition/Engine Start
9. Hazard Warning
INSTRUMENTS AND SWITCHES
Central Dashboard - LHD
10. Heated Windscreen
11. Temperature Control
12. Trip Reset Button
13. Odometer & Trip Meter

14
INSTRUMENTS
Speedometer (1 RHD, 3 LHD)
The speedometer indicates the road speed of the vehicle. The display is miles per
hour (mph) and/or kilometres per hour (kph).
Clock (2)
To advance the hands in a clockwise direction, carefully press the small right-hand
button on the clock face (using a small, blunt device makes this easier). Pressing
the button once will advance in one minute increments. If the button is held down
for longer, a continuous movement of the hands is achieved. The left-hand button
acts in the same way, except the movement is in an anti-clockwise direction.
Tachometer (3 RHD, 1 LHD)
The tachometer displays the engine speed in revolutions per minute (rpm).
WARNING The use of excessive RPM when an engine is not at normal
running temperature may cause premature wear, damage to the engine
and failure of engine components.
Odometer (4 RHD, 13 LHD)
Located in the LCD screen in the bottom of the speedometer, the odometer
records total distance that the vehicle has travelled.
Trip Meter (4 RHD, 13 LHD)
Located in the LCD screen at the bottom of the speedometer is the trip meter,
which can be used to record a distance from a set starting point.
Trip Reset Button (5 RHD, 12 LHD)
The trip meter can be re-set to zero by pressing and holding the button.
PUSH BUTTON SWITCHES
Heater Fan Control (6 RHD, 5 LHD)
Rotate the Heater Fan Control knob clockwise to increase fan speed. Rotate
anti-clockwise to reduce fan speed. A Heater Fan Control icon appears in the
Driver Information Panel.
Footwell Vent (7 RHD, 6 LHD)
When pushed on, the switch will display in white. Air is directed into the footwell.
Air Conditioning (8 RHD, 7 LHD)
When pressed, this button engages the compressor on the engine. The engine
speed may slow for a short time when first switched on. Cold air will be directed
through the heater vents. Press the button again to turn off.
CAUTION Make sure the heater vents are open before turning on
the air conditioning.
Ignition/Engine Start (9 RHD, 8 LHD)
When the key is turned once, the ignition will start. When turned for a second
time, with the ignition key set to the second position, push the Start button to
start the ignition. Whilst pressing and holding the brake pedal (automatic) or
clutch pedal (manual), press and hold the Start button to start the engine.
NOTE: The engine will not start unless the foot brake (automatic) or clutch
pedal (manual) is depressed firmly.
Hazard Warning Switch (10 RHD, 9 LHD)
When pushed on the switch will flash red in conjunction with all the direction
indicators on the vehicle. The left and right indicator icons in the Driver Information
Panel will flash. Hazard lights should be used in an emergency. In the case of an
emergency, move the vehicle to a safe position and turn the hazard lights on.

15
Heated Windscreen (11 RHD, 10 LHD)
The heated windscreen is turned on by pushing the switch located on the
dashboard. When turned on, the heated windscreen icon will display on the
Driver Information Panel and the button will emit an amber light. Elements in
the windscreen will heat up, defrosting/defogging the windscreen. This function
will automatically turn off after approximately 10 minutes.
Temperature Control (12 RHD, 11 LHD)
Rotate the Temperature Control knob clockwise to increase interior temperature,
or anticlockwise to reduce interior temperature. A Temperature Control icon
appears in the Driver Information Panel.
Rev Limit Warning Light (13 RHD, 12 LHD)
A warning light will come on in the Tachometer when the vehicle reaches 200rpm
from its maximum limit.
WARNING Prolonged excessive rpm may cause damage to the engine.
Rear Fog Lamp
Twisting the inner collar of the indicator stalk upwards turns on the rear fog
lamp. When turned on, a symbol will display on the Driver Information Panel.
The rear fog lamp will only operate when the vehicle lights are switched on. The
fog lamp will automatically turn off when the ignition is turned off.
Fuel Level Gauge
Your Morgan Plus Four is equipped with a visual fuel gauge. The gauge will indicate
that the tank is full of fuel when the needle is positioned to the far right of the
gauge. As the fuel is used, the needle will move towards the left hand side of the
gauge, representing the amount of fuel remaining in the tank. A warning light at the
bottom of the gauge will come on when the fuel reaches approximately 6 litres
(1.6 US Gallons).
WARNING Do not allow your vehicle to run completely out of fuel. This
may cause damage to engine, emissions and fuel system components.
Engine Coolant Temperature
The engine coolant temperature is displayed on a gauge located on the instrument
panel. The engine coolant temperature should remain within the normal range
in all running conditions. Check that when at normal operating temperature
the gauge is positioned in approximately the 12 o’clock position. If the gauge
indicates that the engine coolant is higher than normal, proceed with caution.
The engine coolant level should be checked after the coolant temperature has
reduced. This check should take place before the vehicle is driven any further. A
warning light at the bottom of the gauge will come on when the coolant reaches
too high a temperature. If this situation occurs, the engine should be stopped
(at the next safe place) and the engine left to cool. The vehicle should then be
inspected by a Morgan Service agent before further use.
WARNING High engine coolant temperatures can cause serious and
permanent damage to an engine. Never check the engine coolant level when
the coolant is hot. Remove the coolant top up cap slowly using using heavy
duty gloves that will protect protect from scalding from steam or hot coolant.
WARNING If the coolant temperature exceeds a pre-defined threshold,
engine power will automatically be reduced to to reduce the risk of damage
to the engine and drivetrain.

16
1 32
D
4
8
56
7
10
9
12
13
15
16
14 11
DRIVER INFORMATION PANEL
1. Fuel Gauge
2. LCD Screen
3. Coolant Temperature
4. ABS Warning Indicator
5. Oil Level / Oil Pressure Warning
6. Check Seat Belt
7. Heated Screen
8. Selected Drive Mode
(Automatic Vehicles Only)
9. Right Indicator
10. Battery Charge Warning
11. High Beam or Auto Lights
12. Check Engine
13. Fog Lamp
14. Side Lights
15. Brake Warning
16. Left Indicator

17
Drivetrain.
Drive moderately.
Check soon.
Gearbox Getting Hot.
Gearbox Faulty.
Engine Oil
Pressure.
Drive
Moderately.
Measurement
Started.
Conditions Not Met.
No Measurements
Available.
Oil Level
Below Min.
Oil Level
Check
Required.
0/4
Oil Level
Below Min.
Oil Level.
3/4
Washer Low. Oil Level
at Max. Allowed.
5/4
Secure
Vehicle
Against
Rolling.
Powertrain
Breakdown.
Stop At Once!
Gearbox
Overheat.
Stop Carefully.
Engine
Overheat.
Stop Carefully.
Overseer
Off.
Overseer
Fault.
Gearshift
Not Possible.
(Automatic cars only)
Door Open. On. Fan. Heater. Exterior
Temperature.
3 .5
0
C
Ice
Warning.
Oil Level
Over Full.
5/4
DRIVER INFORMATION PANEL ICON EXPLANATION
