Morgan PLUS FOUR User manual

MORGAN MOTOR COMPANY
Pickersleigh Road, Malvern Link, Worcestershire, England, WR14 2LL.
www.morgan-motor.com

The content contained within this handbook is correct at the time of publication, however due to the nature of Morgan motor vehicle production, some details may be subject to change.
Information regarding airbags can be found on page 14 of this handbook.
Version 1.0 January 2023 - MY23 Part No. GP011108 © Morgan Motor Company 2023
WARNING
Occupants requiring additional seating aids should not travel in the vehicle.
Due to the high performance nature of the vehicle, Morgan Motor Company recommend advanced driver training.
WARNUNG
Passagieren, die Sitzhilfe benötigen, sollten nicht mitfahren.
Da diese Hochleistung Fahrzeugen sind, empfehlt Morgan Motor Company jedem Fahrer, an einem Advanced Driving Training vor der Benutzung der
eigenen Modelle teilzunehmen.
ATTENTION
Il est fortement conseillé d’éviter le transport des passagers qui nécessitent des supports pour s’asseoir.
Dès que ces voitures soient à haute prestations, Morgan Motor Company recommande de suivre des cours de Advance Driving à toutes les personnes
qui souhaitent conduire ses modèles.
AVVERTIMENTO
È fortemente sconsigliato il trasporto di passeggeri che necessitino di ausili per la seduta.
Data la tipologia di vettura ad alte prestazioni , Morgan Motor Company raccomanda espressamente corsi di guida di livello avanzato a chiunque intenda
guidare i propri modelli.
ADVERTENCIA
Los ocupantes que requieran asientos auxiliares adicionales no deben viajar en el vehículo.
Debido a la naturaleza de alto rendimiento del vehículo, Morgan Motor Company recomienda capacitación avanzada para conductores.
警告
車両での旅行には、追加の座席支援が必要な住民は適しません。
車両のハイパフォーマンスの性質のため、モーガンモーターカンパニーは、アドバンスドライバートレーニングを推奨します。
تحذير
لا يجب على الأشخاص ذوي الإحتياجات الخاصة ركوب أو قيادة المركبة.
نظرا لطبيعة الأداء العالي للمركبة ، توصي شركة مورغان موتور بتدريب متقدم للسائقين.

Plus Line Owner’s Handbook - Version 1.0 1
TABLE OF CONTENTS
2 INTRODUCTION
A welcome to your vehicle and the
technical specification.
11 SAFETY AND SECURITY
Important warnings and information
about vehicle safety and security.
18 COMFORT AND CONVENIENCE
Information regarding seats and
convenience items.
22 DASHBOARD
Explanation of instruments, switches,
symbols, screens and control stalks.
40 OPERATING THE VEHICLE
Information on how to drive and
operate the vehicle safely.
49 OPERATING THE HOOD
How to put up and take down the hood
and hood cover.
55 FUEL FILLING
56 BONNETS
57 TYRES AND WHEELS
61 FUSES, EXHAUSTS AND BATTERY
62 TOWING / LIFTING THE VEHICLE
64 MAINTENANCE
Advice on keeping your vehicle in
exemplary condition.
70 OWNERSHIP
Information including warranties
and service schedules.
87 INDEX

2
This handbook has been produced in order to give the owner a good
understanding of how best to use and enjoy their Morgan. The owner/driver
should read and understand the content of this handbook before using the car,
and the handbook should then be kept in the car for reference at any time. It
should be passed on to new owners if the car changes ownership.
Welcome to the World of Morgan
Your car is as individual as you are, and employs traditional coach-building
techniques, using only the highest quality materials – leather, aluminium and
seasoned ash. Each Morgan is built to an individual specification. Morgan uses
the latest drive-train technology, using a lightweight, powerful engine that meets
current standards in emissions and fuel economy.

Plus Line Owner’s Handbook - Version 1.0 3
Supplying Dealer Information:
Morgan advises that the Vehicle Identification Number (VIN) is recorded in
this section along with other records that may be useful when requesting or
ordering replacement parts.
The VIN (Vehicle Identification Number) plate is positioned under the left
bonnet on the inner panel ahead of the A-Post. The VIN Number is stamped
into the chassis behind the right hand seat under the carpet.
Vehicle Identification Number: .........................................................................................................
Registration: ...............................................................................................................................................
Body Colour: ...............................................................................................................................................
Trim Colour: ...............................................................................................................................................
Hood Colour: ............................................................................................................................................
Paint Colour Code: ................................................................................................................................
Warranty Start Date: ............................................................................................................................
VEHICLE IDENTIFICATION

4
Engine Information
Engine..........................................................BMW 2.0L (1998.3cc) in-line four cylinder
direct injection with twin scroll turbo.
Cylinders ..................................................4
Capacity ..................................................1998.3cc.
Bore (mm) ..............................................82
Stroke (mm) ..........................................94.6
Compression Ratio ............................10:2:1
Firing Order ...........................................1-3-4-2
Power Net (kW) ................................190 kW at 6000rpm
Torque Nm ............................................Manual: 350 Nm Automatic: 400 Nm
Valve Operation ..................................2 overhead camshafts, chain driven
Valve Timing ...........................................Variable valve timing system
Fuel System
Type ............................................................Electronic fuel injection
Fuel Pressure kPa (psi)......................350 BAR 35000 kPa
Fuel Type .................................................98 or 95 RON unleaded petrol
Ethanol Rating........................................E10 and E5
Ignition System
Type ............................................................Digital electronic
Operation.................................................ECU controlled, direct coil
Spark Plug ................................................NGK/Champion R5/R6 Gap 0.75mm
Cooling System
Type ............................................................Engine driven water pump, electronically
controlled water management module,
radiator, twin electric cooling fans.
Normal Operating Temp. ..............85 – 115°C
Air Conditioning System
Refrigerant................................................R1234yf - 650g
Oil..................................................................Denso ND-12
Capacities
Fuel Tank (approx.) ...................................38 litres (10 US Gall.)
Windscreen washer bottle ...........2.5 litres (0.7 US Gall.)
Engine oil with new filter ...............5.75 litres (1.5 US Gall.)
Rear Differential ..................................1.7 litres (0.5 US Gall.)
MORGAN PLUS FOUR

Plus Line Owner’s Handbook - Version 1.0 5
Transmission
Manual:
Gear Box .......... 6-speed manual with
Comfort and Sport+
engine modes.
Differential ....... Ratio 2.81:1
Transmission
Automatic:
Gear Box .......... 8-speed automatic
with Comfort, Sport
and Sport+ shift
modes.
Differential ....... Ratio 2.81:1
Suspension
Front ...................................................................Double wishbone with anti-roll bar
Rear ...................................................................Double wishbone
Caster Front ..................................................5°30’
Caster Rear ....................................................N/A
Camber Front .............................................-0° 30’ +/- 15’
Camber Rear .................................................-0° 45’ +/- 15’
Toe In Front ...................................................+0° 04’ +/- 0° 02’
Toe In Rear ....................................................+0° 07’ +/- 0° 02’
Brakes
Front ..........................................................4 x 38.1mm piston aluminium caliper, 288mm
(diameter) x 22mm (thickness) ventilated disc.
Rear.............................................................1 x 36mm piston aluminium caliper, 282mm
(diameter) x 26mm (thickness) ventilated disc
with integral self-adjusting handbrake.
Handbrake .............................................Cable operated, self-adjusting.
Operation ..............................................Hydraulic with vacuum servo assistance,
ABS, ESC, BAS, TCS, EBD standard.
Operating Fluid.....................................DOT 4
Oil and Fluid Specifications
Engine .......................................................0W-30 Fully Synthetic
Gearbox Oil - Manual .....................MTF-LT-5
Gearbox Oil - Automatic .............Shell L12108
Rear Differential Oil .........................G1 HYPOID Axle Oil G3 synthetic oil
of the highest grade.
Engine Coolant Type .......................BMW HT-12 Mix ratio 50% for coolant
down to -38oC.
Gear Ratios - Auto
1st ..................................................................5.25
2nd .................................................................3.36
3rd..................................................................2.172
4th..................................................................1.72
5th..................................................................1.316
6th..................................................................1
7th..................................................................0.822
8th..................................................................0.64
Gear Ratios - Manual
1st ..................................................................3.683
2nd .................................................................2.062
3rd..................................................................1.313
4th..................................................................1
5th..................................................................0.809
6th..................................................................0.677
MORGAN PLUS FOUR

6
Wheels and Tyres
15” ALLOY WHEEL:
Wheel Size..............................................15”x6.5” ET-21
Tyres...........................................................205/60R15 91V
15” WIRE WHEEL:
Wheel size...............................................15”x6.5” ET-14
Tyres...........................................................205/60R15 91V
16” WIRE WHEEL:
Tyres...........................................................16”x7” ET-14
Front Tyre................................................205/55R16 91V or 91W
Tyre Pressure.........................................28 PSI
Wheel Torque Setting (Alloy Wheels)..............80Lb/Ft (110Nm)
Wheel Torque Setting (Wire Wheels)..............Hammer Tight
Chassis
Ground Clearance Front Axle......................................................125mm (4.92 in)
Ground Clearance Rear Axle........................................................135mm (5.31 in)
Turning Circle ........................................................................................4.29m (14 ft)
MORGAN PLUS FOUR
Vehicle Dimensions
Length .........................................................................................................3830mm (150.79 in)
Width (Base Wheels).........................................................................1650mm (64.96 in)
Width (Option Wheels)...................................................................1665mm (65.55 in)
Height .........................................................................................................1235mm (48.62 in)
Track Front ..............................................................................................1455mm (57.28 in)
Track Rear ................................................................................................1455mm (57.28 in)
Wheelbase (fully loaded) ................................................................2520mm (99.21 in)
Vehicle Masses
Vehicle in Running Order (Including Fuel) - Auto ..........1115kg
Vehicle in Running Order (Including Fuel) - Manual .....1119kg
Maximum permissible mass...........................................................1300kg
Maximum weight per axle (Front) ...........................................624kg
Maximum weight per axle (Rear) ............................................676kg
This vehicle is not designed for towing.

Plus Line Owner’s Handbook - Version 1.0 7
Fuel Consumption and
Carbon Dioxide Emissions*
MANUAL:
Low CO2...............................................243.5 g/km
Medium CO2.....................................162.3 g/km
High CO2.............................................139.2 g/km
Extra High CO2.................................159.5 g/km
Combined CO2.................................165 g/km
Low .......................................................26.3 mpg 10.7 l/100km
Medium ...............................................39.5 mpg 7.2 l/100km
High .......................................................46.0 mpg 6.1 l/100km
Extra High.............................................40.1 mpg 7.0 l/100km
Combined.............................................38.8 mpg 7.3 l/100km
MORGAN PLUS FOUR
AUTOMATIC:
Low CO2...............................................198.5 g/km
Medium CO2.....................................129.4 g/km
High CO2.............................................118.6 g/km
Extra High CO2.................................148.4 g/km
Combined CO2.................................142.0 g/km
Low .......................................................27.0 mpg 8.7 l/100km
Medium ...............................................41.3 mpg 5.7 l/100km
High .......................................................45.2 mpg 5.2 l/100km
Extra High.............................................36.2 mpg 6.5 l/100km
Combined.............................................37.9 mpg 6.2 l/100km
*All figures quoted are WLTP declared values.

8
MORGAN PLUS SIX
Engine Information
Engine..................................................................BMW 3.0L (2,998cc) in-line six cylinder
direct injection with twin scroll turbo.
Cylinders ..........................................................6
Capacity ..........................................................2998cc.
Bore (mm) ......................................................82
Stroke (mm) ..................................................94.6
Compression ratio .....................................11:1
Firing order .................................................... 1-5-3-6-2-4
Power net (kW) .........................................250 kW at 5000rpm
Torque Nm ....................................................500 Nm
Valve operation ........................................... 2 overhead camshafts, chain driven
Valve timing ....................................................Variable valve timing system
Fuel System
Type ....................................................................Electronic fuel injection
Fuel pressure kPa (psi) ............................350 BAR 35000 kPa
Fuel type ..........................................................98 or 95 RON unleaded petrol
Ethanol Rating................................................ E10 and E5
Ignition System
Type ....................................................................Digital electronic
Operation.........................................................ECU controlled, direct coil
Spark plug .......................................................NGK/Champion R5/R6 Gap 0.75mm
Cooling System
Type ....................................................................Engine driven water pump, electronically
controlled water management module,
radiator, twin electric cooling fans.
Normal operating temperature ........ 85 – 115°C
Air Conditioning System
Refrigerant .......................................................R1234yf - 650g
Oil..........................................................................Denso ND-12
Capacities
Fuel Tank (approx.) ...................................38 litres (10 US Gall.)
Windscreen washer bottle ...................2.5 litres (0.7 US Gall.)
Engine oil with new filter ......................6.5 litres (1.7 US Gall.)
Rear Differential .......................................... 1.7 litres (0.5 US Gall.)
