MORNSUN TM CP Series User manual

The copyrightand authorityforthe interpretation ofthe productsarereserved by MORNSUN TMxxxxCP2013.05.08-A/4Page1of3
ACTIVE HIGH PRECISION
ISOLATIONAMPLIFIER
MILLIVOLT-CLASS POSITIVE AND NEGATIVE
SIGNALINPUT& POSITIVE ANDNEGATIVE
SIGNALOUTPUT
TMxxxxCP
RoHS
PARTNUMBERSYSTEM
TMXXXXCP
Package
Powersupply
Signaloutput
Signalinput
Isolationtransducer
Positiveandnegativesignal
mVclasssignal
Nodistribution
FEATURES
lFour-portisolation(Signalinput,Signal
output, power
supplyand isolationpoweroutput)
lHighaccuracy(0.1% F.S.)
lHighlinearity(0.1%F.S.)
lIsolationvoltage(2.5KVDC/60s)
lExtremelylowtemperaturedrift (35PPM/ C)Industry
standard(Operatingtemperaturerange:-25 C~
71 C)
lHighreliability(MTBF>500,000 hours)
GENERAL DESCRIPTION
TheTMxxxxCPseriesisolation amplifiermoduleshavea
millivolt-class positiveand negativesignalinputand positiveand
negativesignaloutput. Thesemodules,withahigh efficiency
micro-powersourcebuilt-in,can providepowerforsignalprocessing
circuit.Inthethree-wireand four-wiretransmitterapplications,our
productsmakecustomers’designsimpleandhelpfullyimprovethe
room-usingratioofPCB.Adopting electromagnetismisolation
technology, itisavailabletokeephigheraccuracyand extremelylower
temperaturedriftthanphotocouplerisolation.Thesemoduleshave
three-portisolation(input,outputandpowersupply),and theisolation
voltagebetween themisupto2.5kVDC.
SELECTIONGUIDE
Model PowerSupply InputSignal OutputSignal Channels
TM1630CP 24V ±10mV ±5V 1
TM2630CP 24V 20mV ±5V 1
TM4630CP 24V ±50mV ±5V 1
TM5630CP 24V ±75mV ±5V 1
TM6630CP 24V ±100mV ±5V 1
TM7650CP 12V 200mV ±5V 1
TM4530CP 24V ±50mV ±10V 1
TM5530CP 24V ±75mV ±10V 1
TM6530CP 24V ±100mV ±10V 1
Note:Wecould alsooffer customerdesign for special inputand outputasfollow:
Power supply:24/15/12VDC;
Input signal:0~±10/±20/±30/±50/±75/±100mV;
Outputsignal:0~±5V/±10V.
ELECTRICALC
HARACTERISTICS
Powersupply (Nominalpowersupply) ±5%
Inputconsumption ≤1W
PowerSupply
Powerprotection Reverseprotection
Inputsignal Seeproductprogram
InputImpedance ≥10MΩ(@maxinputsignal)
SignalInput
Overload ≤10V
Outputsignal Seeproductprogram
SignalOutputLoadcapacity ≥2KΩ（@maxOutput）
TRANSMISSIONCHARACT
ERISTICS
ZeroOffset 0.1%F.S.
GainError 0.1%F.S.
TemperatureDrift ≥50mV: 0.0035%F.S./;
<50mV: 0.0050%F.S./ (-25~+71 C)

The copyrightand authorityforthe interpretation ofthe productsarereserved by MORNSUN TMxxxxCP2013.05.08-A/4Page2of3
ISOLATIONCHARACTERI
STICS
GalvanicIsolation Three-portisolation (Input,outputand powersupply)
Isolation Voltage 2.5kVDC (tested for1minute,leakagecurrent<1mAandhumidity<70%)
InsulationResistance 100MΩ,500VDC(between input, outputand powersupply)
OTHERCHARACTERISTIC
S
Operation temperature: -25 ~+71 C
Ambient
temperature TransportandStoragetemperature: -50 ~+105 C
Package DIP24
Weight 10g,typ
Application environmentNodust,fiercevibration,impulsion and corrosivegas
Note:1.Allspecifications measured atTA=25 C,humidity<75%, nominalinput voltage and rated output load unless otherwisespecified.
2.Onlytypicalmodelslisted,specifications ofcustomproductmay bedifferent.Pleasecontact ourservicepeopledirectlyforcertain conditions;
3.Inthisdatasheet,allthe test methods ofindicationsare basedon corporatestandards.
APPLICATIONCIRCUITDIAGRAM&SCHEMATICDIAGRAM
Sout+
Sout-
NC
Sin+
Sin-
NC
Pin-
Pin+
-
+
-
+
-
+
132 11 12
1314
2324 15
NC NC NC
16
Signaloutput port
Powerinput port
Signalinput port
12-
11+ 1-
3+
23+
24-
Sout+
Sout-
Sin-
Sin+
Output
Powersupply
Input
APPLICATIONNOTE
1.Pleaseread theusermanualcarefullybeforeusing.IfanyquestionpleasecontactourFAE.
2.Pleasedonot usethisproductinhazardousarea.
3.Thepowersupplyofthisproductshouldbe24VDC powersource.Itisforbiddentouse220VACpowersupply.
4.Toavoidinvalidexplosionprotection function, oranyfailure,disassembling thisproductisforbidden.
AFTER-SALES SERVICE
1.Productsarecarefullyinspectedandqualitycontrolled during production andbeforeshipment.Iftheyoperated abnormallyortherewasanything
wrong,pleasecontactouragentfromwhichyoupurchased orMORNSUN FAE assoon aspossible.
2.MORNSUNwarrantyourproductfor3yearsfrommanufacturing date.During thisperiod, MORNSUN willrepairorreplacetheproduct ifproduct
wasfoundtohavemanufacturing defect.
APPLICATIONCIRCUIT
You cansee “A APPLICATIONGUIDE TOISOLATIONTRANSMITTER”
OUTLINEDIMENSIONS,RECOMMENDEDFOOTPRINT&PACKAGING

The copyrightand authorityforthe interpretation ofthe productsarereserved by MORNSUN TMxxxxCP2013.05.08-A/4Page3of3
Note:
1.All specificationsaremeasured atTa=25 C,humidity<75%, nominalinputvoltageandratedoutputload unlessotherwisespecified.
2.Inthisdatasheet,allthetest setup and methodsarebased onourcorporatestandards.
3.All characteristicsaremeantforlisted model, non-standardmodelsmayperformdifferently,Pleasecontactourtechnicalsupportformoredetail.
4.Contact usforyourspecificrequirement.
5.Specificationsaresubjecttochangewithout priornotice.
