Mosaic Rustic Star FSMVPT2035 Owner's manual

FSMVPT2035
Rustic Star Rocker
Assembly Instructions & User’s Manual
Customer Service: [phone], 7:00am to 12:00am CST (daily)
Live Chat at: www.academy.com
Email: [email protected]
Made in China

Table Of Contents
Note: Before beginning assembly of product, make sure
all parts are present. Compare parts with package content
list and hardware contents above. If any part is missing or
damaged do not attempt to assemble the unit. Contact
customer service for replacement parts.
Page 1 of 5
Warnings ............................................................................................................2
Care and Maintenance.......................................................................................5
Tools and Parts...................................................................................................2-3
Assembly Instructions.........................................................................................4
Warranty Information..........................................................................................5

This rocker requires adult assembly. Keep screws and parts away from children.
Please read this manual before assembly or use.
Do not tighten nuts or screws until assembly is complete.
SKU#: 021568910 Style#: FSMVPT2035 Weight limit: 350 LB
Tools Required (Included)
Page 2 of 5

Right leg
Left leg
Rocker seat
Rocker back
70mm bolts
50mm bolts
Hexagonal nuts
Washers
End caps
Page 3 of 5

DGH
I
E
F
B
C
Step 1:
Attach the rocker back (D) to the left
leg (B) using two 70mm bolts (E), two
washers (H) and two hexagonal nuts
(G). Repeat this step to attach the
rocker back to the right leg (A).
Hand tighten only.
Attach the rocker seat (C) to the left
leg (B) using two 50mm bolts (F),two
washers (H) and two hexagonal nuts
(G). Repeat this step to attach the
Rocker seat to the right leg (A).
Hand tighten only.
Step 2:
Step 3:
Tighten all hexagonal nuts and bolts
using the included wrench (J) and
Allen wrench (K). Cover all nuts
using the end caps (I). The rocker is
now ready to use.
Page 4 of 5

The rocker should be cleaned on a regular basis to promote safe use and prolong product life.
Wipe the frame with a smooth damp cloth and air dry.
Do not use abrasive cleaners as they may damage or scratch the surface paint.
Do not leave this product in harsh weather conditions for extended periods.
For extended life, the bench should be stored indoors or covered during prolonged periods
of non-use.
Storing in a dry location will help prevent rust.
Warranty Information
The appliance has been manufactured under the highest
standards of quality and workmanship. We warrant to the
original consumer purchaser that all aspects of this product will
be free of defects in material and workmanship for one year
from the date of purchase. A replacement for any defective
part will be supplied free of charge for installation by the
consumer. Defects or damage caused by the use of other then
genuine parts are not covered by this warranty. This warranty
shall be effective from the date of purchase as shown in the
purchaser receipt.
This warranty is valid for the original consumer purchaser only
and excludes industrial, commercial or business use of the
product, product damage due to shipment or failure which
results from alteration, product abuse, or product misuse,
whether performed by a contractor , service company , or
consumer. We will not be responsible for labor charges and/or
damage incurred in installation, repair or replacement nor for
incidental or consequential damage.
Page 5 of 5
