Moseley Event 5800 Installation and operating manual

Event 5800

Installation & Reference Manual

Document Number: 602-16620-01, Rev. A

May 8, 2012

Event 5800 Installation & Reference Manual ii

This book and the information contained herein is the proprietary and confidential

information of Moseley, Inc. that is provided by Moseley exclusively for evaluating the

purchase of Moseley, Inc. technology and is protected by copyright and trade secret

laws.

No part of this document may be disclosed, reproduced, or transmitted in any form or by

any means, electronic or mechanical, for any purpose without the express written

permission of Moseley, Inc.

For permissions, contact Moseley Marketing Group at 1-805-968-9621 or 1-805-685-

9638 (FAX).

Notice of Disclaimer: The information and specifications provided in this document are

subject to change without notice. Moseley, Inc. reserves the right to make changes in

design or components as progress in engineering and manufacturing may warrant.

The Warranty(s) that accompany Moseley products are set forth in the sales

agreement/contract between Moseley and its customer. Please consult the sales

agreement for the terms and conditions of the Warranty(s) provided by Moseley. To

obtain a copy of the Warranty(s), contact you Moseley Sales Representative at 1-805-

968-9621 or 1-805-685-9638 (FAX).

The information provided in this document is provided “as is” without warranty of any

kind, either expressed or implied, including, but not limited to, the implied warranties of

merchantability, fitness for a particular purpose, or non-infringement. Some jurisdictions

do not allow the exclusion of implied warranties, so the above exclusion may not apply to

you.

In no event shall Moseley, Inc. be liable for any damages whatsoever – including special,

indirect, consequential or incidental damages or damages for loss of profits, revenue,

use, or data whether brought in contract or tort, arising out of or connected with any

Moseley, Inc., document or the use, reliance upon or performance of any material

contained in or accessed from this document. Moseley’s license agreement may be

provided upon request. Additional Terms and Conditions will be finalized upon negotiation

or a purchase.

The above information shall not be constructed to imply any additional warranties for

Moseley, Inc. equipment including, but not limited to, warranties of merchantability or

fitness for an intended use.

Trademark Information

JavaTM is a trademark of Sun Microsystems Inc.

Windows® is a registered trademark of Microsoft Corporation

All other brand or product names are trademarks or registered trademarks of their

respective companies or organizations.

Event 5800 Installation & Reference Manual iii

EVENT 5800 Installation & Reference Manual

Document Number: 602-16620-01

Revision Levels:

SECTION DWG REV REVISED/RELEASED

All All A December 2011

N/A N/A B May 2012

Event 5800 Installation & Reference Manual iv

Event 5800 Installation & Reference Manual v

Table of Contents

1. Safety Precautions ..................................................................................... 1-1

1.1 RF Energy Health Hazard............................................................................. 1-1

1.2 Protection from Lightning............................................................................. 1-1

1.3 Protection from RF Burns............................................................................. 1-1

1.4 Risk of Personal Injury from Fiber Optics........................................................ 1-1

1.5 This is a Class A product.............................................................................. 1-1

1.6 Turn off all power before servicing ................................................................ 1-1

1.7 Power Supply Safety Requirements............................................................... 1-2

1.8 Battery must be replaced correctly................................................................ 1-2

1.9 Proper Disposal.......................................................................................... 1-2

1.10 Equipment RF Protection............................................................................ 1-2

1.11 Regulatory Notices.................................................................................... 1-3

2. System Description .................................................................................... 2-1

2.1 Introduction............................................................................................... 2-1

2.1.1 Example Applications............................................................................. 2-1

2.1.2 Operational Overview ............................................................................ 2-1

2.2 System Features ........................................................................................ 2-3

2.3 Physical Description .................................................................................... 2-4

2.3.1 Model Types................................................. Error! Bookmark not defined.

2.3.2 Back Panel ........................................................................................... 2-4

2.3.3 Hardware Modules................................................................................. 2-4

2.3.4 Back Panel Connectors........................................................................... 2-6

2.3.4.1 Power Supply Module Connector ........................................................ 2-6

2.3.4.2 Controller Module Connectors............................................................ 2-6

2.3.4.3 Standard Master I/O Module Connectors ............................................. 2-7

2.3.4.4 GigE Master I/O Module Connectors ................................................... 2-7

2.3.4.5 42xE1/T1 Master I/O Module Connectors ............................................ 2-7

2.3.4.6 ASI Mini I/O Module Connectors......................................................... 2-8

2.3.4.7 Optional OC-3 Mini I/O Module Connectors.......................................... 2-8

2.3.4.8 Optional STM-1 Mini I/O Module Connectors ........................................ 2-8

2.3.5 LEDs ................................................................................................... 2-8

2.3.5.1 Back Panel LEDs.............................................................................. 2-8

2.3.6 External AC to DC Converter..................................................................2-10

2.4 Block Diagram & Functional Components ......................................................2-10

2.5 Consecutive Point Architecture ....................................................................2-12

2.6 Spanning Tree Protocol (STP)......................................................................2-14

2.7 1+1 Protection..........................................................................................2-14

2.7.1 Protected Non-Diversity (Hot Standby)....................................................2-14

2.7.2 Protected Diversity...............................................................................2-15

2.7.2.1 Frequency Diversity ........................................................................2-15

2.7.2.2 Spatial Diversity.............................................................................2-15

2.8 1+1 Multi-Hop Repeater Configuration..........................................................2-15

2.9 Data Interfaces .........................................................................................2-17

2.10 100 Mbps Fast Ethernet............................................................................2-17

2.10.1 155Mbps Fast Ethernet........................................................................2-17

2.10.2 Two Network Operation.......................................................................2-17

2.10.3 Single Network Operation....................................................................2-17

2.11 Gigabit Ethernet (1000 Mbps)....................................................................2-17

2.11.1 GigE Port Based VLAN.........................................................................2-18

2.12 Ethernet Quality of Service (QoS)...............................................................2-18

Event 5800 Installation & Reference Manual vi

2.13 Gigabit Ethernet Link Aggregation Configuration...........................................2-19

2.13.1 2+0 East/East Configuration ................................................................2-19

2.13.2 4+0 East/East Configuration ................................................................2-19

2.14 Crosspoint Switch ....................................................................................2-20

2.15 STM-1 Specifications ................................................................................2-21

2.16 STM-1 Mux/Demux (Optional) ...................................................................2-21

2.17 Power Management..................................................................................2-21

2.18 Network Management...............................................................................2-22

2.18.1 IP Address.........................................................................................2-22

2.18.2 Network............................................................................................2-23

2.18.3 NMS Network Operational Principles......................................................2-23

2.18.4 Third Party NMS Support.....................................................................2-24

2.19 System Loopbacks ...................................................................................2-24

3. Pre-Installation Procedures ....................................................................... 3-1

3.1 Site Evaluation........................................................................................... 3-1

3.2 Critical System Calculations ......................................................................... 3-3

3.2.1 Received Signal Level (RSL) and Link Budget ............................................ 3-3

3.2.2 Fade Margin Calculation ......................................................................... 3-4

3.2.3 Availability Calculation........................................................................... 3-4

3.3 Frequency Plan Determination...................................................................... 3-5

3.4 Facility Requirements.................................................................................. 3-6

3.5 Antenna Planning ....................................................................................... 3-6

3.6 Transmit Power Setup ................................................................................. 3-6

3.6.1 5.8 GHz Band....................................................................................... 3-7

3.6.2 5.3 GHz Band....................................................................................... 3-7

3.6.2.1 Internal Antenna ............................................................................. 3-7

3.6.2.2 External Antenna............................................................................. 3-7

4. Installation ................................................................................................ 4-1

4.1 Unpacking ................................................................................................. 4-1

4.2 Notices ..................................................................................................... 4-1

4.3 Pre-Installation Notes.................................................................................. 4-1

4.4 Back-to-Back Bench Testing......................................................................... 4-1

4.5 EVENT 5800 Installations............................................................................. 4-2

4.5.1 Table Top or Cabinet Installation ............................................................. 4-3

4.5.2 Rack Installation ................................................................................... 4-3

4.5.3 External Waveguide Filter Installation ...................................................... 4-3

4.6 External Equipment Connections................................................................... 4-3

4.6.1 Controller Module Connectors ................................................................. 4-3

4.6.2 Standard Master I/O Module Connectors................................................... 4-4

4.6.3 GigE Master I/O Module Connectors......................................................... 4-4

4.6.4 42xE1/T1 Master I/O Module Connectors.................................................. 4-4

4.6.5 ASI Mini I/O Module Connectors............................................................. 4-5

4.6.6 Optional OC-3 Mini I/O Module Connectors ............................................... 4-5

4.6.7 Optional STM-1 Mini I/O Module Connectors.............................................. 4-5

4.7 Ground Connections.................................................................................... 4-5

4.8 Antenna/Feed System................................................................................. 4-5

4.8.1 Antenna Mounting................................................................................. 4-5

4.8.2 Transmission Line ................................................................................. 4-6

4.8.3 Environmental Seals.............................................................................. 4-6

4.8.4 Antenna & Transmission Line Testing ....................................................... 4-6

4.9 Connect the Power Source ........................................................................... 4-6

4.10 Link Alignment ......................................................................................... 4-7

Event 5800 Installation & Reference Manual vii

4.10.1 EVENT 5800 RSL Output....................................................................... 4-7

5. Quick Setup Guide...................................................................................... 5-1

5.1 Quick Start Hardware Overview.................................................................... 5-1

5.1.1 Ensure coaxial Connections .................................................................... 5-1

5.1.1.1 PolyPhaser...................................................................................... 5-1

5.2 Quick Start Software Settings....................................................................... 5-1

5.2.1 PC Network Configuration....................................................................... 5-1

5.2.2 Default IP Address................................................................................. 5-2

5.2.3 Default User Name/Password.................................................................. 5-2

5.3 IP Address Configuration ............................................................................. 5-2

5.4 Link Configuration ...................................................................................... 5-3

5.5 Site Attributes............................................................................................ 5-4

5.6 Reset to Factory Defaults............................................................................. 5-5

5.7 Command Line Interface (CLI) Access ........................................................... 5-5

5.7.1 CLI Access via NMS Ethernet .................................................................. 5-5

5.7.2 CLI Access via Serial Port....................................................................... 5-5

6. On-Site Service .......................................................................................... 6-1

6.1 Removing a Module .................................................................................... 6-1

6.2 Installing a Module ..................................................................................... 6-2

7. Specifications............................................................................................. 7-1

7.1 System Specifications ................................................................................. 7-1

7.2 Ethernet Performance ................................................................................. 7-2

7.2.1 100 Base TX Ethernet Performance.......................................................... 7-2

7.2.2 Gigabit Ethernet (GigE) Performance........................................................ 7-4

8. Connectors ................................................................................................. 8-1

8.1 DC Input (Power) Connector ........................................................................ 8-1

8.2 Ethernet 100BaseTX Payload Connector......................................................... 8-1

8.3 Ethernet 1000BaseT Payload Connector......................................................... 8-1

8.4 SONET Payload Connector ........................................................................... 8-2

8.5 STM-1 Payload Connector............................................................................ 8-2

8.6 DVB/ASI, DS-3, E-3, STS-1 Payload Connector............................................... 8-2

8.7 NMS 10/100BaseTX Connector 1-2................................................................ 8-2

8.8 Alarm/Serial Port Connector......................................................................... 8-3

8.9 T1/E1 Channels 1-2 Connector ..................................................................... 8-3

8.10 T1/E1 Channels 3-16 Connector.................................................................. 8-4

8.11 USB (for Future)....................................................................................... 8-5

8.12 Data Order Wire ....................................................................................... 8-6

8.12.1 RS-422.............................................................................................. 8-6

8.12.2 RS-232.............................................................................................. 8-6

Appendix A. Abbreviations & Acronyms ..........................................................A-1

Appendix B. µV – dBm Conversion Chart .........................................................B-1

Appendix C. FCC Applications Information ...................................................... C-1

Appendix D. Customer Service ........................................................................D-1

D.1 Technical Consultation..............................................................................D-1

D.2 Factory Service .......................................................................................D-1

D.3 Field Repair ............................................................................................D-2

Event 5800 Installation & Reference Manual viii

List of Illustrations

Figure 2-1. Example Installation.......................................................................... 2-2

Figure 2-3. Transceiver Back Panel...................................................................... 2-4

Figure 2-4. Receiver-Only Back Panel................................................................... 2-4

Figure 2-5. EVENT 5800 Modules......................................................................... 2-5

Figure 2-7. Back Panel LEDs ............................................................................... 2-8

Figure 2-9. EVENT 5800 Block Diagram.............................................................. 2-10

Figure 2-10. Ring Configuration ........................................................................ 2-13

Figure 2-11. Consecutive Point Network ............................................................. 2-14

Figure 2-12. 1+1 Non-Diversity Mode Protection ................................................. 2-15

Figure 2-13. 1+1 Diversity Mode Protection ........................................................ 2-15

Figure 2-15. 1+1 Multi-Hop Repeater Configuration ............................................. 2-16

Figure 2-16. Back Panel Connections for Drop/Insert Capability ............................. 2-16

Figure 2-17. Two Network Operation.................................................................. 2-17

Figure 2-18. Single Network Operation............................................................... 2-17

Figure 2-19. GigE Port Based VLAN.................................................................... 2-18

Figure 2-20. Ethernet Quality of Service (QoS).................................................... 2-19

Figure 2-22. Crosspoint Switch ......................................................................... 2-20

Figure 2-23. Crosspoint Switch (a) Repeater and (b) Add/Drop Examples................ 2-20

Figure 2-24. STM-1 Mux/Demux........................................................................ 2-21

Figure 2-25. PC/EVENT 5800 on Same Subnet .................................................... 2-23

Figure 2-26. DTVLINKs on Different Subnets....................................................... 2-24

Figure 3-1. 5.8 GHz Frequency Plan..................................................................... 3-5

Figure 4-1. Back-to-Back Testing Configuration..................................................... 4-2

Figure 4-5. DC Power Cable Connector................................................................. 4-7

Figure 4-7. RSSI Output vs. Received Signal......................................................... 4-8

Figure 5-2. IP Address Label Location .................................................................. 5-2

Figure 6-1. EVENT 5800 Modules......................................................................... 6-1

Figure 6-2. Thumbscrew and Corner Screw Locations............................................. 6-1

Figure 6-3. Threaded Hole Locations.................................................................... 6-2

Figure 6-4. Guides for Installing Cards ................................................................. 6-2

Event 5800 Installation & Reference Manual ix

List of Tables

Table 2-1. Key Benefits/Advantages .................................................................... 2-2

Table 2-2. Master I/O Modules............................................................................ 2-5

Table 2-3. Supported E1/T1 Combinations............................................................ 2-5

Table 2-4. Modem Status LED............................................................................. 2-9

Table 2-5. DVB-ASI In Status LED....................................................................... 2-9

Table 2-6. DVB-ASI Out Status LED..................................................................... 2-9

Table 2-7. TCM/Convolutional Code Rates........................................................... 2-11

Table 2-8. GigE Ethernet Throughput Examples by Modulation & Bandwidth ............ 2-18

Table 3-1. Maximum IDU/ODU Cable Lengths ....................................................... 3-3

Table 3-2. Maximum Output Power vs. Modulation Order for EVENT 5800 ................. 3-6

Table 3-3. Maximum Power Settings for 5.3GHz U-NII Band Operation (US).............. 3-8

Table 5-1. Default User Names & Passwords ......................................................... 5-2

Table 5-2. Serial Cable Pinout............................................................................. 5-5

Table 5-3. Serial Port Parameters........................................................................ 5-5

Table 7-1. 100 Base TX Ethernet % Nominal Throughput........................................ 7-3

Table 7-2. 100 Base TX Ethernet Latency (msec)................................................... 7-3

Table 7-3. Gigabit Ethernet % Nominal Throughput ............................................... 7-4

Table 7-4. Gigabit Ethernet Latency (msec) .......................................................... 7-4

Event 5800 Installation & Reference Manual x

1. Safety Precautions 1-1

1. Safety Precautions

PLEASE READ THESE SAFETY PRECAUTIONS!

Do not turn on power before reading Moseley’s product documentation. This device has a

-48V DC direct current input.

1.1 RF Energy Health Hazard

This symbol indicates a risk of personal injury due to radio frequency

exposure.

The radio equipment described in this guide uses radio frequency transmitters.

Although the power level is low, the concentrated energy from a directional

antenna may pose a health hazard. Do not allow people to come in close proximity to the

front of the antenna while the transmitter is operating. The antenna will be professionally

installed on fixed-mounted outdoor permanent structures to provide separation from any

other antenna and all persons.

WARNING: FCC RF exposure compliance requires a minimum separation distance of

33.9cm maintained between the user and antenna when the product is used with a 9dBi

antenna. For point-to-point use with a 26dBi antenna, this distance must be increased to

a user separation distance of 240cm.

Appropriate warning signs must be properly placed and posted at the equipment site and

access entries.

1.2 Protection from Lightning

Article 810 of the US National Electric Department of Energy Handbook 1996

specifies that radio and television lead-in cables must have adequate surge

protection at or near the point of entry to the building. The code specifies that

any shielded cable from an external antenna must have the shield directly

connected to a 10 AWG wire that connects to the building ground electrode.

1.3 Protection from RF Burns

It is hazardous to look into or stand in front of an active antenna aperture. Do not stand

in front of or look into an antenna without first ensuring the associated transmitter or

transmitters are switched off. Do not look into the waveguide port when the radio is

active.

1.4 Risk of Personal Injury from Fiber Optics

DANGER: Invisible laser radiation. Avoid direct eye exposure to the end of a fiber, fiber

cord, or fiber pigtail. The infrared light used in fiber optics systems is invisible, but can

cause serious injury to the eye.

WARNING: Never touch exposed fiber with any part of your body. Fiber fragments can

enter the skin and are difficult to detect and remove.

1.5 This is a Class A product

WARNING: This is a Class A product. In a domestic environment this product may cause

radio interference in which case the user may be required to take adequate measures to

remedy the interference.

1.6 Turn off all power before servicing

WARNING: Turn off all power before servicing.

Event 5800 Installation & Reference Manual 1-2

1.7 Power Supply Safety Requirements

Safety requirements require a switch be employed between the external DC power

supply and the EVENT 5800 power supplies. The switch must disconnect both poles of the

power supply. A single-pole disconnect device can be used to disconnect the line

conductor where it is possible to rely on the identification of an earthed conductor in a

DC MAINS SUPPLY. The supplied AC to DC converter alleviates this requirement since

the AC MAINS connector can be unplugged to disconnect the power.

1.8 Battery must be replaced correctly

CAUTION: There is a danger of explosion if the battery is incorrectly replaced. Replace

only with the same or equivalent type recommended by the manufacturer. Dispose of

used batteries according to the manufacturer's instructions.

Panasonic (or equivalent) is the manufacturer of the battery (Part Number: 2032).

Disposal instructions are available on the Panasonic website. Please dispose in

accordance with local regulations.

1.9 Proper Disposal

The manufacture of the equipment described herein has required the

extraction and use of natural resources. Improper disposal may contaminate

the environment and present a health risk due to the release of hazardous

substances contained within. To avoid dissemination of these substances

into our environment, and to lessen the demand on natural resources, we

encourage you to use the appropriate recycling systems for disposal. These

systems will reuse or recycle most of the materials found in this equipment in a sound

way. Please contact Moseley or your supplier for more information on the proper disposal

of this equipment.

1.10 Equipment RF Protection

CAUTION: Do not operate the EVENT 5800 without an antenna, attenuator or

load connected to the antenna port. Otherwise, damage may occur to the

transmitter module due to excessive reflected RF energy.

CAUTION: Always attenuate the signal into the receiver antenna port to lest than

–20 dBm ( 22.4 mV / 10 mW ). This will prevent overload and possible damage

to the receiver module.

Event 5800 Installation & Reference Manual 1-3

1.11 Regulatory Notices

FCC Part 15 Notice

Note: This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause

harmful interference, in which case the user will be required to

correct the interference at his own expense.

Pursuant to Part 15.21 of the FCC Rules, any changes or

modifications to this equipment not expressly approved by the

manufacturer may cause harmful interference and void your

authority to operate this equipment. Any external data or audio

connection to this equipment must use shielded cables.

FCC Part 15 Equipment Authorization

The EVENT 5800 Transmitter has been granted Equipment

Authorization under Part 15.247 of the FCC Rules and

Regulations.

Equipment Class: Broadcast Transmitter Base Station

Frequency Range: 5725 -5850 MHz

Emission Bandwidth: 10/25/50 MHz

FCC Identifier: CSUEVENT5800

Event 5800 Installation & Reference Manual 1-4

2. System Description 2-1

2. System Description

This manual is written for those who are involved in the “hands-on” installation of the

EVENT 5800 in a microwave point-to-point link, such as installation technicians, site

evaluators, project managers, and network engineers. It assumes the reader has a basic

understanding of how to install hardware, use Windowsbased software, and operate

test equipment. See the EVENT 5800 User Interface Guide (Moseley Document #602-

15173-01) for information about how to operate the unit.

2.1 Introduction

The Moseley family of digital radios provides high capacity transmission, flexibility,

features, and convenience for wireless digital communications networks. The digital

point-to-point radios represent a new microwave architecture that is designed to address

universal applications for video, audio, data, PDH and SDH platforms. This advanced

technology platform is designed to provide the flexibility to customers for their current

and future network needs.

EVENT 5800 supports a wide range of network interfaces and configurations:

16/32/42/63 x E1/T1

1/2 x 100BaseTX Ethernet

1000BaseTX Ethernet

1/2 x STM-1/OC-3

EVENT 5800 is spectrum and data rate scalable, enabling service providers or

organizations to trade-off system gain with spectral efficiency and channel availability for

optimal network connectivity. EVENT 5800 enables network operators (mobile and

private), government and access service provides to offer a portfolio of secure, scalable

wireless applications for data, video, and Voice over IP (VoIP).

The Moseley EVENT 5800 is a digital microwave radio terminal. A built-in radio

transceiver unit establishes the frequency of operation over the Unlicensed 5.8 GHz ISM

band. Some applications are described below:

2.1.1 Example Applications

EVENT 5800 can be used for unlicensed high-capacity full-duplex Telecommunications

data and broadcast applications for data rates to 100 Mbps:

5.8 GHz band between 5.725 to 5.850 GHz for ISM in 5, 10, 20, and 30 MHz

channels.

EVENT 5800 can be used for Unlicensed high-capacity full-duplex data and broadcast

applications for data rates to 100 Mbps.

2.1.2 Operational Overview

EVENT 5800 digital radios support diversity, 1+0, and 1+1 protection and ring

architectures. The modem and power supply functions are supported using easily

replaceable plug-in modules. A second plug-in modem/IF module can also be installed to

provide diversity, repeater or east/west network configurations.

EVENT 5800 includes integrated Operations, Administration, Maintenance, and

Provisioning (OAM&P) functionality and design features enabling simple commissioning

when the radio network is initially set up in the field at the customer’s premises. EVENT

5800 is scalable and capability of supporting a ring-type architecture. This ring or

consecutive point radio architecture is self-healing. In the event of an outage in the link,

2. System Description 2-2

data traffic is automatically re-routed to ensure that service to the end user is not

interrupted.

Figure 2-1. Example Installation

Table 2-1 shows key features that Moseley technology offers to those involved in the

design, deployment and support of broadband fixed wireless networks.

Table 2-1. Key Benefits/Advantages

Component/Feature Benefits Advantages to Providers/Customers

EVENT 5800 System Universal signal processing platform Enables easy network interface options and

network capacity growth in the future.

Advanced Single Chip Modem ASIC Cost effective solution; simplifying product

logistics and overall product life cycle costs.

The flexibility reduces capital and operating

expenditures commonly associated with field

installation, maintenance, training and

spares.

Integrated Forward Error Correction

(FEC) Frequency independent and Scalable.

Powerful adaptive equalizer Software defined flexibility enables selective

modulation for spectral efficiency and

adherence to worldwide regulatory emissions

guidelines.

Easy to install units Straightforward modular system

enables fast deployment and

activation.

Fast return on investment.

Carrier-class reliability. No monthly leased line fees.

Complete support of

payload capacity Aggregate capacity beyond basic

network payload. Increases available bandwidth of network.

Scalable and spectrally efficient

system. Allows customer full use of revenue-

generating payload channel.

Separate networks for radio

overhead/management and user

payload.

Lowers total cost of ownership.

Ring Architecture Supports a ring (consecutive point)

configuration, thus creating a self-

healing redundancy that is more

reliable than traditional point-to-

Enables network scalability.

2. System Description 2-3

Component/Feature Benefits Advantages to Providers/Customers

point networks.

In the event of an outage, traffic is

automatically rerouted via another

part of the ring without service

interruption.

Increases deployment scenarios for initial

deployment as well as network expansion

with reduced line-of-sight issues.

Ring/consecutive point networks can

overcome line-of-sight issues and

reach more buildings than other

traditional wireless networks.

Increases network reliability due to self-

healing redundancy of the network.

Networks can be expanded by adding

more IDUs or more rings, without

interruption of service.

Minimizes total cost of ownership and

maintenance of the network.

A separate management channel

allows for a dedicated maintenance

ring with connections to each EVENT

5800 on the ring.

Allows for mass deployment.

Adaptive Power Control Automatically adjusts transmit power

in discrete increments in response to

RF interference.

Enables dense deployment. Simplifies

deployment and network management.

Comprehensive

Link/Network

Management Software

A web interface offers security,

configuration, fault, and performance

management via standard craft

interfaces.

Simplifies management of radio network and

minimizes resources as entire network can be

centrally managed out of any location.

Suite of SNMP-compatible network

management tools that provide

robust local and remote

management capabilities.

Simplifies troubleshooting of single radios,

links, or entire networks. Simplifies network

upgrades with remote software upgrades.

Allows for mass deployment.

2.2 System Features

Selectable Rates and Interfaces

oPDH Options: Up to 16 x E1/T1, 100BaseTX/Ethernet (Scalable 1-100 Mbps), DS-

3/E-3/STS-1 (option; consult factory for availability)

oSuper PDH Options: Up to 32 x E1/T1, 100 BaseTX/Ethernet (Scalable 1-100

Mbps)

oEthernet Options: 100 BaseTX/Ethernet (Scalable 1-155 Mbps),

1000BaseTX/Ethernet (Scalable 1-300 Mbps)

oSDH Options: 1-2 x SDH STM-1/OC-3 SONET

Support for multiple configurations for both PDH and SDH

o1+0, 1+1 protection/diversity

oHot Standby

oEast/West Repeater (2 + 0)

Selectable Spectral Efficiency of 0.8 to 6.25 bits/Hz (including FEC and spectral

shaping effects)

QPSK, 16–256 QAM Modulation

Powerful Trellis Coded Modulation concatenated with Reed-Solomon Error Correction

Built-in Adaptive Equalizer

Support of Data Orderwire Channels

oUp to 19.2 kbps asynchronous RS-232

2. System Description 2-4

o64 kbps synchronous RS422

Adaptive Power Control

Standard high-power feature at antenna port

o5W (37 dBm in QPSK mode) in 2 GHz bands

o1W (30 dBm) in 5.8, 7, and 13 GHz bands

Built-in Network Management System (NMS)

Consecutive Point ring architecture

Built-in Bit Error Rate (BER) performance monitoring

Integrated Crosspoint switch: allows a total of 191 E1s (200 T1s) to be mapped any-

to-any between front-panel ports and RF link(s)

Optional STM-1 Mux/Demux: allows the SDIDU to extract up to 63 E1 (or 84 T1) from

an STM-1. In conjunction with an integrated Crosspoint Switch, up to 223 E1 (284

T1s) can be mapped any-to-any between ports, STM-1, and RF link(s).

2.3 Physical Description

The following sections describe the physical features of EVENT 5800 digital radios.

2.3.1 Back Panel

The following illustration shows the general format of a EVENT 5800 back panel.

Figure 2-3. Transceiver Back Panel

This illustration shows the back panel of a transceiver unit that can be configured as a

transmitter or receiver. The following illustration shows the back panel of a receiver-only

unit.

Figure 2-4. Receiver-Only Back Panel

Note that the back panel of a EVENT 5800 unit will be slightly different depending on the

number and type of hardware modules installed. Some modules are standard and

included in all units. Optional modules may be ordered and installed to support specific

functional requirements.

2.3.2 Hardware Modules

The lower section of the EVENT 5800 chassis is comprised of hardware modules. The

number and type of modules depends on the type and required functionality. A maximum

of eight of modules can be installed in the chassis. A minimum of five modules are

required in a basic EVENT 5800 configured for 1+0 operation. They are:

Power Supply Module

Controller Module

Modem & I/F Telemetry Module

Master I/O Module

Mini I/O Module

2. System Description 2-5

Figure 2-5. EVENT 5800 Modules

Power Supply Module: A second power supply module can be installed above this

module and is required for 1+1 or 2+0 configurations.

Controller Module: This module is included in all EVENT 5800 units. It supports the

interface to the LCD/keypad and includes connectors for attaching a PC for configuration

and monitoring via the web, CLI, or SNMP interface.

Mini I/O Module: This module can be ASI, an OC3/STM-1 Optical or STM-1 Electrical

Mini I/O Module.

Modem & IF/Telemetry Module: A second Modem & IF Telemetry module can be

installed above this module and is required for 1+1 or 2+0 configurations. Either module

can be replaced with a Wideband Modem & IF/Telemetry module. The standard Modem

module supports 5-30 MHz channel bandwidths. The Wideband Modem module supports

7-56 MHz channel bandwidths.

Master I/O Module: The Master I/O Module can be one of the following:

Table 2-2. Master I/O Modules

Master I/O Module Payload

E1/T1 Ethernet STM-1 Mux/Demux Jumbo Packets

Standard 1-16 10/100 No No

GigE 1-2 10/100/1000 No 4000

Enhanced GigE (Super PDH) 1-2 10/100/1000 No*/Yes* 4000*/9728*

42xE1/T1 1-42 10/100 No No

Enhanced 1-16 10/100 Yes No

*Enhanced GigE Master I/O comes with two options: Support for STM-1 Mux/Demux with

4000 Jumbo Packets or support for 9728 Jumbo Packets.

Expansion Slot: The Expansion Slot can be populated with a 16xE1/T1 Expansion

Module or 21xE1/T1 Expansion Module. The E1/T1 interface cards support up to 63

channels operating simultaneously. Mixing of E1 and T1 channels is not supported. The

E1/T1 interface is in accordance with G.703. One or two E1/T1 channels can be used as

wayside channels in other operating modes. The Standard Master I/O provides up to

16xE1/T1. The Super PDH Master I/O provides up to 42xE1/T1. Additional 16xE1/T1 or

21xE1/T1 are provided by separate Expansion I/O cards. The GigE Master I/O card

provides up to 2xE1/T1. The total possible T1/E1 combinations are provided in the

following table. Table 2-3. Supported E1/T1 Combinations

Master I/O Expansion I/O E1/T1

Standard None 16xE1/T1
