Rapid M2000 Installation and operating instructions
M2000 MOBILE RAPID RADIO
Security Information:
Please read the instructions in this guide carefully to ensure proper use of the mobile radio and avoid potential hazards.
Electronic Equipment
• Do not use the radio in an area that prohibits the use of wireless devices in case of interfering with other electronic equipment.
Flammable and Explosive Areas
• Do not use the radio in areas that contain potentially ammable or explosive materials (e.g. petrol station).
Operating Environment
• Do not use the radio in dusty, humid, or heavily polluted environments, or expose the radio to magnetic elds, as it may cause
internal circuit faults.
• Do not use the equipment during a thunderstorm. This may cause equipment failure or electric shock.
• Do not expose the radio to direct sunlight for extended periods
• Do not expose the radio to water/moisture as it may lead to re or electric shock.
• Do not place the radio near ames or other heat sources such as heaters, microwaves, candles, or ovens.
Accessories Requirements
• Do not use unapproved or incompatible power sources, chargers, or batteries as this may cause re or explosions.
• Only use manufacturer approved accessories. Use of unapproved accessories may cause damage to the radio and will void the warranty.
Maintenance Service:
• Ensure the radio has been switched off and power has been disconnected before cleaning or performing maintenance of the equipment.
• When the radio is not in use, cover all sockets.
• When cleaning dust off the exterior of the equipment do not use corrosive chemicals – use neutral detergents.
• Keep the radio and accessories dry – do not attempt to dry the equipment with a hairdryer, oven, or microwave.
User Manual & Installation Guide
TS0322
Instructions before use:
• Do not use the mobile radio or charge the battery in potentially explosive environments (e.g. where gas, dust, or steam etc. is present).
• Turn off the radio when refuelling your vehicle or when parked at any refuelling station.
• Do not expose the radio to direct sunlight for extended periods. Do not place the radio near heating appliances.
• Do not expose the radio to extremely dusty conditions or water/moisture. Do not place on an uneven surface.
• Do not disassemble the radio. Maintenance should only be carried out by a qualied technician.
Machine Chart:
Installation:
SIM Inserting Slot
1. Remove SIM card cover, insert SIM card,
place cover back on and screw to tighten.
2. Rotate xed bracket screws clockwise
until the xed bracket is tightened.
3. Connect with the power supply.
DC power input
4. Insert GPS antenna/external main antenna.
GPS antenna interface
5. Plug in the microphone.
Hand microphone interface
12 3 4 5
6
7
8
9101112
13
14
191817
16
15
20 21
Machine Chart Legend
1. Volume Knob
Turn left (-V), Turn right (+V) & Press to set 8. Return 15. Fixed Bracket Screw
2. Indicator 9. Customised Button 16. Fixed Bracket
3. LampLCD 10. Customised Button 17. GPS Antenna Interface
4. SOS 11. 2G/3G Switch Key 18. External Main Antenna Interface
5. Logo 12. SIM Switch Key 19. DC Power Interface
6. Previous Page 13. Mic Interface 20. Headset/USB Interface
Device/Installation Kit Components
1x M2000 PTToC Device 1x Fist Microphone metal bracket
1x Fist Microphone 3x Fist Microphone metal bracket mounting screws
1x Mounting Bracket - Metal 1x GPS Antenna
2x Mounting Bracket pivot screws 1x 4G LTE Patch Antenna 698-2700 MHz (Glass Mount)
2x Mounting Bracket xing screws 2x DC Power cables (1 x black 1 x red)
