Mounting Solutions WMT-83J User manual

WMT-83J Wall Mount Adapter
100 lbs (45 kg) max load
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
EMEA & Asian region:
[phone]
USA, LATAM, Canada, Australia
& New Zealand region:
[phone]
The WMT-83J is a compact and low prole indoor speaker wall mount. It’s providing various distance
from solid wall to cut through acoustic treatment.
This bracket supports loudspeakers weighing up to 45 kg (100 lbs.) and comes with a design factor
of 7:1.
Its speaker & wall mount plate are installed separately and coupled very easily by just one person.
The WMT-83J has its own tilt angle -20°, -25°, -30°.
SPECIFICATIONS:
Functions Wall mounting adapter
Three static tilt angles
Wall mounting plate 150x93 mm 5,91” x 3,66”
Tilt angle -20°, -25°, -30°
Load limit 45 kg 100 lbs
Design factor 7:1 ratio
Dimensions 111 x 114 x 150 mm 4,37” x 4,49” x 5,91”
Shipping dimensions 192 x 118 x 176 mm 7,56” x 4,65” x 6,93”
Net weight 0,88 kg 1,94 lbs
Shipping weight (2 pcs
per box) 2,10 kg 4,63 lbs
COMPABILITY:
Compatible JBL speakers: 8320, 8340 A, 8350
SAFETY INSTRUCTIONS
1. Entrust mounting equipment only to
experienced professionals and strictly follow
the provided safety instructions. Improperly
installed equipment may result in property
damage, personal injury and/or liability for the
installing contractor.
2. Always use safety cables! This will prevent
equipment from falling during setup or while
exploitation.
3. Always carefully check the mounting
surface of the wall. Make sure the wall or
ceiling structure allows to hold the weight of
the speaker including its bracket.
4. Only use appropriate fastening hardware.
5. Always make sure to securely use and lock
all mounting bolts. Loose bolts may become
unscrewed over time due to vibration which
will then create a safety hazard.
PACKAGE CONTENTS
1. WMT-83J wall mounting - 2 pcs
2. Hex key 3 - 1 pcs
3. Installation manual - 1 pcs

WMT-83J Wall Mount Adapter
100 lbs (45 kg) max load
www.mnmounting.com
[email protected]om
2 Merezhna str., Bila Tserkva,
Kyiv region, 09100, Ukraine
EMEA & Asian region:
[phone]
USA, LATAM, Canada, Australia
& New Zealand region:
[phone]
Dimensions
