MoveMaster MoveMaster User manual

User instructions

Your MoveMaster
Congratulations on purchasing an original MoveMaster!
The MoveMaster offers a completely new sense of freedom in the operation of your Computer.
By the possibility of controlling the grip only by the use of the wrist, all five fingers remain free for
the parallel operation of the 10 primary and secondary keys. Due to the extremely short
switching paths of the handle, movement processes are more precise and faster. In addition,
the MoveMaster also offers various adjustment options to meet the ergonomics of your hand.
Optionally available for right-handed (mouse right / MM left)
or left-handed (mouse left / MM right).
Although designed primarily for the ultimate gaming experience, it also provides a
complement to common control in many other applications.
Not suitable for children under 12!

Table positioning
After months of testing, we recommend the
following positioning of your MoveMaster for
optimal and fatigue-free use.
While your hand covers the grip loosely
(depending on preference with your fingers
or the palm of your hand), your forearm
should rest up to the level of the elbow in the
same plane as the MoveMaster. This relieves
the strain on your wrist and allows you to
enjoy the benefits of the MoveMaster. Make
sure you have a comfortable table surface.
The pictures shows the positioning for right-
handed people

Handle control
The primary control function of your
MoveMaster is the revolutionary handle in
combination with the new technical
movement unit.
It works with an extremely fine tuned
mechanic in the 10th millimeter range.
However, this sensitivity requires a certain
acclimatization time. The switches in the
four main directions of movement are
preset by default with the usual WASD.
Attention! Please never try a rotating
movement with the handle!



Height adjustment handle
The handle can be adjusted up to 8 mm in
height.
To increase, use the allen key (3 mm) to turn
the central screw in the handle
counterclockwise until it reaches its desired
position. At the maximum possible height
you feel a skip of the screw.
To lower, turn clockwise and gently push
down on the handle from above

Height adjustment secondary keys
The front secondary keys can be
individually adjusted in height up to 10 mm.
To do so, loosen the fixing screw of the
selected secondary key with the enclosed
allen key (3 mm) by a maximum of two
turns and position it by carefully moving it to
the desired height.
Then tighten the fixing screw again.
This allows you to set all front secondary
keys individually.

Adjustment thumb secondary button
The thumb secondary button can be
individually adjusted in height, depth and
inclination.
Loosen the fixing screw of the thumb
secondary key with the enclosed allen key
(3 mm) by a maximum of two turns and
adjust it by carefully moving it into the
desired position.
Then tighten the fixing screw again

Handle cover and spacer
With the help of the enclosed spacer you
can increase the distance between the
primary buttons and the handle top.
Loosen the two fixing screws with the help
of the enclosed allen key (2.5 mm) and
remove the handle cover. Then insert the
spacer and reset the cover.
You can use max. 2 spacers.
(1 piece is included, others are available
separately at the shop)

Configurator
With the MoveMaster configuration
software you can set, save and load the
button assignment of your MoveMaster
and / or Button Commander. The software
makes it possible to save different
configurations for different applications.
The button assignment can be configured
via the drop-downs above each button.
The set configuration is transferred to the
device via the "Write configuration" button.
Existing configurations can be loaded via
the "Load configuration file" button, but it
will not be transferred to the device imme-
diately. This step can be summarized with
the checkbox „and write configuration".
Then, when loading a configuration from a
file, it is immediately transferred to the de-
vice. Successfully performed actions are
displayed in the green notification box.
The configurator is also downloadable from
our homepage:
www.movemaster.biz>downloads

die
movemaster
manufaktur
Have lots of fun with your original MoveMaster!
Tom Bredinin
Die MoveMasterManufaktur
Edenstetten
94505 Bernried
Germany
www.movemaster.biz
© 2018 Tom Bredinin MoveMasterManufaktur
Errors and omissons execpted.
Subject to change without notice.
