SHAKS S1+ User manual
S1 User Manual 1
S1+ User Manual
https://www.notion.so/S0User-Manual-
e200f7f328c749e0bbedaa0563c732ab
If any question, contact us SHAKS.official on facebook.
[ Contents ]
Compatible Device & Service
S1 is supporting android, Windows PC, Notebook, Nintendo Switch,
Android Phone. Please select mode matching your device. And check your
service to play !
Compatible Device & Service
Button layout & Status indication by LED
Mode selection according to your device
Connect your device
Compatible Gamelist Information
Useful information
S1 User Manual 2
Button layout & Status indication by LED
Please check the button/key name and LED indication to see the status of
your gamepad.
S1 User Manual 3
Mode selection according to your device
When the power is on, even if you change the mode on the side, the mode will
not change. Please follow the 1 step in each mode setting - Change to the
desired mode and press the 'Power button' for a long time to turn the power
off and on to apply it.
2 Step setup: In power-off status, press keys simultaneously until booting.
Select gamepad mode for your device in the table.
Change the “Hot Keys”
Mode Device LED
Status Hot Keys*
Windows, Android
via dongle
Android
Nintendo Switch
Windows
LED #1
#2 Power + LB
Android via
Bluetooth Android phone LED #3 Power + X
Android Mapping Android phone LED #1 Power + A
S1 User Manual 4
Mode Device LED
Status Hot Keys*
Wired Windows Windows LED #3 RB + Cable
Connection
Wired Android Android LED #1 RB + Cable
Connection
Connect your device
Once you correctly choose the mode, power on
Power on: Press 'Power Button' for 3 seconds. When the gamepad is
turned on by pressing the 'Power button', the default is Android mode.
Change mode according to the above table. And follow step 2 based on the
device you wish to connect. After the initial setup is complete, the
gamepad will remember your device to connect automatically.
Connecting with an Windows PC/Nintendo Switch
Plug USB-dongle into your PC.
Press Power+ LB button for 3 seconds.
When “Pairing” is successful: LED signals #1,2 light up.
Window tip) Recommended to use Windows 10 or later. If you are using
Windows 7, please install “Xbox 360 driver” driver first on your PC that
you can find on our website.
Nintendo Switch tip) When using Nintendo Switch, check if ‘Setting >
Controller and Sensor > Pro controller wired communication item is ON’.
Nintendo Switch tip2 The message “Registered” appears, connection
with Nintendo Switch is completed.
Connecting with a Wired Connection
S1 User Manual 5
If your PC do not support Bluetooth, please use “Wired Mode”.
Firstly, turn off the gamepad and connect with USB cable. Then,
connect USB cable to PC USB port while pressing 'RB button'.
When the message "XBOX 360 For Windows" appears on the PC, the
connection is completed!
When “Pairing” is successful: LED signal #1or #3 lights up.
Attention! Recommended to use Windows 10 or later. If you are using
Windows 7, please install “Xbox 360 driver” driver first on your PC that you
can find on our website.
Nintendo Switch tip) The message “Registered” appears, connection
with Nintendo Switch is completed. The LEDs follow Switch’s style.
Connecting Android phone/tablet and TV box by USB-dongle
1. Phone/Tablet Connecting: Plug into smartphone after connecting
USB cable and OTG-gender.
Notice: Since OTG-gender is different for each mobile model, please
purchase and install gender suitable for the model.
2. TV Box Connecting: Plug USB-dongle into the TV set-top box’s USB
port.
Press Power + LB button for 3 seconds.
When “Pairing” is successful: LED signals #1 #2 light up.
Connecting Android phone/tablet and TV box by Bluetooth
Console boxes such as Xbox, Playstation, Nintendo, etc. cannot be
connected.
Press Power + X button for 3 seconds.
If 3rd LED blinks, select & connect ‘SHAKS S1’ on BT device list in your
device.
When “Pairing” is successful: LED signal #3 lights up.
Playing on Mapping Mode (for Android only)
Download ShootingPlus V3 App. Windows is not supported. For more
details, please visit www.en.shaksgame.com
S1 User Manual 6
Press Power + A button for 3 seconds.
If 1st LED blinks, select and connect ‘SHAKS S1’ on BT device list in
your device.
When pairing is successful: LED signal #1 lights up.
Now you are ready to play games with mapped keys on your device!
Only when you are in the mapping mode you can use touch keys as
gamepad controllers that you set up.
Reset & Initializing to recover setup process
If any issue during setup, please reset gamepad and your device as below
and try again the step. SHAKS works like a 4 different gamepad, so,
connection might be confused across those 4 modes.
Booting your device again to confirm all cached log deleted or waiting
for a while 35 seconds), it will automatically delete.
Four the information,
Reset key on gamepad is powered off by force in any emergency
case. Profile stored is not deleted.
The last paired profle will be tried to re-connect. If fail, next one is
being tried in a sequerce.
“Cached log data” can be cleared by OS by 25 minutes
automatically. You can wait this auto clearing process.
Notes) when using Nintendo Switch
① The S1 LED display is the same as LED display on Switch only when
wired connection.
② The following functions cannot be used, please be aware.
Capture button
Wake up with HOME button
Gyroscope sensor
Exclusive games for Joy-Con is not supported
HD vibration X (only maximum output supported)
③ Connection in Handheld mode Tabletop mode)Use USBOTG gender C
type). But, in this case, use it in a flat position or use a stand so that it does
S1 User Manual 7
not touch floor.
Compatible Gamelist Information
Please visit our compatible game list for searching relative information.
💽
Compatible Game List
Useful information
Charge battery by charging cable from a computer or USB power charging
device.
Status Low Battery Charging Fully Charged
LED #4 fast blinking slow blinking stops blinking
