MS MAGIC User manual

- 0 -
User Manual
Upute za korištenje
Uputstvo za upotrebu
MAGIC
MP4 PLAYER
www.ms-start.com

- 1 -
Cautions
Do not subject the device to severe impact or drop it from high position.
Do not use the player in extreme hot or cold, dusty or damp field. Do not expose it to direct
sunshine.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Avoid using the player in strong magnetic field.
Keep the device away from water or other liquids. In the event that water or other liquids enter the
device, power off the product immediately, and clean the device.
Do not use chemical solution to clean the device in order to avoid corrosion. Clean it with a dry
cloth.
We are not responsible for the damages or lost data caused by malfunction, misusing, repairing
the device or battery replacement.
Do not attempt to disassemble, repair or modify the product. This will invalidate guarantee.
The design of the player or actual display may be different from what is shown in this manual. It
should be subject to the actual display or design.
Key Features
MP3&WMA Player
AVI Video player
JPEG image viewer
Package Content
Main Unit ●USB cable
Stereo earphones
Connect to a PC and Download Audio Files
This player is plug & play for WIN2000/XP/ME/Vista OS. But for Windows98/SE, you are required
to install a driver before connection.
To connect it with PC for transferring files,
(1) Plug the larger end of the USB cable to the USB port of the PC, and plug the smaller end to the
USB port of the player.
(2) When the “ ” icon appear at the right bottom of the PC screen, double click “My Computer” on
the desktop, you see two removable disks which indicate the internal flash memory and the
external memory card. Just use the removable disks as a regular local disks, copying files from
or to them.
(3) Removing the player from the PC safely.
For Windows2000/XP/ME/Vista:
a) Left click the icon at the right hand corner of the taskbar.
b) Click the pop-up mini-window with message of “Stop the USB Mass Storage Device …”.
c) Remove the device when you are prompted to.
Stereo FM radio (optional)
Removable Storage Device
Built-in rechargeable lithium-ion battery
User Manual
Application CD
MicroSD card reader
Folder Navigation
Voice Recorder

- 2 -
For Win98, please make sure the data transfer is completed before unplugging the MP3 player.
Charge the Battery
The device has a built-in lithium-icon rechargeable battery. It is charged via USB connection. You
are required to charge it when you use it for the first time. It takes about 3 hours to fully charge the
battery. Connect the larger end of the USB cable to the USB interface of PC, and connect the other
smaller end of the USB cable to the USB interface of this player. The device is connected to PC and
being charged.
NOTICE: For maximum performance, lithium-ion batteries need to be used often. If you don’t use the device
often, be sure to recharge the battery at least once per month.
Use a Memory Card
The device has a memory card slot for reading data from a micro-SD card.
(1) Insert a Micro-SD card to the card slot on the unit body.
(2) Press and hold the MENU button to display the main menu.
(3) Select “Explorer” and press the MENU button to enter the folder browser mode.
(4) In the folder browser mode, you see two folders named “Internal memory” and “Memory Card”.
To play the audio or video files stored on the MicroSD card, access the “Memory Card”folder.
Keys Description
Power On/Off
To turn on the device, slide the Power Switch to “ON” to turn on the power, and then press and
hold the PLAY/PAUSE button until you see prompt on the display.
To power off the device, press and hold the PLAY/PAUSE button until you see prompt on the
A. LCD Display
B. Play/Pause: Turn on or turn off the
device. Also play or pause audios.
C. MENU: Hold for a while to enter the
main menu. Briefly press to confirm
selection confirm or enter the folder
navigation mode.
D. Previous: Play the previous track. Also
move up.
E. Next: Play the next track. Also move
down.
F. VOL+: Turn up the volume.
G. VOL-: Turn down the volume.
H. Earphone Jack
I. Power Switch: Turn on or turn off the
power.
J. USB Port: Connect to a computer.
K. Memory Card Slot: For inserting a Micro
SD-card.

- 3 -
display, and then slide the Power Switch to “OFF” to turn off the power. (Be sure to complete this
step for saving battery charge.)
Note: This player has a power-saving feature which enables the device to power off automatically if it is idle
for about 3 minutes.
Basic operation
Function
Operation
Play/Pause
Press the PLAY/PAUSE button to play or pause.
Adjust Volume
Shortly press the VOL+/VOL- button to decrease or increase volume.
Previous Track
Shortly press the PREVIOUS button.
Next Track
Shortly press the NEXT button.
Fast Forward
Press and hold the NEXT button.
Rewind
Press and hold the PREVIOUS button.
A-B Repeat
To repeat a specified section of a track,
(1) During playing, press and hold the VOL+ button to select the start
point of the repeat.
(2) Press and hold the VOL+ button again to select the stop point. The
music section between the start point and the stop point is repeated.
(3) To stop A-B repeat, press the VOL+ button.
Lock/Unlock
buttons
To protect the buttons against being pressed accidentally or unlock
buttons, hold down the PLAY/PAUSE button and the VOL- together.
Playing music
Enter the music mode
Press and hold the MENU button to display the main menu.
Use the PREVIOUS/NEXT button to select “Music” menu, and press the MENU button to confirm
selection. Now you are in the MUSIC mode, refer music playing to the basic operations.
Search for Tracks
(1) When the music is playing, you can press the MENU button to enter the folder explorer mode.
(2) Press the PREVIOUS/NEXT button to select a folder or track, and press the MENU button to
confirm selection, or press the PLAY/PAUSE button to return.
Display lyric
To display lyric while you are listening music,
(1) Copy a lyric file in LRC format to your player. Please note that the LRC file should be in the
same directory and have the same name of the track to be listened.
(2) Locate and play the track. When the music is playing, press and hold the VOL- button to switch
between lyric and ID3 info mode.
Playing videos
(1) Press and hold the MENU button to display the main menu.
(2) Use the PREVIOUS/NEXT button to select the “Video” menu, and press the MENU button to
enter the video player mode.

- 4 -
(3) Press the PREVIOUS/NEXT button to select the memory that you want to use –Internal
Memory or Memory Card, and press the MENU button to confirm.
(4) Press the PREVIOUS/NEXT button to select a video file that you want to play, and press the
MENU button to play it. For detail information about playing, see the “Basic Operation” section.
(5) Press the MENU button to stop playing and exit.
Note: This player can only play AVI videos. For other formats, you need to use the converting tool included
on the driver CD to convert them. For detail information about the converter, see AVI Converter Quick User
Guide on the CD.
FM Radio(optional)
On the main menu, select “FM Radio” and press the MENU button to turn on the FM radio.
Search Station
(1) Shortly press the MENU button to show the submenus.
(2) Press the PREVIOUS/NEXT button to select “Auto” or “Manual”, and press the MENU button to
enter the auto-search or manual-search mode. In the Manual mode, press the
PREVIOUS/NEXT button to adjust the frequency slightly by the step of 0.1MHz. Optionally, you
can save the found station manually (see “Save Station”for detail information).
Save station
To save the found station,
(1) Shortly press the MENU button to activate the submenus.
(2) Press the PREVIOUS/NEXT button to select “Save” and press the MENU button to confirm.
(3) Press the PREVIOUS/NEXT button to select an empty location for the station, and press the
PLAY/PAUSE button to continue.
(4) Press the PREVIOUS/NEXT button to select “YES” or “NO”, and press the MENU button to
confirm.
Listen to Station
To listen to saved station,
(1) Shortly press the MENU button to activate submenus.
(2) Press the PREVIOUS/NEXT button to select “Preset” menu and press the MENU button to
enter the PRESET mode.
(3) In the PRESET mode, press the PREVIOUS/NEXT button to select a saved station for
listening.
Delete station
(1) Shortly press the MENU button to activate submenus.
(2) Press the PREVIOUS/NEXT button to select “Delete” menu and press the MENU button to
continue.
(3) Press the PREVIOUS/NEXT button to select the station that you want to delete, and press the
PLAY/PAUSE button to continue.
(4) Press the PREVIOUS/NEXT button to select “YES” or “NO”, and press the MENU to confirm.
Viewing Photos
(1) Press and hold the MENU button to display the main menu.

- 5 -
(2) Select “Photo” and press the MENU button to confirm.
(3) Press the PREVIOUS/NEXT button to select the memory that you want to use –Internal
Memory or Memory Card, and press the MENU button to confirm.
(4) Press the PREVIOUS/NEXT button to select a folder or image, and press the MENU to
confirm.
(5) When you are viewing a single photo, you can.
press the PREVIOUS/NEXT button to display the previous or the next photo.
press the PLAY/PAUSE to start or stop an auto slide show.
press the MENU button to enter the file explorer mode for searching for other photos.
Note: Some images may not be displayed. Try to use an image viewer to convert them into supported
format.
Reading E-books
Reading
(1) Press and hold the MENU button to display the main menu.
(2) Select “E-book” and press the MENU button to confirm.
(3) Press the PREVIOUS/NEXT button to select the memory that you want to use –Internal
Memory or Memory Card, and press the MENU button to confirm.
(4) Press the PREVIOUS/NEXT button to select a .txt file, and press the MENU button to open the
selected file.
(5) Press the PREVIOUS/NEXT button to page up or page down manually, or press the
PLAY/PAUSE button to page up or down automatically (by setting the time interval in
Settings/Auto Slide show/Text).
(6) During reading, you can use the bookmark to mark the page for resuming reading later. For
information about bookmark, see “Using bookmark” section.
Using bookmark
(1) Go to the page that you want to mark.
(2) Briefly press the VOL- button to show up a “Save Bookmark” window for saving bookmark.
(3) Press the PREVIOUS/NEXT button to select a bookmark number and press the MENU button
to confirm. The bookmark is saved. It starts from the first line of current page.
(4) To read the page that you marked, shortly press the VOL+ button to show up the “Load
Bookmark” window. Press the PREVIOUS/NEXT button to select a bookmark and press the
MENU button to confirm. You will be guided to that page.
Voice Recording
Record
(1) Press and hold the MENU button to display the main menu.
(2) Select “Record”，and press the MENU button to enter the recorder mode.
(3) Shortly press the PLAY/PAUSE button to start recording. During recording, you can press the
PLAY/PAUSE button to pause or resume recording.
(4) Shortly press the MENU button to stop and save recording.
(5) Press and hold the MENU button to exit.

- 6 -
Play recordings
(1) Select “Explorer” on the main menu to enter the folder navigate mode.
(2) Open the “VOICE” folder, and select the recording file that you want to play.
File Explorer
To browse all files stored in the player,
(1) Press and hold the MENU button to display the main menu.
(2) Select “Explorer”，and press the MENU button to enter the browser mode.
(3) Press PREVIOUS/NEXT button to select a file or folder that you want to view, and press the
MENU button to confirm or press the PLAY/PAUSE button to return to the higher hierarchy of
directory.
Delete File
(1) Select “Explorer” on the main menu to enter the file explorer mode.
(2) Select the file that you want to delete.
(3) Press and hold the VOL- button to delete the selected file.
(4) Press the PREVIOUS/NEXT button to select “YES” and press the MENU button to confirm.
System Setting
(1) On the main menu, select the “Settings” item and press the MENU button to enter the system
settings mode.
(2) Press the PREVIOUS/NEXT button to select setting item and press the MENU button to
confirm or press the PLAY/PAUSE button to cancel/return.
Music
Repeat mode
Once - Play current track once and then stop
Repeat One - Repeat current track
Folder Once - Play all audio files in the current folder
and stop after playing
Folder Repeat - Repeat all audio files in the current
folder
Normal - Play all audio files stored in the player and stop
after playing all
Repeat All - Repeat all audio files stored in the player
Intro - Play the first 10 seconds of every audio file
Play mode
Order - Play audio files in order
Shuffle - Play audio files randomly
Preset EQ
Select a preset EQ mode
User EQ
User-defined equalizer setting

- 7 -
(1) Press the PREVIOUS/NEXT to switch EQ column.
(2) Press the VOL-/VOL+ button to adjust the level.
(3) Repeat pressing the NEXT button until the cursor is on the YES button,
and then press the MENU button to confirm. Or, select “No”to quit.
(4) Go to the Preset EQ menu, and select User EQ to enable the equalizer
setting.
Auto slide
show
Text
Set the time interval between the previous and the next
page in the auto slideshow mode.
Set the time interval between the previous and the next
slide in the slideshow mode.
FM Radio
Stereo Switch
Enable or disable stereo effect
FM Region
Set the frequency band for the local area
Display
Backlight Time
Set the duration of the backlight after a key press.
Brightness
Set the brightness of the screen
Backlight mode
Normal –Half darken the screen when there is no
activity within a few minutes
Power Save - Entirely darken the screen when there is
no activity within a few minutes.
Power Off
Set the continuous working time before the player is turned off automatically.
Language
Select the language for on-screen texts
System
About
Display firmware version and capacity information of the
player
Upgrade
Upgrade the firmware
Load Defaults
Restore system settings to defaults
Troubleshooting
Problem
Possible Cause
Solution
The LCD displays
nothing when the
device is started.
Battery is too low.
Charge the battery.
No sound when
playing an audio file.
The volume is too low.
Adjust the volume.
Bad audio file.
Delete or skip the file.
The player cannot be
connected to the PC.
The USB interface is not
supported by PC’s
motherboard.
Update or replace the PC’s
motherboard.
The displayed time is
changing constantly.
The bit rate of the MP3 file
is changing during
playback.
Try to use fixed bit rate to compress
the MP3 file.
The PC has error
when you plug and
unplug the player.
The player is
disconnected from the PC
abruptly while transferring
files.
Do not disconnect the player from
the PC when transferring files.

- 8 -
Total memory
displayed on the
player is not in
accordance with the
marked amount.
Part of memory is used to
store programs and
display characters.
Some of MP3 files
cannot be played
properly.
The MP3 file is
compressed by a
standard, such as MPEG I
Layer 1 or Layer 2 that the
player does not support.
1. Delete the unsupported MP3 files.
2. Use MPEG I Layer 3 standard to
compress the unsupported MP3
files.
The video cannot be
played.
The file format is not
supported.
Make sure the video is in AVI format.
If not, use the provided converting
tool to convert it.
The video data is
corrupted
Skip it or reload another file
The photo cannot be
displayed
The file format is not
supported
Try to use an image editor (ACDSee
for example) to convert it to a
supported format.
The image resolution is
too high.
Make sure the image resolution
does not excess the limitation by the
device.
The TXT file cannot be
read
The file format is not
supported.
Skip it or reload another file.
Technical Specifications
Item
Specification
Capacity
512MB, 1GB, 2GB, 4GB, 8GB(optional)
Battery Type
Rechargeable lithium-ion polymer battery
Battery Life
About 10 Hours of music playback or 4 hours of video
playback
LCD Display
1.8-inch screen, 160 x 128 pixel
Video Format
AVI (XviD)
Audio Format
MP3, WMA, WMA-DRM9
Photo Format
JPEG, BMP
Image Resolution
7000 X 7000 (Max.)
Bit Rate
MP3: 8-320kbps; WMA: 8-320kbps
Recording Format
WAV(32kbps/8KHz)
SNR
＞90dB
USB Port
USB2.0
Operational Temperature
0℃~ +50℃
Storage Temperature
-20℃~ +65℃
Operational Relative Humidity *
20% ~ 90% (40℃)
Storage Relative Humidity *
20% ~ 93% (40℃)

- 9 -
Predostrožnosti
Ne izlažite ureĎaj jakim udarcima ili bacajte sa velike visine.
Ne koristite ureĎaj u ekstremno toplim ili hladnim uvjetima, te na prašnjavim ili vlažnim mjestima.
Ne izlažite ga izravnoj sunčevoj svjetlosti.
Pretjerana glasnoća iz slušalica može prouzročiti oštećenje ili gubitak sluha.
Izbjegavajte koristiti ureĎaj u jakim magnetskim poljima.
Držite ureĎaj podalje vode ili drugih tekućina. U slučaju da voda ili druge tekućine uĎu u ureĎaj
odmah isključite ureĎaj te ga zatim očistite.
Za čišćenje ureĎaja nemojte koristiti kemijska sredstva za čišćenje kako biste izbjegli koroziju.
UreĎaj čistite suhom krpom.
Naša tvrtka nije odgovorna za oštećenja ili gubitak podataka uzrokovan kvarom, neispravnom
uporabom, popravkom ureĎaja ili zamjenom baterije.
Ne pokušavajte rastavljati, popravljati ili modificirati ureĎaj. To će poništiti jamstvo.
Dizajn ureĎaja ili prikazi na zaslonu se mogu razlikovati od prikazanog u ovom priručniku. Kao
referencu uzimajte prikaze ili dizajn na stvarnom ureĎaju.
Ključne značajke
MP3 i WMA player
AVI video player
Preglednik JPEG slika
Sadržaj ambalaže
UreĎaj ●USB kabel
Stereo slušalice
Povezivanje sa računalom i kopiranje audio datoteka
Ovaj ureĎaj je plug & play za WIN2000/XP/ME/Vista OS. No za Windows98/SE, prije povezivanja
je potrebno instalirati upravljački program,
(1) Veći kraj USB kabela uključite u USB priključak na računalu a manji kraj USB kabela uključite
u USB priključak na ureĎaju.
(2) Kada se u donjem desnom kutu računalnog ekrana pojavi ikona “ ”, na radnoj površini dva
puta kliknite na ikonu “My Computer”, te ćete vidjeti dva uklonjiva diska koji predstavljaju
internu flash memoriju ureĎaja i eksternu memorijsku karticu. Uklonjive diskove koristite isto
kao i obične lokalne diskove, te kopirajte datoteke na ili sa njih.
(3) Sigurno uklanjanje ureĎaja iz računala.
Za Windows2000/XP/ME/Vista:
a. Lijevom tipkom diska kliknite na ikonu u donjem desnom kutu sistemske trake.
b. Kliknite na skočnu poruku teksta “Stop the USB Mass Storage Device …”.
c. Kada se od Vas to zatraži uklonite ureĎaj.
Stereo FM radio (opcionalan)
UreĎaj za pohranu podataka
UgraĎena punjiva litij-ionska baterija
Upute za uporabu
Aplikacijski CD
Čitač MicroSD kartica
Navigacija mapama
Diktafon
