MTN Products AquaCafe User manual

READ ALL DIRECTIONS
BEFORE PLUGGING
IN DISPENSER.
Important: Do not plug in
dispenser until step 4.
This guide is a general
reference to help you quickly
and easily set up your
AquaCafé.
®
SET COOLER IN
DESIRED LOCATION.
Ensure cooler is located on
a level floor, out of direct
sunlight and at least 4 inches
from a wall.
TURN ON HOT
TANK SWITCH.
Once the hot tank has been
primed, turn on the hot tank
switch that is located on
back of the cooler. Water
temperature will reach as high
as 198º F within 5 minutes.
INSERT DRIP TRAY.
Push the drip tray into the
pocket above the metal
clip on the machine to
snap it together.
WARNING TO
USERS AND PARENTS:
Adult supervision
required. Equipment
dispenses very
hot water.
INSERT WATER BOTTLE.
Use the slot on the right-hand
side of the cooler to pull the
door open. Wipe bottle cap with
paper towel. Peel the label off
the 5-gallon bottle. Remove
the bottle probe from inside the
cooler. Insert probe into bottle,
slide the bottle into cooler and
close the door. (Please wear
gloves when setting up or
replacing water bottles.)
1
PLUG IN DISPENSER.
Dispenser should always be
installed within 6 feet of a power
source. Dispenser should be
plugged into a GFCI electrical
outlet. Do not use extension cords.
Ensure hot tank switch on back of
unit is in the Off “O” position prior
to plugging in.
4
2
5
6
7
3
PURGE WATER TANKS.
The AquaCafé®has a self-priming
feature that takes approximately
5 minutes to fill both the hot
and cold tanks. After that time,
dispense water from both the hot
and cold tanks to confirm that
they have filled.
AquaCafé® is a registered trademark of MTN Products.
©2021 DS Services of America, Inc., dba Primo Water North America.
QUICK START GUIDE

STEP 1
Place coffee cup
on cupholder.
STEP 5
Open handle and
discard used K-Cup®
pod. Return K-Cup®pod
funnel holder to the
machine. Machine will
not brew without the
funnel holder.
STEP 3
Open the handle,
put K-Cup®pod
into the holder and
close the handle.
STEP 4
When the water
temperature is low, the
Water Dispense light will
flash until temperature is
reached. When it stops
flashing, press the Water
Dispense button to brew
coffee or tea.
STEP 2
Press the K-Cup®pod
button to select coffee
volume. Press again to
switch between cup sizes.
(6 oz., 8 oz. and 10 oz.)*
*Unit is designed to default
to the 8-oz. cup position.
Once a different cup size
is selected, it becomes the
default for the next brew.
Brewing Instructions
Instruction Sheet
Water Dispense Instructions
• Hot Water – Press the Hot
Water button and hold
for 1 second (the unlock
indicator ring will light up
red.) Then press the
Water Dispense button
to dispense hot water.
• Extra Hot Water for
Cooking Instant
Noodles and Soups –
Press the K-Cup®pod
or button to select the
water volume. When the
water temperature is
low, the Water Dispense
light will flash until
temperature is reached.
When it stops flashing,
press and hold the
Hot Water button for
one second, then
press the Water
Dispense button.
(Only available on
coffee models.)
• Cold Water – Cold water is
the default setting and the
unlock indicator ring will
always be blue unless hot is
selected (then it will be red).
If the unlock indicator
ring is red, press the Cold
Water button, then press
the Water Dispense button.
Otherwise, just press the
Water Dispense button.
• When the water bottle is
empty, the No Water
indicator light will flash.
* K-cup
* K-cup S, M, L;
6 oz., 8 oz., 10 oz.
Brightness
Cold Water
Hot Water
No Water Indicator
Unlock Indicator Ring
Water Dispense
1 4
5
2
3

Peel the label off the
5-gallon bottle cap.
Remove the bottle
probe from inside
the cooler.
Insert probe into bottle,
slide the bottle into
cooler and close
the door.
• Disconnect power cord
prior to cleaning the
external portion of the
brewer/cooler.
• The brewer/cooler housing
can be cleaned with a
soapy, non-abrasive
damp cloth.
• The drip tray is dishwasher
safe (top rack). To remove,
grab drip tray and pull it out.
• To clean the K-Cup®pod
funnel, remove it from the
brewer head assembly.
Wipe out K-Cup®pod
funnel holder with a damp
paper towel. Inspect
the needle assembly for
clogging (coffee grinds);
if clogged, use a paper
clip to clear the needle.
Place the K-Cup®pod
funnel in top rack of
dishwasher. CAUTION:
Needle is sharp!
• Once parts are clean,
reassemble the unit.
Connect power cord
and brewer/cooler is
ready to use.
How to Load Water Bottles
Cleaning Instructions
AquaCafé®is a registered trademark of MTN Products.
K-Cup®and Keurig®are registered trademarks of Keurig Dr Pepper, Inc.
1 2
©2021 DS Services of America, Inc., dba Primo Water North America.
