OPERATION AND PARTS MANUAL
THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALLTIMES.
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
MODEL CDM1H
HAND-HELD CORE DRILL
(ELECTRIC MOTOR)
Revision #4 (12/18/07)

PAGE 6 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
Other important messages are provided throughout this
manual to help prevent damage to your drill, other property,
or the surrounding environment.
CAUTION - Equipment Damage Hazards
ALWAYS wear approved eye and
hearing protection.
CAUTION - Eye and Hearing Hazards
ALWAYS place the core-drill's ON/OFF
switch in the OFF position when the drill
is not in use.
CAUTION - Accidental Starting Hazards
CDM1H HAND-HELD CORE DRILL— SAFETY MESSAGE ALERT SYMBOLS
Safety precautions should be followed at all times when operating
this equipment. Failure to read and understand the Safety
Messages and Operating Instructions could result in injury to
yourself and others.
FOR YOUR SAFETY AND THE SAFETY OF OTHERS!
SAFETY MESSAGE ALERT SYMBOLS
The three (3) Safety Messages shown below will inform you
about potential hazards that could injure you or others. The
Safety Messages specifically address the level of exposure
to the operator, and are preceded by one of three words:
DANGER, WARNING, or CAUTION.
HAZARD SYMBOLS
Potential hazards associated with the operation of the MQ
Model CDM1H Core Drill will be referenced with Hazard
Symbols which appear throughout this manual, and will be
referenced in conjunction with Safety Message Alert
Symbols.
You WILL be KILLED or SERIOUSLY injured if you DO
NOT follow directions.
DANGERDANGER
DANGERDANGER
DANGER
You CAN be KILLED or SERIOUSLY injured if you DO
NOT follow directions.
WARNINGWARNING
WARNINGWARNING
WARNING
You CAN be INJURED if you DO NOT follow directions.
CAUTION
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
ALWAYS wear approved respiratory
protection when required.
WARNING - Respiratory Hazards
NEVER tamper with the factory settings
of the core drill. Personal injury and
damage to the core drill can result if
operating in speed ranges above
maximum allowable.
Rotating drill bit can cut and
crush. Keep hands and feet
clear.
CAUTION - Over Speed Conditions
CAUTION - Rotating Drill Bit
This Operation and Parts Manual has been
developed to provide complete instructions for the
safe and efficient operation of the
MQ Model CDM1H
Core Drill.
Before using this core drill, ensure that the operating
individual has read and understands all instructions in this
manual.

CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07) — PAGE 7
CDM1H HAND-HELD CORE DRILL — RULES FOR SAFE OPERATION
The following safety guidelines should always be used when
operating the MQ Model CDM1H Core Drill.
GENERAL SAFETY
■ DO NOT operate or service this
equipment before reading this entire
manual.
■ This equipment should not be operated
by persons under 18 years of age.
■ NEVER operate this equipment without proper protective
clothing, shatterproof glasses, steel-toed boots, hard hat
and other protective devices required by the job.
■ NEVER operate this equipment under the influence of
drugs or alcohol .
■ NEVER operate this equipment when not feeling
well due to fatigue, illness or taking medicine.
■ NEVER operate the core drill in an
explosive atmosphere or near combustible
materials.The electric motor of this core-
drill emits sparks during operation and
shut-down. A explosion or fire could result
causing severe bodily harm or even death if the sparks
make contact with combustibe or explosive materials.
■ Maintain this equipment in a safe operating condition at
all times.
■ Keep bystanders, children and vistors away while
operating the core drill. Distractions can cause you to
loose control.
■ DO NOT wear wear loose clothing or jewelry. Contain
long hair. Keep your hair, clothing, and gloves away from
moving parts.
■ ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children.
■ ALWAYS be sure the operator is familiar with proper
safety precautions and operation techniques before using
core drill.
■ ALWAYS keep work area clean and free of foreign matter
and debris. Also keep work area well lit.
■ Avoid accidental starting. Make sure power ON/OFF
switch is off before applying power. Carrying the core-
drill with your finger on the power switch invites accidental
starting.
■ NEVER leave the core drill unattended. When not in use
always unplug the core drill from power source.
■ ALWAYS remove any adjusting keys or wrenches before
turing the core drill on. A wrench or key that is left attached
to the rotating part of the core drill may result in personal
injury.
■ DO NOT overreach. Keep proper footing and balance at
all times. Proper footing and balance enables better
control of the core drill in unexpected situations.
■ Keep all inexperienced and unauthorized people away
from the equipment at all times.
■ Become familiar with the components of the core drill
before operating.
■ ALWAYS replace any worn or damaged warning decals.
■ NEVER touch drill bit cutting edges during operation. Also
allow drill bit a sufficient amount of time to cool before
touching.
■ ALWAYS wear proper respiratory (mask),
hearing and eye protection equipment when
operating the core drill.
■ Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
■ Manufacture does not assume responsibility for any
accident due to equipment modifications.
■ NEVER use accessories or attachments, which are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
DANGERDANGER
DANGERDANGER
DANGER
Failure to follow instructions in this manual may lead to
serious injury or even death! This equipment is to be
operated by trained and qualified personnel only! This
equipment is for industrial use only.
Read this manual!

PAGE 8 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
CDM1H HAND-HELD CORE DRILL — RULES FOR SAFE OPERATION
■ Maintain the core drill and drill bits with care. Keep drill
bits sharp. Sharp cutting edges are less likely to bind.
■ If drilling into a workpiece that is unattached, use clamps
or other means to secure the workpiece so that it will not
move. NEVER hold the workpiece by hand or againist
your body.
■ Use this core drill only for its intended purpose. DO NOT
use this core drill for applications not recommended.
■ Inspect the drill after each use. Replace any damaged or
worn parts immediately. DO NOT use a defective core-
drill.
■ NEVER point the core drill at anyone in the area when
operating.
■ ALWAYS hold the core drill firmly with both hands when
drilling.
■ NEVER cover the air vents on the body of the core drill.
ALWAYS leave these vents exposed. These vents are
essential for the cooling of the electric motor. NEVER
place tape over the vent to keep out dust.
■ If a malfunction occurs, immediately unplug the core drill
from the power source and correct the problem. If the
problem can not be corrected, contact your nearest MQ
service center.
■ DO NOT force your core drill. Excerting excessive force
while drilling will damage your machine and is hazardous.
■ ALWAYS make sure drill bits are installed securely so
that it will slip or fall out. It is hazardous to use a core
drill with a loose fitted drill bit.
■ Some materials contain chemicals which may be
toxic.Take precautions to prevent dust inhalation and skin
contact.
ELECTRICAL SAFETY
■ ALWAYS test the ON/OFF switch on the core drill before
operating. The purpose of this switch is to shut down the
electric motor.
■ NEVER use a extension cord that is frayed or damaged
where the insulation has been cut.
■ NEVER carry the core drill by its power cord or disconnect
it by yanking the cord from the power outlet.
■ ALWAYS make certain that the proper extension cord
has been selected for the job. See Table 3.
■ NEVER allow power cord to lay in wate r.
■ NEVER stand in water while operating the core drill.
■ DO NOT walk around with a plugged in core drill. The
possibility exist of your finger accidently hitting the power
ON/OFF switch, causing severe bodily harm or even
death.
■ When connecting the core drill to a power receptacle,
make sure the receptacle circuit is connected to either a
GFCI receptacle or a receptacle protected by a 20 amp
circuit breaker.
■ When plugging the core-drill into a power receptacle, check
the nameplate for the correct operating voltage. Operating
the core drill at the wrong voltage will damage the electric
motor. ALWAYS read the nameplate before applying
power.
■ This core drill is equipped with a 3-prong male power
plug. DO NOT use a 2-prong adapter when plugging into
a wall outlet. This will defeat the purpose of the ground
circuit. If the plug does not fit into the receptacle, contact
a qualified electrician to install a 3-conductor wall
receptacle (outlet).
■ Avoid body contact with grounded surfaces such as pipes,
radiators, ranges and refrigerators.There is an increased
risk of electrical shock if your body is grounded.
■ DO NOT expose the the core drill to rain or wet conditions.
Water entering the drill wii increase the risk of electrical
shock.
■ When operating the core drill outside, be sure to use the
apporpriate outdoor extension cord.This type of extension
cord reduces the risk of electrical shock.
■ ALWAYS hold core drill by its insulated gripping handle
when performing work. The possibility exists of the drill
bit making contact with hidden wiring or its own cord.
Contact with a "live" wire can cause electrical shock to
the operator.
■ ALWAYS remove the AC power cord from the power
source before performing any service or maintenance on
the core drill. This preventative safety measure reduces
the possibility of accendental starting.

CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07) — PAGE 9
TRANSPORTING
■ ALWAYS place the core drill inside its carrying case when
work has been completed.
■ ALWAYS wrap power cord neatly to avoid damage.
■ ALWAYS place wrenches back into carrying case when
work has been completed.
MAINTENANCE
■ NEVER lubricate components or attempt service on a
running core drill.
■ ALWAYS allow the core drill a proper amount of time to
cool before servicing.
■ Keep the core drill in proper running condition.
■ Fix damage to the core drill immediately and always
replace broken parts. Replace with only MQ
recommended parts.
EMERGENCIES
■ ALWAYS know the location of the nearest fire
extinguisher and first aid kit.
■ In emergencies always know the location of the
nearest phone or keep a phone on the job site .
Also know the phone numbers of the nearest
ambulance , doctor and fire department . This
information will be invaluable in the case of an
emergency.
CDM1H HAND-HELD CORE DRILL — RULES FOR SAFE OPERATION

PAGE 10 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
CDM1H HAND-HELD CORE DRILL — GENERAL INFORMATION
APPLICATION
The
MQ CDM1H Hand-Held Core Drill is designed to be used for
either dry or wet drilling applications involving concrete type materials.
Up to 3-inch (76.2 mm) diameter holes can be drilled for
wet drilling
applications using
standard MQ drill bits or 5-1/8 inch (130 mm)
diameter holes for
wet or dry applications using the Cobra™ drill
bits.
Power Plant
The MQ CDM1H is powered by a 115 VAC electric motor @12
amps.Maximum RPM's is 2200 .The unit weighs 9.0 lbs (3.35 kg.)
Features
This unit is equipped with the following:
■ Adjustable Shoulder Rest.
■ Internal Water Feed System.
■ Carrying Case with Tools.
Cobra™ Drill Bits (Wet and Dry)
The Cobra™ drill bits are engineered to drill through reinforced
concrete with or without water.These bits are available in 6 or 10
inch (15.24- 25.4 cm.) drilling
depths and range in diameter
from 1 to 5 inches (25 to 127 mm.).
Standard MQ Drill Bits (Wet)
This core drill can use the following series of wet drilling bits:
■ GCB Series – economy quality small jobs.
■ GB Series – standard quality small to mid-size jobs.
■ PRB Series – premium quality for fast speeds.
■ PCB Series – super premimum quality and long life.
■ PCB Series – pro quality, high steel content and
extremely hard aggregate small jobs.
Contact the MQ Sales Department for the core
drill that best fits your application.
Figure 1. Threads/Adapters and Core Bit Combinations
snoitanibmoCtiBeroCdnasretpadA/sdaerhT.1elbaT
metInoitpircseD
1stib™arboCQMllasehctamdaerhttfahselammm81
2"
5-"1sezisretemaid—tib™arboCQM
3
-"8/5—H1MDChtiwdeilppus)275101DCN/P(retpadA
,stiberoctewtsomrofdaerhtela
m7-"4/1-1otelamef11
retemaid"3-"1
4daerhtelamef7-"4/1-1htiwtiberocteW
5tsomotstcennoc—)M85F411DAN/P(retpa
dalanoitpO
daerhtelamef11-"8/5htiwstiberoctew/yrd
6daerhtelamef11-"8/5htiwtiberoctew/yrD
Threads/Adapters and Core Bit Combinations
The CDM1H core drill is manufactured with a 18 mm male drive
shaft that connects to all MQ Cobra™ drill bits. Included is a 18 mm
female to 1-1/4" - 7 male thread adapter for most wet core bits
(1" - 3" diameter) that are manufactured with a 1-1/4"-7 female
thread lug. For core bits with a 5/8"-11 female lug, an optional
adapter (P/N AD114F58M) is available through Multiquip Parts.
See Figure 1 and Table 1 for placement and description of each
type of drill bit and adapter.

CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07) — PAGE 11
Figure 2. CDM1H Core Drill Dimensions
CDM1H HAND-HELD CORE DRILL — SPECIFICATIONS/DIMENSIONS
snoisnemiD.2elbaT
)htgneL(A .ni52.22
)mm275(
)thgieH(B .ni00.11
)mm972(
)htdiW(C .ni5.01
)mm762(
snoitacificepS.1elbaT
dleH-dnaH
llirDeroC
ledoMH1MDC
rotoMMPR0022@zH06,CAV511
tnerruCspma21
sttaW053,1
retemaiDtiBllirDelbacilppA
stiB
llirDdradnatS
hcni1
)mm52(
retemaiDtiBllirDelbacilppA
stiBllirD™arboC
sehcni5othcni1
)mm721-52(
thgieWteNyrD)
.gK4(.sbl18.8

PAGE 12 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
1. Hand-Grip – The CDM1H uses a plastic hand grip to
guard against possible electric shock. When drilling,
hold this grip firmly.
2. Reset Button – In the event of an overload press this
button. Allow a sufficient amount of time for the electric
motor (windings) to cool down before pressing the reset
button.
3. Electric Motor Brush Covers (2) – Insert tip of a flat
blade screwdriver into slot on brush cover, turn counter-
clockwise and remove cover to gain access to brushes.
4. Stock Release Adjustment Screw – This screw
provided tension for the trigger release spring. Adjust
the screw for the desire amount of spring tension.
5. Adjustable Stock – This stock slides back and forth
and is adjustable. It is provided for operator comfort.
6. Stock Release Lever – To release the stock and set
in position. Squeeze trigger lever and hold, pull back
and set in desired position, then release lever.
7. Rubber Shoulder Pad – Place this pad against your
shoulder or other parts of your body when drilling. Its
purpose is to reduce shock and vibration.
8. Drill Body –The electric motor and associated
components are contain inside the drill body.
9. AC Power Cord – Plug this 16 ft. (4.87 meters) power
cord into a 115 VAC grounded type receptacle. NEVER
remove the ground pin from the plug. This will defeat
the ground circuit and greatly increase the possibility
of electrical shock.
10. Detachable Rubber Handle – Insert the detachable
rubber handle into the desired port. Tighten securely.
11. Handle Port – The CDM1H has 3 handle ports.
12. Wrenches – These wrenches (27 mm and adjustable)
are used to install and remove the core drill bits.
13. Main Shaft – Attach core drill bit to this shaft.
14. Water Shut-off Valve – Turn this valve downward to let
water flow and up to stop.
15. Water Tube/Adapter – Connect this tube/adapter to a
water source. Typically a garden hose.
16. Grease Plug– Using a 5 mm hex wrench, remove this
plug to add lubrication grease. DO NOT over fill.
17. ON/OFFTrigger– Squeeze this trigger to start the drill,
and release to stop.
18. Core Drill Bit– Place bit onto main shaft and tighten
securely. Contact MQ sales department for the core
drill bit that best fits your application.
19. Adapter – 1-1/4" X 7 female to 18 mm male thread for wet
drilling bits from 1-1/2 inch diameter and above.
Figure 3. CDM1H Components
CDM1H HAND-HELD CORE DRILL — COMPONENTS

CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07) — PAGE 13
CDM1H HAND-HELD CORE DRILL — PRE-SETUP
Before Starting:
CAUTION - Read Manual
Before attempting to operate
this core drill, and to avoid
serious injury to personnel,
always read and understand
operation manual. Failure to
read and understand operation
manual could result in serious
harm or even death!
NEVER operate the core drill in a confined
or enclosed area structure that does not
provide ample
free flow of air .
Warning - Toxic Fumes
DANGER - Flammable/Combustible Materials
NEVER operate the core drill in or around
flammable materials. The core drill emits
sparks, if contact is made between the
sparks and the flammable material,the
posibility exists of fire or explosion causing
damage to the equipment and severe bodily
harm even death!
Drilling with a MQ Cobra™ Bit
The drilling of clean holes with Cobra™ core bits (1) requires an
operating technique utilizing the center drill bit adapter (2). Center
drill bit adapters are included with the core bit. As bits wear out,
this adapter may be used with future core bits of similar depth
and diameter.The adapter bit permits an anchoring point (3) so
the bit can be accurately introduced into the surface (4). Once
the hole is started, the center drill bit adapter (2) must be removed.
See Figure 4.
Figure 4. Drilling with a MQ Cobra™ Bit
Drilling With Standard DRY/WET Core Bits
With the proper adapter, 1" to 3" diameter dry/wet core bits can
be used with the CDM1H when drilling vertical and horizontal
holes. All hand-held core drills require practice and operator
technique to ensure consistent clean drilled holes. When using
wet core bits, water MUST be used to ensure proper cooling.
“Bit chatter” around the hole can be eliminated by various
techniques such as angle-entry procedures and fabricated
guides. Angle-entry is one safe and simple way to start the bit
onto the surface. Angle the bit (1) at 10°-15° above the surface
and slowly introduce the bit until it is flush with the surface (2).
See Figure 5.
Figure 5. Drilling with a Standard DRY/WET Core Bit

PAGE 14 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
CDM1H HAND-HELD CORE DRILL — PRE-SETUP
Attaching the Cobra™ Core Bit to the Core Drill
1. Place the core bit and core drill on a suitable workbench or
area that is free of clutter dirt and debris.
2. Before installing the core bit make sure that thepower cord
of the core drill is unplugged from the AC wall receptacle.
NEVER install the core bit on core drill that has power applied
to it.
3. Screw the core bit onto the main shaft of the core drill by
turning it clockwise by hand until tight (Figure 4).
4. Using the supplied wrenches ( 27 mm and adjustable)
continue to tighten the core bit. When using the wrenches,
apply pressure in the opposite direction to fully tighten.
5. Insert the detachable handle into the desired handle port.
Figure 6. Attaching the Cobra™ Core Bit to the Core Drill
Connecting Water to the Core Drill
1. Attach the supplied water hose and garden hose fitting to the
core drill as shown in Figure 5. Be sure to place worm-clamps
on each end of the hose to prevent leaking.
Figure 7. Connecting the Water
Adjusting the Stock (Shoulder Rest)
1. The CDM1H is supplied with an adjustable stock.This stock
can be adjusted by simply squeezing the trigger and sliding
the stock back and forth to the desired position Figure 6).
2. If more spring tension is required (trigger lever), simply adjust
the spring tension bolt until the desired spring tension is
obtained.
Figure 8. Adjusting the Stock
With the proper adapter, 1" to 3" diameter dry/
wet core bits can be used with the CDM1H when
drilling vertical and horizontal holes. See
General Information section. Different size
wrenches may be required depending on the
type of the core bit lug.

CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07) — PAGE 15
Applying Power to the Core Drill
1. This core drill requires 115 VAC, 60 Hz power. Applying
power to the drill that is not specified will cause severe
damage to the core drill. Always read serial plate tag
before applying power to the core drill.
2. The power plug on this core drill is a 3-prong grounded
type plug. ALWAYS connect this plug to a 3-prong
grounded receptacle. NEVER plug this device into a 2-
prong type receptacle.This will defeat the ground circuit.
The use of a 3-prong to 2-prong adapter is strictly
prohibited.
3. Connect the core drill's AC power cord to a 115 VAC wall
receptacle (Figure 7) that is protected by a 20 amp
circuit breaker. For best results connect the power cord
to a GFCI receptacle.
To avoid accidental starting, ALWAYS
keep fingers away from the power OFF/
ON switch when applying power.
Warning - Accidental Starting
CDM1H HAND-HELD CORE DRILL — PRE-SETUP
Figure 9. Connecting the Power
POWER
CORD
(POWER ON)
WET
HANDS
During operation of this core drill, there
exists the possibility of
electrocution,
electrical shock or burn,
which can cause
severe bodily harm or even DEATH!
To avoid these hazards:
NEVER use damaged or worn cables when plugging the
core drill into an AC power receptacle.
NEVER grab or touch a live power
cord with wet hands.
NEVER stand in water and touch a
live power cord.
DANGER - ELECTROCUTION HAZARDS
)noitarepOesahPelgniS,zH06(noitceleSelbaC.3elbaT
nitnerruC
serepmA
nIdaoL
sttaW htgneLelbaCelbawollAmumixaM
021tA
stloV eriW01#eriW21#eriW41#eriW61#
5.2003.tf0001.t
f006.tf573.tf052
5006.tf005.tf003.tf002.tf521
5.7009.tf053.tf002.tf521.tf001
010021.tf052.tf051.tf001
510081.tf051.tf001.tf56
020042.tf521.tf57.tf05
.egatlovwolmorftlusernacegamadtnempiuqE:NOITUAC

PAGE 16 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
CDM1H HAND-HELD CORE DRILL — OPERATION
Before Operating
1. Place the valve on the water source to the ON position, and
then turn the water valve on the core drill (Figure 8) to the
ON position (down). Verify that water is flowing smoothly
and evenly.
This core drill can whip violently if it comes in contact with
rebar or coarse material which would cause the shaft to
bind. Be extremely careful at all times when drilling. The
possibility exists of the core drill severely twisting the wrist
or striking the body with excessive force.
Warning - Binding of Output Shaft
Figure 11. Wall Drilling Application
Figure 12. Floor Drilling Application
NEVER use the adjustable shoulder stock to
pull the bit out of the ground if the bit gets stuck
in the hole.
ALWAYS be on the lookout for exposed wiring
or buried electrical connections when drilling.
ALWAYS drill with uniform pressure and keep
the bit straight. When drilling through steel
rebar, reduce the pressure to avoid overloading
the motor.
2. If water is not flowing, check all connections and correct the
problem.
3. Place the core drill against the surface (Figures 9 and 10) to
be drilled. Hold drill firmly, and squeeze the power ON/OFF
switch to begin drilling.
DO NOT overreach. Keep proper footing and
balance at all times. Proper footing and
balance enables better control of the core drill
in unexpected situations.
Figure 10. Water Valve (ON Position)

CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07) — PAGE 17
CDM1H HAND-HELD CORE DRILL — SHUTDOWN/MAINTENANCE
Shutdown
1. Remove the power cord from the wall receptacle or power
source.
2. Allow a sufficient amount of time for the core drill bit to cool
before attempting to remove it from the core drill.
3. Using the wrenches as illustrated in Figure 4, remove the
core drill bit from the drill.
4. Clean the drill bit with a mild cleaning solution, removing
dirt and foreign matter.
5. Once the core drill has been cleaned, place the core drill
into its carrying case along with all associated hardware. Be
sure to wrap the power cord neatly into the carrying case.
This will extend the life of the cord.
6. Store the carrying case out of the reach of children, in a
location that is moisture free.
Maintenance
1. The CDM1H basically is maintenance-free. The only
maintenance requirement is to periodically check the main
gear grease level.
2. Using the supplied 5 mm allen wrench, remove the grease
plug as shown in Figure11.Figure 8. Wall Application
3. Visually inspect to see if grease is present. It may be
necessary to insert a small blade screw driver or similar
device into the filler hole to determine if the grease level is
low.
4. If the grease level is low, apply 1 shot of lithium base grease,
grade N0.1. DO NOT over fill.
5. Reinstall grease plug and tighten securely.
Figure 13. Main Gear Lubrication

PAGE 18 —CDM1H CORE DRILL — OPERATION AND PARTS MANUAL — REV. #4 (12/18/07)
CDM1H HAND-HELD CORE DRILL — TROUBLESHOOTING
GNITOOHSELBUORTLLIRDEROC.4ELBAT
MOTPMYS MELBORPELBISSOP NOITULOS
.kcutssitiB
si.cte,enotsrorableetS
.TIBdnaerocneewtebthguac .FFOHCTIWSnrutetaidemmI
sahpittib,raewevissecxE
.knahshtiwhsulfemoceb .tuotitfilotrennapsgnisusnoitceridhtobniTIBetatorotyrT
.TIBecalpeR
lamronniwolssignillirD
.noitarepo
detanimatnocsiretawetsaW
gnittucsiLLIRD,pihcleetshtiw
.raber
saosnoerusserpehttsujdA.retawretsawehtkcehcyletaidemmI
.ROTOMdaolrevootton
.nrowsitiB .TIBecalpeR.noisarbarofTIBkcehcyletaidemmI
PITnodesopxetonsidnomaiD
.ecafrus .TIBsserD.noisarbarofTIBkcehcyletaidemmI
TIBnodetisopederaspihC
.ecafrus
.erusserpdeefretawesaercnI.noisarbarofTIBkcehcyletaidemmI
.eriwahtiwTIBhsurBrosserD
TIBnodehcrocseraspihcleetS
.ecafrus .spihcleetsevomeR.noisarbarofTIBkcehcyletaidemmI
