MultiTable KEYBOARD & MOUSE TRAY User manual

Copyright ©2016 MultiTable LLC. All rights reserved.
MTK1203-05 (Assembly Manual) | V.1.0716 | Printed in U.S.A.
Articulating Keyboard & Mouse Tray
ASSEMBLY MANUAL

DO NOT SCREW
BOX CONTENTSBOX CONTENTSBOX CONTENTSBOX CONTENTSBOX CONTENTS
Step 1: Attach palm rests to the keyboard platform
1. Secure the wrist pads (item H) on the keyboard platform (item G) by using
the (4) silver M4 x 15” bolts included in the keyboard platform packaging
a. Secure the wrist pads by placing a screw at each end of the wrist pads
using the pre-drilled holes
Step 2: Mount Keyboard tray to articulating arm assembly
2. Gather the (4) black #8-32 x ½” Screws and (4) black #8 – 32 flange nuts
a. Use the (4) screws and (4) flange nuts to attach the platform (item G) to the
articulating arm (item A)
Important:
1. Please do not use a power drill
to assemble the armrests.
2. Flange nuts must be fully tightened
to ensure nut is locked.
Step 3: Attach palm rests to the keyboard platform
3.Screw the mounting track (item B) ½ inch from the edge into the
underside surface of the table top
a. Screw the two screws into the pre-drilled holes on each corner
of the mounting track (item B)
Step 4: Slide articulating arm assembly into tray and attach track
cap and bumper
4. Slide the articulating arm assembly (item A) into the mounting
track
5. Install the bumper (item F) on the end of the mounting track
Step 5: How to adjust the tray
PAGE 1 | Articulating Keyboard & Mouse Tray PAGE 2 | Articulating Keyboard & Mouse Tray
