Muvi KX-1 User manual

User Manual
VCC-008-KX1-NPNG
VCC-008-KX1-NPNG Manual.indd 1 27/02/2018 09:24

2 3
Contents
What’s in the box 3
Guide to controls 4
Descripon of LED indicators 6
Charging and installing the baery 7
Geng started 8
Touch controls 9
Viewing and transferring les 16
Download and install app 17
Specicaons 18
Accessories 20
Camcorder maintenance ps 21
1. What’s in the box?
1. KX-1 NPNG Camera
2. Baery
3. Waterproof case
4. Quick release frame
5. Curved & at adhesive mounts
6. Helmet Mount
7. USB cable
8. An-fog inserts
9. Lens cloth
10. Decals
11. microSD card
12. User manual
1
2
3
4
5
6
7
8
9
VCC-008-KX1-NPNG Manual.indd 3 27/02/2018 09:24

4 5
2. Guide to controls
1. Stop Recording Buon
2. Shuer Buon
3. Green Indicator Light (L1)
4. Blue WiFi Indicator Light (L2)
5. WiFi Buon
6. Power Buon/Record Buon
7. Baery Cover
8. Microphone
9. Wide Angle Lens
1
2
3
4
5
76
9
8
10. Green Indicator Light (L1)
11. Red Indicator Light [L3]
12. Built-in Touch LCD Screen
13. Speaker
14. Micro HDMI Port
15. microSD Card Slot
16. Micro USB Port
12
16
13
14
15
10
11
VCC-008-KX1-NPNG Manual.indd 5 27/02/2018 09:24

6 7
3. Description of LED indicators 4. Installing and charging
the battery
Slide the baery cover as shown, then insert the baery and close the cover.
To charge your baery, connect the supplied USB cable to a computer or 5V/2A
USB plug.
The red indicator light (L3) will ash when charging the baery. When it is fully
charged, the light will remain solid.
Baery life - Up to 2 hours, depending on the resoluon and framerate used.
Charging me - Up to 2 hours, depending on the charger used.
Please note: To prevent damage, to the baery, remove when operang the camera for long periods whilst
plugged into a power source.
Status Green Light (L1) Blue Light (L2) Red Light (L3)
Recording Video Flashing Solid
Recording Audio Flashing Solid
Taking Photo Single Flash Solid
microSD Card Full Solid Solid
WiFi On Flashing Solid
Charging Flashing
Power On Solid
Fully Charged Solid
Low Baery Solid
Data transmission Solid
VCC-008-KX1-NPNG Manual.indd 6-7 27/02/2018 09:24

89
5. Getting started
Inserng a microSD card
When the camera is turned o,
slide the microSD card into the
microSD card slot with the label
facing the front of the camera.
When the microSD card is fully
inserted, it will click into place.
Turning the camera on/o
Press and hold the power/record
buon for roughly 3 seconds to
turn the camera on or o.
A microSD card with UHS class 3
(U3) speed is recommended.
Tap the Video Icon to enter Video Mode
Tap the Camera Icon to enter Photo Mode
Tap the Burst Icon to enter Burst Photo
Mode
Tap the Interval Shoong Icon to enter
Interval Shoong Mode
Tap the Library Icon to view photos
and videos
Tap the Seng Icon to change sengs
1. Indicates Modes Selected
2. Record Time
3. Baery Level
4. Video Resoluon & Viewing Angle
5. Enter Main Menu
6. Remaining Record Time
6. Touchscreen controls
4
Tap the “X” in the top le-hand corner to
exit main menu.
21
5
3
6
Main Menu
Default View
VCC-008-KX1-NPNG Manual.indd 8-9 27/02/2018 09:24

10 11
Funcon Descripon
Record: Select to record video with audio
Video Only: Select to record video only
Audio Only: Select to record audio only
Video Modes Slow Moon: Select to record a slow moon video
Interval Record: Set me for Interval Record - 1s/2s/5s/10s/30s/60s. To take
a sequence of frames at set intervals to record changes that take place slowly
over me. (Time-lapse)
Auto Record: Set me for Auto Record - 5s/10s/20s
Video + Photo: Set me to take photo(s) during video recording Manual/5s/10s/30s/60s
Resoluon Select Video Resoluon: 4k@10fps, 2.7k@15fps, 1440P@30fps,
1080P@60fps/30fps, 720P@120fps/60fps, 480p@240fps
Viewing Angle Select Viewing Angle: Ultra Wide, Wide, Medium
Bit Rate Select Bit Rate: High, Normal
Auto Overwrite Turn Auto Overwrite: On/O When Auto Overwrite is turned on, it will
record over exisng les when microSD card is full
180⁰ Image Flip Turn Auto Image Rotaon: On/O Turn Auto Image Rotaon on to have
the camera automacally adjust right side up when mounted upside down
Time Stamp Turn Auto Time Stamp: On/O Turn Time Stamp on to show the current day,
month, year, and me in the recorded le
Video Mode Photo Mode
Funcon Descripon
Tap Shuer: If turned on, tap screen to take a picture
Burst: Select Burst Mode: 3 photos/1s, 5 photos/1s, 10 photos/1s
Photo Modes Interval Shoong: Sets Frequency for pics to be taken:
1s, 2s, 3s, 5s, 10s, 30s, 60s
Self Timer: Pics will be taken automacally aer seng me: 2s, 3s, 5s, 10s
Resoluon Select Image Resoluon: 16MP (4608x3456 4:3), 12MP (4000x3000 4:3),
8MP (3200x2400 4:3)
Time Stamp Turn Time Stamp: On/O Turn Time Stamp on to show the current day,
month, year, and me in the le
Please note: We recommend using the camera at 1080p/60fps for the best results.
VCC-008-KX1-NPNG Manual.indd 10-11 27/02/2018 09:24

12 13
Sengs Mode
Funcon Descripon
Sound Turn Sound on to hear beeping indicators
G-Sensor Turn G-Sensor on to start recording (in video mode) when camera moves.
Camera will stop recording when moving stops aer 3 minutes.
WiFi Mode On your mobile device, turn the Wi-Fi on and download the Veho Muvi app
from the Google Play or Apple Store. Press and hold the Wi-Fi Buon for 3
seconds to turn on the camera Wi-Fi. Go to Wi-Fi sengs on your mobile
device, nd and select the Muvi-KX1/2, then enter the password: VehoMuvi.
Launch the Veho Muvi app and click on the Camera buon in the app.
Bluetooth Mode Select search mode to connect with a sele sck
Status Indicator Turn on to see camera status funcons
Screen Display Turn on to see Camera Mode, Record Time, Power Level, Resoluon, Viewing
Angle, Menu Buon, and Remaining Record Time.
Sengs Mode
Funcon Descripon
Sleep Mode Camera will enter power-saving state when no user acvity has been sensed
for a certain me: O, 2 mins, 5 mins, 10 mins.
White Balance Select the appropriate seng according to the lighng condions of the
applicaon scenario.
Stabilizaon Digial image stabilizaon: on/o
Display Standby Display will be automacally turned o when no user acvity has been sensed
for a certain me: O, 10 secs, 30 secs, 60 secs.
TV Output Select PAL or NTSC
Language Select Tradional Chinese, English (default), German, French, Italian, Spanish,
Portuguese, Dutch, Turkish, Russian, Hungarian, Danish, Finnish, Norwegian,
Sweden, Greek, Polish, Czech.
VCC-008-KX1-NPNG Manual.indd 12-13 27/02/2018 09:24

14 15
Sengs Mode
Funcon Descripon
Date/Time Select Date & Time format: M/D/Y H:M, D/M/Y H:M, Y/M/D H:M
Format SD Card Conrm to delete all les on microSD card
Restore Defaults Conrm to Restore Factory Sengs
Version Displays soware version
Library
Displays all video & audio les
Displays all photo les
Displays all video, audio & photo les
Tap on thumbnail to open any le.
Click on the square on the top le-hand corner of the
thumbnail to select each le.
Aer selecng 1 or more les, three yellow opon squares
(¡¡¡) appear in the top right-hand corner.
Tap on the three yellow opon squares (¡¡¡) to delete and
lock the les selected.
Tap the “X” in the top le-hand corner to
exit the library.
VCC-008-KX1-NPNG Manual.indd 14-15 27/02/2018 09:25

16 17
8. Viewing and transferring files
Copying les to a computer
1. Connect the Micro USB cable to the camera and a computer, with the microSD
card in the camera.
2. Turn the camera on.
3. Go to “My Computer”/”This PC” on Windows or the desktop on Mac OS.
4. Open the SD card folder and copy the les to your computer.
Viewing Photos and Videos on a TV
To playback photos/videos on a TV, check the Muvi is set to the correct mode (PAL/
NTSC) and then enter playback mode on the camera. Then connect a HDMI cable to
the camera from the TV.
9. Using the Wi-Fi app.
1. On your mobile device, turn the Wi-Fi on and
download the Veho Muvi app from the Google
Play or Apple Store.
2. Press and hold the Wi-Fi Buon for 3 seconds
to turn on the camera Wi-Fi.
3. Go to Wi-Fi sengs on your mobile device,
nd and select the Muvi KX-1/KX-2,
then enter the password: VehoMuvi.
4. Launch the Veho Muvi and click on the
Camera buon in the app.
Please note: The G-Sensor and Wi-Fi cannot be enabled simultaneously.
VCC-008-KX1-NPNG Manual.indd 17 27/02/2018 09:25

18 19
10. Specifications
Camera
Lens Angle 140°
Aperture 2.5f
Screen 1.8“ Touchscreen integrated
Video
Video Resoluon 4k@10fps, 2.7k@15fps, 1440P@30fps, 1080P@60fps/30fps,
720P@120fps/60fps, 480p@240fps
Video Mode Record, Video Only, Audio Only, Slow Moon, Interval Record,
Auto Record, Video + Photo
Auto Record 5s, 10s, 20s
Self Timer 2s, 3s, 5s, 10s
Interval Record 1s, 2s, 5s, 10s, 30s, 60s
Photo Resoluon 16MP, 12MP, 8MP
Photo Mode Tap Shuer, Burst, Self Timer, Interval Shoong
Burst Mode 3 photos/1s, 5 photos/1s, 10 photos/1s
Photo & Video 5s, 10s, 30s, 60s or Manual
Self Timer 2s, 3s, 5s, 10s
Interval Shoong 1s, 2s, 3s, 5s, 10s, 30s, 60s
Power & Baery
Baery 1050mAh
Baery Life Up to 2 hours, depending on the resoluon and framerate used
Charging Time Up to 2 hours, depending on the charger used
Other
Interface Micro USB, Micro HDMI, microSD
Memory microSD card (up to 64GB)
Operang Temperature 0°C to 60°C
Storage Temperature -20°C to 60°C
Weight 67g
Dimension 52mm x 26mm x 40mm
Funcons
Other Funcons Built-In WiFi, Built-In Bluetooth, 4x Digital Zoom, Video Loop,
Auto Record, 180° Image Flip, Sleep Mode (2min, 5min, 10min)
VCC-008-KX1-NPNG Manual.indd 18-19 27/02/2018 09:25

20 21
11. Accessories
Waterproof Case
Quick Release Frame
Quick Release Buckle
& Thumb Screw
n Please charge the baery every 3 months to maintain baery life.
n To view or upload videos/images at the best quality, copy the les to your
computer rst.
n If your video les are corrupt, try reformang the microSD card with the
camera. To do this, go into the sengs mode, locate the format SD card opon
and press conrm.
n It is normal for the camera to become warm during use, the camera will turn
o automacally it if overheats.
n Turn o the camera before inserng the microSD card.
n While it is possible to use the camera while the baery is charging, you run
the risk of shortening the baery life and damaging it.
12. Camera maintenance tips
VCC-008-KX1-NPNG Manual.indd 20-21 27/02/2018 09:25
