MVP ikon IT28R User manual

REACH INS-TOP MOUNT
Installation, Operation and Maintenance Manual
Please read this manual completely before attempting to install or operate this equipment.
Notify carrier of damage! Inspect all components immediately.
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS!
Printed 05/2020
5659 Royalmount Avenue
Montreal, Qc, Canada H4P 2P9
Tel.: [phone] / Toll Free: 888.275.4538
Fax.: [phone] / Toll Free: 877.453.8832
3560 NW 56th Street
Fort Lauderdale, FL 33309
Tel.: [phone] / Toll Free: 844.218.8477
Fax.: [phone]

Service and Installation Manual
2
CONTENTS
RECEIVING & INSPECTING EQUIPMENT..................................................................................2
SPECIFICATIONS ..........................................................................................................................................3
INSTALLATION....................................................................................................................................4
OPERATION….......................................................................................................................................................5
MAINTENANCE..........................................................................................................................7
WIRING DIAGRAM .......................................................................................................9
All rights reserved. Reproduction of this manual without written permission is prohibited.
SERIAL NUMBERINFORMATION
The serial number of all self-contained refrigerators and freezers is located inside the unit on the left hand
side near the top on the wall.
Always have the serial number of your unit available when calling for parts or service.
This manual covers standard units only. If you have a custom unit, consult the Technical Support Department
at 1-888-275-4538; 514-737-9701.
RECEIVING AND INSPECTING THEEQUIPMENT
Even though most equipment is shipped crated, care should be taken during unloading so the equipment is not
damaged while being moved into the building.
1. Visuallyinspect the exterior of the package and skid or container. Any damage should be noted on the
delivery slip and reported to MVP Group immediately at 1-888-275-4538; 514-737-9701.
2. If damaged, open and inspect the contents with the carrier.
3. WITHIN 48 HOURS OF RECEIPT: In the event that the exterior is not damaged, yet upon opening, there is
concealed damage to the equipment, notify MVP Group immediately at 1-888-275-4538; 514-737-9701.
4. Be certain to check the compressor compartment housing and visually inspect the refrigeration package. Be
sure lines are secure and base is stillintact.
5. Retain all crating material until an inspection has been made or waived.

Service and Installation Manual
4
INSTALLATION
Location
Units represented in this manual are intended for indoor use only. Be sure the location chosen has a floor
strong enough to support the total weight of the cabinet and contents. A fully loaded unit can weigh as much
as 1500 pounds. Reinforce the floor as necessary to provide for maximum loading. For the most efficient
refrigeration, be sure to provide good air circulation inside and out.
Inside Cabinet
Do not pack the units so full that air cannot circulate. The refrigerated air is discharged at the top rear of the
unit. It is important to allow for proper air flow from the top rear to the bottom of the unit. Obstructions to this
air flow can cause evaporator coil freeze ups and loss of temperature or overflow of water from the
evaporator drain pan. The shelves have a rear turn up on them to prevent this. However, bags and other
items can still be located to the far rear of the cabinet. Air is brought into the evaporator coil with fans.
Prevent any obstruction from blocking the outlet or inlet of air flow.
Outside Cabinet
Be sure that the unit has adequate air circulation around it. Avoid hot corners and locations near stoves and
ovens.
It is recommended that the unit be installed no closer than 2" from any wall with at least 12" of clear space above
the unit.
Leveling
Levelling the cabinet is necessary so that the doors will line up with the frames properly. Use a level to make
sure the unit is level from front to back and side to side. Units supplied with legs will have adjustable bullet feet to
make the necessary adjustments. If the unit is supplied with casters, no adjustments are available. Ensure
the floor where the unit is to be located islevel.
Stabilizing
All models are supplied with casters for your convenience. It is very important, however, that the cabinet be
installed in a stable condition with the front wheels locked while in use.
Should it become necessary to lay the unit on its side or back for any reason, allow at least 24 hours before
start-up to allow compressor oil to flow back to place. Failure to meet this requirement can cause
compressor failure and unit damage.
Warranty Repairs will be declined if problems are caused by improper installation.
NOTE
Electrical Connection
Refer to the amperage data on page 3, the serial tag, your local code or the National Electrical Code to be sure
the unit is connected to the proper power source. Each unit must be pluggedon adedicated electric circuit.. Do
not use an extension cord. An external electrical surge protector may berequired. (not included)
DANGER
The unit must be turned OFF and disconnected from the power source whenever
performing service, maintenance functions or cleaning the refrigerated area.

Serviceand InstallationManual
5
OPERATION
CAUTION
Do not throw items into the storage area. Failure to heed these recommendations could result in damage to
the interior of the cabinet.
Refrigerated cycle
Refrigerators: During the refrigeration cycle, the evaporator fans will run continuously even when one or
more doors are open. The door switch will activate the lights when opened.
1. Every 6 hours, the unit will turn off and to allow the evaporator coil to defrost. The controller now
displays defrost symbol. When the coil temperature reaches 41°F or after 20 minutes of defrost , the unit
will turn on again.
2. The factory setting for the temperature range is 34° to 38°F.
Freezers: During the refrigeration cycle, the controller supplies power to the condensing unit and
evaporator fan motors. The evaporator fans will run at any time when the evaporator coil temperature is
below 54° F. They will also keep running when door is open but cycle off during a defrost period. The door
switch will activate the lights when opened.
1. Every 6 hours, the unit will turn off and electric heater will turn on to defrost. The controller now
displays the defrost symbol. When the coil temperature reaches 45°F or after 20 minutes of defrost, the
unit will turn on again.
2. Anti-condensation heaters on door frames work in conjunction with thecompressor.
3. The factory setting for temperature range is -7° to-3°F
SOLID STATETHERMOSTATCONTROLLER
1. FRONTPANELCOMMANDS
Todisplay target set point; in programming mode it selects a parameter or confirm an operation.
Tostart a manual defrost
Toview the last alarm occurrence; in programming mode it browses the parameter
codes or increases the display value
Toview the last alarm occurrence; in programming mode it browses the parameter codes or
decreases the display value
KEY COMBINATION
Tolock & unlock the keyboard
Toenter in programming mode
To return to the room temperature display

Service and Installation Manual
6
1.1 Function of LEDS
LED
MODE
FUNCTION
ON
Compressor enabled
Flashing
-ProgrammingPhase(flashingwith )
- Anti-short cycle delay enabled
ON
Defrost enabled
Flashing
- ProgrammingPhase(flashingwith )
- Driptimein progress
ON
Fans enabled
Flashing
Fans delay after defrost in progress.
ON
An temperature alarm happened
2. MAIN FUNCTIONS
2.1 HOW TO SEE THE SETPOINT
1. Push and immediately release the SET key: the display will show the set point value.
2. Push and immediately release the SET key or wait for 5 seconds to display the
sensor value again.
2.2 HOW TO CHANGE THE SETPOINT
1. Hold the SET key for more than 2 seconds to change the set pointvalue.
2. The value of the set point will be displayedand the LED startsblinking.
3. Tochange the set value, push the or key within 10s.
4. Toset new point value, push the SET key again or wait10s.
2.3 HOW TO START A MANUAL DEFFROST
Hold the key for more than 2 seconds and a manual defrost willstart
2.4 HOW TO LOCK THE KEYBOARD
1. Hold the and keys for more than 3s.
2. The “ POF ” message will be displayed and the keyboard will be locked. At this point, it will be possible only
to see the set point or the MAX or Min temperaturestored.
3. If a key is pressed more than 3s the ” POF ” message will be displayed.
2.5 HOW TO UNLOCK THE KEYBOARD
Hold the and keys together for more than 3s until the “ POF ” message is displayed.
3. ALARM SIGNALS
HOW TO SEE THE ALARM AND
RESET THE RECORDED ALARM
1. Push the or key to
display the alarm signals.
2. When the signal is displayed, hold
the SET key until the “ rst ” message
is displayed, and push the SET key
again. The “ rst ” message starts
blinking and the normal temperature
will be displayed.
Message
Cause
Outputs
“P1”
Room probe failure
Compressor output according to par.
“Con” and “COF”
“P2”
Evaporator probe failure
Defrost end is timed
“HA”
Maximum temperature alarm
Outputs unchanged.
“LA”
Minimum temperature alarm
Outputs unchanged.
“dA”
Door open
Compressor and fans restarts
“EA”
External alarm
Output unchanged.
“CA”
Serious external alarm (i1F=bAL)
All outputs OFF.
“CA”
Pressure switch alarm (i1F=PAL)
All outputs OFF

Serviceand InstallationManual
7
MAINTENANCE
DANGER
The unit must be turned OFF and disconnected from the power source whenever
performing service, maintenance functions or cleaning the refrigerated area.
Refrigerators and Freezers
The interior and exterior can be cleaned using soap and warm water. If this isn't sufficient, try ammonia and
water or a nonabrasive liquid cleaner. When cleaning the exterior, always rub with the "grain" of the stainless
steel to avoid marring the finish.
Do not use an abrasive cleaner because it will scratch the stainless steel and plastic and can damage the
breaker strips and gaskets.
Cleaning the Condenser Coil
The condenser coil requires regular cleaning and it is recommended every 90 days. In some instances, you
may find that there is a large amount of debris and dust or grease accumulated prior to the 90 day time frame.
In these cases the condenser coil should be cleaned every 30 days.
If the build up on the coil consists of only light dust and debris, the condenser coil can be cleaned with a simple
brush. Heavier dust build-up may require a vacuum or even compressed air to blow through the condenser
coil.
If heavy grease is present, there are de-greasing agents available for refrigeration use and specifically for the
condenser coils. The condenser coil may require cleaning with the de-greasing agent and then blown through
with compressed air.
Failure to maintain a clean condenser coil can initially cause high temperatures and excessive run times.
Continuous operation with dirty or clogged condenser coils can result in compressor failures. Neglecting the
condenser coil cleaning procedures will void any warranties associated with the compressor or cost to replace
the compressor.
DANGER
Never use a high pressure water wash for this cleaning procedure as water can damage the
electrical components located near or at the condenser coil.
In order to maintain proper refrigeration performance, the condenser fins must be cleaned of dust, dirt and
grease regularly. It is recommended that this be done at least every three months. If conditions are such that
the condenser is totally blocked in three months, the frequency of cleaning should be increased. Clean the
condenser with a vacuum cleaner or stiff brush. If extremely dirty, a commercial-grade condenser cleaner may
be required.
Stainless Steel Care and Cleaning
To prevent discoloration of rust on stainless steel several important steps need to be taken. First, we need to
understand the properties of stainless steel. Stainless steel contains 70-80% iron which will rust. It also contains
12-30% chromium which forms an invisible passive film over the steels surface which acts as a shield against
corrosion. As long as the protective layer is intact, the metal is still stainless. If the film is broken or
contaminated, outside elements can begin to breakdown the steel and begin to form rust of discoloration.
Proper cleaning of stainless steel requires soft cloths or plastic scouring pads,
NEVER USE STEEL PADS, WIRE BRUSHES OR SCRAPERS!
DANGER

Service and Installation Manual
8
MAINTENANCE
Cleaning solutions need to be alkaline based or non-chloride based. Any cleaner containing chlorides will
damage the protective film of the stainless steel. Chlorides are commonly found in hard water, salts, and
household and industrial cleaners. If cleaners containing chlorides are used, be sure to rinse and dry
thoroughly.
Routine cleaning of stainless steel can be done with soap and water. Extreme stains or grease should be
cleaned with a non-abrasive cleaner and plastic scrub pad. It is always good to rub with the grain of the steel.
There are also stainless steel cleaners available which can restore and preserve the finish of the steel’s
protective layer.
Early signs of stainless steel breakdown can consist of small pits and cracks. If this has begun, clean
thoroughly and start to apply stainless steel cleaners in attempt to restore the passivity of the steel.
Never use an acid based cleaning solution！Many food products have an acidic content
which can deteriorate the finish. Be sure to clean the stainless steel surfaces of ALL food
CAUTION products.
Gasket Maintenance
Gaskets require regular cleaning to prevent mold and mildew build up and also to keep the elasticity of the
gasket. Gasket cleaning can be done with the use of warm soapy water. Avoid full strength cleaning
products on gaskets as this can cause them to become brittle and prevent proper sealing. Do not use
sharp tools or knives to scrape or clean the gasket which could possiblytear the gasket and rip thebellows.
Gaskets can easily be replaced and don’t require the use of tools or authorized service technicians.
The gaskets are "Dart" style and can be pulled out of the groove in the door and replaced by pressing the
new one back into place.
Doors/Hinges
Over time and with heavy use, door hinges may become loose. If the door is beginning to sag, tighten the
screws that mount the hinge brackets to the frame of the unit. If the doors are loose or sagging, this can cause
the hinge to pull out of the frame which may damage both the doors and the door hinges.
Drain Maintenance
Each unit has a drain located inside the unit which removes the condensation from the evaporator coil
and evaporates it into an external condensate evaporator pan. The drain can become loose or
disconnected from moving or bumping. If you notice excessive water accumulation on the inside of the unit,
be sure the drain tube is connected from the evaporator housing to the condensate evaporator drain pan. If
water starts to collect underneath the unit, you may want to check the condensate evaporator drain tube to
be sure it is still located inside the drain pan. The leveling of the unit is important as the units are
designed to drain properly when on a level surface, if your floor is not level, this can also cause drain
problems. Be sure all drain lines are free from obstructions because this may cause water to back up and
overflow the drain pans.

Serviceand InstallationManual
9
ELECTRICALDIAGRAM
MODEL：IT28R
MODEL：IT56R
CONDENSER FAN
CONDENSER FAN

10
Service and Installation Manual
ELECTRICALDIAGRAM
MODEL：IT82R
MODEL：IT28F
N
L
PLUG
CONTACTOR
OVERLOAD
PROTECTOR
LAMP
M
M
CONDENSER
COMPRESSOR
FAN
THERMOSTAT DISPLAY
CURRENT
RELAY
ROOM EVAP
SENSOR
DOOR SWITCH
N
L
PLUG
OVERLOAD
PROTECTOR
CONTACTOR
M
LAMP
THERMAL
CUT-OFF
CONDENSERFAN
COMPRESSOR
M
DOOR
SWITCH
THERMOSTAT DISPLAY
CURRENT
RELAY
STARTING
CAPACITOR
ROOM
EVAP
SENSOR
EVAP FAN
EVAP FAN
DEFROST HEATER
PIPE HEATER

Serviceand InstallationManual
11
ELECTRICALDIAGRAM
MODEL：IT56F
MODEL：IT82FDV
N
L
PLUG
OVERLOAD
PROTECTOR
CONTACTOR
LAMP
M
CONTACTOR THERMAL
CUT-OFF
CONDENSER
FAN
M
COMPRESSOR
THERMOSTAT DISPLAY
CURRENT
RELAY
ROOM
EVAP
STARTING RUN
CAPACITOR CAPACITOR
SENSOR
CONTACTOR
w
X
POWER
PLUG
Y
OVERLOAD
PROTECTOR
EVAP
M M
FAN
THERMAL
CUT-OFF
CONTACTOR
CONDENSER
FAN
COMPRESSOR
LAMP
M M
CURRENT
RELAY
THERMOSTAT DISPLAY
STARTING
CAPACIOR
RUN
CAPACIOR
ROOM
EVAP
SENSOR
EVAP
FAN
PIPE
HEATER
PIPE
HEATER
DEFROST
HEATER
DEFROST
HEATER
DOOR
FRAME
HEATER
MIDDLE
FRAME
HEATER MIDDLE FRAME HEATER
DOOR
FRAME
HEATER
MIDDLE
FRAME
HEATER

Service and Installation Manual
ELECTRICALDIAGRAM
12
MODEL: IT28R

Serviceand InstallationManual
13
WIRINGDIAGRAM
MODEL: IT28F

14
Service and InstallationManual
WIRINGDIAGRAM
MODEL: IT56R

15
Serviceand InstallationManual
WIRINGDIAGRAM
MODEL: IT56F

16
Service and InstallationManual
WIRINGDIAGRAM
MODEL: IT82R

17
Serviceand InstallationManual
WIRINGDIAGRAM
MODEL: IT82FDV

Service and Installation Manual
IKON WARRANTY
Two Year Parts & Labor Warranty
MVP Group (IKON) warrants, to the original purchaser, all of its new equipment to be free from defects in material and
workmanship, under normal use and maintenance service, for a period of two (2) years from the date of original
purchase or 15 months after shipment date from the manufacturer, whichever occurs first. Warranty coverage is
limited to the repair and/or replacement, including labor charges, of defective parts and/or assemblies. The labor
warranty shall include straight time labor charges and travel charges within 100 miles roundtrip. Warranty service must
be arranged by calling 514 737-9701, or toll free, 1 888 275-4538 for service in the United States and Canada.
Warranty service coverage is not offered outside of the United States and Canada.
Additional Three Year Compressor Warranty
In addition to the two (2) years warranty stated above, IKON warrants its compressor units to be free from defects in
both material and installation workmanship under normal and proper use and maintenance service for a period of
three (3) additional years from the date of original installation but not to exceed five (5) years and three (3) months
after shipment from IKON. The three (3) year extended compressor warranty applies only to the compressor part itself
and does not apply to other parts, components or labor charges involved in replacement of compressor.
*RESIDENTIAL APPLICATIONS: MVP GROUP CORP. assumes no responsibility nor liability for any parts, or labor
coverage for component failure, or other damage resulting from installation in residential or non-commercial
applications.
Conditions
All service under this warranty, for either labor or parts, must be performed by a preferred service provider arranged
by the IKON Warranty Department at 514 737-9701, or toll free, 1 888 275-4538. Warranty claims should include
model number of the unit, batch & serial number of the unit, and proof of purchase. Service coverage is limited to units
located in the United States and Canada only.
Limitation & Exclusive Warranty
This part and labor warranty is the sole and exclusive warranty remedy offered by IKON. IKON’s sole obligation under
this warranty is limited to either repair or replacement of parts and is subject to the limitations listed below.
1. IKON will bear no responsibility or liability for any equipment which has been misapplied, mishandled, misused,
subjected to harsh chemical action, or external causes such as the use of extension cords, electrical power fluctuation,
lack of proper maintenance, non-factory approved revisions or modifications or equipment damaged by fire, flood, or
other acts of God.
2. IKON will bear no responsibility for consequential loss or damages such as, including but not limited to, economic loss,
profit loss, personal injury, property damage, damage during transit, losses or damages arising from food or product
spoilage claims.
3. IKON shall bear no responsibility for parts or labor coverage for component failure or other damages resulting from
improper usage, installation, or maintenance as described in the owner’s manual.
4. Exceptions to two (2) year part warranty other than additional three (3) year compressor warranty. Light bulbs and
door gaskets are limited to 90 warranty period, parts only.
5. IKON equipment is intended for commercial use only and this warranty is void if the equipment is installed in other than
commercial applications. IKON assumes no responsibility nor liability for any parts, or labor coverage for component
failure, or other damage resulting from installation in residential or non-commercial applications.
6. All other warranties, either express or implied arising under law or equity or custom of the trade, including but not
limited to, warranties or merchantability or fitness for a particular purpose are excluded. IKON’s liability on any claim,
including but not limited to negligence, shall not exceed the price of the equipment that gives rise to the claim.
18

19
Serviceand InstallationManual
