myappliances ART28003 User manual

60cm Free Standing Dishwasher
Models ART28003 and ART28004

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Turn on the water tap and press the Start/resetbutton.The machine will start working
after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will alsodry better.Unload the appliance, startingfrom the lower basket.
Changing theprogramme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loadinginstructions.
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the ON/OFF button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteammay escape
when the doorisopened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press the On/Off button to switch on the appliance,Open the door.
1.Pressthe Start/Reset button to stop thewashing.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door and press the Start/Reset button, the dishwasher will start
running again after 10 seconds.
For detailed operating method read the corresponding content onthe instruction manual.
1. A running cycle can only be modified ifit has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Reset button for more than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.
Select a programme Close the door, turn the knob to select the desired programme
( See the section entitled instruction )“”Operation

To review the section on troubleshooting Tips
will help you tosolve some common problems
by yourself .
Dear Customer,
Please carefully read this manual before using the
dishwasher,it will help you to use and maintain the
dishwasher properly.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
OperatingInstructions,InstallationInstructionsand
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development andupdating of the product, may
make modifications without giving prior notice.
Dishwasher Features.................................... ...3
A WaterSoftener..................... ....................4、..
Attention before or after loading the Dishwasher
Baskets..........................................................9
FilteringSystem.............................................15
Caring forthe Dishwasher..................... .........16.
B Loading the Salt into the Softener.................5、
C Fill the RinseAid Dispenser.........................5、
D Function ofDetergent.................................6 、
Loadingthe upper ...............................10Basket
Loadingthe Lower ...............................10Basket
Cutlery Basket........................................... ...11
Therecommended method loading big
dishware.................................................... ...12
WashCycleTable...........................................13
Turning on theAppliance................................14
Change the Programme.............. ................14....
At the endof theWash Cycle...........................14
PositioningtheAppliance................... ..........17..
Water Connection.................................. .......18.
About Power Connection........................ .......17.
Start of dishwasher................................ ......19..
Before calling for service........................... .....20.
Errorcodes.................................... ..............21.
Technical information.............................. .....22..
ControlPanel...................................................3
Keep it to refer to it at a later date.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
This appliance is intended tobe used in household
andsimilarapplications suchas:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-byclients inhotels, motels and otherresidential
type environments;
-bed and breakfast type environments.

This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Donotabuse,siton,orstandonthedoorordish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2 Warning: Knives and other utensils with
sharp points must be loadedinthe basket
with their points down orplaced in a
horizontalposition.
)
When using your dishwasher, youshould
prevent plastic items from coming into contact
with the heating element.(This instruction is only
applicable to machines witha visual heating
element.)
Ifthesupplycordis damaged, it must bereplaced
bythemanufactureroritsserviceagentora
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremely dangerousif swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent comparment isempty
after completion of the wash cycle.
The applianceis to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is12.
The maximum permissible inlet water pressure is
1MPa.
The minimum permissible inlet water pressure is
0.04MPa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increase the risk of tripping.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.

Dispose of the dishwasher packaging material correctly.
All packaging materials canbe recycled.
Plastic parts are marked with the standard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene,e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control Panel .
Packaging materialcouldbedangerous for children!
Fordisposing ofpackageand theappliance please go to arecycling centre. Therefore cut
off the power supplycableand make the doorclosingdevice unusable.
Cardboard packaging ismanufactured from recycled paperand shouldbe disposedin the
waste papercollection for recycling.
By ensuring thisproduct is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriatewaste handlingof this product.
For more detailed information about recycling of this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.






11 12
Back View
1
2
3
4
5
6
7
8
9
10
on
Of f
Front view
MainFilter
Detergent Dispenser
CupShelf
CutleryBasket
CoarseFilter
RinseAidDispenser
Inlet pipe connector
Drain pipe connector
Lower Basket
SprayArms
UpperBasket
1
Salt Container
beforeusingit for the first time.
To getthe best performance from yourdishwasher,read all operating instructions
5
6
7
8
9
10
12
11
3
24
Salt and rinse aid warning lights: To show
when the salt container or dispenser need to be
refilled
Start and reset button: To start and pause the
selected washing program or reset the washing
program when the machine is working.
Washing Program Selector : Turn the knob to
select wash cycles .
65
6
4
5
Allin 1functionbutton andindicatorlight : The indicator
light will be on when you select this function.
Power indicator light and switch: To turn on/off
and showthepower supply.
Running indicator light : To show the state of the
dishwasher.
4
2
3
2
3
ECO

The water softener must be set manually, using the water hardness dial.
The water softener is designed to remove minerals and salts from the water,which wouldhave
a detrimentalor adverse effect on the operation of the appliance. Thehigher the
content of these minerals and salts, the harder your water is. The softener should be
adjusted according tothe hardness of the water in yourarea. Your local WaterAuthority
can advise you onthehardnessofthewaterinyourarea.
Adjusting Salt Consumption
The dishwasher is designed toallow for adjustment in the amount of salt consumed based onthe hardness of
thewater used.This is intended tooptimiseand customisethelevel of salt consumption.
1. Unscrew the cap from the saltcontainer.
2. There is a ring on the container with an arrow on it (see figure
ontheside),ifnecessary, rotate thering intheanticlockwise
direction from the "-" Setting toward the "+"sign, based on the
hardnessof the water being used.
It is recommendedthat adjustments should be made in
accordance withthe following scheme:
WATER SOFTENER
Thehardness ofthe water variesfrom place to place. If hard water is used inthe dishwasher, depositswill
form on the dishesand utensils.
The applianceis equipped with aspecial softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardness of your water supply.
dH mmol/l
0~140~8 0~1.4 /0/
14~398~22 1.4~3.9 - 20 50
39~8022~45 3.9~8 Mid 40 25
+60 16
fH
0~10
10~28
28~56
Clarke
WATER HARDNESS
SelectorPosition Salt consumption
(gram/cycle) Auto nomy
(cycles/1kgs)
Please follow the steps below for adjustment in salt consumption.
""/
"-"
"+"
"Mid"
Settingtowardthe"+"sign
Settingtowardthe"-"sign
Settingtowardbetween
the "-" sign and "+" sign
No salt need added
45~60 80~107 56~75 8~11
If your model does not have any water softener, you mayskip this section.
°Clark: British degree
°fH: French degree
°DH: German degree
dH=1.25Clarke=1.78fH=0.178mmol/l
°°°
1
Before using your dishwasher for the first time:
A. Set the water softener
B.
Add 1.5Kg dishwasher salt and then full fill the salt container with water
C. Fill the rinse aid dispenser
D. Fill in detergent

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well the salt dissolves,thesalt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (forsome Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasher has run.
2. If there are spills ofthe salt, a soak or arapid program should be run to remove the excessivesalt.
Always use the salt intended foruse with dishwasher.
The salt container islocated beneath the lower basket and shouldbe filled as explained
inthe following:
Attention!
Only use salt specifically designed for the use indishwashers! Every other type of
salt not specifically designed for theuse in adishwasher, especially table salt, will
damage the water softener. In case of damages caused by the use of unsuitable
salt the manufacturerdoes notgive any warranty nor is liable for any damages caused.
Only fillwithsalt justbefore starting one of thecomplete washingprograms.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottom of the machine for any periodof time, which maycause
corrosion.
Therinse aid isreleasedduring the final rinse to prevent water from forming droplets onyour dishes, which can
leave spots and streaks. Italso improvesdryingby allowing water toroll off the dishes. Your dishwasher is
designed to use liquid rinseaids.The rinseaiddispenser islocated inside thedoor next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume of the rinse aidcontaineris about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spotand streak free drying.
Attention!
Only usebranded rinseaid for dishwasher. Never fill the rinse aid dispenser withanyother substances
(e.g. Dishwasher cleaning agent, liquid detergent).This would damage the appliance.
ARemove the lower basket and thenunscrewandremovethecap fromthe saltcontainer.
B Place theend of the funnel(supplied) into the holeand introduce about 1.5kg of dishwasher salt.
C Fullfill thesalt containerwithwater.It isnormalfora small amount ofwater to comeout of thesalt container.
DAfter filling the container , screw the cap tightly back clockwise.
EUsually, the salt warning light will stop being illuminated within 2-6 days after the salt container hasbeen filled with
salt.
FImmediately afterfilling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pump or other important parts of the machine may be damaged
bysalty water.This isoutof warranty.
(Wesuggest to use the
soak orrapid ).

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting italigned with "open" arrow and turning it tothe closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings.Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are notdrying properly or are show spots,adjustthe dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory valueis "4".)
Increase the dose if there are drops of wateror limespotsonthe dishes after washing.
Reduce itif there aresticky whitish stains on your dishes ora bluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the sizeof the black dot
ontherinse aidlevel indicator changes, as illustratedbelow.
Full
3/4full
1/2full
1/4 full- Should refillto eliminate spotting
Empty
When to Refill the RinseAid Dispenser
Ifthere is no rinse-aid warning light in thecontrolpanel, youcan estimate the amount from the colour
of the optical level indicator C located next to the cap. When the rinse-aidcontainer is full, the whole
indicator will be dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the nextwash. Don'tforget to replacethe cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients arenecessary to remove dirt, crush dirt andtransport it outof the dishwasher.
Most ofthe commercialqualitydetergents are suitable for this purpose.
Detergents
There are 3 sorts of detergents
1.Withphosphate and withchlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
""

Proper Use of Detergent
Use only detergentspecificallymade for the usein dishwashers.Keep your detergentfresh and dry.
Don'tputpowdereddetergentinto the dispenseruntilyou're ready towash dishes.
Dishwasher detergent is corrosive! Takecare to keepit out of reach of children.
Based ontheir chemical composition, detergentscan besplit in two basic types:
Detergent tablets of different brandsdissolve at different speeds. For this reasonsome
detergenttablets cannot dissolve and develop theirfullcleaning power during short
programs. Therefore please use long programs when usingdetergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilledbefore the start of each wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventionaldishwasher. Generally, only one tablespoon of detergent is needed for
anormal washload. Moreheavily soileditems needmore detergent.Alwaysaddthe
detergent justbefore starting the dishwasher, otherwise it couldget damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
DetergentDispenser
conventional, alkaline detergentswith causticcomponents
low alkaline concentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thus the watersoftener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strong and coloured spots will not
be removed completely. Inthiscase please choosea program with a higher temperature.
°
Amount of Detergent to Use
Always add the detergent just before starting each wash cycle.
Only use branded detergentaidfordishwasher.
If the lid is closed: press release button.The lid will spring open.
Detergent tablet
Detergent powder

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Theplaceof main wash cycle detergent placed.
Theplace of pre-washcycle detergent placed.
Please observe themanufacturers dosing and storage
Recommendationsas stated onthedetergent packaging.
Closethe lid and press untilit locks in place.
If the dishes are heavily soiled, place anadditional
detergent dose in the pre-wash detergent chamber. This detergent will take effectduring the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount ofdetergent for thesingle programme onthe last page.
Pleaseaware, that according tothe levelsoiling and the specific hardnessof waterdifferencesarepossible.
Pleaseobserve themanufacturer's recommendations onthe detergent packaging.

Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that arenot heat resistant
Older cutlery with glued parts that are not
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items madefromsyntheticfibres
Some types of glasses can become
dull aftera large number of washes
Silver and aluminum parts have a
tendencyto discolourduring washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishes and itemsof cutlery mustnot lie insideoneanother, orcover each other.
To avoiddamage to glasses, theymust not touch.
Load large itemswhich are most difficult to clean into the lower basket.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
andteacups
Long bladed knives stored in an upright positionare a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontallyin the upperbasket.
Please do not overload your dishwasher. This is important for good results andfor
reasonable consumption of energy.
Load hollow items suchas cups, glasses, pans etc. With the opening facing downwardsso that
water cannot collect in the container or a deep base.
Consider buyingutensils which are identifiedas dishwasher-proof.
Usea mild detergentthatis describedas 'kind todishes'.If necessary, seek further
information from the detergent manufacturers.
For particular items,select aprogramwithaslowa temperature aspossible.
To prevent damage, do not take glassand cutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlerybasketsmay vary from your model.)
Scrape off any largeamounts of leftover food.Soften remnants of burnt food in pans.
It is not necessary to rinse thedishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tipover.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upperbasket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.

The upperbasket is designed to hold more delicate andlighter dishwaresuch asglasses,coffee
and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are
not toodirty).
Position the dishes and cookware so that they will not get moved by the spray of water.
Wesuggest that you place largeitems and the most difficult to clean items are tobe placed into thelower basket:
such as pots, pans, lids, serving dishes and bowls, as shown in the figure below.
It is preferable to placeserving dishes and lids on theside of theracks inorder toavoid blocking the rotation ofthe
topspray arm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans canbe loaded.
1
Cups
2
Small serving bowl
3
Large serving bowl
4
Glasses
Saucers
5
6
Dish
Dessert dishes
7
1
1
4
1
7
2
3
5
6
1
4
1
4
1
8
Oval platter
10
Soup plates
Dessert dishes
7
9
Dinner plates
11
Silverware basket
1010
8
99
77
7

2
4
3
1
5
1
5
6
1
Cups
Saucers
6Medium serving bowl
3
Large servingbowl
45
Glasses
1cups
Small serving bowl
2

Cutlery should be placed in the cutlery basket with the handlesat the bottom. If the rack has side baskets,the
spoons should be loaded separately into the appropriate slots, especiallylong utensils should beplaced in the
horizontal position at the front of the upperbasket as shown in the picture.
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Do not let any item extend through the bottom.
Always load sharp utensils with the sharp point down!
Adjusting the Upper Basket
The height of the upperbasket can be adjusted in order to create more space for large utensils
both for the upper/lower basket.The height of the upper basket can be adjusted by placing the
wheels on different height of the rails. Long items, serving cutlery, salad servers and knives
should be placed on the shelf so that they do not obstruct the rotationof the spray arms.
The shelf canbe folded back or be removed when not required for use.
Upper wheels
Lower wheels
2
452
5
32
3
2
1
1
1
1
1
5554
555
4
632367 3
2
3
4555
1
1
1
1
1
5
4
2
2
3
33
332
2
3
2
2
1
4
4
4
4
8
4
4
4
1
Teaspoons
4
Soup spoons
2
Forks
1
Serving forks
8
Serving spoons
6
Knives
5
3
Dessert spoons
7
Gravy ladles

Means: need to fill rinse into the Rinse-Aid Dispenser.
()
*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 12 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
The power consumption of off-mode is 0W
left-on modeis0.4W
Normal
Rapid
20 g.
Draw out the lower and upper basket, load the dishesand push them back.
It iscommendedtoloadthelowerbasketfirst,thentheupperone(seethe sectionentitled
Loading the Dishwasher ).
Pour in the detergent (see the sectionentitled Salt, Detergent and RinseAid ).
Insert the plug into the socket. The power supplyis 220-240 VAC /50 HZ, the specification of the
socketis 10A 250VAC. Make sure thatthe water supply is turnedon to fullpressure.
Close the door, press the ON/OFF button,andthe ON/OFF light will turn on.Turn the program
knob to select a desiredwash cycle, press the Start/Reset button, the machine will work .
“”
“”
after seconds
1
2
3
410
(OrAll )in1
5/25g
(OrAll )in1
5/25g
For normally soiled loads,
such as pots plates
glassesandlightlysoiled pans.
、、
Pre-wash(50 )
Wash (55 )
Rinse
Rinse(65 )
Drying
℃
℃
℃
Wash (50 )
Rinse(65 )
Drying
Pre-wash℃
℃
A shorter wash for lightly soiled
loads and quick wash
Wash (40 )
Rinse
Rinse(40 )
℃
℃
160 1.30 16.0
165 1.02 12.0
30 0.5 11.0
ECO
(*EN50242)
This is standard programme, it is
suitable to clean normally soiled
tableware and it is the most
efficient programme in terms
of its combined energy and water
consumption for that type of
tableware.

It is dangerous to open the door when washing, because the hot water may scald you.
When the working cycle has finished, the buzzer of the dishwasher will soundfor 8 seconds, then stop. Turn off
the appliance using the ON/OFFbutton, shut off the water supply and open the door of the dishwasher.
Wait for a few minutes before unloading thedishwasher toavoidhandling the dishes and utensils while they
are still hot and more susceptible to breakage. Theywill also dry better.
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoffthewater tap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should thereforebeallowed to cool down around 15 minutes
before removingfromthe appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler andthe drying will be improved.
Unloading thedishwasher
It is normal that the dishwasher is wet inside.
Empty thelower basket first and then the upperone. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause. The running indicator
light will stop blinkingand the buzzer willmooing every minute unlessyou close the door .
After you close the door ,the machine will keep on working after 10 seconds.
during a washcycle
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working,you can open the door
completely.
2
3
14
5
Press the start/reset button
Press the start/reset button, the dishwasher will run
after 10 seconds.
When you press the Start/Reset button to pauseduring washing, the running indicator
light will stop blinking and the dishwasher will mooing every minute unless you press the
Start/Reset button to start.
Acycle that is underway can only be modified if it has only been running for a short
time. Otherwise, thedetergent may have alreadybeen released, and the appliancemay
have already drained thewash water. If this is the case, the detergent dispenser must
be refilled (seethe section entitled " Loading the Detergent " ).
Whenyou press thestart/reset button more than 3 seconds, you can cancel the running
programme andselect other programmes(see the sectionentitled " Starting awash cycle. .. " ).
Whenyou select Normal/Eco.Programmes, you can selecttheAll in1 function.
The Display window shows the state of the dishwasher:
a) Runningindicator lightis off ----------------------------------> stand by;
b) Running indicator light is on and not blinking -------------> pause;
c) Runningindicator light is on and blinking ------------------------> run.
1
2
3
4
Premise

The filter preventslarger remnants of food or other objects from getting inside the pum.
Theresidues may blockthefilter, inthis case they must be removed.
The filter system consists of a coarse filter,a flat (Main filter)
Anda microfilter(Fine filter).
Food and soil particles trapped in thisfilter arepulverizedby a
special jet on the lower spray arm andwashed down todrain.
Larger items, such as pieces of bonesor glass, that couldblock
the drainaretrappedin the coarse filter. To remove theitems
caught by the filter, gently squeeze the tap on the top of this
filterandliftout.
Thisfilter holds soil and food residues in the sumpareaand
prevents itfrom being redepositon the dishes during washcycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. thisreason, it is a good idea to
remove thelarger food particles trapped in the filter aftereach washcycleby rinsing the semicircular filterand
cup under running water. To remove the filter device, pull thecup handle in the upwarddirection.
removes food particles from the wash water, allowing it to be recycledduring the cycle.
For
The dishwasher must never be used without the filters.
Improper replacementof the filter may reduce the performance level ofthe appliance
and damage dishesand utensils.
1
2
Step 1 Turn the filter in anti-clockwisedirection,
then lift it up.
：
Step 2 lift the Main filter up：
3
Step 3 lifttheFinefilter up：
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.

The control panelcan be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use a good appliance polish wax.
Neveruse sharp objects, scouring pads orharsh cleaners onany part of the dishwasher.
ProtectAgainst Freezing
1.Cutoff the electricalpower to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use apan to catch thewater)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottomof the tub and use a spongeto soak up water in the sump.
please take frost protection measures onthe dishwasher in winter.Every fter washing cycles,
please operate as follows time a
：
- Inspect the filters for blocking after every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Removeany foodremnants and
cleanthefilters underrunningwater.
Remarks:
Cleaning the Filter
CleaningThe Door
To clean the coarsefilter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
on thelast page and reinsert the entire assembly in the dishwasher, positioning itin itsseat and pressing downwards.
The entire filter assembly shouldbe cleaned once a week.
When cleaning the filters, don't knock on them. Otherwise, thefilters could be
contorted andtheperformance ofthe dishwashercouldbe decreased.
To clean theedge around the door, you should use only a soft warm, damp cloth.
To avoid penetrationof waterinto the door lock and electrical components,do not
use a spray cleaner of any kind.
Never usea spray cleaner toclean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agentsor some paper towels should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
waterchemicalswillclogthe sprayarmjetsandbearings.
To remove theupper sprayarm, screw off the nut clockwise then
remove thearm.
To remove the lower spray arm, pull out the spray arm upward.
Wash thearms in soapy and warm water and use a soft brush to
cleanthejets.Replace them afterrinsing them thoroughly.

Itisrecommendthatyourun awashcycle with the
dishwasher empty andthenremove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealsto lastlongerandpreventodoursfromforming
withinthe appliance.
If the appliance must be moved, tryto keep it in the
verticalposition. If absolutelynecessary,itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remains trappedin the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Ensure the voltage and frequency of the power being correspondsto
those on the ratingplate. Only insert the plug into an electricalsocket which is earthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate fortheplug, replace the socket, ratherthan usingaadaptors orthelike as
they couldcause overheatingandburns.
Pleaselook at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp,timedelay fuse or circuitbreaker recommended and provide separate circuit serving
only this appliance.
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an
appropriate outlet that is installed and earthed in accordance with all local standards and requirements.
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides,
along the adjacent cabinets or walls.The dishwasher is equippedwith water supply and drain hoses that can
be positioned either to the rightor the left sides to facilitateproper installation.
Once the appliance is positionedfor levelling, the height of the dishwasher
may be alteredvia adjustmentof the screwing level ofthe feet. In any case,
theappliance should notbeinclined more than 2 .
For personal safety:
DO NOT USEAN EXTENSION CORD ORAN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDERANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
After every wash, turn off the water supply to the
appliance and leavethe doorslightly open so that
moisture and odours arenot trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, usea cloth dampened withwaterana little
vinegar, ora cleaning product madespecificallyfor
dishwashers.
After EveryWash
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
When not in Use for aLongTime
