myappliances ART28008 User manual

ART28008

To review the section ontroubleshooting Tips
willhelp youto solve some common problems
by yourself .
Dear Customer,
Please carefully read this manual beforeusing the
dishwasher, it will help you to use and maintain the
dishwasher properly.
Pass it on to any subsequent owner of the appliance.
This manual contains sections on safety Instructions,
OperatingInstructions,InstallationInstructionsand
Troubleshooting Tips, etc.
The manufacturer,following a policy ofconstant
development andupdatingof the product, may
make modifications without giving prior notice.
This usermanualshall also begot fromthe
manufacturer or responsible vendor.
Keep it to refer to it at a later date.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
DishwasherFeatures.......................................3
Attention before or after loading the Dishwasher
Baskets..........................................................9
Filtering System.............................................13
Caring forthe Dishwasher..................... .........14.
A Loading theSalt into the Softener.................4、
B Fill the RinseAid Dispenser.........................5、
C Function of Detergent .................................6 、
Loading the Basket...........................................9
Cutlery Basket..............................................10
WashCycleTable...........................................11
Turning on theAppliance................................11
Change theProgramme.............. ................12....
At the end of theWash Cycle...........................12
Positioning theAppliance................... ..........16..
WaterConnection.................................. .......16.
About Power Connection........................ .......16.
Connection of Drain Hoses..................... .......17.
Start of dishwasher............................. .. ......18.. ..
Before calling for service........................... .....19.
Errorcodes.................................... ..............20.
Technical information.............................. .....21..
ControlPanel...................................................3

Thisappliance is intended tobeused in household
and similarapplicationssuch as:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bedand breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledgeif they have been givensupervision
or instruction concerning useof the applianceina
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.(For EN60335-1)
This appliance is not intended for use by persons
(including children )with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge ,unless they have been givensupervision
or instruction concerning use ofthe appliance bya
personresponsible for their safety.(For IEC60335-1)
This appliance is for indoor useonly, for household
useonly.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in wateror other liquid.
Please unplug before cleaningand maintenance the
appliance .
Use a soft cloth moisten with mild soap, and then use
adryclothtowipeitagain.
When using your dishwasher,
follow the precautions listed below:
1-1

This appliance must be earthed. In the event of a
malfunction or breakdown, grounding will reduce the risk
of anelectric shock by providing a path of least
resistance of electric current. This appliance is equipped
with a cord having an equipment-earthing conductor
and a earthing plug.
The plug must be plugged into an appropriate outlet that
is installed and earthed in accordance with all local
codes and ordinances.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the appliance
is properly grounded.
Do not modify the plug provided with the appliance;
If it does not fit the outlet.
Have a proper outlet installed by a qualified electrician.
Do not abuse, sit on, or stand on the door or dish rack of
the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
1-2

2) Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
Check that the detergent comparment is empty after
completion of the wash cycle.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent.
For plastic items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed for
an automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Children should be supervised to ensure that they do not
play with the appliance.
The door should not be left open, since this could increase
the risk of tripping.
Ifthesupplycordisdamaged,itmustbereplacedbythe
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using
new hose sets and that old hose-sets should not be reused.
The maximum number of place settings to be washed
is 6.
The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.
1-3

Dispose of the dishwasher packaging material
correctly.
All packaging materials can be recycled.
Plasticparts are markedwith thestandard
international abbreviations:
PE for polyethylene,e.g. sheet wrapping material
PS for polystyrene, e.g. padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g. Control
Panel .
Packaging material could be dangerous for children!
For disposing of package and theappliance please
go to a recycling centre. Therefore cut off the power
supply cable and make the door closing device
unusable.
Cardboard packaging ismanufactured from recycled
paper and should be disposed in the waste paper
collection for recycling.
By ensuringthis productis disposed of correctly, you
will help prevent potential negative consequences
for the environment andhuman health,which could
otherwise becaused by inappropriate waste handling
of this product.
For more detailed information about recycling ofthis
product, please contact your local city office and your
household waste disposal service.
DISPOSAL:Do not dispose this productas unsorted
municipal waste. Collection of such waste separately
for special treatment is necessary.
1-4

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Turn on the water tap and press the Start/Pause button. The machine will start working
after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lower basket.
Changing theprogramme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loadinginstructions.
Close the door，
“”
Press the programme button until the selected programme lights up.
( See the section entitled Operation instruction )
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the Power button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteam may escape
when thedoorisopened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press the Power switch button to switch on the appliance, Open the door.
1.Press the start/pause button to stop the machine.
2.Open the door.
3.Add the forgotten dishes.
4.Close the door, then press the start/pause button, the dishwasher will
start running again after 10 seconds.
For detailed operating method read the corresponding content onthe instruction manual.
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Pause button ,than press the program button more than 3 seconds to cancelthe
running programme.
3. Select a new programme.
4. Restart the dishwasher.
C
AB
2

5
2
3
4
6
7
3
beforeusingit forthe first time.
To get the best performance from yourdishwasher,read all operating instructions
Power Button: To turn on/off the powersupply.
Washing Program Selector: Pressthe button
toselectwashcycles.
RinseAid Warning Light : To be on when the
rinseaid dispenser needs to be refilled.
SaltWarningLight:Tobeonwhenthesoftener
needs to be refilled.
Delay Button : To press the buttonto delay.
Delay time:2/4/6/8 hours option.
Start/Pause Button: Press this button to start
or pause the dishwasher.
Filter assemblyDetergent Dispenser
Cup Shelf
Cutlery Basket Rinse Aid Dispenser
Drainpipeconnector
Inlet pipe connector
Spray Arms Basket
1
Salt Container
5
67 89 10
3
2 4
Back ViewFront view
910
78
1
2
3
4
5
6
.
8
Programindicatorlight.

normal for a small amount of water to come out of the salt container.Itis
1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how fully the salt dissolves, the salt warning light may still be on even though the
salt container is filled.
If there is no salt warning light in the control panel (For some Models),you can judge when to load
the salt into the softener by the cycles that the dishwasher had run.
2. If there are spills of the salt,a soak or arapid program should be run to remove the excess salt.
Always use salt intended for use with dishwasher.
The salt container is located beneath the basket and should be filled as follows:
Attention!
Only use salt specifically designed for use in dishwashers!All other types of
salt not specificallydesigned for use in a dishwasher, especially table salt, will
damage the water softener. incase of damagescaused by the use ofunsuitable
salt the manufacturer does notgive any warranty nor is liable for any caused
damages.
Only fill withsalt just before starting one of thecomplete washingprogrammes.
This will prevent any grains of salt or salty water, which may have been split,
remaining of the bottom of the machine for any period of time, which may cause
corrosion.
4
ARemove the basket and then unscrew and removethe cap from the salt container.
BBefore first wash, add 1lt. of water in the salt container of your machine.
CPlace the end of the funnel (supplied) into the hole and introduce about 1kg of salt.
DAfter filling the container , screw the cap tightly back clockwise.
EUsually, the salt warning light will be cease to be illuminated within2-6 daysafterthe salt container has been filled with
salt.
FImmediately after filling the salt into the salt container, a washing programme should be started
Otherwisefilter system,pump or other important parts ofthe machinemay be damagedby salty
water. Itisoutof warranty.
If your model have water softener, you may skip this section.no
Step 1: Enter the status of salt adjustment
Adjusting Salt Consumption
Close the door, within 60seconds after power on,press Start/Pause button and hold for5 seconds,
the machine will enter setting mode.

Setting on the
water softener Digital display stalls
1
Rapid
2
3
5
dH
Water Hardness level
mmol/l
1) 2)
0-5 0-0.9
6-11 1.0-2.0
12-17
18-22
23-34
35-45
2.1-3.0
3.1-4.0
4.1-6.1
6.2-8.0
Glass & Rapid
ECO
ECO & Rapid
ECO & Glass
There are 6 levels of salt consumption in all.It is recommended to select the level according to below table:
Step 2: select a certain level of salt consumption
Contact your local water board for information on the hardness of your water supply.
Press the Start/pause button to select the proper set according to your local environment,
the sets will change in the following sequence: H1->H2->H3->H4->H5->H6;
Step 3: Exit the status of salt adjustment
Without any operation in five seconds, the machine will exit from set mode, the machine is into standby status
1) German degree of measurement for the water hardness
2) millimol, internationel unit for water hardness
*) factorysetting
The rinse aid is released during the final rinse to preventwater from forming droplets on your dishes. That can leave
spots and streaks. Italso improves drying by allowingwater to sheet off thedishes. Your dishwasheris designed to
use liquid rinse aids. The rinseaid dispenseris locatedinsidethe door next to the detergent dispenser. Tofill the
dispenser, openthe cap and pourtherinseaid into thedispenser untilthe level indicatorturns completely black.
The volume of the rinse aid container is about 110ml.
RinseAidDispenser
Function of RinseAid
Rinse aid is automatically added during thelast rinse, ensuring thorough rinsing, and spot andstreak free drying.
5
Glass
6
4*

To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid intothe dispenser, being careful not to overfill.
Replace the cap by inserting italigned with "open" arrow and turning it tothe closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings. Always start with the dispenser
set on "4". If spots and poor drying are problems, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are spotted, adjust thedial to the next
higher number until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase thedose if there are drops of wateror limespotsonthe dishes after washing.
Reduce it ifthere are sticky whitish stains on your dishesora bluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the size of the black dot
onthe rinse aid level indicator changes, as illustrated below.
Full
3/4full
1/2full
1/ 4full- Should refill to eliminate spotting
Empty
6
When to Refill the RinseAid Dispenser
If thereis no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color
oftheopticallevelindicator located nexttothecap. Whentherinse-aidcontainer isfull, the whole
indicator will be dark .As the rinse-aid diminishes, thesize of the dark dot decreases. You should never let
therinseaidgetbelow1/4full.
during the next wash. Don'tforget to replacethe cap before you closedishwasher door.
Clean up any rinse aid split during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of commercial quality detergents are suitable for this purpose.
""
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenserwith anyothersubstances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
Function of RinseAid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
C (Rinse-Aid indicator)

7
AmountofDetergentto Use
Based ontheir chemical composition, dishwasher can be split in twobasictypes:
Detergent tabletsofdifferent brands dissolve at different speeds. Forthisreasonsome
detergenttablets cannot dissolve and develop theirfullcleaning power during short
programmes.Therefore pleaseuselong programmes whenusing detergenttablets, to
ensure the complete removal of detergent residuals.
The dispenser must be refilledbefore the start of each wash cycle following the instructions
provided in the Wash Cycle Table .Your dishwasher uses less detergent andrinse aidthen
conventionaldishwasher. Generally, only one tablespoon of detergent isneededfor
anormal washload.Also,more heavilysoiled items need moredetergent.Always add the
detergent just before starting the dishwasher, otherwise it couldgetdamp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
Detergent Dispenser
Always add the detergent just before starting each wash cycle.
Only use branded detergent aidfordishwasher.
If the lid is closed: press release button. The lid springs open.
conventional, alkaline detergents with caustic components
low alkalineconcentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thewater softener functionof
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness ofwateris only 6 dH.If detergentswithout phosphate wereusedincase ofhard water
often white spots appear at dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strongand coloured spots will not
removed completely. In this case please choose a programme with higher Temperature.
°
Detergent tabletsare only for the models with 3 in 1 functionor 3 in 1program.
Push latch to open

8
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on right:
Theplace of main wash cycle detergent placed.
Theplace of pre-wash cycle detergent placed.
Please observe themanufacturers dosing and storage
Recommendations asstatedonthedetergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dosein the pre-wash detergent chamber.This detergent will take effect during the pre-wash phase.
A
B
Fill in detergent
You find information about the amount of detergent for the single programme on the last page.
Please aware, that according tothe level soiling and the specific hardness of water differencesare possible.
Pleaseobserve themanufacturer's recommendations onthe detergentpackaging.
Cutlery with wooden, horn china or
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that is not
temperature resistant
Bonded cutlery items or dishes
Pewteror copper items
crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Some types of glasses can become
dull aftera largenumber of washes
Silverandaluminium partshave a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are of limited suitability
Don't put powder detergentinto thedispenser until you're ready to wash dishes.
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
Proper Use of Detergent
Usea mild detergent that isdescribed as'kind ofdishes'.If necessary, seek further
information from detergent manufacturers.
For particular items, select a programme with as low a temperature.
Toprevent damage, donot take glass andcutlery out of the dishwasher immediately
after the programme has ended.
Consider buying utensils which are identified as dishwasher-proof.
Dishwasher detergent is corrosive!
Take care tokeep it out of reach of children.
AB

Position the dishes and cookware so that they will notget moved by the spray of water.
9
Dishesand itemsof cutlery must notlie insideoneanother, orcover each other.
To avoiddamage to glasses,theymust not touch.
Loadlargeitemswhicharemostdifficulttocleanintothebasket.
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontallyin the basket.
Please do not overload your dishwasher. This is important forgood resultsandfor
reasonable energy consume.
Load hollow items suchas cups, glasses, pans etc. With the opening downwards sothat
water cannot collect in the container or a deep base.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may vary from your model.)
Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are face down.
2.Curved items, or those with recesses, should be loaded at a slant so that water can run off.
3.Allutensils are stacked securelyand can not tipover.
4.All utensils are placed in the way that the spray arms can rotated freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
Saucers
4
Medium serving bowl
3
Glasses
1
Cups
6
Oval platter
7
Dinner plates
8
Soupplates
Dessertdishes
9
Dish
5
Cutlery basket
10
2
Serving spoons
11

10
Cutlery should be placed inthe cutlery basket with handles atthe bottom. If the rack has side baskets, the spoon
shouldbeloaded individually into the appropriate slots,especially long utensils should beplaced inthehorizontal
position at the front of the upperbasket as shown.
Do not let any item extend through bottom.
Always load sharp utensils with thesharp
point down!
Forpersonal safetyanda top qualityclean, place thesilverware in the basket:
They do not nest together.
Placesilverwarewithhandles-down.
But placeknivesand other potentially dangerous utensilshandles-up.
Teaspoons
4
Soup spoons
2
Forks
1
Serving forks
8
Serving spoons
6
Knives
5
3
Dessert spoons
7
Gravy ladles

11
Starting a washcycle...
Draw out the basket(seethesection entitled Loading the Dishwasher ).
Pour inthedetergent (see the section entitled Salt,
Detergent and Rinse Aid ).
Insert the plug into the socket.The powersupply is 220-240
VAC 50 HZ,the specification of the socket is 10A250VAC.
Make sure that the water supply is turnedon to full pressure.
“”
“
”
Pressthe program button, the wash program willbe changed as follows direction
If a programis selected,theresponse lightwill light. Thenpress the
button, the dishwasher begins to start.
ECO->Intensive->Normal->Glass->Rapid;
Start/Pause
When you press the button to pause during washing,
the program light will stop blinking and the dishwasher will mooing
every minute unless youpressthe button to start.
Start/Pause
Start/Pause
For normally soiled loads,
such aspots,plates,
glassesandlightly
soiled pans.
For heaviest soiled crockery,
and normally soiled pots
pans dishes etc with dried
onsoiling.
、
、
Ashorter washfor lightly soiled
loads and quick wash.
3~15g
120
180
140
30
0.7
0.61
0.9
0.25
8
6.5
10
6
Pre-wash
Wash (60 )
Rinse
Rinse (70 )
Drying
℃
℃
Pre-wash
Wash (50 )
Rinse
Rinse (70 )
Drying
℃
℃
Wash (40 )
Rinse ℃
Rinse (40 )℃
Intensive
Pre-wash 50
Wash (70 )
Rinse
Rinse
Rinse (70 )
Drying
℃
℃
℃
()
Rapid
Normal
(*EN50242)
(1or 2 pieces)
3/15g
*EN 50242 : This programme is the test cycle. The information for comparability test
in accordance with EN 50242, as follows:
Capacity: 6setting
The power consumption of off-mode is 0.49W
left-on modeis 0.49W
Rinse aid setting: 6
This is standardprogramme,
it is suitable to clean normally
soiled tableware and it is the
most efficient programmein
terms of its combined energy
and water consumption for
that type of tableware.
Wash (45 )
Rinse
Rinse(60 )
Drying
℃
℃
For lightly soiled loads,
such asglasses, crystal and
finechina.
75 0.5 7
(or 1 pieces)
3/15g
(or 1 pieces)
3/15g
(or 1 pieces)
18g

12
Whenthe working cycle has finished, the buzzerof dishwasher will sound 8 seconds,then stop.Turn off
the appliance using the ON/OFFbutton, shut off the water supply and open the door of the dishwasher.
Wait afew minutes before unloadingthe dishwasher to avoid handling the dishes and utensilswhile they
are still hot and more susceptible to breakage. Theywill also dry better.
Switch Off the Dishwasher
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoff thewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloadingthedishwasher
It is normal that the dishwasher is wet inside.
will keep on working after 10 seconds.
Ifyou open the door when washing, themachine will pause. When you close the door , themachine
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working,you can open the door
completely.
2
3
Open the door a little to stop the washing.
14
5
6
Premise: Otherwise, the detergent may havealready been
released, and the appliance may have already drained the wash water. Ifthis
isthe case, the detergent dispenser must be refilled (seethe section entitled
" Loading the Detergent " ).
NOTE: If you open the door during washing, the machine will pause. When you
closethe door and press the Button, the machine will keep on
workingafter10 seconds.
The program lights show thestate of the dishwasher:
PressS Button to pause the machine when the door is closed ,Press
Button more than three seconds the machine will be in stand by state ,
then you can change the program to the desired cycle setting (see the section
entitled " Starting a wash cycle. . ." ).
S
a) One of the programlights on----------stand byor pause
b) One of the programlights blinking----- run
You can modify the washing program, When the dishwasher just
runs for a short time.
tart/Pause
tart/Pause
Program
Press the buttontart/PauseS
Press the button, the dishwasher will run
after 10 seconds.
tart/PauseS
It is dangerous to open the door when washing,
because the hotwater may scald you.

The filter prevent larger remnants of food orotherobjects from getting inside the pump.
The filter system consists of acoarse filter, a flat (Mainfilter)
and a micro filter (fine filter).
Food and soil particles trapped by this filter are pulverized by a
special jet on the spray arm and washed down to drain.
Main filter
A
Larger items, such as pieces ofbone or glass, that could block
the drain are trapped in the coarse filter. To removethe items
caughtbythefilter,gentlysqueezethetaponthetopofthis
filter and lift out.
Coarse filter
C
Thisfilterholds soil and food residue in the sump area and
prevents itfrom being deposited on the dishes during wash cycle.
Finefilter
B
Filterassembly
Thefilter efficiently
For best performance and results, the filter assembly must be regularly. this reason, it is a good idea to
remove thelarger food particlestrapping inthe filter after each wash cycle by rinsing the filterand cup under
running water. To remove the filter assembly, pull on thecup handle in the upward direction.
removes food particles from the wash water,allowing it to be re-cyclated during the cycle.
For
Never run the dishwasher without the filters in place.
The dishwasher must never beused without the filters.
Improper replacementof the filter may reduce the performancelevel ofthe appliance
and damage dishesand utensils.
the filter system will be installed.
If do it from step1 to step 3, the filter system will be removed; while if do it from Step 3 to Step 1,
13
Step1 contrarotate the filter assembly(A,B and C),
then lift it all up.
：
Open
C
B
A
Step2: lift B and C up from A;
A
B
C
A
B
C
The End.

The control panelcan be cleaned by using alightly dampenedcloth and dry thoroughly.
The exterior use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
ProtectAgainst Freezing
1.Cut off electrical power to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Removethe filterat the bottomof the tub and use a sponge touseup water in sump.
please take frost protection measures ondishwasher in winter. E fter washing cycles,
please operate as follows ach time a
：
- Inspect the filters for blockingevery time the dishwasher has been used.
- By unscrewing the coarse filter.you can remove the filter system.Remove any foodremnantsand
clean thefilters underrunningwater.
Remarks:
CleaningThe Filter
CleaningThe Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble thefilter parts as shown in the figures
inthelastpageandreinsert the entire assembly in the dishwasher, positioning inits seat and pressing downward.
The entirefilter assembly should be cleaned once a week.
Whencleaning the filters, don't knock on them. Otherwise, thefilters could be
contorted andthe performance ofdishwasher couldbe debased.
To cleantheedge aroundthedoor, youshoulduseonlya soft warm,
damp cloth. To avoid penetration of water into the door lock and
electrical components, do not use a spray cleaner of any kind.
Never usea spray cleaner to clean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agent or some paper towel should not be used because of the risk of
scratching or leaving spots on the stainless steel surface.
14
If your dishwasher cannot work because of the ice, please contact professional service persons.

Itis recommendthatyourun a washcycle withthe
dishwasher empty and then remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealsto ast longer andprevent odours from forming
withinthe appliance.
If the appliance must be moved, try to keep it in the
verticalposition.If absolutelynecessary,itcanbe
positioned on its back.
One of thefactors that cause odors to form in the
dishwasher is food that remainstrappedin the seals.
Periodic cleaning with adamp sponge will preventthis
from occurring.
After every wash, turn off the water supply to the
appliance and leave the door slightlyopen sothat
moisture and odors are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened with water with a little
vinegar, ora cleaning product madespecifically for
dishwashers.
After EveryWash
Remove the Plug
No SolventsorAbrasive Cleaning Moving theAppliance
Seals
When it is not in needfor a long time
15
The installationof the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard
Disconnect electrical power
before installing dishwasher.
Failure to do socan result in
death orelectrical shock.
The installation position ofdishwashershould be near the existing inletanddrain
hosesandpower cord.
One side of the cabinet sink shouldbe chosen to facilitatethe connection of drain
hosesof the dishwasher.
Cleaning the SprayArms
Thespray arms can be easily removed for periodiccleaning
of the nozzles, to prevent possible clogging. Wash them
under running water and carefullyreplace them in their seats,
checking that their rotary movementis inno way impeded.
Graspthe middle of the spray arm, pull itupwardsto remove
it.Wash thearms undera jetof running waterandreturn them
carefully to their seat. After reassembly, check that the spray
arms turn freely. Otherwise, check that they havebeen
installed correctly.
