1 TRIGGER SWITCH
Depress to start and release to stop
your drill. The trigger switch is fitted
with a brake function which stops
your chuck immediately when you
quickly release the switch. It is also a
variable speed switch that delivers
higher speed and torque with
increased trigger pressure. Speed is
controlled by the amount of trigger
switch depression.
2 TRIGGER SWITCH LOCK
The trigger switch can be locked in
OFF position. This helps to reduce
the possibility of accidental starting
when not in use. To lock the switch,
place the forward and reverse
rotation
selector in
the centre
position by
pushing it on
either side of
the drill.
3REVERSIBLE
The forward/reverse rotation control
located above the trigger switch
control the direction of rotation. For
drilling and screw driving use forward
rotation marked “ ” (lever is
moved to the left). Only use reverse
rotation marked “ ” (lever is
moved to the right) to remove screws
or release a jammed drill bit. When
the selector is in the centre position,
the switch is locked.
4 CHUCK ADJUSTMENT (FIG G)
To open the chuck jaws rotate the
front section of the chuck. Insert the
drill bit between the chuck jaws and
rotates the front section in the
opposite direction. Ensure the drill
bits is in the centre of the chuck jaws.
Finally, firmly rotates the front chuck
section in the opposite directions.
Your drill bit is now clamped in the
chuck.
Fig.G
5TORQUE ADJUSTMENT (FIG G)
(Screw driving force of your drill
driver)
The torque is adjusted by rotating the
torque adjustment ring. The torque is
greater when the torque adjustment
ring is set on a higher setting. The
torque is less when the torque
adjustment ring is set on a lower
setting.
Make the setting as follows:
1-5 for driving small screws
6-11 for driving screws into soft material
11-15 for driving screws into soft and
hard material
15-18 for driving larger screws
for heavy drilling
OPERATING INSTRUCTIONS
