MZONE HGMVB-8663 User manual

www.homeguardworld.com/MZONE
[email protected]om
© 2018 Homeguard
TM
TM
Quick Start Guide
SHADOW HD BOOKCAM
Model: HGMVB-8663

General overview
Product accessories
•Please ensure that you read the complete user manual carefully before using any part of the product.
•Keep this copy safe for future reference in case of operational difficulties.
General Introduction
This book camera is especially designed for long-time motion detection and video recording as Max 24 months stand-by
upon one full-charge. So user could easily put the camera anywhere for hidden surveillance for months.
Besides, it has motion detection function. As we known, it's the best way to detect moving things.
Furthermore, there is a hidden huge battery as, which could support Max 24 months stand-by to catch motion.
Main features:
•Put-It-There for easily hidden surveillance
•With motion detection video recording function
•Hidden battery
•Full HD 1080P 30FPS
•Audio could be able/disable
•Night vision
32
Important Remindings:
•Please read the user manual before using the camera.
•Please test the position/angle, playback the video in advance, to make sure it could catch what you want
•Please do not use this camera for illegal purpose. It is important to follow the laws in your country/state
•We could not be responsible for missing any video record due to wrong operation/MicroSD problem/camera angle limit
Important notice: If there Is anything missing, please contact us Immediately
Camera USB cable Manual

Product structure Detection ability
54
Suggested operations:
1. Insert SD and set the time/date before using the camera.
2. Directly switch the mode button to MD, which means motion detection. The Max stand-by time could be 24 months to
catch any motion.
90° camera angle
60° Detection angle
Important notice:
•While using the camera, it should be placed in a
perpendicular direction to those objective people
passing by
•Avoid using the camera in hot or extreme
temperatures that will lower down
motion-detection accuracy
•Once it is switch to MD (MOTION DETECTION
MODE), upon each trigger, there will be about 2
seconds delay to start video record. Thus, please
avoid to use it in somewhere people passing
quickly.
Detection angle 60 degrees
Camera angle 75 degrees
Motion detection distance: 6-8m
Motion
Detection
LED Light
Camera
Lens
Micro-SD MD/OFF/REC
Reset Audio(ON/OFF)
USB
Indicator
6-8m

Charging information How to insert and take out MicroSD card
76
Important notice:
•The camera has the ability to record video only when MicroSD is inserted.
•Please avoid by all means to insert or remove MicroSD when the camera is either powered ON or connected to the
computer. This can possibly cause damage to MicroSD or the entire camera.
•Please ensure that minimal effort is applied to the MicroSD when inserting it in or out of the camera. Use of force can
easily damage the MicroSD or the product parts.
•Before using the product for the first time, ensure that the MicroSD is formatted. Please check for any saved data in
the MicroSD to avoid unexpected loss.
We are not liable or responsible for malfunctions that result from failure to follow the above guidelines.
It is suggested to charge it by a 2A USB power adaptor, with the USB cable in package.
•Once it is low battery, it could not be power on at all, or the red and blue light will flash for 10 seconds and power off
•During charging please put the power switch to "off". And the yellow indicator stays on during charging, and it goes
off once full charged
Insert MicroSD card Take MicroSD out

Time and date setting Detailed parameters
98
First, users don't have to set time/date unless it is necessary. Please follow the bellowing to set time/date
Step 1: Power off the camera, and connect it with PC by the USB cable in the package. Switch the button to REC, after a
dozen of seconds, there will be a disk to open. Then please open YW_ TIME.txt.
Step 2: Please change the numbers/letters
Step3: Disconnect it from PC and power on it. The time settings is done and you will find time & date watermark in the
video recordings.
File name
File Edit Format View Help
yyyy/mm/dd
hh:mm:ss
yes: auto-recycle the SD
no: no auto-recycling
size
Product net weight
Battery
Stand-by power consumption
Motion detection angle
Motion detection distance
Camera angle
Max PIR stand-by time
Day time recording power consumption
Max day time recoridng time
Night vision recording power consumption
Max night vision continuously recording time
Full-Charging time
Resolution
FPS
MD video record
Record continuously
Max SD storage
Loop recording
215 × 148 × 37 mm
402g
Lithium Rechargeable
10uA
90 degrees
6-8 meters
about 75 degrees
2 years
220mA
about 20 hours
820mA
9-10 hours
about 20 hours by 2A USB power adaptor
1080P
30FPS
about 1 minute per file
about 2 minutes per file
32GB
optional
Item Parameter

Indicator status and meanings Note
1110
IMPORTANT REMINDINGS: PLS DON'T PUT SD OUT DURING RECORDING OR IT COULD POSSIBLY CAUSE DAMAGE TO
SD. WHEN THE BATTERY IS RUNNING OUT, IT WILL SAVE THE LAST FILE AND POWER OFF
Switch to REC
Switch to MD
Motion detected
No SD
Low battery
SD full(if it is not auto-recycling)
Charging the camera
Full charged
Connect with PC as a U-disk when
connect with PC and power on the
camera to either REC or MD
The blue light flashes 3 times and goes off, it will record continuously by 2
minutes video each
The red and blue light flash once, then the red light flashes 3 times and goes off
The red & blue light flash once and red will flash 3 times and goes off. It will
save to SD for about each 1 minute video
The blue light will flash for 25 seconds and it powers off
The red and blue light will flash for 10 seconds and it powers off or sometimes
battery is totally running out, it could not power on at all.
The red and blue light will flash for 10 seconds and it powers off
The yellow light stays on (suggested to put the switcher to OFF when charging)
The yellow light will be off
The yellow light will stay and the blue & red light will flash
Indicator status Meanings
