NAPCO ISEEVIDEO - BROCHURE EOP User manual

• Turnkey all-inclusive EOP camera kit comes with 12 months
access for easiest installed means of gaining incremental
recurring monthly revenue from video accounts
• Eliminates time-consuming conventional camera wiring
- Hi-res ethernet-over-power video cameras simply plug in
(4 per system). With EOP Homeplugs, the existing power lines
of a home or business transmit cameras’ video signals.
• Affordably includes 12 mos. video account access on
secure server for live viewing 24/7 or archived events.
• Archives approximately 75 motion-detection-triggered
video clips per camera-account; accounts get email-alerts
when events occur
• Dependable, proprietary rewall-buster technology
ensures all consumers can view their video even on PCs within
high-security firewall networks
• Easy plug and play installs - no software applications to
install on computer or cellphone (supports all brands &
browsers). Streaming video data module auto-senses proper
data-port – no routers to reconfigure
iSee Video EOP Kit with 1 plug-in hi-res camera, G-box plug-
n-play video-web interface, 2 eop homeplugs, 15’ & 3’ cables
and 12 months internet video account access on the Napco
server (model: VCAM1-EOPKT1/12)
iSeeVideo: EOP
Plug-in ethernet over power
camera kit uses existing
powerlines to create a video
transmission network so accounts
can view their premises anytime,
anywhere they have web access

Generate RMR providing easy to install internet video access
The integrated plug-in EOP (Ethernet over power) system provides an
easily installed means of generating added RMR by offering new or
existing accounts remote video surveillance. With the system, consumers
can:
•Look in on their home or business anytime, anywhere using any PC or
web-enabled cellphone.
•Use pixel-based motion detection to trigger video clip storage for
review in progress or later.
Motion detection can be set and time-scheduled by the consumer, so
that motion in a given area of the cameras’ field of view will automatically
trigger a video record of that event. For example, a child returning from
school is detected moving through the front door and video is recorded.
Also, an email alert can be sent to a PC or cellphone.
VGA high-resolution camera uses ethernet over power technology for
plug-and-play, speedy installs
To eliminate traditional camera wiring, iSee Video eop kits use two
Homeplug ethernet-over-power modules. They simply plug into a standard
electrical outlet, transformer-style, and use the existing power lines of a
home or business to transmit the cameras’ video signals. One Homeplug
is connected to the camera wire; likewise, a second EOP homeplug
is connected to the iSee Video G-Box, which is also plugged into the
customers’ modem. The G-Box automatically data-port forwards the video
data for streaming on the internet.
Together the Homeplugs create a powerline network transmitting the
video signals at up to 200 megabits per second, across the phases of
typical residential multiphase power systems to the internet. (Up to four
cameras are supported per system).
Kits come with 12 month server access
Reliable account access allows accounts to look-in on their premises
anytime, anywhere. The kit includes 12 months account access which
provides:
•Password-protected video, available for live, online viewing 24/7
•Access to the Napco video server to view video stored in their personal
archive by triggered motion-detection events with time-/date-stamp.
•50 MB of scalable storage per account, allowing the archiving of
approximately (75) 10 second video clips (pre motion-triggered event;
post motion-triggered event) per camera account with upgrades
available.
•Log in screen and account management tools
Clips include time-/date-stamp, and can be exported, to prevent being
routinely overwritten, by saving them to a PC as a Flash video file.
The consumer’s screen (used to view their premises) can be easily dealer-
customized; the installation company simply uploads their company logo,
and contact information once, for all their accounts.
Works with all standard web browsers
iSee Video’s powerful proprietary firewall-buster technology ensures all
consumers can view their video anywhere, anytime, even on PCs within
high-security firewall networks, such as those in the workplace. Plus,
there is no software to load on consumer’s PC or phones and iSee Video
supports all their internet browser formats, Mac, Windows, Linux and all
web-enabled cellphones, from Razrs to iPhones, from Blackberrys to LGs.
Advanced motion detection to capture events
Pixel-based motion detection with adjustable sensitivity can be used
to trigger the capture of video events. Motion is detected when the
system analyzes video of a specific area of interest and pixel changes
are detected. This feature can be
always on or scheduled to be on
at certain times of the day/night,
by the consumer or installer. When
activated, an e-alert can be sent to
the account automatically, to call
attention to the event in progress
and/or for archived review at a later
time.
To choose an area of interest in
which to detect motion and trigger
event recording:
•Select the area to monitor using a dynamic square target zone.
•The zone can altered and chosen at any time, online
Specications:
Camera:
VGA resolution, 640x480, 320x240, 160x120
Image Sensor CMOS, 1/6” VGA Resolution
Lens F2.8 Fixed Focus, Effective Range: 0.2M to infinity
Cameras supported, 4 per system
Camera operation: Up to 25 FPS (frames per second) with MPEG4 latest
codecs.
Video Options Motion-Detection, Time Stamp, Text Overlay
LAN Ethernet 10/100BaseT
LED Indicators Power, Active, Network
Connector Ethernet RJ-45, SPK, DC Power, Reset
Power Adapter 5V/1A, 100/240 VAC
Certification CE/FCC
Dimensions (HxWxD) 96 x 90 x 36 mm (3.8” x 3.5” x 1.4”)
Weight 131g (0.29lb.) without stand, 256g (0.56lb.) with stand
Plug-in Powerline Ethernet Adapter, with supplied cable: 4 x 2 ¾ x 2 (H x W
x D), Inches
Input Voltage: AC 100-240V,100mA, 50-60Hz
Class 2 AC Adaptor: 9VAC
Dimensions (supports 4 cameras): 4 7/8 x 8 1/4 x1 ½ (H x W x D), Inches
Current: 600mA (Transformer rating)
EOP-Home Plug:
Data Rate: Up to 200 Mbps
Port: Ethernet,10Base-T/100Base-TX
LEDs: Power, PowerLine, Ethernet
Cabling Type: Cat5, RJ-45
Security Feature: AES Encryption
Security Key Bits: 128
Power: One AC Plug, 100-240V, 50-60 Hz
Standards: HomePlug AV Standard, IEEE 802.3, IEEE 802.3u
Compliances: IEEE 802.3, IEEE 802.3u
Ordering information:
VCAM1-EOPKT1/12 Complete eop one camera kit:
1 hi-res camera, G-Box video-web interface, 2 eop homeplugs, 15’ (2) & 3’
cables, ethernet RJ45,12-months account access on the Napco server for 1
camera.
VCAM1-EOPKT2/12 Complete eop two camera kit:
2 hi-res cameras, G-Box video-web interface, 3 eop homeplugs, 15’ (2) & 3’
cables, ethernet RJ45, 12-months account access on the Napco server for 2
cameras.
VCAM1-EOP1/12 Add-on eop camera kit:
(For expansion of kits above): 1 additional hi-res camera, 1 eop homeplug, 15’
(2) & 3’ cables, ethernet RJ45, 12-months account access on the Napco server
for 1 additional cameras. (Note: System supports a maximum of 4 cameras.)
internet
G-Box
EOP Homeplugs
Cameras View from PC View from
cellphone
EOP
Homeplug
Modem
1-800-645-9445
www.napcosecurity.com
Napco Security Systems, Inc. NASDAQ: ‘NSSC’ ©Napco 7/08 A575
