NARDA L3Harris AMB-8059 User manual

NARDA
Safety
Test
Solutions
S.r.l. Socio Unico
Sales & Support:
Via Rimini, 22
20142 - Milano (MI)
Tel.: [phone]
Fax: [phone]
Manufacturing Plant:
Via Benessea, 29/B
17035 - Cisano sul Neva (SV)
Tel.: [phone]
Fax: [phone]
http://www.narda-sts.it
SERIAL NUMBER OF THE INSTRUMENT
You can find the Serial Number near the probe connector.
Serial Number is in the form: 000XY00000.
The first three digits and the letters are the Serial Number prefix, the last four digits are
the Serial Number suffix. The prefix is the same for identical instruments, it changes only
when a configuration change is made to the instrument.
The suffix is different for each instrument.
Document AMB8059EN-10122-1.32 – Copyright ©NARDA 2021
AMB-8059
MULTI-BAND EMF AREA MONITOR
User’s Manual
AMB-8059/00
AMB-8059/01
AMB-8059/02
AMB-8059/03
This version of the User’s Manual is valid for all the devices which serial
number starts with 14x or higher.

II Note and symbols
NOTE:
® Names and Logo are registered trademarks of Narda Safety Test Solutions GmbH and L3 Communications
Holdings, Inc. – Trade names are trademarks of the owners.
If the instrument is used in any other way than as described in this User’s Manual,
it may become unsafe.
Before using this product, the related documentation must be read with great care and fully understood to
familiarize with all the safety prescriptions.
To ensure the correct use and the maximum safety level, the User shall know all the instructions and
recommendations contained in this document.
This product is a Safety Class III instrument according to IEC classification and has
been designed to meet the requirements of EN61010-1 (Safety Requirements for
Electrical Equipment for Measurement, Control and Laboratory Use).
In accordance with the IEC classification, the power supply of this product meets requirements Safety Class II and
Installation Category II (having double insulation and able to carry out mono-phase power supply operations).
It complies with the requirements of Pollution Class II (usually only non-conductive pollution). However,
occasionally it may become temporarily conductive due to condense on it.
The information contained in this document is subject to change without notice.
EXPLANATION OF ELECTRICAL AND SAFETY SYMBOLS :
You now own a high-quality instrument that will give you many years of reliable service.
Nevertheless, even this product will eventually become obsolete. When that time comes, please
remember that electronic equipment must be disposed of in accordance with local regulations.
This product conforms to the WEEE Directive of the European Union (2002/96/EC) and belongs to
Category 9 (Monitoring and Control Instruments). You can return the instrument to us free of
charge for proper environment friendly disposal. You can obtain further information from your
local Narda Sales Partner or by visiting our website at www.narda-sts.it .
Warning, danger of electric shock
Earth
Read carefully the Operating Manual and its
instructions, pay attention to the safety symbols
Unit Earth Connection
Earth Protection Equipotential
KEY TO THE SYMBOLS USED IN THIS DOCUMENT:
The DANGER sign draws attention to a serious risk to a person’s safety, which,
if not avoided, will result in death or serious injury. All the precautions must be
fully understood and applied before proceeding.
The WARNING sign indicates a hazardous situation, which, if not avoided,
could result in death or serious injury. All the precautions must be fully
understood and applied before proceeding.
The CAUTION sign indicates a hazardous situation, which, if not avoided,
could result in minor or moderate injury.
The NOTICE sign draws attention to a potential risk of damage to the
apparatus or loss of data.
The NOTE sign draws attention to important information.

Contents III
Contents
Page
Safety recommendations and instructions ….....................................
EC Declaration of Conformity .........................….................................
IX
X
1 General information
Page
1.1 Documentation...................................................….......................................
1.2 Introduction…..............………………............................................................
1.3 Standard accessories AMB-8059/00 and AMB-8059/02……......................
1.4 Standard accessories AMB-8059/01 and AMB-8059/03…….......................
1.5 Optional accessories…………………………………………….......................
1.6 Main specifications......................................................................................
1.7 AMB-8059/00 and AMB-8059/02………..……...….......................................
1.7.1 Top panel (inside the protective cover)………….......................................
1.7.2 Bottom panel (inside the protective cover)………….................................
1.7.3 Battery compartment cover (inside the protective cover) ….....................
1.7.4 Battery for AMB-8059/00 and AMB-8059/02……………….......................
1.7.5 Tamperproof Interlock (inside protective cover)…………….....................
1.7.6 Base plate…..………………………………………………….......................
1.7.7 Plug (User port)………………………………………………............ ........
1.8 AMB-8059/01 and AMB-8059/03………..……...…...................................
1.8.1 Top panel (inside the protective tube)…………............................ ........
1.8.2 Bottom panel (inside the protective cover)………………….......... ........
1.8.3 Tamperproof Interlock (inside protective cover)….………............ ........
1.8.4 Base plate ……………………………………..………………..................
1.8.5 Plug (User port)………………………………………………............ ........
1.8.6 Data-Supply Connector………………………………………...................
1.8.7 Solar module…….……………………………………………...................
1.8.7.1 8059 Optical link………………………………………..........................
1-1
1-1
1-2
1-3
1-4
1-5
1-21
1-21
1-21
1-22
1-22
1-23
1-24
1-24
1-25
1-25
1-25
1-26
1-26
1-27
1-27
1-28
1-29
2 AMB-8059 Installation and first use with NardaAMConfigurator Page
2.1 Introduction.................................…................................................... ........
2.2 Initial inspection........................….................................................... ........
2.3 Working environment............…............................................. .......... ........
2.4 Return for repairs.........……….............................................. .......... ........
2.5 Cleaning…………………..........................................................................
2.6 Installation – Standard configuration.....................…………............. ........
2.6.1 Installation of AMB-8059/00 and AMB-8059/02……….........................
2.6.2 Installation of AMB-8059/01 and AMB-8059/03…………......................
2.7 Installation – Dual probe configuration.................…………............. ........
2.8 Installation – Car Mounting Kit configuration................……............. ........
2.9 GSM Modem........................................................................ ............ ........
2.9.1 SIM card……………………………………...............………....................
2.9.2 Status of led in relation to the status of the monitoring station...... ........
2.10 Micro SD……………………………………………………..........................
2.11 Field probes…………………………......................….................................
2.12 RF Signals of dangerous intensity…………..………................................
2.13 Signals with AM modulation…………………………….............................
2.14 Controlling the internal batteries................…….......... .......... .......... ........
2.15 Power consumption and operating mode….…………..............................
2.16 Use of NardaAMConfigurator………………………………………….........
2-1
2-1
2-1
2-1
2-2
2-3
2-5
2-6
2-8
2-12
2-19
2-19
2-20
2-21
2-22
2-22
2-22
2-23
2-24
2-25

IV Contents
3 8059SW-02 & NardaEMFGPSLogger - User’s guide and Data Display Page
8059SW-02 User’s guide
3.1 Introduction………….........................................….................................................
3.2 Hardware requirements............................…......…………………………………….
3.3 Software installation…….........................…..........................................................
3.4 Password management………………………………………………………………..
3.4.1 Entering the TERMINAL password…………………………………………………
3.4.1.1 Changing the TERMINAL password……………………………………………..
3.4.2 Entering the SETTING password………………………………...........................
3.4.2.1 Changing the SETTING password………………………….……………………
3.4.3 Entering the DEVICE password…………………………………………………….
3.4.3.1 Changing the DEVICE password……..………………………………………….
3.5 “Point to Point” Main window………….….…….………..………..………………
3.6 Station management………………………………………........................................
3.6.1 Entering a new station………………………...…………......................................
3.6.2 Removing a station…….……….…………..…………..……………………………
3.6.3 Editing a station……..………………..………………………………………………
3.6.4 Automatic data downloads……………………………..……………………………
3.6.5 Answering………………………………………..….……......................................
3.6.6 Calling……………………………….……………….…...……...............................
3.6.7 Auto ASCII File…………………………………………..……...............................
3.6.8 Autoload events…….…………………………………..…….………………………
3.7 Data management……………………………………………………........................
3.7.1 Filing data……………………………………………………………………………...
3.7.2 Exporting data…………………….…………………………………………………..
3.8 Direct reading……………………………………………………………………………
3.9 Send settings…………….……………………………………………………………...
3.10 Calendar of measurements………………….……………………………………….
3.11 Control window………………….…………………………………………………….
3.12 Description of controls............…...............................…………………………….
3.12.1 Alarm....................................................................………………………………
3.12.1.1 Notify alarms through………………………………………............................
3.12.1.2 Last field………………………………………………………………………….
3.12.1.3 Averaging field…………………………………………………………………..
3.12.1.4 Max field alarm setting………………………………………………………….
3.12.1.5 Battery section…………………………………………………………………..
3.12.1.6 Probe section…………………………………………………………………….
3.12.1.7 Temperature limit……………………………………………………………….
3.12.1.8 Relative humidity limit…………………………………………………………..
3.12.1.9 Case open……………………………………………………………………..
3.12.2 Schedule for Modem............................................…………………………….
3.12.3 Schedule for SMS/Wifi...........................................……………………………
3.12.4 Rate Settings.......................….............................……………………………..
3.12.5 Get DATA.............................................................……………………………..
3.12.6 Station Date & Time.............................................……………………………..
3.12.7 Firmware Update..................…............................……………………………..
3.12.8 GSM Off on Exit……………………………………………………………………
3.12.9 Device Password………………………………………………………………….
3.13 General commands.................................................................…………………
3.13.1 Read Station Conf…………………………………………………………………
3.13.2 Enable setting………………………………………………………………………
3.13.3 Hang&Exit…………………………………………………………………………..
3.14 “FTP” Main window………….….…….………..………..………………………..
3.15 Data section…………………………………………………………………………..
3.16 Alarm section…………………………………………………………………………
3.17 Communication section……………………………………………………………..
3.18 Software update..…………………………………………………………………….
3.19 Uninstalling Software………………………………………………………………..
3-1
3-2
3-3
3-7
3-7
3-9
3-10
3-11
3-12
3-12
3-13
3-15
3-15
3-17
3-17
3-18
3-19
3-20
3-20
3-21
3-21
3-21
3-22
3-23
3-24
3-25
3-26
3-27
3-30
3-31
3-31
3-32
3-32
3-33
3-33
3-34
3-34
3-34
3-35
3-36
3-37
3-39
3-40
3-41
3-42
3-42
3-42
3-42
3-42
3-42
3-43
3-44
3-45
3-46
3-49
3-50

Contents V
8059SW-02 Data display
3.20 Introduction…………………………………………………………………………….
3.21 Calendar………………………………………………………………………………..
3.22 Data window……………………………………………………………………………
3.23 Main commands.......................................…..…..…...........................................
3.23.1 File……………………………………………………….…………………………..
3.23.2 Option………………………………………………….…………………………….
3.23.3 Trace………………………………………………….……………………………..
3.23.4 Marker………………………………………………….…………………………….
3.23.5 Vertical…………………………....…………………..……………………………..
3.24 Secondary commands……………………………………………………………….
3.24.1 Save Files…………………………………………………………………………...
3.24.1.1 Save File in ASCII format……………………………………………………….
3.24.2 Open Files…………………………………………………………………………..
3.24.2.1 Open Autotext file………………………………………………………………..
3.24.3 Show table file…..……………………………………..……………………………
3.24.4 ClipBoard……………………………………………….…………………………...
3.24.5 Zoom Mode…………………………………………….……………………………
3.24.6 Comment……………………………………………….……………………………
3.24.7 Redraw……………………………………………………………………………….
3.24.8 Appearance………………………………………………………………………….
3.24.9 Setup…………………………………………………………………………………
3.24.9.1 Color palette………………………………………………………………………
3.24.10 Limit…………………………….…………………………………………………...
3.24.10.1 SCREEN sample……………….………………………………………………..
3.24.11 Software release………………………………….…………………………….…
3.25 Graph window...........…......................................................................................
3.26 Status window………………………………………………………………………...
3.27 Importing data to Word or Excel…………..……….…………………………….....
NardaEMFGPSLogger User’s guide
3.28 Hardware requirements………………………………………………………………
3.29 Installation……………………………………………………………………………..
Disable sleep mode…………………………………………………………………………
3.30 Run the software………………………………………………………………………
3.31 Uninstall software……………………………………………………………………..
NardaEMFGPSLogger Data display
3.32 KML data display………………………………………………………………………
Page
3-51
3-51
3-52
3-54
3-54
3-54
3-55
3-56
3-57
3-58
3-58
3-59
3-61
3-63
3-65
3-66
3-67
3-67
3-68
3-68
3-69
3-69
3-70
3-70
3-70
3-70
3-71
3-71
Page
3-72
3-72
3-75
3-76
3-85
Page
3-87
4 First connection - Point to Point and FTP communication
First connection - Point to Point communication
4.1 General Information…………………………………………………….....................
4.2 First connection - Setting stations to Point-to-point mode………….....................
4.2.1 Optical, Point to Point ……………………………………………………………..
4.2.2 WiFi, Direct AP, Point to Point…………………………………….......................
4.2.3 WiFi Over IP, Point to Point………………………………………………………..
4.2.4 Modem, point to point………………………………………………………………
Setting station RTC (Real Time Clock)…………………………………………………
How to switch the WiFi or the GSM modem on……………………………………….
Programmed mode…………………………………………………………...................
Spontaneous mode……………………………………………………………………….
Automatic mode………..………………………………………………………………….
Page
4-1
4-3
4-8
4-10
4-15
4-17
4-20
4-21
4-22
4-22
4-22

VI Contents
First connection - FTP communication
4.3 General Information……………………………………………………................
4.3.1 Introduction……………………………………………….................................
4.3.2 Brief description of GPRS communication……………………………………
4.3.3 Monitoring networks…………………………………….................................
4.3.4 System operation in GPRS mode…………………………………….............
4.3.5 Some advantages………………………………………..................................
4.4 General Requirements…………………………………….................................
4.4.1 Remote station………………………………………….……………................
4.4.2 FTP server requirements………………………………......…………............
4.4.3 Brief operating description and file structure……….………………..............
4.4.4 Structure…………………………………………………......………….............
4.4.4.1 CFG File (configuration)………………………………….……….... ............
4.4.4.2 FLD File (Read)………………………………………..….………… ............
4.4.4.3 Record File (Write)………………………………………..………… ............
4.4.4.4 FLD File (Write)………………………………………..….………… ............
4.4.4.5 Event File (Write)………………………………………....………… ............
4.5 First installation - Setting stations to FTP mode ...…………………. ............
4.5.1 “Modem, FTP mode” or “Wi-Fi, Remote IP, FTP mode”…………. ............
4.6 AMB-8059 Firmware updates in FTP mode……………………………............
4-26
4-26
4-26
4-26
4-27
4-27
4-28
4-28
4-29
4-29
4-29
4-29
4-30
4-30
4-30
4-31
4-31
4-33
4-53
5 Command protocol Page
5.1 Introduction………………………………..…………………………………………
5.2 List of commands................................................……………………………….
5.3 Query COMMANDs........................................................................................
5.4 Setting COMMANDs......................................................................................
5.5 FTP-GPRS COMMANDs................................................................................
5.6 FTP on Multi-band EMF Area Monitor AMB-8059……………………………
5.6.1 Fundamentals…………………………………………………………………….
5.6.2 Structure…………………………………………………………………………..
5.6.3 Configuration (read)....……………………………….....................................
5.6.4 FLD file (read)…………………………………………………………………….
5.6.5 Record file (write)…………………………………………………………………
5.6.6 FLD file (write)……………………………………………………………………
5.6.7 Event file (write)………………………………………………………………….
5.6.8 Setting status (write)…………………………………………………………….
5.6.9 Checksum algorithm..…………………………………………………………..
5.8 Download Description AMB-8059 for Single and three bands probes………
5.8.1 Command mode…………………………………………………………………
5.8.2 FTP mode………………………………………………………………….
5.8.3 Single and Three Bands Probes Structure description…………………….
5.9 Download Description AMB-8059 for 4-Band Probes…………………………
5.9.1 Command mode…………………………………………………………………
5.9.2 GPRS/ftp mode………………………………………....................................
5.9.3 4-Band Probes Structure description……………..…………………………
5.10 Download Description AMB-8059 for Dual probe operation………………..
5.10.1 Command mode………………………………………………………………
5.10.2 GPRS/ftp mode……………………………………………………………….
5.10.3 Piggy Back Probes Structure description………….................................
5-1
5-2
5-5
5-16
5-25
5-28
5-28
5-28
5-29
5-32
5-32
5-33
5-33
5-34
5-37
5-38
5-38
5-38
5-38
5-46
5-46
5-46
5-46
5-54
5-54
5-54
5-54

Contents VII
6 Accessories
Page
6.1 Introduction……………………………….……….……………………………….
6.2 Initial inspection.................................................…....…………………………
6.3 Operating environment.......................................…..………………………….
6.4 Returning for repair...........................…............….….…………………………
6.5 Cleaning.................................................................………..………………….
6.6 Battery charger (AMB-8059/01 and AMB-8059/03 only)……………………..
6.6.1 Recharging batteries stations equipped with solar panel………………….
6.7 8059-MAST Supporting pole…………………………………………………….
6.7.1 Installation of the AMB-8059 on the mast…………………........................
Indoor and outdoor use……………………………………………………………….
Bags…………………………………………………………………………………..…
6.8 USB-OC Optical USB Converter……………………………………………..…
6.8.1 Introduction…………………………………………………………….………..
6.8.2 Installation………………………………………………………………………
6.9 8059 Optic-link (optional)………………………………………………………
6.10 8059/CMK Car Mounting Kit (optional)……………………………….………
6.10.1 Introduction……………………………………………………………………
6.11 Two-wire USB cable (optional)………………….…………………………….
6.11.1 Introduction……………………………………………………………………
6.11.2 Installation……………………………………………………………………..
6.12 8059/IP66K kit IP66 Adapter..………………….…………………………….
6.12.1 Introduction……………………………………………………………………
6.12.2 Installation……………………………………………………………………..
6-1
6-1
6-1
6-1
6-1
6-2
6-2
6-4
6-4
6-6
6-9
6-10
6-10
6-10
6-11
6-12
6-12
6-13
6-13
6-14
6-15
6-15
6-15
7 Action of the wind into AMB-8059 Page
7.1 Introduction………………………………..………………………..........................
7.2 AMB-8059/00 and AMB-8059/02 without swivel joint………….........................
7.3 AMB-8059/00 and AMB-8059/02 with swivel joint……………..........................
7.4 AMB-8059/01 and AMB-8059/03 without swivel joint………….........................
7.5 AMB-8059/01 and AMB-8059/03 with swivel joint……………..........................
7-1
7-2
7-4
7-6
7-8
8 Troubleshooting & F.A.Q Page
8.1 Troubleshooting …………………………….……………………..........................
8.2 F.A.Q. ……………………………………………………………….......................
8-1
8-9

VIII Contents
Figures
Figure Page
1-1
1-2
1-3
1-4
1-5
1-6
1-7
1-8
1-9
1-10
1-11
1-12
1-13
1-14
1-15
1-16
1-17
1-18
1-19
1-20
2-1
2-2
2-3
2-4
2-5
2-6
2-7
2-8
2-9
2-10
4-1
4-2
4-3
4-4
4-5
4-6
4-7
4-8
4-9
4-10
4-11
4-12
4-13
6-1
6-2
6-3
6-4
6-5
6-6
6-7
6-8
6-9
7-1
7-2
7-3
7-4
EP-1B-01 probe…………………………………………………….….............
EP-3B-01 probe……………………………………………………..………….
HP-1B-01 probe….…………………………………………………...............
EP-4B-01 probe…………………………………….………………….............
EP-1B-03 probe…………………………………………………………………
EP-4B-02 probe…………………………………….……………….................
EP-1B-04 probe………………………………………………………………….
EP-1B-05 probe…………………………………………………………………
EP-1B-06 probe…………………………………………………………………
EP-1B-08 probe…………………………………………………………………
AMB-8059/00 and AMB-8059/02 top panel………..……......…….…………
AMB-8059/00 and AMB-8059/02 battery compartment cover…................
AMB-8059/00 and AMB-8059/02 bottom panel………..…….….................
AMB-8059/00 and AMB-8059/02 Tamperproof interlock……………………
AMB-8059/00 and AMB-8059/02 base plate………………………………….
AMB-8059/01 and AMB-8059/03 top panel…...……............…….………..
AMB-8059/01 and AMB-8059/03 bottom panel……………….…...............
AMB-8059/01 and AMB-8059/03 Tamperproof interlock ………………….
AMB-8059/01 and AMB-8059/03 base plate…………………….…………..
DB9 Female front side view ……………………………………….………….
AMB-8059/01……………………………………………………………………
AMB-8059/03……………………………………………………………………
AMB-8059/00……………………………………………………………………
AMB-8059/02……………………………………………………………………
HP-1B-01 top panel…………………………………………………………….
Dual probe configuration: EP-1B-01 mounted as secondary probe……….
Dual probe configuration: EP-1B-04 mounted as secondary probe………
AMB-8059 area monitor Dual-Probe configuration………………………….
Car Mount Kit……………………………………………………………………
SIM Card......................……..….....................…..………………..………….
FTP communication modes………………………………….……………….
Point to Point communication modes………………………………………..
“Direct readings” button…..………………………………….………………..
“CALL” button…………………………………………………………………..
“WiFi, Direct AP Point to Point” settings.....………………………………...
“WiFi Over IP, Point to Point” settings....………………………………….…
“Modem, Point to Point” settings………………………………………….….
“Modem, FTP mode” settings………………………………………………...
“Wi-Fi, Remote IP, FTP mode” settings……………………………………..
Schedule for FTP frame……………………………………………………….
Schedule for SMS/WiFi frame...………………………………………………
Schedule for GPS frame……………………………………………………….
SIM card installation……………………………………………………………
AMB-8059/00 and AMB-8059/02 on its mast without swivel join…………
AMB-8059/00 and AMB-8059/02 on its mast with swivel joint ..………….
AMB-8059/01 and AMB-8059/03 on its mast without swivel join………….
AMB-8059/01 and AMB-8059/03 on its mast with swivel joint ..………….
Swivel joint……….………………………………….…………………………..
Horizontal position of AMB-8059/00 and AMB-8059/02……………,……..
Horizontal position of AMB-8059/01 and AMB 8059/03……………………
USB-OC adapters………………………………………………………………
Two-wire USB cable connectors………………………………………
Weight Ballast variation in comparison to the wind speed for AMB-
8059/00 and AMB-8059/02 without joint…………………………..…
Weight Ballast variation in comparison to the wind speed for AMB-
8059/00 and AMB-8059/02 with joint………………………………...
Weight Ballast variation in comparison to the wind speed for AMB-
8059/01 and AMB-8059/03 without joint……………………………..
Weight Ballast variation in comparison to the wind speed for AMB-
8059/01 and AMB-8059/03 with joint………………………………...
1-11
1-12
1-13
1-14
1-15
1-16
1-17
1-18
1-19
1-20
1-21
1-21
1-22
1-23
1-24
1-25
1-25
1-26
1-26
1-29
2-3
2-3
2-4
2-4
2-10
2-10
2-10
2-11
2-12
2-19
4-1
4-2
4-9
4-9
4-11
4-16
4-17
4-34
4-35
4-47
4-47
4-48
4-49
6-4
6-4
6-4
6-4
6-6
6-6
6-7
6-10
6-13
7-3
7-5
7-7
7-9

Contents IX
Tables
Table Page
1-1 Technical specifications ……………………….…................................................. 1-5
1-2 Measurement/acquisition functions………………................................................ 1-5
1-3 General Specifications……………………………................................................ 1-6
1-4 Technical specifications for AMB8059/00 with Car mounting kit………………… 1-7
1-5 Max acquisition time ……………...…….…………............................................... 1-8
1-6 Settings/Queries ……………….……….…………................................................ 1-8
1-7
1-8
1-9
Field probes………………....…........……………….............................................
Probe combinations on Dual-probe configuration…………………………….…..
Technical Specifications of Field Probes............................................................
1-9
1-10
1-11
2-1 Led Micro SD status……………………………………………………………….… 2-21
6-1
6-2
6-3
8059-MAST Technical Specifications….…………..............................................
USB-OC Technical Specifications……………………………………………….….
Two-wire USB cable Specifications………………………………………………....
6-4
6-10
6-13
7-1 Wind resistance of the AMB-8059/00 and AMB-8059/02 without swivel joint….. 7-2
7-2 Wind resistance of the AMB-8059/00 and AMB-8059/02 with swivel joint……… 7-4
7-3 Wind resistance of the AMB-8059/01 and AMB-8059/03 without swivel joint….. 7-6
7-4 Wind resistance of the AMB-8059/01 and AMB-8059/03 with swivel joint……… 7-8

X Safety consideration
SAFETY RECOMMENDATIONS AND INSTRUCTIONS
This product has been designed, produced and tested in Italy, and it left the factory in conditions fully
complying with the current safety standards. To maintain it in safe conditions and ensure correct use,
these general instructions must be fully understood and applied before the product is used.
•When the device must be connected permanently, first provide effective grounding;
•If the device must be connected to other equipment or accessories, make sure they are all safely
grounded;
•In case of devices permanently connected to the power supply, and lacking any fuses or other
devices of mains protection, the power line must be equipped with adequate protection
commensurate to the consumption of all the devices connected to it;
•In case of connection of the device to the power mains, make sure before connection that the voltage
selected on the voltage switch and the fuses are adequate for the voltage of the actual mains;
•Devices in Safety Class I, equipped with connection to the power mains by means of cord and plug,
can only be plugged into a socket equipped with a ground wire;
•Any interruption or loosening of the ground wire or of a connecting power cable, inside or outside the
device, will cause a potential risk for the safety of the personnel;
•Ground connections must not be interrupted intentionally;
•To prevent the possible danger of electrocution, do not remove any covers, panels or guards installed
on the device, and refer only to NARDA Service Centers if maintenance should be necessary;
•To maintain adequate protection from fire hazards, replace fuses only with others of the same type
and rating;
•Follow the safety regulations and any additional instructions in this manual to prevent accidents and
damages.

EC Conformity XI
Dichiarazione di Conformità
EU Declaration of Conformity
In accordo alla Decisione 768/2008/EC, conforme alle direttive EMC 2014/30/UE, Bassa Tensione 2014/35/UE e
RoHS 2011/65/UE, ed anche alle norme ISO/IEC 17050-1 e 17050-2.
In accordance with the Decision 768/2008/EC, compliant to the Directives EMC 2014/30/EU, Low Voltage 2014/35/EU
and RoHS 2011/65/EU, also compliant to the ISO/IEC standard 17050-1 and 17050-2
Il costruttore
The manufacturer
narda Safety Test Solutions S.r.l. Socio Unico
Indirizzo
Address
Via Benessea, 29 / B
I-17035 Cisano sul Neva (SV) - Italy
sulla base delle seguenti norme europee armonizzate, applicate con esito positivo:
based on the following harmonized European Standards, successfully applied:
EMC - Emissioni:
EMC - Emission:
EN 61326-1 (2013)
EMC - Immunità:
EMC - Immunity:
EN 61326-1 (2013)
Sicurezza:
Safety:
EN 61010-1 (2010)
dichiara, sotto la propria responsabilità, che il prodotto:
declares, under its sole responsibility, that the product:
Descrizione
Description
SISTEMA DI MONITORAGGIO MULTI-BANDA
MULTI-BAND EMF AREA MONITOR
Modelli
Models
AMB-8059/00, AMB-8059/01, AMB-8059/02, AMB-8059/03
è conforme ai requisiti essenziali delle seguenti Direttive:
conforms with the essential requirements of the following Directives:
Bassa Tensione
Low Voltage
2014/35/EU
Compatibiltà Elettromagnetica
EMC
2014/30/EU
RoHS
RoHS
2011/65/EU
Cisano sul Neva, 03 May 2017 Egon Stocca
General Manager

XII EC Conformity
This page has been left blank intentionally

General Information 1-1
1 – General Information
1.1 Documentation
This Users Manual contains the following annexes:
•A form to be returned to NARDA with the device when requesting
service.
•A checklist of the accessories included in the shipment.
1.2 Introduction
The AMB-8059 family products are revolutionary, accurate and reliable
solutions for remote and continuous monitoring of electromagnetic fields.
AMB-8059/01 and AMB-8059/03 are powered by high capacity internal
batteries and solar panels that ensure practically unlimited autonomy under
conditions of normal sunlight.
For indoor applications, the autonomy of the unit is at least 80 days after full
battery charge.
AMB-8059/00 and AMB-8059/02 don’t have any solar cells, as they are
powered by replaceable high capacity primary battery for several months
autonomy.
The system of acquisition makes it possible to program each parameter
and transfer to a PC the data saved into the unit. The recorded data can be
viewed either as a graph or as a table.
All AMB-8059 models are equipped with internal WiFi and GPS modules.
In the event of any alarm, such as a threshold setting being exceeded, or
any attempt to tamper with the remote unit, or a breakdown of the unit,
AMB-8059/02 and AMB-8059/03, which are equipped with 4G GSM/GPRS
modem, can be programmed to send a SMS, describing the alarm, to the
user’s mobile phone, and/or generate a point-to-point data call to the
controller PC. Station set for Modem/FTP communication mode can be
programmed to access the user’s FTP server and download measurement
results as soon as any alarm condition occurs.
Document AMB8059EN-10122-1.32 - © NARDA 2021

1-2 General Information
1.3 Standard accessories
AMB-8059/00 and
AMB-8059/02
Standard accessories included with AMB-8059/00 and AMB-8059/02 units
are:
A – Lithium-Ion Battery;
B – USB Cable – USB(A)/USB(B) 1.8m (AMB-8059/02 model only).
C – Swivel joint for installation on the supporting pole;
D – 2.5 mm and 5 mm Allen keys for socket –head screws;
E – Software 8059SW-02 on Software Media
F – User’s Manual with Return Form for repair;
G – Checklist of the accessories;
H – Calibration Certificate;
I – USB-OC Optical Converter (AMB-8059/00 model only);
J - Cable, FO Duplex, RP-02, 10m (AMB-8059/00 model only);

General Information 1-3
1.4 Standard accessories
AMB-8059/01 and
AMB-8059/03
Standard accessories included with AMB-8059/01 and AMB-8059/03 units
are:
A – AC/DC Converter with plug adapters;
B – Assembled Solar Panel;
C – USB Cable 2.5m - USB(A)/USB(B);
D – Ethernet Cable;
E – Swivel joint for installation on the supporting pole;
F – 2.5 mm and 5 mm Allen keys for socket – head screws;
G – Software 8059SW-02 on Software Media;
H – User’s Manual with Return Form for repair;
I – Checklist of the accessories;
L – Calibration Certificate.

1-4 General Information
1.5 Optional accessories
Accessories supplied separately (on charge) for all models:
•8059-MAST including;
M - Metal supporting T-shaped base measuring 60 x 60 cm
N - Fiberglass 60mm pole, 2 m long;
O - Tool Kit of screws and clamps.
P - n°3 bags for ballast;
Q - n° 2 Cable ties;
•Field probe EP-1B-01;
•Field probe EP-1B-03;
•Field probe EP-1B-04;
•Field probe EP-1B-05;
•Field probe EP-1B-06;
•Field probe EP-1B-08
•Field probe EP-3B-01;
•Field probe EP-4B-01;
•Field probe EP-4B-02;
•Field probe HP-1B-01;
•Cable, FO Duplex, RP-02, 20m (for AMB-8059/00 only)
•Cable, FO Duplex, RP-02, 40m (for AMB-8059/00 only)
•FO-8059/10 fiber optic 10m (for AMB-8059/01 and AMB-8059/03 only)
•FO-8059/20 fiber optic 20m (for AMB-8059/01 and AMB-8059/03 only)
•FO-8059/40 fiber optic 40m (for AMB-8059/01 and AMB-8059/03 only)
•8059/CMK (available for AMB-8059/00 model only) Car Mounting Kit including:
R - 8059/CMK Car Mounting Kit
- Allen Key 1.5 mm
- Narda EMFGPSLogger Software on Software Media
- Soft carrying case for Magnetic plate
- Soft carrying case for Area monitor
•8059-Optical link (available for AMB-8059/01 and AMB-8059/03 only)
•Two-wire USB Cable 2.5m - USB (A) to IP67 USB (B) (available for AMB-8059/01
and AMB-8059/03 only)
•8059/IP66K Kit IP66 adapter (available for AMB-8059/01 and AMB-8059/03 only)
•Radome dual probe

General Information 1-5
1.6 Main Specifications Tables 1-1 – 1-2 list the specifications of all models.
TABLE 1-1 Technical Specifications
Frequency range
Depending on the probe
Dynamic range Depending on the probe
Resolution Depending on the probe
Sensitivity Depending on the probe
Accuracy Depending on the probe
Measurement Units V/m, kV/m, nT, µT, mT. Depending on the probe
Measured field Total field, average and Peak (MAX)
Sampling 1 S/s
(10)
TABLE 1-2 Measurement/acquisition functions
Memorization interval from 30 sec to 15 min
Internal Memory over 512 Mb
Max Data Storage Capacity over 364 days with 1 acquisition every minute. (See table)
(before data are overwritten)
External memory Micro SD card (not included); max capacity up to 16 GB
Data download Manual
Automatic managed by the unit at predefined timings
(1)
Automatic by PC
(2)
Automatic creation of a TXT and .BMP file after download
Functions AVG, RMS, maximum peak; daily report via SMS
(3)
Display and marking of acquired data
(11)
Field strength alarm two programmable field strength thresholds (warning and alarm) with automatic
notice both of exceeding the limits and returning within the limits
Clock real time internal clock
Messages SMS which can be sent to up to 10 mobile phones simultaneously (see table)
(3)
Sensor display of model and calibration date
Battery management Every record includes Battery Voltage and Charge Current value
Temperature management Every record includes Internal Temperature value
Humidity management Every record includes Internal Humidity value
GPS coordinates Programmable record

1-6 General Information
TABLE 1-3 General Specifications
GSM module Worldwide LTE, UMTS/HSPA+/GSM/GPRS/EDGE coverage
(3)
Wi-Fi WiFi (802.11 b/g)
Field Probes Interchangeable, several models available, single and multi probe operation
Interfaces RS232, USB, Ethernet, Optical
(6)
,Micro SD Card;
4G modem
(3)
.
Protection sensor to notify case opening
Other Alarms protective case opening, internal overheat, internal humidity, battery low, battery
overload (model AMB-8059/01 and AMB-8059/03 only), probe malfunction, field
over limit.
Internal battery
AMB-8059/00 and AMB-8059/02 Non rechargeable primary battery, lithium LSH20, 3,6V, 13A/h;
AMB-8059/01 and AMB-8059/03 Lead 4 V, 2,5 A/h, rechargeable
Power Consumption 1 mA with: 4G, WiFi and optic link off
6 mA with optical link data query every 1 second and WiFi and 4G off
20 mA with 4G and WiFi module in stand-by state
(3)
120 mA max with WiFi transmitting
500 mA max with 4G transmitting
(3)
External power DC, 5 V - 1 A max
(8)
Operating time
AMB-8059/00 and /02 about 8 months @ 1min GSM
(3)
module transmission once time per day
and single probe operating mode (autonomy depends on probe and setting)
(4) (5)
AMB-8059/01 and /03 > 80 days in total darkness @ a 1 min GSM
(3)
module transmission per
day and single probe operating mode (autonomy depends on the setting)
(4) (5)
Recharge time 24 hours with external power unit (AMB-8059/01 and AMB-8059/03 only)
Autotest automatic
Compliance 2014/30, 2014/35, CEI 211-6, CEI 211-7, ITU-T K.83 and ITU-T K.113
(7)
Environment temperature -20 / +55°C
Dimensions (WxDxH) 112 x 112 x 730 mm
112 x 112 x 800 mm (in dual probe configuration – AMB-8059/01 and 03 only)
Weight
AMB-8059/00 1,2 kg only the unit; 6,5 kg total weight inclusive of supports and base
AMB-8059/01 2,4 kg only the unit; 7,7 kg total weight inclusive of supports and base
AMB-8059/02 1,2 kg only the unit; 6,5 kg total weight inclusive of supports and base
AMB-8059/03 2,4 kg only the unit; 7,7 kg total weight inclusive of supports and base
Environmental protection IP55
IP66 with IP66K optional accessory
(9)
Note (1): to the controller PC or to the user’s FTP server depending on the preferred communication mode.
Note (2): directly from the station or from the user FTP server depending on the preferred communication mode.
Note (3): AMB-8059/02 and AMB-8059/03 only are equipped with 4G modem (for station which serial number starts with 290ZY…..);
the previous serial number are equipped with 3G modem.
Note (4): Being not equipped with 4G modem AMB-8059/00 and AMB-8059/01 power autonomy is longer.
Autonomy of AMB-8059/00 with Car Mounting Kit option is 18 hours
Note (5): Specification depending on battery age, environmental temperature and GSM field coverage.
Alarm and GPS status must be set OFF.
Note (6): Optical link available only on: AMB-8059/00, AMB-8059/01 and AMB-8059/03
Note (7): ITU-T K.113 only for AMB-8059/00 with Car Mounting Kit option.
Note (8): AMB-8059/01 and AMB-8059/03 only; as service or maintenance or backup of solar panel in field from S/N prefix 170WY
Note (9): Not suitable with dual probe radome extention and Car Mount Kit option.
Note (10) on page 1-5: Up to 3 S/s on AMB-8059/00 with CMK option.
Note (11) on page 1-5: Data potentially affected by on board transmitting modems or wired connections are marked for further
plausibility evaluation

General Information 1-7
Table 1-4 Technical specifications for AMB8059/00 with Car mounting kit
The Table 1-4 shows the AMB-8059/00 specifications in mobile version. For AMB-8059/00 in standard
configuration refer to Table 1-3.
Field probes Interchangeable
Interface USB (through Fiber Optic), Wi-Fi*
Internal battery Non rechargeable primary battery,
lithium LSH20, 3,6V, 13A/h;
Vehicle speed 0 to 60 km/h
Sample rate 300 ms (GPS coordinates synchronized with EMF)
Operating time Over 200h (max current consumption 40mA with Wi-Fi OFF)
Max data storage in drive test application 18 h
Installation Magnetic mounting kit for the vehicle
Compliance European directives
2014/30, 2014/35, CEI 211-6, CEI 211-7, ITU-T K.113
Ambient temperature -20 to +55 °C
Dimensions 301 x 241 x 750 mm (complete of AMB-8059/00)
Weight Less than 3 kg
Environmental protection IP55
Specification are subject to change without notice
*Future implementation on the Narda EMF GPS Logger software.

1-8 General Information
TABLE 1-5 Max acquisition time
All models can measure and store data for an extremely long period of time: one of the 128 Mb Flash
memories is used exclusively for recording measurements and can contain up to 524.288 records of 32
bytes each. The following formula and table indicate the internal memory capacity depending on the Rate
Setting.
Nrecords * [Rate (min)] / [minutes/day] = Memory capacity (days)
For example, with a Storing Rate of 6 min, considering that a day consists of 1440 minutes, the memory
capacity formula is: 524288 * 6 / 1.440 = 2184.5 days
Storing Rate Memory capacity
30 sec >182 days
1 min >364 days
6 min > 2184 days (~6 years)
The internal memory can be read at every new data transfer to the central unit, at set times or by remote
control. Moreover, when the memory is full, the new data are overwritten on the oldest so as to ensure
availability of the data for the most recent measurement period.
All models also use an additional memory bank of 128Mb which serves various functions. 32kB of this
memory serve for the registration of events, each of them occupies a space of 128 bytes.
In the memory there is therefore space to record at least the latest 224 events.
TABLE 1-6 Settings/Queries
All of the AMB-8059 models are equipped with a WiFi modem module which can be used to download
data from the station via a direct IP (over the internet) connection or via an AP (Access Point) direct
connection or also via a FTP (overt the internet) scheduled connection.
AMB-8059/02 and AMB-8059/03 can also be set and queried remotely via mobile phone or a central unit
consisting of a PC, with 8059SW-02 software installed, connected via GSM or Line Modem (station set for
Point-to-point communication) or, through the Internet, by FTP (station set for FTP communication). All
models can be set and queried locally by means of the RS232, USB, Ethernet (/01 and /03 models)
connection to the controller PC. The following table describes the different possibilities:
Possible functions SMS via Modem
(P-to-P)
via FTP
(non real time)
PC via
RS232
PC via
USB
PC via
ETHERNET
Setting YES YES YES YES YES YES
Reading status and alarms YES YES YES YES YES YES
Reading max value YES NO NO NO NO NO
Reading average value YES YES YES YES YES YES
Download data NO YES YES YES YES YES
Reading of battery YES YES YES YES YES YES
Reading of internal temperature YES YES YES YES YES YES
Reading of internal humidity YES YES YES YES YES YES
Spontaneous call NO YES YES NO NO YES
Reporting alarms YES YES YES NO NO NO
Reporting via SMS of daily maximum YES NO NO NO NO NO
