NARDA LR-01 User manual

NARDA
Safety
Test
Solutions
S.r.l. Socio Unico
Manufacturing Plant:
Via Benessea, 29/B
17035 - Cisano sul Neva (SV)
Tel.: [phone]
Fax: [phone]
www.narda-sts.it
[e-mail]
[email protected]
EQUIPMENT SERIAL NUMBER
You can find the Serial Number on the rear panel of the instrument.
Serial Number is in the form: 0000X00000.
The first four digits and the letter are the Serial Number prefix, the last five digits are
the Serial Number suffix. The prefix is the same for identical instruments, it changes
only when a configuration change is made to the instrument.
The suffix is different for each instrument.
Document LR01EN-30604-2.10 – Copyright © NARDA 2023
User’s Manual
LR-01
LOGGER REPEATER

II Note and symbols
NOTE:
® Names and Logo are registered trademarks of Narda Safety Test Solutions GmbH – Trade names are
trademarks of the owners.
If the instrument is used in any other way than as described in this User’s Manual,
it may become unsafe.
Before using this product, the related documentation must be read with great care and fully understood to
familiarize with all the safety prescriptions.
To ensure the correct use and the maximum safety level, the User shall know all the instructions and
recommendations contained in this document.
This product is a Safety Class III instrument according to IEC classification and has
been designed to meet the requirements of EN61010-1 (Safety Requirements for
Electrical Equipment for Measurement, Control and Laboratory Use).
In accordance with the IEC classification, the power supply of this product meets requirements Safety Class II and
Installation Category II (having double insulation and able to carry out mono-phase power supply operations).
It complies with the requirements of Pollution Class II (usually only non-conductive pollution). However,
occasionally it may become temporarily conductive due to condense on it.
The information contained in this document is subject to change without notice.
EXPLANATION OF ELECTRICAL AND SAFETY SYMBOLS :
You now own a high-quality instrument that will give you many years of reliable service.
Nevertheless, even this product will eventually become obsolete. When that time comes, please
remember that electronic equipment must be disposed of in accordance with local regulations.
This product conforms to the WEEE Directive of the European Union (2002/96/EC) and belongs to
Category 9 (Monitoring and Control Instruments). You can return the instrument to us free of
charge for proper environment friendly disposal. You can obtain further information from your
local Narda Sales Partner or by visiting our website at www.narda-sts.it .
Warning, danger of electric shock
Earth
Read carefully the Operating Manual and its
instructions, pay attention to the safety
symbols.
Unit Earth Connection
Earth Protection Equipotential
EXPLANATION OF SYMBOLS USED IN THIS DOCUMENT :
The DANGER sign draws attention to a serious risk to a person’s safety,
which, if not avoided, will result in death or serious injury. All the
precautions must be fully understood and applied before proceeding.
The WARNING sign indicates a hazardous situation, which, if not avoided,
could result in death or serious injury. All the precautions must be fully
understood and applied before proceeding.
The CAUTION sign indicates a hazardous situation, which, if not avoided,
could result in minor or moderate injury.
The NOTICE sign draws attention to a potential risk of damage to the
apparatus or loss of data.
The NOTE sign draws attention to important information.

Contents III
Contents
Safety recommendations and instructions.………......................
EC Declaration of Conformity .....................................................
VIII
IX
1 General information Page
1.1 Documentation….......................................................................
1.2 Introduction ………….......................................….………………
1.3 Standard accessories ……………..............................................
1.4 LR-01 Optional accessories.......................................................
1.5 LR01/IAM Optional accessories.................................................
1.6 Main specifications.....................................................................
1.7 LR-01 panels……….........................................………...............
1.8 Field Probes…………………………………………………………
1-1
1-1
1-1
1-2
1-2
1-3
1-4
1-5
2 Installation and use Page
2.1 Introduction...............................................................................
2.2 Preliminary inspection..............................................................
2.3 Working environment...............................................................
2.4 Return for repair……….............................................................
2.5 Instrument cleaning…..............................................................
2.6 Installation of the LR-01…………………………………………..
2.7 LR-01 on, Led status, Manual Log Button and Buzzer.............
2.8 Power supply and battery recharging…………………..............
2.9 Install and run Narda Probes Manager software……………….
2.10 Logger …………………………………………………………….
2.10.1 Compact and Extended mode ……………………………….
2.10.2 Average …………………………………………………………
2.10.3 Logger Method ………………………………………………..
2.11 LR-01 Applications ………………………………………………
2-1
2-1
2-1
2-1
2-1
2-2
2-5
2-7
2-8
2-9
2-9
2-9
2-9
2-10
3 Narda Probes Manager Software installation Page
3.1 Introduction.………..............................................…................
3.2 Hardware requirements…………………………………………..
3.3 Installation….............................…………………..…………….
3-1
3-1
3-2
4 Narda Probes Manager Operating instruction
4.1 Introduction.………..............................................…...............
4.2 Main window contents………………………………….............
4.2.1 Title bar…………………………………………………………
4.2.2 Main window displayed measurements……………………..
4.2.2.1 Displayed technical data …………………………………..
4.2.3 Frequency correction setting…………………………………
4.2.4 Reading Rate setting………………………………………….
4.2.5 XYZ / TOT……………………………………………………..
4.2.6 Save measurements …..…………………………………….
4.2.7 Plot……………………………………………………………..
4.2.8 HOLD / RUN………………………………………………….
4.2.9 Exit……………………………………………………………..
4.2.10 Menu………………..………………………………………..
4.2.10.1 Settings .…………..……………………………………….
4.2.10.1.1 Filter .…………………………………………………….
4.2.10.1.2 Video Average.………………………………………….
4.2.10.1.3 Calibrations….………………………………………….
4.2.10.1.4 Communications………………………………………..
4.2.10.2 Preference .….……………………………………………
4.2.10.2.1 Settings….………………………………………………
4.2.10.2.2 Languages………………………………………………
4.2.10.3 Info button .…..…………………………………………….
4.2.11 Logger ……………………………………………………….
5 Update firmware
5.1 Update firmware…………...............................................….....
5.2 To run the update software……………………………………...
5.3 To transfer data………………………..………………………….
6 Uninstalling driver and software
6.1 Uninstalling driver for USB-OC..............................................
6.2 Uninstall Narda Probes Manager ………………………………
Page
4-1
4-6
4-7
4-8
4-9
4-10
4-12
4-13
4-15
4-18
4-24
4-24
4-25
4-25
4-25
4-26
4-27
4-28
4-29
4-29
4-30
4-31
4-32
Page
5-1
5-1
5-1
Page
6-1
6-2

IV Contents
7 LR01 Manager APP Operating instruction
7.1 Introduction.……….........................................................
7.2 Installation……………………..……..……………………..
7.3 LR01 Manager Main window………………………………
7.3.1 Menu……………………………………………………....
7.3.1.1 Settings………………………………………………….
7.3.2 Technical data……………………………………………
7.3.3 Live Measurements………………………………………
7.3.4 Logger and Save measurements………………………
7.3.5 Info ………………………………………………………..
8 Using of LR-01 with WearOS (Smartwatch)
8.1 Introduction……………………………................................
8.2 Installation…………………………….……………………….
8.3. Operations……………………………………………………
8.3.1 Live Measurements…………………………………
8.3.2 Technical data……………………………………….
8.3.3 Settings………………………………………………
8.4 Close the App………………………………………….
9 Command protocol
9.1 Introduction.………….....................................................
9.2 List of commands……………………………………….....
9.3 Query commands………………….................................
9.4 Settings commands ……...............................................
9.5 Log file………………………………………………………
9.5.1 Log file data ………..……………………………………
9.5.1.1 Passive Probes Structure description……………….
9.5.1.2 Single/Three Bands Probes Structure description...
9.5.1.3 4-Bands Probes Structure description………..……
9.5.1.4 EHP2B Active Probe Structure description…………
9.5.2 Field data …………....……………………………………
9.5.3 Additional GPS Structure description…………………..
9.5.3.1 Position Information……………………………………
9.5.4 Battery Log File…………………………………………..
Page
7-1
7-1
7-2
7-3
7-3
7-3
7-4
7-5
7-6
Page
8-1
8-1
8-2
8-2
8-3
8-4
8-4
Page
9-1
9-3
9-5
9-22
9-32
9-33
9-33
9-33
9-34
9-34
9-35
9-37
9-38
9-39
10 Accessories Page
10.1 Introduction………….....................................................
10.2 Preliminary inspection…..………..………………….......
10.3 Work environment…….……..…………………………....
10.4 Return for repair …………...….….................................
10.5 Cleaning…….……………………………….....................
10.6 USB-OC Optical USB Converter ……………….............
10.6.1 Introduction……………………………………………....
10.6.2 Installation………………………………………………..
10.7 LR01-8059 Adapter ……………………….…...............
10.7.1 Introduction……………………………………………...
10.7.2 Installation……………………………………………….
10.8 LR01-8053 Adapter ………......………………...............
10.8.1 Introduction……………………………………………...
10.8.2 Installation……………………………………………….
10.9 TR-02A Tripod…………………………………………….
10.9.1 Introduction………………………………………………
10.10 TT-01 Fiber Glass Telescopic Support..…..………….
10.10.1 Introduction……………………………………………..
10.11 AC/DC USB Power Supply and battery charger ……..
10.12 Shoulder sling ……………………………………………
10.13 LR01/IAM Indoor Area Monitor kit ……………………..
10.13.1 Introduction ……………………………………………..
10.13.2 Description ……………………………………………..
10.13.3 Installation………………………………………………
10.13.3.1 Use with Power Over Ethernet (optional)………….
10.13.4 LR01/IAM Ports ……………..………………………….
10.13.5 User’s Port application examples …………………….
10.14 WearOS (Smartwatch)…………………………………….
10-1
10-1
10-1
10-1
10-1
10-2
10-2
10-2
10-3
10-3
10-3
10-5
10-5
10-5
10-7
10-7
10-9
10-9
10-10
10-11
10-13
10-13
10-14
10-15
10-18
10-19
10-19
10-20
11 Service Page
11.1 Miscellaneous messages………………………………...........
11.2 Initial diagnostic …………………………………………………
11-1
11-2

Contents V
Figures
Figure
1-1
1-2
1-3
1-4
1-5
1-6
1-7
1-8
1-9
1-10
1-11
1-12
1-13
1-14
1-15
1-16
1-17
1-18
1-19
1-20
1-21
1-22
1-23
1.24
1-25
1-26
1-27
1-28
1-29
1-30
1-31
1-32
1-33
1-34
1-35
1-36
1-37
1-38
1-39
1-40
LR-01, adapter and probes ……………………………………
Top panel .…………………...…….………………….………..
Bottom panel ……………………………………………………
EP-1B-01 probe ………………………………………………..
EP-3B-01 probe ………………………………………………..
HP-1B-01 probe ………………………………………………..
EP-4B-01 probe ………………………………………………..
EP-1B-03 probe ………………………………………………..
EP-4B-02 probe ………………………………………………..
EP-1B-04 probe…………………………………………………
EP-1B-05 probe ………………………………………………..
EP-1B-06 probe ………………………………………………..
EP-1B-08 probe ………………………………………………..
EHP-2B-01 probe ……………………………………………...
EHP-2B-02 probe ……………………………………………...
EHP-2B-03 probe ……………………………………………...
EHP-2B-04 probe ……………………………………………..
EHP-2B-05 probe ……………………………………………..
EHP-2B-06 probe ……………………………………………..
EHP-2B-07 probe ……………………………………………..
EHP-2B-08 probe ……………………………………………..
EP-330 probe ………………………………………………….
EP-33M probe ………………………………………………....
HP-102 probe ………………………………………………….
EP-105 probe ………………………………………………….
HP-032 probe ………………………………………………….
EP-301 probe ………………………………………………….
EP-183 probe ………………………………………………….
EP-408 probe ………………………………………………….
EP-44M probe …………………………………………………
HP-050 probe ………………………………………………….
EP-300 probe ………………………………………………….
EP-33A probe ………………………………………………….
EP-33B probe ………………………………………………….
EP-33C probe …………………………………………………
HP-051 probe ………………………………………………….
EP-201 probe ………………………………………………….
EP-333 probe ………………………………………………….
EP-645 probe ………………………………………………….
EP-745 probe ………………………………………………….
Page
1-1
1-4
1-4
1-9
1-10
1-11
1-12
1-13
1-14
1-15
1-16
1-17
1-18
1-19
1-20
1-21
1-22
1-23
1-24
1-25
1-26
1-29
1-30
1-31
1-32
1-33
1-34
1-35
1-36
1-37
1-38
1-39
1-41
1-43
1-45
1-46
1-48
1-50
1-51
1-52
2-1
2-2
2-3
2-4
6-1
LR-01 link with USB-OC ………………………………………
Typical Immunity test irradiation configuration ......…………
LR-01 in a multi-probe configuration ………………………..
Example of calibration of a magnetic field probe …………..
Uninstalling USB-OC…………………………………………..
2-2
2-10
2-10
2-11
6-2
10-1
10-2
10-3
10-4
10-5
10-6
10-7
10-8
10-9
10-10
10-11
10-12
10-13
10-14
10-15
10-16
10-17
10-18
10-19
USB-OC adapters………………………………………………
LR-01 with its 8059 adapter ………………………………….
LR-01 with its 8059 adapter and probe…………………….
LR01-8059 Adapter connectors …………………………….
LR-01 with its 8053 adapter ………………………………….
LR-01 with its 8053 adapter and probe………………………
LR01-8053 Adapter connectors …………………………….
TR-02A Tripod …………………………………………………
LR-01 with 8053 adapter and probe on the TR-02A………..
TT-01 Fiber Glass Telescopic Support………………………
AC/DC Power Supply and battery charger ………………….
USB Cable – USB(A)/USB(C)…………………………………
Shoulder sling ………..…………………………………………
LR-01 Area Monitor – Wall mounted …….………………….
LR01/IAM kit - Wall supporto and Interface (Top view)……..
LR01/IAM kit - Interface Connectors detail (Bot view)…..….
LR01/IAM with Power Over Ethernet …………..……………
Programmable User’s Port HD-15 connector pinout ………
WearOS (Smartwatch)…………………………………………
10-2
10-3
10-3
10-4
10-5
10-5
10-6
10-7
10-8
10-9
10-10
10-10
10-11
10-13
10-14
10-14
10-18
10-19
10-20

VI Contents
Tables
Table
1-1
1-2
1-3
1-4
1-5
1-6
1-7
2-1
2-2
2-3
9-1
9-2
10-1
10-2
10-3
10-4
10-5
10-6
10-7
10-8
10-9
Main specifications …….……..………………………………
8059 Field Probes ……………………………………………
8053 Field Probes ……………………………………………
LR-01 Indoor Area Monitor Field Probes ………………….
Technical Specifications of 8059 Field Probes …………….
Technical Specifications of LR-01 and IAM Field Probes ..
Technical Specifications of 8053 Field Probes ……………
Led status……………………………….…………………….
Manual Log Button status....…………………………………
Buzzer status....……………………………………………….
Query commands …………………………………………….
Setting commands ..………………………………………….
Technical specifications of the USB-OC……………..........
Technical specifications of the LR01-8059 adapter ..........
Technical specifications of the LR01-8053 adapter ..........
Technical specifications of the TR-02A Tripod……...........
Technical specifications of the TT-01.…………….………..
Technical specifications of the AC/DC Power Supply ……
Technical specifications of the USB(A)/USB(C) Cable……
Technical specifications of the Shoulder Sling …………….
Technical specifications of the Indoor Area Monitor ………
Page
1-3
1-6
1-7
1-8
1-9
1-23
1-27
2-5
2-6
2-6
9-3
9-4
10-2
10-4
10-6
10-7
10-9
10-10
10-10
10-12
10-13

EC Conformity VII
SAFETY RECOMMENDATIONS AND INSTRUCTIONS
This product has been designed, produced and tested in Italy, and it left the factory in conditions fully
complying with the current safety standards. To maintain it in safe conditions and ensure correct use,
these general instructions must be fully understood and applied before the product is used.
•When the device must be connected permanently, first provide effective grounding;
•If the device must be connected to other equipment or accessories, make sure they are all safely
grounded;
•In case of devices permanently connected to the power supply, and lacking any fuses or other
devices of mains protection, the power line must be equipped with adequate protection
commensurate to the consumption of all the devices connected to it;
•In case of connection of the device to the power mains, make sure before connection that the voltage
selected on the voltage switch and the fuses are adequate for the voltage of the actual mains;
•Devices in Safety Class I, equipped with connection to the power mains by means of cord and plug,
can only be plugged into a socket equipped with a ground wire;
•Any interruption or loosening of the ground wire or of a connecting power cable, inside or outside the
device, will cause a potential risk for the safety of the personnel;
•Ground connections must not be interrupted intentionally;
•To prevent the possible danger of electrocution, do not remove any covers, panels or guards installed
on the device, and refer only to NARDA Service Centers if maintenance should be necessary;
•To maintain adequate protection from fire hazards, replace fuses only with others of the same type
and rating;
•Follow the safety regulations and any additional instructions in this manual to prevent accidents and
damages.

VIII Safety considerations
Dichiarazione di Conformità
EC Declaration of Conformity
In accordo alla Decisione 768/2008/EC, conforme alle direttive EMC 2014/30/UE, Bassa Tensione 2014/35/UE e
RoHS 2011/65/UE, ed anche alle norme ISO/IEC 17050-1 e 17050-2.
In accordance with the Decision 768/2008/EC, compliant to the Directives EMC 2014/30/UE, Low Voltage 2014/35/UE and
RoHS 2011/65/EU, also compliant to the ISO/IEC standard 17050-1 and 17050-2
Il costruttore
The manufacturer
narda Safety Test Solutions S.r.l. Socio Unico
Indirizzo
Address
Via Benessea, 29 / B; I-17035 Cisano sul Neva (SV) - Italy
sulla base delle seguenti norme europee armonizzate, applicate con esito positivo:
based on the following harmonized European Standards, successfully applied:
EMC:
EMC:
EN 301 489-1 (V2.2.3); EN 301 489-17 (V3.2.4); IEC EN 61326-1 (2021)
Sicurezza:
Safety:
IEC EN 62368-1 (2020); EN 61010-1 (2010)
Radio:
Radio:
EN 300 328 (V2.2.2)
Salute:
Health:
IEC EN 62311:2020; IEC EN 62479:2010
dichiara, sotto la propria responsabilità, che il prodotto:
declares, under its sole responsibility, that the product:
Descrizione
Description
Ripetitore Registratore – Logger Repeater
Modello
Model
LR-01
è conforme ai requisiti essenziali delle seguenti Direttive:
conforms with the essential requirements of the following Directives:
Apparecchiature Radio
RED
2014/53/EU
Compatibiltà Elettromagnetica
EMC
2014/30/EU
Bassa Tensione
Low Voltage
2014/35/EU
RoHS
RoHS
2011/65/EU
Cisano sul Neva, 12 September 2022
Egon Stocca
General Manager

General information 1-1
1 – General information
1.1 Documentation
The following documents are included in this Manual:
•A questionnaire to be sent to NARDA together with the apparatus
should service be required.
•A checklist of the Accessories included in the shipment.
1.2 Introduction
1.3 Standard
Accessories
LR-01 is a programmable logger repeater directly connected to a personal
computer via optical fiber cable to USB adapter. It is also possible to
connect to PCs via USB and Wi-Fi with dedicated software (see Chapter 4).
With Bluetooth connection is available an App for mobile device (see
Chapter 6). With its internal rechargeable battery, it measures electric and
magnetic fields through more than 32 different probes and immediately
records and plots the results. The probes can be attached to the dedicated
heavy-duty connector on the LR-01 via the specific adapter, which also
features excellent shielding properties and can therefore be used at very
high field strengths without interference. In addition to the standard Narda
Probes Manager software delivered with the Logger Repeater, the
communication and control protocol is freely available so users can fully
control the LR-01 with their usual test software.
LR-01 provides also programmable on-board acoustic, visual and vibration
alarms. It is an ideal solution for EMC applications, in chambers and
TEM/GTEM cells, and in EMF applications.
An optional Indoor Area Monitor kit makes it possible to easily transform the
instrument into a performing very compact field monitoring station; please
refer to paragraph 10.13 for further information.
Fig. 1-1 LR-01 Adapter and Probes
Standard accessories included with LR-01 are:
•USB Cable – USB(A)/USB(C) 2m
•AC/DC Converter with plug adapters
•Cable, FO Duplex, RP-02, 10 m
•USB-OC Optical Converter
•Conical Tripod support
•LR-01 Software Media including User’s Manual;
•Software Narda Probes Manager on Software Media
•User’s Manual with Return Form for repair
•Checklist of the accessories
•Calibration Certificate
Document LR01EN-30604-2.10 - NARDA 2023

1-2 General information
1.4 LR01 Optional
accessories
LR-01 accessories supplied separately (on charge):
•LR01-8053 Adapter
•LR01-8059 Adapter
•LR01 Connectors cover
•Cable, FO Duplex, RP-02, 20 m
•Cable, FO Duplex, RP-02, 40 m
•Carrying case
•EP-105 E-Field Sensor
•EP-183 E-Field Sensor
•EP-201 E-Field Sensor
•EP-300 E-Field Sensor
•EP-301 E-Field Sensor
•EP-330 E-Field Sensor
•EP-333 E-Field Sensor
•EP-33A E-Field Sensor
•EP-33B E-Field Sensor
•EP-33C E-Field Sensor
•EP-33M E-Field Sensor
•EP-408 E-Field Sensor
•EP-44M E-Field Sensor
•EP-645 E-Field Sensor
•EP-745 E-Field Sensor
•HP-032 H-Field Sensor
•HP-050 H-Field Sensor
•HP-051 H-Field Sensor
•HP-102 H-Field Sensor
•EP-1B-01 E-Field Sensor
•EP-1B-03 E-Field Sensor
•EP-1B-04 E-Field Sensor
•EP-1B-05 E-Field Sensor
•EP-1B-06 E-Field Sensor
•EP-1B-08 E-Field Sensor
•EP-3B-01 E-Field Sensor
•EP-4B-01 E-Field Sensor
•EP-4B-02 E-Field Sensor
•HP-1B-01 H-Field Sensor
•EHP-2B-01 E and H-Field Sensor
•EHP-2B-02 E and H-Field Sensor
•EHP-2B-03 E and H-Field Sensor
•EHP-2B-04 E and H-Field Sensor
•TT-01 Fiber Glass Telescopic Support
•TR-02A Tripod complete with joint
•Shoulder Sling, Neck Belt for LR-01 (Safety lanyard ¼” thread)
•Android, WearOS (Smartwatch) and iOS Utility
1.5 LR01/IAM
Optional accessories
LR01/IAM accessories supplied separately (on charge):
•LR01/IAM Indoor Area Monitor kit including:
- Wall support bracket, 2 pcs. Washer and 2 pcs Screws M4x20mm
- 1 pcs. Screws 1/4”x5/8
- Radome, 3 pcs. plastic washer and 3pcs. Screws M4x10mm
- 2.5mm and 3mm Allen Key
- Software Media + User’s Manual + Calibration Certificate
•Cable, DB15(m)/DB15(m), 1,8 m
•Ethernet cable, 5 m
•Cable, FO Duplex, RP-02, 20 m
•Cable, FO Duplex, RP-02, 40 m
•Power Over Ethernet
•Carrying case
•EHP-2B-05 E and H-Field Sensor
•EHP-2B-06 E and H-Field Sensor
•EHP-2B-07 E and H-Field Sensor
•EHP-2B-08 E and H-Field Sensor

General information 1-3
1.6 Main specifications When not differently specified, the following specifications refers to an
operating ambient temperature of 23°C and relative humidity of 50%.
Table 1-1 Technical specifications
Probe compatibility 8053 and 8059 standards
Interfaces Optical (RP-02), USB (USB(C)), WiFi (802.11 b/g/n), Bluetooth (5.0)
Optical fiber connection Serial Optical Interface 115200 Baud
RP02 connector up to 40 m (USB-OC)
Sampling time Automatic from 0.3 s to 1 s
(1)
Internal log interval Settable from 1 sec to 1 hour, manually triggered, on adjustable threshold
Max data storage capability Up to 250000 points
Probe depending specifications Frequency range, Frequency flatness, Dynamic range, Resolution,
Sensitivity, Accuracy, Overload, Measurement units, Detector, Sampling
rate, Acquisition method
GPS module Satellite System GPS + QZSS
Supplementary data
Battery voltage and capacity
Data & Time
Temperature
Humidity (relative)
Pressure
GPS coordinates
Altitude
Compass
Speed
Acceleration
Internal sensor for reporting and logging
Warnings and Alarms Field, Probe, Temperature, Humidity, Battery
Notifications Communications
Alarms indication Acoustic, visual, vibration, data log
Internal memory 256 Mb
Calibration
(2)
internal E
2
PROM
Internal battery 3.7 V / 1320 mAh Li-Ion, rechargeable
Operating time
(3)
Stand alone mode up to 100 hours
Optical mode
(4)
up to 60 hours
BT mode
(4)
up to 20 hours
WiFi mode
(4)
up to 10 hours
Recharging time < 2.5 hours
External supply 5 VDC, Imax 600 mA
Firmware updating Through the optical link
Self test Automatic at power on
Operating temperature -20 to +55 °C
Storage temperature -30 to +75°C
Operating relative humidity
(5)
5 to 95 %
Ingress protection Up to IP65
(6)
Dimensions φ54 mm, L 116 mm
Weight 300 g
Tripod support Threaded insert ¼”
Specification are subject to change without notice
(1) Probe depending
(2) Recommended re-calibration interval 24 month
(3) Operating time depends on the driven probe, measure setting, and communication channel
(4) Continuous communication worst case
(5) Without condensation
(6) With Area Monitor option

1-4 General information
1.7 LR-01 panels
Fig. 1-2 Top panel
Legend:
1. Robust bayonet connector
2. GPS antenna
3. Wireless antennas
4. Visual alarm
5. Manual log button
6. Vibration alarm
Fig. 1-3 Bottom panel
Legend:
1. ON/OFF button
2. Power ON LED
3. Manual log button
4. Status LED
5. USB-C connector
6. Fiber Optic connector
7. Serial Number
8. Acoustic alarm
9. Threaded insert UNC 1/4“
Compass heading 0 degrees (North) corresponds to the direction where
the GPS antenna is located.

General information 1-5
1.8 Field Probes LR-01 can measure and log fields detected by many electric and magnetic
field probes.
Both the probes of the 8059 family and the probes of the 8053 family are
compatible with the Logger Repeater, by means of the appropriate adapter. In
addition, a series of probes, aimed at the use of indoor area monitors has
been developed, specifically for LR-01.
Narda EMF Area Monitor AMB-8059 has a set of electric and magnetic
probes covering the frequency range from 10 Hz to 60 GHz.
PMM 8053B measurement system is complete with a series of electric and
magnetic field probes in the frequency range from 5 Hz to 40 GHz.
LR-01 measurement system is equipped with a series of electric and
magnetic field probes in the frequency range from 500 kHz to 60 GHz

1-6 General information
The following list shows the 8059 probes:
TABLE 1-2 8059 Field Probes
Field Probe Range of frequency Reading
ELECTRIC FIELD PROBE EP-1B-01 100 kHz – 3 GHz 0.2 – 200 V/m
TRI-BAND ELECTRIC FIELD PROBE EP-3B-01 100 kHz – 3 GHz 0.2 – 200 V/m
MAGNETIC FIELD PROBE HP-1B-01 10 Hz – 5 kHz 50 nT – 200 µT
QUAD-BAND ELECTRIC FIELD PROBE EP-4B-01 100 kHz – 3 GHz 0.03 – 200 V/m
ELECTRIC FIELD PROBE EP-1B-03 100 kHz – 7 GHz 0.2 – 200 V/m
QUAD-BAND ELECTRIC FIELD PROBE EP-4B-02 100 kHz – 7 GHz (0.03) 0.2 – 200 V/m
ELECTRIC FIELD PROBE EP-1B-04 10 Hz – 5 KHz 5 V/m – 20 kV/m
ELECTRIC FIELD PROBE EP-1B-05 300 kHz – 18 GHz 0.5 – 800 V/m
ELECTRIC FIELD PROBE EP-1B-06 300 kHz – 40 GHz 0.5 – 800 V/m
ELECTRIC FIELD PROBE EP-1B-08 100 kHz – 8 GHz 0.2 – 200 V/m
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-01
E: 500 kHz – 9.25 GHz
H: 20 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-02
E: 500 kHz – 60 GHz
H: 20 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-03
E: 1.34 MHz – 9.25 GHz
H: 1 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-04
E: 1.34 MHz – 60 GHz
H: 1 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
With EHP-2B-XX weighted models of field probes, after selecting the
desired limit, the meter gives the percentage of level referred to it.
Probes belonging to this group allow measurements compensation
based on frequency.
If the frequency of the signal to be measured is known, it is possible
to apply an automatic flatness correction, and the LR-01 is also able
to properly switch between linear and quadratic detection, as the
selected standard requires, depending on the frequency. In other
words, the field level evaluation becomes linear under 10 or 30 MHz,
depending on the selected standard.

General information 1-7
The following list shows the 8053 probes:
TABLE 1-3 8053 Field Probes
Field Probes Frequency range Level range
ELECTRIC FIELD PROBE EP-105 100 kHz - 1000 MHz 0.05 - 50 V/m
ELECTRIC FIELD PROBE EP-300 100 kHz - 3 GHz 0.1 - 300 V/m
ELECTRIC FIELD PROBE EP-330 100 kHz - 3 GHz 0.3 - 300 V/m
ELECTRIC FIELD PROBE EP-301 100 kHz - 3 GHz 1 - 1000 V/m
ELECTRIC FIELD PROBE EP-333 100 kHz – 3.6 GHz 0.15 - 300 V/m
ELECTRIC FIELD PROBE EP-183 1 MHz – 18 GHz 0.8 - 800 V/m
ELECTRIC FIELD PROBE EP-408 1 MHz – 40 GHz 0.8 - 800 V/m
ELECTRIC FIELD PROBE EP-44M 100 kHz - 800 MHz 0.25 - 250 V/m
ELECTRIC FIELD PROBE EP-33M 700 MHz - 3 GHz 0.3 - 300 V/m
ELECTRIC FIELD PROBE EP-33A 925 MHz - 960 MHz 0.03 - 30 V/m
ELECTRIC FIELD PROBE EP-33B 1805 MHz - 1880 MHz 0.03 - 30 V/m
ELECTRIC FIELD PROBE EP-33C 2110 MHz - 2170 MHz 0.03 - 30 V/m
ELECTRIC FIELD PROBE EP-201 60 MHz – 12 GHz 3 – 500 V/m
ELECTRIC FIELD PROBE EP-645 100 kHz – 6.5 GHz 0.35 – 450 V/m
ELECTRIC FIELD PROBE EP-745 100 kHz – 7 GHz 0.35 – 450 V/m
MAGNETIC FIELD PROBE HP-032 0.1 - 30 MHz 0.01 - 20 A/m
MAGNETIC FIELD PROBE HP-102 30 - 1000 MHz 0.01 - 20 A/m
MAGNETIC FIELD PROBE HP-050 10 Hz – 5 kHz 10 nT – 40 µT
MAGNETIC FIELD PROBE HP-051 10 Hz – 5 kHz 50 nT – 200 µT
The probes of the 8053 family have flatness compensation factors on
board that can be applied when the signal source frequency is known,
in order to make the measurement even more accurate.

1-8 General information
The following list shows the LR-01 specific probes, designed for indoor area monitor:
TABLE 1-4 LR-01 Indoor Area Monitor Field Probes
Field Probe Range of frequency Reading
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-05
E: 500 kHz – 9.25 GHz
H: 20 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-06
E: 500 kHz – 60 GHz
H: 20 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-07
E: 1.34 MHz – 9.25 GHz
H: 1 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
ELECTRIC AND MAGNETIC FIELD
SHAPED PROBE EHP-2B-08
E: 1.34 MHz – 60 GHz
H: 1 MHz – 1 GHz
E: 0.1 (0.5) – 1000 %
H: 0.3 (1.5) – 1000 %
The probes of this family are designed to achieve compact
dimensions, useful for indoor area monitoring, therefore resulting a
good compromise between size and performance.

General information 1-9
TABLE 1-5 Technical Specifications of 8059 Field Probes
ELECTRIC FIELD PROBE EP-1B-01
Frequency range 0.1 – 3000 MHz
Reading range 0.2 – 200 V/m
Overload 600 V/m
Dynamic range > 60 dB
Linearity ± 0.5 dB (0.5 to 100 V/m) @ 50 MHz
Resolution 0.01 V/m
Sensitivity 0.2 V/m
Flatness @ 20V/m 1 – 200 MHz ±0.8 dB
150 kHz - 3 GHz ±1.5 dB
Anisotropy @ 6V/m ± 0.8 dB @ 50 MHz
(typical 0.6 dB)
Rejection of magnetic field > 20 dB
Temperature error 0.1 dB/°C
A/D conversion On board
Calibration factors On board E
2
prom
Temperature sensor On board
Dimensions Length 450mm, diameter 55mm
Weight 180g
Fig. 1-4 EP-1B-01 probe

1-10 General information
TRI-BAND ELECTRIC FIELD PROBE EP-3B-01
Wide band Low pass High pass
Frequency range 0.1 – 3000 MHz 0.1 – 862 MHz 933 – 3000 MHz
Reading range 0.2 – 200 V/m
Overload 600 V/m
Dynamic range > 60 dB
Linearity ± 0.5 dB (0.5 to 100 V/m)
@ 50 MHz ± 0.5 dB (0.5 to 100 V/m) ± 0.5 dB (0.5 to 100 V/m)
Resolution 0.01 V/m
Sensitivity 0.2 V/m
Flatness @ 20V/m 1 – 200 MHz ±0.8 dB
150 kHz - 3 GHz ±1.5 dB
1 – 200 MHz ±0.8 dB
150 kHz - 862 MHz ±1.5 dB
933 – 3000 MHz ±1.5 dB
Anisotropy @ 6V/m ± 0.8 dB @ 50 MHz
(typical 0.6 dB)
+/- 0.8 dB @ 1 GHz
(typical 0.6 dB)
Attenuation out of band Not applicable 933 MHz – 3 GHz > 23 dB
(respect to 50 MHz)
0.1 – 862 MHz > 23 dB
(respect to 1 GHz)
Rejection of magnetic
field > 20 dB
Temperature error 0.1 dB/°C
A/D conversion On board
Calibration factors On board E
2
prom
Temperature sensor On board
Dimensions Length 450mm, diameter 55mm
Weight 180g
Fig. 1-5 EP-3B-01 Probe

General information 1-11
MAGNETIC FIELD PROBE HP-1B-01
Frequency range 10 Hz – 5 kHz
Reading range 50 nT – 200 µT
Overload > 1 mT
Dynamic range > 72 dB
Linearity ± 0.5 dB (200 nT to 100 uT) @ 50 Hz
Resolution 1 nT
Sensitivity 50 nT
Flatness @ 40 Hz - 1 kHz 1 dB (typical 0.6)
Anisotropy @ 50 Hz 3µT 0.3 dB
Rejection of electric field > 20 dB
A/D Conversion On board
Calibration factors On board E
2
prom
Temperature sensor On board
Dimensions Length 83 mm, diameter 53 mm
Weight 110g
Fig. 1-6 HP-1B-01 Probe

1-12 General information
QUAD-BAND ELECTRIC FIELD PROBE EP-4B-01
Wide band EGSM 900 Band pass EGSM 1800 Band pass UMTS Band pass
Frequency range 0.1 – 3000 MHz 925 – 960 MHz 1805 – 1880 MHz 2110 – 2170 MHz
Level range 0.2 – 200 V/m 0.03 – 30 V/m
Dynamic range > 60 dB > 60 dB
Linearity ± 0.5 dB (0.5 to 100 V/m) ± 0.5 dB (0.06 to 20 V/m)
Resolution 0.01 V/m
Sensitivity 0.2 V/m 0.03 V/m
Flatness @ 6 V/m
1 – 200 MHz +/-0.8 dB
0.15 MHz - 3 GHz +/-1.5 dB
925 – 960 MHz
+0.5 / -2.5 dB
1805 MHz – 1880 MHz
+0.5 / -2.5 dB
2110 – 2170 MHz
+0.5 / -2.5 dB
Anisotropy @ 3 V/m
±0.8 dB @ 50 MHz
(typical 0.6 dB)
±0.8 dB (typical 0.6 dB)
@ 942.5 MHz
±0.8 dB (typical 0.6 dB)
@ 1842.5 MHz
±0.8 dB (typical 0.6 dB)
@ 2140 MHz
Out band attenuation not applicable
Rejection
to 1842 GSM = 25 dB
to 2140 UMTS = 25 dB
Rejection
to 942 GSM = 15 dB
to 2140 UMTS = 13 dB
Rejection
to 942 GSM = 17 dB
to 1842 GSM = 10 dB
H filed rejection > 20 dB
Temperature error 0°C÷50°C = ±0.3 dB -20°C÷0°C = - 0.1 dB / °C
Center frequency drift not applicable 40°C÷60°C = ±100 kHz -20°C÷40°C = -100 kHz / °C
A/D conversion On board
Calibration factors On board E
2
prom
Temperature sensor On board
Size Length 450 mm, diameter 55 mm
Weight 210g
Fig. 1-7 EP-4B-01 probe
