Nautilus Marine Rescue GPS User manual
Quick start guide
Important!
Get to know Nautilus GPS
MMSI
Operation
Test sequence
Maintenance
Battery Information
Rewinding Antenna
Specifications
03
04
05
06
07
08
08
09
09
10
Table of Contents
2
1
3
4
Open the dive cap by releasing the latch.
Press the blue button to power on the Nautilus GPS.
It will now begin to search for a GPS lock.
Remove the antenna retainer and manually unfurl the antenna.*
Hold the red button for 5 seconds to begin distress transmission.
The Nautilus Marine Rescue GPS is an aid to your safety. It is not a life-saving device.
It is not intended to save your life.
QUICK START GUIDE TO ACTIVATE H ELP
* Be cautious when removing antenna retainer. The antenna may spring out rapidly.
Proudly made in Canada
03
Ensure that the O-rings are always
clean and free of contaminants.
Performing a test will reduce the
battery life. Only perform a test
once before each dive trip
This equipment is intended for
emergency use. Do not activate
unless in an emergency situation.
Dive cap should remain sealed
unless in distress situation or when
performing self-test.
DSC functionality may be disabled
in certain countries subject to
regulations.
We recommend using Panasonic
CR123 3V (1550 mAh) batteries.
Lower quality batteries may have a
reduced lifespan.
Do not open dive cap underwater.
Be cautious when removing antenna
retainer. The antenna may spring out
rapidly.
In the case of accidental activation,
the user should deactivate the
Nautilus GPS distress signal and
notify the appropriate search and
rescue authorities (e.g., U.S. Coast
Guard or Rescue Coordination
Center serving the geographic
region) at the earliest possible time.
The Nautilus Marine Rescue GPS is an aid to your safety. It is not a life-saving device.
It is not intended to save your life.
In order to comply with CE RF
exposure guidelines, ensure that the
Nautilus GPS is at least 16cm from
your body when transmitting.
IMPORTANT!
Proudly made in Canada
04
GET TO KNOW NAUTILUS GPS
Power Button (On/Off) - Blue
Dive Cap Clasp
Test Button - Yellow
Help Button - Red
Dive Cap
O-ring
Latch
Antenna
Antenna
Retainer
Nautius Marine Rescue GPS
Marine Rescue GPS
Nautilus
(Antenna winder)
Proprietary Tool
www.NautilusLifeLine.com
Online Manual
Proudly made in Canada
05
OPERATION
Open the dive cap by releasing the latch.
Press the blue button: Nautilus GPS goes to ON standby state and GPS attempts to lock.
Pressing the blue button again powers off the LifeLine GPS.
• Blue LED flashes slowly while GPS searching
• Blue LED flashes quickly when GPS location determined
Remove the antenna retainer exposing the “H”elp button allowing user to manually unfurl
the antenna.
• User can press red “H”elp button at any time – not necessary to wait
for GPS to find location.
Hold the red “H” button for 5 seconds to begin distress transmission.
a. Red LED indictor flashing (Blue LED extinguishes)
• Red LED slow flashes if GPS not locked
(same cadence as Blue LED if red button not pressed)
• Red LED quick flashes if GPS locked
(same cadence as Blue LED if red button not pressed)
• Red LED on solid 3s before DSC/AIS transmission
b. White strobe begins – quick double flash every 5s.
(to save energy, the white strobe shuts off in bright sun)
* Note: To prevent false alerts the LifeLine GPS will wait 20s before start of
first transmission sequence. (Red LED on solid)
2
1
3
4
5
Batteries should be within
the marked expiry date.
Batteries Not Included
Ensure that your
Nautilus GPS has
two CR123 batteries
installed.
Pull forward only
to remove antenna retainer
Warning:
DO NOT
pull up
How to remove antenna retainer
How to deactivate distress transmission:
Hold down the red button for 5 seconds to deactivate distress transmission
* Note: Pressing the blue button will also power off the Nautilus GPS and end distress transmission,
however transmission will begin again if Nautilus GPS is powered back on.
Proudly made in Canada
06
MMSI
2
1
3
4
5
Each Nautilus GPS comes pre-programmed with an MID number. This number
serves as your identification and will be transmitted along with your distress call.
The number can be found on the back label of your Nautilus GPS.
If your vessel (or the vessel you are traveling with) has a DSC enabled VHF radio, it
is recommended to program the vessel MMSI number into your Nautilus GPS. This
allows your Nautilus GPS to send a DSC position report directly to the vessel VHF
radio by holding down the yellow button for 5 seconds.
Note: Not required for use of the red Help button
USER MID
VESSEL MMSI CONFIGURATION
MMSI PROGRAMMING (Android & iOS)
Download and install Nautilus GPS MMSI Programming App from Google
Play or Apple iTunes. (Note: ios app requires ios 8 or later)
Start the App and enter Own Ship’s MMSI, Group MMSI, and if desired, AIS
Only or DSC Only.
Lay Nautilus GPS face down with Label pointing up.
Aim your mobile phone’s flashlight at Nautilus GPS and press START. Your
mobile phone’s flashlight will flicker. Try not to move the phone during the
programming sequence.
Nautilus GPS flashes the white strobe LED twice when successfully
programmed and returns to IDLE state. If no valid programming sequence
received after 60s, Nautilus GPS returns to IDLE state.
REGION CONFIGURATION (COMING SOON)
Proudly made in Canada
07
Press and hold Nautilus GPS Test Button for 5s till ORANGE indicator on Solid
Releasing TEST button the ORANGE indicator will flash with the same rate as BLUE indicator
• Slow flashing indicates no acquired position
• Fast flashing indicates acquired position
Test sequence begins after Nautilus GPS has acquired position.
Approximately 20s after acquiring position the ORANGE Indicator will stop flashing (on solid)
and Nautilus GPS will transmit a low power Routine Own Ship Position Report.
This message will be received by all surrounding vessels with AIS receivers. As well, if you
have programmed a vessel MMSI (see page 7), the message will be received on the vessel’s
VHF radio.
Low Battery indicated by alternate sequencing of ORANGE – RED indicators. Replace
batteries before next use.
Good Battery indicated by Nauitlus GPS returning to IDLE.
2
1
3
4
5
6
Note: Test should be done at a temperature between 10-30 degrees Celsius.
TEST SEQUENCE
MAINTENANCE
Check the O-ring carefully for dust or contaminants before submerging the unit.
Applying a very sparing application of lubricant to the piston o-ring can be beneficial.
Proudly made in Canada
08
REWINDING ANTENNA
To rewind the antenna, after use of the Nautilus GPS, use the tool provided in the box. Pass
the end of the antenna through the slot of the rewinding tool. Insert the tool into the open
space of the top cap. Continuously turn the tool clockwise to fully spool the antenna back
into place. Remove the tool and replace the antenna retainer.
(Need to install with proper
orientation +, - symbols)
How to install batteries
Unscrew two screws
on top cap Insert two batteries Put screws back
The batteries should be replaced per the battery
vendor's expiry date as printed on the batteries
and recorded on the back label or after TEST
mode battery change notice (alternating RED and
Yellow LEDs). Replacing the batteries requires a
Philips #1 head screw driver and a clean, non lint
surface. We recommend using Panasonic
CR123A 3V batteries. Lower quality batteries
may have a reduced lifespan.
BATTERY INFORMATION
Proudly made in Canada
09
This radio device is designed to only provide an effective
alerting and locating capability in close proximity to a
vessel. This radio beacon is NOT an EPIRB.
Proudly made in Canada
WARNING：The FCC / The Industry Canada regulations provide that changes or modications not expressly
approved by the party responsible for compliance could void the user’s authority to operate the equipment.
SPECIFICATIONS
AIS Transmit Power: 1 Watt
AIS Frequency: 161.975 and 162.025 MHz
DSC Transmit Power: 0.5 Watt
DSC Frequency: 156.525 MHz
Messages: Individual Distress Relay, Distress Alert
Environmental Temperature Range: -20°C ~ +55°C
Waterproof Depth: 425 feet (130 meter) sea water with dive cap closed
Dimensions: 2.9 x 3.8 x 1.5 inch (75 x 97 x 39mm)
Weight: 4.6 oz (131g) after inserting two batteries
Splashproof with dive cap open
Proudly made in Canada
10
