Navitar Resolv4k Series User manual

Installation Instructions

All lens attachments, Resolv4K core Zooms and Resolv4K Fixed lenses have been
designed with a standard dovetail size for ease of modularity across the product line.
For installation of the zoom, simply insert the dovetail end of the zoom into the bottom
of the rear adapter and secure it with the (3) M4 screws supplied with the rear adapter.
Use the 2mm hex wrench supplied with your zoom to secure the screws.
For installation of the lens attachment, coax and other accessories simply insert the
dovetail end of the lens attachment into the bottom of the Resolv4K Zoom and secure
it with the (3) M4 screws supplied with the Resolv4K Zoom. Use the 2mm hex wrench
supplied with your zoom to secure the screws.
Note: The nominal torque applied on the screw is 20 in-oz. (0.14 N m)
Do not overtighten, as you may damage the lens.
INSTALLATION OF LENS ATTACHMENTS & ACCESSORIES
Left: Rear adapter installed on top of zoom. Right: Lens attachment installed on bottom of zoom.
rear adapter
core zoom
core zoomlens attachment accs.

It is important that the Resolv4K Zoom be properly installed onto the mount. All flat mounts
(1-80370, 1-80371, 1-80270, 1-80271) have a ledge on the backplate. This ledge is to sit
within the notch located at the center of the Resolv4K Zoom or Fixed body tube (see diagram
below). This provides a solid surface for which the system can be held. Install the saddle
over the lens and secure with M5 screws using the 4mm hex wrench supplied with the mount.
USING THE MOUNT WITH THE RESOLV4K SYSTEM
Left: Location of ledge on mount and notch on body tube. Right: Secure saddle with screws.
To set parfocality zoom to high magnication. Adjust
the “Z” axis to achieve best focus. Then zoom to
low magnication, do not adjust “Z” axis to refocus.
Unlock the screws and adjust the parfocality using the
adjustment ring on the rear adapter. When the image
is in optimal focus, you should be able to go through
zoom without loss of focus. Lock the parfocality ring
in two places (see Fig.1) using a 1.5mm hex wrench
(supplied with your lens).
All Resolv4K rear adapters have boresight
adjustability. The adjustment is made by using a
1.5mm hex wrench to adjust the M3 set screws at the
top of the adapter (see Fig. 2).
Tip: For easier boresight adjustment, rst loosen the
M3 screws and align the “X” axis of the sensor along
the same “line” as one of the M3 screws. Next, use
the (2) wrenches (supplied with your lens) in opposite
positions along the “X” axis to adjust the boresight.
This type of alignment enables the user to “push” the
image in the direction being actuated.
SET PARFOCALITY & BORESIGHT
Fig. 1: Location of parfocality
adjustment. Secure with set screw.
Fig. 2: Location of set screws for
boresight adjustment.

Pair a Navitar Resolv4K lens with a Pixelink CMOS
machine vision camera for excellent image quality
and outstanding value.
Camera Models for
Resolv4K Core Lenses
Model M/C Sensor Resolution MP Sensor
Size FPS Sensor Diagonal
Pixel
Size
PL-D755CU-T C Sony IMX250 2448 x 2048 5.0 2/3” 68 11.1 mm 3.45 µm
PL-D755MU-T M Sony IMX250 2448 x 2048 5.0 2/3” 68 11.1 mm 3.45 µm
PL-D759CU-T C Sony IMX255 4096 x 2160 9.0 1” 45 16.1 mm 3.45 µm
PL-D759MU-T M Sony IMX255 4096 x 2160 9.0 1” 45 16.1 mm 3.45 µm
PL-D7512CU-T C Sony IMX253 4096 x 3000 12.0 1.1” 35 17.5 mm 3.45 µm
PL-D7512MU-T M Sony IMX253 4096 x 3000 12.0 1.1” 35 17.5 mm 3.45 µm
• High frame rate CMOS technology
• USB 3.0 high speed data throughput
• Global/Rolling shutter and trigger
• 1/2” to 1.1” format
• 1.3 - 20 MP models available
• Color or Monochrome
Pixelink® PL-D Camera Features:
Navitar, Inc.
200 Commerce Drive
Rochester, NY 14623
[e-mail] | 800.828.6778
www.navitar.com
