VOIGTLANDER NOKTON 35mm F1.2 Aspherical III VM User manual

INSTRUCTION MANUAL
NOKTON 35mm F1.2 Aspherical III
VM
Mar 2020, Ver 1.0COSINA CO., LTD.

Voigtländer VM-mount lenses cover full frame format and are manually
controlled lenses. The user sets the focus and aperture. They are designed
to be used on both rangender lm cameras and digital cameras with
M-type lens mount. They can also be used on mirrorless cameras with the
appropriate adapters.
Features of Voigtländer VM-mount lens
■ VM-mount
■ Full frame format
■ Smooth focus for precise focusing
■ All metal construction

Tips for lens care and safety
Never touch the lens surface. In case it is dirty or dusty use commercial lens
cleaner or appropriate lens cleaning cloth.
If the user ignores this warning sign and uses the equipment
the wrong way serious injuries and even death might be the
result.
If the user ignores this caution sign it might result in injuries
and damage the equipment.
Never look directly at the sun with a telephoto lens as this
can damage your eyes.
Keep the lens, camera and accessories out of reach of
children.
Store the lens away from direct sunlight and always store
the lens with lens-cap on. Failure to do so can create a re
hazard.
WARNING
CAUTION
WARNING
CAUTION
CAUTION
These tips are to protect the user from injury or damaging the lens.

Description of Parts
① Filter Ring
② Aperture Ring
③ Focus Ring
④ Distance Scale
⑤ Depth of Field Ring
⑥ Distance Index
⑦ Mount
⑧ Aperture Index
⑨ Aperture Scale
⑩ Depth of Field Scale
⑪ Mount Index
①
⑧
⑨
⑩
⑪
②
③
④
⑤
⑥
⑦

● How to attach/detach the lens
Please refer to the instruction manual for your camera for how to attach/detach
the lens. Please hold the Depth of Field Ring ⑤ to attach/detach the lens. To
attach/detach the lens while holding other parts of the lens barrel can damage
the lens.
● Rangender coupling
Coupled focusing range of this lens is ∞ ~ 0.7m. However, rangender coupling
range will be di󱐯erent depending on the rangender mechanism of the camera
used.
● Attaching Filter
Screw the lter (Ø52mm) to the front of the lens.
● Attaching Mount Adapter
This lens can be used with below mentioned Voigtländer accessories.
VM-E Mount Adapter II
VM-E Close Focus Adapter
VM-X Close Focus Adapter

● Optional Lens Hood LH-8
Optional Lens Hood LH-8 are available.
Please ask your dealer for details.
● Attachment and Removal of optional Lens Hood
To attach, line-up the white mark on the Lens Hood
with Aperture Index ⑧ on the lens and turn the Lens
Hood clockwise while pushing it toward the lens.
To remove, push the Lens Hood toward the lens and
turn it counterclockwise.

Product Name NOKTON 35mm F1.2 Aspherical III
Focal Length 35mm
Maximum Aperture F1.2
Minimum Aperture F22
Lens Construction 7 groups 9 elements
Angle of View 61.53°
Aperture Blade 12
Rangender Coupling ∞ ~ 0.7m
Minimum Focus 0.5m
Filter Ø52mm
Maximum Diameter Approx. Ø60.8mm
Length Approx. 50.5mm
Weight Approx. 332g
Mount VM-mount
Supplied Accessory Front Cap, Rear Cap
●Specications
* Specication and information is subject to change without prior notice.
