NC ENGINEERING SW1.5 Assembly instructions

1
SW1.5 Site Dumper
SW1.5 Site DumperSW1.5 Site Dumper
SW1.5 Site Dumper
OPERATORS
OPERATORS OPERATORS
OPERATORS
INSTRUCTION
INSTRUCTION INSTRUCTION
INSTRUCTION
MANUAL
MANUALMANUAL
MANUAL
NC ENGINEERING (HAMILTONSBAWN) LTD
2 Killyrudden Road, Hamiltonsbawn, Co Armagh, BT61 9S
Tel: [phone] ax: 028 38870362
email: [email protected]om www.nc-engineering.com
REVISION
ORGINAL INSTRUCTIONS

2

3
Dear Customer
Even if you have operated this type of equipment before, it is
very important that your new equipment operations and
instructions are explained to you by a Dealer Representative
following delivery of your equipment.
This will explain the operating controls and enable you to
gain maximum productivity from your new dumper.

4

5
Pre Handover Check List
Return form to
NC ENGINEERING (HAMILTONSBAWN) LTD
2 Killyrudden Road
Hamiltonsbawn
Co Armagh BT61 9S
Delivery on this machine has been completed, including the following items.
Tick check box when each item is completed.
 1. Operator Handbook delivered with equipment and operator controls and
warning labels explained to user
 2. Maintenance Handbook, service intervals, fluid level checks and adjustments
explained to user.
 3. Parts book and information explained (Parts book can be purchased through
dealer)
 4. All items on delivery checklist have been completed
Operators signature: …………………………………………
Signature on behalf of Dealer: ……………………………...
DISTRIBUTOR/DEALER:………………
E UIPMENT MODEL: …………………
E UIPMENT SERIAL No:………………
HOURMETER READING: ………………
DELIVERY DATE: ……………………….
TODAYS DATE: ………………………….
Customer Name (Please Print): ………………………………………………………………
Address: ………………………………………………………………………………………
…………………………………………………………………………………………………
Postcode: …………………… Country:…………………………. Tel: ……………………...
Delivery Checklist (Continued on reverse side)
Complete this form with the user / customer and return it to NC
At Dealership
 Make sure any necessary field service instructions have been completed
 Make sure all necessary certificates and literature are available
 All decals are fitted

6
At Delivery Point with Customer
 Explain parts book
 Explain all warning labels on equipment
 Show location of all serial numbers on equipment
Lubrication & Maintenance
 Explain maintenance requirements, fuel & lubricant specifications
 Instruct how to use service schedules of maintenance handbook
 Show all lubrication points on the equipment
Fluid Levels
Instruct how to measure all fluid levels and fill procedures
 uel
 Hydraulic Tank
 Engine oil
 Transmission / Power train
 Coolant (inspect with engine stopped & cool)
Show Location of All Filters
 Hydraulics system
 Engine oil
 uel system
 Engine air
Water and Sedimentor Drains
 uel water separator
 uel tank drain bung
 Hydraulic tank drain bung
Operation & Demonstration
 Review operator handbook
 Starting stopping operations
 Direction change controls
 Accelerator & braking controls
 Warning devices (i.e. horn/ beacon)
 Hydraulics controls
Legislation Awareness
 Ensure the user is aware of the appropriate local, national, and international Health &
Safety Legislation for the equipment being operated
DEALER STAMP:

7
Contents
Page No.
Declaration of Conformity 9
Noise Level Declaration 10
Vibration Declaration 11
Post Delivery Checks 12
Machine Data 14
Skip & Loading Information 14
Steering 15
Transmission 15
Brakes 15
Engine 15
Vehicle Identification Plate - VIN 15
Safety Decals and Descriptions 16
Safety Information 18
ROPS 22
Seatbelt & Seat Adjustment 23
Battery Isolator 26
Warning Others 27
Skip Prop 28
Engine Canopy 29
Driving Controls 30
Starting Procedure 31
Moving forwards & Backwards 31
Acceleration 32
Slowing Down / Stopping 32
Steering the dumper 32
Skip Control 32
Dashboard Warning Lights 33

8
Contents
Page No.
Safe Operating Instructions 35
Visibility 36
Climbing / Descending Gradients 37
Crossing Gradients 38
ROPS 39
Transportation 40
Towing Procedure 41

9
Engineering (Hamiltonsbawn) Ltd.
Manufacturers of Agricultural and Industrial Equipment
2 Killyrudden Road, Hamiltonsbawn, Tel: 028
38871970
Richhill, o. Armagh.
Fax: [phone]
Northern Ireland. E.mail: info@nc engineering.com
8T619SF www.nc-engineering.com
EC – DECLARATION OF CONFORMITY
Machine description : Site Dumper
Make NC
Type SW1.5
Manufactured by NC Engineering (Hamiltonsbawn) Ltd
Address: 2 Killyrudden Road, Hamiltonsbawn Richhill,
Co. Armagh. BT61 9S
This machinery has been designed and manufactured in accordance with the following European
Standards: -
2006/42/CE: Machinery Directive
Measured Sound Power Level: 98 dB LWA
Guaranteed Sound Power Level: 99 dB LWA
Net Installed Power: 17.5kW
A technical construction file for this machine is retained at the above address.
Declaration
Signed: ______________________________________
Name: David Wilson CEng; MSc; MIAgrE
Being the responsible person appointed by the manufacturer (or nominated representative of the manufacturer established in
the EC) and employed by:
NC Engineering (Hamiltonsbawn) Ltd
This declaration of Conformity complies with Regulation 22 of The Supply of Machinery (Safety) Regulations 1992

10
Noise Level Declaration
The noise levels are measured according to ISO6395:1998
The noise level of this machine is
L
WA
99dB ( A )
L
PA
82dB ( A )
L
WA
:- A - Weighted sound power level.
L
PA
:- A - Weighted sound pressure level.

11
Vibration Declaration.
The absence of a harmonised test code together with variable conditions under which this
equipment may be used allows only representative figures to be quotes.
Whole Body Vibration Level : a
w
(m/s²) = 0.1
Hand / Arm : a
ha
( m/s² ) ≤ 3.98
The above figures are for reference purposes only. It is the responsibility of the employer to access
vibration exposure based on the actual site conditions and operating practices at the point of use.
Employers should not rely solely on published vibration figures when undertaking risk assessments.
Depending on the site conditions cycle times may need to be adjusted in order to reduce operator
exposure levels.

12
Post Delivery Checks
• Check the condition of the machine and make sure it has not been damaged during
delivery.
• Tightness of wheel nuts.
• Check the following Oil levels in engine.
Hydraulic oil and fuel levels.
Coolant level.
Battery liquid level.
Tyre pressures. (3 Bar)
The procedures for checking fluid levels can be found in the maintenance manual
If there are any faults with the machine please report them immediately to your NC dealer
representative.
On delivery of your new machine fully read this handbook:
READ THIS HANDBOOK IN FULL

13
Routine Checks
DAILY CHECKS
WEEKLY GREASE POINTS ( heck each side of the dumper)
Hydraulic filter
indicator
Hydraulic oil
level
Coolant level
uel Sedimentor
Air filter
Engine oil level
Refer to maintenance instruction manual for
further details on the above checks.

14
Machine Data
SKIP & LOADING INFORMATION
The dumper is fitted with a swivelling load carrying skip for transporting bulk materials
commonly found on construction sites.
CAPACITIES
Max. safe load: 1500 kg
Heaped: 815 Litres
Struck: 605 Litres
Water: 480 Litres
Never attempt to load the skip beyond its rated capacity
This dumper is basically a load carrying vehicle, that can be used for a multitude of
building/contracting site work, but essentially used to transport materials away from
excavators and other building material. The dumper will allow, if used in the correct manner
the operator to accurately place material such as soil, sand, clay, stone, debris etc. in the drop
point without damage to the material or themselves.
In the lowered or load position the skip is seated in such a fashion so that the driver has
ample view ahead. Therefore when loading the skip get off the machine and do not allow
the load to be heaped in such away that will impair view.
Before moving off on the dumper insure that the skip is fully lowered and the swivel lock is
engaged.
The following information is provided for operators for their own safety.
Stay within the safe working limits of the machine. Never attempt to use
the dumper for any task other than what it was intended for by the
manufacturer. Failure to do so could result in serious injury of DEATH.
Never Tip or Swivel The Skip Unless The Machine Is On Level Ground .
Do Not Use The Edge Of The Skip When Raised As A Dozer Blade.
The maximum distance to travel with a fully laden dumper is 1km at 15kph
To stop the tyre overheating.

15
Machine Data
STEERING
Steering of the dumper is by an ‘Orbital’ hydrostatic steering unit, that articulates the centre
of the machine using a hydraulic cylinder which in turn gives a steering motion.
BRAKES
Braking is provided by Hydrostatic retardation. A park brake automatically engages when
the accelerator pedal is released. There is also the Park Brake Switch, this is used to stop the
vehicle in the event of an emergency.
ENGINE
This machine has a three cylinder diesel engine that transmits power to the wheels via a
hydrostatic pump and wheel motors. The dumper is equipped with electric start from a key
on the steering column. A battery isolator is provided under the bonnet in the engine
compartment.
VEHICLE IDENTIFICATION PLATE - VIN
The VIN plate (A) is located on the left hand side of the rear chassis beside the steps. The
number is unique to each machine and must be quoted when in contact with the
manufacturer. rom the VIN the manufacturer can call up detail relating to each individual
machine i.e. Date sold, customer, serial No., special build features etc.
(A)

16
Safety Decals and Descriptions
SAFETY DECALS
The Machine is fitted with a number of safety decals placed in areas to draw the attention
of the users. It is important that before using the machine theses decals are read and un-
derstood. The decals must be clean and readable at all times, if they need to be replaced
they can be obtained from NC spares department.
Part No. Symbol. Descriptions.
DEC~1920-002 Hydraulic oil.
DEC~1920-003 uel.
DEC~1920-010 Ignition key positions.
DEC~1920-012 Seat belt must be worn.
DEC~1920-016 No repairs to ROPS.
DEC~1920-017 Pinch points.
DEC~1920-019 Caution moving parts / Do not open when hot.
DEC~1920-078 it skip prop before accessing area. Tightness of turntable bolts
DEC~1920-031 Battery.
DEC~1920-032 Wheel nut torque / Tyre pressure.

17
Part No. Symbol. Descriptions.
DEC~1920-033 Sound levels.
DEC~1920-005 Skip controls.
DEC~1920-013 Do not operate controls until operators manual has been read.
DEC~1920-007 Safe gradients / Don’t side tip on gradient / Lower skip before moving
DEC~1920-006 Visibility / No passengers / Towing procedures / Transport / Read manual.
DEC~1920-020 Select direction of travel
DEC~1920-079 Maintenance decal.
DEC~1920-004 Keep clear of tipping area.
Safety Decals and Descriptions
DE ~1920-005
DE ~1920-013
DE ~1920-004
51
20% max
41
25% max
1 6
16% max
5
20% max
1
16% max
4
25% max
1
1 6
DE ~1920-007
DE ~1920-006

18
Safety Information
FOR SAFETY & PROTECTION READ THE FOLLOWING
Both operators and maintenance personnel must read the following safety
notice. The information below is given for your own safety. They must be
read before operating or carrying out any maintenance to the machine.
Local site rules must be adhered to at all times.
• Before operating the machine ensure that correct training has been given, and you are fully
conversant with the machine and its controls.
• A full training regime must be put in place for all operators to insure safe use of the machine.
• Do not operate the machine unless trained.
• All personnel must read these instructions before operating the machine. Always ensure instruction
manual is kept with the machine. If it gets lost, damaged or dirty replace it immediately.
• The decals are fitted to the machine for safety, if any become unreadable replace them with new
equivalents.
• Always ensure that the machine is run in a well ventilated area. Never run engine in a confined
space or close to flammable material.
• While refuelling the machine ensure that the engine is stopped. If fuel is split whilst refuelling take
measures to clean it up, do not restart engine until it is safe.
• The exhaust of this machine can reach high temperatures do not place objects close to it or on it.
Do not perform maintenance on a hot engine.
• Operator must be aware of all prohibited areas e.g. slopes, rough or dangerous terrain.
• Do not clean around the machine if the engine is running.
• When carrying out maintenance on the hydraulic system ensure that the oil is cool and that there is
no residual pressure in the circuit. Skin could be penetrated from hydraulic oil under pressure.
• Ensure that the operator wears all the necessary safety equipment at all times.
• Do not operate the machine if it is damaged, incorrectly adjusted or unassembled.
• To prevent an accident, place a warning sign on the machine and remove keys whilst performing
maintenance.
• When filling the skip no persons should be on the machine.
• Do not carry passengers.
• The foot plate should be kept clean from oil or dirt.
• Do not remove the coolant cap when engine is hot. Do not add coolant to the engine when hot.
• The machine should be parked in a safe position on firm level ground. Never leave the engine
running or key in the ignition.
• Before taking the machine onto the public road insure that the vehicle adheres to all road traffic
regulations. When on the road driving laws must be obeyed.
• Tyre repair must only be carried out by trained persons with the correct knowledge and equipment.
A reputable tyre firm with competent staff is recommended for this task.
• If the machine does roll over, the driver should brace themselves, hold tight to the steering wheel,
allow the seat belt to retain them and wait for the machine to come to a halt.
• If replacing parts always use parts supplied or recommended by the manufacturer. Never use parts
of lower specification.
• Always use qualified personnel to carry out repairs on the machine.
• Never over fill the engine with oil or the fuel tank with fuel.
• If the hydraulic oil level is low never start the engine.
• When starting the machine follow the instructions on the manual and on the machine.
• If oil is leaking from the machine report it and get it repaired immediately.

19
Safety Information
This machine is designed to transport free flowing materials. If used in the correct manner it
shall provide a efficient and safe means of transport and meet all performance standards.
The operator of the machine must be an able bodied adult fully trained in its operation.
ALWAYS
• Perform a daily check of the machine before starting.
• Ensure instruction manual stays with the machine.
• Check for children before starting, as they could be out of sight.
• Have machine in neutral gear before starting.
• Look for danger in the work area i.e. Holes, trenches, people working in confined area etc.
• Clear obvious hazards and operate with caution.
• Ensure visibility is clear when operating the machine.
• Operate the machine carefully on gradients.
• If stuck winch the machine free.
• Wear protective clothing.
• Wash and clean machine daily keeping water away from electrics.
• Adjust seat to suit each driver.
• Reduce load amount if material is of a sticky or non free flowing nature.
NEVER
• Mount or jump obstacles such as kerbs and manholes.
• Speed over rough terrain, always approach with caution.
• Leave unattended the machine with the engine running this is not only dangerous but can
cause engine damage.
• Attempt any repair to vehicle unless key is removed.
• Tamper with any safety device on the machine.
• Remove or tighten any hose when engine is running.
• Start the machine unless on the drivers seat.
• Carry any passenger.
• Load the machine so that visibility is obstructed.
• Overload the dumper beyond its rated pay load.
• ill the skip with a load that protrudes over the edge. This will block visibility, make the
dumper unstable and could cause danger to pedestrians.
• Tip into a trench unless some one is guiding the driver in with signals to prevent the trench
giving way.
• Move the dumper with the skip in the tip or hi-lift position.
• Work under the skip unless supplied prop is in place.
Always use the correct fuel, oil and grease specified by the manufacturer.
Check for over head obstructions and never operate the machine unless it is safe
to do so.
Do not use the dumper other than what it was intended for by the
manufacturer.
The driver should make themselves aware to other work colleagues.
Ensure the tyres are run at the correct pressures and well maintained.
Never cross steep inclines.
Never drive the machine close to unsteady ground such as trenches, holes etc.

20
Safety Information
SAFETY DECALS
The Machine is fitted with a number of safety decals placed in areas to draw the attention of
the users. It is important that before using the machine these decals are read and understood.
The decals must be clean and readable at all times, if they need to be replaced they can be
obtained from NC spares department.
50
500
200
800
1000
1500
3000
DE ~1920-039(B)
HT1.5
9
1
19
171615141312
8
1
20
7
7
718
2000
21
6
16
14
1312
12
13
11
17
15
15
12
13
11
14
12 13
5
10
20
19
77
77
20
19
821 186
23
11
10
9
8
5
4
32
DE ~1920-005
