USE AND CARE GUIDE
PATH LIGHT
MODEL # NEB-LSP-0009
1. Preparation
• Before beginning assembly of product, make sure all parts
are present. Compare parts with package contents list. If
any part is missing or damaged, do not attempt to assemble
the product.
• Estimated installation time: 10-15 minutes.
• No Tools Required for Assembly.
2. Assembly
• Screw together the light body (A) and the ground stake (D)
as shown above. Ensure the wire goes through the center
of the stake.
3. Installation
• Determine the location of your light. Dig a small starter hole
in the ground with a screw driver or trowel.
• Press the stake into the hole until the light is secure, but
can still be adjusted.
• Dig a small trench from the light to the transformer wire.
• Secure the connector clip (C) to the transformer wire, as
shown above.
• Test the connection by turning on the lights. Make any
desired adjustments.
• Secure the light in the ground and fill in the trenches
with dirt.
ALight Body (1) CConnector Clip (1) DGround Stake (1)
BLight Post (1)
A
D
B
C
ASSEMBLY AND INSTALLATION
WARNING: Never use a hammer to insert the light into the ground.
WARNING: The wire connector (C) contacts have sharp edges for piercing the
main low voltage cable. To avoid injury, do not touch the metal contacts.
CAUTION: The wire from low voltage power unit should be 12-18 AWG type
underground Low Energy Circuit Cable.
IMPORTANT:
• Do not submerge the fixture in water.
• Do not install the fixture within
10 ft. of water.
• The landscape wire can also be
hidden under surface.
• Protect the wiring by routing it in
close proximity to the light fixture,
or next to a building structure.
(Power Pack Sold Separately)
TROUBLESHOOTING
Problem
12 VOLT TAP
15 VOLT TAP
Total Fixture Wattage
Total Fixture Wattage
0-60 Watts
0-60 Watts
61-120 Watts
61-120 Watts
121-180 Watts
121-180 Watts
181-240 Watts
181-240 Watts
241-300 Watts
241-300 Watts
600W Transformer = (2x300) Watts
600W Transformer = (2x300) Watts
900W Transformer = (3x300) Watts
900W Transformer = (3x300) Watts
Possible Cause
CABLE LENGTH
CABLE LENGTH
0-50 feet
0-50 feet
16 AWG
16 AWG*
16 AWG
16 AWG*
14 AWG
14 AWG*
14 AWG
14 AWG*
12 AWG
12 AWG*
12 AWG
12 AWG*
12 AWG
12 AWG*
51-100 feet
51-100 feet
16 AWG
16 AWG
14 AWG
16 AWG
12 AWG
14 AWG
12 AWG
14 AWG
Not Recommended
12 AWG
Not Recommended
12 AWG
Not Recommended
12 AWG
101-150 feet
101-150 feet
14 AWG
16 AWG
12 AWG
12 AWG
Not Recommended
12 AWG
Not Recommended
12 AWG
Not Recommended
Not Recommended
Not Recommended
Not Recommended
Not Recommended
Not Recommended
Solution
The fixture will not light.
The light flickers (one only)
The lights flicker (all)
There is no power.
There is a disconnect or
break in the wire.
There is a loose connection to the fixture.
There is a loose connection
at the transformer.
The transformer setting is incorrect.
Check the outlet and ensure that a breaker or
GFCI circuit has not been tripped.
Repair the loose connection and ensure proper
contact.
Unplug the transformer from the outlet and
visually inspect the positive and negative
connecting points. Each wire should securely be
screwed in and ot contact with each other.
Follow the wires from the fixture and ensure
continuity back to the transformer.
.
Check the settings on the transformer.
PRODUCT GUARANTEE
CABLE SELECTION
* NOT RECOMMENDED FOR HALOGEN LANDSCAPE LIGHTS
This data is provided as a general guideline. Actual performance will depend on the installation layout, the fixtures, and the condition of the cable.
NOTE: Most LED landscape lighting fixtures can operate with full illumination down to as little as 8VAC. It is possible to have extended length runs with LED fixtures that go beyond the
specifications shown in the guidelines above.
For more information, detailed video
instructions, and warranty registration,
visit NEBOLIGHTS.com
If you experience a problem, please do not return to your local store. Contact our Customer Service team at 800-255-6061
CARE AND CLEANING
Before Cleaning, Disconnect the power to the fixture by unplugging the fixture.
Do not use any cleaners with chemicals,
solvents or harsh abrasives.
Clean the fixture with a soft damp cloth.
