SpectraViewTM LCD Series
Color calibration solution for 19" and 21" high-performance NEC LCDs
PROFESSIONAL

Unparalleled display performance for your
COLOR-CRITICAL
applications.
Designed for professionals with color critical
applications, the SpectraViewII Color Calibration
Solution combines award-winning NEC Display
Solutions LCD monitor technology with a color
measurement sensor and sophisticated software.
The result is a highly accurate, reliable, repeat-
able and feature-rich display calibration and
profiling solution.
Quick and easy measurements. The SpectraViewII
system uses the iOne Display 2, a custom, co-
branded colorimeter from GretagMacbeth, to take
color measurements of the display screen during
calibration. The software analyzes these measure-
ments and sends color adjustment commands
directly to the display monitor. This means that
color adjustments are made in the monitor rather
than in the video graphics adapter, resulting in
full use of the number of colors available on the
graphics adapter and a much brighter image with
the maximum possible color gamut. With Spectra-
ViewII, the video graphics adapter is not used at all
to make any gamma or tone response curve cor-
rections to the display, so the full color resolution
and fidelity of the system is maintained.
10-bit internal look-up tables (LUTs) - Each LCD monitor supported
by SpectraViewII features three internal 10-bit LUTs. These tables
allow very precise adjustments to be made to the display’s tone
response curve without reducing the number of displayable colors.
Display Data Channel Command Interface (DDC/CI) - SpectraViewII
communicates with the monitors using DDC/CI, which is a two-way
communications link between the video graphics adapter and
display monitor using the normal video signal cable. No extra cables
are necessary. All adjustments to the monitor settings are done
automatically using this communications link.
Multiple calibration sets - Different monitor calibrations can
be instantly loaded, allowing quick and easy switching between
different calibration settings without the need to re-calibrate the
display. Each time a calibration set is loaded, the necessary monitor
settings and ICC/ColorSync profiles are automatically updated.
Calibrated display information - At the end of each monitor cali-
bration, an information window is displayed, which shows the results
of the calibration and includes a wealth of information about the
display such as the measured color gamut, grayscale color tracking,
Delta-E and luminance values. Additional information about the dis-
play monitor such as the model name, serial number and the total
number of hours that it has been in use are also displayed.
Calibration status validation - SpectraViewII will query each cali-
brated monitor to see if any controls have changed since the last
calibration. If anything has changed, the previous calibrated state
can be restored automatically.
Application flexibility - SpectraViewII provides many features and
options that make it flexible enough to be used in a large variety of
applications, including full DICOM support for medical imaging. The
display luminance can be adjusted to either a specific value or to
the maximum possible that the display can achieve.
Network support (Windows only) - SpectraViewII integrates with
the NEC NaViSetTM Administrator network software(available sepa-
rately from your NEC representative) to provide remote network
access and monitoring of display monitors. NaViSet Administrator
is able to read, display and log the current calibration settings
and status of displays on an existing network(LAN). This feature is
particularly useful for large installations where central monitoring
and asset management is needed.
Monitor locking - Once calibrated, the On Screen Manager(OSM)
controls for the display monitors can be locked to prevent acciden-
tal or unauthorized adjustment, which may invalidate the calibrated
state of the monitor.
Monitor profiling - After calibration, the display is automatically
profiled and highly accurate ICC/ColorSync color profiles are gener-
ated and automatically registered with the color management
system. These profiles use the Bradford Chromaticity Adaptation
matrix.
Colorimeter function - The software features a colorimeter func-
tion, which allows direct measurements to be taken by the color
sensor and the results displayed in a variety of different formats.
SpectraViewII Color Calibration Solution Features and Benefits

The 21" NEC MultiSync LCD2180UXWG LED, the
world’s first LED-backlit LCD desktop display,
delivers new levels of image detail and color
scale to professional-level users in the areas of
computer graphics, digital animation, medical
imaging, pre-press production and film, video and
photo editing. Chosen from only the top 5% of
the manufacturer’s production, the LEDs used
for this display meet stringent purity and light
output vs. power requirements.
Using LEDs as the backlight source in lieu of
normal fluorescent tubes, the LCD2180WG LED
reveals an amazingly broad color gamut without
loss of luminance. This state-of-the-art technol-
ogy is able to produce more detail and greater
nuances on digital images than any other LCD or
CRT on the market today.
MultiSync LCD2180WG LED features include:
Wide color gamut achieves more than 100% of NTSC
and Adobe RGB
Variable whitepoint system backlight results in a
broader range between color steps with no loss of
luminance when the whitepoint is adjusted(no loss of
luminance between 5000-9300K)
Built-in color feedback system stabilizes target color
in one minute after power is turned on vs. 30 minutes
in standard desktop LCDs. The system also maintains
the stability of color over time
ColorComp compensates for the differences with the
screen’s white uniformity and improves the color and
luminance uniformity of the display
10-bit internal look-up tables (LUTs) allow the monitor
to display from a color palette of more than 1 billion
colors as well as precise adjustments to be made to
the display’s tone response curve without reducing the
number of displayable colors
Built-in feedback maintains color stability and better
color tracking compared to CCFL
True 10-bit digital video input designed for compatibil-
ity with future 10-bit video cards and operating systems
Professional-level LCD monitors. When combined with the SpectraViewII Color Calibration Solution, select 19" and 21" NEC LCDs deliver the utmost in
desktop color performance.
XtraView+TM technology allows for 176° viewing angle
from all directions
Environmentally friendly and RoHS compliant due to
omission of CCFL lighting source
Passive cooling system results in no fan noise or mov-
ing mechanical parts
Dual DVI connectivity allows for multi-computer
configurations through a single monitor, significantly
improving productivity
The 19" NEC MultiSync LCD1980SXi and 21"
LCD2180UX, have not only revolutionized the way
flat-panel monitors are engineered and designed,
but how they can be used. With their multitude of
leading-edge capabilities, combined with ground-
breaking minimalist design, these monitors
could easily be considered the most intelligent
visual display solutions to date. Not only are
these monitors smart investments for you and
your company, their advanced functionality and
productivity-enhancing technologies illustrate
their unique brilliance.
Features and benefits of the LCD1980SXi and
LCD2180UX include:
Ultra-thin-frame design allows you to view more of
your ideas and less of the monitor bezel, while freeing
up more horizontal and vertical desktop space for
multiple-monitor applications
XtraView+ technology allows for the widest viewing
angles available(up to 176°) without off-angle color shift
Rapid ResponseTM technology delivers virtually unin-
terrupted, undistorted viewing of high-speed video
NaViSetTM software offers an expanded and intuitive
graphical interface, allowing you to more easily adjust
display settings via mouse and keyboard. The Adminis-
trator version utilizes the monitor’s advanced control
and diagnostics capabilities to provide IT profession-
als with remote access to monitor settings over their
existing network
GammaCompTM internal circuitry automatically con-
verts 8-bit data from the PC to 10-bit and back to 8-bit,
producing smooth, accurate color tones
TileMatrixTM allows you to build video
walls of various configurations(up to 5 x
5) through the Advanced OSM
TileCompTM compensates for tiled bezel
width to optimally display still images
(MultiSync LCD1980SXi)
Power-off timer automatically turns
your monitor’s power off after a user-
determined amount of time
AutoBrightTM function aligns the moni-
tor’s brightness level with the application
in use for optimal viewing
Auto DVI cable detection eliminates manual setup steps
and ensures optimal performance between your system
and monitor
Advanced No Touch Auto AdjustTM provides optimal
image settings upon initial power-on and closed
signal changes(includes a user-selectable mode in the
Advanced OSM)
Pivot capability and height-adjustable stand add
flexibility to your viewing preferences

MultiSync is a registered trademark, and Advanced No
Touch Auto Adjust, Ambix+, AutoBright, GammaComp,
NaViSet, Rapid Response, SpectraViewII, TileMatrix and
TileComp are trademarks of NEC Display Solutions.
All other brand or product names are trademarks or
registered trademarks of their respective holders.
Product specifications subject to change. 8/05 ver. 1.
©2005 NEC Display Solutions of America, Inc.
All rights reserved.
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
www.necdisplay.com
LCD2180WG LED (LCD2180WGLEDBKSV)
21.3"/54 cm
0.27mm
94 @ native res0lution
200 cd/m2(with ColorComp off )
430:1
176° Vert., 176° Hor. (88U/88D/88L/88R)@ CR>10
Rapid Response(20ms)
More than 16 million with 8-bit video card,
More than 1 billion with 10-bit video card
103%
107%
75 kHz
60 Hz
ANALOG RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green:(0.3Vp-p negative
0.7Vp-p positive)
2X DVI-D(10-bit video support on Input 2)
ANALOG/DIGITAL
1600 x 1200 @ 60 Hz
1600 x 1200
Ultra-thin frame(bezel), tilt base, XtraView+
wide-angle viewing technology, cable manage-
ment, ColorComp screen uniformity correction,
OmniColor 6-axis color control, 10-bit video input
(using DualLink DVI), sRGB and Adobe RGB color
space emulation, digital controls, vacation switch,
power-off timer, color temperature mode, serial
number display, Rapid Response, ISO 13406-2
No
100-240V @ 50-60 Hz
100W
7W
18.6 x 18.2 x 8.3 in./473 x 461.7 x 211.9mm
18.6 x 14.6 x 4.9 in./473 x 370.4 x 124.5mm
40.3 lbs./18.3 kg
31.1 lbs./14.1 kg
100 x 100mm
5-35° C/41-95° F
30-80%
3658m/12,001 ft.
-10-60° C/14-140° F
10-85%
12,192m/40,000 ft.
UL/C-UL or CSA, FCC Class B/Canadian DOC, TUV GS,
TUV Ergonomie, CE
Yes
SpectraViewII Color Calibration Kit(custom-cali-
brated colorimeter and software)*, hood
3 years parts and labor, including backlight
24 hours/7 days
LCD1980SXi (LCD1980SXi-BK-SV)
19"/48 cm
0.294mm
86 @ native resolution
270 cd/m2
500:1
176° Vert., 176° Hor.(88U/88D/88L/88R)
Rapid Response(25ms)
More than 16 million
70%
69%
31.5-81.1 kHz
50-85 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level(positive/negative)
Composite Sync: TTL Level(positive/negative)
Composite Sync on Green(0.3 Vp-p negative
0.7 Vp-p positive)
Ambix+ technology(DVI-I, DVI-D, VGA 15-pin D-sub)
ANALOG/DIGITAL
640 x 400 @ 70-85 Hz(digital only)
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Ultra-thin frame(bezel), GammaComp, TileMatrix,
TileComp, XtraView+ wide-angle viewing technol-
ogy, Ambix+ technology, Advanced No Touch Auto
Adjust, AutoBright, CableComp, power-off timer,
Rapid Motion, digital smoothing, digital controls,
OmniColor 6-axis color control, sRGB, third-party
touchscreen and protective glass integration,
Plug and Play(VESA DDC2B & 2Bi), VESA DPMS power
management, optional MultiSync SoundBar80,
automatic DVI selection, ISO 13406-2
Designed for integration
100-240V @ 50-60 Hz
45W
<1W
412.2 x 365 x 200mm/16.2 x 14.4 x 7.9 in
412.2 x 337 x 80mm/16.2 x 13.3 x 3.1 in
21.4 lbs/9.7 kg
13.9 lbs/6.3 kg
100 x 100mm
5-35°C/41-95°F
30-80%
3048 m/10,000 ft
-10-60°C/14-140°F
10-85%
12,192m/40,000 ft
UL/C-UL or CSA, VCCI(class2), PCT, FCC Class B/Cana-
dian DOC, TUV GS, TUV Ergonomie, CE
No
SpectraViewII Color Calibration Kit(colorimeter and
software)*. hood
3 years parts and labor, including backlight
24 hours/7 days
LCD2180UX (LCD2180UX-BK-SV)
21.3"/54 cm
0.27mm
94 @ native resolution
250 cd/m2
500:1
176° Vert., 176° Hor.(88U/88D/88L/88R)
Rapid Response(20ms)
More than 16 million
72%
69%
31.5-91.1 kHz
50-85 Hz
Analog 0.7 Vp-p/75 Ohms
Separate Sync: TTL Level(positive/negative)
Composite Sync: TTL Level(positive/negative)
Composite Sync on Green(0.3 Vp-p negative
0.7 Vp-p positive)
Ambix+ technology(DVI-I, DVI-D, VGA 15-pin D-sub)
ANALOG/DIGITAL
640 x 400 @ 70-85 Hz(digital only)
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @60 Hz
1600 x 1200 @ 60 Hz
Ultra-thin frame(bezel), GammaComp,
TileMatrix, XtraView+ wide-angle viewing
technology, Ambix+ technology, Advanced
No Touch Auto Adjust, AutoBright, CableComp,
power-off timer, digital smoothing, digital controls,
sRGB, OmniColor 6-axis color control sRGB,
third-party touchscreen and protective glass
integration, Plug and Play(VESA DDC2B & 2Bi), VESA
DPMS power management, optional MultiSync
SoundBar80, automatic DVI selection, ISO 13406-2
Designed for integration
Universal 100(110-240V) 50-60 Hz internal
52W
<1W
467 x 391 x 200mm/18.4 x 15.4 x 7.9 in
467 x 358.7 x 85mm/18.4 x 14.1 x 3.3 in
24.3 lbs/11.5 kg
17 lbs/7.7 kg
100 x 100mm
5-35°C/41-95°F
30-80%
4,850 m/15,900 ft
-10-60°C/14-140°F
10-85%
13,600m/44,600 ft
UL/C-UL or CSA, VCCI(class2), PCT, FCC Class B/Cana-
dian DOC, TUV GS, TUV Ergonomie, CE
No
SpectraViewII Color Calibration Kit(colorimeter and
software)*, hood
3 years parts and labor, including backlight
24 hours/7 days
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Display Colors
Color Scale Achievement
NTSC
Adobe RGB
Synchronization Range
Horizontal
Vertical
Input Signal
Video
Sync
Input
Resolutions Supported
Recommended Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (WxHxD)
Net (with stand)
Net (without stand)
Net Weight
(with stand)
(without stand)
VESA Hole Configuration Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Regulatory Approvals
RoHS Compliant
Optional Accessories
Limited Warranty
Technical Support
* Monitor available as bundled solution with SpectraViewII Color Calibration Kit, which is compatible with Mac or Windows systems
