NEC SpectraView® 242
Order Code: 60003544 NEC LCD 24" Professional Colour Display
Professional 24 inch Colour Display. The NEC
SpectraView® 242 is a high-end professional performance
LCD monitor using latest 10-bit AH-IPS with GB-R LED
backlight for colour critical applications with many features
and benefits for obtaining best picture quality and colour
accuracy, whilst maintaining attractive value for money.
DELIVERING GENUINE BENEFITS
Backlight Ageing Correction - brightness and white point.
Ergonomically Mastered - comfortable viewing with
ErgoDesign® and TORO™ design.
Extraordinary Features - such as Digital Uniformity Control,
Picture-in-Picture, USB Hub, 3D LUT colour space emulation,
backlight ageing correction, DisplayPort.
Facility to create and calibrate - thanks to the SpectraView®
Profiler software.
Consistent Colour Viewing - with 10-bit AH-IPS and GB-R
Backlight 16:10 TFT display.
True Colours - with a wide colour gamut (108.6% size / 99.3%
coverage AdobeRGB) and hardware calibration with 14-bit LUT
(look up table) for 42-bit colour control and gamma correction,
irrespective of colour and input.
OUTSTANDING PERFORMANCE
Ergonomic. Suitable for long and intensive working with 150 mm height adjust
with 90° portrait capability, Automatic NTAA IPS viewing angle stability for
bestergonomics.
•
Colour Space Emulation. Each input can be assigned to the 3D LUT (9x9x9) to
define a unique colour space, e.g. sRGB, Adobe RGB.
•
Integrated USB HUB (2 up; 3 down). Can be used to attach USB peripherals such
as mouse and keyboard. At the same time the 2 up connectors can be assigned to
different video inputs (input following), which may be feeding the Picture in Picture
feature. Since the USB standard is supported by various platforms (Windows, Mac,
Linux etc.) easy support is assured when using simultaneous heterogeneous
environment.
•
Cabinet and Stand Design. Allows a very reduced packaging footprint compared
to similar displays.
•
DisplayPort Connector. Is compact and features an in-built locking mechanism,
which can be disengaged with a simple button press. Longer cable lengths and IPS
colour support ensure that application flexibility is enhanced.
•
This document is © copyright 2013 NEC Display Solutions Europe GmbH.
All rights reserved in favour of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All
specifications are subject to change without notice. Errors and omissions are excepted. 29.07.2013
www.nec-display-solutions.com

NEC SpectraView® 242
SPECIAL CHARACTERISTICS
Adjustable power LED (colour and brightness), Advanced NTAA,
AmbiBright, Auto Black Level, Auto Brightness, Auto Contrast,
AutoBright, Backlight Ageing Correction, CableComp with Sync
Continuity Detection, DDC/CI compatible, Digital Uniformity Control
(ColorComp), Direct Brightness and Contrast, EcoModes,
GammaComp (14 bit Look Up Table) and 14 bit Gamma Correction,
NaViSet Administrator 2, NaViSet®and NaViSet®Administrator
compatible, OmniColor™: sRGB and 6-Axis-Colour-Control,
Overdrive, Picture-in-Picture Mode, Quick release Stand and Handle,
Rapid Response Technology, RapidMotion, Self Diagnostics,
SpectraView® Profiler Software, TileComp, TileMatrix, TORO™
Design, Windows 8 compatible
Energy Efficiency Carbon Footprint Meter / Carbon Savings
Meter
Ecological Materials Efficient mechanical design for minimised
packaging; Minimal use of harmful material
Ecological Standards ErP compliant
Technical Specification NEC SpectraView® 242
DISPLAY
PanelTechnology AH-IPS GB-R LED Backlight
Screen Size [inch/cm] 24.1 / 61.1
Screen Aspect Ratio 16:10
Pixel Pitch [mm] 0.270
Brightness (typ.) [cd/m2]340
Contrast Ratio (typ.) 1000:1
Viewing Angle [°] 178 horizontal / 178 vertical (typ.at contrast ratio 10:1)
Response Time (typ.) [ms] 8 (grey-to-grey); 16 (8 white / black; 8 black / white)
Colours [Billion] 1.074 (10-bit per colour)
Colour Gamut Size / Coverage 108.6% / 99.3% Adobe RGB
SYNCHRONISATION RATE
Horizontal Frequency [kHz] 31.5 - 93.8 and 118.4 (analog); 31.5 - 91.1 and 118.4 (digital)
Vertical Frequency [Hz] 50 - 85
RESOLUTION
Optimum Resolution 1920 x 1200 at 60 Hz
Supported 1920 x 1080p; 1600 x 1200; 1440 x 900;1400 x 1050; 1280 x 1024;
1280 x 960; 1280 x 720p; 1200 x 1920;1152 x 870; 1152 x 864;
1024 x 768; 832 x 624; 800 x 600;720 x 576p; 720 x 480p; 720 x
400; 640 x 480; 640 x 480p
CONNECTIVITY
Digital 1 x DVI-D; 1 x HDMI; 1 x DisplayPort
Analog 1 x D-sub 15 pin
ELECTRICAL
Power Consumption on Mode [W] 37 (typ.);28 (Eco Mode); 56 (max.)
Power Savings Mode [W] 0.5
Power Supply 100-240 V;0.84 A/0.38 A; integrated power supply
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C] +5 to +35
Operating Humidity [%] 20 to 80
ERGONOMICS
Height adjustable Stand [mm] 150 (Landscape mode)
Screen Tilt / Swivel [°] -5 to +30; -45 to +45
Screen Rotate [°] 0 to 90 (landscape to portrait mode)
MECHANICAL
Bezel Width [mm] 18.2
Dimensions (W x H x D) [mm] 556.8 x 378 - 528 x 227.6 (Landscape mode)
Weight [kg] 10.6
VESA Mounting [mm] 100 x 100 (4 points)
ADDITIONAL FEATURES
Colour Versions Black Front Bezel, Black Back Cabinet
Cable Management yes
Kensington security slot yes
Plug and Play VESA DDC/CI; DDC2B/2Bi; EDID Standard
Audio Option: MultiSync®Soundbar Pro
Adjust Functions Advanced NTAA (Advanced Non-Touch-Auto-Adjustment);Advanced
User Menu; Auto Adjust; Black Level; Brightness; Colour
Temperature Control; Contrast; Expansion Mode; Fine Adjust
(analog); Hotkeys; Intelligent Power Management; Language Select;
Monitor Information; OmniColor™: sRGB and 6-axis-colour-control;
On-Screen-Display (OSD) lock-out; Sharpness; sRGB; USB; User
Menu
Shipping Content DisplayPort cable; Monitor; Power Cable; Signal Cable DisplayPort;
Sales Office List; User Manual; CD-ROM with SpectraView®Profiler
Software and manual
Signal Cable:DVI-D - DVI-D
Safety and Ergonomics EAC;CE;TÜV Ergonomics;TÜV GS; C-tick; FCC Class B; UL/C-UL
or CSA; CCC; ISO 9241-307 (pixel failure class I);MPR II/ MPR III;
PCBC/B-mark; PSB; RoHS
Warranty 3 years warranty incl. backlight
