Projector
PE506UL/ PE506WL
User’s Manual
Please visit our web site for User’s Manual in the latest version:
https://www.sharp-nec-displays.com/dl/en/pj_manual/lineup.html
Model No.
NP-PE506UL/ NP-PE506WL.

Ver. 1 9/21
Trademarks
• AccuBlend and MultiPresenter are trademarks or registered trademarks of Sharp NEC Display Solutions, Ltd. in
Japan, in the United States and other countries.
• Apple and Mac are trademarks of Apple Inc. registered in the U.S. and other countries.
• Microsoft and Windows are either a registered trademark or trademark of Microsoft Corporation in the United
States and/or other countries.
• MicroSaver is a registered trademark of Kensington Computer Products Group, a division of ACCO Brands in the
U.S. and other countries.
• The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
• PJLink trademark and logo are trademarks applied for registration or are already registered in Japan, the United
States of America and other countries and areas.
• Blu-ray is a trademark of Blu-ray Disc Association.
• CRESTRON and ROOMVIEW are registered trademarks of Crestron Electronics, Inc. in the United States and other
countries.
• Other product names and logos mentioned in this user’s manual may be the trademarks or registered trademarks
of their respective holders.
• GPL/LGPL Software Licenses
The product includes software licensed under GNU General Public License (GPL), GNU Lesser General Public
License (LGPL), and others.
For more information on each software, see “readme.pdf” in the “about GPL&LGPL” folder on the supplied CD-
ROM.
NOTES
(1) The contents of this user’s manual may not be reprinted in part or whole without permission.
(2) The contents of this user’s manual are subject to change without notice.
(3) Great care has been taken in the preparation of this user’s manual; however, should you notice any questionable
points, errors or omissions, please contact us.
(4) Notwithstanding article (3), NEC will not be responsible for any claims on loss of profit or other matters deemed
to result from using the Projector.

I
Important Information
Important Information
Safety Cautions
Precautions
Please read this manual carefully before using your NEC projector and keep the manual handy for future reference.
CAUTION
To turn off main power, be sure to remove the plug from power outlet.
The power outlet socket should be installed as near to the equipment as possible, and should be easily
accessible.
CAUTION
TO PREVENT SHOCK, DO NOT OPEN THE CABINET.
THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within the unit may be sufficient to cause electrical
shock. Therefore, it is dangerous to make any kind of contact with any part inside of the unit.
This symbol alerts the user that important information concerning the operation and maintenance of this
unit has been provided.
The information should be read carefully to avoid problems.
WARNING: TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
DO NOT USE THIS UNIT’S PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THE PRONGS
CAN BE FULLY INSERTED.
Machine Noise Information Regulation - 3. GPSGV,
The highest sound pressure level is less than 70 dB (A) in accordance with EN ISO 7779.
CAUTION
Avoid displaying stationary images for a prolonged period of time.
Doing so can result in these images being temporarily sustained on the surface of the LCD panel.
If this should happen, continue to use your projector. The static background from previous images will
disappear.
Disposing of your used product
In the European Union
EU-wide legislation as implemented in each Member State requires that used electrical and electronic
products carrying the mark (left) must be disposed of separately from normal household waste. This in-
cludes projectors and their electrical accessories. When you dispose of such products, please follow the
guidance of your local authority and/or ask the shop where you purchased the product.
After collecting the used products, they are reused and recycled in a proper way. This effort will help us
reduce the wastes as well as the negative impact to the human health and the environment at the mini-
mum level.
The mark on the electrical and electronic products only applies to the current European Union Member
States.
Outside the European Union
If you wish to dispose of used electrical and electronic products outside the European union, please
contact your local authority and ask for the correct method of disposal.
For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household
waste! There is a separate collection system for used batteries, to allow proper treatment and recycling
in accordance with legislation.
According to EU directive 2006/66/EC, the battery can’t be disposed improperly. The battery shall
be separated to collect by local service.

II
Important Information
FCC Information (for USA only)
WARNING
• The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those
specified by Sharp NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government
regulation could void your right to operate this equipment.
• This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Supplier’s declaration of conformity (for USA only)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions.
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ-
ing interference that may cause undesired operation.
U.S.Responsible Party: Sharp NEC Display Solutions of America, Inc.
Address: 3250 Lacey Rd, Ste 500
Downers Grove, IL 60515
Telephone Number: 630-467-3000
Type of Product: Projector
Equipment Classification: Class A Peripheral
Model Number: NP-PE506UL/NP-PE506WL
For UK only: In UK, a BS approved power cord with moulded plug has a Black (five Amps) fuse installed for use with
this equipment. If a power cord is not supplied with this equipment please contact your supplier.
UKCA Information (for UK only)
Herby, Sharp NEC Display Solutions, Ltd., declares that the model: NP-PE506ULG/ NP-PE506WLG) is in
compliance with the relevant statutory requirements.
UK Frequency band restriction:
Usage of this device is limited to indoor in the band 5150 to 5350 MHz.
Important Safeguards
These safety instructions are to ensure the long life of your projector and to prevent fire and shock. Please read
them carefully and heed all warnings.
Installation
• Do not place the projector in the following conditions:
- on an unstable cart, stand, or table.
- near water, baths, or damp rooms.
- in direct sunlight, near heaters, or heat radiating appliances.
- in a dusty, smoky or steamy environment.
- on a sheet of paper or cloth, rugs or carpets.
• If you wish to have the projector installed on the ceiling:
- Do not attempt to install the projector yourself.
- The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk

III
Important Information
of bodily injury.
- In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance
with any local building codes.
- Please consult your dealer for more information.
• Do not install and store the projector in the below circumstances. Failure to do so may cause of malfunction.
- In powerful magnetic fields
- In corrosive gas environment
- Outdoors
• If intense light like laser beams enters from the lens, it could lead to malfunction.
CAUTION
This equipment is designed to be used in the condition of the power cord connected to earth. If the
power cord is not connected to the earth, it may cause electric shock. Please make sure the power
cord is earthed properly.
Do not use a 2-core plug converter adapter.
Cable information
CAUTION
Use shielded cables or cables attached ferrite cores so as not to interfere with radio and television
reception. For details, please refer to “Making Connections” in this user’s manual.
WARNING
• Operation of this equipment in a residential environment could cause radio interference.
• Do not cover the lens with the lens cap or equivalent while the projector is on. Doing so can lead to melting
of the cap due to the heat emitted from the light output.
• Do not place any objects, which are easily affected by heat, in front of the projection lens. Doing so could lead
to the object melting from the heat that is emitted from the light output.
• Do not use a spray containing flammable gas to get rid of accumulated dust and dirt on the filter and the
projection window. It may cause of fire.
Fire and Shock Precautions
• Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the build-up of heat inside
your projector. Allow at least 4 inches (10 cm) of space between your projector and a wall.
• Prevent foreign objects such as paper clips and bits of paper from falling into your projector. Do not attempt to
retrieve any objects that might fall into your projector. Do not insert any metal objects such as a wire or screwdriver
into your projector. If something should fall into your projector, disconnect it immediately and have the object
removed by a qualified service personnel.
• Do not place any objects on top of the projector.
• Do not touch the power plug during a thunderstorm. Doing so can cause electrical shock or fire.
• The projector is designed to operate on a power supply of 100-240V AC 50/60 Hz. Ensure that your power supply
fits this requirement before attempting to use your projector.
• About the projector’s light source
- Do not look into the projector’s lens.
Strong light that could damage your eyes is projected when the projector is operating. Be especially careful
when children are around.
- Do not look at the projected light using optical devices (magnifying glasses, reflectors, etc.). Doing so could
result in vision impairment.
- Check that there is no one looking at the lens within the projection range before turning on the projector.
- Do not allow children to operate the projector alone. When a child is operating the projector an adult should
always be present and watch the child carefully.
- The below pictogram, that is indicated near the lens on the cabinet, describes this projector is categorized in the
risk group 2 of IEC 62471-5:2015. As with any bright light source, do not stare into the beam, RG2 IEC 62471-5:2015.

IV
Important Information
• Keep any items such as magnifying glass out of the light path of the projector. The light being projected from the
lens is extensive, therefore any kind of abnormal objects that can redirect light coming out of the lens, can cause
unpredictable outcome such as fire or injury to the eyes.
• Do not place any objects, which are easily affected by heat, in front of a projector exhaust vent.
Doing so could lead to the object melting or getting your hands burned from the heat that is emitted from the
exhaust.
• Do not splash water over the projector. Doing so can cause electrical shock or fire. If the projector gets wet, turn
off the projector, unplug the power cord and have the projector serviced by a qualified service personnel.
• Handle the power cord carefully. A damaged or frayed power cord can cause electric shock or fire.
- Do not use any power cord other than the one supplied with the projector.
- Do not bend or tug the power cord excessively.
- Do not place the power cord under the projector, or any heavy object.
- Do not cover the power cord with other soft materials such as rugs.
- Do not heat the power cord.
- Do not handle the power plug with wet hands.
• Turn off the projector, unplug the power cord and have the projector serviced by a qualified service personnel
under the following conditions:
- When the power cord or plug is damaged or frayed.
- If liquid has been spilled into the projector, or if it has been exposed to rain or water.
- If the projector does not operate normally when you follow the instructions described in this user’s manual.
- If the projector has been dropped or the cabinet has been damaged.
- If the projector exhibits a distinct change in performance, indicating a need for service.
• Disconnect the power cord and any other cables before carrying the projector.
• Turn off the projector and unplug the power cord before cleaning the cabinet.
• Turn off the projector and unplug the power cord if the projector is not to be used for an extended period of time.
• When using a LAN cable:
For safety, do not connect to the terminal for peripheral device wiring that might have excessive voltage.
• Lens shift, focus and zoom operations.
- When shifting the lens or adjusting the focus or zoom, do so from either behind or to the side of the projector.
If these operations are performed from the front, your eyes could be exposed to strong light and get injured..
- Keep your hands away from the lens area when performing the lens shift operation. If not, your fingers could get
caught in the cap between the cabinet and the lens.
CAUTION
• Do not use the adjustable tilt foot for purposes other than originally intended. Misuses such as gripping the
tilt-foot or hanging on the wall can cause damage to the projector.
• Do not turn off the AC power for 60 seconds after the light source is turned on and while the POWER indicator
is blinking blue. Doing so could cause premature Light failure.
Remote Control Precautions
• Handle the remote control carefully.
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• Do not short, heat, or take apart batteries.
• Do not throw batteries into fire.
• If you will not be using the remote control for a long time, remove the batteries.
• Ensure that you have the batteries’ polarity (+/−) aligned correctly.
• Do not use new and old batteries together, or use different types of batteries together.
• Dispose of used batteries according to your local regulations.

V
Laser Safety Caution
!
WARNING
CLASS 2 OF IEC 60825-1 SECOND EDITION LASER PRODUCT
• LASER RADIATION - DO NOT STARE INTO BEAM.
• Use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
For USA
This product is classified as Class 2 of IEC 60825-1 Second edition 2007-03.
Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No.
57, dated June 24, 2007.
For other regions
This product is classified as Class 1 of IEC 60825-1 Third edition 2014-05 and RG2 of IEC 62471-5 First edition
2015-06.
• Obey the laws and regulations of your country in relation to the installation and management of the device.
• Outline of laser emitted from the built-in light module:
Wave length: 449-461nm
Maximum power: 105W
• Radiation pattern from the protective housing:
Wave length: 449-461nm
Maximum laser radiation output: 66.6mW
The laser module is equipped in this product. Use of controls or adjustments of procedures other than those
specified herein may result in hazardous radiation exposure.
Light Module
• A light module containing multiple laser diodes is equipped in the product as the light source.
• These laser diodes are sealed in the light module. No maintenance or service is required for the performance
of the light module.
• End user is not allowed to replace the light module.
• Contact qualified distributor for light module replacement and further information.
Important Information

VI
• The caution and the explanatory labels of the LASER PRODUCT in Class 1 conforming to IEC 60825-1 Third
edition are stuck on the below indicated positions.
Label 1
For USA only
NP-PE506UL
LABEL(Warning)
520084000
2021/08/30 SONG
SONG
WARNING: MOUNT ABOVE THE HEADS OF CHILDREN
Additional warning against eye exposure for close exposures less than 1m
520084000
I
520084000
Label 2
NP-PA1004ULG
LABEL(LASER G)(PA1004UL)
24L8989□
T01L636□
2020/02/21 Abe
Lee
Utsunomiya
Yamada
PJ
Biz.
For USA
Label 2
For other regions
Label 2
Important Information

VII
Laser light radiation range
The figure below shows the maximum radiation range of the laser light.
Horizontal angle (unit: degree)
Zoom
Lens position
Right most Center (Reference value) Left most
HR HC HL
Wide 33.0 22.3 33.0
Tele 21.8 14.2 21.8
Zoom
Lens position
Upper most Center (Reference value)
VU VC
Wide 29.45 14.4
Tele 19.2 9.0
HC
HC
HL
HR
VU
VC
VC
Upper
Left
Right
Important Information

VIII
About High Altitude mode
• Set [High altitude] to [ON] in the Setting menu when using the projector at altitudes approximately 1700 meters or higher.
Using the projector at an altitude of about 1700 meters or more without setting [High altitude] to [ON] can cause
the projector to overheat and shut down the protector.
• Using the projector at altitudes less than approximately 1700 meters and setting it to [ON] can cause the light
module to overcool, causing the image to flicker. Switch [High altitude] to [OFF].
• Using the projector at altitudes approximately 1700 meters or higher can shorten the life of optical components
such as the light module.
• When the projector is at altitudes approximately 1700 meters or higher, it will switch from [OFF] to [ON]
automatically.
Clearance for Installing the Projector
When installing the projector, keep sufficient space around it, as described below. If not, the hot exhaust emitted
from the projector may be taken back in.
Also, make sure no wind from an air-conditioner hits the projector. The projector’s heat control system may detect
an abnormality (temperature error) and automatically shut off the power.
20 cm/8" or greater
Exhaust vent
Wall
NOTE:
In the above figure, it is assumed that there is sufficient space above the projector. There is also an intake vent in the front. Leave about
10 cm or more space behind, and even more space for installing the cables.
Precautions for Ceiling Installation
Do not install the projector in the following places. Attached substances such as oil, chemicals and
moisture may cause deformation or cracks of the cabinet, corrosion of the metal parts, or malfunction.
• Outdoors and places with humid or dust.
• Places exposed to oil smoke or steam.
• Places where corrosive gases are generated.
About Copyright of original projected pictures:
Please note that using this projector for the purpose of commercial gain or the attraction of public attention in a venue
such as a coffee shop or hotel and employing compression or expansion of the screen image with the following
functions may raise concern about the infringement of copyrights which are protected by copyright law.
[ASPECT], [KEYSTONE], Magnifying feature and other similar features.
Turkish WEEE information relevant for Turkish market
AEEE Yonetmeliğine Uygundur.
This device is not intended for use in the direct field of view at visual display workplaces. To avoid incommoding
Important Information

IX
reflections at visual display workplaces this device must not be placed in the direct field of view.
Power management function
The projector has power management functions. To reduce power consumption, the power management functions
(1 and 2) are factory preset as shown below. To control the projector from an external device via serial cable con-
nection, use the on-screen menu to change the settings for 1 and 2.
1. STANDBY MODE (Factory preset: NORMAL)
To control the projector from an external device, select [NETWORK STANDBY] or [SLEEP] for [STANDBY MODE].
NOTE:
• When [NORMAL] is selected for [STANDBY MODE], the following terminals and functions will not work:
MONITOR OUT terminal, AUDIO OUT terminal, LAN functions. Please refer to page 39 about details.
2. Power management (Factory preset: Ready)
To control the projector from an external device, select [OFF] for [Power management].
NOTE:
• When [5 Min] is selected for [Timer], you can enable the projector to automatically turn off in 5 Min if there is no signal received by any
input or if no operation is performed.
360° projection function
Our projector support 360° projection.
Vertical 360°
菜单
MENU
信号源
SOURCE
退出
EXIT
决定
ENTER
横向 360°
竖向 360°
（竖向与横向的组合）
Horizontal 360°
菜单
MENU
信号源
SOURCE
退出
EXIT
决定
ENTER
横向 360°
竖向 360°
（竖向与横向的组合）
Vertical & Horizontal 360°
菜单
MENU
信号源
SOURCE
退出
EXIT
决定
ENTER
横向 360°
竖向 360°
（竖向与横向的组合）
Important Information

Table of Contents
Table of Contents
Important Information............................................................... I
1. Introduction ......................................................................... 1
❶What’s in the Box? ........................................................................................................ 1
❷Introduction to the Projector ......................................................................................... 2
About this user’s manual ......................................................................................... 2
❸Part Names of the Projector.......................................................................................... 3
Front/Top ................................................................................................................. 3
Rear ......................................................................................................................... 4
Top Features............................................................................................................ 5
Terminal Panel Features .......................................................................................... 6
❹Part Names of the Remote Control............................................................................... 7
Battery Installation ................................................................................................... 8
Remote Control Precautions ................................................................................... 8
Operating Range for Wireless Remote Control ....................................................... 8
Angle sensor ............................................................................................................ 9
2. Projecting an Image (Basic Operation) ............................... 10
❶Flow of Projecting an Image........................................................................................ 10
❷Connecting Your Computer/Connecting the Power Cord .......................................... 11
❸Turning on the Projector.............................................................................................. 12
❹Change the On-Screen menu language...................................................................... 13
5Selecting a Source ...................................................................................................... 14
Selecting the computer source.............................................................................. 14
6Adjusting the Picture Size and Position ...................................................................... 15
Adjust the Tilt Foot................................................................................................. 16
Zoom...................................................................................................................... 17
Focus ..................................................................................................................... 17
Lens shift ............................................................................................................... 18
7Correcting Keystone Distortion [KEYSTONE] ............................................................. 20
8Optimizing Computer Signal Automatically ................................................................ 22
Adjusting the Image Using Auto Adjust................................................................. 22
9Turning Up or Down Volume ....................................................................................... 22
❿Turning off the Projector ............................................................................................. 23
When Moving the Projector ....................................................................................... 24
3. Convenient Features.......................................................... 25
❶Turning off the Image and Sound................................................................................ 25
❷Freezing a Picture........................................................................................................ 25
❸Magnifying a Picture.................................................................................................... 25
4. Using the VIEWER .............................................................. 27
USB-A function ................................................................................................................ 27
5. Using On-Screen Menu ...................................................... 29
❶Menu item overview .................................................................................................... 29
❷List of Menu Items....................................................................................................... 30

Table of Contents
❸Menu Descriptions & Functions [INPUT]..................................................................... 33
Computer............................................................................................................... 33
HDMI1 and HDMI2 ................................................................................................ 33
USB-A.................................................................................................................... 33
LAN ........................................................................................................................ 33
❹Menu Descriptions & Functions [Display menu].......................................................... 34
[Auto PC adj.]......................................................................................................... 34
[Fine sync].............................................................................................................. 34
[H position]............................................................................................................. 34
[V position] ............................................................................................................. 35
[H. size] .................................................................................................................. 35
[Aspect].................................................................................................................. 35
[Orientation] ........................................................................................................... 36
[Menu position] ...................................................................................................... 36
[Background display] ............................................................................................. 37
[Signal format]........................................................................................................ 37
❺Menu Descriptions & Functions [Color adjust]............................................................ 38
[Image mode]......................................................................................................... 38
[Contrast] ............................................................................................................... 39
[Brightness]............................................................................................................ 39
[Color temp.] .......................................................................................................... 39
[Red]....................................................................................................................... 39
[Green] ................................................................................................................... 39
[Blue]...................................................................................................................... 39
[Sharpness]............................................................................................................ 39
6Menu Descriptions & Functions [Setting] .................................................................... 40
[On start] ................................................................................................................ 40
[Standby mode] ..................................................................................................... 41
[High altitude]......................................................................................................... 41
[Cooling fast].......................................................................................................... 42
[Key lock] ............................................................................................................... 42
[Contrast optimization]........................................................................................... 43
[Baud rate] ............................................................................................................. 43
[Laser control] ........................................................................................................ 44
[Sound]................................................................................................................... 44
[HDMI setup].......................................................................................................... 45
❼Menu Descriptions & Functions [Expand] ................................................................... 46
[Language] ............................................................................................................. 46
[Auto setup]............................................................................................................ 47
[Keystone] .............................................................................................................. 48
[Security]................................................................................................................ 51
[Power management]............................................................................................. 52
[Filter] ..................................................................................................................... 53
[Test pattern].......................................................................................................... 53
[Network setup]...................................................................................................... 54
[Control ID]............................................................................................................. 55
[Factory default]..................................................................................................... 56
❽Menu Descriptions & Functions [USB-A] .................................................................... 57
[Set slide] ............................................................................................................... 57
[Slide transition effect] ........................................................................................... 57
[Sort order]............................................................................................................. 57
[Rotate] .................................................................................................................. 58
[Best fit].................................................................................................................. 58

Table of Contents
[Repeat].................................................................................................................. 58
[Apply].................................................................................................................... 58
❾Menu Descriptions & Functions [Info.] ........................................................................ 59
6. Network control ................................................................. 60
❶Network control operation........................................................................................... 60
❷Enter through a Web browser ..................................................................................... 61
Connecting Your Computer................................................................................... 61
❸[System status] page................................................................................................... 62
4[General setup] page ................................................................................................... 62
❺[Picture setup] page .................................................................................................... 62
❻[Image setup] page...................................................................................................... 63
❼[Network setup] page .................................................................................................. 64
7. Installation and Connections ............................................. 65
❶Setting Up the Screen and the Projector .................................................................... 65
Tables of screen sizes and dimensions................................................................. 67
Example of installation on a desktop..................................................................... 68
Lens shift range ..................................................................................................... 70
❷Making Connections ................................................................................................... 72
Connecting Your Computer................................................................................... 72
Cautions when using a DVI signal ......................................................................... 73
Connecting an External Monitor ............................................................................ 74
Connecting Component Input ............................................................................... 75
Connecting HDMI Input ......................................................................................... 76
Connecting to a Wired LAN................................................................................... 77
Connecting to a Wireless LAN............................................................................... 77
8. Connecting with MultiPresenter app.................................. 80
1Things you can do by connecting the projector with MultiPresenter app .................. 80
2Connecting to MultiPresenter ..................................................................................... 81
9. Maintenance ...................................................................... 82
❶Cleaning the Filter ....................................................................................................... 82
❷Cleaning the Lens........................................................................................................ 84
❸Cleaning the Cabinet................................................................................................... 84
10. Appendix.......................................................................... 85
❶Troubleshooting .......................................................................................................... 85
Common Problems & Solutions ............................................................................ 85
If there is no picture, or the picture is not displayed correctly. ............................. 86
Feature of each indicator....................................................................................... 88
Indicator Message (Status message) .................................................................... 88
Indicator Message (Error message)....................................................................... 89
❷Specifications.............................................................................................................. 91
❸Cabinet Dimensions .................................................................................................... 93
❹Pin Assignments of D-Sub COMPUTER Input Terminal ............................................. 95
❺Compatible Input Signal List ....................................................................................... 96

Table of Contents
❻PC Control Codes and Cable Connection .................................................................. 98
❼Troubleshooting Check List ...................................................................................... 100
❽REGISTER YOUR PROJECTOR! (for residents in the United States, Canada, and
Mexico) ................................................................................................................ 102

1
1. Introduction
❶What’s in the Box?
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Please save the original box and packing materials if you ever need to ship your projector.
Unless otherwise described in the user’s manual, the drawings for the projector cabinet show examples of the PE506UL.
Projector
Lens cap × 1
(440165300)
(Only for PE506UL )
Remote control
(393004710)
Batteries (AAA × 2)
(391003200)
Power cord
(US: 310004900)
(EU: 310003100)
Computer cable (VGA)
(310002200)
NEC Projector CD-ROM
User’s manual (PDF)
(510054500)
• Important Information (510054600)
• Quick Setup Guide(U/G) (510054800)
Quick Setup Guide(G2) (510054700)
For North America only
Limited warranty
For customers in Europe:
You will find our current valid Guarantee Policy on our Web Site:
https://www.sharpnecdisplays.eu

2
1. Introduction
❷Introduction to the Projector
This section introduces you to your new projector and describes the features and controls.
• Simple Computer System Setting
The projector has the Multi-scan system to conform to many computer output signals quickly. Up to WUXGA
resolution can be accepted.
• Useful Functions for Presentations
The digital zoom function allows you to focus on the crucial information during a presentation.
• Brightness adjustment
Brightness of the projection light source can be selected.
• Multilanguage Menu Display
The screen menu of the projector is available in 27 languages: English, German, French, Italian, Spanish, Polish,
Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian,Arabic, Turk-
ish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazakh, Vietnamese, Thai, Farsi, Romania.
• Convenient Maintenance Functions
Filter maintenance functions provide for better and proper maintenance of the projector.
• Security Function
The Security function helps you to ensure security of the projector. With the Key lock function, you can lock the
operation on the control panel. PIN code lock function prevents unauthorized use of the projector.
• Colorboard Function
At the time of simple projection on the colored wall, you can get the close color image to the color image projected
on a white screen by selecting the similar color to the wall color from the preset four colors.
• Power Management
The Power management function reduces power consumption and maintains the light source life.
About this user’s manual
The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to
review the user’s manual. This may save you time later on. At the beginning of each section of the manual you’ll find
an overview. If the section doesn’t apply, you can skip it.

3
1. Introduction
❸Part Names of the Projector
Front/Top
Controls
(→page 5)
Lens shift dial (→page 18)
Front Remote Sensor
(→page 8)
Intake Vent
Exhaust Vent
Heated air is exhausted from here.
Indicators
(→page 5)
Zoom Lever
(→page 17)
Focus Ring
(→page 17)
Adjustable Tilt Foot
(→page 16)
Lens
Unless otherwise described in the user’s manual, the drawings for the projector cabinet show examples of the PE506UL.
Lens Cap
(For PE506UL only)
For protecting lens.
Make sure to take it off during
projection.

4
1. Introduction
Rear
* This security slot supports the MicroSaver ®Security System.
NOTE:
• Security and theft protection lock compatible with Kensington security cables/equipment. For products, visit Kensington’s website.
Security chain opening
Attach an anti-theft device.
The security chain opening accepts
security wires or chains up to
0.18 inch/4.6 mm in diameter.
Rear Remote Sensor
(→page 8)
Built-in Security Slot ( )*
Use for the theft and dropping-off
prevention measure.
AC Input
Connect the supplied power cord’s
three-pin plug here, and plug the
other end into an active wall outlet.
(→page 11)
Terminal Panel
(→page 6)
Intake Vent / Filter Cover
(→page 82)
Adjustable Tilt Foot
(→page 16)
Monaural Speaker (16 W)
Unless otherwise described in the user’s manual, the drawings for the projector cabinet show examples of the PE506UL.

5
1. Introduction
Top Features
1. (POWER) Button
(→page 12, 23)
2. LIGHT Indicator
(→page 88)
3. STATUS Indicator
(→page 88)
4. POWER Indicator
(→page 12, 23, 24, 88)
5. INPUT Button
(→page 14)
6. MENU Button
(→page 29)
7. EXIT Button
8. ▲▼◀▶ / Volume Buttons ◀▶ / Keystone Button ▼
(→page 20, 22)
9. ENTER Button
4 3 2
7
5
6
1
89
