NEFF B27CS24G0B User manual

Oven
[en] User manual and installation in-
structions
B27CS24G0B

en Safety
2
Futher information and explanations are available on-
line:
Table of contents
INFORMATION FOR USE
1 Safety....................................................................2
2 Preventing material damage ...............................5
3 Environmental protection and saving en-
ergy .......................................................................5
4 Familiarising yourself with your appliance ........6
5 Accessories..........................................................9
6 Before using for the first time ...........................11
7 Basic operation ..................................................12
8 Time-setting options..........................................13
9 Baking and roasting assistant ..........................14
10 Childproof lock...................................................15
11 Rapid heat-up .....................................................15
12 Sabbath mode ....................................................16
13 Basic settings.....................................................16
14 HomeConnect ...................................................17
15 Cleaning and servicing......................................19
16 Cleaning functions.............................................21
17 Rails ....................................................................22
18 Appliance door...................................................23
19 Troubleshooting.................................................26
20 Disposal..............................................................27
21 Customer Service...............................................27
22 Declaration of Conformity .................................28
23 How it works.......................................................28
24 INSTALLATION INSTRUCTIONS .......................33
24.1 General installation instructions.......................33
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡To prepare meals and drinks.
¡In private households and in enclosed
spaces in a domestic environment.
¡Up to an altitude of max. 4000m above
sea level.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.

Safety en
3
1.4 Safe use
Always place accessories in the cooking com-
partment the right way round.
→"Accessories", Page9
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
▶Never store combustible objects in the
cooking compartment.
▶If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order
to stifle any flames.
Loose food remnants, fat and meat juices
may catch fire.
▶Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.
Opening the appliance door creates a
draught. Greaseproof paper may come into
contact with the heating element and catch
fire.
▶Never place greaseproof paper loosely
over accessories when preheating the ap-
pliance and while cooking.
▶Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶Caution should be exercised here in order
to avoid touching heating elements.
▶Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
▶Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire. The ap-
pliance door may spring open. Hot steam and
jets of flame may escape.
▶Only use small quantities of drinks with a
high alcohol content in food.
▶Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
▶Open the appliance door carefully.
The telescopic shelves become hot when the
appliance is in use.
▶Allow hot telescopic shelves to cool down
before touching them.
▶Only touch hot telescopic shelves with
oven gloves.
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶Never touch these hot parts.
▶Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, de-
pending on the temperature.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The appliance and its parts that can be
touched may have sharp edges.
▶Take care when handling and cleaning
them.
▶If possible, wear protective gloves.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
▶Keep your hands away from the hinges.
Components inside the appliance door may
have sharp edges.
▶Wear protective gloves.
Alcoholic vapours may catch fire in the hot
cooking compartment, and the appliance
door may spring open and may fall off. The
door panels may shatter and fragment.
→"Preventing material damage", Page5
▶Only use small quantities of drinks with a
high alcohol content in food.
▶Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
▶Open the appliance door carefully.

en Safety
4
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶Repairs to the appliance should only be
carried out by trained specialist staff.
▶Only use genuine spare parts when repair-
ing the appliance.
▶If the power cord of this appliance is dam-
aged, it must be replaced by trained spe-
cialist staff.
If the insulation of the power cord is dam-
aged, this is dangerous.
▶Never let the power cord come into contact
with hot appliance parts or heat sources.
▶Never let the power cord come into contact
with sharp points or edges.
▶Never kink, crush or modify the power
cord.
An ingress of moisture can cause an electric
shock.
▶Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the appliance or the power cord is dam-
aged, this is dangerous.
▶Never operate a damaged appliance.
▶Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶If the appliance or the power cord is dam-
aged, immediately unplug the power cord
or switch off the fuse in the fuse box.
▶Call customer services. →Page27
WARNING‒Danger: Magnetism!
Permanent magnets are used in the control
panel or in the controls. These may affect
electronic implants, e.g. heart pacemakers or
insulin pumps.
▶Wearers of electronic implants must stay at
least 10 cm away from the control panel.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶Keep packaging material away from chil-
dren.
▶Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
1.5 Cleaning function
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices
may catch fire when the cleaning function is in
progress.
▶Before starting the cleaning function, al-
ways remove the worst of the food residues
and remnants from the cooking compart-
ment and accessories.
The outside of the appliance gets very hot
when the cleaning function is in progress.
▶Never hang combustible objects, e.g. tea
towels, on the door handle.
▶Leave the front of the appliance clear.
▶Keep children at a safe distance.
If the door seal is damaged, a large amount
of heat is generated around the door.
▶Do not scrub or remove the seal.
▶Never operate the appliance if the seal is
damaged or missing.
WARNING‒Risk of serious harm to
health!
The appliance gets very hot when the clean-
ing function is in progress. The non-stick coat-
ing on baking trays and tins is destroyed and
noxious gases are released.
▶Never clean non-stick baking trays or bak-
ing tins using the cleaning function.
▶Only clean enamelled accessories at the
same time.
WARNING‒Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so
that food left over from roasting, grilling and
baking will burn off. This process releases va-
pours, which can irritate mucous membranes.
▶Keep the kitchen well ventilated while the
cleaning function is running.
▶Do not remain in the room for long periods.
▶Keep children and pets away.
WARNING‒Risk of burns!
The cooking compartment gets very hot when
the cleaning function is in progress.
▶Never open the appliance door.
▶Allow the appliance to cool down.
▶Keep children at a safe distance.

Preventing material damage en
5
The outside of the appliance gets very hot
when the cleaning function is in progress.
▶Never touch the appliance door.
▶Allow the appliance to cool down.
▶Keep children at a safe distance.
2 Preventing material damage
2.1 General
ATTENTION!
Alcoholic vapours may catch fire in the hot cooking
compartment and cause permanent damage to the ap-
pliance. The appliance door may spring open due to
an explosion and it may fall off. The door panels may
shatter and fragment. Due to the resulting negative
pressure, the cooking compartment may become con-
siderably deformed inwards.
▶Do not heat spirits (≥ 15% vol.) when undiluted (e.g.
for marinating or pouring over food).
If there is water on the cooking compartment floor
when operating the appliance at temperatures above
120°C, this will damage the enamel.
▶Do not use the appliance if there is water on the
cooking compartment floor.
▶Wipe away any water on the cooking compartment
floor before operation.
Objects on the cooking compartment floor at over
50°C will cause heat to build up. The baking and
roasting times will no longer be correct and the enamel
will be damaged.
▶Do not place any accessories, greaseproof paper or
foil of any kind on the cooking compartment floor.
▶Only place cookware on the cooking compartment
floor if a temperature above 50°C has been set.
When the cooking compartment is hot, any water in-
side it will create steam. The change in temperature
may cause damage.
▶Never pour water into the cooking compartment
when it is still hot.
▶Never place cookware containing water on the
cooking compartment floor.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶Allow the cooking compartment to dry after use.
▶Do not keep moist food in the cooking compartment
for a long time with the door closed.
▶Do not store food in the cooking compartment.
Leaving the appliance to cool down with the door open
will damage the front of neighbouring kitchen units over
time.
▶Always allow the cooking compartment to cool
down with the door closed after cooking at high
temperatures.
▶Take care not to trap anything in the appliance
door.
▶Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced during
operation.
Fruit juice dripping from the baking tray leaves stains
that cannot be removed.
▶When baking very juicy fruit flans, do not pack too
much on the baking tray.
▶If possible, use the deeper universal pan.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶Never use oven cleaner in the cooking compartment
when it is still warm.
▶Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
If the seal is very dirty, the appliance door will no
longer close properly during operation. This may dam-
age the front of adjacent kitchen units.
▶Keep the seal clean at all times.
▶Never operate the appliance if the seal is damaged
or missing.
Sitting or placing objects on the appliance door may
damage it.
▶Do not place, hang or support objects on the appli-
ance door.
▶Do not place cookware or accessories on the appli-
ance door.
With certain models, accessories may scratch the door
pane when closing the appliance door.
▶Always push accessories fully into the cooking com-
partment.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings tell you to do so.
¡Not preheating the appliance can reduce the en-
ergy used by up to 20%.

en Familiarising yourself with your appliance
6
Use dark-coloured, black-coated or enamelled baking
tins.
¡These types of baking tin absorb the heat particu-
larly well.
Open the appliance door as little as possible during
operation.
¡This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance
to reheat.
When baking multiple dishes, do so in succession or
in parallel.
¡The cooking compartment is heated after baking
the first dish. This reduces the baking time for the
second cake.
If the cooking time is relatively long, you can switch
the appliance off 10minutes before the cooking time
ends.
¡There will be enough residual heat to finish cooking
the dish.
Remove any accessories that are not being used from
the cooking compartment.
¡Accessories that are not being used do not need to
be heated.
Allow frozen food to defrost before cooking.
¡This saves the energy that would otherwise be re-
quired to defrost it.
Note:
The appliance requires:
¡A maximum of2W in networked standby mode
¡A maximum of 1W when the appliance is not con-
nected to the network, with the display switched on
¡A maximum of 0.5W when the appliance is not con-
nected to the network, with the display switched off
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operat-
ing status.
1
2 23
1
Display
2
Buttons
3
Control element

Familiarising yourself with your appliance en
7
4.2 Buttons
The buttons are touch-sensitive areas. To select a function, press the corresponding button.
Symbol Name Use
On/off Switch the appliance on or off
Main menu Select operating modes and settings
Time-setting options/
childproof lock
¡Set the "timer", "cooking time" or "Ready at" time for delayed starts
¡Activate or deactivate the "childproof lock"
Information ¡View additional information
¡View the current temperature
Rapid heat-up ¡Activate or deactivate the "Rapid heat-up" function
¡Activate or deactivate the "PowerBoost" function
Start/stop Start or pause the appliance
4.3 Control element
You can configure all the functions on your appliance using the control element. You can change the setting values
that are displayed more brightly.
Press and hold a button to scroll through the setting values quickly. Release the button to stop scrolling quickly.
Button Name Use
Left Navigate to the left on the display
Right Navigate to the right on the display
Up Navigate upwards on the display
Down Navigate downwards on the display
4.4 Display
The display shows the current settings, options or relevant information.
Symbols
Different symbols may appear on the display.
Symbol Name Use
HomeConnect ¡Home network and HomeConnect server connected
¡The number of lines shows the signal strength of the home network
→"HomeConnect ", Page17
Home network Home network not connected
→"HomeConnect ", Page17
HomeConnect server HomeConnect server not connected
→"HomeConnect ", Page17
Remote start Remote start activated
→"HomeConnect ", Page17
Remote diagnostics Remote diagnostics activated
→"HomeConnect ", Page17
4.5 Main menu
The main menu provides an overview of your appliance's functions.
Press the ⁠button to open the main menu.
Function Name Use
Heating functions Select the required heating function and temperature for your food

en Familiarising yourself with your appliance
8
Function Name Use
Baking and roasting
assistant
Recommended settings for baking and roasting
MyProfile Individually adjust the appliance settings
HomeConnect Connect the oven to a mobile end device and remotely control it.
→"HomeConnect ", Page17
EasyClean Clean less stubborn dirt from the cooking compartment
Pyrolytic self-cleaning Clean the cooking compartment
4.6 Types of heating
This is where you will find an overview of the types of heating. You will find recommendations for using the types of
heating.
For temperatures above 275°C, the appliance reduces the temperature to approx. 275°C after around 40minutes.
Symbol Heating function Temperature Use
CircoTherm® hot air 40-200°C Bake or roast on one or more levels.
The fan distributes the heat from the ring-shaped heating ele-
ment in the back wall evenly around the cooking compartment.
Top/bottom heating 50-275°C Traditionally bake or roast on one level. This type of heating is
especially good for cakes with moist toppings.
The heat is emitted evenly from above and below.
Circo-roasting 50-250°C Roast poultry, whole fish or larger pieces of meat.
The grill element and the fan switch on and off alternately. The
fan circulates the hot air around the food.
Pizza setting 50-275°C Cook pizza or food that requires a lot of heat from below.
The bottom heating element and the ring-shaped heating ele-
ment in the back wall heat the cooking compartment.
Bread-baking setting 180-240°C For baking bread, bread rolls and baked goods that require
high temperatures.
Full-surface grill 50-290°C For grilling flat items such as steaks, sausages or bread, and
for cooking au gratin.
The entire area below the grill element becomes hot.
Centre-area grill 50-290°C For grilling small amounts of steaks, sausages or bread, and
for cooking au gratin.
The central area below the grill element becomes hot.
Bottom heating 30-250°C For cooking in a bain marie and for baking food for extra time.
The heat is emitted from below.
Slow cooking 70-120°C For gentle, slow cooking of seared, tender pieces of meat in
cookware without a lid.
The heat is emitted evenly from above and below at a low tem-
perature.
Dough proving 35-55°C For proving dough and culturing yoghurt.
Dough will prove more quickly than at room temperature. The
surface of the dough does not dry out.
Defrost 30-60°C For gently defrosting frozen food.

Accessories en
9
Symbol Heating function Temperature Use
Top/bottom heating
eco
50-275°C For gently cooking selected types of food.
Heat is emitted from above and below.
This type of heating is most effective between 150 and
250°C.
This type of heating is used to determine the energy consump-
tion in the conventional mode.
CircoTherm® eco 40-200°C For gently cooking selected types of food on one level without
preheating.
The fan distributes the heat from the ring-shaped heating ele-
ment in the back wall around the cooking compartment.
This type of heating is most effective between 125 and
200°C.
This type of heating is used to determine the energy consump-
tion in circulating-air mode and the energy efficiency class.
4.7 Cooking compartment
The functions in the cooking compartment make your
appliance easier to use.
Shelf supports
The rails in the cooking compartment enable you to
place accessories at different heights.
→"Accessories", Page9
Your appliance has four shelf positions. The shelf posi-
tions are numbered from bottom to top.
You can remove the rails, e.g. for cleaning.
→"Rails", Page22
Lighting
One or more oven lights illuminate the cooking com-
partment.
When you open the appliance door, the light in the
cooking compartment switches on. If the appliance
door remains open for longer than 15minutes, the light
switches off again.
For most operating modes, the lighting is switched on
during operation. The lighting switches off again when
the operation ends.
Cooling fan
The cooling fan switches on and off depending on the
appliance's temperature. The hot air escapes above
the door.
ATTENTION!
Do not cover the ventilation slot above the appliance
door. The appliance overheats.
▶Ensure that the ventilation slots are unobstructed.
To ensure that the appliance cools down more quickly
after operation, the cooling fan continues to run for a
certain period afterwards.
Appliance door
If you open the appliance door during operation, the
operation stops. When you close the appliance door,
the operation continues automatically.
5 Accessories
Use original accessories. These have been made espe-
cially for your appliance.
Note:Accessories may become deformed if they get
hot. Deformation has no effect on function. As the ac-
cessory cools down, it will regain its original shape.
The accessories supplied may differ depending on the
appliance model.

en Accessories
10
Accessories Use
Wire rack ¡Cake tins
¡Ovenproof dishes
¡Cookware
¡Meat, e.g. roasting joints or steak
¡Frozen meals
Universal pan ¡Moist cakes
¡Baked items
¡Bread
¡Large roasts
¡Frozen meals
¡Catch dripping liquids, e.g. fat when
grilling food on the wire rack.
Accessory support When using the cleaning function, you can
accessories at the same time, e.g. the univer-
sal pan.
→"Self-cleaning function", Page21
5.1 Locking function
The locking function prevents the accessories from tilt-
ing when they are pulled out.
You can pull out the accessories approximately halfway
without them tipping. The accessories must be inserted
into the cooking compartment correctly for the tilt pro-
tection to work properly.
5.2 Sliding accessories into the cooking
compartment
Always slide the accessory into the cooking compart-
ment the right way round. This is the only way to en-
sure that accessories can be pulled out approximately
halfway without tipping.
1. Turn the accessories so that the notch ⁠ is at the
rear and is facing downwards.
2. Insert the accessory between the two guide rods for
a shelf position.
Wire rack Insert the wire rack with the open
side facing the appliance door and
the curved lip ⁠ facing downwards.
Baking tray
E.g. univer-
sal pan or
baking tray
Slide the tray in with the sloping
edge ⁠ towards the appliance door.
3. To place the accessory at shelf positions with pull-
out rails, pull out the pull-out rails.
Wire rack
or baking
tray
Position the accessory so that its
edge is behind the lug ⁠ on the pull-
out rail.
Note:The pull-out rails lock in place when they are
fully pulled out. Gently push the pull-out rails back
into the cooking compartment.
4. To place the accessory at shelf positions with pull-
out rails, pull out the pull-out rails.
Wire rack
or baking
tray
Position the accessory so that it is
below the lug ⁠ on the pull-out rail.
5. Push the accessory all the way in, making sure that
it does not touch the appliance door.
Note:Take any accessories that you will not be using
out of the cooking compartment while the appliance is
in operation.
Combining accessories
You can combine the wire rack with the universal pan
to catch any liquid that drips down.
1. Place the wire rack on the universal pan so that
both spacers ⁠ are on the rear edge of the univer-
sal pan.
2. Insert the universal pan between the two guide rods
for a shelf position. In so doing, the wire rack is on
top of the upper guide rod.

Before using for the first time en
11
Wire rack
on univer-
sal pan
5.3 Removing accessories from the cooking
compartment
1. Pull out the accessory on the telescopic shelf as far
as the notch ⁠.
Wire rack
or baking
tray
2. Hold the accessory on both sides in the area
marked ⁠ and remove it.
Wire rack
or baking
tray
5.4 Other accessories
You can purchase other accessories from our after-
sales service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.neff-international.com
Accessories vary from one appliance to another. When
purchasing accessories, always quote the exact
product number (E no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our after-
sales service.
6 Before using for the first time
Configure the settings for initial start-up. Clean the ap-
pliance and accessories.
6.1 Initial use
When the appliance is connected to the power supply
for the first time or following a lengthy power failure, the
settings that you will need to configure before you can
use it will appear.
Notes
¡You can change these settings at any time by going
to the basic settings.
→"Basic settings", Page16
¡You can also use HomeConnect to configure the
settings. If your appliance is connected, follow the
instructions in the app.
Setting the language
1. Connect the appliance to the power supply.
aThe first setting will appear after a few seconds.
2. Use the ⁠button to navigate to the bottom row.
3. Use the ⁠ or ⁠button to select the language.
4. Use the ⁠button to navigate back to the top row.
5. Use the ⁠button to select the next setting.
Setting the time
1. Use the ⁠button to navigate to the bottom row.
2. Use the ⁠ or ⁠button to select the correct hour.
3. Use the ⁠button to navigate to the next row.
4. Use the ⁠ or ⁠button to select the correct number of
minutes.
5. Use the ⁠button to navigate back to the top row.
6. Use the ⁠button to select the next setting.
Setting the date
1. Use the ⁠button to navigate to the next row.
2. Use the ⁠ or ⁠button to select the correct day.
3. Use the ⁠button to navigate to the next row.
4. Use the ⁠ or ⁠button to select the correct month.
5. Use the ⁠button to navigate to the next row.
6. Use the ⁠ or ⁠button to select the correct year.
7. Press the ⁠button repeatedly until "Date" appears.
8. Use the ⁠button to apply the settings.
9. Open and close the appliance door once.
aThe appliance will perform a self-test, after which it
will be ready to use.
aInitial configuration is now complete.
6.2 Cleaning the appliance
Before using the appliance to cook food for the first
time, you must clean the cooking compartment and ac-
cessories.
1. Remove the product information, accessories and
any leftover packaging (e.g. polystyrene pellets)
from the cooking compartment.
2. Wipe the smooth surfaces in the cooking compart-
ment with a soft, damp cloth.
3. Press ⁠ to switch the appliance on.
→"Switching on the appliance", Page12
4. Set the required heating function and temperature
for the heat-up process and press ⁠ to start.
→"Setting the type of heating and temperature",
Page12
Heating up
Heating function CircoTherm hot air ⁠
Temperature Maximum
Cooking time 1hour
5. Keep the kitchen ventilated while the appliance is
heating.

en Basic operation
12
6. Press ⁠ to switch off the appliance after 1hour.
→"Switching off the appliance", Page12
7. Allow the appliance to cool down.
8. Clean the smooth surfaces with soapy water and a
dish cloth.
9. Thoroughly clean any accessories you used with
soapy water and a dish cloth.
7 Basic operation
7.1 Switching on the appliance
▶Press ⁠ to switch the appliance on.
Notes
¡In the basic settings, you can specify whether the
heating functions or the main menu should appear
when you switch on the appliance.
→"Basic settings", Page16
¡If you do not perform any actions on the appliance
for an extended period, it will automatically switch it-
self off.
7.2 Switching off the appliance
▶Press ⁠ to switch the appliance off.
Notes
¡The residual heat indicator will appear on the dis-
play while the cooking compartment is still hot.
→"Residual heat indicator", Page12
¡The cooling fan will continue to run until the cooking
compartment has cooled down.
→"Cooling fan", Page9
7.3 Residual heat indicator
After you have switched off the appliance, the residual
heat indicator will appear on the display.
Display Temperature
Residual heat high Over 120°C
Residual heat low Between 60 and 120°C
7.4 Setting the type of heating and
temperature
1. Press ⁠ to switch the appliance on.
aThe heating functions will then be displayed.
2. Use the ⁠ or ⁠button to select the required heating
function.
3. Use the ⁠button to navigate to the next row.
4. Use the ⁠ or ⁠button to select the required temperat-
ure or setting.
5. Press ⁠ to start.
aThe cooking time will appear on the display.
aThe heat-up indicator bar visualises the rising tem-
perature.
6. When the food is ready, press ⁠ to switch the appli-
ance off.
7.5 Changing the temperature
You can also change the temperature once you have
started the appliance.
1. Use the ⁠ or ⁠button to select the temperature
row.
2. Use the ⁠ or ⁠button to select the required temperat-
ure.
aThe temperature will now be changed.
7.6 Changing the type of heating
If you switch to a different heating function, the appli-
ance will reset all the settings.
1. Press ⁠ to pause operation.
2. Use the ⁠ or ⁠button to select the required heating
function.
3. Use the ⁠button to navigate to the next row.
4. Use the ⁠ or ⁠button to select the required temperat-
ure.
5. Press ⁠ to start.
7.7 Pausing operation
1. Press ⁠.
2. Press ⁠ again to resume operation.
7.8 Cancelling operation
Note:Some functions, e.g. cleaning functions, cannot
be cancelled.
▶Press and hold the ⁠button until the function that is
currently in progress is cancelled.
aOperation will stop and all the settings will be reset.
aThe cooling fan will continue to run until the cooking
compartment has cooled down.
7.9 Viewing the current temperature
You can view the current temperature while the appli-
ance is heating up.
▶Press ⁠.
aThe temperature will be displayed for a few
seconds.
7.10 Displaying information
Requirement:The ⁠button must be lit.
▶Press ⁠.
aThe information will be displayed for a few seconds.

Time-setting options en
13
8 Time-setting options
Your appliance has different time-setting options, with
which you can control its operation.
8.1 Overview of the time-setting options
When you are setting a time, the time values will in-
crease by greater increments as you scroll through the
higher values. The cooking time, for example, can be
set in 1-minute increments up to 1 hour, and then in 5-
minute increments thereafter.
Time-setting
option
Use
Timer ⁠ When you set a time on the timer,
the timer will run independently of
the appliance and will not intervene
in its operation. The timer does not
affect the appliance.
Cooking
time ⁠
Once the cooking time has elapsed,
the appliance automatically stops
heating.
Ready at ⁠ Along with the cooking time (dura-
tion), you can set the time at which
you want cooking to end. The appli-
ance will start up automatically so
that it finishes cooking at the re-
quired time.
8.2 Timer
You can set the timer regardless of whether the appli-
ance is on or off.
Setting the timer
1. Press ⁠.
2. Once the appliance is switched on, use the
⁠button to select "Timer" ⁠.
3. Use the ⁠ or ⁠button to select the timer duration.
4. Press ⁠ to start the timer.
a⁠ will appear on the display. The timer duration will
then count down.
aOnce the timer duration has elapsed, an audible sig-
nal will sound.
5. Press any button to end the audible signal.
Changing the timer
1. Press ⁠.
2. Use the ⁠ or ⁠button to change the timer duration.
aThe setting will then be applied.
Cancelling the timer
1. Press ⁠.
2. Use the ⁠button to set a timer duration of "00:00".
aThis cancels the current timer duration.
8.3 Cooking time
Once the set cooking time has elapsed, the appliance
switches off automatically. You can only use the cook-
ing time in conjunction with a heating function.
Setting the cooking time
1. Set a heating function and a temperature.
2. Press ⁠.
3. Select the default value.
Button Default value
⁠ 10minutes
⁠ 30minutes
4. Use the ⁠ or ⁠button to select the required cooking
time.
5. Once the cooking time has been set, press ⁠ to
start.
aThe cooking time will appear on the display. The
cooking time will count down.
aOnce the cooking time has elapsed, an audible sig-
nal will sound.
6. Press any button to end the audible signal.
Changing the cooking time
1. Press ⁠.
2. Use the ⁠ or ⁠button to change the cooking time.
aThe setting will then be applied.
Cancelling the cooking time
1. Press ⁠.
2. Use the ⁠button to set a cooking time of "00:00".
aThis cancels the current cooking time.
3. To continue without setting a cooking time, press ⁠.
8.4 Delayed start/"Ready at" time
With this function, the appliance automatically switches
itself on, and then switches itself off at the preselected
end time. To enable it to do this, you set the cooking
time (duration) and specify when you want your food to
be ready. You can only use the delayed start function
in conjunction with a heating function.
Setting the "Ready at" time for delayed starts
Notes
¡Do not leave food that spoils easily in the cooking
compartment for too long.
¡You cannot use the delayed start function with every
heating function.
1. Place the food into the cooking compartment and
close the appliance door.
2. Set a heating function and a temperature.
3. Press ⁠.
4. Use the ⁠ or ⁠button to select the required cooking
time.
5. Use the ⁠button to navigate to "Ready at" ⁠.
aThe time at which your food will be ready will ap-
pear on the display.
6. Use the ⁠button to select the required end time.
7. Press ⁠ to confirm the delayed start.
aThe appliance will start at the appropriate time.
aOnce the cooking time has elapsed, an audible sig-
nal will sound.
8. Press any button to end the audible signal.
Changing the "Ready at" time for delayed starts
1. Press ⁠.
2. Use the ⁠button to select "Ready at" ⁠.

en Baking and roasting assistant
14
3. Use the ⁠ or ⁠button to change the end time.
aThe setting will then be applied.
Cancelling the "Ready at" time for delayed starts
1. Press ⁠.
2. Use the ⁠button to reset the end time.
aThe end time corresponds to the current time plus
the set cooking time.
aThe appliance will start heating using the set cook-
ing time.
9 Baking and roasting assistant
The baking and roasting assistant helps you to use
your appliance to cook various dishes by suggesting
the optimal settings.
The baking and roasting assistant helps you to make
classic cakes, bread and roasts. The appliance selects
the optimal heating function for you. The default tem-
perature and cooking time can be changed according
to your requirements.
9.1 Overview of available foods
You can choose from the following foods:
¡Rich fruit cake
¡Victoria sponge cake
¡Victoria sponge cake, on two levels
¡Swiss roll
¡Jam tarts
¡Jam tarts, on two levels
¡Fruit crumble
¡Pavlova
¡Vol au vents
¡Small cakes
¡Small cakes, on two levels
¡White bread
¡Scones
¡Scones, on two levels
¡Pizza, frozen
¡Oven chips
¡Baked potatoes
¡Baked potatoes, on two levels
¡Lasagne, chilled
¡Roast pork
¡Top rump
¡Slow roasting joint
¡Leg of lamb
¡Whole chicken
¡Chicken drumsticks
¡Duck
9.2 Configuring the baking and roasting
assistant
Note:Use fresh and, ideally, chilled food. Use frozen
food straight from the freezer.
Requirement:The cooking compartment must have
cooled down.
1. Press ⁠ to switch the appliance on.
2. Press ⁠.
3. Use the ⁠ or ⁠button to select the "Baking and roast-
ing assistant" ⁠.
4. Use the ⁠button to navigate to the next row.
5. Use the ⁠ or ⁠button to select the required category.
6. Use the ⁠button to navigate to the next row.
7. Use the ⁠ or ⁠button to select the required food.
8. Use the ⁠button to navigate to the next row.
aThe recommended settings will appear on the dis-
play.
9. Note:Additional information cannot be selected for
all foods.
Use the ⁠button to view additional information.
aAdditional information will appear, for example re-
garding which shelf position, accessories or cook-
ware you should use or when you should turn or stir
your food or add liquid.
10. Use the ⁠button to navigate back to the recommen-
ded settings.
11. Use the ⁠button to adjust the temperature or cook-
ing time, if required.
‒Use the ⁠ or ⁠button to select the temperature
or cooking time.
‒Use the ⁠ or ⁠button to change the setting.
12. Press ⁠ to start the baking and roasting assistant.
aSome food needs to be turned or stirred. An audible
signal will sound and a notification will appear on
the display to let you know when it is time to turn or
stir your food.
aOnce the duration has elapsed, an audible signal
will sound and the appliance will stop heating.
13. Note:Some programs allow you to extend the cook-
ing time.
→"Extending the cooking time", Page14
If you are happy with the cooking result, use the
⁠button to select "End".
9.3 Extending the cooking time
1. Use the ⁠button to select "Extend cooking time".
2. Use the ⁠ or ⁠button to change the settings, if re-
quired.
3. Press ⁠ to start the appliance again for the extra
cooking time.

Childproof lock en
15
10 Childproof lock
You can secure your appliance to prevent children
from accidentally switching it on or changing the set-
tings.
10.1 Locks
Your appliance has two different locks:
Lock Activate/deactivate
Automatic childproof lock Via the MyProfile menu ⁠
One-time childproof lock Using the ⁠button
10.2 Activating the automatic childproof
lock
The automatic childproof lock disables the control
panel to prevent children from accidentally switching
on the appliance. To switch on the appliance, interrupt
the automatic childproof lock. Once the appliance has
finished cooking, it automatically disables the control
panel.
Note:When you activate the automatic childproof lock,
the appliance will immediately disable the control
panel. The ⁠ and ⁠buttons will not be disabled.
Requirement:The appliance must be switched on.
1. Press ⁠.
2. Use the ⁠ or ⁠button to select "MyProfile" ⁠.
3. Use the ⁠button to navigate to the next row.
4. Use the ⁠ or ⁠button to select "Automatic childproof
lock".
5. Use the ⁠button to select the required settings.
6. Use the ⁠button to set the lock to "Activated".
7. Press ⁠.
8. Use the ⁠button to save your settings.
aWhen you switch off the appliance, ⁠ will appear
on the display.
10.3 Interrupting the automatic childproof
lock
1. Press and hold the ⁠button until "Childproof lock
deactivated" appears on the display.
2. Press ⁠ to switch the appliance on and then start it
up.
10.4 Deactivating the automatic childproof
lock
1. Press and hold the ⁠button until "Childproof lock
deactivated" appears on the display.
2. Press ⁠ to switch the appliance on.
3. Press ⁠.
4. Use the ⁠ or ⁠button to select "MyProfile" ⁠.
5. Use the ⁠button to navigate to the next row.
6. Use the ⁠ or ⁠button to select "Automatic childproof
lock".
7. Use the ⁠button to select the required settings.
8. Use the ⁠button to set the lock to "Deactivated".
9. Press ⁠.
10. Use the ⁠button to save your settings.
10.5 Activating the one-time childproof lock
The one-time childproof lock disables the control panel
to prevent children from accidentally switching on the
appliance. To switch on the appliance, deactivate the
one-time childproof lock. After you have switched off
the appliance, the control panel will no longer be dis-
abled.
Note:When you activate the automatic childproof lock,
the appliance will immediately disable the control
panel. The ⁠ and ⁠buttons will not be disabled.
▶Press and hold the ⁠button until "Childproof lock
activated" appears on the display.
10.6 Deactivating the one-time childproof
lock
▶Press and hold the ⁠button until "Childproof lock
deactivated" appears on the display.
11 Rapid heat-up
You can use the "Rapid heat-up" and "PowerBoost" functions to reduce the heat-up time. Whether the appliance is
preheated with the "Rapid heat-up" function or the "PowerBoost" function depends on the heating function that has
been set.
11.1 Rapid heat-up and PowerBoost
Function Heating function Food in the cooking compartment
Rapid heat-up Top/bottom heating ⁠ After preheating
PowerBoost ¡CircoTherm hot air ⁠
¡Bread-baking setting ⁠
Before heating up
Only cook on one level

en Sabbath mode
16
11.2 Activating the "Rapid heat-up" function
1. Set Top/bottom heating ⁠ and a temperature of at
least 100°C.
2. Press ⁠ to start.
aThe ⁠button will be lit.
3. Use the ⁠button to activate the "Rapid heat-up"
function.
a⁠ will appear on the display.
aOnce the set temperature has been reached, the
"Rapid heat-up" function will switch itself off auto-
matically and an audible signal will sound. ⁠ will go
out on the display.
4. Place the food in the cooking compartment.
11.3 Deactivating the "Rapid heat-up"
function
▶Use the ⁠button to deactivate the "Rapid heat-up"
function early.
11.4 Activating the "PowerBoost" function
1. Place the food on a single level in the cooking com-
partment.
2. Set CircoTherm hot air ⁠ or the Bread-baking
setting ⁠ and a temperature of at least 100°C.
3. Press ⁠ to start.
aThe ⁠button will be lit.
4. Press the ⁠button to activate the "PowerBoost"
function.
a⁠ will appear on the display.
aOnce the set temperature has been reached, the
"PowerBoost" function will switch itself off automatic-
ally and an audible signal will sound. ⁠ will go out
on the display.
11.5 Deactivating the "PowerBoost"
function
▶Use the ⁠button to deactivate the "PowerBoost"
function early.
12 Sabbath mode
You can set a cooking time of up to 74hours using
Sabbath mode. You can use top/bottom heating to
keep food warm between 85°C and 140°C during
this time without having to switch the appliance on or
off.
12.1 Starting Sabbath mode
Notes
¡If you open the appliance door during operation, the
appliance stops heating. When you close the appli-
ance door, the appliance continues to heat again.
¡Once you have started the operation, you cannot
change any settings or pause operation.
Requirement:Sabbath mode must be activated in "Fa-
vourites" in the basic settings.
→"Basic settings", Page16
1. Press ⁠ to switch the appliance on.
2. Use ⁠ or ⁠ to select "Sabbath mode".
3. Use ⁠ to navigate to the next row.
4. Use ⁠ or ⁠ to select the temperature.
5. Use ⁠ to navigate to the next row.
6. Use ⁠ or ⁠to select the cooking time.
7. Press ⁠ to start Sabbath mode.
aThe cooking time appears on the display. The cook-
ing time counts down.
8. Once the cooking time has elapsed, an audible sig-
nal sounds. A note appears on the display confirm-
ing that the operation has finished. The appliance
stops heating up and responds again as usual out-
side of Sabbath mode.
‒Press ⁠ to switch the appliance off.
The appliance automatically switches off after ap-
prox.10to 20 minutes.
12.2 Cancelling Sabbath mode
▶Press ⁠ to cancel Sabbath mode.
13 Basic settings
You can configure the appliance to meet your needs.
13.1 Overview of the basic settings
Here you can find an overview of the basic settings
and factory settings. The basic settings depend on the
features of your appliance.
Basic setting Selection
Language See selection on the appliance
Time 00:00 - 23:59
Date Day, month and year
1Depending on the appliance specifications
Basic setting Selection
Favourites
→"Changing your
favourites",
Page17
Set the heating functions that
you want to appear in the heat-
ing functions menu
Audible signal ¡Short duration
¡Medium duration
¡Long duration
Button tone ¡Off (except for ⁠)
¡On
Display brightness 5 settings
Clock display ¡Digital
¡Off
1Depending on the appliance specifications

HomeConnect en
17
Basic setting Selection
Lighting ¡On during operation
¡Off during operation
Childproof lock ¡Button lock only
¡Door lock and button lock
Automatic childproof
lock
¡Deactivated
¡Activated
Operation after
switch-on
¡Main menu
¡Types of heating
¡Baking and roasting assist-
ant
Night-time dimming ¡Switched off
¡On (display dimmed
between 10 p.m. and 5.59
a.m.)
Brand logo ¡Indicators/symbols
¡Do not display
Fan run-on time ¡Recommended
¡Minimum
Pull-out rail system1¡Not retrofitted (rack or
single set of pull-out rails)
¡Retrofitted (two or three sets
of pull-out rails)
Home Connect HomeConnect Settings
→"HomeConnect ", Page17
Factory settings Restore
1Depending on the appliance specifications
13.2 Changing MyProfile
1. Press ⁠ to switch the appliance on.
2. Press ⁠.
3. Use the ⁠ or ⁠button to select "MyProfile" ⁠.
4. Use the ⁠button to navigate to the next row.
5. Use the ⁠ or ⁠button to select a setting.
6. Use the ⁠button to navigate to the next row.
7. Use the ⁠ or ⁠button to change the setting.
8. Press ⁠.
9. To save your settings, use the ⁠button to select
"Save".
‒To discard your settings, use the ⁠button to se-
lect "Discard".
13.3 Changing your favourites
In Favourites, you can set the heating functions that
you want to appear in the heating functions menu.
Note:
Some heating functions cannot be deactivated:
¡CircoTherm hot air ⁠
¡Circo-roasting ⁠
¡Full-surface grill ⁠
1. Press ⁠ to switch the appliance on.
2. Press ⁠.
3. Use the ⁠ or ⁠button to select "MyProfile" ⁠.
4. Use the ⁠button to navigate to the next row.
5. Use the ⁠ or ⁠button to select "Favourites".
6. Use the ⁠button to select "Set favourites".
7. Use the ⁠ or ⁠button to select the required heating
function.
8. Use the ⁠button to navigate to the next row.
9. Use the ⁠ or ⁠button to select a setting.
Setting Display in the heating func-
tions menu?
Activated Yes
Deactivated No
10. Press ⁠.
11. To save your settings, use the ⁠button to select
"Save".
‒To discard your settings, use the ⁠button to se-
lect "Discard".
14 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings
and monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of HomeConnect services
in your country. You can find information about this at:
www.home-connect.com.
The HomeConnect app guides you through the entire
login process. Follow the instructions in the HomeCon-
nect app to configure the settings.
Tips
¡Please consult the documents supplied by
HomeConnect.
¡Please also follow the instructions in the HomeCon-
nect app.
Notes
¡Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeCon-
nect app.
→"Safety", Page2
¡Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
¡In networked standby mode, the appliance requires
a maximum of2W.
14.1 Setting up HomeConnect
Requirements
¡The appliance is connected to the power supply and
is switched on.
¡You have a mobile device with a current version of
the iOS or Android operating system, e.g. a smart-
phone.
¡The mobile device and the appliance are within
range of your home network's Wi-Fi signal.

en HomeConnect
18
1. Download the HomeConnect app.
2. Open the HomeConnect app and scan the follow-
ing QR code.
3. Follow the instructions in the HomeConnect app.
14.2 HomeConnect Settings
You can adjust the settings and network settings for HomeConnect by going to your appliance's basic settings.
Which settings the display shows will depend on whether HomeConnect has been set up and whether the appliance
is connected to your home network.
Basic setting Possible settings Explanation
Wi-Fi Switch on
Switch off
If Wi-Fi is activated, you can use HomeConnect.
In networked standby mode, the appliance requires a max-
imum of 2W.
Network Connect to network
Disconnect from network
If you disconnect the appliance from the network, all network
information will be deleted. This setting is useful if you have
new login details for the router.
Connect to app - This setting initiates the connection between the HomeCon-
nectapp and the appliance.
Remote control On
Off
When this function is deactivated, all you can do is view the
appliance's operating status in the app.
When this function is activated, you can remotely start and
control the appliance.
Appliance information
⁠
- The display shows information about the network or the appli-
ance.
14.3 Operating the appliance with the
HomeConnect app
When the Remote start function is activated, you can
use the HomeConnectapp to remotely configure the
appliance's settings and start it.
Note:Some operating modes can only be started on
the oven itself.
Requirements
¡The appliance must be switched on.
¡The appliance must be connected to your home net-
work and to the HomeConnectapp.
¡To configure the appliance's settings using the
HomeConnectapp, "Remote control" must be
switched on in the basic settings. When the Remote
start function is deactivated, only the appliance's op-
erating statuses are displayed in the HomeCon-
nectapp.
1. Press ⁠ to switch the appliance on.
2. Tap ⁠.
aThe display will show the main menu.
3. Use the ⁠ or ⁠button to select "Remote start" ⁠.
4. To switch on the Remote start function, tap ⁠.
aThe display will show ⁠.
5. Configure a setting in the HomeConnectapp and
send it to the appliance.
Notes
¡If you open the appliance door within 15minutes
of activating the Remote start function or of the
set program ending, the Remote start function
will be deactivated.
¡When you start the oven using the controls on
the appliance itself, the Remote start function is
activated automatically. You can use the
HomeConnectapp to adjust the settings or start
a new program.
14.4 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of op-
timisation, troubleshooting or security updates.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
WLAN home network (Wi-Fi). The HomeConnectapp
will inform you once installation is successful.

Cleaning and servicing en
19
Notes
¡You can continue to use your appliance as normal
while updates are downloading. Depending on your
personal settings in the app, software updates can
also be set to download automatically.
¡We recommend that you install security updates as
soon as possible.
¡Installation takes a few minutes. You cannot use
your appliance during installation.
14.5 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip:For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com
14.6 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the
HomeConnect server (initial registration):
¡Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the Wi-Fi
communication module installed).
¡Security certificate of the Wi-Fi communication mod-
ule (to ensure a secure data connection).
¡The current software and hardware version of your
appliance.
¡Status of any previous reset to factory settings.
This initial registration prepares the HomeConnect
functions for use and is only required when you want to
use the HomeConnect functions for the first time.
Note:Please note that the HomeConnect functions
can only be utilised with the HomeConnect app. In-
formation on data protection can be retrieved in the
HomeConnect app.
15 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
15.1 Cleaning products
In order to avoid damaging the various oven surfaces
on the appliance, do not use unsuitable cleaning
products.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶Do not use steam- or high-pressure cleaners to
clean the appliance.
ATTENTION!
Unsuitable cleaning products may damage the sur-
faces of the appliance.
▶Do not use harsh or abrasive cleaning products.
▶Do not use cleaning products with a high alcohol
content.
▶Do not use hard scouring pads or cleaning
sponges.
▶Do not use any special cleaners for cleaning the ap-
pliance while it is hot.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶Never use oven cleaner in the cooking compartment
when it is still warm.
▶Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
New sponge cloths contain residues from production.
▶Wash new sponge cloths thoroughly before use.
Suitable cleaning agents
Only use cleaning agents that are suitable for the differ-
ent surfaces on your appliance.
Follow the instructions on cleaning the appliance.
→"Cleaning the appliance", Page20
Appliance front
Surface Suitable cleaning agents Information
Stainless steel ¡Hot soapy water
¡Special stainless steel
cleaning products
suitable for hot sur-
faces
To prevent corrosion, remove any limescale, grease, starch or albu-
min (e.g. egg white) stains on stainless steel fronts immediately.
Apply a thin layer of the stainless steel cleaning product with a soft
cloth.
Plastic or painted
surfaces
E.g. control panel
¡Hot soapy water Do not use glass cleaner or a glass scraper.
To avoid permanent stains, remove any descaling agent that gets
onto the surface immediately.

en Cleaning and servicing
20
Appliance door
Area Suitable cleaning agents Information
Door panels ¡Hot soapy water Do not use a glass scraper or a stainless steel wool.
Tip:Remove the door panels in order to clean them thoroughly.
→"Appliance door", Page23
Door cover ¡Made of stainless
steel:
Stainless steel cleaner
¡Made of plastic:
Hot soapy water
Do not use glass cleaner or a glass scraper.
Do not use stainless steel care products.
Tip:Remove the door cover for thorough cleaning.
→"Appliance door", Page23
Stainless steel in-
terior door frame
Stainless steel cleaner Discolouration can be removed using stainless steel cleaner.
Do not use stainless steel care products.
Door handle ¡Hot soapy water To avoid permanent stains, remove any descaling agent that gets
onto the surface immediately.
Door seal ¡Hot soapy water Do not remove or scrub.
Cooking compartment
Area Suitable cleaning agents Information
Enamel surfaces ¡Hot soapy water
¡Vinegar water
¡Oven cleaner
Soak any heavily soiled areas and use a brush or steel wool.
Leave the appliance door open to dry the cooking compartment
after cleaning it.
Notes
¡It is best to use the cleaning function.
→"Self-cleaning function", Page21
¡Enamel burns at very high temperatures, causing minor discol-
ouration. The functionality of your appliance is not affected by
this.
¡The edges of thin trays cannot be completely enamelled and may
be rough. This does not impair corrosion protection.
¡Food residues will leave a white coating on the enamel surfaces.
The coating does not pose a health risk. The functionality of your
appliance is not affected by this. You can remove residues with
lemon juice.
Glass cover for
the oven light
¡Hot soapy water Use oven cleaner to remove very heavy soiling.
Rails ¡Hot soapy water Soak any heavily soiled areas and use a brush or steel wool.
Note:To clean thoroughly, detach the rails.
→"Rails", Page22
Accessories ¡Hot soapy water
¡Oven cleaner
Soak any heavily soiled areas and use a brush or steel wool.
Enamelled accessories are dishwasher-safe.
15.2 Cleaning the appliance
In order to avoid damaging the appliance, you must
clean your appliance only as specified, and with suit-
able cleaning products.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
▶Caution should be exercised here in order to avoid
touching heating elements.
▶Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices may catch
fire.
▶Before using the appliance, remove the worst of the
food residues and remnants from the cooking com-
partment, heating elements and accessories.
Requirement:Read the information on cleaning
products.
→"Cleaning products", Page19
1. Clean the appliance using hot soapy water and a
dish cloth.
‒For some surfaces, you can use alternative
cleaning agents.
→"Suitable cleaning agents", Page19
2. Dry with a soft cloth.
