NEFF C17MS22.0 User manual

[en] INSTRUCTION MANUAL
BUILT-IN OVEN
C17MS22.0

en
3
Table of contents
[en]INSTRUCTI ONMANUAL
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 5
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 8
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7Environmental protection . . . . . . . . . . . . . . . . . . 9
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 9
*Getting to know your appliance . . . . . . . . . . . . 10
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Menu for the types of heating . . . . . . . . . . . . . . . . . . 11
Cooking compartment functions . . . . . . . . . . . . . . . . 12
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 12
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 13
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 13
KBefore using for the first time. . . . . . . . . . . . . . 14
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning the cooking compartment . . . . . . . . . . . . . . 14
Cleaning the accessories. . . . . . . . . . . . . . . . . . . . . . 14
1Operating the appliance . . . . . . . . . . . . . . . . . . 15
Switching the appliance on and off . . . . . . . . . . . . . . 15
Setting and starting the appliance operation . . . . . . . 15
Changing or cancelling the appliance operation . . . . 16
Heating up the appliance quickly . . . . . . . . . . . . . . . . 16
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 16
Showing and hiding the time-setting options . . . . . . . 16
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 17
Start delay – "Ready at" . . . . . . . . . . . . . . . . . . . . . . . 17
Checking, changing or deleting settings . . . . . . . . . . 17
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 17
Automatic childproof lock . . . . . . . . . . . . . . . . . . . . . 17
One-time childproof lock . . . . . . . . . . . . . . . . . . . . . . 18
^Microwave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cookware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Microwave power settings . . . . . . . . . . . . . . . . . . . . . 19
Setting the microwave . . . . . . . . . . . . . . . . . . . . . . . . 19
Setting the microwave to combi-mode . . . . . . . . . . . . 20
QBasic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Changing MyProfile . . . . . . . . . . . . . . . . . . . . . . . . . .21
List of basic settings. . . . . . . . . . . . . . . . . . . . . . . . . .21
Setting favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
FSabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Starting Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . .22
Cancelling Sabbath mode . . . . . . . . . . . . . . . . . . . . .22
DCleaning agent . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .22
Surfaces in the cooking compartment . . . . . . . . . . . .23
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .24
.Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 24
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Finishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Subsequent cleaning . . . . . . . . . . . . . . . . . . . . . . . . .25
Removing heavy deposits of dirt . . . . . . . . . . . . . . . .25
pRails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Detaching and refitting the rails . . . . . . . . . . . . . . . . .25
qAppliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Removing the door cover . . . . . . . . . . . . . . . . . . . . . .26
Removing and fitting the door panels. . . . . . . . . . . . .27
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 28
Fault table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Maximum operating time exceeded . . . . . . . . . . . . . .28
Cooking compartment bulbs . . . . . . . . . . . . . . . . . . .28
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 29
E number and FD number . . . . . . . . . . . . . . . . . . . . .29
nBaking and roasting assistant . . . . . . . . . . . . . 29
Information on the settings . . . . . . . . . . . . . . . . . . . . .29
Selecting a meal. . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Setting the food . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
PProgrammes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Information on the settings . . . . . . . . . . . . . . . . . . . . .30
Selecting a dish . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Setting the programme. . . . . . . . . . . . . . . . . . . . . . . .31

en Intended use
4
JTested for you in our cooking studio. . . . . . . . 31
Silicone moulds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cakes and small baked items . . . . . . . . . . . . . . . . . . 31
Bread and rolls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Pizza, quiche and savoury cakes . . . . . . . . . . . . . . . . 37
Bakes and soufflés. . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Poultry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Meat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Fish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . . 46
Dessert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Eco heating functions. . . . . . . . . . . . . . . . . . . . . . . . . 49
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .51
Slow cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Drying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Allowing the dough to prove at dough proving setting. .
54
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Heating food in a microwave . . . . . . . . . . . . . . . . . . .56
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Test dishes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.neff-international.com and in the online shop
www.neff-eshop.com
8Intended use
Intended us e Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 12

Important safety information en
5
(Important safety
information
Impor t ant safety informat i on General information
:Warning – Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
hot cooking compartment.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.

en Important safety information
6
Microwave
:Warning – Risk of fire!
■Using the appliance for anything other than
its intended purpose is dangerous and may
cause damage.
The following is not permitted: drying out
food or clothing, heating slippers, grain or
cereal pillows, sponges, damp cleaning
cloths or similar.
For example, heated slippers and grain or
cereal pillows may catch fire, even several
hours after they have been heated.The
appliance must only be used for the
preparation of food and drinks.
Risk of fire!
■Food may catch fire. Never heat food in
heat-retaining packages.
Do not leave food heating unattended in
containers made of plastic, paper or other
combustible materials.
Do not select a microwave power or time
setting that is higher than necessary. Follow
the information provided in this instruction
manual.
Never use the microwave to dry food.
Never defrost or heat food with a low water
content, e.g. bread, at too high a microwave
power or for too long.
Risk of fire!
■Cooking oil may catch fire. Never use the
microwave to heat cooking oil on its own.
:Warning – Risk of explosion!
Liquids and other food may explode when in
containers that have been tightly sealed.
Never heat liquids or other food in containers
that have been tightly sealed.
:Warning – Risk of burns!
■Foods with peel or skin may burst or
explode during, or even after, heating.
Never cook eggs in their shells or reheat
hard-boiled eggs. Never cook shellfish or
crustaceans. Always prick the yolk when
baking or poaching eggs. The skin of foods
that have a peel or skin, such as apples,
tomatoes, potatoes and sausages, may
burst. Before heating, prick the peel or skin.
Risk of burns!
■Heat is not distributed evenly through baby
food. Never heat baby food in closed
containers. Always remove the lid or teat.
Stir or shake well after the food has been
heated. Check the temperature of the food
before it is given to the child.
Risk of burns!
■Heated food gives off heat. The ovenware
may become hot. Always use oven gloves
to remove ovenware or accessories from
the cooking compartment.
Risk of burns!
■Airtight packaging may burst when food is
heated. Always observe the instructions on
the packaging. Always use oven gloves to
remove dishes from the cooking
compartment.
Risk of burns!
■The accessible parts become very hot when
in operation. Never touch hot parts. Keep
children at a safe distance.
Risk of burns!
■At the highest settings in microwave only
mode, the drying function will automatically
switch on an additional heating element to
heat the cooking compartment. Never touch
the inside surfaces of the cooking
compartment or the heating elements while
they are hot. Keep children at a safe
distance.
Risk of burns!
■Using the appliance for anything other than
its intended purpose is dangerous.
You are not permitted to use it to dry food
or clothing or to warm slippers, grain or
cereal pillows, sponges, damp cleaning
cloths or the like.
This is because, for instance, overheated
slippers, grain or cereal pillows, sponges
and damp cleaning cloths, etc., may cause
burns to the skin.

Important safety information en
7
:Warning – Risk of scalding!
■There is a possibility of delayed boiling
when a liquid is heated. This means that the
liquid reaches boiling temperature without
the usual steam bubbles rising to the
surface. Even if the container only vibrates a
little, the hot liquid may suddenly boil over
and spatter. When heating, always place a
spoon in the container. This will prevent
delayed boiling.
:Warning – Risk of injury!
■Unsuitable ovenware may crack. Porcelain
or ceramic ovenware can have small
perforations in the handles or lids. These
perforations conceal a cavity below. Any
moisture that penetrates this cavity could
cause the ovenware to crack. Only use
microwave-safe ovenware.
Risk of injury!
■If using the appliance in microwave mode
only, placing cookware and containers
made of metal or featuring metal detailing
inside the appliance may cause sparks
when the appliance is operating. This may
damage the appliance. Never use metal
containers when using the appliance in
microwave mode only.
:Warning – Risk of electric shock!
The appliance is a high-voltage appliance.
Never remove the casing.
:Warning – Risk of serious damage to
health!
■The surface of the appliance may become
damaged if it is not cleaned properly.
Microwave energy may escape. Clean the
appliance on a regular basis, and remove
any food residue immediately. Always keep
the cooking compartment, door seal, door
and door stop clean.
Risk of serious damage to health!
■Microwave energy may escape if the
cooking compartment door or the door seal
is damaged. Never use the appliance if the
cooking compartment door, the door seal
or the plastic door frame is damaged. Call
the after-sales service.
Risk of serious damage to health!
■Microwave energy will escape from
appliances that do not have any casing.
Never remove the casing. For any
maintenance or repair work, contact the
after-sales service.

en Causes of damage
8
]Causes of damage
Ca u s e s of damage General information
Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean.
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
Microwave
Caution!
■Creation of sparks: Metal – e.g. a spoon in a glass –
must be kept at least 2 cm from the cooking
compartment walls and the inside of the door.
Sparks can irreparably damage the glass on the
inside of the door.
■Combining accessories: Do not combine the wire
rack with the universal pan. Sparks may be created if
they are inserted directly on top of one another. Only
insert them into their own shelf level.
■Microwave only: The universal pan and baking tray
are unsuitable when using the microwave only. If you
use either of these, this may create sparks, which
may damage the cooking compartment. Place
cookware on the wire rack provided, or place it in
the microwave and set a type of heating.
■Foil containers: Do not use foil containers in the
appliance. They damage the appliance by producing
sparks.
■Operating the microwave without food: Operating the
appliance without food in the cooking compartment
may lead to overloading. Never switch on the
microwave unless there is food inside. The short
crockery test is the exception to this rule.
~"Microwave" on page 18
■Microwave popcorn: Never set the microwave output
too high. Use a maximum microwave output of 600
watts. Always place the popcorn bag on a glass
plate. The door panels may jump if overloaded.

Environmental protection en
9
7Environmental protection
En v i r o n ment al pr ot ect i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the
cooking compartment.
■Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■Remove any unnecessary accessories from the
cooking compartment.
■Open the appliance door as infrequently as possible
when the appliance is in use.
■It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

en Getting to know your appliance
10
*Getting to know your
appliance
Get t i ng to know your appl i ance In this chapter, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
In the control panel, set the appliance's different
functions. The current settings are shown on the
display.
Controls
Use the controls to set your appliance simply and
directly.
Touch buttons
There are sensors under the touch buttons. Touch on
the corresponding touch button to select a function.
--------
ShiftControl control
Use the ShiftControl control element to navigate
through the lines on the display and select the settings.
Settings that you can change have left and right
arrows '.
Note: You can also scroll through the settings values
quickly by pressing and holding a button. As soon as
you release the button, you stop scrolling through the
values quickly.
Main menu
Touch the 0touch button to access the main menu.
+RWDLU 



 
©
&

(Display
0Touch buttons
8ShiftControl control
Touch button Use
#on/off Switching the appliance on or
off~"Switching the appliance on
and off" on page 15
0Main menu Selecting operating modes and set-
tings ~"Setting and starting the
appliance operation" on page 15
3Time-setting options Setting the timer, cooking time, or
"Ready at" start delay ~"Time-
setting options" on page 16
Childproof lock Activating or deactivating the child-
proof lock ~"Childproof lock"
on page 17
!Information Displaying further information
Displaying the current temperature
~"Setting and starting the
appliance operation" on page 15
°Rapid heating Activating or deactivating the "Rapid
heating" function ~"Heating up the
appliance quickly" on page 16
#Start/Stop Starting or stopping the operation
~"Setting and starting the
appliance operation" on page 15
Button Use
(Left Navigates to the left on the display
)Right Navigates to the right on the display
%Up Navigates upwards on the display
&Down Navigates downwards on the display
Menu Use
¢Types of heating
Selecting the required type of heating and tempera-
ture for your dish ~"Switching the appliance on and
off" on page 15
•Microwave
You can use the microwave to cook, heat up or
defrost your dishes more quickly.~"Microwave"
on page 18
¡Microwave combination
You can also use this to switch on a type of heating on
the microwave.~"Microwave" on page 18

Getting to know your appliance en
11
--------
Menu for the types of heating
Your appliance has different types of heating. After
switching on the appliance, you are taken directly to the
menu for the types of heating.
--------
£Baking and roasting assistant
Recommended settings for baking and roasting
~"Baking and roasting assistant" on page 29
±Microwave programmes
You can use these to prepare food using the
microwave.~"Programmes" on page 30
4MyProfile
Individually adjusting the appliance settings
~"Basic settings" on page 21
ªDry
Use after every operation with EasyClean or the micro-
wave
šEasyClean
Cleaning light soiling from the cooking compartment
~"Cleaning function" on page 24
Type of heating Temperature Use
‚Hot air 30 - 275 °C For baking and cooking on one or more levels.
The fan distributes the heat from the ring heating element in the back panel
evenly around the cooking compartment.
ƒTop/bottom heating 50 - 275 °C For traditional baking and roasting on one level. Especially suitable for cakes with
moist toppings.
Heat is emitted evenly from the top and bottom.
‡Circo-roasting 50 - 250 °C For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the
hot air around the food.
„Circotherm intensive 50 - 275 °C For preparing pizza and dishes which require a lot of heat from underneath.
The bottom heating element and the ring heating element in the back panel heat
up.
ˆFull-surface grill 50 - 290 °C For grilling flat items, such as steaks or sausages, for making toast, and for au gra-
tin dishes.
The whole area below the grill element becomes hot.
‰Centre-area grill 50 - 290 °C For grilling small amounts of steaks or sausages, for making toast, and for au gra-
tin dishes.
The centre area under the grill heating element becomes hot.
†Bottom heat 50 - 250 °C For cooking in a bain marie and for the final baking stage.
The heat is emitted from below.
ŠLow temperature cooking 70 - 120 °C For gentle and slow cooking of seared, tender pieces of meat in ovenware without
a lid.
The heat is emitted evenly from the top and bottom at low temperatures.
ŒDough proving 35 - 55 °C For leaving yeast dough and sourdough to prove and for culturing yogurt.
Dough will prove more quickly than at room temperature. The surface of the
dough does not dry out.
¯Plate warming 30-70 °C For preheating ovenware.
‘Top/bottom heating eco 50-275 °C For gently cooking selected types of food.
Heat is emitted from above and below.
This heating function is most effective between 150 and 250 °C.
This heating function is used to measure the energy consumption in the conven-
tional mode.
žHot air eco 30-275 °C For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back
panel around the cooking compartment.
This heating function is most effective between 125 and 275 °C.
This heating function is used to measure both the energy consumption in air recir-
culation mode and the energy efficiency class.

en Accessories
12
Cooking compartment functions
The functions in the cooking compartment make your
appliance easier to use. This, for example, enables the
cooking compartment to be well lit and a cooling fan to
prevent the appliance from overheating.
Opening the appliance door
If you open the appliance door during an operation, the
operation is paused. The operation continues to run
when you close the door.
Interior lighting
If you open the appliance door, the interior lighting
switches on. If the door remains open for longer than
around 15 minutes, the lighting switches off again.
For most operating modes, the interior lighting switches
on as soon as the operation is started. When the
operation has finished, the lighting switches off.
Note: You can set the interior lighting not to come on
during the operation in the basic settings. ~"Basic
settings" on page 21
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after the operation, the cooling fan continues to
run for a certain period afterwards.
Note: You can change how long the cooling fan
continues to run for in the basic settings. ~"Basic
settings" on page 21
_Accessories
Ac c e s s o r i e s Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use original accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may deform when they become
hot. This does not affect their function. Once they have
cooled down again, they regain their original shape.
Microwave
Only the wire rack provided is suitable when using the
microwave only. If you use the universal pan or the
baking tray, this may create sparks, which may damage
the cooking compartment.
When using the appliance in combination with the
microwave or "Dishes" mode, you can use the universal
pan, baking tray or any other accessories that have
been included with the appliance.
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
The wire rack is suitable for use in the
microwave.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.

Accessories en
13
Inserting accessories
The cooking compartment has three shelf positions.
The shelf positions are counted from the bottom up.
When using positions 1, 2 and 3, always insert the
accessory between the two guide rods for a shelf
position.
Notes
■Ensure that you always insert the accessories into
the cooking compartment the right way round.
■Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
Locking function
The accessories can be pulled out approximately
halfway until they lock in place. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to
work properly.
When inserting the wire rack, ensure that the catch
tappet ‚is at the rear and is facing downwards. The
lettering "microwave" must be at the front and the outer
rail must face downwards ¾.
When inserting baking trays, ensure that the catch
tappet ‚is at the rear and is facing downwards. The
sloping edge of the accessory ƒmust be facing
forwards towards the appliance door.
Example in the picture: Universal pan
Optional accessories
You can purchase optional accessories from the after-
sales service and specialist retailers, or on the Internet.
You will find a comprehensive range of products for
your appliance in our brochures and on the Internet.
Both availability and whether it is possible to order
online differ between countries. Please see your sales
documents for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, please always quote the
exact designation (E no.) of your appliance.
~"Customer service" on page 29
--------



D
D
D
E
D
Accessories
Baking and roasting shelf
Baking tray
Universal pan
Baking tray, non-stick
Universal pan, non-stick
Extra-deep pan
Profi pan
Lid for the Profi pan
Pizza tray
Grill tray
Ceramic brick
Glass roasting dish, 5.1 litres
Glass pan
Steaming set for ovens
Decorative strip

en Before using for the first time
14
KBefore using for the first
time
Be f o r e us i ng for the first ti me Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
As soon as the appliance is connected to the power
supply, the first setting "Language" appears on the
display.
Setting the language
1. Use the &button to navigate to the bottom line.
2. Use the (or )button to select the language.
3. Use the %button to return to "Language".
4. Use the )button to select the next setting.
Setting the time
1. Use the &button to navigate to the bottom line.
2. Use the (or )button to select the current hour.
3. Use the &button to navigate to the next line.
4. Use the (or )button to select the current minute.
5. Press the %button repeatedly until "Time" appears.
6. Use the )button to select the next setting.
Setting the date
1. Use the &button to navigate to the bottom line.
2. Use the (or )button to select the current day.
3. Use the &button to navigate to the next line.
4. Use the (or )button to select the current month.
5. Use the &button to navigate to the next line.
6. Use the (or )button to select the current year.
7. Press the %button repeatedly until "Date" appears.
8. Use the )button to apply the settings.
The initial use is complete.
Notes
■You can change these settings at any time in the
basic settings. ~"Basic settings" on page 21
■After connecting the appliance to the power or
following a power cut, the settings for initial use are
shown in the display.
Cleaning the cooking compartment
To eliminate the new-appliance smell, heat up the
cooking compartment without anything in it and with the
oven door closed.
1. Remove the accessories from the cooking
compartment.
2. Remove any leftover packaging, such as polystyrene
pellets, from the cooking compartment.
3. Before heating the appliance, wipe the smooth
surfaces in the cooking compartment with a soft,
damp cloth.
4. Use the # touch button to switch on the appliance.
5. Set the specified type of heating and temperature,
then start the appliance. ~"Setting and starting the
appliance operation" on page 15
6. Keep the kitchen ventilated while the appliance is
heating.
7. Use the # touch button to switch off the appliance
once the specified time has elapsed.
8. Wait for the cooking compartment to cool down.
9. Clean the smooth surfaces with soapy water and a
dish cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
Settings
Type of heating CircoTherm ‚
Temperature Maximum
Cooking time 1 hour

Operating the appliance en
15
1Operating the appliance
Oper at i ng the appl i anc e You have already learnt about the controls and how
they work. Now we will explain how to set your
appliance. You will learn about what happens when you
switch the appliance on and off, and how to select the
operating mode.
Switching the appliance on and off
To switch the appliance on or off, touch the #touch
button.
After the appliance has switched off, the display shows
whether the residual heat in the cooking compartment
is high or low.
Notes
■Certain indicators and instructions (e.g. about
residual heat in the cooking compartment) remain
visible on the display even when the appliance is
switched off.
■After the appliance has completed an operation, you
will hear the cooling fan continuing to run until the
cooking compartment is cooled as much as
possible.
■Switch off your appliance when you do not need to
use it. If no settings are made for a long time, the
appliance switches off automatically.
Setting and starting the appliance operation
Example: ‚"Hot air" at 170 °C
1. Touch the #touch button to switch on the
appliance.
You are taken directly to the ¢"Types of heating"
menu.
2. Use the (or )button to select the type of heating.
3. Use the & button to navigate to the next line.
4. Use the (or )button to select the temperature.
Note: Additional settings are available depending on
the operating mode. For each further setting, use the
&button to navigate to the next line. Use the ( or )
button to select the setting.
5. Touch the #touch button to start the appliance
operation.
The heating bar and run time appear on the display.
Note: If you would like to go directly to the 0main
menu after switching on the appliance, you can select
the main menu under "Operation after switching on" in
the basic settings chapter.
Default values
The appliance suggests a temperature or setting for
each type of heating. You can accept this value or
change it in the appropriate area.
Heating bar
As soon as a type of heating has started, the heating
bar appears on the display.The heating bar shows the
temperature increase in the cooking compartment.
Run time
When a type of heating has been started, the run time is
displayed. The run time counts upwards during the
operation. You can therefore check how long the
operation has already been running.
Displaying the current temperature
To show the current temperature on the display, press
the !touch button.
The current temperature is shown briefly only when
heating up.
Further information
If the !touch button lights up, information can be
displayed. Touch the !touch button to do this. The
information is displayed for a few seconds.
Display Temperature
Residual heat high above 120 °C
Residual heat low between 60 °C und 120 °C
+RWDLU

©
&
+RWDLU 
&

en Time-setting options
16
Changing or cancelling the appliance
operation
Changing the appliance operation
1. Use the #button to stop the operation.
2. Use the &or %button to navigate to the line for the
setting that should be changed.
3. Use the (or )button to change the setting.
4. Use the #touch button to start the changed
operation.
Notes
■The cooling fan may continue to run while an
operation is interrupted.
■After a temperature change, the paused running time
continues to count. After a change in the type of
heating, the running time starts again from zero.
Cancelling the appliance operation
Press and hold the #touch button until the appliance
operation is cancelled.
Note: Operating modes such as the cleaning function
cannot be cancelled.
Heating up the appliance quickly
You can reduce the heating time using the Rapid
heating function.
Notes
■When the °touch button lights up, rapid heating
can be activated.
■Touch the °touch button to deactivate the Rapid
heating function early.
Activating the "Rapid heating" function
1. Set ‚Hot air and the temperature.
Note: Set a temperature above 100 °C to allow the
appliance to preheat quickly.
2. Touch the #touch button to start the appliance
operation.
3. Touch the °touch button to activate the "Rapid
heating" function.
The °symbol appears on the display.
4. Once the set temperature has been reached, the
"Rapid heating" function switches off automatically.
The °symbol disappears from the display. Place
the food in the cooking compartment.
OTime-setting options
Ti me- s et t i ng opt i ons Your appliance has different time-setting options.
Note: If you have set a time-setting option, the time
interval increases if you set a higher value. Example:
You can set a cooking time of up to one hour in one-
minute increments; for cooking times over one hour,
you can set a cooking time in five-minute increments.
Showing and hiding the time-setting options
To show or hide the time-setting options, touch the
0touch button.
Note: After a particular length of time, the time-setting
options that are shown are automatically hidden. If you
have already set a cooking time, it will be applied.
Setting the timer
The timer can be set when the appliance is switched on
or off.
1. Touch the 0touch button.
The time-setting options are shown on the display.
2. Select the cooking time using the )button.
Note: When the appliance is switched on, use the %
button to navigate to the Timer .line and then
select the cooking time using the )button.
3. Touch the 0touch button to start the timer.
The .symbol appears on the display.The timer
counts down.
Note: As soon as the set time has elapsed, a signal
sounds. To cancel the signal tone, touch the 0touch
button.
Function Type of heating Place the food in
the cooking
compartment
Rapid heating Hot air ‚After heating
Top/bottom heating ƒ
Time-setting option Use
.Timer The timer functions like an egg timer. The
appliance does not switch on and off auto-
matically.
+Cooking time Once the set cooking time has elapsed,
the appliance switches off automatically.
*Ready at The appliance switches on automatically,
and once the set cooking time has
elapsed and the end time has passed, it
switches off automatically.
PLQ_V
K_PLQ



7LPHU
'XUDWLRQ
5HDG\DW

Childproof lock en
17
Setting the cooking time
Once the set cooking time has elapsed, the appliance
switches off automatically. The function can only be
used in combination with a type of heating.
1. Touch the #touch button.
2. Set the type of heating and temperature.
3. Touch the 0touch button.
The time-setting options are shown in the display.
4. Use the (or )button to set the cooking time.
– Default value for the (button = 10 minutes
– Default value for the )button = 30 minutes
5. Touch the #touch button to start the set cooking
time.
As soon as the cooking time has elapsed, an audible
signal sounds and the appliance ends the operation
automatically. Touch the 0touch button to end the
audible signal.
Start delay – "Ready at"
The appliance switches on automatically and switches
off at the preset end time.To do this, set the cooking
time and determine the end time for the operation.
The start delay can only be used in combination with a
type of heating.
Notes
■Ensure that food is not left in the cooking
compartment for too long as it may spoil.
■It is not possible to start every type of heating with a
start delay.
1. Slide food into the cooking compartment on a
suitable accessory and close the appliance door.
2. Touch the #touch button.
3. Set the type of heating and temperature.
4. Touch the 0touch button.
The time-setting options are shown on the display.
5. Select the cooking time using the )button.
6. Use the &button to navigate to the "*Ready at"
line.
7. Select the end time using the )button.
8. Touch the #touch button.
The appliance waits until the appropriate time to start
the operation.
As soon as the end time has passed, a signal sounds
and the appliance stops the operation automatically. To
cancel the signal tone, touch the 0touch button.
Checking, changing or deleting settings
1. Touch the 0touch button.
The time-setting options are shown on the display.
2. Use the &or %button to navigate through the
lines.
3. If necessary, change the setting using the (or )
button. Set "00:00" to delete a time function.
The setting is applied automatically.
AChildproof lock
Ch i l d p r o o f lock Your appliance is equipped with a childproof lock so
that children cannot switch it on accidentally or change
any settings.
Your appliance has two different locks.
Note: As soon as you activate the childproof lock, the
control panel is locked. The 0and #touch buttons
are not included.You can deactivate the childproof lock
at any time.
Automatic childproof lock
The control panel is locked so that the appliance cannot
be switched on. To switch it on, the automatic
childproof lock must be interrupted. After the appliance
operation, the control panel is locked automatically.
Activating
1. Touch the ±touch button.
2. Touch the 0touch button.
3. Use the ( or )button to select "MyProfile".
4. Use the &button to navigate to the next line.
5. Use the ( or )button to select "Automatic childproof
lock".
6. Use the &button to navigate to the bottom line.
7. Use the )button to select "Activated".
8. Touch the 0touch button.
9. Use the &button to navigate to the next line to save
the setting.
The "Automatic childproof lock" is activated. The
1symbol appears on the display after switching off
the appliance.
Cancelling
1. Press and hold the 0touch button until "Childproof
lock deactivated" appears on the display.
2. Touch the ±touch button.
3. Switch on the required appliance operation.
Deactivating
1. Press and hold the 0touch button until "Childproof
lock deactivated" appears on the display.
2. Touch the ±touch button.
3. Touch the 0touch button.
4. Use the ( or )button to select "MyProfile".
5. Use the &button to navigate to the next line.
6. Use the ( or )button to select "Automatic childproof
lock".
7. Use the &button to navigate to the bottom line.
8. Use the (button to select "Deactivated".
9. Touch the 0touch button.
10. Use the &button to navigate to the next line to save
the setting.
The "Automatic childproof lock" is deactivated.
11. Touch the ±touch button.
Lock Activate/deactivate
Automatic childproof lock Via the MyProfile menu ~"Basic
settings" on page 21
One-time childproof lock Via the 0 touch button

en Microwave
18
One-time childproof lock
The control panel is locked so that the appliance cannot
be switched on. To switch it on, the one-time childproof
lock must be deactivated. After the appliance is
switched off, the control panel is no longer locked.
Activating and deactivating
1. Press and hold the 0touch button until "Childproof
lock activated" appears on the display.
The childproof lock is activated.
2. Press and hold the 0touch button until "Childproof
lock deactivated" appears on the display.
The childproof lock is deactivated.
^Microwave
Microwave You can use the microwave to cook, heat up or defrost
food quickly. The microwave can be used on its own, or
in combination with a type of heating.
To ensure optimum use of the microwave, please
observe the notes on cookware and familiarise yourself
with the data in the application tables at the end of the
instruction manual.
Cookware
Not all cookware is suitable for microwaves. To ensure
that your food is heated and the appliance is not
damaged, only use cookware that is suitable for
microwaves.
Heat-resistant cookware made of glass, glass ceramic,
porcelain or heat-resistant plastic is suitable. These
materials allow microwaves to pass through. You can
also use ceramic if it has been fully glazed and has no
cracks.
You can also use serving dishes. This saves you having
to transfer food from one dish to another. You should
only use cookware with decorative gold or silver trim if
the manufacturer guarantees that they are suitable for
use in microwaves.
To bake in combined operation, you can use ordinary
metal baking tins. This means that the cake is also
browned from below.
Metal dishes are not suitable for other applications.
Metal does not allow microwaves to pass through. Food
in covered metal containers will remain cold.
Caution!
Creation of sparks: Metal (e.g. a spoon in a glass) must
be kept at least 2 cm from the cooking compartment
walls and the inside of the door. Sparks may irreparably
damage the glass on the inside of the door.
Cookware test
Never switch on the microwave unless there is food
inside. The short cookware test is the only exception to
this rule.
Perform the following test if you are unsure whether
your cookware is suitable for use in the microwave.
1. Heat the empty cookware at maximum power for ½
to 1 minute.
2. Check the temperature of the cookware during this
time.
The cookware should remain cold or warm to the touch.
The cookware is unsuitable if it becomes hot or sparks
are generated.
In this case, stop the test.
:Warning – Risk of burns!
The accessible parts become very hot when in
operation. Never touch hot parts. Keep children at a
safe distance.

Microwave en
19
Accessories included
Only the wire rack provided is suitable when using the
microwave only. If you use the universal pan or the
baking tray, this may create sparks, which may damage
the cooking compartment.
When using the appliance in combination with the
microwave or "Dishes" mode, you can use the universal
pan, baking tray or any other accessories that have
been included with the appliance.
When using the microwave, it is best to insert
accessories at level 1, unless otherwise specified.
Microwave power settings
A variety of microwave power settings that are suitable
for different types of food and food preparation are
available.
A cooking time must always be set to operate the
microwave. You can either apply the default cooking
time or adjust it in the relevant menu.
The maximum setting is designed for heating liquids
only; it is not designed for heating food. To protect the
appliance, the maximum power of the microwave is
gradually reduced to 600 W during the first few
minutes. Full power is made available again after a
cooling period.
Setting the microwave
To achieve optimum results with the microwave, always
insert the wire rack at shelf position 1.
Note: If you use the microwave function very regularly,
you can change the "Operation after switch-on" option
in the microwave's basic settings.
1. Touch the #touch button to switch on the
appliance.
2. Touch the 0touch button.
The main menu appears.
3. Use the (or )button to select "Microwave •".
4. Use the &button to open the microwave menu.
A microwave output setting and cooking time are
suggested.
5. Use the (or )button to set the required microwave
output setting.
6. Use the &button to navigate to the next line.
7. Use the (or )button to set the required cooking
time.
8. Touch the #touch button to start the appliance
operation.
The #touch button lights up red. The cooking time
counts down on the display.
To prevent condensation from forming when the
appliance is in microwave only mode, the appliance will
automatically switch on an additional heating element
when it is set to 600 W or "Max.". The cooking
compartment and the accessories will become hot. The
cooking result is not affected by this.
Note: You can switch this function off in the basic
settings. ~"Basic settings" on page 21
:Warning – Risk of burns!
At the highest settings in microwave only mode, the
drying function will automatically switch on an additional
heating element to heat the cooking compartment.
Never touch the inside surfaces of the cooking
compartment or the heating elements while they are
hot. Keep children at a safe distance.
Changing the cooking time
You can change the cooking time at any time during
operation by touching the (or )touch button.
Changing the microwave output setting
1. Touch the #touch button and reset the microwave
output setting and cooking time.
2. Touch the #touch button to start the appliance
operation.
The cooking time has elapsed
As soon as the end time has been reached, an audible
signal sounds and the appliance ends the microwave
operation automatically.
"xFinished" appears on the display.
Touch the 0touch button to stop the audible signal.
If you want to set a new cooking time, touch the #
touch button.
Otherwise, touch the #touch button to switch off the
appliance.
Pausing the operation
Touch the #touch button to pause the oven. Press the
#touch button again to continue the operation.
Opening the appliance door interrupts the operation.
Touch the #touch button once the door has been
closed. The operation continues.
Note: If you have altered the basic setting, make sure
that the microwave does not resume operation without
food inside. ~Page 21
:Warning – Risk of burns!
The accessible parts become very hot when in
operation. Never touch hot parts. Keep children at a
safe distance.
Cancelling the operation
Touch the #touch button.
Power
settings
Food Maximum cook-
ing time
90 W For defrosting delicate foods 1 hr 30 mins
180 W For defrosting and continued cooking 1 hr 30 mins
360 W For cooking meat and heating deli-
cate foods
1 hr 30 mins
600 W For heating and cooking food 1 hr 30 mins
max. For heating liquids 30 mins

en Microwave
20
Starting drying
To dry the cooking compartment, it is heated up so that
the moisture in the cooking compartment evaporates.
You will then need to open the appliance door to allow
the steam to escape from the cooking compartment.
Caution!
Enamel damage: Do not start any operations when
there is water on the cooking compartment floor. Before
operation, wipe away the water from the cooking
compartment floor.
1. Leave the appliance to cool down.
2. Remove the worst dirt from the cooking
compartment immediately and wipe away moisture
from the cooking compartment floor.
3. If necessary, touch the #touch button to switch the
appliance on.
4. Touch the 0touch button to display the operating
modes.
5. Use the ( or ) button to select "Drying ª".
6. Use the & button to navigate to the next line.
The duration is displayed. It cannot be changed.
7. Use the & button to navigate to the next line.
8. Touch the #touch button.
The drying function is started and is ended
automatically after 10 minutes.
9. Open the appliance door and leave it open for 1 to 2
minutes so that the moisture in the cooking
compartment can escape.
Setting the microwave to combi-mode
Several types of heating are suitable for combining with
the microwave. The microwave output setting can be
set to 90 W, 180 W or 360 W.
Types of heating available:
1. Touch the #touch button to switch on the
appliance.
2. Touch the 0touch button.
The main menu appears.
3. Use the (or )button to select "Microwave
combination operation ¡".
4. Touch the &touch button.
The "Hot air" default value is shown on the display.
5. Use the (or )touch button to set the required type
of heating.
6. Use the &button to navigate to the next line.
Set the desired temperature using the (or )button.
7. Use the &button to navigate to the next line.
Use the (or )button to set the required microwave
output setting.
8. Use the &button to navigate to the next line.
Use the (or )button to set the required cooking
time.
9. Touch the #touch button.
The appliance starts the operation. The cooking time
counts down on the display.
You can change the temperature, microwave output
setting and cooking time at any time. To do this, use the
%or &button to navigate to the required field, and set
the value you want using the (or )button.
The cooking time has elapsed
As soon as the end time has been reached, an audible
signal sounds and the appliance ends the microwave
operation automatically.
"xFinished" appears on the display.
Touch the 0touch button to stop the audible signal.
If you want to set a new cooking time, touch the #
touch button.
Otherwise, touch the #touch button to switch off the
appliance.
Pausing the operation
Touch the #touch button to pause the oven. Press the
#touch button again to continue the operation.
Opening the appliance door interrupts the operation.
The operation continues to run automatically when the
door is closed.
Cancelling the operation
Touch the #touch button.
‚Hot air
ƒTop/bottom heating
‡Circo-roasting
ˆGrill, large area
‰Grill, small area
