NEFF D39G69S0 User manual

[de] Gebrauchsanleitung ............................3
[en] Instruction manual ............................10
[nl] Gebruiksaanwijzing ...........................17
Dunstabzugshaube
Extractor hood
Afzuigkap
D39G69S0

10
Table of contents
Important safety information .................................................. 10
Environmental protection ....................................................... 12
Saving energy................................................................................... 12
Environmentally-friendly disposal.................................................. 12
Operating modes ..................................................................... 12
Exhaust air mode.............................................................................12
Circulating-air mode ........................................................................12
Operating the appliance.......................................................... 13
Control panel ....................................................................................13
Setting the fan ..................................................................................13
Intensive setting ...............................................................................13
Fan run-on time ................................................................................13
Interval ventilation ............................................................................ 13
Lighting ..............................................................................................13
Saturation display ............................................................................ 13
Cleaning and maintenance ..................................................... 14
Trouble shooting...................................................................... 15
After-sales service................................................................... 16
Accessories for circulated air mode ...................................... 16
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at
www.neff-international.com and in the online shop
www.neff-eshop.com
Important safety information
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for
future use or for subsequent owners.
The appliance can only be used safely if it
is correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly
at its installation location.
This appliance is intended for domestic use
and the household environment only. The
appliance is not intended for use outside.
Do not leave the appliance unattended
during operation. The manufacturer is not
liable for damage which is caused by
improper use or incorrect operation.
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
This appliance may be used by children
over the age of 8 years old and by persons
with reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around
the appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old
at a safe distance from the appliance and
power cable.
Check the appliance for damage after
unpacking it. Do not connect the appliance
if it has been damaged in transport.
This appliance is not intended for operation
with an external clock timer or a remote
control.
Danger of suffocation!
Packaging material is dangerous to
children. Never allow children to play with
packaging material.
Danger of death!
Risk of poisoning from flue gases that are
drawn back in.
Always ensure adequate fresh air in the
room if the appliance is being operated in
exhaust air mode at the same time as room
air-dependent heat-producing appliance is
being operated.
Room air-dependent heat-producing
appliances (e.g. gas, oil, wood or coal-
operated heaters, continuous flow heaters
or water heaters) obtain combustion air
from the room in which they are installed
and discharge the exhaust gases into the
open air through an exhaust gas system
(e.g. a chimney).

11
In combination with an activated vapour
extractor hood, room air is extracted from
the kitchen and neighbouring rooms - a
partial vacuum is produced if not enough
fresh air is supplied. Toxic gases from the
chimney or the extraction shaft are sucked
back into the living space.
Adequate incoming air must therefore
always be ensured.
An incoming/exhaust air wall box alone
will not ensure compliance with the limit.
Safe operation is possible only when the
partial vacuum in the place where the heat-
producing appliance is installed does not
exceed 4 Pa (0.04 mbar). This can be
achieved when the air needed for
combustion is able to enter through
openings that cannot be sealed, for
example in doors, windows, incoming/
exhaust air wall boxes or by other technical
means.
In any case, consult your responsible
Master Chimney Sweep. He is able to
assess the house's entire ventilation setup
and will suggest the suitable ventilation
measures to you.
Unrestricted operation is possible if the
vapour extractor hood is operated
exclusively in the circulating-air mode.
Risk of fire!
Grease deposits in the grease filter may
catch fire.
Clean the grease filter at least every
2 months.
Never operate the appliance without the
grease filter.
Risk of fire!
Grease deposits in the grease filter may
catch fire. Never work with naked flames
close to the appliance (e.g. flambéing). Do
not install the appliance near a heat-
producing appliance for solid fuel
(e.g. wood or coal) unless a closed, non-
removable cover is available. There must
be no flying sparks.
Risk of fire!
Hot oil and fat can ignite very quickly.
Never leave hot fat or oil unattended.
Never use water to put out burning oil or
fat. Switch off the hotplate. Extinguish
flames carefully using a lid, fire blanket or
something similar.
Risk of fire!
When gas burners are in operation without
any cookware placed on them, they can
build up a lot of heat. A ventilation
appliance installed above the cooker may
become damaged or catch fire. Only
operate the gas burners with cookware on
them.
Risk of fire!
Operating several gas burners at the
same time gives rise to a great deal of
heat. A ventilation appliance installed
above the cooker may become damaged
or catch fire. Never operate two gas
burners simultaneously on the highest
flame for longer than 15 minutes. One
large burner of more than 5 kW (wok) is
equivalent to the power of two gas
burners.
Risk of burns!
The accessible parts become very hot when
in operation. Never touch hot parts. Keep
children at a safe distance.
Risk of injury!
Components inside the appliance may
have sharp edges. Wear protective gloves.
Risk of injury!
Items placed on the appliance may fall
down. Do not place any objects on the
appliance.
Risk of injury!
The light emitted by LED lights is very
dazzling, and can damage the eyes
(risk group 1). Do not look directly into the
switched on LED lights for longer than
100 seconds.
Risk of electric shock!
A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the

12
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of electric shock!
Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Risk of electric shock!
Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Causes of damage
Caution!
Risk of damage due to corrosion. Always switch on the
appliance while cooking to avoid condensation. Condensate
can produce corrosion damage.
Risk of damage due to ingress of humidity into the electronic
circuitry. Never clean operator controls with a wet cloth.
Surface damage due to incorrect cleaning. Clean stainless
steel surfaces in the direction of the grain only. Do not use any
stainless steel cleaners for operator controls.
Surface damage due to strong or abrasive cleaning agents.
Never use strong and abrasive cleaning agents.
Risk of damage from returning condensate. Install the exhaust
duct in such a way that it falls away from the appliance slightly
(1° slope).
Environmental protection
Your new appliance is particularly energy-efficient. Here you
can find tips on how to save even more energy when using the
appliance, and how to dispose of your appliance properly.
Saving energy
During cooking, ensure that there is a sufficient supply of air
so that the extractor hood can work efficiently and with a low
level of operating noise.
Adjust the fan speed to the intensity of the cooking fumes.
Only use intensive mode where this is required. A lower fan
speed means that less energy is consumed.
If there are intensive cooking fumes, select a higher fan
speed in good time. If cooking fumes have already spread in
the kitchen, the extractor hood must be operated for longer.
Switch off the extractor hood if you no longer require it.
Switch off the lighting if you no longer require it.
Clean and, if required, replace the filter at regular intervals in
order to increase the effectiveness of the ventilation system
and to prevent the risk of fire.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
Operating modes
This appliance can be used in exhaust-air mode or circulating-
air mode.
Exhaust air mode
Note: The exhaust air must not be conveyed into a functioning
smoke or exhaust gas flue or into a shaft which is used to
ventilate installation rooms which contain heat-producing
appliances.
Before conveying the exhaust air into a non-functioning
smoke or exhaust gas flue, obtain the consent of the heating
engineer responsible.
If the exhaust air is conveyed through the outer wall, a
telescopic wall box should be used.
Circulating-air mode
Note: To bind odours in circulating-air mode, you must install
an activated carbon filter. The different options for operating the
appliance in circulating-air mode can be found in the brochure.
Alternatively, ask your dealer. The required accessories are
available from specialist outlets, from customer service or from
the Online Shop. The accessory numbers can be found at the
end of the instructions for use.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning used
electrical and electronic appliances (waste
electrical and electronic equipment - WEEE). The
guideline determines the framework for the return
and recycling of used appliances as applicable
throughout the EU.
The air which is drawn in is cleaned by the
grease filters and conveyed to the exterior
by a pipe system.
The air which is drawn in is cleaned by the
grease filters and an activated carbon filter and
conveyed back into the kitchen.

13
Operating the appliance
These instructions apply to several appliance variants. It is
possible that individual features are described which do not
apply to your appliance.
Note: Switch on the extractor hood when you start cooking and
switch it off again several minutes after you have finished
cooking. This is the most effective way of removing the kitchen
fumes.
Control panel
Setting the fan
Note: Always adjust the fan strength to meet current conditions.
If there is a large build-up of steam or fumes, select a high fan
setting.
Switching on the appliance
1. Press the button.
The fan starts at setting 1.
2. Press the "+" or "-" buttons to set another fan setting.
Switching off the appliance
Press the button.
Intensive setting
You can use the intensive setting if there is a large build-up of
odours and fumes/vapours.
1. Press the button.
The intensive setting is activated.
2. Press the button.
The intensive setting is deactivated.
Note: The intensive setting run time is 6 minutes. Once this
time has elapsed, the appliance switches back to the fan
setting.
Fan run-on time
1. Press the button.
The current fan setting and the remaining run-on time in
minutes are displayed alternately in the display panel. The fan
continues to run at the previous setting for 15 minutes. Once
this time has elapsed, the ventilation and lighting
automatically switch off.
2. Press the button.
The fan run-on ends before the end of the remaining run-on
time.
Interval ventilation
With intermittent ventilation, the ventilation switches on
automatically for 10 minutes every hour. After 24 hours, the
appliance switches off.
1. Press the button.
is shown on the display.
2. Press the button.
The intermittent ventilation switches off.
Lighting
The lighting can be switched on and off independently of the
ventilation.
Press the button.
Setting the brightness
1. Press and hold the button for two seconds.
The brightness is reduced.
2. Press the button.
The maximum brightness is restored.
Saturation display
When the metal grease filter or activated carbon filter is
saturated, the corresponding symbol flashes:
Metal grease filter:
Activated carbon filter:
If you have not yet done so, clean the metal grease filter or
replace the activated carbon filter immediately.
For instructions on how to clean the metal grease filter, please
refer to the section "Cleaning and maintenance".
Resetting the saturation indicators
1. Switch off the motor.
2. Press and hold the button for two seconds.
Switching over the display for circulating-air mode
For circulating-air mode, the electronic control display must be
switched over accordingly:
1. Check that the extractor hood is connected and switched off.
2. Press and hold the "+" button for two seconds.
flashes twice, i.e. the electronic control is switched over to
circulating-air mode.
3. Press the "+" button.
flashes once, i.e. the electronic control is switched back to
exhaust-air mode.
Explanation
1 Switch the fan on/off
2 Switch on the fan run-on
3 Switch on the interval ventilation
4 Turn the fan down
5 Display panel
6 Switch up the fan setting
7 Switch on intensive mode
8 Reset the saturation indicator
9 Switch on the lighting

14
Cleaning and maintenance
Risk of burns!
The appliance becomes hot during operation. Allow the
appliance to cool down before cleaning.
Risk of electric shock!
Penetrating moisture may result in an electric shock. Clean the
appliance using a damp cloth only. Before cleaning, pull out the
mains plug or switch off the circuit breaker in the fuse box.
Risk of electric shock!
Do not use any high-pressure cleaners or steam cleaners,
which can result in an electric shock.
Risk of injury!
Components inside the appliance may have sharp edges. Wear
protective gloves.
Cleaning agents
Observe the information in the table to ensure that the different
surfaces are not damaged by using the wrong type of cleaning
agent. Do not use
harsh or abrasive cleaning agents,
cleaning agents with a high concentration of alcohol,
hard scouring pads or sponges,
high-pressure cleaners or steam cleaners.
Wash new sponge cloths thoroughly before use.
Follow all instructions and warnings included with the cleaning
agents.
Removing metal grease filter
1. Fold the filter cover upwards.
Notes
The opening angle of the filter cover is restricted to
approx. 80°. Do not open the filter cover any further,
otherwise the hinges may be damaged.
The filter cover locks in any position.
2. Remove the two metal grease filters under the filter cover and
the metal grease filter on the underside of the appliance.
Unfasten the lock, fold the metal filter forwards and remove it
from the bracket.
Note: Grease can accumulate at the bottom of the metal
grease filter. Hold the metal grease filter level, otherwise
grease will drip out.
3. Clean the metal grease filter.
4. After removing the filters, clean the inside of the appliance.
5. Clean the filter cover.
Cleaning the metal mesh grease filters
These instructions apply to several appliance variants. It is
possible that individual features are described which do not
apply to your appliance.
Risk of fire!
Grease deposits in the grease filter may catch fire.
Clean the grease filter at least every 2 months.
Never operate the appliance without the grease filter.
Notes
Do not use any aggressive, acidic or alkaline cleaning
agents.
When cleaning the metal mesh grease filters, also clean the
holder for the metal mesh grease filters in the appliance
using a damp cloth.
The metal mesh grease filters can be cleaned in the
dishwasher or by hand.
By hand:
Note: You can use a special grease solvent for stubborn dirt. It
can be ordered via the Online Shop.
Soak the metal mesh grease filters in a hot soapy solution.
Clean the filters with a brush and then rinse them thoroughly.
Leave the metal mesh grease filters to drain.
Area Cleaning agents
Stainless steel Hot soapy water:
Clean with a dish cloth and dry with a
soft cloth.
Clean stainless steel surfaces in the
direction of the grain only.
Special stainless steel cleaning prod-
ucts are available from our after-sales
service or from specialist retailers.
Apply a very thin layer of the cleaning
product with a soft cloth.
Painted surfaces Hot soapy water:
Clean using a damp dish cloth and dry
with a soft cloth/towel.
Do not use any stainless steel cleaners.
Aluminium and plas-
tic
Glass cleaner:
Clean with a soft cloth.
Glass Glass cleaner:
Clean with a soft cloth. Do not use a
glass scraper.
Operating controls Hot soapy water:
Clean using a damp dish cloth and dry
with a soft cloth.
Risk of damage to the electronics from
penetrating moisture. Never clean oper-
ator controls with a wet cloth.
Do not use any stainless steel cleaners.

15
In the dishwasher:
Note: If the metal mesh grease filters are cleaned in the
dishwasher, slight discolouration may occur. This has no effect
on the function of the metal mesh grease filters.
Do not clean heavily soiled metal mesh grease filters together
with utensils.
Place the metal mesh grease filters loosely in the dishwasher.
The metal mesh grease filters must not be wedged in.
Installing the metal mesh grease filter
1. Insert the second metal grease filter under the filter cover with
the lock facing downwards.
Insert the metal grease filter on the underside of the
appliance.
2. Fold the metal grease filter back and lock.
3. Close the filter cover.
4. Press and hold the button for two seconds.
The saturation indicator is reset.
Changing the activated charcoal filter
(only in circulating-air mode)
In order to guarantee efficient odour filtration, the filter must be
serviced regularly.
The activated charcoal filters must be replaced at least every
4 months.
Notes
The activated charcoal filters are not included in the delivery.
The activated charcoal filters can be obtained from specialist
retailers, from our after-sales service or from the Online Shop.
The activated charcoal filters cannot be cleaned or
reactivated.
1. Remove the metal grease filter, see above.
2. Turn the old activated carbon filter and remove from the
holder.
3. Insert the new activated carbon filter into the holder and turn.
4. Install the metal grease filter, see above.
5. Press and hold the button for two seconds.
The saturation indicator is reset.
Trouble shooting
Malfunctions often have simple explanations. Please read the
following notes before calling the after-sales service.
Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be carried
out and damaged power cables replaced by one of our trained
after-sales technicians. If the appliance is defective, unplug the
appliance from the mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
LED lights
Defective LED lights must only be replaced by the
manufacturer, their customer service department or a licensed
technician (electrician).
Malfunction table
--------
Problem Possible cause Solution
The appliance
does not work
The plug is not
plugged in.
Connect the appliance to
the electricity supply
Power cut Check whether other
kitchen appliances are
working
Faulty fuse Check in the fuse box to
make sure that the fuse for
the appliance is OK
The button illu-
mination does
not work.
The control unit
is faulty.
Call the after sales service.
The lighting
does not work.
The lighting is
defective.
Call the after-sales service.
If or
appears on the
display
The grease or
activated char-
coal filter is sat-
urated.
Clean the filter  see sec-
tion "Cleaning and mainte-
nance".

16
After-sales service
Our after-sales service is there for you if your appliance needs
to be repaired. We will always find the right solution in order to
avoid unnecessary visits from a service technician.
When calling us, please give the product number (E no.) and
the production number (FD no.) so that we can provide you with
the correct advice. The rating plate with these numbers can be
found inside the appliance (remove the metal mesh grease
filter to gain access).
You can make a note of the numbers of your appliance and the
telephone number of the after-sales service in the space below
to save time should it be required.
Please be aware that a visit by an after-sales engineer will be
charged if a problem turns out to be the result of operator error,
even during the warranty period.
Please find the contact data of all countries in the enclosed
customer service list.
To book an engineer visit and product advice
Rely on the professionalism of the manufacturer. You can
therefore be sure that the repair is carried out by trained service
technicians who carry original spare parts for your appliances.
Accessories for circulated air mode
(not included in the delivery)
E no. FD no.
After-sales service
GB 0344 892 8989
Calls charged at local or mobile rate.
IE 01450 2655
0.03  per minute at peak. Off peak 0.0088  per
minute.
Z5135X5
Z5135X4
Z5135X1
Z5270X0
Z5170X1
