NEO hsm2host User manual

HSM2HOST 2-Way Wireless Transceiver
V1.0 Installation Guide
Contents:
English ................................ 1
Français .............................. 17
Español ............................... 37
Português ........................... 57
WARNING: This manual contains information on limitations regarding product use
and function and information on the limitations as to liability of the manufacturer. The
entire manual should be carefully read.
D-304886

1
Specifications and Features
• Current Draw: 60mA
• Voltage: Draws current from the PowerSeries Neo alarm controller (10.8VDC to 12.5VDC)
• Frequency: 433MHz (HSM2HOST4), 868MHz (HSM2HOST8), 912-919MHz
(HSM2HOST9UL)
• Zones - can receive signals from up to 128 wireless zones, plus 16 wireless keypads. Also supports
up to 32 wireless keys
• Supervisory - programmable supervisory window
• Can be wired up to 1000 ft. / 230 m from the main panel with 22 AWG wire
• Connects to Corbus
• Compatibility: The HSM2HOST is used with PowerSeries Neo alarm panels
• Operating temperature: 0°C to +49°C (32-122°F)
• Relative humidity: 93% non-condensing
• Separate, built-in wall and case tampers
NOTE: For Commercial BURG (UL) the Supervisory window shall be set to 4 hours.
For Residential Fire (UL/ULC) the Supervisory window shall be set to 200 seconds.
For Residential BURG (UL/ULC) the supervisory window shall be set to 24 hours.
For UL Home Healthcare applications the supervisory window shall be set to 24 hours
Only models operating in the band 912-919 MHz are UL/ULC listed where indicated. Only UL
approved devices are to be used with UL/ULC listed systems.
Compatible Wireless Devices
Please refer to the instruction sheets of the following devices for more information. On the chart
below and throughout this document, x in the model number represents the operating frequency of the
device as follows: 9 (912-919 MHz), 8 (868MHz), 4 (433MHz).
The HSM2HOSTx (x= 4/8/9) can receive signals from the following devices:
Alarm Controllers
PowerSeries Neo alarm Controllers HS2128
HS2064
HS2032
HS2016
Modules
Wireless keypads HS2LCDWFx
HS2LCDWFPx
HS2LCDWFPVx
Wireless Devices
Wireless PG smoke detector PGx926UL
Wireless PG smoke and heat detector PGx916UL
Wireless PG CO detector PGx913
Wireless PG PIR motion detector PGx904(P)UL
Wireless PG PIR + camera motion detector PGx934(P)UL

2
Safety Instructions
• This equipment must be installed by Service Persons only (service person is defined as a person having the
appropriate technical training and experience necessary to be aware of hazards to which that person may be exposed
in performing a task and of measures to minimize the risks to that person or other persons). It must be installed and
used within an environment that provides the pollution degree max 2, over voltages category II, in non-hazardous,
indoor locations only.
• The installer is responsible for instructing the system user in regards to electrical safety precautions when using a
system which includes this equipment and also in regards to each of the following:
• Do not attempt to service this product. Opening or removing covers may expose the user to dangerous volt-
ages or other risks.
• Any servicing shall be referred to service persons only.
• Use authorized accessories only with this equipment.
• Secure the receiver to the building structure before applying power to the alarm controller.
Use adequate mounting means to secure the receiver to the building structure (e.g., plastic/metal anchors and screws).
Only UL/ULC listed devices can be used in UL/ULC listed installations.
HSM2HOST9 is listed for UL Commercial Burglary, Residential Fire, Residential Burglary and Home Health Care,
ULC Residential Fire and Residential Burglary:
UL1610 Central-Station Burglar-Alarm Units
UL1023 Household Burglar-Alarm System Units
UL985 Household Fire Warning System Units
UL1637 Home Health Care Signaling Equipment
ULC-S545-02 Residential Fire Warning System Control Units
ORD-C1023-1974 Household Burglar-Alarm System Units
UL 609 Local Burglar Alarm Units and Systems
UL365 Police Station Connected Burglar Alarm Units and Systems
Wireless PG curtain motion detector PGx924UL
Wireless PG dual tech motion detector PGx984(P)
Wireless PG mirror motion detector PGx974(P)UL
Wireless PG outdoor motion detector PGx994UL
Wireless PG glass break detector PGx912
Wireless PG shock detector PGx935UL
Wireless PG flood detector PGx985UL
Wireless PG temperature detector (indoor use) PGx905UL
Wireless PG key PGx939UL
Wireless PG key PGx929UL
Wireless PG panic key PGx938UL
Wireless PG 2-button key PGx949UL
Wireless PG indoor siren PGx901UL
Wireless PG outdoor siren PGx911UL
Wireless PG repeater PGx920UL
Wireless PG door/window contact PGx975UL
Wireless PG door/window contact w/ AUX PGx945UL

3
Introduction
The HSM2HOSTx two-way wireless transceiver adds wireless capability to PowerSeries Neo alarm
controllers, model HS2128, HS2064, HS2032 or HS2016. This manual describes how to install,
program and maintain the HSM2HOST.
Controls & Indicators
Status LEDs
The LEDs on the front of the HSM2HOST provide feedback regarding the installation, operation and
troubleshooting of the unit. The LEDs function as follows:
Red LED Operation
Module Power Up: On steady during module power-up sequence then off.
Firmware Update: Slow flashing = update in progress
Rapid flashing = update failed
Very rapid flashing = update corrupt, contact distributor
Trouble Condition: • No trouble: 1 rapid flash every 10 seconds.
If troubles are present, a series of flashes occur every 2 seconds. Each
series of flashes indicate troubles as follows:
• 1 flash: Module not enrolled
• 2 flashes: Loss of contact with module for over 60 seconds
• 3 flashes: Corbus low voltage
• 8 flashes: RF interference (jam condition)
Module Confirmation: On steady during module confirmation process.
Placement Test: On steady when location is bad. Off when location is good.
Green LED Operation
Placement Test: On steady when location is suitable. Off when location is unsuitable.
For UL/ULC listed systems, signal must be “Strong”. See
Wireless Device Status Indications on page 9 for details.
Tamper
The HSM2HOST has separate built-in wall and case tampers. The case tamper is disabled by default
on the NA version (enabled on EU version). Section [804][510] option 3 enables or disables the case
tamper. Enable or disable the wall tamper by fastening the breakaway wall tamper bracket securely to
the wall using one of the supplied screws.
The case tamper activates when the case is opened and restores when the case is closed. The wall
tamper on the back of the unit is depressed by the mounting surface when properly installed. If the
unit is removed, the tamper activates. Ensure the mounting surface is smooth and free of obstructions
that block access to the rear of the unit. Electrical wires should not run over or under the module when
it is mounted.
NOTE: The built in wall and case tamper must be installed and enabled for UL/ULC listed
Commercial/ Residential Burglary applications.
NOTE:

4
Setup & Wiring
Choose a Mounting Location
NOTE: Permanently mount the HSM2HOST receiver and wireless devices AFTER
placement testing each device (See “Permanently Mount” on page 5).
Find a place that is:
•dry,
• within operating temperature range,
• central to the proposed placement of all wireless devices,
• as high as possible. The range is reduced if mounted below ground level,
• far from sources of interference, including: electrical noise (computers, televisions, electric
motors, appliances, heating and air conditioning units), large metal objects like heating ducts and
plumbing which may shield the electro-magnetic waves,
• smooth and free of obstructions that block access to the rear of the unit.
Connect the HSM2HOST
CAUTION: Remove all power (AC, DC, telephone lines) from the system while connecting modules
to the Corbus.
1. With the alarm panel powered down, connect the HSM2HOST to the four-wire Corbus of the
alarm panel according to Figure 1.
2. Once the wiring is complete, power up the security system.
Figure 1: Corbus Wiring
CORBUS TO
HSM2HOST
Enroll The HSM2HOST
The HSM2HOST must be enrolled onto the alarm panel before any wireless devices can be
enrolled.When the alarm system is powered up for the first time, the first keypad or the HSM2HOST
(if using a wireless keypad as the first keypad) can be enrolled. To do this:
1. Once the HSM2HOST is wired to the alarm panel and power has been applied, power up a
wireless keypad.
2. Press any button on the keypad to enroll it on the HSM2HOST. The HSM2HOST is then
automatically enrolled on the alarm panel.
Alternately, enroll the HSM2HOST on the system at any time using the following procedure:
1. Enter Installer Programming section [902][000] (Auto Enroll All Modules).
2. When prompted, press [*] to enroll.

5
To manually enroll,
1. Enter Installer Programming section [902][001] (Enroll Modules).
2. When prompted, key in the serial number found on the back of the HSM2HOST. The module is
enrolled.
Delete the HSM2HOST
To remove the HSM2HOST from the system:
1. Enter Installer Programming section [902][106] (Delete HSM2HOSTx).
2. Press [*] to delete.
Test HSM2HOST Location for RF Interference
With the alarm panel powered up and the HSM2HOST enrolled, enter installer programming section
[904]. Observe the status of the red LED. If the red LED is on, interference levels are high and a new
mounting location should be found. If the red LED is off, interference is low and the location is good.
NOTE: For UL/ULC listed systems, signal must be “Strong”. See Wireless Device Status
Indications on page 9 for details.
Permanently Mount
Once a suitable location is found, mount the HSM2HOST as follows:
1. Pull the Corbus wires through the holes at the back of the cabinet.
2. Mount the cabinet securely to the wall using the three screws supplied.
3. To enable the wall tamper, fasten the breakaway wall tamper bracket securely to the wall using the
supplied screw.
Figure 2: Mounting the HSM2HOST

6
Wireless Device Setup and Programming
[804][000] Enroll Wireless Devices
1. Enter Installer Programming section [804][000].
2. When prompted, either activate the device (see device installation sheet) to enroll immediately or enter
a device ID number. Do the latter to pre-enroll devices then enroll them later at the customer site.
The alarm panel determines the type of device being enrolled and presents the appropriate
programming options.
3. Use the scroll keys or type in the corresponding number to select an option.
4. Scroll through the available selections, key in a number or enter text as appropriate.
5. Press [*] to accept and move to the next option.
6. Once all options are configured, the system prompts to enroll the next device.
7. Repeat the process described above until all wireless devices are enrolled.
[804][001]-[716] Wireless Device Configuration
To configure wireless devices:
1. Enter Installer Programming section [804] then select one of the following sub-sections:
• 001-128 – Configure wireless zones
• 551-556 – Configure wireless sirens
• 601-632 – Configure wireless keys
• 701-716 – Configure wireless keypads
2. Select a device to configure using the scroll keys or go directly to a specific device by entering a
hotkey.
3. Use the scroll buttons or enter a hotkey to select a configuration option for the device. See device
sheets for details.
4. Press [*] to accept and move to the next option.
5. Once all options are configured, the system returns to the base configuration menu.
Repeat the process described above to configure other wireless devices.
[804][801] RF Jam Detect
To configure RF jamming:
1. Enter Installer Programming section [804][801].
Select one of the following options by scrolling or entering the hotkey:
• 00 – Enabled/Disabled
• 01 – UL 20/20-USA
• 02 – EN 30/60-Europe
• 03 – Class 6 30/60-British
2. Press [*] to accept the selection.
3. Press [#] to exit the section.
[804][802] Wireless Supervision Window
For EN installations, 1 hour or 2 hours must be selected.When option 06 is used, which configures
the system to generate fault conditions after a device has been detected as absent for 24 hours, smoke
detectors generate a fault condition after a maximum of 18 hours when the supervision toggle option
is disabled.
To program the Wireless Supervisory Window:
1. Enter Installer Programming section [804][802].
2. Select one of the following options by scrolling or entering the hotkey:
• 00 – Enabled/Disabled

7
• 01 – After 1 Hour
• 02 – After 2 Hours
• 03 – After 4 Hours
• 04 – After 8 Hours
• 05 – After 12 Hours
• 06 – After 24 Hours
3. Press [*] to accept the selection.
4. Press [#] to exit the section.
NOTE: For UL Residential Burglary (UL1023), Home Health Care (UL1637), ULC
Residential Burglary (ULC/ORD-C1023) installations, the maximum Supervision window
shall be set to 24 hours.
For UL Residential Fire (UL985) installations, the maximum supervision window is set to 200s.
For UL Commercial Burglary (UL1610/UL365) and ULC Residential Fire (ULC-S545), the maximum
supervision window shall be set to 4 hours.
[804][810] Wireless Options
To program wireless options:
1. Enter Installer Programming section [804][810].
2. Select one of the following options by scrolling or entering the hotkey:
• 01 – RF Delinquency
• 02 – Wireless Supervisory/ RF Jam Alarm
• 03 – Wireless Tamper
• 04 – 200s Fire Supervision
3. Press [*] to accept the selection and [#] to exit.
[804][841] Motion Cameras
To program wireless options:
1. Enter Installer Programming section [804][841].
Select one of the following options by scrolling or entering the hotkey:
001 Visual Verification On: Alarms trigger image capture from PIR
Cameras
Off: Alarms do not trigger image capture from
PIR Cameras
002 View Time Window 01 Alarm + 5 Minutes
02 Alarm + 15 minutes
03 Alarm + 1 Hour
003 View Other Alarms 01 Fire enabled/disabled
02 Duress enabled/disabled
03 Medical enabled/disabled
04 Panic enabled/disabled

8
[804][901]-[905] Delete Wireless Devices
To delete wireless devices:
1. Enter Installer Programming section [804] then select one of the following sub-sections:
• 901 – Delete wireless zone devices
• 902 – Delete wireless key
• 903 –Delete sirens
• 904 - Delete repeater
• 905 - Delete keypad
2. Select a device to delete using the scroll keys or go directly to a specific device by entering a hotkey.
3. Press [*] to delete or [#] to exit.
[804][921]-[925] Replace Wireless Devices
To replace a wireless device:
1. Enter Installer Programming section [804] then select one of the following sub-sections:
• 921 – Replace wireless zone devices
• 922 – Replace wireless keys
• 923 – Replace sirens
• 924 – Replace repeater
• 925 – Replace keypad
2. Press [*] to select a sub-section. The first available device is displayed.
3. Select a device to replace using the scroll keys or go to a specific device by entering a hotkey.
4. Press [*]. When prompted, activate the device (full enrollment) or enter the device ID (pre-
enrollment). A message is displayed confirming enrollment.
[804][990][001 – 005] Show All Devices
Use this section to review wireless devices enrolled on the system and to view serial numbers
associated with each device.
To review wireless device information:
1. Enter Installer Programming section [804][990] then select one of the following sub-sections:
• [001] – all zones
• [002] – repeaters
• [003] – sirens
• [004] – wireless keys
• [005] – keypads
2. Press [*] to select a wireless device type. The first available device is displayed.
3. Use the scroll keys to view the enrolled devices.
NOTE: This option is not fully supported by LED and ICON keypads.
[804][999] Reset to Factory Defaults
Selecting this option resets HSM2HOST programming to factory default settings.
[904] Placement Testing Wireless Devices
The following test modes are available:
• 001-128 – Test wireless zones
• 520 – Test all repeaters
• 550 – Test all sirens
• 600 – Test all wireless keys
• 700 – Test all keypads

9
Two test results are provided:
• 24-hour: Average results of signal strength testing over a 24-hour period.
• Now: Signal status results of the current test.
During testing, the Ready and Armed LED's flash to indicate data is being received. A flashing Trouble
LED indicates RF interference. The following status indicators may be displayed:
Table 1: Wireless Device Status Indications
LCD Icon* LED+ Status Repeater [905]
Strong 1 9 Strong signal strength Repeater 1
Good 210 Good signal strength Repeater 2
Poor 311 Poor signal strength Repeater 3
1-Way 412 The device is operating in 1-way mode only.
The alarm panel cannot configure or control the
device
Repeater 4
Not Test 513 Displayed as the Now result if no test was
performed.
Repeater 5
None 14 Always displayed as the 24-hour result when
testing wireless keys.
Repeater 6
*For Icon keypads, digit 1 indicates 24-hour test results; digit 2 indicates Now test results.
+For LED keypads, the first digit indicates 24-hour results; the second digit indicates Now test results.

10
Programming Worksheets
Use these pages for recording custom programming options. (Installers Programming: [*][8])
[000] Module Labels
[801] Keypad Labels (1 x 14 Characters)
001: 009:
002: 010:
003: 011:
004: 012:
005: 013:
006: 014:
007: 015:
008: 016:
[802] Zone Expander Labels (1 x 14 Characters)
001: 009:
002: 010:
003: 011:
004: 012:
005: 013:
006: 014:
007: 015:
008: 016:
[803] Output Expander Labels (1 x 14 Characters)
001: 009:
002: 010:
003: 011:
004: 012:
005: 013:
006: 014:
007: 015:
008: 016:

11
[806] HSM2HOST Label (1 x 14 Characters)
01:
[809] HSM2300 Power Supply Label (1 x 14 Characters)
01:
02:
03:
04:
[810] HSM2204 4 High-Current Output Label (1 x 14 Characters)
01:
02:
03:
04:
[820] Siren Label (1 x 14 Characters)
01: 09:
02: 10:
03: 11:
04: 12:
05: 13:
06: 14:
07: 15:
08: 16:
[821] Repeater Label (1 x 14 Characters)
01:
02:
03:
04:
05:
06:
07:
08:

12
[804] Wireless Programming
Key # Partition # User Label Key # Partition # User Label
19
210
311
412
513
614
715
816
[804][000] Wireless Device Enrollment – Wireless Keys
[804][000] Wireless Device Enrollment – Wireless Sirens
WLS
Siren # Partition # Siren Label WLS Siren # Partition # Siren Label
19
210
311
412
513
614
715
816
[804][000] Wireless Device Enrollment – Wireless Keypads
WLS
Keypad
#
Keypad
Assignment Keypad Label WLS
Keypad
#
Keypad
Assignment Keypad Label
19
210
311
412
513
614
715
816

13
[804][000] Wireless Device Enrollment Wireless Repeaters
Repeater # Repeater Label
1
2
3
4
5
6
7
8

14
Warning Please Read Carefully
Note to Installers
This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the
attention of the users of this system.
System Failures
This system has been carefully designed to be as effective as possible. There are circumstances, however, involving fire, burglary, or other types of emergen-
cies where it may not provide protection. Any alarm system of any type may be compromised deliberately or may fail to operate as expected for a variety of
reasons. Some but not all of these reasons may be:
• Inadequate Installation
A security system must be installed properly in order to provide adequate protection. Every installation should be evaluated by a security professional to ensure
that all access points and areas are covered. Locks and latches on windows and doors must be secure and operate as intended. Windows, doors, walls, ceilings
and other building materials must be of sufficient strength and construction to provide the level of protection expected. A reevaluation must be done during and
after any construction activity. An evaluation by the fire and/or police department is highly recommended if this service is available.
• Criminal Knowledge
This system contains security features which were known to be effective at the time of manufacture. It is possible for persons with criminal intent to develop
techniques which reduce the effectiveness of these features. It is important that a security system be reviewed periodically to ensure that its features remain
effective and that it be updated or replaced if it is found that it does not provide the protection expected.
• Access by Intruders
Intruders may enter through an unprotected access point, circumvent a sensing device, evade detection by moving through an area of insufficient coverage, dis-
connect a warning device, or interfere with or prevent the proper operation of the system.
• Power Failure
Control units, intrusion detectors, smoke detectors and many other security devices require an adequate power supply for proper operation. If a device operates
from batteries, it is possible for the batteries to fail. Even if the batteries have not failed, they must be charged, in good condition and installed correctly. If a
device operates only by AC power, any interruption, however brief, will render that device inoperative while it does not have power. Power interruptions of
any length are often accompanied by voltage fluctuations which may damage electronic equipment such as a security system. After a power interruption has
occurred, immediately conduct a complete system test to ensure that the system operates as intended.
• Failure of Replaceable Batteries
This system’s wireless transmitters have been designed to provide several years of battery life under normal conditions. The expected battery life is a function
of the device environment, usage and type. Ambient conditions such as high humidity, high or low temperatures, or large temperature fluctuations may reduce
the expected battery life. While each transmitting device has a low battery monitor which identifies when the batteries need to be replaced, this monitor may
fail to operate as expected. Regular testing and maintenance will keep the system in good operating condition.
• Compromise of Radio Frequency (Wireless) Devices
Signals may not reach the receiver under all circumstances which could include metal objects placed on or near the radio path or deliberate jamming or other
inadvertent radio signal interference.
• System Users
A user may not be able to operate a panic or emergency switch possibly due to permanent or temporary physical disability, inability to reach the device in time,
or unfamiliarity with the correct operation. It is important that all system users be trained in the correct operation of the alarm system and that they know how
to respond when the system indicates an alarm.
•SmokeDetectors
Smoke detectors that are a part of this system may not properly alert occupants of a fire for a number of reasons, some of which follow. The smoke detectors
may have been improperly installed or positioned. Smoke may not be able to reach the smoke detectors, such as when the fire is in a chimney, walls or roofs,
or on the other side of closed doors. Smoke detectors may not detect smoke from fires on another level of the residence or building.
Every fire is different in the amount of smoke produced and the rate of burning. Smoke detectors cannot sense all types of fires equally well. Smoke detectors
may not provide timely warning of fires caused by carelessness or safety hazards such as smoking in bed, violent explosions, escaping gas, improper storage of
flammable materials, overloaded electrical circuits, children playing with matches or arson.
Even if the smoke detector operates as intended, there may be circumstances when there is insufficient warning to allow all occupants to escape in time to
avoid injury or death.
• Motion Detectors
Motion detectors can only detect motion within the designated areas as shown in their respective installation instructions. They cannot discriminate between
intruders and intended occupants. Motion detectors do not provide volumetric area protection. They have multiple beams of detection and motion can only be
detected in unobstructed areas covered by these beams. They cannot detect motion which occurs behind walls, ceilings, floor, closed doors, glass partitions,
glass doors or windows. Any type of tampering whether intentional or unintentional such as masking, painting, or spraying of any material on the lenses, mir-
rors, windows or any other part of the detection system will impair its proper operation.
Passive infrared motion detectors operate by sensing changes in temperature. However their effectiveness can be reduced when the ambient temperature rises
near or above body temperature or if there are intentional or unintentional sources of heat in or near the detection area. Some of these heat sources could be
heaters, radiators, stoves, barbeques, fireplaces, sunlight, steam vents, lighting and so on.
• Warning Devices
Warning devices such as sirens, bells, horns, or strobes may not warn people or waken someone sleeping if there is an intervening wall or door. If warning
devices are located on a different level of the residence or premise, then it is less likely that the occupants will be alerted or awakened. Audible warning devices
may be interfered with by other noise sources such as stereos, radios, televisions, air conditioners or other appliances, or passing traffic. Audible warning
devices, however loud, may not be heard by a hearing-impaired person.
• Telephone Lines
If telephone lines are used to transmit alarms, they may be out of service or busy for certain periods of time. Also an intruder may cut the telephone line or
defeat its operation by more sophisticated means which may be difficult to detect.
• Insufficient Time
There may be circumstances when the system will operate as intended, yet the occupants will not be protected from the emergency due to their inability to
respond to the warnings in a timely manner. If the system is monitored, the response may not occur in time to protect the occupants or their belongings.
• Component Failure
Although every effort has been made to make this system as reliable as possible, the system may fail to function as intended due to the failure of a component.

15
• Inadequate Testing
Most problems that would prevent an alarm system from operating as intended can be found by regular testing and maintenance. The complete system should be
tested weekly and immediately after a break-in, an attempted break-in, a fire, a storm, an earthquake, an accident, or any kind of construction activity inside or
outside the premises. The testing should include all sensing devices, keypads, consoles, alarm indicating devices and any other operational devices that are part of
the system.
• Security and Insurance
Regardless of its capabilities, an alarm system is not a substitute for property or life insurance. An alarm system also is not a substitute for
property owners, renters, or other occupants to act prudently to prevent or minimize the harmful effects of an emergency situation.
IMPORTANT - READ CAREFULLY: DSC Software purchased with or without Products and
Components is copyrighted and is purchased under the following license terms:
• This End-User License Agreement (“EULA”) is a legal agreement between You (the company, individual or entity who acquired the Software and any
related Hardware) and Digital Security Controls, a division of Tyco Safety Products Canada Ltd. (“DSC”), the manufacturer of the integrated security
systems and the developer of the software and any related products or components (“HARDWARE”) which You acquired.
• If the DSC software product (“SOFTWARE PRODUCT” or “SOFTWARE”) is intended to be accompanied by HARDWARE, and is NOT accompanied
by new HARDWARE, You may not use, copy or install the SOFTWARE PRODUCT. The SOFTWARE PRODUCT includes computer software, and may
include associated media, printed materials, and “online” or electronic documentation.
• Any software provided along with the SOFTWARE PRODUCT that is associated with a separate end-user license agreement is licensed to You under the
terms of that license agreement.
• By installing, copying, downloading, storing, accessing or otherwise using the SOFTWARE PRODUCT, You agree unconditionally to be bound by the
terms of this EULA, even if this EULA is deemed to be a modification of any previous arrangement or contract. If You do not agree to the terms of this
EULA, DSC is unwilling to license the SOFTWARE PRODUCT to You, and You have no right to use it.
Software Product License
The SOFTWARE PRODUCT is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties. The
SOFTWARE PRODUCT is licensed, not sold.
1.GRANT OF LICENSE This EULA grants You the following rights:
(a) Software Installation and Use - For each license You acquire, You may have only one copy of the SOFTWARE PRODUCT installed.
(b) Storage/Network Use - The SOFTWARE PRODUCT may not be installed, accessed, displayed, run, shared or used concurrently on or from different com-
puters, including a workstation, terminal or other digital electronic device (“Device”). In other words, if You have several workstations, You will have to acquire
a license for each workstation where the SOFTWARE will be used.
(c) Backup Copy - You may make back-up copies of the SOFTWARE PRODUCT, but You may only have one copy per license installed at any given time. You
may use the back-up copy solely for archival purposes. Except as expressly provided in this EULA, You may not otherwise make copies of the SOFTWARE
PRODUCT, including the printed materials accompanying the SOFTWARE.
2. DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS
(a) Limitations on Reverse Engineering, Decompilation and Disassembly - You may not reverse engineer, decompile, or disassemble the SOFTWARE
PRODUCT, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation. You may not make any
changes or modifications to the Software, without the written permission of an officer of DSC. You may not remove any proprietary notices, marks or labels from
the Software Product. You shall institute reasonable measures to ensure compliance with the terms and conditions of this EULA.
(b) Separation of Components - The SOFTWARE PRODUCT is licensed as a single product. Its component parts may not be separated for use on more than one
HARDWARE unit.
(c) Single INTEGRATED PRODUCT - If You acquired this SOFTWARE with HARDWARE, then the SOFTWARE PRODUCT is licensed with the HARD-
WARE as a single integrated product. In this case, the SOFTWARE PRODUCT may only be used with the HARDWARE as set forth in this EULA..
(d) Rental - You may not rent, lease or lend the SOFTWARE PRODUCT. You may not make it available to others or post it on a server or web site.
(e) Software Product Transfer - You may transfer all of Your rights under this EULA only as part of a permanent sale or transfer of the HARDWARE, provided
You retain no copies, You transfer all of the SOFTWARE PRODUCT (including all component parts, the media and printed materials, any upgrades and this
EULA), and provided the recipient agrees to the terms of this EULA. If the SOFTWARE PRODUCT is an upgrade, any transfer must also include all prior ver-
sions of the SOFTWARE PRODUCT.
(f) Termination - Without prejudice to any other rights, DSC may terminate this EULA if You fail to comply with the terms and conditions of this EULA. In such
event, You must destroy all copies of the SOFTWARE PRODUCT and all of its component parts.
(g) Trademarks - This EULA does not grant You any rights in connection with any trademarks or service marks of DSC or its suppliers.
3. COPYRIGHT - All title and intellectual property rights in and to the SOFTWARE PRODUCT (including but not limited to any images, photographs, and text
incorporated into the SOFTWARE PRODUCT), the accompanying printed materials, and any copies of the SOFTWARE PRODUCT, are owned by DSC or its
suppliers. You may not copy the printed materials accompanying the SOFTWARE PRODUCT. All title and intellectual property rights in and to the content
which may be accessed through use of the SOFTWARE PRODUCT are the property of the respective content owner and may be protected by applicable copy-
right or other intellectual property laws and treaties. This EULA grants You no rights to use such content. All rights not expressly granted under this EULA are
reserved by DSC and its suppliers.
4. EXPORT RESTRICTIONS - You agree that You will not export or re-export the SOFTWARE PRODUCT to any country, person, or entity subject to Cana-
dian export restrictions.
5. CHOICE OF LAW - This Software License Agreement is governed by the laws of the Province of Ontario, Canada.
6. ARBITRATION - All disputes arising in connection with this Agreement shall be determined by final and binding arbitration in accordance with the Arbitra-
tion Act, and the parties agree to be bound by the arbitrator’s decision. The place of arbitration shall be Toronto, Canada, and the language of the arbitration shall
be English.
7. LIMITED WARRANTY
(a) NO WARRANTY - DSC PROVIDES THE SOFTWARE “AS IS” WITHOUT WARRANTY. DSC DOES NOT WARRANT THAT THE SOFTWARE
WILL MEET YOUR REQUIREMENTS OR THAT OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED OR ERROR-FREE.
(b) CHANGES IN OPERATING ENVIRONMENT - DSC shall not be responsible for problems caused by changes in the operating characteristics of the
HARDWARE, or for problems in the interaction of the SOFTWARE PRODUCT with non-DSC-SOFTWARE or HARDWARE PRODUCTS.
(c) LIMITATION OF LIABILITY; WARRANTY REFLECTS ALLOCATION OF RISK - IN ANY EVENT, IF ANY STATUTE IMPLIES WARRANTIES
OR CONDITIONS NOT STATED IN THIS LICENSE AGREEMENT, DSC’S ENTIRE LIABILITY UNDER ANY PROVISION OF THIS LICENSE
AGREEMENT SHALL BE LIMITED TO THE GREATER OF THE AMOUNT ACTUALLY PAID BY YOU TO LICENSE THE SOFTWARE PRODUCT
AND FIVE CANADIAN DOLLARS (CAD$5.00). BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIA-
BILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
(d) DISCLAIMER OF WARRANTIES - THIS WARRANTY CONTAINS THE ENTIRE WARRANTY AND SHALL BE IN LIEU OF ANY AND ALL
OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FIT-

16
NESS FOR A PARTICULAR PURPOSE) AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF DSC. DSC MAKES NO
OTHER WARRANTIES. DSC NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON PURPORTING TO ACT ON ITS BEHALF TO
MODIFY OR TO CHANGE THIS WARRANTY, NOR TO ASSUME FOR IT ANY OTHER WARRANTY OR LIABILITY CONCERNING THIS SOFT-
WARE PRODUCT.
(e) EXCLUSIVE REMEDY AND LIMITATION OF WARRANTY - UNDER NO CIRCUMSTANCES SHALL DSC BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES BASED UPON BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLI-
GENCE, STRICT LIABILITY, OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, LOSS OF PROFITS,
LOSS OF THE SOFTWARE PRODUCT OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF SUBSTITUTE OR REPLACEMENT
EQUIPMENT, FACILITIES OR SERVICES, DOWN TIME, PURCHASERS TIME, THE CLAIMS OF THIRD PARTIES, INCLUDING CUSTOMERS,
AND INJURY TO PROPERTY. WARNING: DSC recommends that the entire system be completely tested on a regular basis. However, despite frequent test-
ing, and due to, but not limited to, criminal tampering or electrical disruption, it is possible for this SOFTWARE PRODUCT to fail to perform as expected.
Limited Warranty
Digital Security Controls warrants the original purchaser that for a period of twelve months from the date of purchase, the product shall be free of defects in
materials and workmanship under normal use. During the warranty period, Digital Security Controls shall, at its option, repair or replace any defective product
upon return of the product to its factory, at no charge for labour and materials. Any replacement and/or repaired parts are warranted for the remainder of the
original warranty or ninety (90) days, whichever is longer. The original purchaser must promptly notify Digital Security Controls in writing that there is defect
in material or workmanship, such written notice to be received in all events prior to expiration of the warranty period. There is absolutely no warranty on soft-
ware and all software products are sold as a user license under the terms of the software license agreement included with the product. The Customer assumes
all responsibility for the proper selection, installation, operation and maintenance of any products purchased from DSC. Custom products are only warranted to
the extent that they do not function upon delivery. In such cases, DSC can replace or credit at its option.
International Warranty
The warranty for international customers is the same as for any customer within Canada and the United States, with the exception that Digital Security Con-
trols shall not be responsible for any customs fees, taxes, or VAT that may be due.
Warranty Procedure
To obtain service under this warranty, please return the items) in question to the point of purchase. All authorized distributors and dealers have a warranty pro-
gram. Anyone returning goods to Digital Security Controls must first obtain an authorization number. Digital Security Controls will not accept any shipment
whatsoever for which prior authorization has not been obtained.
Conditions to Void Warranty
This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover:
• damage incurred in shipping or handling;
• damage caused by disaster such as fire, flood, wind, earthquake or lightning;
• damage due to causes beyond the control of Digital Security Controls such as excessive voltage, mechanical shock or water damage;
• damage caused by unauthorized attachment, alterations, modifications or foreign objects;
• damage caused by peripherals (unless such peripherals were supplied by Digital Security Controls);
• defects caused by failure to provide a suitable installation environment for the products;
• damage caused by use of the products for purposes other than those for which it was designed;
• damage from improper maintenance;
• damage arising out of any other abuse, mishandling or improper application of the products.
Items Not Covered by Warranty
In addition to the items which void the Warranty, the following items shall not be covered by Warranty: (i) freight cost to the repair centre; (ii) products which
are not identified with DSC's product label and lot number or serial number; (iii) products disassembled or repaired in such a manner as to adversely affect per-
formance or prevent adequate inspection or testing to verify any warranty claim. Access cards or tags returned for replacement under warranty will be credited
or replaced at DSC's option. Products not covered by this warranty, or otherwise out of warranty due to age, misuse, or damage shall be evaluated, and a repair
estimate shall be provided. No repair work will be performed until a valid purchase order is received from the Customer and a Return Merchandise Authorisa-
tion number (RMA) is issued by DSC's Customer Service.
Digital Security Controls’s liability for failure to repair the product under this warranty after a reasonable number of attempts will be limited to a replacement
of the product, as the exclusive remedy for breach of warranty. Under no circumstances shall Digital Security Controls be liable for any special, incidental, or
consequential damages based upon breach of warranty, breach of contract, negligence, strict liability, or any other legal theory. Such damages include, but are
not limited to, loss of profits, loss of the product or any associated equipment, cost of capital, cost of substitute or replacement equipment, facilities or services,
down time, purchaser’s time, the claims of third parties, including customers, and injury to property. The laws of some jurisdictions limit or do not allow the
disclaimer of consequential damages. If the laws of such a jurisdiction apply to any claim by or against DSC, the limitations and disclaimers contained here
shall be to the greatest extent permitted by law. Some states do not allow the exclusion or limitation of incidental or consequential damages, so that the above
may not apply to you.
Disclaimer of Warranties
This warranty contains the entire warranty and shall be in lieu of any and all other warranties, whether expressed or implied (including all implied warranties
of merchantability or fitness for a particular purpose) and of all other obligations or liabilities on the part of Digital Security Controls. Digital Security Controls
neither assumes responsibility for nor authorizes any other person purporting to act on its behalf to modify or to change this warranty, nor to assume for it any
other warranty or liability concerning this product.
This disclaimer of warranties and limited warranty are governed by the laws of the province of Ontario, Canada.
WARNING: Digital Security Controls recommends that the entire system be completely tested on a regular basis. However, despite frequent testing, and due
to, but not limited to, criminal tampering or electrical disruption, it is possible for this product to fail to perform as expected.
Out of Warranty Repairs
Digital Security Controls will at its option repair or replace out-of-warranty products which are returned to its factory according to the following conditions.
Anyone returning goods to Digital Security Controls must first obtain an authorization number. Digital Security Controls will not accept any shipment whatso-
ever for which prior authorization has not been obtained.
Products which Digital Security Controls determines to be repairable will be repaired and returned. A set fee which Digital Security Controls has
predetermined and which may be revised from time to time, will be charged for each unit repaired.

Émetteur-récepteur sans fil bidirectionnel
HSM2HOST
V1.0 Manuel d'installation
AVERTISSEMENT : Le présent manuel contient des
informations relatives aux limitations concernant
l'utilisation et les fonctionnalités du produit ainsi que
les limitations de la responsabilité du fabricant. Lisez
attentivement le manuel dans son intégralité.
17

18
Spécifications et caractéristiques
• Courant absorbé : 60 mA
• Tension : Alimente en courant la centrale d'alarme PowerSeries Neo (de 10,8 V CC à 12,5 V CC)
• Fréquence : 433 MHz (HSM2HOST4), 868 MHz (HSM2HOST8), 912-919 MHz
(HSM2HOST9UL)
• Zones : peut recevoir les signaux de 128 zones sans fil, plus 16 pavés numériques sans fil. Prend en
charge aussi jusqu'à 32 clés sans fil
• Supervision : fenêtre de supervision programmable
• Emplacement :
• peut être câblé jusqu'à 230 m / 1000 pieds de la centrale avec un câble de calibre 22 AWG
• se connecte au bus Corbus
• Compatibilité : L'émetteur-récepteur HSM2HOST est utilisé avec les centrales d'alarme
PowerSeries Neo
• Température de fonctionnement : de 0°C à +49°C (de 32 à 122°F)
• Taux d'humidité relative : 93%, sans condensation
• Contacts anti-sabotage séparés de boîtier et à montage mural intégré
REMARQUE: Pour les installations anti-intrusion commerciales (UL), la fenêtre de
supervision doit être de 4 heures.
Pour les installations anti-incendie résidentielles (UL/ULC), la fenêtre de supervision doit être de
200 secondes.
Pour les installations anti-intrusion résidentielles (UL/ULC), la fenêtre de supervision doit être de
24 heures.
Pour les applications de santé domestique UL, la fenêtre de supervision doit être de 24 heures
Seuls les modèles fonctionnant dans la plage 912-919 MHz sont homologués UL/ULC si précisé.
Seuls les dispositifs approuvés UL sont utilisables avec les systèmes homologués UL/ULC.
Dispositifs sans fil compatibles
Veuillez consulter les feuillets d'instructions des dispositifs suivants pour plus d'information. Dans le
tableau ci-dessous et tout au long de ce document, la lettre x dans le numéro de modèle représente la
fréquence de fonctionnement du dispositif comme suit : 9 (912-919 MHz), 
8 (868 MHz), 4 (433 MHz).
Le module HSM2HOSTx (x=4/8/9) peut recevoir les signaux des dispositifs suivants :
Centrale d'alarme
Centrales d'alarme PowerSeries Neo HS2128
HS2064
HS2032
HS2016
Modules
Pavés numériques sans fil HS2LCDWFx
HS2LCDWFPx
HS2LCDWFPVx

19
Dispositifs sans fil
Détecteur de fumée PG sans fil PGx926UL
Détecteur de fumée et détecteur
thermique PG sans fil PGx916UL
Détecteur de gaz CO PG sans fil PGx913
Détecteur de mouvement PG sans fil PGx904(P)UL
Détecteur de mouvement IPR PG sans
fil + caméra PGx934(P)UL
Détecteur de mouvement à rideaux PG
sans fil PGx924UL
Détecteur de mouvement à double
technologie PG sans fil PGx984(P)
Détecteur de mouvement à miroir PG
sans fil PGx974(P)UL
Détecteur de mouvement extérieur PG
sans fil PGx994UL
Détecteur de bris de glace PG sans fil PGx912
Détecteur de chocs PG sans fil PGx935UL
Détecteur d'inondation PG sans fil PGx985UL
Détecteur de température PG sans fil
(intérieur) PGx905UL
Clé PG sans fil PGx939UL
Clé PG sans fil PGx929UL
Clé de demande d'aide PG sans fil PGx938UL
Clé à 2 boutons PG sans fil PGx949UL
Sirène intérieure PG sans fil PGx901UL
Sirène extérieure PG sans fil PGx911UL
Répétiteur PG sans fil PGx920UL
Contact de porte / fenêtre PG sans fil PGx975UL
Contact de porte / fenêtre PG sans fil
avec sortie AUX PGx945UL
