NES S Series User manual

series S
Vertical and Horizontal Modifications
150 L, 200 L, 300 L, 400 L, 500 L,
750 L, 1000 L, 1500 L, 2000 L
SOLAR WATER HEATERS
INSTALLATION
and OPERATION MANUAL
Version 2.0
SN -
with one coil
SОN -
with two coils
SEL -
without coil

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
2
Table of contents
1. INSTRUCTION TO INSTALLER ................................................................................ 3
2. DESCRIPTION OF WATER TANK ............................................................................ 4
.
3. CONNECTING OF SAFETY RELIEF VALVE TO WATER TANK......................................5
4. ANTI-CORROSION PROTECTION -MAGNESIUM ANODE........................................5
5. TECHNICAL PARAMETERS - VERTICAL MODIFICATIONS........................................ 6
5.1. SEL - withhout coil..................................................................................................6
5.2. SN - with one coil....................................................................................................8
5.3. SОN - with two coils................................................................................................10
5.4. SОN PRL- with parallel coils....................................................................................12
6. TECHNICAL PARAMETERS - HORIZONTAL MODIFICATIONS............................... 13
6.1. H SEL - without coil...............................................................................................13
6.2. H SN - with one coil...............................................................................................14
6.3. H SОN - with two coils..........................................................................................15
7. TRANSPORT AND PACKAGING ............................................................................ 16
8. WARRANTY.................................................... ......................................................16
.
9. RECYCLING AND WASTE DISPOSAL...................................................................... 18

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
3
• Thermal insulation of the room. This provides
efficiency of the appliance and prevents the
water from freezing.
1.2. Requirements for installaon
• The length of connecng pipes between the
water tank and consumer must be as short as
possible.
• Before connecng the boiler to the
installaon, check all screw connecons (bolt
inspecon cover ange, plug and anode).
In very rare cases - during transportaon,
loading and unloading operaons - the screw
connecons may be loosen.
• The ghtening torque for anges is around
160-190 Nm.
• Before commissioning, check the installaon
for leaks
• Do not exceed the working pressure of 8 bar.
• If there is a risk of freezing of water in the
tank - drain the tank completely or let the
water heater works connuously.
• Pressure regulator. In case of pressure in
the water supply network above 5 bar, it is
desirable to install a pressure regulator at
the inlet of cold water. We recommend that
the controller be set to 4 bars, thus ensuring
the correct operaon of the product and its
opmum service life.
• Expansion vessel. We recommend installing
an expansion vessel to absorb water expansion
when heated.
The volume and type are determined by a
qualied designer in accordance with the
technical data of the boiler, the system in place
and the local and European safety standards!
Installaon is carried out by a qualied
technician in accordance with his operang
instrucons.
• Drain connecon (hose) of safety valve.
When the boiler is running, in some cases it
is possible to release a small amount of water
from the relief valve as a result of a linear
expansion of the water. For this reason, it is
necessary to build a diversionary connecon,
which is to be comply with local and European
standards and safety provisions! It must be of
sucient inclinaon for water drainage. Both
ends must be open to the atmosphere and be
provided with an-freeze. At pipe installaon,
Dear Customers,
We strongly hope that the appliance you
have bought from us will contribute to creating
comfort at you homes and decreasing the
energy expenditure.
This manual contains important information
for the safe and correct installation, start-up
and trouble-free operation and maintenance
of the water heater.
The water heater can be used for producing of
domestic hot water (DHW) only in the manner
described in this manual.
The application and any other was the area
of operation is not recommended by the
manufacturer and is not responsible for the
occurrence of defects or failures.
1. INSTRUCTION TO INSTALLER
The preparation, installation and
commissioning must be performed
by an authorized installer / service.
During installation and operation, the country
specific requirements and regulations must be
observed:
• local construction regulations on installation
of water tank; weight of the boiler to comply
with the stability of the floor of the room
where it will be installed.
• regulations and norms concerning the fitting
of theinstallation with safety devices.
• safety during installation - personal
protective equipment
iUse only original parts
1.1. Requirements to water tank installation
room
When choosing a room for tank installation
observe the following requirements:
• to have a drainage channel. Some
maintenance procedures require draining of
all water from the tank.

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
4
take safety measures from valve ring burns.
1.3. Requirements for periodic maintenance.
Over me, limestone is deposited
during the operaon of the product
under the inuence of high temperature
(so-called scale). Therefore, we recommend
that the product be serviced by an authorized
service center every two years. The prophylaxis
must include inspecon and cleaning of the
anode protector, which is replaced with a new
one if necessary. The performed prophylaxis is
reected in the warranty card of the product.
2. DESCRIPTION OF WATER TANK.
The water heaters S series are used for
producing of domesc hot water (DHW).
SEL models, the heat source is an electric
heater.
SN models have a built-in heat exchanger (coil
type) designed to connect to a solar installaon
or boiler. Opon for installaon of an electric
heang element.
SON models have two built-in heat exchanger
(coil type) for connecon to the solar system
and boiler. Opon for installaon of an electric
heang element.
Product features:
• Floor standing
• Vercal or Horizontal modicaons
• High eciency insulaon and outer casing of
PVC
• Complex corrosion protecon realized
by means of tanium enamel and anode
protecon
• All threads are internal
• Convenient inspecon opening
• Outlet / Outlets for installaon of one or
more electric heang elements
• The heat exchanger/s ( SN / SON) enables the
tank to ulize an external
• sources of renewable energy, such as a solar
system and a biomass boiler
• Easy installaon
2.1. Water tank.
Water tank is made of low-carbon steel S235JR,
ghtly covered with tanium enamel on the
inside. It is then baked to produce a smooth
and uniform deposion - free glazing. Thus
the domesc hot water remains clean, and the
water tank is protected against corrosion.
All threads are internal (see technical
parameters).
2.2. Electric heang element -
(opon).
Outlet connection of electric heating element
1 ½“ :
3000W/230V; 4500W/230V;
6000W/230V; 7500W/400V.

The connection of the electric
heating element to the electric power
supply must be done by a qualified
electricians.
When connect the heating element
to the electric network, make sure
that it is properly grounded.
CONNECTIONS SCHEMES
Water tank
Capacity, L
Length
L, mm
Current,
W
Voltage,
V
150 ÷ 2000 210 3000 230
300 ÷ 2000 320 4500 230
400 ÷ 2000 410 6000 230
500 ÷ 2000 590 7500 230/400

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
5
Screws with rubber heads are mounted at the
bottom of the vertical water tank / 150 to 500
l / - use to level the tank.
3. CONNECTING OF SAFETY RELIEF VALVE
TO WATER TANK
Legend:
1. Cold water inlet-water supply
2. Check (return) valve
3. Tee
4. Safety (relief) pressure valve
5. Cold water inlet - water tank
6. Stopcock (drainag)

Stop (Shut-off) valves should never
be installed between a safety (relief)
valve and the tank.
It is recommended once a year to
check the operation of the safety
valve.
4. ANTI-CORROSION PROTECTION -
MAGNESIUM ANODE
The magnesium anode protector protects
from corrosion of the inner
surface of the water tank.
Over time, during the operation of the product
under the influence of high temperature,
limestone (so-called scale) is deposited.
Therefore, we recommend that the product
be serviced by an authorized service center
every two years. The prophylaxis must include
inspection and cleaning of the anode protector,
which is replaced with a new one if necessary.
The performed prophylaxis is reflected in the
warranty card of the product.
2.3. Thermostat (opon).
The double protecon thermostat has
a control range from 30 ° C to 80 ° C,
operang temperature 95 degrees.
The THERMOSTAT provides temperature
control and safety tolerance with manual
adjustment (TLSC model) and automac
adjustment (TLSC / A model).

WARNING!
All installation operations, including
manual adjustments, must be
fulfilled by a qualified specialist
following all safety conditions.
2.4. Screws with rubber head

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
6
5. TECHNICAL PARAMETERS - VERTICAL MODIFICATIONS
5.1. SEL - withhout coil.
SEL 150 SEL 200 SEL 300 SEL 400 SEL 500
Capacity L 150 200 300 400 500
Height / Min. vercal clearance H, mm 1070/1210 1340/1460 1420/1580 1490/1670 1720/1890
Diameter D, mm Ø 560 Ø 560 Ø 660 Ø 750 Ø 750
Insulaon 50 mm rigid PPU
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13 13
Electric heang element (oponal) kW 2 х (3÷6) 2 x (3÷6) 2 x (3÷6) 2 x (3÷7.5) 1 x (3÷7.5)
Weight kg 50 68 86 123 140
Cold water inlet A, mm Rp1”/202 Rp1”/202 Rp1”/215 Rp11/4”/270 Rp11/2”/270
Hot water outlet B, mm Rp1”/895 Rp1”/1112 Rp”/1182 Rp11/4”/1204 Rp11/2”/1453
Recirculaon R, mm Rp3/4”/788 Rp3/4”/987 Rp3/4”/1055 Rp1”/1005 Rp1”/1250
Sensor sleeve for thermostat G, mm, Rp1/2” 788 900 1008 950 1208
Air vent sleeve F, mm, Rp” 1070 1340 1410 1480 1710
Inspecon opening/Flange O, mm,
Ø, mm
180/309
Ø 110
180/309
Ø 110
180/320
Ø 110
180/450
Ø 110
180/450
Ø 110
Drain sleeve Y, mm, Rp” 20 20 20 20 20
Thermometer T, mm, Rp1/2” 895 1138 1170 1204 1453
Anode P, mm, Rp1/4” 1070 1340 1410 1079 1340
Sleeve for Electric element
on water tank body
U, mm, Rp11/2” /630 Rp11/2” /750 Rp11/2” /850 Rp11/2” /900 Rp11/2” /1010
Sleeve for Electric element on inspecon
opening ange
Uo, mm, Rp11/2” /309 Rp11/2” /309 Rp11/2” /320 Rp11/2”/450 Rp11/2” /450
Addional sensor sleeve Z, mm - - - - -

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
7
H
2xB
F
Y
G
R
T
2xA
P1
Z
P2
U1
O
UO1
UO2/3
SEL 400-500
SEL 150-300
SEL 750-1000 SEL 1500-2000
D, ø SEL 150-2000
O
H
A
Y
B
F
G
R
P
T
U
UO1
H
A
Y
B
F
G
R
T
O
P
U
UO 1
H
A
Y
B
F
G
R
T
O
P
Z
U1
UO1
SEL 750 SEL 1000 SEL 1500 SEL 2000
Capacity L750 1000 1500 2000
Height / Min. vercal clearance H, mm 2000/2030 2050/2080 2310/2370 2310/2370
Diameter D, mm Ø 950 Ø 1050 Ø 1050 Ø 1350
Insulaon 100 mm so PPU, removable
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13
Electric heang element (oponal) kW 2 x (3÷7.5) 3 x (3÷7.5) 4 x (3÷7.5) 5 x (3÷7.5)
Weight kg 210 245 342 645
Cold water inlet A, mm Rp11/2”/300 Rp11/2”/320 2 х Rp11/2”/320 2 х Rp11/2”/385
Hot water outlet B, mm Rp11/2”/1630 Rp11/2”/1700 2 x Rp11/2”/1975 2 x Rp11/2”/1885
Recirculaon R, mm Rp1”/1405 Rp1”/1487 Rp1”/1487 Rp1”/1635
Sensor sleeve for thermostat G, mm, Rp1/2” 1435 1570 1487 1685
Air vent sleeve F, mm, Rp1” 1945 2020 2320 2311
Inspecon opening/Flange O, mm
Ø, mm
280/450
Ø 200
280/460
Ø 200
280/460
Ø 200
560/555
Ø 400
Drain sleeve Y, mm, Rp1” 20 40 40 30
Thermometer T, mm, Rp1/2” 1630 1700 1975 1835
Anode P, mm, Rp11/4” 1435 1570 2 х 1570/1650 2 х 1625/1705
Sleeve for Electric element
on water tank body
U, mm, Rp11/2” /1040 Rp11/2”/1140 Rp11/2” /1220 2 х Rp11/2” /1330
Sleeve for Electric element on inspecon
opening ange
Uo, mm, Rp11/2” /450 2 x Rp11/2” /460 3 х Rp11/2”/460 3 х Rp11/2” /555
Addional sensor sleeve Z, mm, Rp1/2” 535 520 520 745

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
8
5.2. SN - with one coil
* optional positioning of an electric heater
SN 150 SN 200 SN 300 SN 400 SN 500
Capacity L 150 200 300 400 500
Height / Min. vercal clearance H, mm 1070/1210 1340/1460 1420/1580 1490/1670 1720/1890
Diameter D, mm Ø 560 Ø 560 Ø 660 Ø 750 Ø 750
Insulaon 50 mm rigid PPU
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13 13
Electric heang element (oponal) kW 2 х (3÷6) 2 x (3÷6) 2 x (3÷6) 2 x (3÷7.5) 2 x (3÷7.5)
Weight kg 59 73 104 145 167
Cold water inlet A, mm Rp1”/202 Rp1”/202 Rp1”/215 Rp11/4”/270 Rp11/2”/270
Hot water outlet B, mm Rp1”/868 Rp1”/1140 Rp1”/1170 Rp11/4”/1204 Rp11/2”/1453
Recirculaon R, mm Rp3/4”/450 Rp3/4”/500 Rp3/4”/663 Rp1”/673 Rp1”/831
Oper. pressure / max. Coil temp.S1 bar/0C16/110 16/110 16/110 16/110 16/110
Test pressure S1 bar 25 25 25 25 25
Coil capacity S1 L 4.56 5.55 7.40 9.25 11.10
Heat exchange surface S1 m20.74 0.9 1.2 1.5 1.8
Coil inlet S1i, mm, Rp1” 592 692 805 850 960
Coil outlet S1o, mm, Rp1” 202 202 215 270 270
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S1
kW (m3/h) 25(0.61) 29(0.71) 53(1.30) 62(1.52) 72(1.77)
NL – power coecient at 60°C, S1 NL 60°C 2.5 4.5 11 13 18
Pressure drop Δp, S1 Δp, mbar 65 75 120 180 210
Sensor sleeve for thermostat G, mm, Rp1/2” 738 892 995 950 1168
Air vent sleeve F, mm, Rp1” 1070 1340 1410 1480 1710
Inspecon opening/Flange O, mm,
Ø, mm
180/309
Ø 110
180/309
Ø 110
180/320
Ø 110
180/450
Ø 110
180/450
Ø 110
Drain sleeve Y, mm, Rp1” 20 20 20 20 20
Thermometer T, mm, Rp1/2” 868 1138 1170 1204 1453
Anode P, mm, Rp11/4” 1070 1340 1410 1079 1340
Sleeve for Electric element on water tank body U, mm, Rp11/2” /680 Rp11/2”/850 Rp11/2” /850 Rp11/2”/900 Rp11/2” /1130
Sleeve for El. element on inspecon opening ange Uo, mm, Rp11/2” /309 Rp11/2”/309 Rp11/2” /320 Rp11/2”/450 Rp11/2” /450
Addional sensor sleeve Z, mm, Rp1/2” 422 392 407 450 568

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
9
SN 750 SN 1000 SN 1500 SN 2000
Capacity L750 1000 1500 2000
Height / Min. vercal clearance H, mm 2000/2030 2050/2080 2310/2370 2310/2370
Diameter D, mm Ø 950 Ø 1050 Ø 1050 Ø 1350
Insulaon 100 mm so PPU, removable
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13
Electric heang element (oponal) kW 2 х (3÷7.5) 4 x (3÷7.5) 5 x (3÷7.5) 5 x (3÷7.5)
Weight kg 242 286 392 712
Cold water inlet A, mm Rp11/2”/300 Rp11/2”/320 2 х Rp11/2”/320 2 х Rp11/2”/385
Hot water outlet B, mm Rp11/2”/1630 Rp11/2”/1700 2 х Rp11/2”/1975 2 х Rp11/2”/1885
Recirculaon R, mm Rp1”/1405 Rp1”/1487 Rp1”/1487 Rp1”/1635
Oper. pressure / max. Coil temp.S1 bar/0C16/110 16/110 16/110 16/110
Test pressure S1 bar 25 25 25 25
Coil capacity S1 L 12.95 16.65 18.50 25.28
Heat exchange surface S1 m22.1 2.7 3 4.1
Coil inlet S1i, mm, Rp1” 970 1070 1170 1265
Coil outlet S1o, mm, Rp1” 300 320 320 385
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S1
kW (m3/h) 80(1.97) 105(2.58) 131(3.22) 180(4.42)
NL – power coecient at 60°C, S1 NL 60°C 32 42 64 80
Pressure drop Δp, S1 Δp, mbar 210 260 310 420
Sensor sleeve for thermostat G, mm, Rp1/2” 1435 1487 1487 1685
Air vent sleeve F, mm, Rp1” 1950 2020 2320 2311
Inspecon opening/Flange O, mm,
Ø, mm
280/450
Ø 200
280/460
Ø 200
280/460
Ø 200
560/555
Ø 400
Drain sleeve Y, mm, Rp1” 20 40 40 30
Thermometer T, mm, Rp1/2” 1630 1700 1975 1835
Anode P, mm, Rp11/4” 1435 1570 2 х 1570/1650 2 х 1625/1705
Sleeve for El. element on water tank body U, mm, Rp11/2” /1040 2 х Rp11/2” /1145 2 х Rp11/2”/1220 2 х Rp11/2”/1330
Sleeve for El. element on inspecon opening ange Uo, mm, Rp11/2” /450 2 х Rp11/2” /460 3 х Rp11/2” /460 3 х Rp11/2”/555
Addional sensor sleeve Z, mm, Rp1/2” 535 520 520 745
* optional positioning of an electric heater
2xA
2xB
F
Y
G
R
T
P1
Z
P2
U1
U2
O
UO1
UO2/3
S1i
S1o
H
SN 750-1000 SN 1500-2000
H
Y
B
F
G
R
T
P
Z
A
U1
U2
O
UO1
S1i
S1o

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
10
5.3. SОN - with two coils.
SON 150 SON 200 SON 300 SON 400 SON 500
Capacity L 150 200 300 400 500
Height / Min. vercal clearance H, mm 1070/1210 1340/1460 1420/1580 1470/1670 1720/1890
Diameter D, mm Ø 560 Ø 560 Ø 660 Ø 750 Ø 750
Insulaon 50 mm rigid PPU
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13 13
Electric heang element (oponal) kW 2 х (3÷6) 2x (3÷6) 2 x (3÷6) 2 x (3÷7.5) 2 x (3÷7.5)
Weight kg 65 82 118 160 185
Cold water inlet A, mm Rp1”/202 Rp1”/202 Rp1”/215 Rp11/4”/270 Rp11/2”/270
Hot water outlet B, mm Rp1”/1070 Rp1”/1168 Rp1”/1182 Rp11/4”/1240 Rp11/2”/1453
Recirculaon R, mm Rp3/4”/788 Rp3/4”/987 Rp3/4”/957 Rp1”/1105 Rp1”/1206
Operang pressure / Max.Coils temp. S1/S2 bar/0C16/110 16/110 16/110 16/110 16/110
Test pressure S1/S2 bar 25 25 25 25 25
Coil capacity S1/S2 L4.56/2.47 5.55/3.70 7.40/5.55 9.25/6.17 11.10/7.40
Heat exchange surface S1/S2 m20.74/0.4 0.9/0.6 1.2/0.9 1.5/1 1.8/1.2
Lower coil inlet S1 S1i, mm, Rp1” 592 692 805 850 960
Lower coil outlet S1 S1o, mm, Rp1” 202 202 215 270 270
Upper coil inlet S2 S2i, mm, Rp1” 874 1112 1170 1210 1350
Upper coil outlet S2 S2o, mm, Rp1” 674 812 894 952 1062
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C S1
kW (m3/h) 25(0.61) 29(0.71) 53(1.30) 62(1.52) 72(1.77)
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S2
kW (m3/h) 15(0.37) 18(0.44) 21(0.52) 27(0.66) 34(0.84)
NL – power coecient at 60°C, S1/S2 NL 60°C 2.5/1 4.5/1.5 11/2 13/2.2 18/2.8
Pressure drop Δp, S1/S2 Δp, mbar 65/48 75/55 120/70 180/80 210/90
Sensor sleeve for thermostat G, mm, Rp1/2” 788 1037 1104 1054 1206
Air vent sleeve F, mm, Rp1” 1070 1340 1410 1480 1710
Inspecon opening/Flange O, mm,
Ø, mm
180/309
Ø 110
180/309
Ø 110
180/320
Ø 110
180/450
Ø 110
180/450
Ø 110
Drain sleeve Y, mm, Rp1” 30 30 30 30 30
Thermometer T, mm, Rp1/2” 892 1138 1170 1152 1453
Anode P, mm, Rp11/4” 1070 1340 1410 1337 1568
Sleeve for El. element on water tank body U, mm, Rp11/2” /752 Rp11/2” /645 Rp11/2” /852 Rp11/2” /901 Rp11/2” /1111
Sleeve for El. element on inspecon opening ange Uo, mm, Rp11/2” /309 Rp11/2” /309 Rp11/2” /320 Rp11/2”/450 Rp11/2” /450
Addional sensor sleeve Z, mm, Rp1/2” 352/631 302/752 320/852 450/901 450/1011
*optional positioning of an electric heater

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
11
SON 750 SON 1000 SON 1500 SON 2000
Capacity L750 1000 1500 2000
Height / Min. vercal clearance H, mm 2000/2030 2050/2080 2310/2370 2310/2370
Diameter D, mm Ø 950 Ø 1050 Ø 1050 Ø 1350
Insulaon 100 mm so PРU, removable
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13
Electric heang element (oponal) kW 2 х (3÷7.5) 2 x (3÷7.5) 3 х (3÷7.5) 4 x (3÷7.5)
Weight kg 263 315 423 761
Cold water inlet A, mm Rp11/2”/300 Rp11/2”/320 2x Rp11/2”/320 2x Rp11/2”/385
Hot water outlet B, mm Rp11/2”/1630 Rp11/2”/1700 2xRp11/2”/1975 2x Rp11/2”/1885
Recirculaon R, mm Rp1”/1405 Rp1”/1487 Rp1”/1487 Rp1”/1265
Operang pressure / Max.Coils temp. S1/S2 bar/0C16/110 16/110 16/110 16/110
Test pressure S1/S2 bar 25 25 25 25
Coil capacity S1/S2 L 12.95/8.63 16.65/11.72 18.50/15.42 25.28/18.50
ТHeat exchange surface S1/S2 m22.1/1.4 2.7/1.9 3/2.5 4.1/3
Lower coil inlet S1 S1i, mm, Rp1” 970 1080 1180 1635
Lower coil outlet S1 S1o, mm, Rp1” 300 320 320 385
Upper coil inlet S2 S2i, mm, Rp1” 1560 1660 1790 1885
Upper coil outlet S2 S2o, mm, Rp1” 1160 1220 1350 1420
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S1
kW (m3/h) 80(1.97) 105(2.58) 131(3.22) 180(4.42)
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S2
kW (m3/h) 50(1.23) 62(1.52) 74(1.82) 110(2.70)
NL – power coecient at 60°C, S1/S2 NL 60°C 32/10 42/28 64/34 80/55
Pressure drop Δp, S1/S2 Δp, mbar 210/150 260/110 310/260 420/300
Sensor sleeve for thermostat G, mm, Rp1/2” 1435 1487 1487 1685
Air vent sleeve F, mm, Rp1” 1950 2020 2320 2311
Inspecon opening/Flange O, mm,
Ø, mm
280/450
Ø 200
280/460
Ø 200
280/460
Ø 200
560/484
Ø 400
Drain sleeve Y, mm, Rp1” 30 30 30 30
Thermometer T, mm, Rp1/2” 1630 1700 2089 1835
Anode P, mm, Rp11/4” 1728 1798 2 х 2090 2 х 2003
Sleeve for El. element on water tank body U, mm, Rp11/2” /1040 Rp11/2” /1140 2 х Rp11/2” /1220 2 х Rp11/2” /1340
Sleeve for El. element on inspecon opening ange Uo, mm, Rp11/2” /450 Rp11/2” /460 Rp11/2” /460 2 х Rp11/2”/484
Addional sensor sleeve Z, mm, Rp1/2” 535/1040 520/1140 520/1220 745/1340
* optional positioning of an electric heater
SON 750-1000
H
Y
F
G
R
T
P
Z2
A
U1
U2
Z1
O
UO1
B
S2i
S2o
S1i
S1o 2xA
H
2xB
F
Y
R
T
U1
U2
P
Z2
Z1
G
O
SON 1500-2000
UO1
UO2
S1i
S1o
S2i
S2o

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
12
5.4. SОN PRL - with two parallel coils.
SON PRL 200 SON PRL 300 SON PRL 500
Capacity L 200 300 500
Height / Min. vercal clearance H, mm 1340/1460 1420/1580 1720/1890
Diameter D, mm Ø 560 Ø 660 Ø 750
Insulaon 50 mm rigid PPU
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95
Test pressure of tank bar 13 13 13
Electric heang element (oponal) kW 1 x (3÷6) 1 x (3÷6) 1 x (3÷6)
Weight kg 90 125 196
Cold water inlet A, mm Rp1”/202 Rp1”/214 Rp11/2”/272
Hot water outlet B, mm Rp1”/1138 Rp1”/1182 Rp11/2”/14555
Recirculaon R, mm Rp3/4”/757 Rp3/4”/856 Rp1”/1187
Operang pressure / Max.Coils temp. S1/S2 bar/0C16/110 16/110 16/110
Test pressure S1/S2 bar 25 25 25
Coil capacity S1/S2 L 6.14/3.5 8.9/5.36 12.6/8.0
ТHeat exchange surface S1/S2 m20.9/0.5 1.35/0.8 1.9/1.2
Lower coil inlet/outlet S1 S1i/ S1o, mm, Rp1” 982/207 1085/214 1312/272
Upper coil inlet/outlet S2 S2 i/ S2o i,mm, Rp1” 857/402 960/414 1187/550
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S1/S2
kW (m3/h) 29(0.71)/ 18(0.44) 58(1.42)/25(0.61) 72(1.77)/ 34(0.84)
NL – power coecient at 60°C, S1/S2 NL 60°C 4.5/1.3 10/1.8 28/2.8
Pressure drop Δp, S1/S2 Δp, mbar 75/55 150/65 210/90
Sensor sleeve for thermostat G, mm, Rp1/2” 1037 1103 1208
Air vent sleeve F, mm, Rp1” 1340 1420 1720
Inspecon opening/Flange O, mm,
Ø, mm
180/309
Ø 110
180/319
Ø 110
180/452
Ø 110
Drain sleeve Y, mm, Rp1” 30 30 30
Thermometer T, mm, Rp1/2” 1138 1170 1455
Anode P, mm, Rp11/4” 1340 1420 1572
Sleeve for Electric element on water tank body U, mm, Rp11/2” Rp11/2” /645 Rp11/2” /852 Rp11/2” /1111
Sleeve for El. element on inspecon opening ange Uo, mm, Rp11/2” 309 320 452
Addional sensor sleeve Z1/Z2, mm, Rp1/2” 302/752 320/852 452/1013

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
13
6. TECHNICAL PARAMETERS - HORIZONTAL MODIFICATIONS.
6.1. H SEL - without coil.
HSEL 200 HSEL 300 HSEL 500 HSEL 1000 HSEL 1500
Capacity (L) 200 300 500 1000 1500
Height / Length H, L, mm 695/1340 790/1340 890/1710 1190/2080 1190/2380
Diameter D, mm Ø 560 Ø 660 Ø 750 Ø 1050 Ø 1050
Insulaon 50 mm rigid PPU 100 mm so PРU, removable
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13 13
Electric heang element (oponal) kW 2 x (3÷7.5) 2 x (3÷7.5) 2 x ( 3÷7.5) 3 x (3÷7.5) 4 x (3÷7.5)
Weight kg 68 86 140 245 342
Cold water inlet A, mm Rp1”/220 Rp1”/260 Rp11/2”/270 Rp11/2”/370 Rp11/2”/360
Hot water outlet B, mm Rp1”/220 Rp1”/260 Rp11/2”/270 Rp11/2”/320 Rp11/2”/320
Recirculaon R, mm Rp1”/420 Rp1”/465 Rp1”/515 Rp1”/665 Rp1”/665
Sensor sleeve for thermostat G, mm, Rp1/2” 220 260 270 370 580
Inspecon opening/Flange O, mm,
Ø, mm
180/420
Ø 110
180/465
Ø 110
180/515
Ø 110
280/665
Ø 200
280/665
Ø 200
Thermometer T, mm, Rp1/2” 220 260 270 370 580
Anode P, mm, Rp11/4” 320 360 370 470 2 x 680/770
Sleeve for Electric element
on water tank body
U, mm, Rp11/2” Rp11/2” /195 Rp11/2” /258 Rp11/2” /245 2 x Rp11/2” /280 2 x Rp11/2” /280
Sleeve for Electric element on
inspecon opening ange
Uo, mm, Rp11/2” Rp11/2” /420 Rp11/2” /465 Rp11/2” /515 Rp11/2” /665 Rp11/2” /665
Addional sensor sleeve Z, mm, Rp11/2” - - - 370 580

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
14
6.2. H SN - with one coil.
HSN
200
HSN
300
HSN
500
HSN
1000
HSN
1500
Capacity (L) 200 300 500 1000 1500
Height / Length H, L, mm 695/1340 790/1410 890/1710 1190/2080 1190/2380
Diameter D, mm Ø 560 Ø 660 Ø 750 Ø 1050 Ø 1050
Insulaon 50 mm rigid PPU 100 mm so PРU, removable
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13 13
Electric heang element (oponal) kW 2 x (3÷7.5) 2 x (3÷7.5) 2 x (3÷7.5) 2 x (3÷7.5) 3 x (3÷7.5)
Weight kg 73 104 167 286 392
Cold water inlet A, mm Rp1”/220 Rp1”/260 Rp11/2”/270 Rp11/2”/360 Rp11/2”/360
Hot water outlet B, mm Rp1”/220 Rp1”/260 Rp11/2”/270 Rp11/2”/340 Rp11/2”/340
Recirculaon R, mm Rp1”/420 Rp1”/465 Rp1”/515 Rp1”/665 Rp1”/665
Oper. pressure / max. Coil temp.S1 bar/0C16/110 16/110 16/110 16/110 16/110
Test pressure S1 bar 25 25 25 25 25
Coil capacity S1 L 5.55 7.40 11.10 16.65 18.50
Heat exchange surface S1 m20.9 1.2 1.8 2.7 3
Coil inlet S1i, mm, Rp1” 692 805 960 1080 1180
Coil outlet S1o, mm, Rp1” 202 215 270 320 320
Prolonged power acc. to DIN 4708;
80°C/60°C/45°C, S1
kW (m3/h) 29(0.71) 53(1.30) 72(1.77) 105(2.58) 131(3.22)
NL – power coecient at 60°C, S1 NL 60°C 4.5 11 18 42 64
Pressure drop Δp, S1 Δp, mbar 260 260 310 260 310
Sensor sleeve for thermostat G, mm, Rp1/2” 220 260 270 360 360
Inspecon opening/Flange O, mm,
Ø, mm
180/420
Ø 110
180/465
Ø 110
180/515
Ø 110
280/665
Ø 200
280/665
Ø 200
Thermometer T, mm, Rp1/2” 220 260 270 360 580
Anode P, mm, Rp11/4” 320 360 370 460 2 x 690/770
Sleeve for Electric element
on water tank body
U, mm, Rp11/2” Rp11/2” /240 Rp11/2” /238 Rp11/2” /245 Rp11/2” /280 2 x Rp11/2” /280
Sleeve for Electric element on inspecon
opening ange
Uo, mm,Rp11/2” Rp11/2” /420 Rp11/2” /465 Rp11/2” /515 Rp11/2” /665 Rp11/2” /665
Addional sensor sleeve Z, mm, Rp11/2” - - - 360 580

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
15
6.3. H SОN - with two coils.
HSON
300
HSON
500
HSON
1000
HSON
1500
Capacity (L) 300 500 1000 1500
Height / Length H, L, mm 790/1410 890/1710 1190/2080 1190/2380
Diameter D, mm Ø 660 Ø 750 Ø 1050 Ø 1050
Insulaon 50 mm rigid PPU 100 mm so PРU, removable
Oper. pressure / max. temperature bar/0C8/95 8/95 8/95 8/95
Test pressure of tank bar 13 13 13 13
Electric heang element (oponal) kW 1 x (3÷7.5) 1 x (3÷7.5) 2 x 7.5 3 x 7.5
Weight kg 118 185 315 423
Cold water inlet A, mm Rp1”/260 Rp11/2”/270 Rp11/2”/360 Rp11/2”/360
Hot water outlet B, mm Rp1”/260 Rp11/2”/270 Rp11/2”/320 Rp11/2”/320
Recirculaon R, mm Rp1”/465 Rp1”/515 Rp1”/665 Rp1”/665
Operang pressure / Max.Coils temp. S1/S2 bar/0C16/110 16/110 16/110 16/110
Test pressure S1/S2 bar 25 25 25 25
Coil capacity S1/S2 L7.40/5.55 11.10/7.40 16.65/11.72 18.50/15.42
ТHeat exchange surface S1/S2 m21.2/0.9 1.8/1.2 2.7/1.9 3/2.5
Lower coil inlet/outlet S1 S1i, S1o, mm, Rp1” 535/290 585/325 790/340 790/340
Upper coil inlet/outlet S2 S2i, S2o, mm, Rp1” 697/610 785/655 1005/855 1005/855
Prolonged powe acc. to DIN 4708;
80°C/60°C/45°C S1/S2
S1/S2, kW (m3/h) 53(1.30)/
21(0.52)
72(1.77)/
34(0.84)
105(2.58)/
62(1.52)
131(3.22)/
74(1.82)
NL – power coecient at 60°C, S1/S2 S1/S2, NL 60°C 11/2 18/2.8 42/28 64/34
Pressure drop Δp, S1/S2 S1/S2, Δp, mbar 120/70 210/90 260/210 310/260
Sensor sleeve for thermostat G, mm, Rp1/2” 260 270 360 360
Inspecon opening/Flange O, mm,
Ø, mm
180/465
Ø 110
180/515
Ø 110
280/665
Ø 200
280/665
Ø 200
Thermometer T, mm, Rp1/2” 260 270 360 580
Anode P, mm, Rp11/4” 360 370 460 2 x 690/770
Sleeve for Electric element
on water tank body
U, mm, Rp11/2” Rp11/2” /465 Rp11/2” /515 2 x Rp11/2” /665 2 x Rp11/2” /665
Sleeve for Electric element on inspecon
opening ange
Uo, mm,Rp11/2” Rp11/2” /280
Addional sensor sleeve Z, mm, Rp11/2” - - 360 580

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
16
changes, especially if they are not made by au-
thorized aer-sale service personnel of Man-
ufacturer.
- Tesng and operaon pressures greater
that values established by Manufacturer and
set forth in product manuals, or use of water
with characterisc values exceeding: Dissolv-
able salts – 500 mg/l; Calcium carbonate – 200
mg/l; Free carbon dioxide – 50 mg/l; ph con-
tent – minimum 5 and maximum 12.
8.2.2.) Freeze, ood, natural disasters or third
party acons as well as any intervenons into
normal funconing condions of water heat-
ers and the control of Manufacturer.
The customer as well should monitor the an-
corrosion system (magnesium anodе). He
should periodically check the magnesium an-
ode and replace it depending on the geograph-
ic locaon at intervals depending on the type
of water (so of hard) of the region where the
water heater is being used.
8.2.3.) The warranty cercate is considered
void for water heaters whose serial idenca-
on number has been modied, removed or
blurred, or cannot be expressly aested.
8.2.4. ) Damages in the appearance of prod-
ucts shall not be considered as defects except
for those ones which cause losses during op-
eraon or change technical characteriscs of
water heaters set forth in brochures.
8.2.5.) Manufacturer preserves the right, in
case of replacement, to deliver another mod-
el of water heater in order to fulll approved
warranty claims when the original model is not
being manufactured.
8.3. Claiming warranty
Every customer who has purchased a water
heater from Manufacturer and who has good
reasons to lay a warranty claim, shall proceed
as follows:
8.3.1) Immediately nofy in wring:
- The installer, or the company that has sold
the water heater to him, or
- The distributor rm, or
- The commercial representave of Manufac-
turer in the region.
For this purpose the claimant shall ll out a
claim form; the laer shall be accompanied by
7. TRANSPORT AND PACKAGING
We recommend to transport the water tank to
the installation site in its packaging placed on
the pallet, and stretch foil.
During transport and installation, depending
on the weight, appropriate safety equipment
must be used in accordance with Directive
2006/42/EC.
When transporting items weighing more than
30 kg, the use of pallet jack, fork truck or other
hoisting devices is a must.
8. WARRANTY
8.1. Manufacturing defects and materials
guarantee
Manufacturer expressly guarantees that the
products it manufactures shall be free from de-
fects in materials and workmanship which can
prevent from normal operaon under proper
and normal use, installaon and maintenance
for the intended funcons of the products, for
a period set out in the warranty cercate of
the respecve water heater model you have
bought. The warranty period begins from the
date indicated in the purchase invoice. If a
product or any component there of is deter-
mined to be defecve in manufacture or ma-
terials, Manufacturer will repair or replace the
defecve component or product
8.2. Exclusions and Limitaons of Warranty
Coverage
8.2.1.) The customer can claim warranty
during warranty period of respecve prod-
uct immediately aer any defects have been
determined, except for in case of noceable
defects at the moment of purchase, in which
case the customer must make the claim at the
shop immediately aer nocing the defect as
it is provided for in the general condions of
sale.
- Accidents, installaon on movable struc-
tures, negligence, improper care or noncon-
formity.
- Failure to observe the installaon, use and
maintenance instrucons set forth in the in-
stallaon manual of respecve product.
- Improper installaon and use as well as

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
17
ty for indirect damages such as loss of data at
informaon applicaons, loss of producon,
thermal variaons at the service, etc. which
do not violate the applicable regulaons of any
country concerning product liability.
8.4.3.) Abovemenoned warranty limitaons
will be applied in any cases, and when they do
not violate the regulaons in any country con-
cerning product liability. If this circumstance
annuls some of preceding clauses, annulment
will refer only to this clause, while the others
will remain valid. In conclusion, excluded is ap-
plicaon of any Regulaon pointed out in this
Warranty which violates the Law 23/July 10,
2003 and Direcve 1999/44/EU concerning
water heaters and their use on the territory of
the EU.
8.4.4.) Any other warranty right that is not
menoned in this Warranty Cercate is ex-
cluded.
9. RECYCLING AND WASTE DISPOSAL
Submit all packaging material for recycling
according to the local regulaons and require-
ments.
At the end of life cycle of each product its com-
ponents are due to be disposed of in conform-
ity with regulatory prescripons.
According to Direcve 2002/96/EC regarding
electrical and electronic equipment waste,
disposal thereof is required separately from
the normal ow of solid household waste.
Obsolete equipment shall be collected sepa-
rately from other recyclable waste containing
materials with adverse eect on health and
environment.
Expired appliances must be collected sepa-
rately from other recyclable waste containing
substances hazardous to health and environ-
ment.
Both metal and non-metal parts are sold out
to licensed organizaons for recyclable metal
or non-metal waste collecon. In any case they
should not be treated as household waste.
the document proving the purchase of the wa-
ter heater (invoice) with the date of purchase
in it.
8.3.2.) Aer receiving the claim form, Man-
ufacturer considers it and makes decision
whether the claim has grounds, and whether
the defect is within the scope of the warranty
set forth in this cercate for limited warranty;
aer which informs the customer as to its deci-
sion and the steps he shall do.
8.3.3.) The return of a product cannot be done
without wrien authorizaon issued by the
Quality Department. The return procedure
shall be according to RMA (Return Material Au-
thorizaon).
8.3..4) If on customer’s request, and when
there is reason for urgency, the customer de-
mands immediate replacement of the product
he has claimed warranty for, before making the
decision as to the claim, said request shall be
accompanied by a Purchase requision from
the Commercial Department. Aer decision
for sasfacon of the claim has been made,
the Purchase requision menoned above will
be annulled by issuing a receipt for returned
goods; with this receipt the customer can pur-
chase another product with the same price in
case the claim has proved grounded.
8.3.5) Manufacturer reserves the right to
make in situ reports from the claims they have
received for the purpose of checking every
aspect that might be useful for beer con-
sideraon of warranty claims; for this reason
the customer shall not make any changes in
installaon condions which are reasons for
the claim without prior wrien consent of the
Technical Department.
8.4. Limitaon of liability
8.4.1) Manufacturer is not liable before the
customer, neither directly nor indirectly, for
any non-fulllment or delay at applying the
warranty obligaons which might originate
from external pressure of other circumstances
outside the Manufacturer.
8.4.2.)The liability of Manufacturer under this
Warranty Cercate is limited to the above-
menoned obligaons and up to the sum in
accordance with the purchase receipt of the
product to be claimed; excluded is any liabili-

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
18

INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
19

ISO 9001
BUREAU VERITAS
Certification
tel.: [phone]
www.burnit.bg
